TCT Mobile 909 Users Manual
User Manual
English - CJA33NAALAAB
1
Contents
1 Your BoomBand ........................................................................... 3
2 Pairi ng ..............................................................................................6
3 Walk trackin g ................................................................................9
4 Sleep tracking .............................................................................. 11
5 Call re minde r ..............................................................................13
6 Anti-loss a ler t .............................................................................14
7 Silen t alar m ..................................................................................15
8 ROM Upgrade .............................................................................16
Troubleshooting ................................................................................17
Safety and use ....................................................................................18
General information ........................................................................19
Warranty ............................................................................................ 20
2
Your BoomBand
1
1.1 What’s included
Your BoomBand box includes:
• Corebox
• Wristband
• Charger
• BoomBand User Manual
Coreb ox Charger Wris tba nd
3
1.2 Charging your BoomBand
Insert the Corebox into the charger, as shown by the arrow in the
following picture. Ensure that the icons on the Corebox match those
on the charger.
• Pre-charging: If the BoomBand batteries are completely flat, the
LED lights will only begin to indicate after several minutes' charging.
• Charging: The LED lights will indicate progressively on your
BoomBand and blink every 5 seconds.
• Fully charged: Five lights are on and blinking every 30 seconds.
Battery type Standby time Charging time
Lithium-polymer
battery
4
3-5 days About 1.5 hours
1.3 Installation
Insert one end of the Corebox into the wristband, as shown by
the arrow in the following picture and then place the Corebox
completely into the wristband.
Perform the steps in reverse order to remove the Corebox.
5
Pairing
2
The BoomBand is compatible with mobile devices supporting
Bluetooth 4.0 LE (Android 4.3 or higher versions).
Currently, the BoomBand supports the following models: ALCATEL
ONETOUCH Idol X+; ALCATEL ONETOUCH POP S3; ALCATEL
ONETOUCH POP S7; ALCATEL ONETOUCH POP S9; ALCATEL
ONETOUCH IDOL 2 Mini; ALCATEL ONETOUCH IDOL 2 Mini S;
ALCATEL ONETOUCH IDOL 2S; ALC ATEL ONETOUCH IDOL 2.
2.1 First pairing
• Download BoomBand Life from http://www.alcatelonetouch.
com. (BoomBand Life is pre-installed in ALCATEL ONETOUCH
Idol X+.)
• After installation and launch, you are requested to set your
personal info as below:
• Once you choose to pair BoomBand, a message is displayed to
prompt you to turn on Bluetooth (if it is off) and then search for
BoomBand devices.
6
• BoomBand Life requests to pair with nearby BoomBand devices and
will remind you to knock the BoomBand twice for confirmation.
The 5 LED lights will then blink in sequence.
• When the BoomBand is successfully paired, it vibrates once and 5
lights come on together. “Connect successfully!” will be
displayed.
At least 4 LED lights are required for the first pairing. It is
recommended that the Corebox be charged during the
first pairing.
2.2 Changing paired phones
• On entering the main interface of BoomBand Life a message is
displayed to prompt you to turn on Bluetooth (if it is off) and then
search for BoomBand devices.
• If you change the paired phone, all original data recorded from the
BoomBand will be saved in the old phone and new data will be
generated in the newly paired phone.
7
