TCL Communication B052 User Manual

CJB1FD0ALAAA
TABLE OF CONTENTS
Support ..................................................................... 1
Service Activation.................................................... 2
Device Overview ..................................................... 3
SIM Card .................................................................. 4
Memory Card ........................................................... 5
Power ........................................................................ 7
Home Screen ........................................................... 7
Tethering & Mobile HotSpot ............................... 11
Accessing Files .....................................................12
Contacts .................................................................12
Gmail ....................................................................... 13
Text Entry................................................................ 13
Text Messaging ..................................................... 16
Web Browsing .......................................................19
Bluetooth® .............................................................. 20
Battery & Memory Management......................... 21
Protecting Your Device ........................................23
Accessories ............................................................ 24
Caring For Your Device .......................................25
Approved Firmware Versions ..............................26
Additional Information ..........................................27
TCL Communications Ltd. Warranty ..................29
Electronic Recycling Program ............................32
Safety Information ................................................. 32
ALCATEL Information ...........................................44
SUPPORT
This guide provides you with the information you need to get started.
For more information and additional support, please visit www.t-mobile.com/support where you can:
n
Register at my.t-mobile.com to check your
minutes, pay your bill, upgrade your device, and change your rate plan.
n
Review your device’s User Manual and
troubleshooting FAQs.
n
View the latest troubleshooting solutions in the
Suppor t Forums or ask a question of your own.
SERVICE ACTIVATION
If you are a new T-Mobile® customer and your service has not yet been activated, simply call Customer Care at 1-800-937-8997 and a T-Mobile Activations representative will assist you.
You will need the following information when activating service:
n
Your Service Agreement and the agent code on
your Agreement
n
Your name, home address, home phone
number, and billing address
Note: For business and government accounts, please provide the organization’s name, address, and tax ID.
n
Your Social Security number, current driver’s
license number, and date of bir th for credit check purposes
n
Your choice of T-Mobile rate plan and ser vices
(see www.t-mobile.com for latest plan information)
n
Your SIM serial number and IMEI number
(located on the box barcode label)
By activating service, you acknowledge that you have read, understand, and agree to be bound by each of T-Mobile’s Terms and Conditions, and by your Service Agreement.
21
DEVICE OVERVIEW
Camera
Back key
Home key
Micro-USB Connector
Headset connector
Front camera
Touch screen
Recent key
Power key
Volume up/down
keys
SIM CARD
The SIM (Subscriber Identity Module) card identifies your device to the wireless network. You cannot browse the Internet using network without properly installing SIM card.
Installing SIM card
1. Detach the SIM card from its packaging.
43
2. Insert SIM card into SIM slot located on left side of device. Follow the steps below and the icons on your device to insert SIM card accurately.
MEMORY CARD
Memory cards add extra storage space for your music, pictures, videos, and more. This device uses a microSD memory card size. Memory card sold separately.
Installing memory card
1. Insert the microSD card into the microSD slot. Follow the steps below and the icons on your device to insert microSD card accurately.
65
Charging your device
1. Insert the small end of the charging cable into the device micro-USB connector located on top of device, as shown.
2. Plug the other end of the charging cable into provided charger, connect charger to power outlet.
POWER
To turn the power on or off, press and hold the power key located on right side of device.
HOME SCREEN
You can bring all the items (applications, shortcuts, folders and widgets) you love or use most frequently to your Home screen for quick access. Touch the
Home key to get instant access to the Home screen.
Status bar
Touch and drag d own to open
Back
Touch to go back to last sc reen.
the notifications panel.
Search bar
Touch to enter tex t
search screen.
Touch to enter vo ice
search screen.
Swipe main home screen left and right to view additional home screens.
Favorite applications tray
Touch to enter the applications.
Touch and hold to move or change applications.
Recent apps
Touch to view recent apps.
Applications icon
Touch to open applications menu.
Home screen is provided in an extended format to allow more space for adding applications, shortcuts etc. Slide all Home screens horizontally left and right to get a complete view of the Home screens. The white circles at the lower part of the screen indicate which screen you are viewing.
Status bar
The Status bar appears at the top of your Home screen. Icons indicating your tablet’s status and new notification alerts appear in the Status bar.
87
Notifications panel
Touch and drag down the Status bar to open the Notifications panel. Touch the notifications to view details or touch on the bottom of Notifications panel to clear all notifications (ongoing notifications will remain). In the Notifications panel, touch or swipe down the top gray bar to access the Settings shortcut panel. Touch Settings shortcut options displayed to enable/disable functions or to access full Settings menu touch Settings icon at top of panel.
Touch to access Settings menu with all options
Unlock the screen
Press the Power key once to light up the screen, slide the screen up, draw the unlock pattern you have created or enter PIN or password to unlock the screen.
Add items to the Home screen
1. Tap the Applications icon to access the Applications menu.
2. Touch and hold the desired item, and then drag it to a blank area on the preferred Home screen.
Move and delete items
Touch and hold the item you want to move or delete and then drag it to another location or to the X Remove icon at the top of the screen.
Touch to clear all notifications (ongoing notifications will remain).
Applications menu
To access all Applications from the Home screen, tap the Applications icon . Swipe up or down through the menu screens to view all applications. As you download new applications, they will appear in the
Applications menu in alphabetical order.
Change Home screen wallpaper
You can change your wallpaper two different ways:
1. Touch and hold an empty area on the Home screen and then select WALLPAPERS from bottom options. Slide left and right to view Wallpaper image options, touch Set Wallpaper on top bar to set image.
2. Change your wallpaper by going to Settings >
Display > Wallpaper.
109
TETHERING & MOBILE HOTSPOT
Tether your device
1. Use provided USB Cable to connect your device to your computer. You will see in Status bar when USB tethering is active.
2. Tap the Applications icon
3. Tap Settings
4. Tap More.
5. Tap Tethering & Mobile HotSpot.
6. Tap the switch icon next to USB tethering to turn on tethering (Wi-Fi must be off to activate this option).
Tethering works with Windows® XP, Windows® 7, Windows 10, Windows Vista®, Mac OS X and Linux.
When you connect your device to a computer with a USB cable, you can either share your mobile data connection by tethering or you can share files—you cannot do both. Do not turn on tethering if you want to use your computer to access your device’s memory card.
.
Activating Mobile HotSpot
1. From Home screen or Applications menu touch
Mobile HotSpot icon.
.
2. Toggle Mobile HotSpot button to right On position, bar will display in blue. If first time activating Mobile HotSpot, you will be prompted to create password.
3. Use computer to search for Mobile HotSpot wireless name ALCATEL ONETOUCH POP7 LTE
XXXX ( the last four digits of your device’s
IMEI), select to connect.
4. Enter password to complete connection.
ACCESSING FILES
To access media files and photos saved on your device or to transfer files from your SD card to your computer, connect your device to a computer using supplied USB Cable.
Once connected to computer, swipe down your device’s Status to see USB for file transfer option, select this option. Then select the file type you would like to access:
Transfer files (MTP) to access media files.
Transfer photos (PTP) to access camera photos.
Please note, you can only access one file type option at a time. Once file type is selected use your computer to access your device files.
1211
CONTACTS
Adding a new contact
1. From the Home screen, touch .
2. Touch
3. Enter contact’s name and other contact
4. When finished, touch
to create a new contact.
information.
to save.
GMAIL
Setting up Gmail™
1. From the Home screen, tap the Applications icon .
2. Tap
3. Follow the on-screen instructions.
.
TEXT ENTRY
Onscreen Keyboard settings
Touch from the Home screen, touch Settings and select Language & input. Scroll to KEYBOARD & INPUT METHODS, locate keyboard of choice: Android keyboard, Google Keyboard, or Google voice
typing and touch it to view available settings for each input option.
Adjust the Onscreen Keyboard orientation
Turn the device sideways or upright to adjust the Onscreen Keyboard orientation. You can also adjust Onscreen Keyboard orientation by changing the settings. Select Settings , select Display, then select Rotate the contents of the screen or Stay in
current orientation after touching the When device is rotated.
1413
Android keyboard
Touch to switch
between << abc/
Abc /ABC >> mode.
Touch to
Press and hold
to open se ttings.
Touch to switch b etween symb ol and numeric keyboard.
enter text.
Touch to input space.
Text editing
You can edit the text you have entered.
Touch and hold or double-tap within the text you
would like to edit.
Drag the tabs to change the highlighted selection.
The following options will be available: CUT,
COPY, SHARE, SELECT ALL, REPLACE... and PASTE.
TEXT MESSAGING
Use the messaging feature to send and receive text (SMS) and multimedia (MMS) messages.
Writing a message
In message screen, touch the new message icon to write text/multimedia messages.
Touch to create a ne w message.
Touch to search in a ll messages .
Touch to view the whole message thread.
To communicate with a saved contact, touch contact photo in Message history to open Quick Contact panel. For unsaved contacts, touch default photo in Message history to add the number to your Contacts.
1615
Sending a text message
Enter the mobile phone number of the recipient in the To bar or touch to add recipients, touch Type message bar to enter text message. When finished, touch to send the text message.
An SMS message of more than 160 characters will be charged as several SMS. When the total number of characters you have entered is approaching the 160-character limit, a counter will appear on the lower right corner above Send option of the text box to remind you how many characters are allowed to be entered in one message.
Specific letters (accent) will increase the size of the SMS, which may cause multiple SMS
to be sent to your recipient.
Deleting message threads
Touch to delete selected message.
To delete an entire message thread, touch and hold message from Messaging screen until highlighted, then touc h trash bin to dele te.
Deleting individual message threads
To delete individual messages in a message thread, open message thread, touch & hold message to access Message
Options and select
DELETE.
1817
WEB BROWSING
Using Google Chrome
1. From the Favorite applications tray or Applications menu, touch Google Chrome icon
.
2. Touch the URL bar at the top, enter the address of the web page.
3. Touch
.
BLUETOOTH®
Your device comes with Bluetooth connectivity, a wireless technology that enables a data connection between your device and a Bluetooth headset or other Bluetooth device (sold separately).
Turn on Bluetooth and pair with a headset
1. From the Home screen, touch Application icon , then select Settings .
2. Scroll to Bluetooth and move switch beside Bluetooth to right position to activate
3. Device will search for available Bluetooth devices automatically when Bluetooth is turned on.
4. Scroll to the desired Bluetooth device.
5. Touch the Bluetooth device to pair with your device.
.
2019
BATTERY & MEMORY MANAGEMENT
Optimizing battery life
To optimize battery life you can adjust your screen brightness and display timeout.
1. From the Home screen, tap the Applications icon
.
2. Tap Settings
3. Tap Display.
4. Tap Brightness level.
5. Position the slider on the left of the bar to maximize battery life.
6. Tap Sleep, set to 15 seconds to maximize batter y life.
Optimizing memory
Using Task Manager to free up memory space:
1. From the Home screen, tap the Applications icon
2. Select Settings
3. Tap the application you want to stop or uninstall.
4. Tap FORCE STOP, UNINSTALL or DISABLE options vary based on application.
.
and select Apps.
Clearing the Browser cache:
Increase available storage space by clearing out browser caches.
1. From the Home screen, tap the Applications icon
2. Tap
3. Tap Menu key
4. Tap Settings.
5. Tap Privacy.
6. Tap CLEAR BROWSING DATA.
7. Mark the checkboxes to clear browser history,
8. Tap CLEAR.
Deleting old messages:
1. From the Home screen, tap Messaging icon
2. Tap Menu key
.
3. Tap Delete all threads.
.
.
cache, cookies, etc.
.
.
.
2221
PROTECTING YOUR DEVICE
Prevent others from using your device without your permission. Device protection is automatically activated when you add a Google Account and set a screen lock. Together with Android Device Manager, you can locate and erase your device, and protect it from reuse if it’s lost or stolen. Even if your device gets wiped, your google Account password will be required before anyone can use your device.
To activate
1. Select Protect this device checkbox when
prompted during device set up.
2. Set Pattern, Password or PIN.
3. Protect your device activation is complete when you setup your password.
ACCESSORIES
Charger, 5.0VDC/2000mA
USB cable, 5pins micro-USB
2423
CARING FOR YOUR DEVICE
Make it last
Your device is a complex electronic device; think of it as a mini-computer. Here are a few tips to help you extend the life of your new device.
Do not get your phone wet. Even a small amount of moisture can damage your device and accessories.
Protect your device’s screen. Your device’s screen is delicate. Guard against scratches by using a screen protector or a protective case.
Do not use damaged accessories. If your charger or any other accessory is damaged, replace it or take it to a qualified service dealer. Do not attempt to charge your device if the charger has been dropped, received a sharp blow, or has been otherwise damaged; doing so may damage your device.
APPROVED FIRMWARE VERSIONS
This device will only operate with firmware versions that have been approved for use by T-Mobile and the device manufacturer. If unauthorized firmware is
placed on the device it will not function.
INFORMATION ABOUT SAFEGUARDING DEVICES
T-Mobile encourages customers to take appropriate measures to secure their devices and invites them to take advantage of the features available on this device to help secure it from theft and/or other unauthorized access and use. This device has a locking function (e.g., user-defined codes or patterns) that can serve as a first line of defense against unauthorized use or access to stored information. Preloaded security applications that allow customers to track or locate misplaced devices can be found on several T-Mobile devices. Lost or stolen devices should be immediately reported to T-Mobile so that proper measures can be taken to protect accounts. For additional information, visit: www.tmobile. com/devicesecurity and www.tmobile.
com/Company/PrivacyResources.aspx
2625
ADDITIONAL INFORMATION
Use of some content or features may incur separate, additional charges, and/or require qualifying service or access to a Wi-Fi connection.
Wi-Fi: Devices using wireless connections may be vulnerable to unauthorized attempts to access data and software stored on the device. Plan data allotment applies to use by connected devices sharing Wi-Fi. Use of connected devices subject to T-Mobile’s Terms and Conditions.
Mobile HotSpot (Tethering): Qualifying service required. Plan data allotment applies. Roaming and on-network data allotments differ; see your selected service for details. Use of connected devices subject to T-Mobile Terms and Conditions.
Messaging/Data: You will be charged for all data and messages sent by or to you through the network, regardless of whether or not data or message is received. Character length/file size of messages/ attachments may be limited. T-Mobile is not liable for content of messages/attachments or for any failures, delays, or errors in any T-Mobile generated alerts or notifications. Your data session, plan, or
service may be slowed, suspended, terminated, or restricted if you use your service in a way that
interferes with or impacts our network or ability to provide quality service to other users, if you roam for a significant portion of your usage, or if you use a disproportionate amount of bandwidth during a billing cycle. You may not use your plan or device for prohibited uses.
Devices, accessories and screen images are simulated. Coverage not available in some areas. See Terms and Conditions (including arbitration provision) at T-Mobile.com, for rate plan information, charges for features and services, coverage details, and restrictions and details. The Bluetooth word mark and logo are owned by Bluetooth SIG, Inc. and are used by T-Mobile under license. Google, Android and Gmail are trademarks of Google, Inc. T-Mobile and the magenta color are registered trademarks of Deutsche Telekom AG. ©2016 T-Mobile USA, Inc.
2827
TCL COMMUNICATIONS LTD. WARRANTY
TCL Communications Ltd. warrants to the original retail purchaser of this wireless device that should this product or part thereof during normal consumer usage and condition be proven to be defective in material or workmanship that results in product failure within the first twelve (12) months from the date of purchase as shown on your original sales receipt from an authorized sales agent. Such defect(s) will be repaired or replaced (with new or rebuilt parts) at the company’s option without charge for parts or labor directly related to the defect(s). Batteries, power adapters, and other accessories sold as in box items are also warranted against defects and workmanship that results in product failure within the first twelve (12) month period from the date of purchase. This warranty extends to products purchased and sold within the United States.
The limited warranty for your wireless device will be voided if any of the following conditions occur:
Non-compliance with the instructions for use or
installation, or with technical and safety standards applicable in the geographical area where your phone is used;
Connection to any equipment not supplied or not
recommended by TCL Communications Ltd.;
Modification or repair performed by individuals
not authorized by TCL Communications Ltd. or its affiliates;
Changes to the device operating system by the user
or third party applications;
Acts of god such as inclement weather, lightning,
power surges, fire, humidity, infiltration of liquids or foods, chemical products, download of files, crash, high voltage, corrosion, oxidation;
Removal or altering of the wireless device’s event
labels or serial numbers (IMEI);
Damage from exposure to water or other liquids,
moisture, humidity, excessive temperatures or extreme environmental conditions, sand, excess dust and any condition outside the operating guidelines;
Rooted devices;
Damage as result of physical abuse regardless of cause.
There are no express warranties, whether written, oral or implied, other than this printed limited warranty or the mandatory warranty provided by your jurisdiction. In no event shall TCL Communications Ltd. or any of its affiliates be liable for incidental or consequential damages of any nature whatsoever, including but not limited to commercial loss, to the full extent those damages can be disclaimed by law. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitation of the duration of implied warranties, so the preceding limitations or exclusions may not apply to you.
3029
How to obtain Support: Contact the customer care center by calling (855-368-0829) or going to (http:// www.alcatelonetouch.us). We have placed many self­help tools that may help you to isolate the problem and eliminate the need to send your wireless device in for service. In the case that your wireless device is no longer covered by this limited warranty due to time or condition, you may utilize our out of warranty repair options.
How to obtain Hardware Service within the terms of this warranty: Create a user profile (alcatel.finetw.com) and then create an RMA for the defective device. Ship the device with a copy of the original proof of purchase (e.g. original copy of the dated bill of sale, invoice) with the owner’s return address (No PO Boxes accepted), wireless carrier’s name, alternate daytime phone number, and email address with a complete problem description. Only ship the device. Do not ship the SIM card, memory cards, or any other accessories such as the power adapter. You must properly package and ship the wireless device to the repair center. TCL Communications Ltd. is not responsible for devices that do not arrive at the service center or are damaged in transit. Insurance is recommended with proof of delivery. Upon receipt, the service center will verify the warranty conditions, repair, and return your device to the address provided in the RMA.
ELECTRONIC RECYCLING PROGRAM
For more information on Electronic Recycling, please:
1) Visit ALCATEL ONETOUCH Electronic Recycling Program website at http://www.alcatelonetouch. us/electronic-recycling-program, or
2) Call ALCATEL ONETOUCH US Customer Support at 1-855-368-0829.
SAFETY INFORMATION
We recommend that you read this chapter carefully before using your device. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein.
TRAFFIC SAFETY
Given that studies show that using a device while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their device when the vehicle is not parked. When driving, do not use your device or headphone to listen to music. Using a headphone can be dangerous and forbidden in some areas. When switched on, your device emits electromagnetic waves that can interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:
- Do not place your device on top of the dashboard or
3231
within an airbag deployment area,
- Check with your car dealer or the car manufacturer to make sure that the dashboard is adequately shielded from device RF energy.
CONDITIONS OF USE
You are advised to switch off the device from time to time to optimize its performance.
Switch the device off before boarding an aircraft.
Switch the device off when you are in healthcare facilities, except in designated areas. As with many other types of equipment now in regular use, these devices can interfere with other electrical or electronic devices, or equipment using radio frequencies.
Switch the device off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, petrol station, or chemical plant, or in any potentially explosive atmosphere.
When the device is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc. In particular when using the device, you should hold it against the ear on the opposite side to the device, if any.
To avoid hearing impairment, move the device away from your ear while using the "hands-free" mode
because the amplified volume might cause hearing damage.
Do not let children use the device and/or play with the device and accessories without supervision.
Please note that your device is a unibody device, the back cover and battery are not removable. Do not attempt to disassemble your device. If you disassemble your device the warranty will not apply. Also, disassembling the device may damage the battery, and may cause leakage of substances that could create an allergic reaction.
Always handle your device with care and keep it in a clean and dust-free place.
Do not allow your device to be exposed to adverse weather or environmental conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The manufacturer's recommended operating temperature range is 14°F to +131°F.
At over 131°F the legibility of the device’s display may be impaired, though this is temporary and not serious.
Do not open, dismantle or attempt to repair your device yourself.
Do not drop, throw or bend your device.
Do not use the device if the glass made screen is damaged, cracked or broken to avoid any injury.
Do not paint it.
3433
Use only approved battery chargers and accessories that are compatible with your device model.
Remember to make back-up copies or keep a written record of all important information stored in your device.
Some people may suffer epileptic seizures or blackouts when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your device.
Parents should monitor their children’s use of video games on the device. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions:
- Take a minimum of a 15-minute break hourly.
- Play in a room in which all lights are on.
- Play at the far thest distance possible from the screen.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and see a doctor.
When you play games on your device, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow the instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders.
PRIVACY
Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your device regarding taking photographs and recording sounds with your device. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/ or to record the voices of other people or any of their personal attributes, and duplicate or distribute them, as this may be considered to be an invasion of privacy. It is the user's sole responsibility to ensure that prior authorization be obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your device (including the operator) disclaim any liability which may result from the improper use of the device.
Please note that by using this device some of your personal data may be shared with the main device (smartphone). It is under your own responsibility to protect your own personal data and not share it with any unauthorized devices or third party devices
3635
connected to yours. For products with Wi-Fi features, only connect to trusted Wi-Fi networks. Also, when using your product as a hotspot (where available), use network security. These precautions will help prevent unauthorized access to your device. Your product can store personal information in various locations including a SIM card, memory card, and built-in memory. Be sure to remove or clear all personal information before you recycle, return, or give away your product. Choose your apps and updates carefully, and install from trusted sources only. Some apps can impact your product’s performance and/or have access to private information including account details, call data, location details and network resources.
BATTERY
Please note your tablet is a unibody device, the back cover and battery are not removable. Observe the following precautions for battery use:
- Do not attempt to open the back cover and replace the inner rechargeable Li-Polymer battery. Please contact the dealer to replace it.
- Do not attempt to eject, replace, or open battery.
- Do not puncture the back cover of your device.
- Do not burn or dispose of your device in household garbage or store it at temperature above 140°F.
- Do not dispose of your device with household trash, to dispose of device contact your local municipal
waste disposal center for electronic waste options.
This symbol on your device, battery and
accessories means that these products must be taken to collection points at the end of their life:
- Municipal waste disposal centers with specific bins for these items of equipment.
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these collection points.
In non-European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead they are to be taken to collection points for them to be recycled.
CHARGERS
Chargers will operate within the temperature range of: 14°F to 113°F.
3837
The chargers designed for your device meet with the standard for safety of information technology equipment and office equipment use. They are also compliant to the eco design directive 2009/125/EC. Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction. They should be used for this purpose only.
The charger shall be installed near the device and shall be easily accessible.
Federal Communications Commission (FCC) Declaration of Conformity
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment.
This device has been tested and found to comply with the limits for a Class B digital, pursuant to Par t 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment.
FCC RF Exposure Information (SAR):
This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the United States.
During SAR testing, this is set to transmit at its
4039
highest certified power level in all tested frequency bands, and placed in positions that simulate RF exposure in usage near the body with the separation of 9 mm. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.
The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands.
The FCC has granted an Equipment Authorization for this model device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model device is on file with the FCC and can be found under the Display Grant section of HYPERLINK "http://www. fcc.gov/oet/ea/fccid" www.fcc.gov/oet/ea/fccid after searching on FCC ID:
2ACCJB052.
For this device, the highest reported SAR value for
usage near the body is:
Maximum SAR for this model and conditions under which it was recorded:
9015W (Body worn)
1.49 W/kg
SAR compliance for body operation is based on a separation distance of 9 mm between the device and the human body. During use, the actual SAR values for this device are usually well below the values stated above. This is because, for purposes of system efficiency and to minimize interference on the network, the operating power of your device is automatically decreased when full power is not needed. The lower the power output of the device, the lower its SAR value.
Body-worn SAR testing has been carried out at a separation distance of 9 mm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body.
If you are not using an approved accessory ensure that whatever product is used is free of any metal and that it positions the device the indicated distance away from the body.
Organizations such as the World Health Organization and the US Food and Drug Administration have
4241
suggested that if people are concerned and want to reduce their exposure they could use a hands-free accessory to keep the wireless device away from the head or body during use, or reduce the amount of time spent on the device.
LICENSES
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the Bluetooth SIG,Inc. and any use of such marks by TCL Communication Ltd. and its affiliates are under license. Other trademarks and trade names are those of their respective owners.
9015W Bluetooth Declaration ID D028888
The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance.
Your device uses non-harmonized frequency and is intended for use in all European countries.
The WLAN can be operated in the EU without restriction indoors, but cannot be operated outdoors in France.
Google, the Google logo, Android, the Android logo, Google Search™, Google Maps™, Gmail™, YouTube, Google Play Store, Google Latitude™ and Hangouts™
are trademarks of Google Inc.
The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License (the text will show when you touch and hold Google legal in Settings >
About Tablet > Legal information) 1.
ALCATEL INFORMATION
Website: www.alcatelonetouch.us
Technical Support Number: In the United States, call
855-368-0829.
Facebook: http://www.facebook.com/alcatelonetouchusa
Twitter: http://www.twitter.com/alcatel1touch
Visit our website to download your device’s user manual and for frequently asked questions (FAQs).
Your device is a transceiver that operates on Wi-Fi with
2.4GHz and 5GHz, Bluetooth with 2.4GHz.
Disclaimer
There may be certain differences between the user manual description and the device’s operation, depending on the software release of your device or specific operator services.
This device may contain materials, including
1
It may not be available according to the countries.
4443
applications and software in executable or source code form, which is submitted by third parties for inclusion in this device ("Third Party Materials").
All third party materials in this device are provided "as is", without warranty of any kind, whether express or implied, including the implied warranties of merchantability, fitness for a particular purpose or use/third party application, interoperability with other materials or applications of the purchaser and non­infringement of copyright. The purchaser undertakes that TCL Communication has complied with all quality obligations incumbent upon it as a manufacturer of mobile devices and devices in complying with Intellectual Property rights.
45
Loading...
