TCT Mobile 001 Users Manual

English
3DS09782AAAA01
www.alcatel.com
English
ALCATEL BUSINESS SYSTEMS © 2003. All rights reserved. ALCATEL reserves the right, in customer's interest, to alter material or technical specifications without prior notice.
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 1
2
7. Directories p. 30
7.1 Accessing your directories p. 30
7.2 Creating a directory file p. 32
7.3 Classifying a file in a family p. 33
7.4 Available options p. 34
7.5 Assigning a ring tone to a family p. 36
7.6 Temporary SIM card p. 36
8. Messages p. 37
8.1 Accessing messages p. 37
8.2 Reading your messages p. 38
8.3 Writing a message p. 43
8.4 Data entry system: predictive mode p. 45
8.5 Sending a message p. 48
8.6 Deleting your messages p. 49
9. My setup p. 50
9.1 Sounds p. 50
9.2 Pictures p. 55
9.3 Black/White background (Negat.Screen) p. 55
9.4 Downloaded data (Downloaded) p. 56
9.5 Zoom p. 57
9.6 Numbers p. 57
10. Games p. 59
1
CONTENTS
Safety and precautions p. 4
Information p. 9
1.Your telephone p. 11
1.1 Keys p. 11
1.2 Icons p. 13
1.3 Symbols used in the User Guide p. 14
2. Getting started p. 15
2.1 SIM Card and battery p. 15
2.2 Switching your phone on p. 18
2.3 Switching your phone off p. 18
3. Calls p. 19
3.1 Making a call p. 19
3.2 Calling your voice mail p. 20
3.3 Receiving a call p. 20
3.4 Options available while calling p. 21
3.5 Double line management p. 24
4. Call memory p. 25
5. MENU p. 26
6. Events p. 29
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 1
4
SAFETY AND PRECAUTIONS
We recommend that you read this chapter carefully before use.The manufacturer disclaims any liability for damage which may result as a consequence of improper use or use contrary to the instructions contained herein.
TRAFFIC SAFETY:
Given recent studies, which show that using a mobile telephone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset…), drivers are requested to refrain from using their mobile telephone when the vehicle is not parked.
Your mobile phone when powered emits radiation which may interfere with the vehicle electronic systems such as anti-lock brakes (ABS, airbag). As a result, you should:
-avoid placing the phone on the dashboard or within an airbag deployment area.
- connect the phone to an external antenna or switch the phone off. The antenna should be mounted and located away from the driver and passengers or separated from them by a metal screen (e.g. the car roof).
- check with the car manufacturer or your car dealer that the dashboard is adequately shielded from mobile phone RF energy.
CONDITIONS OF USE:
Switch the phone off before boarding an aircraft to avoid
prosecution.
Switch the phone off when you are in health care facilities, except
3
11. Alarms p. 63
11.1 Wake up p. 63
11.2 Appointments p. 64
11.3 Birthdays p. 64
11.4 Options p. 64
12. Calculator/Converter p. 65
12.1 Calculator p. 65
12.2 Convert p. 66
13. Setup p. 68
13.1 Services p. 68
13.2 Clock p. 76
13.3 Languages p. 76
13.4 Dictionary p. 76
13.5 Input mode p. 77
13.6 Display p. 77
13.7 Pickup p. 77
13.8 Automatic power off p. 78
13.9 Double line management p. 78
13.10 Keypad lock p. 78
14.WAP p. 79
14.1 Accessing WAP Services p. 79
14.2 Available options p. 80
14.3 Setting up your access p. 82
14.4 Launching WAP p. 84
15. Warranty p. 85
16. Character set p. 88
17. Accessories p. 89
18.Troubleshooting p. 91
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 3
6
CHARGERS
Mains powered chargers mains will operate within the temperature range: 0 to 40°C. The chargers designed for your mobile phone meet with the standard for safety of information technology equipment and office equipment use.They should be used for this purpose only.
RADIO WAVES:
THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
5
in designated areas. As with many other types of equipment now in regular use, mobile telephones can interfere with other electrical or electronic devices, or equipment using radio frequency. When the phone is switched on, avoid placing it near a medical aid device, if you carry one, such as a pacemaker, one hearing aid or insulin pump. When using the phone you should hold it against the ear on the opposite side to the device, if any.
Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, gas station, or chemical plant, or in any potentially explosive atmosphere. Do not let small children use the phone without supervision. Do not attempt to open or repair it yourself. Use only Alcatel batteries, battery chargers, and accessories that are compatible with your phone model. (See Accessories List, chapter 17). Alcatel will not be held responsible if this is not respected. Do not allow your phone to be exposed to unfavourable environmental conditions (humidity,rain, infiltration of liquids, dust, sea air, etc). The manufacturer’s recommended operating temperature range is -10°C to + 55°C. Over 55°C the legibility of the phone’s display may be impaired, though this is temporary and not serious.
BATTERY:
Before removing the battery from your phone,please make sure that the phone is switched off.Take precautions with the battery and do not attempt to open the battery (chemical substances may cause burns). Do not pierce, disassemble nor cause a short-circuit in a battery.Do not burn or dispose of a used battery in household waste or store it at temperatures above 60 °C. Batteries must be disposed of in accordance with locally applicable environmental legislation. Batteries should not be used for any other purpose than the one intended. Never use damaged batteries.
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 5
87
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such as the Federal Communications Commission of the US Government (FCC) or by Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue.
Tests for SAR are conducted using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the phone.
Before a phone model is available for sale to the public, compliance with national regulations and standards must be shown.The highest SAR value for this model phone when tested for use at the ear is
0.24 W/Kg and for use close to the body is 0.74 W/Kg. While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for RF exposure.
Your telephone is equipped with a built-in antenna. For optimal operation, you should avoid touching it or degrading it.
The World Health Organization (WHO) considers that present scientific information does not indicate the need for any special precautions for use of mobile phones. If individuals are concerned, they might choose to limit their own or their children's RF exposure by limiting the length of calls, or using "hands-free" devices to keep mobile phones away from the head and body. " (fact sheet n°193).
Additional WHO information about electromagnetic fields and public health are available on the following site : http://www.who.int/peh­emf."
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 7
109
Web site: www.alcatel.com
Wap address: wap.alcatel.com
Alcatel hotline No.: see “Alcatel Services” leaflet (calls charged at
applicable local rate in your country).
Your telephone is a transceiver that operates on GSM networks with 1900 MHz bands (One Touch 331p) or 850 and 1900 MHz bands (One Touch 331a).
Pr
otection against theft
Your telephone is identified by an IMEI (phone serial number) shown on the packaging label and in the product’s memory.We recommend that you note the number the first time you use your telephone by entering , , , , and keep it safely. It may be requested by the police or your operator if your telephone is stolen. This number allows your mobile telephone to be blocked preventing a third person from using it, even with a different SIM card.
January 2003
INFORMATION
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 9
(1) Depending on your phone model.
!
12
Switch phone On/Off from the main screen (long
keypress).
Access the MENU / Confirm the option (short keypress). Access the “Operator” services (long keypress).
Volume control during a call. Scroll to select an option.
Access the directory (keypress downwards). Access the messages (keypress upwards).
Ans
wer/Hang up
Access the call memory (Redial) (short keypress).
Access your voice mail (long keypress).
Switch On/Off the backlighting (long keypress). Access WAP (long keypress) (1).
Lock or unlock the keypad (long keypress). Enter upper / lower case letters, digits, punctuation marks, access the bar of symbols.
Activate / deactivate the vibrator (long keypress).
1.1
11
1
1
YOUR TELEPHONE
ok
05:13
18-04-2002
Delete
Switch on
Switch off
Back
Voicemail
Backlighting
WAP access (1)
Answer
Hang up
Call memory
Menu
Scroll
Messages
Directory
Vol ume
Lock / Unlock
keypad
Vibrator
Network
Delete (short keypress). Return to the previous screen (short keypress). Return to the main screen (long keypress).
Keys
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 11
OK
OK
1.3 Symbols used in the User Guide
(1) Depending on your phone model. Check the
availability of this service with your operator.
!
14
Indicates the line number when the SIM card has two distinct telephone numbers (1).
Preferred tariff area. (1)
Keypad locked.
“Manual Network Search” mode.
(See page 75)
Roaming within your subscription country.
The following symbols are used throughout the guide:
Briefly press the centre of the scroll key to confirm an option.
Move the scroll key up or down to select an option.
Use the keypad keys to enter digits, letters, and punctuation marks.
OK
OK
(1) Icons and other illustrations shown in this User Guide
are for information only.
(2) Check the availability of this service with your
operator.
!
1.2
13
Battery charge level.
Vibrator mode: your telephone vibrates but emits no ring
tone nor beep. (See page 52)
Silent mode: your telephone emits no ring tone, no beep and does not vibrate. (See page 52)
Events (Information to consult): voice messages, all unanswered calls, unread short messages, downloaded data (see page 29), and WAP alerts (2).
Short message list is full: your telephone cannot store any more messages.You must access the short message list and delete at least one message. (See page 49)
Call Forwarding activated: your calls are forwarded. (See page 71)
Programmed appointments, birthdays, or wake-up.
(See pages 63, 64)
Signal strength indicator.
Icons (1)
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 13
16
Close the cover and slide it as shown
Click into place
1
1
2
CLICK
2
Inserting the battery
Insert the battery
(1) The telephone is compatible with 3 V, 3/5V, and 1.8/3 V
SIM cards. Former 5 V SIM cards can no longer be used. Contact your operator.
!
2.1 SIM Card and battery
15
You must insert a SIM card in order to use your phone.
Fit SIM card with the chip facing downwards
Slide the SIM card into its compartment. Check that it is properly inserted
Push the SIM card with your finger to release it
1
2
1
2
2
GETTING STARTED
Inserting and removing the SIM card (1)
Press the button and pull the cover
Remove the battery
1
2
1
Press
2
Removing the battery
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 15
2
2.3 Switching your phone off
2.2
Switching your phone on
If you do not know your PIN code, please contact your network operator.
Do not leave your PIN code near your phone and store your card in a safe place when you are not using it.
!
18
If you are prompted to enter the time and date, enter the new data if necessary, then confirm by .
If cell broadcast messages are displayed, use the key to browse through them in full or press the key to return to the main screen.
While the phone is searching for a network, <<<–>>> is displayed. (???-??? is displayed if your SIM card is rejected by the network, in this case please contact your operator).
OK
From the main screen, press the key (long keypress).
Switch your phone on (long keypress)
Enter your PIN code if
you are prompted to
Main screenConfirm
Network
Pin Code
Please enter PIN Code:
..................
Use exclusively Alcatel chargers that are compatible with your phone model.
When you first use your phone you must charge the battery for approximately 3 hours.
For optimal backlighting, your battery must be fully charged.
!
17
Connect the battery charger
The on-screen indicator stops flashing when charging is over
Disconnect the battery charger once charging is complete
1
2
1
2
Charging the battery
•A short beep will sound when charging begins.
• The charging indicator icon may take several minutes to start to
flash if your battery is new or very low.
• The mains socket outlet must be close to the phone and easily
accessible.
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 17
OK
05:13
18-04-2002
OK
The caller's number is displayed if it was transmitted by the network (check the availability of this service with your operator).
!
3.3 Receiving a call
To use your voice mail abroad, contact your operator before leaving. If your operator's voice mail access number is not shown, dial the number that was supplied to you with your subscription. To later modify this number, use the “Numbers” MENU option. (See page 57)
!
3.2
Calling your voice mail
20
Your voice mail works like an answering machine that you can consult at any time. Access the voice mail with a long keypress on , the screen will then dispay the message “Call?”,confirm by pressing or press
to make the call.
When receiving a call, answer by pressing ,speak, then hang up by pressing .
You may find the country’s or the area’s name by pressing the key associated with the first character of its name. Once the “Country/area” code is displayed, dial the rest of the number and make the call.
If you make a mistake, you can delete digits by pressing the
key.
To enter characters "+" or "P" (pause), make a long key­press on (the following characters scroll: 0, +, •, P).
!
3.1
Making a call
19
3
3
CALLS
Hello
Dial the number
Make the call
Hang up
To make an emergency call, if your telephone is within the area covered by a network, dial 112 or the emergency number provided by your operator.
To make an international call:
Display the "+"
prefix (long
keypress)
Display the list of countries
Select the
country/area
Confirm
Cntry/area
Albania Algeria Andorra
Talk
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 19
OK OK
OK
OK
(1) Check the availability of this service with your
operator.
!
22
OK
A beep will inform you of a second incoming call.
If you accept the new call by pressing the key, the ongoing call is automatically put on hold; you can then swap between the calls by pressing the key and then the key.
To r efuse the second call, press the key twice.
OK
Handling a second incoming call (1)
OK
18:06
MARIE
AUDREY
18:08
MARIE AUDREY
...
18:08
MARIE AUDREY
...
Swap calls
Directory Access the directory
Messages
Services (1)
Back Return to the previous screen
Access the services supported by your network operator
Read your messages
(1) Check the availability of this service with your
operator.
!
3.4
21
Options available while calling
Volume
Hold call (1)
Handsfree
Dial (1)
Increase or decrease the sound level
Make a second call (an ongoing call will be automatically put on hold and you can switch between calls by pressing the key)
Activate/deactivate the handsfree mode (the symbol is then replaced by )
Caution: move the handset away from your ear before activating this mode because the amplified volume could cause hearing damage
Place an ongoing call on hold (you can later resume the call by pressing the key)
OK
Save Number
Store a phone number in one of your directories: SIM or Product (Mobile)
the vibrator is activated: the telephone will not ring.
the vibrator and ring tone are switched off.
To switch off the ring tone, press when the telephone rings.You can take a call by pressing . If you press again, the call will be rejected.
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 21
OK
OK
OK
3.5
Double line management (1)
During a call, you can use the key to adjust the volume. (1) Check the availability of this service with your
operator.
!
24
Your SIM card can contain two lines with two different phone numbers.
By default, you are automatically on line 1. To switch from line 1 to line 2, open “Menu/Setup/Double line/Line choice” (1).
Whichever line is selected (1 or 2) you can receive calls intended for both lines. Calls made will be invoiced on the selected line.
Select "Conference"
The 3rd person joins the conference
Confirm
OK
Pressing the key hangs up the communication you had with the
correspondent you have selected.
To end the conference call, click on the key and select the
“End Conf. Call” option.
OK
Swap calls End 2nd call Conference
MARIE
AUDREY
FREDERICK
(1) Check the availability of this service with your
operator.
!
23
You are handling 2 calls
Confirm
Select “Conference”
The conference starts
A third call comes in
Confirm
Answer the call and speak with
your new correspondent
OKOKOK
A third call comes in
FREDERICK
Swap calls End 2nd call Conference
MARIE AUDREY
...
MARIE AUDREY
MARIE
AUDREY
FREDERICK
Your telephone allows you to converse with several persons at the same time.
Conference calls (1)
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 23
OK
26
Previous screen: Press (short keypress).
Main screen: Press (long keypress).
OK
OK
List of functions
Select an option
Confirm
Main screen
Select “Menu”
Confirm
5
5
From the main screen, press the key to go to the MENU.
OK
OK
OK
MENU
Selection of a MENU function
Return to the screens
05:13
18-04-2002
Network
My setup
Sounds Pictures Negat.Screen
Sounds
Mode Volume Ring Tones
Services
Menu
Directory Messages My setup Games
The caller's number is displayed if it was transmitted by the network (check the availability of this service with your operator).
To r eturn to the main screen, press the key (long keypress).
!
4
4
25
To access the call memory, press , the screen will display the last numbers called preceded by the following symbols:
= Answered incoming call.
= Unanswered incoming call.
= Outgoing call.
Select the number you want by pressing then press to make the call.
CALL MEMORY
Save Number
Modify Num.
Clear
CallMem
Back
Store the selected phone number in the directory
Return to the previous screen
Clear all the numbers in the call memory
Modify the selected phone number
Using available options
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 25
OK
OK
(1) Depending on your phone model.
28
Games:
Access the games proposed.
My tribe: Access an instant messaging WAP site (1).
Alarms:
Set your telephone's alarms (appointments, birthdays, wake­up).
Calculator/Converter:
Perform currency conversions (Euros/currencies, etc.) and basic calculations.
Setup:
Set up your telephone (displays, formats, etc.) and take advantage of the features provided by your operator (security, call forwarding, etc.).
You can customise your main MENU by changing the order of the options. For example, you can choose to display “Sounds” at the beginning of your Menu: select this option, make a long keypress on the key to place it in the first position in your new list. The icon is displayed after the selected option. To cancel this duplicated item, select it in the list and make a long keypress on the key.
!
(1) Depending on your model, the language and availability
of this service with your operator.
!
27
For each of the listed functions, refer to the appropriate chapter in this User Guide.
Events:
Access your voice mail, unanswered incoming calls, unread short messages, and information downloaded in the handset as well as WAP alerts (1).
Directory:
Access / create directory files and make calls from your directory.
Messages (SMS):
Read, write and send your short messages.
My setup:
Customise your ring tones, icons, On/Off and main screens, your direct dial numbers, your keypad and prefixes and the black/white screen background (Negat.Screen).
Organisation of functions
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 27
7.1 Accessing your directories
30
7
7
DIRECTORIES
Tw o directories are available, the SIM directory and the product
directory (Mobile).
For easy consultation, all your contacts are stored in a joint list.
The icon displayed in front of a name indicates whether the name belongs to the SIM directory or to the Mobile’s:
SIM directory
Product directory (Mobile).
• Access directories from the main screen by pressing downwards.
• Or from the MENU (cf. page 26) by pressing then selecting
“Directory”.
OK
To search for the name you are looking for
OK
OK
OK
SIM Dir.
VERONICA
BRIAN
FLORENCE
Directory Messages My setup Games
(1) Check the availability of this service with your
operator.
29
You can access events sent to your telephone that you have not yet read or listened to.
EVENTS
6
6
!
Messages (Msg.): Access unread messages. (See page 37)
Unanswered incoming calls (Call):
Display the calling parties’ numbers that tried to reach you with no success. (See page 25)
Voice mail (Vocal):
Call your voice mail to listen to your new voice messages. (See page 20)
Alerts (WAP) (1): Access the WAP alerts you have received.
Information downloaded (Dnload):
Consult the information that you have downloaded.
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 29
OK
7.2 Creating a directory file
If you use your telephone abroad, you should store the numbers in the directory in the international format with the “+” prefix. (See page 19)
!
32
If your directories are empty, the “Directory empty! Create a file?” message will be displayed.
From the list of names in your directories, press the key to create a file.
OK
Each name in a directory can have up to 3 numbers: Home, Mobile, Office.
Files created in the SIM directory can be consulted from a different mobile phone.
OK
OK
OK
View Create Zoom
Create
In SIM In Mobile
Create
Enter name:
VERONICA
0148............
0663............
139............
31
You can assign 3 different numbers to the same name: Home, Mobile, Office (see page 32). If you want to call a party who has several numbers, first you must choose the number you wish in the list.
or
OK
Choose the appropriate number
You can also search for the name of the person you wish to contact by pressing the key associated with the first letter of his/her name.
Example: Press the key twice to find the first name beginning with “B”, then scroll the list to the name you are looking for using the
key. In some languages, depending on the input mode, this
search is performed using the “Search name” option. (See page
34)
Searching for a name by its first letter
Calling from the directory
Displaying a phone number
View Create Zoom
SIM Dir.
VERONICA
DENNIS
HELEN
SIM Dir.
VERONICA
DENNIS
HELEN
SIM Dir.
VERONICA
HOME
MOBILE
OK
OK
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 31
OK
7.4 Available options
(1) Depending on the language.
!
34
From the list of names in your directory, you can access the following options by pressing the key:
OK
(1) If the caller’s number is displayed.
!
You do not have to fill in all the information, but at least one number must be entered for each name.
Up to 250 phone numbers can be stored in the product directory. The SIM directory's capacity depends on the operator.
!
7.3 Classifying a file in a family
33
Switch from one to another by pressing the key or key.
OK
To differentiate your files, you can classify them in groups called “families”: Private , Profession. , Other , or None. A different ring tone can be assigned to each family. This classification will allow you to easily distinguish a professional call from a private call (1). It is possible to screen incoming calls by family. (See pages 73,
74)
The files you created may be organised in alphabetical order, by family (Private , Profession. , Other , or None) or by directory (SIM then Mobile). (See page 32)
Create
Home:
Create
Mobile:
Create
Office:
Create
View
Modify
Create a file
Modify the file contents
Delete Delete the selected file
Display the contents of each file
Zoom
Organise
Change the character size (1)
Search name
Find a name in a list (1) according to the entry mode
Display names:
- In alphabetical order
- By family: Private, Professional, Other or None
- By directory: SIM then Mobile
Classify
Ring tones Assign a melody to a family
Classify the selected file in the appropriate family
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 33
OK
OK
7.6 Temporary SIM card
7.5 Assigning a ring tone to a family
36
•Keypress on : the SIM card you just inserted becomes your main card. You can create the files with up to three numbers (Home, Mobile, Office). If you reinsert your old SIM card, you will no longer find the three numbers that were formerly associated with the same name.
• Keypress on : the SIM you just inserted is considered as “Temporary”.You will be able to create or modify files with one number only. If you then reinsert the first card (your main card), you will find the three number association it originally contained.
OK
When you create a file, you can include 3 different numbers (Home, Mobile, Office).
If you change your SIM card,an information message will be displayed when the telephone is switched on.You must then decide if this card will become your main SIM card or if it is being inserted temporarily:
New SIM
(C): Main OK: Temporary
You can assign a ring tone to a family, so when you receive a call from a contact classified in a particular family, the ring tone for the incoming call will be the one assigned to that family. An icon is also assigned to each family, allowing you to easily recognise your correspondent’s family. (See page 33)
35
You can copy a file or all the contents of a directory to another. You may choose to keep or to delete the original directory or file.
OK
OKOKOK
Copying from one directory to another
Ring tones Copy Copy all
SIM -> Mobile
Mobile -> SIM
Keep origin
Delete origin
SIM Dir.
VERONICA
BRIAN
FLORENCE
Copy Copy a file from a directory into the other
Copy all Copy the whole directory into the other
Memory
Back Return to the previous screen
Display the available memory in your directories
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 35
8.2 Reading your messages
8.1 Accessing messages
(1) To deactivate the audible signal (see page 50).
38
When a new message is received, a screen message “Do you want to read your new messages?” and the icon are displayed and
an audible signal (1) is emitted.
The icon disappears when all new “Events” (messages, calls, ...) have been consulted.
“Unread” messages
!
OK
OK
• Read immediately
If you want to read immediately the messages, press the key.
OK
Do you want to
read your new
messages?
Unread
0607...
0613...
Unread
08:30
Network
09/03 09:03
: 0613....
Don’t wait
(1) Check the availability of this service with your
operator.
(2) Depending on the language.
!
37
8
8
MESSAGES (1)
Make a keypress upwards on the key from the main screen.
Or press the key from the MENU (see page 26) and select
“Messages”.
OK
Unread
Read/Saved
Write
Delete msg
Read the new messages
Delete your messages by category
My canned
Complete a canned message or create your own canned messages
Create a new message
View the read messages
Zoom
Parameters
Change character size (2)
Set parameters, especially the number of the service centre if it is not automatically displayed (you cannot send a message without this number)
Archives
View the messages archived in the telephone’s memory
The messages will be automatically stored on your SIM card directory, but you can store them in your telephone’s memory by selecting the “Archive” option.
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 37
OK
OK
(1) Except protected objects (sounds, images). (2) If the received message contains sounds, images, icons,
animations.
!
40
OK
While reading a message, you can access the following options using the key:
OK
Available options
The capacity of your SIM card depends on your operator. The icon is displayed when there are too many stored messages: please delete some.
!
39
OKOKOK
• Read later
If you want to read your messages later, press the key.
Events Directory Messages My setup
Do you want to
read your new
messages?
08:30
Network
Services
Menu
Network
1 Msg.
0 Call
0 Vocal
Save icon (2)
Store an icon in the list of icons
Save
Animation (2)
Store an animation in the list of animations
Save
sound (2)
Store a sound in the list of sounds
Archive
Save from your SIM card to the telephone memory
Save
canned (1)
Store this message as a canned message
Delete
Answer
Forward (1)
Delete the selected message
Forward the selected message after modifying the recipient's name or the parameters
Write a message in reply to a message you received
Save Number
Store the original message number or the destination number in the directory
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 39
05:13
18-04-2002
42
Receiv
ed: All messages that you received, read, and stored. Your friends can send you messages containing icons, animations, mood icons, sounds, and texts. When you receive those messages, you may also store these objects so that you can use them later.
If a message contains several icons, sounds, or animations, select the object using the key and confirm with the key.
You can call one of the numbers that appears in a message you have
received by pressing .
T
o send: All written and not yet sent messages. Sent: All written, sent and stored messages. If “Receipt” was activated in the “Parameters” option,when you view the sent messages, the following symbols are displayed:
Message sent in expectation of an acknowledgement receipt.
Message sent and acknowledgement received.
Message unsuccessfully delivered (in this case you should send the message again).
“Archived” messages
These messages can be read or written messages that you have sent from the SIM card memory to the telephone memory.You can save up to 30 messages in your telephone memory.
Archived messages are classified in three groups: Received,To send, Sent.
OK
(1) Check the availability of this service with your
operator.
(2) Depending on the language.
!
41
“Read/Saved” messages
These messages can be read messages, written messages which are sent or not sent, or messages that are stored on the SIM card.
Back
Return to the current message
Zoom
Change the character size (2)
Parameters
Update the following parameters: Serv. Centre: your operator’s service centre number (may be provided automatically) E-mail centre (1):calling number for sending an e-mail (can be automatically presented to you) Format: in which the message is to be delivered to your correspondent (SMS, e-mail, fax, etc.) Validity: time during which the network presents the message again to your recipient in case of unsuccessful delivery Receipt: activate/deactivate the acknow­ledgement receipt request
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 41
OK
The underlined options (see page 44) will be displayed only in the predictive mode.
!
44
Send to Send the message
Insert Icon
Add icons (only valid for non protected EMS icons)
Insert Sound
Add sounds (only valid for non protected EMS sounds)
Insert Mood Add mood icons
Exit message
To exit the current message and return to the messages menu
Preview Preview the message
Save message
OtherWords Access the list of other suggested w
ords
Save the message
Back Return to the previous screen
Add word
Insert digits
Punctuation
Ad
d a word to the dictionary (depending
on the language)
Insert a punctuation mark
Predictive/
Normal mode
Switch from normal to predictive mode
Language Modify the dictionary language
Insert digits
8.3
43
Make a keypress upwards on the key from the main screen.
Or press the key from the MENU (see page 26) and select
“Messages”.
You can create a message or amend a stored message. You can create a message with text only but can also assign icons or sounds, or mood icons (See page 47)
OK
Writing a message
The shape of the cursor will tell you whether you are in:
- predictive mode (data entry system, see page 45) or
- normal mode
To s witch from one mode to the other, make a long keypress on the key.
While writing the message, depending on the selected entry mode, you can access the following options by pressing the key.
OK
Messages
Unread (5) Read/Saved (4) Write
Directory Messages My setup
Games
1 Message(s)
Do you
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 43
OK
OK
OK
OK
8.4
Data entry system (1): predictive mode
(1) Depending on the language.
!
You may also use the following keys:
There is a dictionary in which you can add (1), modify or delete words. To add a word while writing a message, press the key and select the “Add word” option (1).
OK
ok
05:13
18-04-2002
Access the
options
Accept displayed
word or number
(press
downwards only)
Scroll the word
or text
Upper case/lower
case/numbers /
access to symbol bar
Switch between
Normal/Predictive
mode (long
keypress)
Delete
Space
Other words
Network
46
The character displayed may not correspond to the one you requested; the system suggests the most usual word. Do not worry about the words initially suggested, go on typing, the system will make better suggestions as you type.
!
(1) Depending on the language.
!
45
To make it easier to write short messages, your phone has an assisted data entry system: in predictive mode (1), the cursor looks like a thick bar . To create a word, you only need to pr
ess once the key
for each letter contained in the word.
When you have finished typing your word:
• If the suggested word is the one you want: Press to validate and insert a space.
• If the word suggested is not the one you want: Press to scroll for other suggestions and validate your choice of word by pressing .
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:53 Page 45
8.5
Sending a message (1)
(1) Messages exceeding 160 characters, input of icons,
sounds and mood icons may result in the billing of several SMS.The number of SMS will be indicated on the screen while typing and there will be a beep for every new message.
!
48
You can send a message:
•To a recipient in your directories. (See page 30)
• Manually by keying in your correspondent’s number.
OKOKOK
•To several recipients by selecting the group of recipients (choose
the “Distrib.list” option). The list should have been created beforehand.
•To a recipient with an e-mail address, if you have stored the email
centre number using the “Parameters” option. (See page 41)
Send to
Insert Icon
Insert Sound
Addresses
Directory Dial Distrib.list
Messages
To: 255
255:
3 Messages Sent
47
Your messages can be customised with icons, sounds or mood icons to reflect your emotion:
Ironic Sad Glad
Confused Amazed Happy
Indifferent Crying In love
Devil Angry Laughing
Inquiring Show-off Joking
You can also create your own mood icons using the alphabetical characters (example: :-)).
While writing the message, the sound or icon that you inserted is represented by a symbol ( or ).
You can add more icons and sounds to your phone by downloading them from the Internet. (See page 56)
The recipient of the message must have a compatible EMS (Enhanced Message Service) mobile phone in order to display icons and mood icons, and listen to the sounds attached to your message.
Icons, sounds, mood icons
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 47
9.1 Sounds
50
9
9
From the “Sounds” menu, press the key to access the various options.
OK
From the main screen, press the key to access the MENU.
Select “My Setup” then one of the proposed options.
OK
OK
OK
OK
MY SETUP
Directory Messages My setup Games
My setup
Sounds Pictures Negat.Screen
My setup
Sounds Pictures Negat.Screen
Sounds
Mode Volume Ring tones
8.6 Deleting your messages
The icon means that the message list is full.You must delete at least one of them to receive new messages.
!
49
You can delete several messages at once by selecting the “Delete msg” option.
You can then access the following options:
All
Sent
Received
Before...
Delete all messages
Only delete messages (sent and received) prior to a date you have specified
Only delete messages you have received and read
Only delete messages that you have sent
Archives
Delete all messages archived in the memory of the telephone
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 49
OK
52
You can choose from the following modes:
Sound Normal ring tone (increasing volume).
Vibrator No sound is emitted (ring tone, message or
appointment alert, low battery beep), but the vibrating system is activated. The icon is displayed on the main screen.
Vibr.+sound Simultaneous activation of the vibrator and normal
ring tone (increasing volume).
Vibr., sound Activation of the vibrator followed by the normal
ring tone.
Vibra...sound Vibrator is activated followed by several beeps,
then by a normal ring tone.
Silent No sound is emitted and the vibrator is
deactivated.The icon is displayed.
Mode
From the “Compose” option, you can create your own tunes.
Compose my melody
(1) Depending on your phone model. Check the
availability of this service with your operator.
!
51
Mode
Volume
Ring tones
Compose
Select the mode (see below)
Compose a melody
Select a ring tone for an incoming call with
Adjust the volume with
Msg. sound
Key beeps
Choose a sound to announce an incoming message
Activate/deactivate the beep played with each short or long keypress
ON sound
Choose the sound which will be played when the phone is switched on
OFF sound
Choose the sound which will be played when the phone is switched off
Downloaded
(1)
Access a WAP site to download new melodies
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 51
OK
OK
OK
To r eturn to the main screen, press the key (long keypress).
!
54
While you are composing your tune, use the key to access the following options:
OK
Available options
53
To compose your melody, use the keypad as shown below:
ok
Change duration
Primary notes of an octave (C, D, E, F, G,A, B)
Change octave
Add a pause
Add a sharp
OK
OK
OK
My setup
Sounds Pictures Negat.Screen
Save Save&Quit Last 5 notes
Sounds
ON sound OFF sound Compose
Save
Last 5 notes
Instrument
Save your tune
Save&Quit
Save your tune and return to the previous screen
Play all Listen to the entire melody
Choose an instrument: piano, xylophone, guitar, bass, strings
Listen to the last five notes
Tempo
Modify title
Choose the tempo: allegro, andante, lento
Change the title of the melody
Delete
Delete the selected melody
Back
Return to the previous screen
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 53
OK
9.4
Downloaded data (1) (Downloaded)
9.3 Black/White background (Negat.Screen)
(1) Check the availability of this service with your
operator.
(2) If your mobile has no available memory, this means that
too many icons, sounds, etc. are stored, you should delete some.
!
56
The saved data will then appear in the appropriate lists (sounds, main screen icons, icons, mood icons,on/off screens, canned messages) (2).
Choose your display mode: black text on a white background or white text on black background.
OKOKOK
OK
New icon!
Icon 04/07
My setup
Sounds Pictures Negat.Screen
My setup
Sounds Pictures Negat.Screen
See
Save
Delete
Save Delete
9.2 Pictures
(1) Depending on your phone model. Check the
availability of this service with your operator.
!
55
Downloading may be performed from your mobile (WAP), the Internet or from a voice server. Once you are connected to WAP or a website offering this service on the Internet (1), select the object you wish to download and perform the downloading. When it is completed, you will receive an SMS containing the object you selected.
Main screen: is displayed when your telephone is switched on and/or when no feature is in use (call, sending short messages, etc.). You can personalise your screen by changing the icon and display format for the date.
On/Off scr.: allows you to customise the On/Off screens of your mobile phone with a welcome message, an animation, or an icon.
Downloaded: access a WAP (1) site to download images.
OK
My setup
Sounds Pictures Negat.Screen
Pictures
Main screen On/Off scr. Downloaded
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 55
9.6 Numbers
(1) Depending on your phone model.
!
58
Activate/cancel the prefix which will be added automatically before the phone number when making the call (enter the prefix, confirm by pressing ).
Direct dial numbers: once entered these numbers can be directly accessed from the main screen with a long keypress on the following keys , , , , , , . (1).
Create or modify direct dial numbers
OK
OK
OKOKOK
Keypad
Prefix
Modify
Key number:
4
Modify
Tel. number:
0123...
Create
Enter the key name:
RAY
Keypad
4 RAY
6 DIANA
7 FRANK
Modify Delete Back
Confirm Directory Back
Keypad
4 RAY
6 DIANA
7 FRANK
9.5
Zoom (1)
(1) Depending on your phone model and the language.
!
57
Save your telephone number,if it is not already recorded on your SIM card). Enter the number - confirm by pressing .
OK
Change your voice mail number (enter the number, confirm by pressing ).
OK
Voicemail
My Number
Your telephone can display two different sized characters (small or large). If you want to display more information (Wap, Directory, Messages, MENU), select the “Zoom” function.
OK
My setup
Downloaded Zoom Numbers
My setup
Pictures Negat.Screen Downloaded Zoom Numbers
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 57
OK
60
1
59
GAMES (1)
Yo u can access the games from the MENU by pressing the key.
OK
Games Calc/Conv Setup Events
You have the option of setting the parameters for the Games in the “Config.” option (keypad, sounds, difficulty...).
Starshot, a hero from deep space, travels throughout the galaxy to discover new entertainment. Help him with his faithful companion Willfly (the little rocket) to foil the traps set by the terrible Wolfgang.
The game software programs built into your telephone have been designed and developed by INFOGRAMES.They are protected by copyright laws. Any non-authorized reproduction of this software as well as any alterations to the copyright notices or other rights appearing on the software are strictly prohibited.
© 2002 Infogrames
(1) The games in your One Touch 331 telephone are suitable for all.
!
Killer Expo
While at the commands of the Willfly rocket, you must avoid obstacles encountered on Killer Expo planet and at the same time eliminate the enemies you come across throughout the 4 levels in order to save Starshot.
To steer, use the , , , keys.
To fire, use the key.
During the game, you can display:
• Your position ,
• Your result,
• Your shield points ,
• Your life points .
Willfly’s mission will be made easier if the numerous bonuses are collected: Weapon , Shield , Invulnerability , Star . Warning: some bonuses have been hidden by the scary Wolfgang!
If you think you are the best, send your high scores to your friends. Your name will certainly be shown in their “High scores” tables (1).
(1) Requires the sending of an SMS.
!
10
10
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 59
6261
Eyes & Stars
For this strategy game, you must align 4 pawns (horizontally, vertically or diagonally). Your opponent, over several rounds, is the terrible Wolfgang. You have the option of choosing your pawns to face the enemy.
To align the pawns, use the , , , , keys.
To confirm the placement of a pawn, use the key.
Run run run
Saved by Willfly, Starshot must pass the platforms to get out of the labyrinth. Starshoot can run on these platforms, climb up and down the ladders, hang and move along the cables, jump from one platform to the other and finally control the stars that he collected on the way in order to dig a hole to trap his opponents.
Note: you must absolutely find the key to to move through the 7 stages of each of the 4 levels.
(1) Requires the sending of an SMS.
!
To move from one platform to the next, climb up and down the ladders, hang and move along the cables, use the , ,
,,keys.
To throw a star, jump from one platform to the other, use the key.
During the game, you can display:
• Your result,
• Your star points ,
• Your life points .
• Key (once it has been found)
If you think you are the best, send your high scores to your friends (1). Your name will perhaps be displayed in their “High scores” tables.
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 61
11.3
11.2
Appointments
Birthdays
11.1 Wake up
1
Options11.4
64
You can schedule your appointments (enter the date and time – confirm by pressing – enter the purpose of the appointment – confirm by pressing ) and program how often they occur (once, daily, weekly).
Once an appointment is scheduled, the icon appears. You can schedule up to five appointments.The alarm will sound whether the phone is switched on or off, but pressing any key will shut it off.
You can also change or cancel an appointment. In addition, you can program a short message to be sent (with icons, and/or a melody) at the appointment time.
OK
You schedule birthdays in the same way as appointments but on an annual basis.You can schedule up to five birthday dates.
The "snooze" function can be activated when you program any alarm.The alarm will be repeated at regular ten minute intervals after the first sounding.
63
Access the alarms features from the MENU (see page 26) by pressing the key.
OK
Set the alarm time and confirm by pressing .
Once this feature is activated, the icon appears on the main screen. Under “Options”,you can choose to program the alarm clock with a melody. The alarm will sound whether the phone is switched on or off, but pressing any key will shut it off.
OK
ALARMS
05:13
18-04-2002
Network
Messages My setup Games Alarms
Alarms
Wake up Appointment Birthdays
11
11
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 63
OK
OK
(1) The currency converter uses the final conversion rates
for the EURO () set on 31/12/1998, which are used in accordance with the official conversion rules.
(2) Depending on your phone model.
!
To enter decimals ("."), use the key (long keypress).
To r eturn to the main screen, press the key (long keypress).
!
12.1 Calculator
66
12.2 Convert
65
12
12
You can access the calculator and the currency converter from the main screen in two different ways:
Enter a figure directly on the keypad, then press the key and
select the “Calculator” or “Convert” option.
Press the in the Menu and select the “Calc/Conv” option.
OK
OK
CALCULATOR/ CONVERTER
The currency converter allows you to:
OK
OK
Rapidly convert into Euros (for the Euro zone only) from
the main screen (1) :
Convert
15.24
100.00
05:13
18-04-2002
Network
Convert Save Number Calculator
FF
Calculator
10
+
-
*
/
Calculator
10 + 3
+
-
*
/
Calculator
10
+
-
*
/
Calculator
13
+
-
*
/
Convert a sum of money
In the menu “Convert”, select the type of conversion (“Euro” (2) or “Curren/Curren”), enter the sum to be converted then press
to display the result.
OK
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 65
OK
OK
OK
13.1 Services
When you have selected or created the first currency, repeat the same operation for the second currency, then enter the exchange rate for these 2 currencies.
To r eturn to the main screen, press the key (long keypress).
!
(1) Contact your operator if necessary.
!
13
13
68
SETUP
Access the “Setup” option from the MENU (see page 26) by pressing the key.
OK
PIN Code (1) SIM card protection code requested each time the
phone is switched on if the code is activated.
Activate/ Activate (or cancel) this code. Deactivate
Change Update the code (4 to 8 digits).
PIN2 Code (1) Protection code for certain functions on the SIM
card (Billing / Cost / FDN, etc.) requested when these functions are used if this code is activated.
Change Update the code (4 to 8 digits).
OK
Security
Alarms Calc/Conv Setup Events
Setup
Services Clock Languages
67
From “Convert”, select the option “Currency” to display the list of currencies.
To choose the currencies to be converted from this table access the following options with :
OK
Modify the currencies to be converted
Confirm
Add
Back
Select the currency
Return to the previous screen
Add a new currency (which can subsequently be changed)
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 67
OK
(1) Check the availability of this service with your
operator.
!
70
Cumul. dur. Total duration of calls made.
InclusiveTime Duration subscribed (enter the time - confirm by
).
Reset Reset (immediately or periodically) the total
duration of calls made.
Beep durat. Activate/cancel the beep which sounds during a call
at an interval set by the user (enter the interval ­confirm by ).
Expense (1) Management of call charges.
Last call Cost of last charged call.
Credit Remaining credit in relation to “Set Credit”.
Cumul. cost Total cost of charged calls.
Set Credit Maximum credit beyond which all charged calls are
barred (enter credit - confirm by ).
Reset Reset the total cost of charged calls.
Unit value Cost of one telecom unit in the chosen currency
(select the “Others?” option for another currency and press the key to enter a decimal point).
OK
OK
OK
(1) Check the availability of this service with your
operator.
!
69
Netwrk Change the code requested to access the “Call Code (1) Barring” options associated with network. (See
page 73)
MENU code Protection code for certain MENU functions
(Services/Setup/Language), requested when these functions are used if this code is activated.
Activate/ Activate (or cancel) this code. Deactivate
Change Update the code (4 to 8 digits).
Prod.Code Protection code for your telephone, requested
each time it is switched on if this code is activated.
Activate/ Activate (or cancel) this code. Deactivate
Change Update the code (4 to 8 digits).
Change SIM Define the SIM card as the main card (see page 36).
Duration Call time management.
Last call Duration of the last call.
Avail.Duration Remaining time available in relation to time
indicated under the “InclusiveTime” (for user's information only).
Billing
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 69
Calls
(1) Check the availability of this service with your
operator.
(2) Depending on your phone model.
!
72
Call wait (1) Activate/cancel signalling of a second incoming call
by a beep while you are in communication.
Conceal ID Activate/cancel the option which makes your (CLIR) (1) calls anonymous (your number will not be
transmitted by the network to the parties you call).
Caller ID Activate/cancel display of the caller's number (or (CLIP) (1) name if it is stored in the directory) with every call.
Auto Redial (2)
Activate/ Activate/cancel automatic call back if the first call Deactivate was unsuccessful.
Forbidden No List of numbers for which automatic call back failed
(10 unsuccessful attempts).
Reset Reset the blacklist.
Ntwk. (Completion of Calls to Busy Subscribers) Redial (1) Automatic call back of the last dialled busy number.
(1) Check the availability of this service with your
operator.
!
71
All All your calls are forwarded. The icon is
displayed.
Conditional Calls are forwarded if the line is busy, the call is not
answered or the phone is outside the network range.
If busy Only if your line is busy.
No reply Only if you do not answer.
Unreach. Only if the phone is out of the network range.
Data Data calls are forwarded to the specified number.
Fax Fax calls are forwarded to the specified number.
Status List of call forwarding operations activated from
this phone.
Cancel All Cancel all activated call forwarding.
Forward (1)
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 71
(1) Check the availability of this service with your
operator.
!
74
Exc. All calls other than those to numbers included in
“Prof.” the “Profession.” family are barred.
Exc. All calls other than those to numbers included in
“Other” the “Other” family are barred.
Incoming Activate/cancel incoming call barring.This option is
applicable in the following cases:
Except All calls from a number not stored in your
Dir. directories are barred.
All (1) All incoming calls are barred.
If abroad (1) Incoming calls are barred if you are abroad.
Exc. All calls other than those from numbers included in
“Private” the “Private” family are barred.
Exc. All calls other than those from numbers included in
“Prof.” the “Profession.” family are barred.
Exc. All calls other than those from numbers included in
“Other” the “Other” family are barred.
Status List of call barring operations activated.
(1) Check the availability of this service with your
operator.
!
73
Outgoing Activate/cancel the call barring. This option is
applicable in the following cases:
Except Calls to numbers not stored in your phone
Dir. directories are barred.
All (1) All outgoing calls are barred.
International(1)Outgoing international calls are barred.
Exc.-
>
Outgoing calls except those to the subscription
Home (1) country are barred.
ExceptFDN (1)Calls to numbers other than the specific FDN
directory (contained in the SIM card) are barred.
Activate/ All calls which do not begin with one of the Deactivate numbers stored in the "FDN" directory are barred.
Change If the “ExceptFDN” option is activated, you can
update the "FDN" directory after entering PIN2 code (update "FDN" directory by pressing ).
View View the list of FDN numbers.
Exc. All calls other than those to numbers included in
“Private” the “Private” family are barred.
OK
Call Barring
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 73
13.4
13.2
13.3
Clock
Languages (1)
Dictionary (2)
(1) Depending on your phone model.
(2) Depending on your phone model and language.
!
Time/Date Setting your telephone's date and time.
Format Date and time display format.
Message display languages (select by pressing ). The “Automatic” option chooses the language of your SIM card (if it is available in the phone).
OK
76
Direct access Profile access (See page 84)
WAP
Preferred List of networks for priority connection (update
this list with ).
Forbidden List of forbidden networks (update the list with
).
OK
OK
There is a dictionary to which you can add your own words to those already contained in the assisted data entry system.
(1) Check the availability of this service with your
operator.
!
75
SMS CB (1) Messages broadcast over the network (weather
forecast, traffic, etc.) are automatically displayed on the main screen. You can find the last SMS CB message in “Menu/Messages/Last CB”.
CB list List of the message codes to be displayed.
Reception Depending on the selected option, the phone
displays messages broadcast by the network.
Full The phone permanently scans the network and
displays broadcast messages according to your "CB list" option.
Limited The phone intermittently scans the network and
displays broadcast messages according to your "CB list" option.
None The phone does not receive any broadcast
messages.
Searching Search for a home network.
Available List of available networks in your radio
environment.
Mode Depending on the option, the search mode is:
Automatic First network searched for is the last one used.
Manual User chooses the network from a list.
Networks
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 75
13.9
13.8
13.10 Keypad lock
Double line
Automatic power off
13.5
13.7
13.6 Display
Pick up
Input mode
(1) Check the availability of this service with your
operator.
!
78
Power off When this option is activated, the phone is
automatically switched off if it is not used (i.e. no keypresses, no calls, no incoming messages) after an amount of time chosen by the user (enter the duration, confirm by ).
OK
Keypad lock When this option is activated, the keypad will be
automatically locked if you have not used your phone for a certain length of time.
This function allows you to move from line 1 to line 2 (1). (See page 24)
Key
=
After pressing the key.
Any key After pressing any key on the keypad (1 to #).
(1) Depending on the language.
!
77
Pick up Allows you to choose the way a call will be
answered.
Automatic Automatically (without pressing a key) after
approximately 2 rings (this option is only available if your phone is connected to an audio accessory).
Backlight Backlighting intensity (press to adjust); we
recommend using the minimum necessary intensity to save battery power. However, you can use the
key (long keypress) to activate the
backlighting.
Contrast Display contrast (press to adjust).
OK
OK
Access to different entry modes (1).
When you consult your dictionary, you can add, modify or delete words using the options available by pressing the key.
OK
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 77
14.1
Accessing WAP Services (2)
14.2
Available options (1)
(1) Depending on your phone model.
When browsing, you can exit the WAP mode anytime by pressing the key.
!
80
While viewing a WAP page, you can access a number of options by pressing either:
• the key (long keypress)
• the key (short keypress)
OK
Access the WAP site directly by entering the address
Set up the connection parameters for your WAP service access providers. In most cases, your browser connection is already set up
Profiles
Go to URL
Launch
Bookmarks
Launch the WAP browser to the default profile, if it has already been configured
Access your favourite sites
(1) Check the availability of this service with your
operator.
(2) Depending on your phone model and the language.
(3) Depending on the operator, this screen may not be
displayed (to switch between modes, see page 83-84).
!
79
WAP (1)
14
14
WAP (Wireless Application Protocol) is a service that allows you to obtain information such as weather conditions, stock market averages, traffic conditions, etc.
You can access mobile Internet services from the main screen by pressing:
• the key (long keypress) (2)
• or key and then selecting “Services”
OK
OK
OK
(3)
Wap
Homepage Bookmarks Profiles
Services
WAP Entertainment Taxi
Services
Menu
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 79
OK
14.3
Setting up your access (1)
(1) Enter the information provided by your operator.
(2) Depending on the profile type.
(3) Depending on your phone model.
!
82
Select a profile from the list of profiles and access the following options by pressing the key.
OK
(1) Depending on your phone model.
(2) Check the availability of this service with your
operator.
(3) Depending on the language.
81
!
Connect.
Status
Alert List
Zoom Change the character size (3)
Display the list of your alerts (2)
Display the information bar for your Internet session (1)
Exit WAP
Back
Return to the previous screen
Finish consulting Internet services and return to the main screen
Show URL
Display the address of the site you are currently visiting (1)
Add a favourite site to your bookmarks
Access your favourite sites (bookmarks)
Access a site directly by entering its address
Enter address
Add
bookmark
Bookmarks
...
HomePage
Specific options on the current page
Return directly to the home page
Launch
Create
Modify
Delete
Launch WAP even if no profile is pre­selected
Activate
Select a preset profile and go back to the profile list (2)
Delete a profile that you created (2)
Return to the previous screen
Modify the profile parameters (2)
Create a new profile (3)
Back
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 81
OK
OK
14.4
Launching WAP (1)
(1) Enter the information supplied by your operator.
!
84
By selecting Setup/Services/WAP,you can access a menu that allows you to modify the parameters to launch your browser:
“Direct” access: when you select Services/WAP from the main screen, your WAP homepage is automatically accessed.
“Profile” access: when you select Services/WAP from the main screen, the following screen is displayed:
Wap
Homepage Bookmarks Profiles
83
To create a new profile, you must enter the following parameters (1):
•Profile name
• Homepage
• IP address
• Security : Normal (port 9201) / Secure (port 9203)
• GSM user name (Login)
• Password
• Access number
• Access Type (Digital/Analogue)
•Then select the option “Validate”
(1) Depending on the profile type.
!
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 83
15
86
and of the overall electric installation,
4) accidents or the consequences of theft, (of the vehicle), acts of vandalism, lightning, fire, humidity, infiltration of liquids, atmospheric influences,
5) combination or integration of the equipment in hardware not supplied or not recommended by Alcatel, without express written consent for such,
6) modifications, alterations, or repairs carried out by parties not authorised by Alcatel, the dealer or the approved maintenance centre,
7) use of the equipment for a purpose other than that for which it was designed,
8) normal wear,
9) deterioration caused by external causes (RF interference produced by other equipment, fluctuations in mains voltage and/or voltages on telephone lines, etc),
10) modifications made to the equipment even if they are unavoidable due to changes in regulations and/or modification of network parameters,
11) connection faults resulting from unsatisfactory radio transmission or caused by the absence of radio relay coverage.
Equipment on which markings or serial numbers have been removed or altered, and handsets on which labels have been removed or deteriorated shall be excluded from the warranty. The above provisions constitute the only claims which can be made against the manufacturer and dealer on the grounds of equipment defects, this warranty excludes any other explicit or implied warranty except the statutory warranty in force in the user’s country.
85
Congratulations on choosing this mobile phone - we hope that you will be totally satisfied with it.
Notwithstanding any other applicable statutory warranties, this mobile phone is guaranteed against any manufacturing defect for a period of ONE (1) year from the date of purchase shown on your invoice. Nevertheless if the statutory warranty in force in your country exceeds one (1) year, the statutory warranty is not affected by the manufacturer’s warranty.
The present warranty terms also apply to the battery and accessories but for a period of SIX (6) months from the date of purchase shown on your invoice. Under the terms of this warranty, you must inform your dealer or any maintenance centre (see list of maintenance centres at our website - www.alcatel.com) without delay, of any defect and present the invoice given to you at the time of purchase.
The dealer will decide whether to replace or repair, as appropriate, all or any part of the equipment (telephone or accessory) found to be defective. This warranty covers the cost of parts and labour but excludes any other costs. Repair or replacement may be carried out using reconditioned components offering equivalent functionality.
Servicing under the terms of this warranty, especially repair, modification or replacement of parts shall entitle to a three month warranty unless there are statutory provisions to the contrary.
This warranty shall not apply to damage or defects (to your telephone and/or accessory) caused by:
1) use not conforming with the instructions for use or installation,
2) non observation of the technical and safety standards applicable in the country where the equipment is used,
3) improper maintenance of batteries and other sources of energy,
WARRANTY
15
15
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 85
88
To enter a word, press the key which corresponds to the desired letter several times until the wanted letter appears.
: space.
CHARACTER SET
A short keypress on the key will display the symbol bar with the cursor automatically placed on the “•”.The key allows you to move from left to right.
Up
Down
87
16
16
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:54 Page 87
OK
Only use your mobile phone with Alcatel batteries, battery chargers, and accessories that are compatible with your phone model.
!
90
Transparent case
HC 30
Input keyboard
KB 1
Basic car kit
MP 79
Basic car cradle
MP 85
Easy-to-install hands-
free car kit
MP 86
(1) Depending on your phone model and availability.
The chargers designed for your mobile phone meet with the standard for safety of information technology equipment and office equipment use. They should be used for this purpose only.
!
89
17
17
The latest generation of Alcatel mobile telephones offers a large range of accessories:
Battery
B 58
Headset
M 13
Single range charger
????
Cigar lighter charger
C 56
ACCESSORIES (1)
Changeable front panels
FPxx
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:55 Page 89
92
Outcoming calls cannot be made or no incoming calls are received
I cannot create a file in my directory
I cannot access my voice mail
I cannot send messages
The main screen displays a black envelope icon
I have already entered 3 incorrect PIN codes
- Make sure your mobile phone is connected to the network
- Check your subscription with your operator (credit, SIM card validity)
- Check that the directory is not full, delete some files
- Make sure that your voicemail number is stored in the “Numbers” option
- Check the service centre number with your operator
- Your correspondent’s phone could be incompatible with the transmission mode you are using (EMS standard for any transmission of icons, sounds,...)
- Check that your short message memory is not full
- Too many short messages are stored in your SIM memory, delete some!
- Contact your operator to get your PUK code to unblock your mobile
91
We recommend that you carry out the following checks before contacting the Customer Care Service:
My mobile phone will not switch on
The <<< >>>> symbol is displayed: my mobile phone is not connected to a network:
SIM card error
- Press the key for at least two seconds
- Check your battery charge level
- Try to reach the network by moving to a different location (if you are inside a building, stay near a window)
- Check your mobile coverage with your operator
- Make sure your SIM card is valid by checking with your operator
- Make sure the SIM card is correctly inserted
- Check with your operator that your SIM card is 3V compatible, former 5V SIM cards can no longer be used
TROUBLESHOOTING
18
18
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:55 Page 91
9493
The icon is still showing
I cannot save my new downloaded items
I have plugged in the charger, but:
-the charging indicator is not displayed
- the charge icon is displayed, but the animation does not start
- Go to “Menu/Events” and check all events
- Delete old downloaded items by going to“Menu/My setup/Downloaded”
-The charging indicator may take several minutes to start to flash if the battery is very low. Please wait a few minutes and the telephone will start charging again normally
- Remove your telephone battery then reinsert it and the telephone will start charging again normally
Notes...
BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:55 Page 93
Loading...
