Quick Start Guide
CJB1B3A01AAB
This product meets applicable national
SAR limits of 1.6 W/kg.
The specic maximum SAR values can
be found in the Radio Waves section
www.sar-tick.com
of this user guide.
When carrying the product or using
it while worn on your body, either
use an approved accessory such as
a holster or otherwise maintain a
distance of 10 mm from the body to
ensure compliance with RF exposure
requirements. Note that the product
may be transmitting even if you are
not surng internet.
Safety and use
We recommend that you read this chapter carefully before
using this device. The manufacturer disclaims any liability for
damage, which may result as a consequence of improper
use of this device or of use contrary to the instructions
contained herein.
Do not switch on your device when its use is
prohibited or when using the device may cause
interference or danger.
Follow rules or regulations in hospitals and
health care facilities. Switch off your device near
medical apparatus.
2
Switch off your device in an aircraft. The device
may cause interference to aircraft control
signals.
Switch off your device near high-precision
electronic devices. The device may affect the
performance of these devices.
Do not attempt to disassemble your device or
its accessories. Only qualied personnel are
allowed to service or repair the device.
Do not place your device or its accessories in
containers with a strong electromagnetic eld.
Do not place magnetic storage media near your
device. Radiation from the device may erase the
information stored on them.
Do not subject your device to high temperatures
or use it in a place with ammable gas such as
a petrol station.
Keep your device and its accessories away from
children. Do not allow children to use your
device without guidance.
Only use approved batteries and chargers to
avoid the risk of explosion.
Observe the laws or regulations on device use.
Respect others’ privacy and legal rights when
using your device.
It is recommended that the equipment only be used in an
environment where the temperature is between -10°C and
50°C and humidity is between 10% to 90%.
3
CHARGERS
Mains powered chargers will operate within the
temperature range of: 0°C to 40°C.
The chargers designed for your device meet with the
standard for safety of information technology equipment
and ofce equipment use.
They are also compliant to the ecodesign directive
2009/125/EC. Due to different applicable electrical
specications, a charger you purchased in one jurisdiction
may not work in another jurisdiction. They should be used
for this purpose only.
1. Overview
Y859 is a portable wireless router, providing a simple way to
share 4G with any Wi-Fi embedded device.
1.1 Package contents
Y859 USB cable
Quick start guide Charger
4
1.2 Application
PC
PAD
1.3 Device overview
Number Description
Power on/off Key
WPS Key
5
Smart phone
Number Description
LED light
Micro USB Interface
Use the device’s 2 buttons as follows:
Button Description
Power
On/Off
Long press to turn on/off the device
Short press to put the LED in either active
or sleep mode.
Long press to turn on WPS
WPS
Short press to put the LED in either active
or sleep mode
1.4 Turning on the device
Step 1: Open back cover from Bottom of right corner,
then take out battery and put SIM card as remark.
Step 2: Long Press the Power On/Off button.
