Quick Start Guide
Thank you for buying the ALCATEL ONETOUCH 8056/8057,
We hope you will enjoy your high-quality communication
experience.
You have purchased a product which uses open source (http://
opensource.org/) programs mtd, msdosfs, netfilter/iptables and
initrd in object code and other open source programs licensed
under the GNU General Public License and Apache License.
We will provide you with a complete copy of the corresponding
source codes upon request within a period of three years from
the distribution of the product by TCL Communication Ltd.
You may download the source codes from http://sourceforge.
net/projects/alcatel/files/. The provision of the source code is
free of charge from internet.
English - CJB1CH1ALAAA
1
Table of contents
1 Your device ................................................................3
1.1 Appearance ......................................................................... 3
1.2 Home screen ...................................................................... 5
1.3 Apps and widgets ............................................................... 8
1.4 Basic operation ................................................................... 9
2 Settings ....................................................................13
2.1 Device ................................................................................. 13
2.2 Personal ............................................................................ 14
2.3 System ................................................................................ 15
Safety information .......................................................16
General information ....................................................26
Warranty ......................................................................28
This device meets applicable national SAR
limits of 1.6 W/kg. SAR values can be
found on page 24 of this user guide. When
carrying the device or using it while worn
www.sar-tick.com
on your body, either use an approved
accessory such as a holster or otherwise
maintain a distance of 0 mm from the body
to ensure compliance with RF exposure
requirements. Note that the product may
be transmitting even if you are not using it.
To prevent possible hearing damage, do not
listen at high volume levels for long periods.
Exercise caution when holding your device
near your ear while the loudspeaker is
in use.
The tablet contains magnets which
may interfere with other devices and
items (such as credit card, pacemakers,
defibrillators, etc.). Please maintain at least
15 cm of separation between your tablet
and the devices/items mentioned above.
2
Your device
1
1.1 Appearance
123
4
5
6
7
8 9
3
Number Function
1 Earphone socket
2 Microphone
3 micro-USB connector/Battery charge port
4 Power key
5 Volume Up/Down
6 Front camera
7 microSD Card
8 Rear camera
9 Speaker
Inserting the microSD card
Be sure to insert your Micro SD card in the correct direction to
avoid damage. Please refer to the following instructions.
1 2
3 4
Note
Please charge before first use. Normally, the tablet will
power on and display the Home Screen when you press
and hold the Power key, but if the tablet is low on power,
a battery icon will appear indicating that you should charge
the device before use. Only use the charger recommended by TCL
Communication Ltd. and its affiliates.
This device cannot be charged using the USB connection on your
computer. Please plug in your charger before first use.
4
1.2 Home screen
Your device includes a Home screen with three pages, giving
you more space to add your favorite apps, folders and widgets,
all accessible with a single touch. To switch between screens,
slide your finger left or right.
1.2.1 Lock/Unlock your screen
Once your device is powered on, it shows a locked screen
interface, which is set as default.
Press and slide the locked screen to the right to unlock, slide
left to access the camera directly.
5
1.2.2 Icons on your screen
Google Search
All Apps
Back
Name Description
Google
Search
Voice
Actions
All Apps Touch to show all apps list interface.
Back Go back to the previous menu or screen.
Home Return to the home screen.
Recent apps Touch to access Add widgets, Manage
Touch it to access the Google search
engine.
Use Voice Actions to watch a video, send
email, set alarm, get directions, etc.
applications, Wallpaper and Settings; touch
and hold to view recent apps.
6
Status Bar
Voice Actions
Home
Recent apps
Touch and drag down the Status bar to open the Quick
setting panel or Notification panel. Touch and drag up to
close it.
Notification panel
When there are notifications, touch and drag down the Status
bar to open the Notification panel and read the detailed
information.
Touch to switch to the
Quick setting panel
Touch to clear all event–based
notifications (other ongoing
notifications will remain)
Quick setting panel
You can enable or disable functions or change modes by
touching the icons on the Quick setting panel.
Touch to switch to the
Notification panel
Touch to access Settings,
where you can set more
items
7
1.3 Apps and widgets
1.3.1 Apps
The Applications (apps) list contains all pre-embedded and
newly installed apps. To access the apps list, touch the all apps
key on the Home screen.
1.3.2 Widgets
By touching and holding an empty area on the Home screen,
you can switch to widget interface mode.
1.3.3 Get more apps
Touch the Google Play Store icon to get more apps.
1.3.4 Create and manage shortcuts on the
desktop
When you touch and hold an icon on the All Apps menu or
when in widget interface mode, it will jump to the Home screen
automatically, from here you can drag it to your preferred
location. Overlapping icons together will build a folder. You can
name the folder by touching the tab under the icons.
1.3.5 Remove an app icon from desktop
Touch and hold the item to be removed to activate Move
mode, drag the item up to the top of the " " icon, and
release after the item turns red.
1.3.6 Uninstall apps
Press to enter all Apps, then touch and hold the Apps
icon you want to uninstall, drag it over the " " icon, which
appears at the top-left of the desktop.
8
1.4 Basic operation
1.4.1 Power on your device
Press and hold the Powe r key until the tablet powers on. It will
take a few seconds before the screen lights up.
1.4.2 Power off your device
•Press and h old the Power key for about 3 s econd s until
the opt ions a ppear, select " Power of f " to powe r off yo ur
device.
•Press and h old the Power key for about 7 s econd s to
rest art your devic e.
1.4.3 Stand-by mode
Press the Power key once to shut down the screen and to
enter stand-by mode.
Note: When unused, the product will enter stand-by mode
automatically. Press the Power key once to wake it up.
1.4.4 Restart
•Press and h old the Power key for about 3 s econd s until
the opt ions a ppear, select " Reboo t" to restar t your device.
•When your d evice is frozen , press a nd hold t he Power ke y
for abo ut 10 seconds to sh ut down yo ur device. The n press
the Power key to res tar t.
1.4.5 Connecting to a computer via USB
After connecting your device to a computer via USB, you can
transfer files between your device and the computer.
Note: Files copied to your tablet are not available until
the USB data cable is disconnected from the PC
completely. Use a USB 2.0 version or higher to connect
the devices.
9
