READ THIS MANUAL CAREFULLY BEFORE USE - FAILURE TO DO SO MAY RESULT
IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. KEEP THIS MANUAL
FOR FUTURE REFERENCE. Products covered by this manual may vary in appearance,
assembly, inclusions, specications, description and packaging. Keep packaging and
bags away from children and dispose of all packaging properly before use.
Made in China
TM
ELECTRIC LONGBOARD
REMOTE CONTROLLED
User Manual
PLEASE DO NOT
RETURN THIS
PRODUCT
TO THE STORE
We will be happy to correct any problems that you may
have, or answer any of your questions regarding the
purchase of this product. Please contact us at our Toll
Free customer service number 1-800-599-8898 for any
assistance and replacement parts. Thank You.
Dist. by TDC USA, Inc. Faireld, NJ 07004
©2018 All Rights Reserved.
Made in China.
Item #60776
www.tdcusainc.com
4
About Your New Electric Longboard
Thanks for purchasing the Kruze Electric Longboard by
TDC USA Inc.
To ensure your safety and the safety of others, please
read and follow the guidelines in this user manual carefully
before riding.
Please keep a copy of your purchase receipt. This copy of
receipt is asked upon when ling a claim for any warranty
related issues.
If you have any questions concerning this product,
contact us at 1-800-988-8898 M-F 9:00 AM – 5:00 PM EST
or email us at support@tdcusainc.com
Age:
14
Weight Capacity:
Max 200 lbs
Top Speed
Up To 10 MPH
Estimated top speed is based on a
smooth at surface with no wind. Actual
data may vary.
Estimated Riding Range
6 miles
Depending on load weight and other
riding conditions
Product Weight
15 lbs
Battery
25V Lithium Ion Phosphate
Deck
7-Ply Wood Construction
Charger
120V, 0.35A
Overall Dimensions
32” Length x 9” Width
Connectivity Range
3 feet
Optimal Operating Temperature
45°F - 100°F
Product Specications:
5
Warranty Information
1 YEAR LIMITED WARRANTY
Your Kruze Electric Longboard includes a 1 year limited hardware
warranty. The warranty covers product defects in materials and
workmanship under normal use. This warranty is limited to residents
of the United States only and is available only to original purchasers.
This warranty starts on the date of your purchase and lasts for 1 year
warranty period. The warranty period does not extend if the product
is repaired or replaced. We may change the availability of this limited
warranty at our discretion, but any changes will not be retroactive.
Warranty services are provided by TDC USA Inc. If a hardware defect
arises and a valid claim is received during the warranty period, TDC
USA Inc. will repair the hardware defect by using new or refurbished
parts that are equivalent to new in performance and reliability. This
warranty is for 1 replacement only of like-items and does not cover
items out of production if the product is no longer made or stocked.
This warranty is not assignable or transferable.
DO NOT DISASSEMBLE THE PRODUCT.
Doing so will void this warranty. Only TDC USA Inc. is the authorized
service center who should perform service on this product.
Warning: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This warranty does not cover any damage due to the following:
A) Transportation
B) Storage
C) Improper use
D) Failure to follow the product instructions or perform any preventive
maintenance
E) Modications
F) Unauthorized repair
G) Normal wear and tear
H) External causes such as accidents, abuse, or other actions or events
beyond our reasonable control
6
It is important to read and follow all instructions and warnings in
this user manual and use good judgment in order to ride safely.
Please ride responsibly and respect those around you, both for
your safety and to the safety of others. Before using this product,
the user must acknowledge and accept personal responsibility of
all risks associated with the use of this Kruze Electric Longboard,
which may include, but are not limited to, muscle injuries, broken
bones, lacerations, or other serious injuries that may be sustained
while using this product.
Always wear a helmet when riding. Avoid water, wet surfaces,
slippery/uneven surfaces, steep hills, trac, cracks, tracks, gravel,
rocks, or any obstacles that could cause a loss of traction and
cause a fall. Avoid night riding, areas with poor visibility, and small
spaces.
APPROPRIATE RIDER USE AND PARENTAL SUPERVISION.
The recommended minimum rider age of 14 years is an estimate
only, and can be aected by the rider’s size, weight or skills. Any
rider unable to adequately understand the controls or techniques
required to ride the product should not attempt to ride it. A parent’s
decision to allow his or her child to ride this produce should be
based on the child’s maturity, skills and ability to follow rules.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS.
· Always check and obey any local laws or regulations which
may aect the locations where the product may be used. Ride
defensively. Watch out for potential obstacles that could catch
the wheels or force you to swerve suddenly or lose control. Avoid
pedestrians etc who may enter your path and respect the rights
and property of others.
· The Product is not for indoor use.
· Never use headphones or phone when riding.
Warnings
SAFETY NOTICE. READ BEFORE RIDING
7
Warnings
Your board can lose power and brakes at any moment.
• In the event of wireless interference or battery fault, the board turns
into an non powered skateboard, you must rely on skating techniques
like foot braking or sliding to stop. Do not ride in environments, on
inclines, or at speeds where you would not be safely in control of an non
powered longboard. Ensure the longboard speed is safe to yourself and
others. Be ready to stop at any time while riding.
Cars and other vehicles can kill you.
• Always be aware when riding around other vehicles. Ride defensively
and assume other vehicles can’t see you. Be aware of the local laws that
govern the use of your board on public roads, bike paths, sidewalks, or
other places.
Protect your board.
• Never ride o curbs, perform tricks, jumps, hops, or any other related
high impact stunts while using this board. It will cause damage to
internal electronic components over time and can be very dangerous on
a board with so much power and speed. This will also void the warranty.
WARNING!
• Stay in open spaces and flat areas. Avoid steep slopes or high traffic
areas until you’re familiar with riding
• This longboard is intended for 1 user only. Never carry passengers on
the longboard with you.
• Always wear shoes when riding.
• Never ride at high speed on uneven terrain or slopes.
• Do not carry heavy items when riding.
• Avoid water! Your Kruze Electric Longboard is not waterproof. Electrics,
bearings and other components can be damaged. Water damage is not
covered under the warranty.
• Keep fingers, hair and clothing away from belts, motors, wheels, and all
moving parts.
• Do not open or tamper with electronic housing, which will also void the
warranty.
• Never operate your Kruze Electric Longboard near flammable vapor,
liquids dust or other fire hazards.
WARNING!
8
How To Ride
Determine your stance. If you are unsure, place the foot you kick a ball
with towards the back of the longboard. This is your dominant foot.
Your Kruze Electric Longboard has a lot of power. Follow
these tips to ensure a safe riding experience.
• Move the throttle wheel in small increments.
• Keep a wide stance on the board
• Keep a low center of gravity
• Lean forward when accelerating.
• Lean backwards when braking.
Left Foot
Right Foot
Left Foot
Right Foot
REGULAR FOOTED
(Lefty foot forward)
GOOFY FOOTED
(Right foot forward)
lean back
when braking
lean forward
when accelerating.
9
Controls and features
1. Power On/O
2. Mini USB Charging Port
3. Forward/Brake Lever
4. Speed Switch (High/Low)
5. Direction Selector (Forward/Backward)
6. Paired Indicator
7. Battery Indicator
8. Reset
1. Power ON/OFF
2. Battery Indicator
1.
2.
10
Remote
Connecting your remote to the longboard
· Connect your remote to the longboard. By default, your Kruze Electric
Longboard has been paired to the associated remote included in
the package. After turning on the Kruze Electric Longboard and the
remote, both will automatically connect. If the automatic connection is
successful, the pairing indicator will turn green.
If Connection Fails
After switching both the longboard and remote control ON (both
must have sucient Battery Charge for normal operation), and if the
remote control and longboard are not communicating, the blue color
connection indicator on the remote control (A) will be ashing.
1. Switch the longboard OFF (Press and release the ON/OFF switch
(C) when OFF, no indicator lamps will be illuminated).
2. Press the remote control reset button (D) until all remote control
indicators are ashing rapidly. Use a pen etc to reach button.
3. Ensure that the longboard and remote control are within 3 feet of
each other, then switch the longboard ON. When ON, the battery
charge and the connection indicator lamp (B) will illuminate.
4. Check that the connection indicator (A) on the remote control is
illuminated steady blue color and not ashing. This means that
longboard and remote control are paired. If connection is not
successful, repeat the pairing procedure.
11
Using your Remote
Using your Remote
· Push the throttle up to move forward and/or accelerate.
The speed at which the longboard accelerates depends on how
far up you push the throttle. If this is your rst time riding, please
start by gently pushing the throttle so you are comfortable
with the acceleration. Make sure you have proper stance to
accommodate the acceleration.
· Push the throttle down to brake and/or decelerate. The
speed at which the longboard decelerates depends on how far
down you push the throttle.
Note: Make sure you are familiarize with how to safely
perform manual braking before riding.
Controlling Speed
• Use the accelerator / decelerator paddle (A) to control
speed. Push the paddle forward (toward “Speed UP”)
to accelerate. Hold the paddle in position, as required,
to maintain a constant speed.
• To coast without any motor assistance (or braking); for
example, when riding downhill, release the paddle so it
is in the neutral position.
• To apply “braking”, pull back on the paddle (toward
“Brake”). Note that when braking, your weight will have
a tendency to shift forward - it is recommended to shift
your body weight back a little before braking and adjust
your balance accordingly during braking.
• To change motor speed allow the longboard to come to
a complete stop, then move the speed selector switch
(B) to the required position “HI” for high speed ; “LO”
for low speed.
Turning
• Lean your body either side of the longboard to initiate
turn. If you lean to the right, your longboard will turn to
the right. If you lean to the left your longboard will turn
to the left. If turning is either too fast or too slow you
can adjust the trucks by tightening or loosing.
12
A
TO PREVENT ELECTRIC SHOCK, MATCH THE WIDER PRONG OR PLUG
TO WIDE SLOT IN OUTLET. FULLY INSERT.
Remote Control Battery
charging.
1. Connect the micro-USB cable
to the remote control charging
point (B)
2. Connect the other end of the
USB cable to a suitable charger such as a mobile telephone
charger or computer USB port.
3. Switch the remote ON. One or more battery charge indicators flash to
indicate charging.
4. When charging is complete, The battery charge indicators will be off.
Disconnect the USB cable from the charger and the remote control.
Charging Longboard and Remote
WARNING
Longboard Battery Charging.
1. Ensure that the longboard is OFF.
2. Insert the battery charger connector into the charging port (A) on the
side of the longboard battery pack.
3. Connect the charger to a standard outlet and switch it ON. When
charging the indicator on the charger illuminates RED. The charger
may feel warm during charging - this is normal and not a cause for
concern.
4. When charging is complete, the indicator on the charger illuminates
green. Disconnect the charger from the outlet and unplug the battery
connector from the charger port.
B
13
Battery Care
When charging the battery, ONLY use the specied battery charger
provided in the package. DO NOT place the battery in or near re,
or under direct sunlight. Do not continue charging the battery if this
does not charge within the specied charging time. Doing so may
cause the battery to become hot, or rupture. The temperate range
which the battery can be charge is 45°F – 100°F. Charging the battery
outside of this temperate range may harm the performance of the
battery or reduce the battery’s life expectancy.
FCC Regulations state that any unauthorized changes or
modications to this equipment not expressly approved by
the manufacture could void the user’s authority to operate this
equipment. This product satises FCC Regulations when shield
cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric
appliances such as radios and televisions, use shield cables and
connectors for connections.
BATTERY CARE AND CHARGING
• Never modify the electrical system. Alternations could cause a re resulting in
serious injury and could also damage the electrical system.
• Charge the longboard with the supplied or recommended charger only. Use of
the wrong charger could cause a re or explosion resulting in serious injury.
Charge the remote control using a suitable USB cable charger and cable such
as a mobile telephone charger or computer equipped with a standard USB port.
• Battery charging must be performed by adults only. Never allow children to
charge the battery.
• Ensure the voltage and frequency of the charger is compatible with mains
electrical supply.
• Use the battery charger in dry locations only.
• The longboard and remote control battery must be charged before rst use.
• Battery charging generally takes 1 to 2 hours from discharged to fully charged.
• Misusing the battery may cause the battery to get hot or rupture and cause
serious injury.
• Do not pierce the battery with sharp objects, strike the battery, step on the
battery or otherwise subject it to strong impact or shock.
• Do not expose the battery to water or any liquids that allow the battery to get
wet.
• Do not place the battery near res, stoves, or other high temperature locations.
• Do not disassemble or modify the battery.
• Do not store the battery inside hot car or under extreme cold weather
conditions.
WARNING
14
Troubleshooting
Problem Possible Cause Possible Cause
Under-charged
battery
Charge battery and ensure battery
charging and care procedures are
followed.
Longboard not
running or
Dead battery
Vehicle battery no longer holding
charge or serviceable. Have battery
checked by authorized service
center.
was running
but suddenly
stopped
Battery charger
not working
Have charger professionally
checked. If not working - replace.
Motor electronics
or switches
damaged / faulty
Seek diagnosis and repair from
authorized service center.
Short run time
Under-charged
battery
Charge battery and ensure battery
charging and care procedures are
followed.
Longboard runs
sluggishly.
Unsuitable riding
conditions
Vehicle being overloaded or used
on unsuitable surfaces or inclines.
Unload vehicle (Max 200lbs) and/or
use on suitable surface.
Longboard turns
ON and OFF
intermittently.
Electrics or
switches
damaged / Faulty
Seek diagnosis and repair from
authorized service center.
15
Battery Disposal
DISPOSAL AT END OF LIFE
This product must not be disposed of by incineration, landlling, or mixing with
household trash. Improper disposal of the battery contained within this product
may result in the battery heating up, rupturing, or igniting which may cause serious
injury. The substances contained inside the battery present chemical risks to the
environment. The recommended disposal for this product at its end-of-life is to
dispose of the entire unit at or through an e-Waste recycling center, program, or
facility. Local regulations and laws pertaining to the recycling and disposal of lithium
ion batteries and/or products containing them will vary according to country, state, and
local governments. You must check laws and regulations corresponding to where you
live.
In order to properly dispose of the battery and/or unit, it is the user’s responsibility to
dispose of their waste equipment properly with accordance with local regulations and
laws. For additional information about where you should drop o your batteries and
electrical or electronic waste, please contact your local or regional waste-management
oce, your household waste disposal service, or your point-of sale.
DECLARATION OF CONFORMITY:
This device complies with Part 15 of FCC Rules.
Operations is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC RELATED INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuantto Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.+ Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modications to this equipment. Such modications could void the user’s
authority to operate the equipment.
FCC Information
Dist. by TDC USA, Inc. Faireld, NJ 07004
©2018 All Rights Reserved. Made in China.
Item #60776
Questions and Comments
1-800-599-8898 (9 am - 5 pm EST)
www.tdcusainc.com
ELECTRIC LONGBOARD
REMOTE CONTROLLED
Loading...
