LCD TV CONTROL BOARD
SPECIFICATION
MODEL: T.MSD309.9X
Part Number: MST-10062620
AUTHOR:
CHECKED BY:
RECHECKED1 BY:
RECHECKED2 BY:
APPROVED BY:
PUBLISHED DATE: 2010-07-02
The information in the specification is subject to change without notice.
Cathy
2010.07.01
11:56:49 +08'00'
wangzhimeng
2010.06.24
19:27:55 +08'00'
数字签名者：shelden
DN：cn=shelden, o=CVT,
ou=SW,
email=dengyourong@cvte.cn, c=<
无
日期：2010.06.24 19:43:19 +08'00'
2010.06.24
19:58:47
+08'00'
CONTENT
PAGE ITEM
1 CONTENT
1 REVISION HISTORY
2 GENERAL DESCRIPTION
2 FEATURES
5 FUNCTION LAYOUT
6 PCB DIMENSIONS
6 SCHEMATIC OF IR & KEY BOARD
7 INTERFACE DEFINITION
11 CONFIGURATION & GENERAL PRECAUTIONS
T.MSD309.9X-SPECIFICATION
REVISION HISTORY
VERSION DATE BOARD ID PAGE DESCRIPTION AUTHOR
V1.0 2010.06.22
V1.1 2010.06.26
T.MSD309.9A
10227
T.MSD309.9A
10227
All First issued. Cathy
2 Rectify the feature. Cathy
- 1 -
T.MSD309.9X-SPECIFICATION
1. GENERAL DESCRIPTION
T.MSD309.9X is a multi-purpose and energy-efficient ultra thin LCD TV control board with single/dual
LVDS interface. It supports LCD panel larger than 26” which resolution is up to 1920×1080.
T.MSD309.9X supports ATV, DVB-T, DVB-C(only with MSD308PX), Teletext, NICAM/A2, H.264,
HDCP(V1.1), USB(V2.0 HS), 3×HDMI(V1.3), SCART, PC-RGB, CVBS and YPbPr, as well as coaxial output
and audio line out. An audio amplifier which supports 2×9W(8ƻ) output is built-in.
T.MSD309.9X can receive and decode both Free-To-Air DTV and CA DVB-T program. It can decrypte
programs encrypted by Irdeto, Viaccess, Conax with built-in CI(optional).
T.MSD309.9X could connect with accessory modules to support extended functions such as built-in
DVD and External HDMI. Software upgrade, multimedia playback and PVR are applicable with the USB slot.
2. FEATURES
CHIPSET MSD309PX/MSD308PX
MARKET AREA Pan Europe, UK
OSD LANGUAGE English, French, German, Italian, Spanish, Portuguese (optional)
Panel Type LCD
PANEL
TV INPUT
Interface Dual/Single LVDS Interface
Max Resolution 1920×1080
Receiving Range 48.25MHz ~ 863.25MHz
Input impedance 75ƻ
Video System PAL, SECAM
ATV
DTV
Sound System
Teletext 1000Pages
Max Storage Channels 100CH
Receiving Range
Input Impedance 75ƻ
Channel Bandwidth 7MHz/8MHz
DVB-T
Modulation
Video System MPEG-2 MP@ML, H.264
DVB-C
(only with
MSD308PX)
BG, DK, I, L/L’
NICAM/A2
VHF (174MHz ~ 230MHz)
UHF (474MHz ~ 862MHz)
COFDM 2K/8K
QPSK,16QAM,64QAM
16QAM, 32QAM, 64QAM,
128QAM, 256QAM
Sound System
Basic Functions
Common Interface Built-In
Max Storage Channels 400CH(dynamic)
MPEG-1 layer 1/2,MPEG-2 layer 2,
DD(need license),DD+(need license)
EPG, Subtitle, LCN, Teletext (Europe),
MHEG-5(UK) (optional, only with 2 DDR)
- 2 -
PC-RGB Format Up to 1920×1080@60Hz
Video System PAL/NTSC/SECAM
CVBS
Video level 1.0 V
VIDEO INPUT
YPbPr 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
SCART CVBS & RGB
PC Audio Earphone Input 0.2 ~ 2.0 V
AUDIO INPUT
CVBS/YPbPr Audio L/R RCA Input 0.2 ~ 2.0 V
Frequency Response 100Hz~15KHz @±3dB (1KHz, 0dB reference signal)
AUDIO OUTPUT
Max Output power
2×9W(8ƻ) THD+N<10%@1KHz
(Power Supply: 24V, Audio Input: 0.5V
Requirement 24V/12V/5V/5VSB
POWER
To Panel 5V, 12V
Management Standby Power Consumption < 0.3W(Board Only)
COMB FILTER 3D
DEINTERLACE 3D
WEAK SIGNAL
ENHANCEMENT
NOISE
REDUCTION
YES
YES
USB FUNCTION Multimedia, PVR, Software upgrade
KEY FUNCTION MENU, CH+, CH-, VOL+, VOL-, INPUT, POWER
EXPANDABLE
FUNCTION
DVD, External HDMI, External USB
TV 1 IEC-Connector
USB 1 USB Slot(type A)
HDMI 3×HDMI terminal(type A)
SCART 1 SCART terminal(black)
PC Audio 1 Earphone terminal(black)
INPUT
PC-RGB 1 D-SUB terminal(blue, 15 pin)
TERMINALS
YPbPr 1 Earphone terminal(black)
CVBS 1 RCA terminal(yellow)
CVBS & YPbPr Audio 2 RCA terminals(white, red)
CI Slot(optional) 1 CI Slot(black)
Coaxial(optional) 1 RCA terminal(orange)
OUTPUT
Earphone Out 1 Earphone terminal(black)
T.MSD309.9X-SPECIFICATION
±5%
P-P
RMS
RMS
)
RMS
- 3 -
T.MSD309.9X-SPECIFICATION
USB MULTIMEDIA PLAYBACK FORMAT
Media
Movie
Music
File system: Hi Speed FS, FAT32, FAT16, NTFS(NTFS compressed file is not supported)
Note: Licenses are required for DivX, MPEG, H.264, AC3, MP3, WMA and AAC.
File
Ext.
.mpg MPEG-1, MPEG-2
.avi
.ts MPEG-2, H.264
.mov/
.mkv
.dat MPEG-1
.mp4
.vob MPEG-2
.mp3 -- MP3
.wma -- WMA
.m4a/
.aac
.jpg/
.jpeg
.bmp BMP
.png
Video Audio
DivX, Xvid, MJPEG,
MPEG-4 SP/ASP,
H.264
MPEG-4 SP/ASP,
H.264
MPEG-4 SP/ASP,
H.264
MPEG-1, MPEG-2
Codec
Max Solution: 1920×1080
Max Data Rate: 40 Mbps
MP3, WMA,
AAC, AC3
-- AAC
Progressive JPEG Max Resolution: 1024×768
Baseline JPEG Max Resolution: 8192×8192
Non-Interlaced Max Resolution: 3000×3000
Interlaced Max Resolution: 1500×1500
Max Solution: 1920×1080
Max Data Rate: 20 Mbps
Max Solution: 720×576
Max Data Rate: 40 Mbps
Sample Rate: 8K~48KHz
Bit Rate: 32K~320Kbps
Channel: Mono/Stereo
Sample Rate: 16K~48KHz
Bit Rate: 32K~442Kbps
Channel: Mono/Stereo
Max Resolution: 6500×6500
Pixel Depth: 1/4/8/16/24/32 bpp
Remark
SUBSTITUTABLE PRIMARY MATERIALS
The table is for reference only, the actual item is the standard.
NAME TYPE BRAND REMARKS
H5PS5162FFR-S5C Hynix --
DDR
FLASH
TUNER
NT5TU32M16CG-25C Nanya --
K4T51163QI-HCF7 Samsung --
W9751G6JB-25 Winbond --
MX25L3206EM2I-12G Macronix --
W25Q32BVSSIG Winbond --
EN25Q32A-100HIP EON --
DT82WT-3R-E TCL --
XDTT-6F1C/T1146 XuGuang --
CDT-SFT338-80 ChinaDragon --
- 4 -
3. FUNCTION LAYOUT
The picture is for a reference only, the actual item is the standard.
The optional connectors and terminals are marked with “*”.
TOP VIEW OF T.MSD309.9X
CN3:
Inverter
*CN21: DVD Power
Supply & Communication
CN5: LVDS
Interface
CN23:
Speaker
CN24: Amplifier
T.MSD309.9X-SPECIFICATION
*CN27: Audio
Power Supply
Line Out
External HDMI
*CN28:
CN9: Key & IR
Interface
CN2: Built-In
Power Supply
- 5 -
*CN20: External
USB In
*CN22: DVD
Video & Audio In
FRONT VIEW OF T.MSD309.9X
T.MSD309.9X-SPECIFICATION
USB
Slot
HDMI1 InHDMI2
In
SIDE VIEW OF T.MSD309.9X
YPbPr InCVBS
In
R L
CVBS/YPbPr Audio In
RF In
*Coaxial
REQUIREMENT OF WIRE HARNESS
YPbPr In
SCART
Out
PC
Audio In
PC-RGB
In
*CI
Slot
HDMI3 InEarphone
Out
Note:
The external HDMI is used in the case of requiring more than 3 HDMI, for it can be expanded to more
than one terminals with an HDMI switch.
HDMI3 and external HDMI can’t coexist with each other.
- 6 -
4. PCB DIMENSION
The overall height of T.MSD309.9X is 22 mm.
T.MSD309.9X-SPECIFICATION
7+7)[
6DPVXQJ઼
',*8$1*
5. SCHEMATICS OF IR BOARD & KEY BOARD
1
A A
CN1
1
5V
2
LED_R
3
LED_G
4
IR
5
GND
6
K0
7
K1
8
K2
9
B B
14PIN- 2.0-D- H-G
C C
K3
10
K4
11
K5
12
K6
13
K7
14
GND
2
PMLL4148L
5V
D1
E1
47uF-16V-±20%-4*7
3
R8
5K1ohm- 0402-±5%-1/16W
C1
0.1uF-0402- Y5V-+80%- 20%-25V
ˉ
105
ć
IR
LED_R
LED_G
RE1
MIM-0KM1AKL-5383V1
123
C2
560pF-0402-X7R-±10%- 50V
D2
1
2
3
Green/red-Diameter 3.0-Commen cathod
-Figure of fog-Ge nera l luminanc e
4
S4S3S1 S7S6 S5 S2
GND
K0
K1
K2
K3
D D
K4
K5
K6
1
2
Title
Number RevisionSize
B
Date : 2010-4-16 Sheet of
File: F:\Doc uments and Set tings\..\IR&KEY. SchDoc Dra wn By:
3
4
- 7 -
T.MSD309.9X-SPECIFICATION
6. INTERFACE DEFINITION
The optional connectors are marked with “*”.
ƹ CN2(10PIN/2.54): BUILT-IN POWER SUPPLY CONNECTOR
NO. SYMBOL DESCRIPTION
1 5VSB +5V Power Supply when Standby
2 PON Power On/Off
3 GND
4 GND
5 P5V
+5V Power Supply for Panel
6 P5V
7 5V
Main +5V Power Supply
8 5V
9 GND Ground
10 12V +12V DC Power Supply
ƹ CN3(6PIN/2.0): INVERTER CONNECTOR
NO. SYMBOL DESCRIPTION
1 12V
+12V DC Power Supply
2 12V
3 BLO Back-Light ON/OFF Control for Panel
4 ADJ Brightness Adjustment for Panel
5 GND
6 GND
Ground
Ground
ƹ CN5(2× 20PIN/2.0): LVDS INTERFACE
NO. SYMBOL DESCRIPTION
1 VSEL
2 VSEL
3 VSEL
4 GND
5 GND
6 GND
7 TXO0- LVDS ODD 0- Signal
8 TXO0+ LVDS ODD 0+ Signal
9 TXO1- LVDS ODD 1- Signal
10 TXO1+ LVDS ODD 1+ Signal
11 TXO2- LVDS ODD 2- Signal
12 TXO2+ LVDS ODD 2+ Signal
13 GND
14 GND
15 TXOC- LVDS ODD Clock- Signal
16 TXOC+ LVDS ODD Clock+ Signal
17 TXO3- LVDS ODD 3- Signal
Power Supply for Panel
Ground
Ground
- 8 -
T.MSD309.9X-SPECIFICATION
NO. SYMBOL DESCRIPTION
18 TXO3+ LVDS ODD 3+ Signal
19 TXE0- LVDS EVEN 0- Signal
20 TXE0+ LVDS EVEN 0+ Signal
21 TXE1- LVDS EVEN 1- Signal
22 TXE1+ LVDS EVEN 1+ Signal
23 TXE2- LVDS EVEN 2- Signal
24 TXE2+ LVDS EVEN 2+ Signal
25 GND
26 GND
27 TXEC- LVDS EVEN Clock- Signal
28 TXEC+ LVDS EVEN Clock+ Signal
29 TXE3- LVDS EVEN 3- Signal
30 TXE3+ LVDS EVEN 3+ Signal
31 GND
32 GND
33 3.3V Mode Select
34 DISPLAY Display Control(Only for PDP)
35 VSEL1 Reserved Power Supply/
36 VSEL2 Reserved Power Supply
37 TXO4- LVDS ODD 4- Signal
38 TXO4+ LVDS ODD 4+ Signal
39 TXE4- LVDS EVEN 4- Signal
40 TXE4+ LVDS EVEN 4+ Signal
Ground
Ground
ƹ CN9(14PIN/2.0): KEY & IR BOARD CONNECTOR
NO. SYMBOL DESCRIPTION
1 5V +5V DC Power Supply
2 RED Red Indicator
3 GRN Green Indicator
4 IR IR Receiver
5 GND Ground
6 K0 Key0
7 K1 Key1
8 K2 Key2
9 K3 Key3
10 K4 Key4
11 K5 Key5
12 K6 Key6
13 K7 Key7(Reserved)
14 GND Ground
- 9 -
T.MSD309.9X-SPECIFICATION
ƹ *CN20(4PIN/2.0):EXTERNAL USB CONNECTOR
NO. SYMBOL DESCRIPTION
1 5V +5V DC Power Supply for USB
2 DM USB Data-
3 DP USB Data+
4 GND Ground
ƹ *CN21(8PIN/2.0): DVD POWER SUPPLY & COMMUNICATION
CONNECTOR
NO. SYMBOL DESCRIPTION MAX CURRENT
1 D5
2 D5
3 GND
4 GND
5 D12 +12V DC Power Supply for DVD 1000 mA
6 DIR IR Data Transfer to DVD --
7 DAT/RX Data Receiver/Serial Data Receiver --
8 STB/TX DVD Standby Control/Serial Data Transmitter --
+5V DC Power Supply for DVD 1200 mA
Ground --
ƹ *CN22(11PIN/2.0):DVD VIDEO & AUDIO INPUT CONNECTOR
NO. SYMBOL DESCRIPTION
1 NC No Connection
2 GND Ground
3 DRI DVD Audio Right Channel Input
4 GND Ground
5 DLI DVD Audio Left Channel Input
6 DPB DVD YPbPr-Pb Input
7 GND Ground
8 DPR DVD YPbPr-Pr Input
9 GND Ground
10 DY DVD YPbPr-Y Input
11 GND Ground
ƹ CN23 (4PIN/2.54): SPEAKER CONNECTOR
NO. SYMBOL DESCRIPTION
1 LO Audio Left Channel Output
2 GND
3 GND
4 RO Audio Right Channel Output
Ground
- 10 -
T.MSD309.9X-SPECIFICATION
ƹ CN24 (4PIN/2.54): AMPLIFIER POWER SUPPLY CONNECTOR
NO. SYMBOL DESCRIPTION
1 24V
2 24V
3 GND
4 GND
+24V Power Supply for Amplifier
Ground
ƹ *CN27 (3PIN/2.0): AUDIO LINE OUT CONNECTOR
NO. SYMBOL DESCRIPTION
1 LO Audio Left Channel Output
2 GND Ground
3 RO Audio Right Channel Output
ƹ *CN28(2×10PIN/2.0): ENTERNAL HDMI CONNECTOR
NO. SYMBOL DESCRIPTION
1 HDMI_RX2+ HDMI 2+ Signal
2 HDMI_RX2- HDMI 2- Signal
3 HDMI_RX1+ HDMI 1+ Signal
4 HDMI_RX1- HDMI 1- Signal
5 HDMI_RX0+ HDMI 0+ Signal
6 HDMI_RX0- HDMI 0- Signal
7 HDMI_RXC+ HDMI Clock+ Signal
8 HDMI_RXC- HDMI Clock- Signal
9 HDMI_SCL HDMI DDC I2C SCL
10 HDMI_SDA HDMI DDC I2C SDA
11 GND
12 GND
13 POW_SINK HDMI 5V
14 HPD_CON Hot Plug Detect
15 GND
16 GND
17 CEC CEC Signal
18 +5V +5V Power Supply
19 M_SCL Main I2C SCL
20 M_SDA Main I2C SDA
Ground
Ground
- 11 -
T.MSD309.9X-SPECIFICATION
7. CONFIGURATION & GENERAL PRECAUTIONS
Relative humidity: 80%.
Storage temperature: -10~60°C.
Operation temperature: 0~40°C.
Protect the board from static electricity in case of damage to the IC.
Keep the board away from conductor when it is working.
Don’t push or pull the connectors when the board is working.
Don’t press , distort or disassemble the board.
Clean the board with soft dry cloth when it’s dirty.
Don’t wire in the board to power supply before panel is correctly connected.
High-speed USB devices with Hi Speed FS file system are recommended for multimedia and
PVR application.
Mobile HDD or high-speed USB stick are recommended for better performance in PVR and
timeshift application.
The USB current must be kept within 1 A.
- 12 -
Loading...
