TCL Communication B032 User Manual
5022N
Quick Reference Guide
ALCATEL ONETOUCH would like to thank you for your purchase.
Our goal is to provide you with a high-quality mobile communication
experience.
For more information about how to use your mobile phone, please
visit www.alcatelonetouch.us to consult the FAQs.
English - CJB1DH4ALAAA
1
Indice
1 Your mobile ��������������������������������������������������������������������� 3
2 Text input ���������������������������������������������������������������������� 14
3 Phone call ���������������������������������������������������������������������� 16
4 Contacts ������������������������������������������������������������������������ 18
5 Messaging����������������������������������������������������������������������� 18
6 Email ������������������������������������������������������������������������������ 20
7 Getting connected �������������������������������������������������������� 21
8 Find my location using GPS satellites ������������������������ 24
9 Data backup ������������������������������������������������������������������ 25
10 Factory data reset �������������������������������������������������������� 25
11 Applications & Internal storage ���������������������������������� 26
12 Upgrade ������������������������������������������������������������������������� 27
Safety and use
General information
Troubleshooting
www.sar-tick.com
������������������������������������������������������������������������� 28
�������������������������������������������������������������� 38
���������������������������������������������������������������������� 41
This product meets applicable
national SAR limits of 1.6 W/kg. The
specific maximum SAR values can be
found in the RADIOWAVES section
of this user guide.
When carrying the product or using
it while worn on your body, either
use an approved accessory such as
a holster or otherwise maintain a
distance of 10 mm from the body to
ensure compliance with RF exposure
requirements. Note that the product
may be transmitting even if you are
not making a phone call.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker
is in use.
2
Your mobile ������������������
1
1�1 Keys and connectors
Headset connector
Front Camera
Touch screen
Back key
Home key
Micro-USB
connector
3
Recents key
Camera Flash/Flashlight
Power
key
Recents key
Recent apps� Touch to open a list of thumbnail images
•
of apps you've worked with recently. Touch it to open
an app. Swipe it left or right to remove a thumbnail
from the list.
Home key
• From any application or screen, touch to return to the
Home screen.
• Touch and hold to open Google search.
• Double-click the home button to access the camera
application.
Back key
• Touch to go back to the previous screen, or to close
a dialog box, options menu, the notification panel, etc.
4
Volume up
Volume down
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the popup menu to select from
Power off/Reboot/Airplane mode.
• Press and hold the Powe r key and Volume down key
to capture a screenshot.
• Press and hold the power key for at least 8 seconds to
force reboot or hold it longer to power off.
Volume Keys
• Under call mode, adjusts the earpiece or headset
volume.
• In Music/Video/Streaming mode, adjusts the media
volume.
• In general mode, adjusts the ringtone volume.
• Mutes the ringtone of an incoming call.
• In camera preview mode, press Volume up or down
key to enter burst shoot.
5
1�2 Getting started
1�2�1 Set up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Power off your
phone before inserting or removing the SIM card.
Place the SIM card with the chip facing downwards and slide it into
its housing. Make sure that it is correctly inserted. To remove the
card, press and slide it out.
For this phone, both SIM1 and SIM2 can support 2G and 3G
networks. If both of them are 3G SIM cards, only one card
can support 3G network. Your phone only supports microSIM card. Do not attempt to insert other SIM types like mini
and nano cards, otherwise you may damage your phone.
6
Installing or removing the battery
Please power off your phone before removing the battery.
• Insert and click the battery into place, then close the cover.
• Unclip the cover, then remove the battery.
Installing or removing the microSD card
To install, insert the microSD card first, and then place it into the slot
with the gold contact facing down. To remove the external microSD
card, slide and take it out from the slot.
Charging the battery
Connect battery charger to your phone and plug into the socket.
If the battery is very low, there will be no indication that
power is being received until the charge is sufficient to show
the charging status bar. To reduce power consumption and
energy waste , once the batter y is fully charged, disconnect
your charger from the plug; switch off Wi-Fi, GPS, Bluetooth
or background-running applications when not in use; reduce
the backlight time, etc.
7
1�2�2 Power on your phone
Hold down the Powe r key until the phone powers on. It will take a
few seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you should set the following
options: Language, Google Account, etc .
Even if no SIM card is installed, your phone will still power on and you
will be able to connect to a Wi-Fi network.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the phone
options appear, select Power off.
1�3 Home screen
You can move all of the items (applications, shortcuts, folders and
widgets) you use most frequently to your Home screen for quick
access. Touch the Home key to switch to the Home screen.
The Home screen is provided in an extended format to allow more
space for adding applications, shortcuts, etc. Slide the Home screen
horizontally left and right to get a complete view.
Status bar
• Status/Notification indicators
• Touch and drag down to open
the notification panel.
Search bar
• Touch to enter text search screen.
• Touch to enter voice search screen.
Touch an icon to open an application,
folder, etc .
Favorite tray applications
• Touch to enter the application.
• Touch and hold to move or
change applications.
Touch to enter application list.
8
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Touch and Hold
Touch and hold the item to enter the available options.
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen up and down to scroll through the applications,
images, web pages, etc .
Flick
Similar to swiping, but flicking makes it move quicker.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways to have a better view.
1�3�2 Status bar
From the status bar, you can see both phone status (to the right side)
and notification information (to the left side).
9
Status icons
GPRS connected Bluetooth is on
GPRS in use
EDGE connected
EDGE in use Roaming
3G connected Headset connected
3G in use No SIM card installed
HSPA+ connected Vibrate mode
HSPA+ in use Battery is very low
Signal strength Battery is low
Wi-Fi is on
Connected to a Wi-Fi
network
Airplane mode Battery is charging
No signal GPS is on
Portable Wi-Fi hotspot
is on
Alarm is set
Connected to a
Bluetooth device
Speakerphone is on
Battery is partially
drained
Battery is full
Connected to VPN
10
Notification icons
New Gmail message Missed call
New Email message Call forwarding is on
New text or multimedia
message
Problem with SMS or
MMS delivery
New Google Hangouts
message
New voicemail Download finished
Upcoming event
Screenshot captured
Both USB tethering and
portable hotspot are on
USB tethering is on
More notifications are
hidden
Song is playing
Radio is on
Uploading data
An open Wi-Fi network
is available
Phone is connected via
USB cable
System update available
Carrier data use
threshold approaching
or exceeded
11
Touch and drag down the Status bar to open the Quick settings panel
or Notification panel. Touch and drag up to close it. When there are
notifications, you can touch them to access notifications directly.
Notification panel
When there are notifications, touch and drag down the Status bar
to open the Notification panel to read more detailed information.
Touch to switch to the Quick settings
panel.
Touch to clear all event–based
notifications (other ongoing
notifications will remain).
Quick settings panel
Touch and drag down the Notification panel or touch
the Quick settings panel. You can enable or disable functions or
change modes by touching the icons.
Touch to enter user screen.
Touch to access the Settings, where you
can set more items.
to open
12
1�3�3 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by
creating a variety of patterns, PIN or password etc.
1�3�4 Personalize your Home screen
Add
You can long press a folder, an application, or a widget to activate the
Move mode and drag the item to any Home screen.
Reposition
Long press the item to be repositioned to activate the Move mode
and drag the item to the desired position and release. You can move
items both on the Home screen and the Favorite tray. Hold the icon
on the left or right edge of the screen to drag the item to another
Home screen.
Remove
Long press the item to be removed to activate the Move mode. Drag
the item up to the top of the
Create folders
To improve the organization of items (shortcuts or applications) on
the Home screen, you can add them to a folder by stacking one item
on top of another. To rename a folder, open it and touch the folder’s
title bar to input the new name.
Wallpaper customization
Touch Settings on the applications screen then touch Display\
Wallpaper to customize wallpaper.
icon.
1�3�5 Volume adjustment
You can set the ringer, media and phone ringtone volumes to your
preference by pressing the Volume up/down key, or touching
Settings\Sound & notification\Alarm volume or Ring volume
to set the volume.
1�3�6 Application tab
Touch
from the Home screen to enter the applications list.
To return to the Home screen, touch the Home ke y.
13
Consult recently-used applications
To consult recently-used applications, you can touch the Recents
key. Touch a thumbnail in the window to open the related application.
Touch one thumbnail and slide left or right to delete it.
Text input ����������������������
2
2�1 Using Onscreen Keyboard
Onscreen Keyboard settings
Touch Settings\Language & input, touch the keyboard you want
to set up and a series of settings will become available for your
selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard
orientation. You can adjust it by changing the settings (Touch
Settings\Display\When device is rotated�
2�1�1 Android keyboard
Touch to enter
text or numbers.
Touch to switch
"abc/Abc" mode;
Long press to
switch "abc/ABC"
mode.
Touch to switch
between numeric
keyboard and
alphabetic on MS.
Touch to input comma;
Long press to show
input options.
Long press to
select symbols.
14
Loading...
