Thank you for buying DL900. We hope you will enjoy your highquality mobile communication experience.
Yaris-5 7042A USA QG_20140912.indd 12014/9/12 9:29:58
English - CJB33ACC9AAA
1
Table of contents
1 Your mobile ��������������������������������������������������������������������� 3
2 Text input ���������������������������������������������������������������������� 14
3 Phone call ���������������������������������������������������������������������� 15
4 People ����������������������������������������������������������������������������17
5 Messaging����������������������������������������������������������������������� 18
6 Email ������������������������������������������������������������������������������ 19
7 Getting connected �������������������������������������������������������� 20
8 Locate my location using GPS satellites ��������������������� 22
9 Data backup ������������������������������������������������������������������ 23
10 Factory data reset ������������������������������������������������������� 23
11 Applications & Internal storage ���������������������������������� 24
Safety and use ������������������������������������������������������������������������� 25
General information �������������������������������������������������������������� 32
Troubleshooting���������������������������������������������������������������������� 32
This product meets applicable
national SAR limits of 1.6 W/kg. The
specific maximum SAR values can be
found on page 31 of this user guide.
When carrying the product or using
it while worn on your body, either
www.sar-tick.com
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker
is in use.
2
use an approved accessory such as
a holster or otherwise maintain a
distance of 10 mm from the body to
ensure compliance with RF exposure
requirements. Note that the product
may be transmitting even if you are
not making a phone call.
Yaris-5 7042A USA QG_20140912.indd 22014/9/12 9:29:58
Your mobile ������������������
1
1�1 Keys and connectors
Headset connector
Front camera
Touch screen
Back key
Home key
Yaris-5 7042A USA QG_20140912.indd 32014/9/12 9:29:59
micro-USB
connector
Menu key
3
Camera Flash/
Flashlight
Camera
Volume up
Volume down
Power key
Menu key
• Touch to access Settings options.
• Touch and hold: Touch and hold it to open a list of
thumbnail images of applications you've worked with
recently.
Home key
• While on any application or screen, touch to return to
the Home screen.
Back key
• Touch to go back to the previous screen, or to close a
dialog box, options menu, the notification panel, etc .
These keys are visible when the screen lights up.
4
Yaris-5 7042A USA QG_20140912.indd 42014/9/12 9:30:00
Power key
• Press: Lock the screen/Light up the screen
• Press and hold: Power on or pop up the menu to get
more options, such as Restart, Airplane mode, etc.
• Press and hold Powe r key and Volume down key to
capture a screenshot.
• Press to mute the ringtone when there’s an incoming
call.
Volume keys
• Under call mode, adjust the earpiece or headset
volume.
• In Music/Video/Streaming mode, adjust the media
volume.
• Mute the ringtone of an incoming call.
• Press to light up the screen when it dims during a call.
5
Yaris-5 7042A USA QG_20140912.indd 52014/9/12 9:30:00
1�2 Getting started
1�2�1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power off
your phone before inserting or removing the SIM card.
To install, please open SIM card lock first, and then place the SIM
card into the slot with its chip facing downwards. Make sure that it
is correctly inserted. To remove the card, please open SIM card lock
and take it out from the slot.
Before inserting/removing the SIM card, you should ensure
the phone is off, to protect it from corruption or damage.
Your phone only supports micro-SIM card. Do not attempt
to insert other SIM type like mini and nano card, otherwise
may cause phone damage.
Installing or removing the microSD card
To install, please open microSD card lock first, and then place the
microSD card into the slot with the gold contact facing downwards.
To remove the external microSD card, please open microSD card
lock and take it out from the slot.
Before inserting/removing the microSD card, you should
ensure the phone is off, to protect it from corruption or
damage. In addition, regularly removing or inserting the SD
card may cause the phone to restart.
6
Yaris-5 7042A USA QG_20140912.indd 62014/9/12 9:30:10
Installing or removing the battery
• Insert and click the battery into place, then close the phone cover.
• Unclip the cover, then remove the battery.
Charging the battery
Connect the battery charger to your phone and mains socket
respectively.
The charging status bar will not float if your battery is
extremely consumed. To reduce power consumption and
energy waste , when battery is fully charged, disconnect your
charger from the plug; switch off Wi-Fi, GPS, Bluetooth or
background-running applications when not in use; reduce the
backlight time, etc.
1�2�2 Power on your phone
Hold down the Powe r key until the phone powers on. It will take
some seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you should set following
options: language, date & time, Google account, etc.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the Phone
options appear, select Power off.
Yaris-5 7042A USA QG_20140912.indd 72014/9/12 9:30:15
7
1�3 Home screen
You can bring all the items (applications, shortcuts, folders and
widgets) you love or use most frequently to your Home screen for
quick access. Slide the Home screen horizontally left and right to
get a complete view of the home screen. Touch the Home key to
switch to Home screen.
8
Status bar
• Status/Notification indicators
Favorite tray applications
• Touch to enter the application.
• Touch and hold to move or change
applications.
Application tab
• Touch to open main menu.
Yaris-5 7042A USA QG_20140912.indd 82014/9/12 9:30:15
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Touch and Hold
Touch and hold the home screen to access the available options for
setting the wallpaper.
Drag
Place your finger on any item to drag it to another location.
Slide/Swipe
Slide the screen to scroll up and down the applications, images, web
pages… at your convenience.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them
apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways to have a better view.
1�3�2 Status bar
From status bar, you can view both phone status (to the right side)
and notification information (to the left side).
Yaris-5 7042A USA QG_20140912.indd 92014/9/12 9:30:15
9
Status icons
GPRS connectedNo signal (gray)
GPRS in useRoaming
EDGE connected
EDGE in useSignal strength (blue)
3G connectedVibrate mode
3G in useRinger is silenced
HSPA (3G+) connected
HSPA (3G+) in useBattery is very low
Connected to a Wi-Fi
network
Bluetooth is on
Connected to a
Bluetooth device
Airplane modeBattery is charging
Alarm is setHeadset connected
No SIM card inserted
Phone microphone
is mute
Battery is low
Battery is partially
drained
Battery is full
10
Yaris-5 7042A USA QG_20140912.indd 102014/9/12 9:30:15
Notification icons
New text or
multimedia message
Problem with SMS or
MMS delivery
New Hangouts messageCall forwarding is on
New voicemailCall in progress
Upcoming eventUploading data
Data is synchronizingDownloading data
Song is playing Select input method
Screenshot captured
USB tethering is on
Portable Wi-Fi hotspot
is on
Missed call
Call on hold
An open Wi-Fi network
is available
Phone is connected via
USB cable
Radio is on
Yaris-5 7042A USA QG_20140912.indd 112014/9/12 9:30:16
11
