Quick start guide
Vodafone Chat
Page 2
For more information about how to use the phone, please go to
www.vodafone.com/vodafonechat to download complete user manual.
Also on our website you can find helpful FAQs, realize software
upgrade, etc.
Your mobile1
Keys and connectors1.1
Volume key
micro-USB connector
Loudspeaker
Flash
Camera
Notification
light
Status bar
Widget bar
Left softkey
Send key
Silence key
Voicemail key
Sym key
Shift key
Space key IM key
Earpiece
Home screen
Navigation key/
OK key
Right softkey
End key
Delete key
Enter key
Alt key
Microphone
Headset
connector
Flick to go left/right/up/down•
Press to confirm an option (press the middle of •
the key)
Answer/Send a call•
Enter Call log•
Press: End a call•
Return to the Home screen
Press and hold: Power on/off•
Press and hold: Access your voicemail•
Press once: Input a capital letter•
Press twice: Lock the keyboard in capital letter •
input mode
Press once: Input a top-half key character•
Press twice: Lock the keyboard in top-half key •
input mode
Alt + B: Access Bluetooth
Alt + J: Access Apps
Alt + M: Access Music
Alt + P: Access Device sound profiles
1 2
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:1-Sec1:2IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:1-Sec1:2 2012-8-8 11:02:372012-8-8 11:02:37
Page 3
Press: Enter a space (in Edit mode)•
Press OK key, then Space key to unlock the
keypad (on the Lock screen)
Press and hold: Access text input language list (in •
Hold down • Space key, then press Alt key to select
input method
Enter symbol table•
Hold down • Alt key, then press Sym key to enter
emoticon table
Confirm an option•
Enter the next line•
Press and hold: Switch between General and Silent •
profile
Volume up/down•
Scroll up/down•
Edit mode)
Lock the keypad (on the Home
screen)
From the status bar, you can view both phone status and notifications.
(1)
Status bar 1.2.1
Battery charge level.
Bluetooth activated and visible.
Bluetooth activated but invisible.
Bluetooth connecting.
Java application activated.
Headset connected.
Keypad locked.
Mute is on during a call.
Silent profile is activated.
Alarm or appointment programmed.
Level of network reception.
Missed calls.
Call in progress.
Press to delete a word or character•
Press to access applications: Google Talk, MSN, •
Facebook, Facebook Chat, Twitter
Home screen1.2
The Home screen is divided into several parts, as shown below:
Status bar
Stopwatch activated.
Email unread.
Radio is on.
WAP message.
(2)
Roaming.
SD card inserted.
SIM card unavailable.
GPRS in use.
2G network available.
3G network available.
Widget bar
Select to enter main
menu screen
3 4
(1)
The icons and illustrations in this guide are provided for informational
purposes only.
(2)
Depending on your network operator.
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:3-Sec1:4IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:3-Sec1:4 2012-8-8 11:02:382012-8-8 11:02:38
Page 4
Wi-Fi disconnected.
Wi-Fi connected.
Line switching
Vibrate and ring mode: your phone vibrates and rings.
Music active.
GPRS connected.
Edge in use.
Edge connected.
Music player active.
Vibrate mode.
SMS unread.
MMS unread.
Sending MMS.
Flight mode.
(1)
: indicates the selected line.
Getting started2
Set-up2.1
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power
off your phone and remove battery before inserting or removing the
SIM card.
Widget bar1.2.2
Widgets are convenient shortcuts for quick access from the Home
screen.
Lock/Unlock screen1.2.3
To protect your phone and privacy, you can lock the screen by pressing
and holding the Space key.
To unlock the screen, press
, then the Space key.
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card,
press it and slide it out.
Installing or removing the battery
Main menu 1.2.4
To access the main menu screen, select "Menu" from the Home screen.
Insert and click the battery into place, then close the telephone •
cover.
Unclip the cover, then remove the battery.•
(1)
Depending on your network operator.
5 6
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:5-Sec1:6IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:5-Sec1:6 2012-8-8 11:02:382012-8-8 11:02:38
Page 5
Installing and removing the memory card (microSD card)
Calls3
Placing a call3.1
Enter the desired number from the keypad directly or select a contact
from Contacts or Call log, then press the key to place the call. The
number you entered can be saved to Contacts by selecting "Save".
Insert the microSD card with its golden contact facing downwards into
the slot until it is locked in place. To remove it, gently push the card in
until it unlocks.
Charging the battery
Connect the battery charger to your phone and outlet respectively.
To reduce power consumption and energy waste, when battery
is fully charged, disconnect your charger from the plug; switch
off Bluetooth or background-running applications when not in
use; reduce the backlight time, etc.
Power on your phone2.2
Hold down the key until the phone powers on, type in your PIN code
if necessary. The main screen is displayed.
Set up your phone for the first time
The first time you power on the phone, you are required to adjust initial
basic settings and login to your Facebook account to synchronize
Facebook information.
Power off your phone2.3
Hold down the key from the Home screen.
7 8
If you make a mistake, you can delete the incorrect digits by pressing
the Delete key.
To hang up, press the
key.
Answering or rejecting a call3.2
When you receive an incoming call, press the key or select "Answer"
by pressing the key to answer.
Hang up the call by pressing the
is not one of your Facebook friends and the remind setting is active,
a reminder screen will appear to suggest sending a Facebook friend
request to the caller.
Calling your voicemail 3.3
Your voicemail is provided by your network to avoid missing calls. It
works like an answering machine that you can listen to at any time. To
access your voicemail, hold down the key.
key. If the caller (local contact only)
(1)
Changing the menus4
The menus can be changed to the way you want them.
Change the order
Access the main menu, focus on the main menu item you want to move,
select "Options/Move", and tick "√" will be shown on the item you
selected, then release it to your favorite destination.
Show/Hide
Access the main menu, select "Options/Add and remove menu", and
select the left check box of the selected menu once to show/hide, and
then select "Done" to save the operation.
(1)
Contact your network operator to check service availability.
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:7-Sec1:8IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:7-Sec1:8 2012-8-8 11:02:382012-8-8 11:02:38
Page 6
Messaging5 ........................
You may access this menu using the following options:
Access from the main menu screen by selecting "• Messaging".
from the widget bar.
Select •
SMS/MMS5.1
You can create, edit and receive SMS and MMS with this mobile phone.
MMS enables you to send video clips, images, photos, animations and
sounds to other compatible mobiles and e-mail addresses.
Write new SMS/MMS5.1.1
You can select "Write new SMS/MMS" from the messaging screen
to write text/multimedia messages. One or more recipients can be
added from the contact list and you can remove a recipient by pressing
. Select "Contacts" using the key and then select multiple
recipients.
An SMS will be converted to MMS automatically when images, videos,
audio, slides or attachments are inserted; Subject, CC/BCC/email
address is added; or the message contains more than 8 pages of text.
When finished entering text, press the
An SMS message of more than a certain number of characters
(the number of characters depends on your language) will
be charged as several SMS messages. An MMS message
containing photos and/or sounds may also be billed as more
than one message. Specific letters (accents) will increase the
size of the SMS, this may cause your recipient to receive your
message as two or more SMS messages.
Email5.2
Your phone has an email client with the settings pre-defined for a few
popular email services like – Gmail, Sky, AOL, etc. Besides these, you can
set up other POP3 or IMAP4 email accounts that you may be using.
key to send it.
Email account set-up5.2.1
Pre-defined email service
If you own an email account with a predefined service, you can install
it to your phone by selecting the service (Gmail, Sky, etc.), entering
the username, password and account name, and then confirming by
selecting "OK".
New email service
To set up a new email account other than the predefined email services,
select "Other Email accounts".
You are required to enter your email address, display name, password,
account name, then confirm with "Save". Afterwards you‘ll need to
select protocol
address and outgoing server address, and finally select "Save".
(1)
(POP3 or IMAP4), then enter your incoming server
Contacts6 .............................
Consulting your contacts6.1
You can access this function from the main menu screen by selecting
"Contacts" or selecting
When accessing this menu, you will see two tabs:
Phone
Group
When consulting your contacts for the first time, you are
required to import them from the SIM card to your phone.
Adding a contact6.2
You can add a new contact by selecting "Add contact".
The following fields are accessible when you create a new entry in
Contacts: Name, Image, Mobile, Home, Work, Email, Birthday, Birthday
reminder, URL, Address, Ringtone.
(1)
Consult your email service provider for more information about protocol.
from the widget bar.
List all contacts
Organize contacts into groups
9 10
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:9-Sec1:10IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:9-Sec1:10 2012-8-8 11:02:382012-8-8 11:02:38
Page 7
Call log7 ...............................
You can access this function like this:
Select • from main menu
Press • key from Home screen
Select •
from widget bar
All calls 7.1
The call log shows three different types of call:
Missed calls
Outgoing calls (Redial)
Answered calls
Locate one contact, select "View" to view call details, press the
to place a call directly.
key
Available options7.2
When you press "Options", you can have access to Send message, Dial,
Missed calls, Call settings, Edit before call, Delete, etc.
Voicemail7.3
From this menu, you can view all voicemail memory.
Facebook8 ...........................
Facebook is a social utility that connects people with friends and others
who work, study and live around them. You can select "Facebook" in
main menu to launch Facebook application.
11 12
Music9 ...................................
You can access this feature from the main menu screen by selecting
"Music".
From here, you can access either the Music player or the Radio.
Music player 9.1
Gives you full flexibility when managing music both on your mobile
and SD card.
Radio9.2
Your phone is equipped with an FM radio
You can use the application as a traditional radio with saved channels
or display parallel visual information related to the radio program if
you tune to stations offering Visual Radio service. You can listen while
running other applications.
(3)
Wi-Fi 10
Using Wi-Fi, you can connect to the Internet when your phone is within
range of a wireless network. Wi-Fi can be used on phone even when no
SIM card is inserted.
To access this function, press
.
To connect/disconnect a wireless network
Press "• Wi-Fi"
Select "• WIFI Connection"
If the network you selected is secured, you are required to enter a
password or other credentials (contact network operator for details).
When finished, select "Options/Done".
To disconnect a Wi-Fi network, select "Options/Disconnect".
(1)
The quality of the radio depends on the coverage of the radio station in
that particular area.
(2)
Depending on your network operator and market.
(3)
Depending on the model.
...............................
(1)
(2)
with RDS
functionality.
to enter the main menu, and select
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:11-Sec1:12IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:11-Sec1:12 2012-8-8 11:02:382012-8-8 11:02:38
Page 8
Available options:
Connect Press to connect to Wi-Fi network
Add Press to add new Wi-Fi networks of your
Define Access Point
Wi-Fi status Press to check the status of Wireless Local
Disable Wi-Fi Press to deactivate Wireless Local Area
Power save mode Press to select Constantly awake mode,
Refresh Press to refresh all the available Wi-Fi networks
choice when Wi-Fi is on
Press to set Access Point
Area Networks
Networks
Power save mode, Max power save mode
WEB11 ..................................
WEB lets you browse the entire Web anywhere. It recognizes and
suggests URL completions based on your bookmarks and browsing
history, lets you save pages for viewing offline and gives your phone a
virtual mouse.
Camera12 ............................
Your mobile phone is fitted with a camera for taking photos and
shooting videos.
To access this function, select
SD card (if available) is automatically set as the preferred
storage location for any photos and videos which you take.
from the main menu screen.
Pictures13
This menu displays the following two tabs when accessed:
Camera roll
Images
Videos
Facebook gallery is displayed in albums. The first album will be "Fan
photos" which is generated automatically and contains all pictures
where you have been tagged.
.............................
List photos you have taken
List images provided with the phone
List videos you have taken
Clock14 ...............................
Alarm14.1
Your mobile phone has a built-in alarm clock with a snooze feature.
You can set up to five separate alarms and choose whether or not the
alarm should repeat.
WorldTime14.2
The WorldTime shows current local time and the time zone in different
cities. You may view up to three cities at one time.
Time and Date14.3
Allows you to set the date and time in either 12/24h format.
You can also set the daylight saving adjustment.
13 14
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:13-Sec1:14IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:13-Sec1:14 2012-8-8 11:02:392012-8-8 11:02:39
Page 9
Calendar15 ..........................
Once you enter this menu from the main menu screen, you'll see a
month-view calendar for you to keep track of important meetings,
appointments, etc. Days with events entered will be marked in colour.
When you are logged onto Facebook, all your Facebook
friends' birthday reminders will be synced automatically to
your local calendar. An
to notify you of upcoming birthdays.
icon will appear on the status bar
Social16 ...............................
You can enter this menu by selecting "Social" on the main menu.
It enables to you easily access features including MSN, Gtalk, FBChat
and Twitter.
Apps17 ..................................
Access useful applications from this menu.
The applications you use most frequently can be added to or removed
from the main menu screen by selecting "Options" on the main menu
screen, and then select "Add and remove menu".
Tools18 .................................
You phone is equipped with several frequently used tools. You can
access these tools by selecting "Tools" on the main menu.
Weather18.1 ......................................................
Your phone is equipped with a weather app which will give you forecasts
of up to three days for favorite cities.
To access the function, select "Menu" through the
main menu screen and select
, then .
News18.2 .............................................................
A huge time saver, providing news updates from a website in a simple
form.
Once subscribed to a channel, it gives you the ability to track and
manage all your favorite RSS content on your mobile phone at anytime,
anywhere!
Tasks18.3 ..............................................................
Enables you to easily manage and track the progress of a task with
priorities. All the tasks will be sorted by due date.
key to access the
Notes18.4 ............................................................
You can create a note in text or voice format by accessing "Notes" from
the applications list.
15 16
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:15-Sec1:16IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:15-Sec1:16 2012-8-8 11:02:392012-8-8 11:02:39
Page 10
Calculator18.5 ....................................................
Access this feature by selecting "Calculator" from the applications list.
Enter a number, select the type of operation to be performed, and enter
the second number, then press the
key to display the result.
Converter18.6 ...................................................
You can use the Weight and Length conversion by selecting the unit
you wish to convert, then press the to input the digits. Finally
confirm with "OK".
Stopwatch18.7 ..................................................
The stopwatch is a simple application for measuring time with the ability
to register several results and pause/resume measurement.
File manager19 ..........................
You will have an access to all audio and visual files stored in phone or
SD card in File manager. You can access a number of items with this
option: My music, My images, My videos, Camera roll, Other files,
Phone, SD card, etc.
Inserting the SD card:
Settings20 ...........................
From the main menu, select the menu icon and select the function
of your choice in order to customize your phone.
Device sound profiles20.1
To modify the device sound profiles, select "Edit" to reveal the following
functions using the OK key: Mode, Ringtone, Ring type, Volume,
Keypad, Message beep, Power on beep, Power off beep.
Device settings20.2
Enables you to easily set your phone: Display, Set language, Time and
date, Headset mode, Keypad shortcuts, Set auto-lock time.
Connectivity20.3
A set of profile settings for Bluetooth, Data account, Multimedia
message, Internet, Email, Streaming, etc.
Bluetooth20.3.1
To use your phone with a Bluetooth device, you need to proceed in
two steps:
• Pair and register the device to your phone,
• Select it to use hands-free communication. Only one Bluetooth audio
device (your Bluetooth headset or your Bluetooth car kit) can be
connected during communication.
Factory reset20.4
Insert the microSD card with its golden contact facing downwards into
the slot until it is locked in place.
17 18
Select to restore factory settings.
All user data, files and downloaded applications will be lost
permanently.
You may also realize factory reset using hard keys: hold down
press key at the same time.
and
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:17-Sec1:18IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:17-Sec1:18 2012-8-8 11:02:392012-8-8 11:02:39
Page 11
Making the most of your 21
mobile
Vodafone Chat 655/655W PC suite21.1
Vodafone Chat 655/655W PC suite is available for downloading from the
website: www.vodafone.com/vodafonechat
The Vodafone Chat 655/655W PC suite includes:
Backup/restore•
You can backup important data in your mobile and restore it when
needed.
GPRS Modem•
Use your phone to connect a PC to the internet.
Multimedia Personalization•
Customize your phone with images, animations and melodies.
Music management•
Create and transfer playlists with music files and provide lyric editing.
Messaging•
You can compose SMS/MMS easily on your PC and transfer them to
your phone.
Supported Operating Systems
Windows XP/Vista/Windows 7•
Vodafone Chat 655/655W Software 21.2
Upgrade
Using the Vodafone Chat 655/655W Software Upgrade tool you can
update your phone’s software from your PC.
Download Vodafone Chat 655/655W Software Upgrade from website
(www.vodafone.com/vodafonechat) and install it on your PC. Launch the
tool and update your phone by following the step by step instructions
(refer to the User Guide provided together with the tool).
Your phone will now have the latest software.
All personal information will be permanently lost
following the update process. We recommend you backup
your personal data using Vodafone Chat 655/655W PC suite
before upgrading.
Webcam 21.3
You can use your phone as a webcam for instant messaging on your PC.
Connect your phone to your PC via the USB cable.•
Go to the "• My computer" folder on your PC and find the USB video
device.
(1)
Webcam use may vary according to the operating system of your PC.
(1)
19 20
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:19-Sec1:20IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:19-Sec1:20 2012-8-8 11:02:392012-8-8 11:02:39
Page 12
Text input mode/22
character table
There are two text entry methods that can be used to write messages:
Normal •
Predictive mode•
Normal
This mode allows you to type text by choosing a letter or a sequence
of characters.
Predictive mode
This mode can perform predictive input in the hardware keypad and
supports multi-language input.
Safety and use
We recommend that you read this chapter carefully before using your
mobile phone. The manufacturer disclaims any liability for damage,
which may result as a consequence of improper use or use contrary to
the instructions contained herein.
TRAFFIC SAFETY:•
Given that studies show that using a mobile phone while driving a vehicle
constitutes a real risk, even when the hands-free kit is used (car kit,
headset...), drivers are requested to refrain from using their mobile phone
when the vehicle is not parked. Check the laws and regulations on the
use of wireless mobile phones and their accessories in the areas where
you drive. Always obey them. The use of these devices may be prohibited
or restricted in certain areas.
When driving, do not use your mobile phone and headphone to listen
to music or to the radio. Using a headphone can be dangerous and
forbidden in some areas.
When switched on, your mobile phone emits electromagnetic waves
that can interfere with the vehicle’s electronic systems such as ABS antilock brakes or airbags. To ensure that there is no problem:
- do not place your mobile phone on top of the dashboard or within an
airbag deployment area,
- check with your car dealer or the car manufacturer to make sure
that the car’s electronic devices are shielded from mobile phone RF
energy.
CONDITIONS OF USE:•
You are advised to switch off the mobile phone from time to time to
optimize its performance.
Remember to abide by local authority rules of mobile phone use on
aircrafts.
Operational Warnings: Obey all posted signs when using mobile devices
in public areas.
Follow Instructions to Avoid Interference Problems: Turn off your mobile
device in any location where posted notices instruct you to do so. In
an aircraft, turn off your mobile device whenever instructed to do so
by airline staff. If your mobile device offers an airplane mode or similar
feature, consult airline staff about using it in flight.
Switch the mobile phone off when you are in health care facilities,
except in designated areas. As with many other types of equipment
now in regular use, mobile phones can interfere with other electrical or
electronic devices, or equipment using radio frequency.
Switch the mobile phone off when you are near gas or flammable liquids.
21 22
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:21-Sec1:22IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:21-Sec1:22 2012-8-8 11:02:392012-8-8 11:02:39
Page 13
Strictly obey all signs and instructions posted in a fuel depot, gas station,
or chemical plant, or in any potentially explosive atmosphere.
When the mobile phone is switched on, it should be kept at least 15 cm
from any medical device such as a pacemaker, a hearing aid or insulin
pump. In particular when using the mobile phone you should hold it
against the ear on the opposite side to the device, if any.
Read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about using
your mobile device with your implantable medical device, consult your
healthcare provider.
To avoid hearing impairment, answer the call before holding your mobile
phone to your ear. Also move the handset away from your ear while
using the “hands-free” option because the amplified volume might
cause hearing damage.
It is recommended to have proper supervision while small children use
your mobile phone.
When replacing the cover please note that your mobile phone may
contain substances that could create an allergic reaction.
Always handle your mobile phone with care and keep it in a clean and
dust-free place.
Do not allow your mobile phone to be exposed to adverse weather
or environmental conditions (moisture, humidity, rain, infiltration of
liquids, dust, sea air, etc.). The manufacturer’s recommended operating
temperature range is -10°C (14°F) to +55°C (131°F) (the max value
depends on device, materials and housing paint/texture).
Over 55°C (131°F) the legibility of the mobile phone’s display may be
impaired, though this is temporary and not serious.
Do not open or attempt to repair your mobile phone yourself.
Do not drop, throw or try to bend your mobile phone.
Do not use the mobile phone if the glass made screen, is damaged,
cracked or broken to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are
recommended by TCT Mobile Limited and its affiliates and are
compatible with your mobile phone model.TCT Mobile Limited and its
affiliates disclaim any liability for damage caused by the use of other
chargers or batteries.
Your mobile phone should not be disposed of in a municipal waste.
Please check local regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all
important information stored in your mobile phone.
Some people may suffer epileptic seizures or blackouts when exposed
to flashing lights, or when playing video games. These seizures or
blackouts may occur even if a person never had a previous seizure or
blackout. If you have experienced seizures or blackouts, or if you have
a family history of such occurrences, please consult your doctor before
playing video games on your mobile phone or enabling a flashing-lights
feature on your mobile phone. Parents should monitor their children’s
use of video games or other features that incorporate flashing lights
on the mobile phones. All persons should discontinue use and consult
a doctor if any of the following symptoms occur: convulsion, eye
or muscle twitching, loss of awareness, involuntary movements, or
disorientation. To limit the likelihood of such symptoms, please take the
following safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your mobile phone, you may experience
occasional discomfort in your hands, arms, shoulders, neck, or other
parts of your body. Follow these instructions to avoid problems such as
tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop
and rest for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after
playing, stop the game and see a doctor.
Prolonged exposure to music at full volume using the music
player may damage your hearing. Set your mobile phone’s volume
to it’s lowest setting prior to inserting headphones in your ears and
adjust the volume to your preference. Only use headphones that
are recommended by TCT Mobile Limited and it’s affiliates.
PRIVACY:•
Please note that you must respect the laws and regulations in force in
your jurisdiction or other jurisdiction(s) where you will use your mobile
phone regarding taking photographs and recording sounds with your
mobile phone. Pursuant to such laws and regulations, it may be strictly
forbidden to take photographs and/or to record the voices of other
people or any of their personal attributes, and reproduce or distribute
them, as this may be considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization
be obtained, if necessary, in order to record private or confidential
conversations or take a photograph of another person; the manufacturer,
the seller or vendor of your mobile phone (including the operator)
disclaim any liability which may result from the improper use of the
mobile phone.
23 24
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:23-Sec1:24IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:23-Sec1:24 2012-8-8 11:02:392012-8-8 11:02:39
Page 14
BATTERY AND ACCESSORIES:•
Before removing the battery from your mobile phone, please make sure
that the mobile phone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes
and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it
at temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally applicable
environmental regulations. Only use the battery for the purpose for
which it was designed. Never use damaged batteries or those not
recommended by TCT Mobile Limited and/or its affiliates.
This symbol on your mobile phone, the battery and the
accessories means that these products must be taken to
collection points at the end of their life:
- Municipal waste disposal centers with specific bins for
these items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in
the environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with
this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary
bins if your jurisdiction or your region has suitable recycling and
collection facilities; instead they are to be taken to collection points for
them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program
at www.recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS
CHARGERS•
Home A.C./ Travel chargers will operate within the temperature range of:
0°C (32°F) to 40°C (104°F).
The chargers designed for your mobile phone meet with the standard
for safety of information technology equipment and office equipment
use. Due to different applicable electrical specifications, a charger you
purchased in one jurisdiction may not work in another jurisdiction. They
should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.15 A
Output: 5 V, 550 mA
Battery: Lithium 1000 mAh
RADIO WAVES:•
THIS MOBILE PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radio-frequency (RF) energy. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed
by independent scientific organizations through periodic and thorough
evaluation of scientific studies. These guidelines include a substantial
safety margin designed to ensure the safety of all persons, regardless
of age and health.
The exposure standard for mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by
public authorities such as the Federal Communications Commission of
the US Government (FCC), or by Industry Canada, is 1.6 W/kg averaged
over 1 gram of body tissue. Tests for SAR are conducted using standard
operating positions with the mobile phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the
actual SAR level of the mobile phone while operating can be well below
the maximum value. This is because the mobile phone is designed to
operate at multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the mobile phone. Before
a mobile phone model is available for sale to the public, compliance with
national regulations and standards must be shown.
25 26
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:25-Sec1:26IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:25-Sec1:26 2012-8-8 11:02:392012-8-8 11:02:39
Page 15
The highest SAR value for this model mobile phone when tested is 0.826
W/Kg (Vodafone Chat 655/655W) for use at the ear and 1.06 W/Kg
(Vodafone Chat 655W, with 1.0cm distances), 0.685 W/Kg (Vodafone Chat
655, with 1.5 cm distances) for use close to the body.
While there may be differences between the SAR levels of various
mobile phones and at various positions, they all meet the government
requirement for RF exposure. For body-worn operation, the mobile
phone meets FCC RF exposure guidelines provided that it is used with
a non-metallic accessory with the handset at least 10 mm from the
body. Use of other accessories may not ensure compliance with FCC RF
exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site: http://
www.phonefacts.net
The World Health Organization (WHO) considers that present scientific
information does not indicate the need for any special precautions for
use of mobile phones. If individuals are concerned, they might choose
to limit their own or their children’s RF exposure by limiting the length
of calls, or using “hands-free” devices to keep mobile phones away from
the head and body. (fact sheet n°193). Additional WHO information
about electromagnetic fields and public health are available on the
following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for
help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
For the receiver devices associated with the operation of a licensed radio
service (e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject
to the condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Your mobile phone is equipped with a built-in antenna. For optimal
operation, you should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in
positions other than against your ear. In such circumstances the device
will be compliant with the guidelines when used with headset or usb
data cable. If you are using another accessory ensure that whatever
product is used is free of any metal and that it positions the mobile
phone at least 10 mm away from the body.
27 28
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:27-Sec1:28IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:27-Sec1:28 2012-8-8 11:02:392012-8-8 11:02:39
Page 16
LICENCES •
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks by
TCT Mobile Limited and its affiliates is under license.
Other trademarks and trade names are those of their
respective owners.
Bluetooth QD ID B018931
The Wi-Fi Logo is a certification mark of the Wi-Fi
Alliance.
General information
Website: • www.alcatelonetouch.com
Facebook:• http://www.facebook.com/alcatelonetouchusa
Twitter:• http://www.twitter.com/alcatel1touch
Hot Line Number• : In the United States, call 877-702-3444 for
technical support.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatelonetouch.
com
Your mobile phone is a transceiver that operates on following networks:
Vodafone 655W: Blue 3G GSM Qual Band (850/900/1800/1900) and
UMTS Dual Band (900/2100) with WiFi
Vodafone 655: Blue 3G GSM Qual Band (850/900/1800/1900) and
UMTS Dual Band (900/2100) without WiFi
Protection against theft
Your mobile phone is identified by an IMEI (mobile phone serial
number) shown on the packaging label and in the product’s memory.
We recommend that you note the number the first time you use your
mobile phone by entering *#06# and keep it in a safe place. It may be
requested by the police or your operator if your mobile phone is
stolen.
Disclaimer
There may be certain differences between the user manual description
and the mobile phone’s operation, depending on the software release of
your mobile phone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences, if
any, nor for their potential consequences, which responsibility shall be
borne by the operator exclusively.
(1)
Contact your network operator to check service availability.
(1)
29 30
IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:29-Sec1:30IP4347_VF655_VF655W_QG_Eng_USA_Black_02_120808.indd Sec1:29-Sec1:30 2012-8-8 11:02:392012-8-8 11:02:39
Loading...
