TEAC’s Passion for Music is Everlasting.

The TEAC story began over half a century ago when a young

Japanese engineer, Katsuma Tani, introduced a tape-recorder to

the market. Since then, a continued commitment to music has

generated a plethora of first-class audio products proudly carrying

the TEAC brand name. Now, Tani’s passion to the music has been

handed down to today’s engineers in order for them to deliver the

passion contained in every single musical note to all.

Launch of the best-selling Stereo Cassette Deck, C-1

Launch of the new flagship Hi-Fi system, Reference 600 series

Launch of the first TEAC DAB product, T-H300DAB

Launch of the first TEAC premium Components, Reference 500 series

Launch of the first TEAC CD Player, PD-11

Launch of the first TEAC Dolby NR Stereo Cassette Deck, A-350

Launch of the world‘s first Stereo Compact Cassette Deck, A-20

Launch of the best-selling Reel-to-reel Tape Recorder, A-4010S

Launch of the first TEAC Stereo Tape Recorder, TR-102

Foundation of TEAC Corporation, in Tokyo Japan

When you first listen to TEAC’s top-of-the-range Stereo Receiver, the AG-H600NT,

you’ll experience the same emotions as the performing musicians.

This is achieved not by magic but through the accumulation of TEAC’s superior technology and experience.

It is a fact that a clean and stable power supply is critical when striving to achieve the ultimate audio performance. Any sudden and rapid

increase of the signal level required in a musical passage, such as in the introduction to the second movement of Beethoven’s Ninth Symphony,

requires a measured and controlled power input. That’s why, from the very beginning of its development, TEAC’s engineers carefully designed

the power supply section of the AG-H600NT to deliver pure and unwavering power supply to every single part of the unit.

Shown with a Docking Station for iPod, DS-20. (iPod not included)

When you listen to music on TEAC’s PD-H600 CD player,

you will hear subtle details that you never knew existed, breathing new life into

even the most familiar recordings.

TEAC Reference 600

The Compact Disc is still the most popular and widely used digital music source in the world, and its potential is huge and

indispensable. For accurate signal reading from discs, TEAC’s Reference 600 CD Player employs an ultra high precision CD

mechanism incorporated into a rigid body construction, skilfully created, and machined by craftsmen.

AG-H600NT, Stereo Receiver PD-H600, CD Player

Enforced Power Supply

A large Toroidal-core power transformer delivers ample current power

to the heart of the amplifier and a Schottky barrier diode in the rectifier

circuit offers great advantages in responding to sudden musical surges.

The AG-H600DNT also carries many ELNA electrolytic capacitors and

resistors exclusively designed for high fidelity products. There is an

oxygen-free copper coil for the audio filter in the power amplifier

section. Also, in the power amplifier, a Direct FET Power MOSFET is

employed to maximize fully the Class-D amplifier.

There is no limit to versatility

With an integrated iPod docking station, the AG-H600NT is more

than flexible enough to handle today’s latest portable music players.

Moreover, with the innovative AG-H600NT, Internet Radio offers

countless music stations from all over the world – while a neat AM/

FM tuner delivers your local information. No matter where you are,

over 10,000 Internet Radio stations are available – from a cool jazz

station riff in New York City to a meditative beat from mystic Bali.

For Massive Sound with Great Subtlety

A closer look at the electronics reveals that Burr-Brown’s 24-bit/192kHz

Delta-sigma D/A Converters maximize the potential of the latest

compact-disc recordings. In addition, as you would expect from TEAC,

every component – including the ELNA electrolytic capacitors and

resistors – are exclusively chosen by experienced engineers for true

audiophiles. A shunt regulator maintains the same level of output

current by adjusting the value of the resistors, which are connected in

parallel in the in-flow current section.

Flawless Current to Every Single Section

In addition, a Toroidal-core power transformer is incorporated into the

CD player, to supply a stable current to the unit, while the thick film

resistors used in the signal input section also contribute to the player’s

natural, free-flowing sound. In order to avoid jitter noise, a master

clock generator, operated with a finite low-noise current, is located

independently on the circuit adjacent to the D/A converter.

Uncompromised Details

TEAC has even thought of incorporating large speaker cable

terminals for a better connection – and included an FL display that

can be turned off to cancel the unwanted effects of high-frequency

radiation noise.

Fully Armoured

The CD tray itself is constructed using one of the strongest synthetic

materials available, contributing to the anti-vibration qualities when the

disc is rapidly rotating and ensuring rigidity throughout. In addition,

the CD mechanism is positioned at the precise centre of the unit, thus

optimising the balance-to-weight ratio.

Moreover, construction of the unit has been fully equipped with a

robust chassis and thick aluminium panels for the front, top, and sides.

AG-H600NT Stereo Receiver

DS-20 Docking Station for iPod

PD-H600 CD Player

Appendix

RC-1181 RC-1182

Specifications

AG-H600NT

AM/FM/Internet-Radio Stereo Receiver

Output Power: 75W + 75W (8 ohms, 1kHz, 0.5%THD)
90W + 90W (4 ohms, 1kHz, JEITA)
Total Harmonic Distortion: 0.05% (8 ohms, 1kHz, 40W)
Signal-to-Noise Ratio: 70dB (Phono)
100dB (CD, AUX)
110dB (Tone Direct)
Input Sensitivity: 2.8mV, 47k ohms (Phono-MM)
180mV, 47k ohms (CD, AUX)
Frequency Response: 10Hz - 65,000Hz (8 ohms, -3dB, 1W)
Tone Control: Bass ±12dB (at 100Hz)
Mid ±12dB (at 1kHz)
Treble ±12dB (at 10kHz)
Tuner: AM (522kHz - 1620kHz)
FM (87.50MHz - 108.00MHz, 50kHz steps)
Internet-Radio (MP3, WMA, RealAudio)
Number of Preset: 30 AM, 30 FM
Network: Ethernet (10Base-T, RJ-45)
Wireless LAN (IEEE802.11b/g)
Security (WEP, WPA, WPA2)
Audio Input: 4 (Phono, CD, AUX, iPod)
Audio Output: 1 (Line)
Speaker Terminals: Binding-post x 2 pairs
Headphone: 6.3mm Stereo
Display: Fluorescent Dot-matrix
Display Dimmer: Yes (Normal, Dimmed, Off)
Power Requirements: 120V, 60Hz (US), 230V, 50Hz (EUR/Asia)
Consumption Power: 50W (Standby: 0.7W)
Dimension (W x H x D) 11.4” x 4” x 12.6” 290 x 102 x 320mm
Weight: 15 lbs. 6.8kg
Accessories: System Remote Control, AAA Batteries x 2
AM Loop Antenna, FM Lead-type Antenna
Wireless LAN Antenna, Power Cord
Owner’s Manual, Warranty Card
Option: Docking Station for iPod (DS-20, Sold separately)

PD-H600

CD Player

Compatible Discs: CD-DA, CD-R/RW, MP3, WMA
Frequency Response: 20Hz - 20,000Hz (±0.5dB)
Total Harmonic Distortion: Less than 0.003% (1kHz)
Signal-to-Noise Ratio: more than 110dB (1kHz, 0dB, A weight)
D/A Converter: 24bit/192kHz Delta-sigma (PCM1796)
Oversampling Rate: 8-times
Repeat Play Yes (1, All)
Shuffle Play: Yes
Programme Play: Yes (30 Tracks)
Display: Fluorescent Dot-matrix
Display Dimmer: Yes (Normal, Dimmed, Off)
Audio Output: 1 RCA (Gold-plated, 2.0Vrms, 1kHz, 0dB)
Digital Output: 1 Coaxial (Gold-plated, 0.5V, 75 ohms)
Signal Ground Terminal: 1
Power Requirements: 120V, 60Hz (US), 230V, 50Hz (EUR/Asia)
Consumption Power: 9W (Standby: 0.7W)
Dimension (W x H x D) 11.4” x 4” x 12.1” 290 x 102 x 308mm
Weight: 11.9 lbs. 5.4kg
Accessories: System Remote Control, AAA Batteries x 2
RCA Cable, Power Cord, System Cable
Owner’s Manual, Warranty Card

DS-20

Docking Station for iPod

iPod Dock: 1
Audio Output: 1
S-Video Output: 1
Composite Video Output: 1
Dimension (W x H x D) 4” x 4” x 1.5”
100 x 100 x 39mm
Weight: 14 oz. 400g
Accessories: Dock Adapters
