FHD LED/LCD TV
LE42C9FHD
USER MANUAL
IMPORTANT !
WARRANTY INFORMATION INSIDE. PLEASE READ
Trademark of TEAC Corporation JAPAN
www.teac.com.au
Owner’s Name
Owner’s Address
Postcode
Model Name/No. Serial No.
Dealer’s Name
Dealer’s Address
Postcode
Thank you for selecting a TEAC product.
If your TEAC product malfunctions, please call us directly for warranty support
between Monday to Friday at 8.30AM – 5PM AEST at the
TEAC Warranty Service Hotline
1300 553 315
For other enquiries, please contact us at:
www.teac.com.au
When calling to receive warranty service, please have:
1. Your model and serial number
2. Proof of purchase
3. And your product in front of you
NOTE:
- You are required to provide a copy of your proof of purchase in order to have your claim
processed.
- Please read the Terms and Conditions for details of your warranty entitlement.
WARRANTY PROCEDURE
Please read the owner’s manual carefully and ensure that you have followed the correct installation and operating procedures.
1. Please read this warranty card.
2. Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service.
3. If you require Warranty Service, please contact the TEAC Warranty Service Hotline at 1300 553 315 for assistance. Please ensure
that you have the model number, serial number and purchase receipt ready when you call.
Please complete the section below and keep this information for your own records.
v1.6: May 2015
TEAC PRODUCT
excluding commercial use products
SIZE (TV)
WARRANTY PERIOD
from date of purchase
WARRANTY SERVICE TYPE
LED/LCD TV
42” and above
12 months
In-home service*
19” to 40”
12 months
Authorised Service Centre Service
All other TEAC products
N/A
12 months
Authorised Service Centre Service
TERMS AND CONDITIONS
v1.6: May 2015
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
1. TEAC warrants that this product is free from defects in material and workmanship under normal domestic use with reasonable care and skill.
Maintenance and cleaning (i.e. laser head) is not covered by this warranty. The TEAC warranty only applies to TEAC products purchased
NEW from a TEAC Authorised Retailer in Australia. This warranty only applies to the original purchaser and cannot be transferred.
2. The benefits to the consumer given by this Warranty are in addition to other rights and remedies of the consumer under a law in relation to
goods or services to which the warranty relates, being the Australian Consumer Law.
3. Refund or replacement via your TEAC Authorised Retailer is available for a period of 14 days after purchase for goods that have been
inspected and determined to have a major failure. Refund and exchange is not applicable for change of mind.
4. Subject to the terms herein, this warranty effectively covers TEAC products, excluding products purchased for commercial purposes, as
specified in the Warranty Periods Table below from the date of purchase. Commercial use products are covered for 12 months only
(Authorised Service Centre).
5. In Home Service/Pick up* Service
This service will only be provided as part of this warranty if all the following conditions are met;
a) The product is indicated in the Warranty Period Table.
b) The product is within the warranty period.
c) The product is located within the normal service area of the local TEAC Authorised Service Centre.
If TEAC determines that the product is not repairable on site, TEAC can complete the repair by taking the product to a TEAC Authorised
Service Centre.
Authorised Service Centre Service
The purchaser is required to send the product at their own expense to the nearest TEAC Authorised Service Centre for repair. In this event,
proof of purchase is required to support a warranty claim. After the repair, the product will be available for collection by or return to the
purchaser at a fee upon request. TEAC in-home service can be made available at a fee upon request.
6. A 12-month replacement warranty is applicable to all Accessories such as Remotes, Power Adapters and Cables.
7. TEAC will ensure to the best of its abilities that all required parts are made available for any required service/repair.
8. TEAC Australia Pty Ltd and its Authorised Service Centres will use their best endeavours to complete product repairs within a reasonable
period based on available resources and workload during the time when service is requested and performed.
9. Refurbished parts may be used to repair the product. In the case of a replacement, the product may be replaced, with a refurbished unit of the
same type or, if one is unavailable, a similar refurbished model with equal or better features and specifications.
10. Please be advised that if the product presented for repair is capable of retaining user-generated data, the data may be lost during servicing.
Customers are strongly encouraged to back up all important information/data before sending the product in for service/repair.
11. Service will be provided only during normal business hours and under safety conditions and circumstances. TEAC and its authorised service
agents can refuse any repair if safety, in relation to OH&S, becomes a concern to its staff or authorised service agents’ personnel.
12. The warranty is void and warranty claims may be refused, subject to the Australian Consumer Law, if:
a) The product was not transported, installed, operated or maintained according to manufacturer instruction, or
b) The product was abused, damaged, tampered, altered or repaired by any unauthorised persons, or
c) Product failure is due to accidents during use, installation or transit, power surges, use of defective or incompatible external devices, exposure
to abnormal conditions such as excessive temperatures or humidity, or entry of liquids, objects or creatures into the product, cockroach
infestations, or
d) The customer is unable to provide proof of purchase of the product for verification, or
e) The serial number of the product is missing or has been tampered with.
13. Where any repairs or services required that are outside of the terms and conditions of this Warranty are requested by the customer, or where
a fault is determined to be outside of the terms and conditions of the Warranty during an In-Home Service call, the customer shall be charged
for the cost of the repair and/or the In-Home service call fee.
14. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment
other than as stated in this warranty and outlined above.
15. TEAC and/or its Authorised Service Centres reserve the right to inspect and verify whether the product is exhibiting a major failure as claimed
by customers/retailers.
16. LCD dead pixel policy, please contact TEAC at support@teac.com.au for assistance.
Contents
Introduction...............................................................................2
Warning.....................................................................................3
Caution.......................................................................................4
Stand Assembly.........................................................................6
Wall Mounting Installation Guidelines...................................7
Main Unit Description..............................................................8
Remote Control........................................................................10
Basic Operation .......................................................................11
OSD Menu................................................................................13
Multimedia Operation..........................................................................21
Recording Operation..............................................................27
Specifications...........................................................................32
Trouble Shooting.....................................................................33
1
Introduction
Thank you very much for your purchase of our LED TV.
it handy for ready reference.
INSTALLATION
ķ
Locate the
reflection on the picture screen can cause eyestrain. Soft and indirect lighting is recommended for
comfortable viewing.
ĸ
Allow enough space between the receiver and the wall to permit ventilation.
Ĺ
Avoid excessively warm locations to prevent possible damage to the cabinet or premature
component failure.
ĺ
This TV can be connected to 100-240V~ 50/60HZ.
Ļ
Do not install the TV near heat sources such as a radiator, air ducts, direct sunlight, or closed and
confined areas. Do not cover
TV in a room where direct light does not strike the screen. Total darkness or a
the ventilation openings when using the TV.
Read this manual carefully and keep
ļ
The indicator light goes out about 30 seconds after you disconnect the TV from the power supply.
Until the indicator light goes out, you will not be able to power it back on.
2
Warning
CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER- SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to avoid the risk
of electric shock, do not disassemble this equipment by anyone
except a qualified service personnel.
This symbol is intended to alert the user to the presence
of important operating and maintenance instructions in
the literature accompanying the equipment.
Class I structures of equipment should be connected to the grid
power output with a protective earth connection on the socket.
Power plug as a broken applianceˈbroken installations should be
easy to operate.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
3
Caution
Caution
High voltages are used in the operation of this product.
- Do not
To prevent fire or electrical shock hazard, do not expose
the main unit to
open the product's casing. Refer servicing
to qualified service personnel .
Caution
rain or moistureˈdo not place objects
filled with liquids, such as vases, on the apparatus.
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
Caution
television receiver.
Caution
Avoid exposing the main unit to direct sunlight and other
sources of heat. Do not stand the television receiver
directly on other products which give off heat. E. g. video
cassette players, Audio amplifiers. Do not block the
ventilation holes in the back cover. Ventilation is essential
to prevent failure of electrical component. Do not squash
power supply cord under the main
4
unit or other heavy objects.
Caution
Caution
Never stand on, lean on, or push the unit or its stand. Ensure
children are supervised when near the unit.
Caution
Do not place the main unit on an unstable cart stand,
shelf or table. Serious injury to an individual, and
damage to the television, may result if it should fall.
Caution
When the product is not used for an extended period
of time, it is advisable to disconnect the AC power
cord from the AC outlet.
Caution
The LED panel used in this product is made of glass.
Therefore, it can break when the product is dropped
or applied with impact. Be careful not to be injured
by broken glass pieces in case the LED panel breaks.
5
Stand Assembly
1. Attach the stand base set to the bottom of the TV by firmly tightening the supplied 4pcs screws.
2. The TV stand is now assembled.
6
Wall Mounting Installation Guidelines
Screw size for wall mounting: M6 ( The depth of the wall-mount hole is 19mm, please choose a
screw of the appropriate length)
Use the four screws to fix the TV onto a wall mounting bracket ( not included) via the four VESA
standard holes on the back of the television.
Note:
1. Wall Mount is not included with the TV; it needs to be purchased separately.
2. Use only VESA-compatible wall mounts according to the specifications recommended for this
model. Use of other wall mounts, or inappropriate installation may cause personal injuries or
damage to the TV.
3. Follow all instructions from the user manual of your chosen wall mount.
7
Main Unit Description
Control Panel Button Function
VOL+ : Volume up.
VOL- : Volume down.
CH+: TV channel up.
CH- : TV channel down.
MENU : Press to select the main menu.
SOURCE : Select the input signal.
POWER :
Turn the TV on or off.
TV Terminal Connections
4
21
3
5
6 109 117
1. HDMI2/MHL input terminal.
2. HDMI 3 input terminal.
3. USB input terminal.
4. Video input terminal.
5. Audio input terminal.
6. EAR PHONE output terminal.
7. YPb Pr input terminal.
8. PC AUDIO input terminal.
9. VGA input terminal of simulation signal of PC.
10. Coaxial output terminal.
11. RF antenna.
12.. HDMI 1 input terminal.
8
8
11
Optional Configuration as below:
Connect the USB to the USB jack on the set.
NOTE
Ɣ,WLVRQO\P$0$;RI'&FXUUHQWRXWSXWZKHQ\RXFRQQHFWZLWK86%MDFN
Ɣ7RHQVXUH WKH 0RELOH +' ZRUNV ZHOO \RXVKRXOGXVHRWKHUSRZHUVXSSO\IRU WKH0RELOH +'
Ɣ,W VXSSRUWV 0RELOH+' E\ FRQQHFting with USB jack (must more than 2 GB). The partitions of
WKH0RELOH +'FDQ¶WEH PRUHWKDQ SDUWLWLRQV7KH PD[SDUWLWLRQLV 7%,WVXSSRUWV )$7)$7
document. The max FAT document is 4GB and the max FAT32 document is 2TB.
9
RETURN
D.SETUP
D.MENU
OK
A-B GOTO
D.TITLE ASPECT
PMODE
Remote control
: Press this button to Turn the TV on or off.
: Press this button to mute or restore sound.
SMODEINPUT AUDIO
INPUT: Press to change signal source.
AUDIO: Press to select the DTV audio.
(Used for models with DTV function only)
PMODE: Select picture mode.
SMODE: Select sound mode.
0-9: Select and switch to a channel using 0 - 9.
FAV: Switch between customer set " Favorite List"
: Switch back and front between the current and
previous channels.
: Stop playing the Media.
: Press to start playing the MEDIA, or to pause playing.
INFO
(Used for models with MEDIA function only)
: Start to record. (The U disk will be formatted when
in burning , please do not store important files in the U disk)
RED, GREEN, YELLOW, BLUE: Correspond to the
different colored subjects.
EPG: Enter electronic program guide.
(Used for models with DTV function only)
INFO: Press to display the channel information. In teletext
mode,press to reveal the hidden information.
OK: Enter the selected option or execute the selected
operation. NOTE
press this button to display “channel list”
in TV source.
RETURN: Press to return to previous layer.
EXIT: Exit the OSD (On-screen display).
92/Ÿ92/ź Adjust the volume.
&+Ÿ&+źChange the channel up and down.
MENU: Press this button to enter the main menu for various
optional adjustable setting.
SUBTITLE: Open or close subtitle.
: Press to play backward (Used for models with MEDIA function only)
: Press to play forward. (Used for models with MEDIA function only)
: Skip to previous chapter. (Used for models with MEDIA function only)
: Skip to next chapter. (Used for models with MEDIA function only)
GOTO: Jump to the appointed chapter.
ASPECT: Press to adjust picture ratio.
SLEEP: Set the sleep timer.
, D.SETUP, D.MENU, D.TITLE, A-B is Invalid.
10
Basic Operation
First Time Installation
1.The "First Time Installation" menu will appear on your screen.
2. Select Type,OSD Language,Country,Auto Scan,Time Zone then press the OK button to start
the tuning process,This process will find all available channels and store them.
NOTE: Home Mode is a power setting that is
designed to suit home usage and the Energy
Star Rating of this TV is based on Home
Mode. Home Mode is highly recommended
for the best energy efficiency.
Shop Mode is a power setting that is
designed to suit shop display. Energy use is
not optimised and picture settings may reset
automatically.
11
Basic Operation
Selecting an input source
The unit incorporates multiple input sources which can be selected via the
INPUT button on the television panel or remote control. The following
steps explain the procedures involved.
1. Press the INPUT button to enter the Input menu. The screen will
display the Input Source menu.
2. Use the CH+/- button on the TV set or /\ / \/ direction buttons to
select the desired input source.
3. Press OK to enter the selected source.
NOTE: Please make sure the device is connected before selecting the
input source.
Using the On Screen Display Menu
The On Screen Display (OSD) menu acts as the Main Menu and aids the user in browsing
through the different options/properties available on the television unit. Press the MENU
button on the remote control to access the OSD menu as shown below:
Main menu
SOUND
CHANNEL
LOCK
SETUP
Picture Mode
Brightness
Contrast
Sharpness
Saturation
Hue
Color Temp
Red
Submenu
(Picture menu
for example)
Hint---you should operate the OSD menu according to the hint.
Use the </> direction buttons to make a selection from the main menu ( PICTURE,SOUND,
CHANNEL, LOCK, or SETUP ). Press \/ button to enter the submenu system.
Once in the submenu, use \/ //\ buttons to select an item. Press the OK button to access the
selected item to make changes to the settings.
To return to the main menu, press the MENU button.
To exit the menu display, press the EXIT button.
NOTE:
Some menu items can only be activated when the right INPUT selection has been
made (ie, the CHANNEL selection can only be accessed under DTV and ATV input
selections).
12
OSD Menu
1. PICTURE menu
Picture display settings can be altered as desired. The following options are adjustable:
Description
Picture Mode: There are four preset settings to choose from: Standard, Dynamic, Personal and Mild.
Note: Custom settings are saved into Personal Mode.
Brightness: Adjust the overall brightness of the picture.
Contrast: Adjust the difference between the brightest and darkest regions of the picture.
Sharpness: Increase this setting to see Sharp edges in the picture; decrease it for softer edges.
Saturation:
Hue: Controls the tint ( NTSC mode only).
Color Temp: Choose from Stand, Cool, Personal and Warm.
Red: Controls the red colour of the picture.
Green: Controls the green colour of the picture.
Blue: Controls the blue colour of the picture.
Aspect Ratio: Choose from Full, 4:3, Zoom1, Zoom2.
Adjust the saturation of the color based on your own like.
Advanced Settings: Adjust advanced video features to fine tune the picture.
NR:
Set options to reduce video noise from Off, Weak,
Medium, Strong.
MPEG NR:
Dynamic Contrast:
Backlight: Adjust the backlight.
Note: Different aspect ratios are available depending on the input source.
Set options to reduce MPEG noise from Off, Weak,
Medium, Strong.
Available Dynamic Contrast from Off,
Weak, Medium, Strong.
13
OSD Menu
2. SOUND menu
General sound settings can be adjusted according to personal preference with the following
options:
Description
Sound Mode: There are five preset settings to choose from: Standard, Music, Movie, Sports and
User.
Note: Treble and Bass can only be adjusted in User mode.
Treble: Adjust the relative intensity of higher pitched sounds.
Bass: Adjust the relative intensity of lower pitched sounds.
Balance: Adjust the balance of the left and right sound track, or turn off the volume of the
left or right sound track.
Surround Sound: Turn on/off the surround sound function by selecting “off” / “on”.
EQ Setting: Adjuse the curve of 7 bands equalizer.
AVL: Control the volume of the program automatically. Turn on the function by selecting “On”.
SPDIF: Select from the following options: Off, PCM and Auto.
Sound Type: Select from Left, Right, Mixed, Stereo.
14
OSD Menu
3. CHANNEL Menu
This menu selection contains scanning preferences (either automatic or manual tuning),
Channel, Auto Scan, Manual Scan, Channel Edit, Signal Information.
Settings can be altered for individual channels.
NOTE: Some menus are
available only in DTV Mode
while recording is not in
progress.
Description
Press the MENU button once to enter CHANNEL setup menu as shown above. Press OK to enter
the submenu. In the CHANNEL setup menu press the buttons to select the desired item. Press
the MENU button to return to the previous menu. Press the EXIT button to exit.
If Lock is enabled, Auto and Manual Scan are password protected. Key in the correct password.
(Default password: 0000)
Auto Scan
Press OK to enter the auto scan option.
Select the desired Country and Tune Type
using the buttons, then press OK to
start scanning.
NOTE:
ATV+DTV option is selected, the first 50%
If
of the scan will be for ATV tuning, while the
second half would be for DTV tuning. If
desired, the user has the option to exit the
tuning process midway by pressing the
button.
EXIT
15
OSD Menu
Digital Manual Scan
Press the OK button to enter the Digital Manual
Scan menu.
Select a DTV channel, and press OK to start
searching.
Frequency:
Auto or enter digital numbers.
Strength:
Note: DTV is able to receive DVB-T signal, not
DVB-T2 signal.
Analog Manual Scan
Press the OK button to enter the Analog Manual
Scan menu.
Analog Scan
Channel to Save: Select a channel number.
Color/Sound System: Select a TV system for
AFC:
Star
NOTE:
Press the RED button to save any changes to the settings.
Channel Edit
The Channel Edit menu offers the user to make personal changes to the program listings.
Various options are subjective to Analog TV and Digital TV programs. Press the OK button
to enter the Channel Edit menu from the CHANNEL menu as shown below.
Press buttons to select Frequency:
Displays the signal strength.
: Press buttons to select frequency.
searching.
Turn on/off the auto frequency control function.
: Press buttons to manual search.
If Lock is enabled, Channel Edit is password
protected. Key in the correct password.
(Default password: 0000)
16
OSD Menu
Delete :
Move:
Skip:
Favorite Manager
)LUVWSUHVVźŸEXWWRQWRKLJKOLJKWDGHVLUHGFKDQQHO
3UHVVWKH5HGEXWWRQWRVHWLWWRWKH)DYRXULWHJURXS
3UHVVWKH*UHHQEXWWRQWRVHWLWWRWKH)DYRXULWHJURXS
3UHVVWKH<HOORZEXWWRQWRVHWLWWRWKH)DYRXULWHJURXS
3UHVVWKH%OXHEXWWRQWRVHWLWWRWKH)DYRXULWHJURXS
Signal Information
'LVSOD\VWKHVLJQDOLQIRUPDWLRQLQ'79PRGH
Select the channel to delete and press the
Choose “Yes” to confirm the deletion, or “No” to cancel.
Select the channel to be moved and press the BLUE button. Use the CH+/- buttons to
change the channel position. Press the BLUE button again to confirm the change. Press
the MENU button to save and exit.
Select a channel and press the GREEN button to mark the channel. As long as the channel has
a skip label, it will be skipped when you search through the channels with the CH+/- buttons.
RED button. A confirmation message will pop up.
17
OSD Menu
4. LOCK menu
This option allows parents to block channels and programs using a password.
NOTE: The default password is 0000. If you have forgotten your current password, the
master password is 8899. Please take note of this.
Description
Enable: Turn on/off the Lock Channel function.
Note: You are required to enter a password to access this menu. (Default password is 0000).
Channel Locks: When a channel is locked, you must enter your password to view the channel.
Use the buttons to select the channel, and press the OK/ button on the remote control
to lock the channel. Press the button a second time to unlock the channel.
Parental Rating: Allows you to select the Program Rating threshold to lock programs by rating.
New Password: You can set a custom password by keying it in twice.
Clear Lock: Select this option to erase all password settings, including resetting the password to
default (0000).
OK/
18
OSD Menu
5. Setup menu
The option settings allows alterations to the language and regional settings.
Description
Time Settings:
Clock: Use the buttons to select the
position, and the buttons to set the time.
: The time cannot be changed manually in
NOTE
DTV mode because the clock is synchronised
with the broadcast signals received.
Timer:
Power on Timer: Turn on/off the power on timer.
Timer:Set the power on time.
Power On Source: To select source: ATV / DTV
Power On Channel: To select power on channel.
Power Off Timer:
Set the power off time.
Timer:
Turn on/off the power off timer.
OSD Time: Lets you adjust the amount of time
the On Screen Menu stays on the screen
before disappearing.
Sleep Timer: Set the time span before the unit goes
to sleep from the following selections: 5min, 15min,
30min, 60min, 90min, 120min, 240min and OFF.
Auto Sleep: Turn the automatic standby function on/off. When activated, the unit will switch to
standby if it has not received any signal input for an extended period of time. (3/4/5 hours)
19
OSD Menu
OSD Language: Select the language option for the OSD menu.
Audio Languages: (can be selected in DTV mode): Allows you to select first and
second audio language.
Subtitle: (can be selected in DTV mode)
Teletext:
Blue Screen:
HDMI CEC Control
DVR Settings: Use the buttons to select the DVR Settings, then press OK to enter.
OAD:
Restore Factory Default:
System Info:
Adjust Teletext settings. Only available under DTV and ATV source.
Turn on/off the blue screen.
: Turn on/off HDMI CEC Control.
For more about DVR Settings, please see “Recording Operation”.
Display a menu to check for new firmware available on broadcast.
Select to erase all custom settings and return to factory defaults.
(If Lock is enabled, this requires password access)
Display system information.
Allows you to select first and second subtitle language.
:
20
Multimedia Operation
USB Usage Precautions
Never turn the unit off or disconnect a USB Storage Device (Flash Drive) when it is
being accessed. Doing so could damage the TV and the connected USB storage
device.
Do not use a device that has a maximum current consumption of 100 mA or more.
Do not use a device that has security functions or other special functions.
Do not use a device that is divided into two or more partitions.
A USB hub cannot be used to connect USB devices to this unit.
USB storage devices that can be played on this unit
Only USB Storage Device (Flash Memory) maximum 64GB can be used. Do NOT
use a high-capacity USB hard disk with this unit.
Some flash memory players that charge from USB terminals cannot be used for
playback.
Hard disk drives, CD/DVD Drives, and other devices connected via USB cannot be
used.
This unit cannot copy or move files.
Playable formats: FAT16,FAT32
Depending on the condition of the USB flash drive, this unit migh
the files on it or skipping
NTFS, HFS and HFS+ formats are not supported and cannot be used.
Max. number of playable folders: 200
Max. number of playable files: 999
If the USB storage device contains more than 999 files or 200 folders, this unit
cannot play it back correctly.
This unit cannot play files that are larger than 2GB.
Files with variable bit rates might not play correctly.
might occur.
File information display
t not be able to play
The display of this unit can only show single-byte letters and numbers.
If the file information contains Japanese, Chinese or other double-byte characters,
playback is possible but the name will not be shown correctly.
21
Multimedia Operation
Basic Operation
1). Press the INPUT button on the remote control to display the input source menu and select USB
with the buttons. Press the OK button to enter the Multimedia menu as shown below.
2). Press to select the type of media you want to play from the connected USB device, as follows:
PHOTO, MUSIC, MOVIE and TEXT. Press to select the device and press OK button to enter.
Press to browse through the files. Press the OK button to select the file or access the folder,
then press the button to play the selected media in full screen.
In full screen mode, you can access playback controls at the bottom of the screen by pressing the OK button
and press EXIT to hide it. Press to stop and exit the full screen program.
22
Multimedia Operation
To access photo, audio, video, or text files from an external drive, first choose USB Input, then select the
type of media to be played to enter the folder/file navigation screen.
1. Photo
To display photos, select files from the folder and press PLAY to view in full screen. The image should
appear on screen as illustrated below.
To play background music during a photo display, first enter the music playing menu and start music
playback. Ensure that “Background Music” is set to “ON” via the Quick Menu. Next, return to the Photo
file navigation. Start the photo display while the music continues to play.
9/76
154910i4mrbvis9oetioor_jpg_thumb_jpg
OK Slide Show/ Single View Previous / Next Rotate EXIT Back Quick Menu
Date 2013-02-01 20:34:56
Resolution 600×375
ZOOM IN
ZOOM OUT
D.MENU
Press to select options on the toolbar, and press OK to change.
OK: Start playback / pause photo viewing.
Previous / Next: Display the previous / next photo.
Rotate: Rotate the photo clockwise/counter clockwise.
EXIT: Press the EXIT button and select Back to return to the previous menu.
Quick Menu:
Press D.MENU to enter Quick Menu.
Interval Time: Adjust slideshow frames interval time.
Repeat: Select repeat modes from Repeat All, Repeat 1, Repeat None.
Sideshow Effect:
Select the Sideshow Effect from Fade In, Fade Out.
Background Music: Play/pause music. (You can only play or pause the music you have selected).
2. Music
To play audio files, select a file from the folder and press PLAY to start the music.
Information about the music file is displayed on the screen.
23
Multimedia Operation
Press to select the option on the table, and press OK to change.
Press to search for music, and press OK to select.
Press the EXIT button and select Back to return to the previous menu.
Quick Menu: Press D.MENU to enter Quick Menu.
Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None.
Background Music: Turn on/off background music for musical photo/text display.
Screen Mute: Press the BLUE button to switch off the screen display.
NOTE:This is NOT Standby.Turn the screen on with any button on the remote other than the STANDBY
button.
3. Movie
To play video files, select a file from the folder. If Preview is turned on, the video will start playing
in a window on the side. Press PLAY to start watching the video in full screen.
Press to select options on the toolbar, and press OK to change.
: Previous chapter.
: Next chapter.
: Play/Pause program.
: Fast reverse.
: Fast forward.
Quick MENU:
Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None.
Encode Type: Select the encode type for the movie.
Sort:
Press D.MENU to enter Quick Menu.
Sort the file list by File Size or File Name.
24
Multimedia Operation
4. Display Text
To play text files (most files with the extension .txt), select a file from the folder and press PLAY.
ZOOM IN
ZOOM OUT
Previous / Next 0~9 kcaBTIXEuneMkciuQegaPotoG
Press to select options on the toolbar, and press OK to change.
Press 0~9
to select specific pages.
Prev/Next: Turn to previous/next file.
Press the EXIT button and select Back to return to the previous menu.
Quick Menu:
Press D.MENU to enter Quick Menu.
Repeat: Select the repeat mode from Repeat All, Repeat 1, Off.
Background Music: Enable or disable background music.
Encoding Type: Change the type of encoding to suit different languages.
D.MENU
25
Multimedia Operation
Supported Formats:
MOVIE
(AVI)
MUSIC
Special note:
1. the Media Unit can only support USB memory devices, such as hard disk drives and
flash drives, and will not support multimedia devices such as mobile phones and cameras
for recording purposes.
2. Unit will only support hard disk drives with additional power supply, maximum disk
partition size of 400GB and a maximum capacity of 1.5TB. For optimum performance, it
is highly recommended that a hard disk drive with an external power supply be used for
larger capacities.
3. The maximum
4. When using external USB, it is suggested that high quality USB extension cables
(supported 480mHz) be used to ensure smooth playing of video files.
5. The television unit can only support audio formats of single and binary channels.
The max bitrate is 6Mbps. The max resolution is 720x576 pixels.
Mono colour, 16 -colour, 256-colour, 16-bit, 24-bit, 32-bit. The max
resolution is 3000x3000 pixels; min resolution is 100x100 pixels.
Sample rate: 8K – 48K, Bitrate: 32K-320K
number of files that each folder can contain is 5000 files.
26
Recording Operation
Digital Video Recording (DVR) settings (In DTV Mode only)
The DVR function allows this unit to record live digital TV (DTV) programs, allowing for viewing on
demand at any time. This function supports DTV program recording, Time shift and playback as
described below.
DVR will only record when there is an external USB drive connected to the unit with sufficient memory
space available. Recording can be done both manually on demand and also using Scheduled
Recording.
NOTE:
This recoding function is only suitable for DVB-T, not suitable for DVB-T2 or analog signal.
27
Recording Operation
Recorded list
Red button: Delete One program.
Green button: Delete All programs.
Yellow button: Replay the program.
Blue button: Zoom In/Out between full screen view and preview mode.
After the recording has been done, the stored programs can be viewed through a Recorded List
by pressing the Green button on the remote control. To play the items, press OK on the remote to
select the recorded program. To delete the program from the list, press the RED button.
28
Recording Operation
Device List
NOTE:
NOT all USB devices, such as phones, MP3 players, cameras, and the like, are compatible with
recording files. Please use USB Flash Drives, or external HDDs with a separate power supply.
The USB drive has to be formatted before any recording can be done to ensure that it is in the
correct file system format and that there is enough data space for recording.
WARNING:
Ensure that no valuable information is currently stored in the hard disk, as the formatting
process means that ALL DATA will be ERASED from the memory drive connected to the
USB/HDD port. TEAC does not take responsibility for lost data.
29
Recording Operation
Schedule List
Red button: Delete One scheduled program.
Green button: Delete All scheduled programs.
Scheduled Recording is a function which allows the user to record future programs without physically
being present to initiate the recording. A schedule setup is made to mark recording dates and times of
the broadcasted programs stated on the Electronic Program Guide (EPG). Recording would terminate
at the end of the program.
Scheduled recording can start while the TV is on (the channel will switch automatically), or on Standby
Mode. Please make sure that the connected USB device has enough data storage for recording. If
data space runs out, the recording will stop automatically.
CAUTION: DO NOT remove the USB drive while recording is in progress. This may damage the drive.
Time Shift
Time shift is an ideal way to temporarily pause live TV in case of a distraction such as a doorbell or
a ringing telephone. Once the distraction has passed, playback can be resumed from the point
where the TV program was paused. Press the PLAY/PAUSE button on the remote control to start
the Time shift mode. Press the PAUSE button again to resume playback.
NOTE:
again to close.
30
Recording Operation
Electronic Program Guide (EPG)
Press the EPG button to display the OSD menu as below:
Details information
of selected
program.
Program list for the
current channel.
Press direction
buttons to navigate
the lists.
Once the program of choice has been highlighted, press the REC button on the remote control. This
will bring you to Record Mode, where you can set the start and end time of the recording.
Recorded Mode
Setting the Recorded Mode
The TV will record the program automatically according to the
set time.
MODE: Select the record mode.
Channel : Display the name of the recording program.
Start Time: Set the start time.
End Time: Set the end time.
Press OK button to save the setting and exit the menu.
NOTE:
- If channel locks or parental control locks are enabled, the locked programmes and channels
can be recorded, viewed and played back on this TV using password access. Key in your current
password when the password prompt pops up.
- While recording is in progress for a locked channel, you will still need to key in the password to
watch that channel. This does not interrupt the recording process.
31
Specifications
HDMI INPUT
Horizontal
Mode Resolution
480i 720 x480i 15.73 59.94/60
576i 720 x 576i 15.63 50
480p 720 x480p 31.47 59.94/60
576p 720 x 576p 31.26 50
720p 1280 x 720p 37.50
1080i 1920 x 1080i 28.13
1080p 1920 x 1080p 56.25
COMPONENT (YPbPr) INPUT
Mode Resolution
480i 720 x480i 15.73 59.94/60
576i 720 x 576i 15.63 50
480p 720 x480p 31.47 59.94/60
576p 720 x 576p 31.26 50
720p 1280 x 720p 37.50
Frequency
(KHz)
44.96
33.75
67.5
Horizontal Frequency
(KHz)
44.96
Vertical
Frequency
(HZ)
50
59.94/60
50
59.94/60
50
59.94/60
Vertical Frequency
(HZ)
50
59.94/60
1080i 1920 x 1080i 28.13
33.75
1080p 1920 x 1080p 56.25
67.5
32
50
59.94/60
50
59.94/60
Troubleshooting
Before consulting service personnel, check the following chart for
PROBLEM SOLUTION
TV will not turn on
No picture, no sound
Poor picture, sound OK
ƔMake sure the power cord is plugged in.
ƔThe batteries in the remote control may be
Exhausted; replace the batteries.
ƔCheck the cable between TV and antenna/
device.
ƔPress the power button on the remote.
ƔPress the SOURCE button the remote, then press the
“Ÿ/ź”button repeatedly to select the TV source.
ƔCheck the cable between TV and antenna/
device.
ƔTry another channel, the station may have broadcast
difficulties.
ƔAdjust the brightness/contrast in the Video menu.
that the unit is set to PAL
Audio noise ƔMove any infrared equipment away from the TV.
possible solutions.
external AV
external AV
Check
The TFT LED panel uses a panel consisting of sub pixels which requires sophisticated technology to
produce. However, there may be
a small number of
will have no impact on the performance of the product.
bright or dark pixels on the screen. These pixels
33
In the event of a product failure within the warranty period, please call the
TEAC Warranty Service Hotline
Between Monday to Friday - 8.30AM to 5PM AEST
*Please have your purchase receipt and the product’s serial number ready
For other enquiries and support please visit
1300 553 315
www.teac.com.au
Loading...
