TCL Communication B104 Users Manual
Quick Start Guide
For more information about how to use your phone, please visit
www.alcatel-mobile.com to download the complete user manual.
Moreover, from the website you can also consult FAQ.
This product meets applicable national
SAR limits of 1.6 W/kg. The specific
maximum SAR values can be found on
Radio waves section.
When carrying the product or using it
www.sar-tick.com
while worn on your body, either use an
approved accessory such as a holster or
otherwise maintain a distance of 10 mm
from the body to ensure compliance with
RF exposure requirements. Note that the
product may be transmitting even if you
are not making a phone call.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at
high volume levels for long periods. Exercise caution
when holding your device near your ear while the
loudspeaker is in use.
English - CJB1MM0ALAAA
Your phone �������������������
1
2
3
4
5
6
7
8
9
10
1
1
2
3
4
Left soft key
Call logs (idle screen)
Send call
Voice mail (long press)
Star Key (long press
key +/P/W)
Right soft key
Power on/off
End call
Vibrate alert (Vibrate
mode activated)
1
5
8
6
9
10
7
Menu key:
Confirm an option
Profile (when no widgets)
(No side key default Volume +)
Calendar (when no widgets)
(No side key default Volume -)
Write message(when no
widgets)
Alarm (when no widgets)
Torch key(Long press: switch
on/off the torch )
“0“ key Short press: Dial ‘0’
Short press: Add space
1�1 Keys and connectors
Menu key
Confirm an option (press the center of the key)
Left soft key
•Unlock keypad
•Access to main menu
Send call
Access to call log ( on Home screen)
Right soft key
Access contacts
Power key
•Power on/off the phone (long press)
•End call
•Return to the Home screen
On the Home screen
•Input "1"
•Dial voice mail number (long press)
In edit mode
•Input most frequently used symbols
•Input "1" (long press)
On the Home screen
•Enter "0"
•“0“ key Idle screen:Short key press: Dial ‘0’ Edit
mode:Short press: Add space
In edit mode:
•Input "0" (long press)
2
From Idle screen
Short press Input "*"
Long key press : Switch between ‘+/P/W’
In Edit mode
Shortpress:inputmethod≠number:
Access to symbol table
Hash key #Idle screen
Short key press: Input "#"
Longkeypress:Vibraonon/o
In edit mode
Short press: Change the input method
Long press: Access to the language list
3
1�2 Status bar icons
(1)
In 2053X
Battery charge level
Level of network reception
Meeting mode: your phone vibrates, but neither rings
nor beeps
Silent mode: your phone neither rings, beeps nor
vibrates
Bluetooth status (Activated)
Airplane mode
Headset connected
Alarm clock programd
Missed calls
Roaming
Unread SMS
Message full
Call divert
Music activated
(1)
The icons and illustrations in this guide are provided for
information purposes only.
4
In 2053D
GRPS connection status.
Call divert
Roaming
Getting started �������������
2
2�1 Set up
Removing and installing the back cover
Removing and installing the battery
Inserting and removing microSD card
5
Inserting and removing the SIM card
1
Place the SIM card with the chip facing downwards and slide it
into its housing. Make sure that it is correctly inserted. To remove
the card, press it and slide it out.
1
For dual SIM model
support micro SIM card. Do not attempt to insert
other SIM types like mini and nano cards, otherwise
this may cause damage to your phone.
1
(1)
and single model
1
(2)
which only
Charging the battery
•Connect battery charger to your phone and plug into the
socket.
•Charging may take about 20 minutes to start if the battery is
out of power.
•Be careful not to force the plug into the socket.
•Make sure the battery is correctly inserted before connecting
the charger.
•The mains socket must be near to the phone and easily
accessible (avoid electric extension cables).
•You are advised to charge the battery to its maximum
when using the phone for the first time (approximately
3 hours) .
(1)
2053D
(2)
2053X
6
•To reduce power consumption and energy waste, when battery
is fully charged, disconnect your charger from the plug; reduce
the backlight time, etc.
The charge is complete when the animation stops.
2�2 Power on your phone
Hold down the key until the phone powers on.
2�3 Power off your phone
Hold down the key from the idle screen.
Calls ��������������������������������
3
3�1 Making a call
Enter the desired number, then press the key to place the
call. If you make a mistake, you can delete the incorrect digits
by pressing the key. To hang up the call, press the key.
Making an emergency call
If your phone is covered by the network, dial the emergency
number and press the key to make an emergency call. This
works even without a SIM card and without typing the PIN code
or unlocking the keypad.
3�2 Calling your Voice mail
To access your voicemail, hold down the key.
(1)
3�3 Answering a call
When you receive an incoming call, press the key to answer
and then hang up using the ke y.
3�4 Available functions during the call
During a call, you can access your Call records, contacts,
messages, etc. without hanging up the phone.
(1)
Contact your network carrier to check service availability.
7
Call logs �������������������
4
You can access your call history by pressing from the idle
screen, or press the key and select the icon from the
Menu.
Camera ���������������������
5
This function enables you to take pictures. Press to take the
picture. You set them as wallpaper or select them as incoming call
image to a contact in your Contacts..
Call filter ������������������
6
You can create Blacklist and Whitelist through this function.
Application ��������������
7
7�1 Sound Recorder
Use this function to record audio files. The phone support WAV
and AMR. The recording file you stopped will be stored in My
music automatically..
7�2 Convert
Convert support weight conversion and length conversion.
7�3 Alarm
Your phone has a built-in alarm clock with snooze feature. You
can set five alarms with wake-up time and other customized
options.
8
