TCL L48S4700, L55S4700 Schematic

MANUAL DE SERVIÇO

TELEVISORES LCD

MODELOS : L48S4700 E L55S4700

MSTV(3)-115

ESPECIFICAÇÕES

Tensão de rede: 127 - 220V ~ (60 Hz) automático.
Consumo Stand by: < 0,5 W

Consumo médio:

Potência de áudio:

Resolução:

Contraste:

Brilho:

Tempo de

Peso:

Dimensões (Lx A x P):

Controle Remoto: RC199E
Condições de funcionamento: Temperatura: 0 ~35°C Umidade: 20 ~ 80% sem condensação.

Impedância de entrada de antena: 75 ohm tipo de
Sistema de sintonia F.S. ( Frequency synthesizer ) PLL
Sistema de televisão: Padrão M 525 linhas
Canais de recepção: 54MHz a 864MHz

Frequências Intermediarias

N E : 789.178

Resposta:

L48S4700 63 W
L55S4700 85 W
L48S4700 2 x 8 W RMS
L55S4700 2 x 8 W RMS
L48S4700 FHD (1920X1080) Diagonal visual : 48" (121cm )
L55S4700 FHD (1920X1080) Diagonal visual : 55" (139cm )
L48S4700 4.000: 1
L55S4700 4.000: 1
L48S4700 280 cd/m²
L55S4700 280 cd/m²
L48S4700 9,0 ms
L55S4700 8,0 ms
L48S4700 9,8Kg (c/ pedestal)
L55S4700 13,9Kg (c/ pedestal)
L48S4700 1091 x 683 x 220 (1091 x 633 x 82 Sem pedestal)
L55S4700 1245 x 770 x 221 (1245 x 720 x 90 Sem pedestal)

sbalanceada para VHF/UHF/CABO

Sinal Digital 44MHz

Portadora de vídeo : 45,75 MHz

Portadora de som : 41,25 MHz/ 4,5MHz
Sinais
Analógicos

Portadora de croma: 42,17 MHz

3,575611MHz (PALM)

Subportadoras de croma:

3,582056 MHz (PALN)
3,579545 MHz (N

TSC)

1. ÍNDICE

1. Especificações ...............................................................................................................................................Capa

2. TABELA DE TENSÕES E ATUALIZAÇÃO DE SOFTWARE

2.1 TENSÕES..........................................................................................................................................................03

2.2 ATUALIZAÇÃO DE SOFTWARE

2.2.1 INSTRUÇÕES PARA ACESSAR MENU DE SERVIÇO................................................................................03

2.2.2 VERIFICAÇÃO DA VERSÃO DE SOFTWARE.............................................................................................03

2.2.3 SW PRINCIPAL + MBOOT SW.................................................................................................................03

2.2.4 ATUALIZAÇÃO QUANDO O APARELHO NÃO TEM VÍDEO.......................................................................04

3. FLUXO DE SINAIS...................................................................................................................................................05

4. DIAGRAMA DE BLOCOS - FONTE DE ALIMENTAÇÃO.............................................................................................06

5. FLUXO DA FONTE DE ALIMENTAÇÃO.....................................................................................................................07

6. DIAGRAMA DE BLOCOS SINAL I C........................................................................................................................08

7. ESQUEMAS ELÉTRICOS

7.1 PCI PRINCIPAL - CONEXÕES............................................................................................................................09

7.2 PCI PRINCIPAL - FONTES.................................................................................................................................10

7.3 PCI PRINCIPAL - FONTES.................................................................................................................................11

7.4 PCI PRINCIPAL - SINTONIZADOR.....................................................................................................................12

7.5 PCI PRINCIPAL - SAÍDA ÁUDIO........................................................................................................................13

7.6 PCI PRINCIPAL - ENTRADA RGB......................................................................................................................14

7.7 PCI PRINCIPAL - LAN E SPDIF.........................................................................................................................15

7.8 PCI PRINCIPAL - USB WIFI...............................................................................................................................16

7.9 PCI PRINCIPAL - HDMI 1 E 2............................................................................................................................17

7.10 PCI PRINCIPAL - HDMI3 E FONTE MHL..........................................................................................................18

7.11 PCI PRINCIPAL - RESET E CHAVE PAINEL......................................................................................................19

7.12 PCI PRINCIPAL - MEMÓRIA EEPROM............................................................................................................20

7.13 PCI PRINCIPAL - CONEXÃO LVDS.................................................................................................................21

7.14 PCI PRINCIPAL - FILTROS FONTE..................................................................................................................22

7.15 PCI PRINCIPAL - FILTROS FONTE..................................................................................................................23

7.16 PCI PRINCIPAL - PROCESSADOR PRINCIPAL................................................................................................24

7.17 PCI PRINCIPAL - PROCESSADOR PRINCIPAL................................................................................................25

7.18 PCI PRINCIPAL - PROCESSADOR PRINCIPAL................................................................................................26

7.19 PCI PRINCIPAL - PROCESSADOR PRINCIPAL................................................................................................27

7.20 PCI PRINCIPAL - SAÍDA FONES.....................................................................................................................28

7.21 PCI PRINCIPAL - AMPLIFICADOR DE ÁUDIO.................................................................................................29

7.22 PCI PRINCIPAL - CONEXÕES PROCESSADOR E MEMÓRIA SDRAM..............................................................30

7.23 PCI PRINCIPAL - PROCESSADOR PRINCIPAL................................................................................................31

7.24 PCI PRINCIPAL - MEMÓRIA SDRAM..............................................................................................................32

7.25 PCI PRINCIPAL - FILTROS FONTE..................................................................................................................33

7.26 PCI TECLADO................................................................................................................................................34

7.27 P

7.28 PCI WIFI 1.....................................................................................................................................................36

7.29 PCI WIFI 2.....................................................................................................................................................37

7.30 PCI FONTE SMPS..........................................................................................................................................38

7.31 PCI FONTE DO BACKLIGHT...........................................................................................................................39

7.32 CONTROLE REMOTO.....................................................................................................................................40

8.1 VISTA EXPLODIDA................................................................................................................................................41

CI SENSOR..................................................................................................................................................35

2

02

2. TABELA DE TENSÕES E ATUALIZAÇÃO DE SOFTWARE

2.1 TENSÕES

Posição Valor Observação
P101 Pinos 1, 2 e 4 12V +/- 5% MAIN POWER
UD05/QD80 5V +/- 5% 5V
US01 5V +/- 5% USB_5V
US02 5V +/- 5% MHL_5V
P101 Pin 7 3,3V +/- 5% 3.3VSB
TU01 Pin 6 3,3V +/- 5% 3.3V
UD33 3,3V +/- 5% 3.3V
UD15 1,5V +/- 5% 1.5V
UD01 1,2V +/- 5% VCCK

2.2 ATUALIZAÇÃO DE SOFTWARE

2.2.1 INSTRUÇÕES PARA ACESSAR MENU DE SERVIÇO

Sempre que nesse manual solicitar acessar o menu de serviço deve-se efetuar o procedimento a seguir:

- Ligar o aparelho;

- No controle remoto pressionar a tecla MENU;

- Selecionar menu IMAGEM;

- Selecionar opção CONTRASTE;

- No controle remoto pressionar a sequência numérica 9735;

- Nesse momento o menu de serviço estará disponível

2.2.2 VERIFICAÇÃO DA VERSÃO DE SOFTWARE.

1) Com a TV ligada entrar no m enu de serviço

2) No menu de Serviço verifique se a

2.2.3 SW PRINCIPAL + MBOOT SW

A - Através do menu do usuário.
B – Salvar o arquivo “MS08F6upgrade.bin” na raiz de um dispositivo USB.
C – Conectar o dispositivo USB, com o software, na porta USB.
D – Selecionar MENU  OPÇÕES  ATUALIZAÇÃO DE SW  CONFIRMAR
E – Pressionar ENTER.
F – A atualização se iniciará

versão de software instalada está correta.

Nota: A versão do Software a ser usada deverá ser a informada no plano de materiais do respectivo produto.

03

2. TABELA DE TENSÕES E ATUALIZAÇÃO DE SOFTWARE

2.2 ATUALIZAÇÃO DE SOFTWARE

2.2.4 ATUALIZAÇÃO QUANDO O APARELHO NÃO TEM VÍDEO

A – Salvar o arquivo na raiz de um dispositivo USB.
B – Deixar o aparelho desligado (Power AC).
C – Conectar o dispositivo USB, com o software de instalação, na porta USB
D – Pressionar a tecla Power do TV e mantendo -a pressionada ligue a TV à tomada.
E – A atualização se iniciará.

Alteração do Project ID (Caso informações do painel esteja

Modelo Project ID (Painel)
48S4700 071
55S4700 073

Caso a tela fique totalmente escuro devido à diferença de painel x software instalado, pressione
062598+MENU+xxx
(xxx:Panel ID)

Modelo Painel Código
48S4700 ST4761B02_1 062598+ MENU +071
55S4700 ST5461B03_1 062598+ MENU +073

Após a atualização a TV entrará no modo TV canal 2. Entre no menu de serviço novamente , selecione a opção
Factory Reset, pressione enter , selecione sim e pressione enter novamente.
Após o reset desligue e ligue novamente o aparelho pela chave power.

m erradas)

04

3. FLUXO DE SINAIS

05

4. DIAGRAMA DE BLOCOS - FONTE DE ALIMENTAÇÃO

AC Input

100 - 240Vac

EMI Filter

and Rectier

Bridge Diode

PWM IC

13-RT7736-BGB

Photo coupler

Output1: 12V

Transformer

Output2: 53V

VCC Voltage

PWM Signal

Switching

MOSFET

Feedback Signal

06

5. FLUXO DA FONTE DE ALIMENTAÇÃO

07

6. DIAGRAMA DE BLOCOS DE SINAL I C

HDMI1_SCL

HDMI1

HDMI1_SDA

2

HDMI2

HDMI3

HDMI2_SCL

HDMI2_SDA

HDMI3_SCL

HDMI3_SDA

MS08PA

TU1_SCL

TU101

TU1_SDA

Tuner

08

7. ESQUEMAS ELÉTRICOS

7.1 PCI PRINCIPAL 1 - CONEXÕES

12V 12V

10K

GND

GND

GND

3.3VSB

GND

DIM_PWM

NC/

470R

R118

BL_ON_OUT

R103

10K

12V

GND

DIM_DC

POWER_ON

BL_ON

DIM_DC

R101

DIM_DC

T

POWER_ON

R104
220R

GND

BL_ON

C101

10U

T

C102

0.01U

C103

0.01U

P_ON

T

12V

T

GND

BL_ON

C104

0.01U

GND

4

6

8

10

12

GND6

MAIN_POWER

P101

CD41

220U

16V

T

GND5

12

3

5

7

DIM_PWM

9

DIM_PWM

11

C105

0.1U

0.01U

GND

T

T

C106

GND

C107

0.1U

R105

220R

T

STB

GND

3.3VSB

R102

10K

DIM_OUT

C198 CLOSE TO connect

3.3VSB

R164

47K

ESD5VNC/

D100

2 1

R165

22K

GND

KEY_IN

KEY_IN

P103A

KEY_IN

T

5

4

3

2

3.3VSB

1

3V3SB

KEY

GND

IR

T

GND2

T

F103A

GND

GND

R119

10K

3.3VSB

IR

C153

470P

C157

0.1U

F103

T

R109

220R

IR_IN

3.3VSB

C154

0.1U

GND

R165/C157 CLOSE TO IC

GND

LED

T

C174

0.1U

GND

1K

R163

LED_OUT

LED_OUT

09

7. ESQUEMAS ELÉTRICOS

7.2 PCI PRINCIPAL - FONTES

MAIN_POWER

R125

0R

12V

T

12V

3.3VSB

R121

2K2

POWER_ON_OUT

L:Power Down,H:Power On

R122
220R

POWER_ON

R123

NC/

4K7

NC/

R124

3K3

R129

NC/

C121

33K

B

0.1U

NC/

C

E

GND

R127

NC/

Q122

BT3904

R130

NC/

2K7

Q121

PMV65XPNC/

S

0R

D

G

0.1U

C122

NC/

12V

CD83

6800P

CD80
10U

GND

RD83

1K2

GND

CD81
10U

CD84

0.01U

CD82

0.1U

CD85

2U2

1

2

SS

3

REF

4

5 6

Vref=0.59V

UD05

FB

SS

REF

GND

ILIM

IN

HG

SW

LG BST

MP2905

10

CD86 0.01U

9

8

7

CD87 0.1U

RD82
6R8

RD80

4K7

RD81
6R8

RD8B

10K

GND

RD8A

10K

1

S1

2

G1
3

S2
4

G2

QD80

A04832

8

D1A

7

D1B

D2A

D2B

RD85

36K

CD89

CD88

150P

1U

RD84

9K1

LD80

6

5

6.8UH

CD8B

10U 0.1U

CD8C

10U

CD8D

10U

CD8E

5V

5V

@max5A

CD8A

3900P

RD86

2R2

GND

GND

10

7. ESQUEMAS ELÉTRICOS

7.3 PCI PRINCIPAL - FONTES

(Vin=2.5V-5.5V)

5V

If Vout=1V Set RD61=150K RD62=4.7K RD63=220K

If Vout=1.2V Set RD61=150K RD62=0R RD63=150K

If Vout=1.5V Set RD61=150K RD62=8.2K RD63=91K

If Vout=1.8V Set RD61=150K RD62=6.2K RD63=68K

5V

CD61
10U

GND

BOM COST=1.22RMB

GND

CD60

0.1U

Fixed Fsw=1.2MHZ

Fixed OCP=4.2A

4

3

2

1

MP2143

PGND

SW

VIN

PG

LD60
1UH

UD01

RD60

510K

OUT

AGND

FB

EN

5

6

7

8

GND

Vref=0.6V

RD62

120K

RD63
39K

GND

RD61

150K

GND

VID0

CD62

22U

RD74

VCCK

T

CD63

22U

Min 1.16V/ Max 1.24V

RD71

39K

3.3VSB

RD73

4K7

0R

4K7

VCCK

CD64

0.1U

RD72

RD70
1K

VCCK

@max3A

GND

QD70

2N7002K

UD33

AS1117-3.3

5V

5V

UD33A

NC/

AZ1084

ADJ/GND

GND

4

OUT

VIN

3

C176 0.1U

C175

10U

4

4

OUT

VIN

3

AS1117AD

2

1

4

2

VOUTVIN

GND/ADJ

1

GND

UD15

GND/ADJ

1

23

NC/

16V

C1

100U

R171
330R

R172

68R

C177

10U

GND

C184

100U

16V

NC/

C171

10U

10U

C185

NC/

GND

1V5

T

C172

0.1U

1.5V

1.5V

T

3V3

3.3V

3.3V

11

C182 0.1U

C181

10U

Output 1.5076V=1.25*(1+68/330)

GND

7. ESQUEMAS ELÉTRICOS

7.4 PCI PRINCIPAL - SINTONIZADOR

TU01

IF-AN
IF-AP

IF_AGC_A

IF_DN
IF_DP

IF_AGC_D

VCC
SDA

SCL

GND

RF_SW

11
10
9
8
7
6
5
4
3
2
1

RF_SW1

3.3V

TUNER_FAT-

TUNER_FAT+
TUNER_AGC

T_SDA

T_SCL

TU-GND1

T

GND

T_SDA

T_SDA

T_SCL

IF_AGC2

TUNER_AGC

3.3V

RF_SW1

T T

T_SCL

T

CT29

22P

GND

IF-

T

CT28

22P

T

IF+

RT13

220R
220R

RT12

1K

RT14

3.3V

RT10

RT11

4K7

4K7

TUNER_FAT+

TUNER_FAT-

RT21
470R

TU1_SDA

TU1_SCL

IF_AGC

RF_SW

TUNER_FAT+

TUNER_FAT-

CT77

GND

33P

33P

CT78

CT70

0.22UH

CT71

0.22UH

CT37

22P

CT38

22P

RF_SWITCH

CT30

CT81

TU1_VCC

T T

0.1U

10U

CT32

6800P

GND

GND

CT26

NC/

47P

CT35

0.1U

CT27

NC/

CT73

20P

47P

RT20
NC/

200R

CT36

0.1U

FAT+_D

FAT-_D

Close to tunter

GND

GND

close to SOC

12

7. ESQUEMAS ELÉTRICOS

7.5 PCI PRINCIPAL - SAÍDA ÁUDIO

Audio Output

GND

WHITE

RED

P311

P312

2

1

2

1

T

GND-R

T

GND-L

GND

AVOUT1_R

T

F301

GND

AVOUT1_L

T

F300

GND

C314

1U

1U

C315

C313

1000P

C332

1000P

GND

CLOSE TO SOC

R335

220K

AVOUT1_L_OUT

AVOUT1_R_OUT

R301

220K

13

7. ESQUEMAS ELÉTRICOS

7.6 PCI PRINCIPAL - ENTRADA RGB

NEARLY IC

GREEN

BLUE

RED

WHITE

RED

P310

AV1 IN

10

9

8

7

6

5

4

3

2

1

GND_AV_IN

T

T

AV1/Y

HD1_PB

HD1_PR

GND

R357

68R

C330

0.047U
VCOM0

NEARLY CONNECTOR

C340

0.047U

C345
1000P

R346

47R

C303

0.047U

C341

0.047U

C343

0.047U

AV1_V_IN

HD1_Y_IN

HD1_SOG_IN

HD1_Y_IN-

HD1_PB_IN

R315
33R

R345

47R

R341

T

T

F313

R342

75R

GND

F322

C320

NC/

47P

GND

R347
75R

10R

R343

68R

GND

GND

L_IN

F305

GND

R389 12K

R348
75R

GND

C389 560P

NC/

F323

R_IN

T

GND

T

F306

NC/

C393 1000P

GND

close to conn.

R305 10K

R304 10K

NC/

C394 1000P

12K

R390

GND

C390 560P

NC/

R344

47R

C344

0.047U

close to SOC

C301 1U

C302 1U

HD1_PR_IN

AV/YPBPR_L_IN

AV/YPBPR_R_IN

14

7. ESQUEMAS ELÉTRICOS

7.7 PCI PRINCIPAL - LAN E SPDIF

Must be differential 100ohm

F307

GND

IPTV IN WLAN CONNECTOR

F309F308

F312F311F310

ETHERNET

P400

U300

TXVP_0

TXVN_0

RXVP_1

RXVN_1

FE7

FE8

close to U300

C319

0.1U

GND

C322

0.1U

1

2

3

4

TS8121CLF

5

6

7

8 9

NET_TX1P

16

15

NET_TX1N

14

13

12

NET_RX1P

11

10

NET_RX1N

R320

R322

75R

R321

75R75R

C325

1000P

R323

75R

NET_TXC

GND

NET_RXC

TX1P

TX1N

RX1P

TXC

RX1N

RXC

SPDIF

NET_TX1P

T

NET_TX1N

T

NET_RX1P

T

NET_RX1N

T TT

NET_TXC

NET_RXC

1

2

3

4

5

6

7

8

SPDIF_OUT

close to SOC

15

C351

0.1U

R361

220R

C352

33P

R362

120R

GND

SPDIF

F321

T

P301

2

T

GND12

1

BLACK

7. ESQUEMAS ELÉTRICOS

7.8 PCI PRINCIPAL - USB WIFI

USB CONNECTOR

USB1_D-_IN

USB1_D+_IN

R150

R151

0R

0R

USB1_D+_IN

USB1_D-_IN-

USB1_D+_IN+

USB1_D-_IN

5V

2R2R100

2R2R100A

WIFI_ON

T

3.3V

USB1_D+

T

GND GND

USB1_D-

WIFI_5V

T

C100

0.1U

T

WIFI_GND

C100A

0.1U

T

GND

NC/

P302A

1

2

3

4

5

6

USB1_5V

T

USB3_D+

5V

GND

C321
10U

R338

4K7

US01

5

VIN

4 3

EN/EN# NC

U0RX

USB2_D-

USB2_D+
U0TX

VOUT

GND

RT9711A

1

2

R351

470R

R352

470R

GND

C300
470U

16V

GND

C329

10U

USB3_D-

USB_5V

R381

2R2

R382

2R2

GND

T

D­T

D+

F3F2F1

RXDTXD

TTT

F4

9
1
8
2
7
3
6
4
5

10

11

P304

MNT-HOLE1

MNT-HOLE2

16

GND

7. ESQUEMAS ELÉTRICOS

7.9 PCI PRINCIPAL - HDMI 1 E 2

GND

HDMI1_SCL
HDMI1_SDA

H1_HPD_OUT

F406

F407

F408

F409

F410

R415 100R

R416 100R

R424

10K

H1_HPD

H1_SCL

H1_SDA

H_CEC

H1_5V

R425

4K7

CEC

47K

R429

R417 47K

B

C

E

R404
100R

R407

1K

BT3904

Q402

H1_RX2+

H1_RX2-

H1_RX1+

H1_RX1-

H1_RX0+

H1_RX0-

H1_RXC+

H1_RXC-

H_CEC

H1_ARC

H1_SCL

H1_SDA

H1_5V

H1_HPD

GND

HDMI1

P800

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

GND1

RX1+

RX1-

GND3

RXC+

RXC-

NC2

DDCDA

VCC

RX2+

RX2-

GND2

RX0+

RX0-

GND4

NC1

DDCCLK

GND5

HPD

GND

HDMI3_SCL

HDMI3_SDA

H3_HPD_OUT

F416

F417

F418

F419

F420

R410 100R

R411 100R

R413

10K

H3_HPD

H3_SCL

H3_SDA

H_CEC

H3_5V

R414

4K7

47K

R408

R409 47K

B

C

E

R412

1K

Q403

BT3904

H3_RX2+

H3_RX2-

H3_RX1+

H3_RX1-

H3_RX0+

H3_RX0-

H3_RXC+

H3_RXC-

H_CEC

H3_SCL

H3_SDA

H3_5V

H3_HPD

GND

HDMI2

P801

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

GND1

RX1+

RX1-

GND3

RXC+

RXC-

NC2

DDCDA

VCC

RX2+

RX2-

GND2

RX0+

RX0-

GND4

NC1

DDCCLK

GND5

HPD

H1_ARC

GND

F403

C410

2U2

GND

R406

0R

GND

H1_ARC_OUT

17

7. ESQUEMAS ELÉTRICOS

7.10 PCI PRINCIPAL - HDMI3 E FONTE MHL

HDMI3

GND

HDMI2_SCL
HDMI2_SDA

F411

F412

F413

F414

F415

5V

R432 100R

R433 100R

H2_HPD

H2_SCL

H2_SDA

H_CEC

MHL_5V

R430

4K7

H2_HPD_OUT

R431
10K

MHL_DETECT

R459

MHL_5V

33R

H2_RX2+

H2_RX2-

H2_RX1+

H2_RX1-

H2_RX0+

H2_RX0-

H2_RXC+

H2_RXC-

H_CEC

H2_SCL

H2_SDA

H2_HPD

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

P802

RX2+

GND1

RX1+

GND2

RX1-

RX0+

GND3

RX0-

RXC+

GND4

RXC-

NC1

NC2

DDCCLK

DDCDA

GND5

VCC

HPD

RX2-

MHL_EN

MHL_CABLE_DET

NC/

5V

R440
100R

1K

R441

AVDD5V_MHL

R439

NC/

10K

C407

0.1U

GND

R434

5R6

C405

10U

C411

0.1U

GND

C406

0.1U

MHL_5V

MHL_DETECT

US02

1

VIN

2

GND

RT9728B

0.047U

VOUT

ILIM

FAULTEN/EN#

C401

GND

R435

100R

R436

300K

6

5

43

GND

MHL_CABLE_DET

220U

NC/

R442

18K

C402

16V

GND

C403

10U

MHL_5V

C404

0.1U

GND

18

7. ESQUEMAS ELÉTRICOS

7.11 PCI PRINCIPAL - RESET E CHAVE PAINEL

3.3VSB

3

1

R506

22K

C504
10U

GND

R507

D502

0BAV99

47K

2

B

Q501

BT3906

E

C

47KR508

C503
2U2

GND

C505

NC/

0.1U

Close to SOC

MCU_RESET

MCU_RESET

Reset=H
Normal=L

BAT54C

T

R511

3K3

D501

1 2

3

STB_RST

Normal=H

Standby=L

3.3VSB

Q502

E

B

C

BT3906

If 24v<17.8V then reset_H

If 12v<8.3V then reset_H

12V

GND

R515

56K

R516

27K

PANEL_ON

LO =>Panel OFF
HI =>Panel ON

12V

5V

R544

4K7

R541

R542

R545

3K3

NC/

0R

R543
33K

B

C515

0.1U

0R

C

E

GND

Q505

PMV65XP

S

Q506

BT3904

R546
2K7

PANEL_VCC

T

D

G

C514

0.1U

PANEL_VCC

19

7. ESQUEMAS ELÉTRICOS

7.12 PCI PRINCIPAL - MEMÓRIA EEPROM

GND

C516

0.1U

C517

2U2

3.3V

0.1U

C507

R517

10K

GND

NAND-RBZ
NAND-REZ
NAND-CEZ

NAND-CLE
NAND-ALE
NAND-WEZ
NAND-WPZ

R549

NC/

10K

UF01

MT29F1G08A

1

NC/RST

2

NC

3

NC1

4

NC2

5

NC3

6

R/B2

7

R/B1

8

RE

9

CE1

10

CE2

11

NC4

12

VCC

13

VSS

14

NC5

15

NC6

16

CLE

17

ALE

18

WE

19

WP

20

NC7

21

NC8

22

NC9

23

NC10

24 25

NC11 NC12

NC24
NC23
NC22
NC21

I/O7
I/O6
I/O5

I/O4
NC20
NC19

PRE

VCC1

VSS1
NC18
NC17
NC16

I/O3

I/O2

I/O1

I/O0
NC15
NC14
NC13

48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26

NAND-D7
NAND-D6
NAND-D5
NAND-D4

NC/

NAND-D3
NAND-D2

NAND-D1

NAND-D0

R518

0R

3.3V

0.1U

C508

GND

NAND-RBZ

NAND-REZ

NAND-CEZ

NAND-CLE

NAND-ALE

NAND-WEZ

NAND-WPZ

NAND-D7

NAND-D6

NAND-D5

NAND-D4

NAND-D3

NAND-D2

NAND-D1

NAND-D0

R520 22R

R521 22R

R522 22R

R524 22R

R525 22R

R526 22R

R527 22R

R528 22R

R529 22R

R530 22R

R531 22R

R532 22R

R533 22R

R534 22R

R535 22R

NAND_RBZ

NAND_REZ

NAND_CEZ

NAND_CLE

NAND_ALE

NAND_WEZ

NAND_WPZ

NAND_D7

NAND_D6

NAND_D5

NAND_D4

NAND_D3

NAND_D2

NAND_D1

NAND_D0

C520

33P

GND

C519

33P

20

7. ESQUEMAS ELÉTRICOS

7.13 PCI PRINCIPAL - CONEXÃO LVDS

FFC PIN NAME

No.

PANEL_VCC

1

PANEL_VCC

2
3

PANEL_VCC

4

PANEL_VCC

5

NC

6

GND

7

GND

8

GND

9

NC
LD_EN

10
11

TXE4+

12
13

14
15
16
17
18
19

TXE4-

TXE3+

TXE3-

GND

TXEC+

TXEC-

GND

TXE2+

20

TXE2-

21

TXE1+

22

TXE1-

23

TXE0+

24

TXE0-

3D_LR_OUT

25
26

3D_EN

TXO4+

27
28

TXO4-

29

TXO3+

TXO3-

30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50

51

GND

TXOC+

TXOC-

GND

TXO2+

TXO2-

TXO1+

TXO1-

TXO0+

TXO1-

GND

NC
NC

LG_DIM
LVDS_SEL
3D_FORMAT1
3D_VSYNC_IN

3D_FORMAT0/SDA/WP

SDA/SCL/WP

SCL

NC

DIM_OUT

MCU

OUT

PWM

OUT

PWM

OUT

IN
OUT
OUT
OUT

R540 22R

MS_DIM_OUT

P500

PANEL_VCC1

T

1
2
3
4
5
6
7
8
9
10
11
12
13

TXE4+

TXE4-

TXE3+

TXE3­14
15
16

TXEC+

TXEC­17
18
19
20
21
22
23

TXE2+

TXE2-

TXE1+

TXE1-

TXE0+

TXE0­24
25
26
27
28
29

TXO4+

TXO4-

TXO3+

TXO3­30
31
32

TXOC+

TXOC­33
34
35
36
37
38
39

TXO2+

TXO2­TXO1+

TXO1-

TXO0+

TXO0­40
41
42
43
44

GND

LVDS_SEL
45
46
47
48
49
50
51

PANEL_VCC

C571

0.1U

GND

R580
R581
R582
R583

NC/
NC/
NC/
NC/

100R

100R
100R

100R

SDA

SCL

21

7. ESQUEMAS ELÉTRICOS

7.14 PCI PRINCIPAL - FILTROS FONTE

AUVRM

L602

1000R

C602

0.1U

C603

0.47U

AUVAG

core power

XTALO

XTALI

IF-AGC

3.3V

GND

R601

10K

close to SOC

0RR603

R604

NC/

1M

R602

0R

X24M1

24M

C642

33P

C643

33P

GND

GND

R618

100R

IF_AGC

VCCK

C638
22U

C637

2U2

C635

2U2

C604

2U2

C613

0.1U

C606

0.1U

C607

0.1U

1.5V

C608

0.1U

C609
22U

C615

10U

C610

0.1U

C616

2U2

C617

0.1U

L600
600R

C618

0.1U

+1.15V_VDDC_RX

C636

0.1U

C619

0.1U

C611

0.1U

C620

NC/

GND

0.1U

C612

0.1U

C621

NC/

0.1U

Close to SOC

GND

C605

0.022U

GND

C681

0.1U

GND

DDR3 POWER

22

7. ESQUEMAS ELÉTRICOS

7.15 PCI PRINCIPAL - FILTROS FONTE

STANDBY POWER_3.3

3.3VSB

GND

C622

10U

3.3V

C623

0.1U

C624

0.1U

NORMAL POWER 3.3V

C625

0.1U

NC/

C626

0.1U

R625
1000R

C627

NC/

0.1U

AVDD_DMPLL

C628

NC/

0.1U

3.3VSB

0R

R626

AVDD_AU

GND

C629

0.1U

C630

NC/

0.1U

GND

C631
10U

C632

0.1U

C633

0.1U

C634

1U

23

7. ESQUEMAS ELÉTRICOS

7.16 PCI PRINCIPAL - PROCESSADOR PRINCIPAL

U001

HD1_PR_IN

HD1_Y_IN-

HD1_Y_IN
HD1_PB_IN

HD1_SOG_IN

M3

L2
L3

K2
M5
M4

N2
N1
N3
M2
M1

R2
R3

P2

P3

K4
M6

RIN0P
GIN0M
GIN0P
BIN0P
HSYNC0
VSYNC0

RIN1P
GIN1M
GIN1P
BIN1P
SOGIN1

RIN2P
GIN2M
GIN2P
BIN2P
HSYNC2
VSYNC2

U001

RGB

CVBS

MSD6308RTMN

PHY

USB

RN
RP

TN

TP

DM_P0

DP_P0

DM_P1

DP_P1

CVBS1P
CVBS0P

VCOM0

CVBS_OUT

RXVN_1

B2
B1

RXVP_1

TXVN_0

C2

TXVP_0

C1

C4

USB2_D-

USB2_D+

B4
Y10

USB1_D-_IN

W10

USB1_D+_IN

T1

AV1_V_IN

T3
T2
R1

VCOM0

T

CVBS-OUT

NAND_D0
NAND_D1
NAND_D2
NAND_D3
NAND_D4
NAND_D5
NAND_D6
NAND_D7

NAND_ALE

NAND_WPZ

NAND_CEZ
NAND_CLE

NAND_REZ

NAND_WEZ

NAND_RBZ

U20
V15

AA18

Y20

T16

W18

T14

Y21

Y18

W17

Y17

W16

Y16

AA16

W15

AA15

Y19
AA19
AA20

W21

V20

W20

V17

W19

U16

U17

T15
V16
U15
U14
V19
V18
V21

T8
T9
V7

U9

V9
U8
U7

PCM_D0
PCM_D1
PCM_D2
PCM_D3
PCM_D4
PCM_D5
PCM_D6
PCM_D7

PCM_A0
PCM_A1
PCM_A2
PCM_A3
PCM_A4
PCM_A5
PCM_A6
PCM_A7
PCM_A8
PCM_A9
PCM_A10
PCM_A11
PCM_A12
PCM_A13
PCM_A14

PCM_RESET
PCM_IRQA_N
PCM_IOWR_N
PCM_OE_N
PCM_IORD_N
PCM_CE_N
PCM_WE_N
PCM_CD_N
PCM_REG_N
PCM_WAIT_N

NAND_ALE
NAND_WPZ
NAND_CEZ
NAND_CLE
NAND_REZ
NAND_WEZ
NAND_RBZ

TS0_D0
TS0_D1
TS0_D2
TS0_D3
TS0_D4
TS0_D5
TS0_D6

TS0_D7
TS0_CLK
TS0_VLD

TS0_SYNC

TS1_D0

TS1_D1

TS1_D2

TS1_D3

TS1_D4

TS1_D5

TS1_D6

TS1_D7
TS1_CLK
TS1_VLD

TS1_SYNC

VIFP

VIFM

IFAGC

TGPIO0

TGPIO1

T_I2C_CLK
T_I2C_SDA

W14
W13
W11
Y15
Y13
Y12
Y14
W12
AA12
AA13
Y11

T13
U13
T12
U10
T11
U11
T10
V12
V13
U12
V10

W2
W1

Y3

AA4
Y4

Y2
Y1

FAT+_D

FAT-_D

IF-AGC

RF_SW

TU1_SCL
TU1_SDA

24

MSD6308RTMN

7. ESQUEMAS ELÉTRICOS

7.17 PCI PRINCIPAL - PROCESSADOR PRINCIPAL

U001

AV/YPBPR_L_IN
AV/YPBPR_R_IN

AVOUT1_L_OUT

AVOUT1_R_OUT

HP_L
HP_R

AUVAG

AUVRM

I2S_BCLK
I2S_MCLK

I2S_LRCK

I2S_DATA

DIM_DC

IR_IN

MCU_RESET

XTALI
XTALO

GND

U5

LINE_IN_1L

V5

LINE_IN_1R

T5

LINE_IN_2L

T4

LINE_IN_2R

V4

LINE_IN_3L

U4

LINE_IN_3R

V2

LINE_OUT_0L

V1

LINE_OUT_0R

W4

EARPHONEOUTL

Y5

EARPHONEOUTR

V3

VAG

U2

VRM

A3

I2S_OUT_BCK

B3

I2S_OUT_MCK

C3

I2S_OUT_WS

A2

I2S_OUT_SD

E4

I2S_IN_WS/T2_RESET

F5

I2S_IN_BCK/T2_I2CS_SCL

E5

I2S_IN_SD/T2_I2CS_SDA

P9

SPI1_DI

R8

SPI1_CK

R9

SPI2_DI

R10

SPI2_CK

F6

IRIN

D3

RESET

AA2

XTALIN

AA3

XTALOUT

F9

TESTPIN

Analog audio

I2S

demod

HDMI

SPDIF

MHL

A_RX0N

A_RX0P

A_RX1N

A_RX1P

A_RX2N

A_RX2P
A_RXCN
A_RXCP

DDCDA_CK
DDCDA_DA
HOTPLUGA

C_RX0N
C_RX0P
C_RX1N
C_RX1P
C_RX2N
C_RX2P

C_RXCN

C_RXCP

DDCDC_CK
DDCDC_DA
HOTPLUGC

D_RX0N
D_RX0P
D_RX1N
D_RX1P
D_RX2N
D_RX2P

D_RXCN

D_RXCP

DDCDD_CK
DDCDD_DA
HOTPLUGD

PAD_ARC0

SPDIF_IN

SPDIF_OUT

MHL_CABLE_DETMCP_TEST

MHL_VBUS_EN

CEC

H2
J3
J2
J1
K3
K1
G2
H3
H6
H5
G4

W7
Y8
W8
Y9
AA9
W9
AA7
Y7
W6
AA6
Y6

E2
F3
F2
F1
G3
G1
D2
E3
J4
L6
K6

J5
J6

E6
A4
AA10P8
W5

H1_RX0-

H1_RX0+

H1_RX1-

H1_RX1+

H1_RX2-

H1_RX2+

H1_RXC-

H1_RXC+
HDMI1_SCL
HDMI1_SDA

H1_HPD_OUT

H2_RX0-

H2_RX0+

H2_RX1-

H2_RX1+

H2_RX2-

H2_RX2+

H2_RXC-

H2_RXC+

HDMI2_SCL
HDMI2_SDA

H2_HPD_OUT

H3_RX0-

H3_RX0+

H3_RX1-

H3_RX1+

H3_RX2-

H3_RX2+

H3_RXC-

H3_RXC+

HDMI3_SCL
HDMI3_SDA

H3_HPD_OUT

H1_ARC_OUT

CEC

SPDIF_OUT

MHL_CABLE_DET

MHL_EN

C701

NC/

33P

close to SOC

GND

MSD6308RTMN

25

7. ESQUEMAS ELÉTRICOS

7.18 PCI PRINCIPAL - PROCESSADOR PRINCIPAL

U001

R714

4K7

SCL
SDA

3.3V

R715

4K7

R716

100R

R917

100R

AMP_RESET
MS_DIM_OUT

LG_DIM_OUT

KEY_IN
LED_OUT

HP_DET_IN

SPI_SDI

U0RX

U0TX

VID0

PANEL_ON

POWER_ON_OUT

BL_ON_OUT
PM_CONFIG0

STB_RST

PM_CONFIG1

T18

3D_EN/PCM_PWR_EN

T17

AMP_MUTE

U18

BRI_ADJ

K5

PWM_PM

F4

KEY0

D4

LED_R

G7

ARC_DET

G5

SAR3

D6

PM_SPI_CK

E7

PM_SPI_DI

D7

PM_SPI_DO

F7

PM_SPI_CZ1N

L5

UART0_RX

L4

UART0_TX

L15

M_I2C_SLC

K15

M_I2C_SDA

L16

UART_RX2

L17

UART_TX2

W3

VID0

E8

PANNEL_ON/OFF

D1

PWR_ON/OFF

D8

VBL_CTRL

U3

PMCONFIG0

D5

3D_LR_IN

G6

PMCONFIG1

PWM

SAR

SPI

GPIO_PM

LVDS

TCON

LVA0N
LVA0P
LVA1N
LVA1P
LVA2N

LVA2P
LVACKN
LVACKP

LVA3N

LVA3P

LVA4N

LVA4P

LVB0N

LVB0P

LVB1N

LVB1P

LVB2N

LVB2P
LVBCKN
LVBCKP

LVB3N

LVB3P

LVB4N

LVB4P

LDE
LCK

LVSYNC

LHSYNC

TCON0
TCON1
TCON2
TCON3
TCON4
TCON5
TCON6
TCON7

N19
N21
N20
P19
P20
R19
R20
R21
T19
T21
T20
U19

H20
J19
J20
J21
K19
K21
K20
L19
L20
M19
M20
M21

G20
H19
G21
G19

J16
J17
J15
K17
J18
K18
K16
L18

TXE0-

TXE0+

TXE1-

TXE1+

TXE2­TXE2+
TXEC­TXEC+

TXE3-

TXE3+

TXE4­TXE4+

TXO0-

TXO0+

TXO1-

TXO1+

TXO2-

TXO2+

TXOC-

TXOC+

TXO3­TXO3+

TXO4­TXO4+

3.3VSB

4K7

R704

NC/

R705

NC/

R706

R707 4K7

PM_CONFIG0

4K7

4K7

SPI_SDI

MSD6308RTMN

26

GND

R708

R709

R712

R713

4K7

NC/

4K7

NC/

4K7

4K7

PM_CONFIG1

LG_DIM_OUT

7. ESQUEMAS ELÉTRICOS

7.19 PCI PRINCIPAL - PROCESSADOR PRINCIPAL

3.3VSB

AVDD_AU

J7K7L7

R6

3.3V

AVDD_DMPLL

R5

R15

R16

R17

R18

GND

AVDD5V_MHL

H7

V6

H11

H12

H13

H14

H15

H16

H17

H18J8J9

J10

J11

J12

J13

J14

K8

K10

K9L8L9

L10M7M8M9M10N4N5N6N7N8N9

N10P4P5P6P7

P10

P15

P16

P17

P18

R4

R7

R11

R12

R13

R14

GND

T6T7U6

U001

AVDD_NODIE

VDDC1

VDDC7

VDDC

L11

N12

N13

M11

VDDP

AVDD_AU33

AVDD3P3_DMPLL

AVDD_DVI_USB_MPLL

AVDD_DVI_USB_MPLL1

VDDC2

VDDC3

VDDC4

VDDC5

VDDC6

AVDDL_MOD

DVDD_RX_1

P12

P13

N14

N15

P14

M12A7M14B7M13

AVDD_PLL

AVDD_MOD

AVDD_MOD1

DVDD_RX_1_1

DVDD_RX_2

DVDD_RX_2_1

DVDD_DDR

DVDD_DDR1

C7

GND_EFUSE

AVDD5V_MHL

DVDD_NODIE

MCP_VDDC

MCP_VDDC1

F8

P11

N11

GND70

GND71

GND72

AVDD_DDR0_D

AVDD_DDR0_D1

AVDD_DDR0_D2

AVDD_DDR0_CMD

C5

L12

K12

K11C6K14

GND60

GND61

GND73

GND74

AVDD_DDR1_D

AVDD_DDR1_D1

L14

GND62

GND75

AVDD_DDR1_D2

AVDD_DDR1_CMD

AVDD_DDR1_CLK

L13

K13

GND63

GND64

GND65

GND66

AVDD_DRAM

AVDD_DRAM1

B5

B6

GND67

GND68

GND69

GND78

GND33

GND79

GND9

A6

A13

GND34

GND80

GND

GND1

A15

A18

GND35

GND2

GND3

B12

GND36

GND4

B14

B16

GND37

GND38

GND5

GND6

B17

B19

GND39

GND40

GND7

GND8

C9

B20

GND41

GND42

GND10

GND11

C10

C21

GND43

GND44

GND12

GND13

D9

E20

GND45

GND46

GND14

GND76

F11

F13

GND47

GND48

GND15

GND16

F15

F17

GND49

GND50

GND51

GND17

GND18

GND19

F19

F21

GND52

GND77

G9

G8

GND53

GND54

GND20

GND21

G10

G11

GND81

GND22

GND23

G12

G13

GND55

GND56

GND24

GND25

G14

G15

GND57

GND58

GND26

GND27

G16

G17

GND59

GND28

GND29

G18

GND82

GND83

GND30

H8

H9

GND84

GND31

GND32

H10

MSD6308RTMN

VCCK

+1.15V_VDDC_RX

C708

GND

1U

GND

1.5V

27

7. ESQUEMAS ELÉTRICOS

7.20 PCI PRINCIPAL - SAÍDA FONES

MAIN_POWER

C912

0.1U

C905

1U

GND

C906

1U

C903

1U

C904

1U

0.01UC951

C935

0.01U

INCONNECTED=H
CONNECTED=L

HP_DET_IN

R934

1K

R933

10K

3.3V

HP_L

HP_R

H_DET

T

Close to soc

L901

10UH

L902

10UH

R920
200R

C917

10U

GND

R921

200R

C918
10U

C981

C982

22U

22U

FH1

GND

HP_L

HP_R

FH2

T

5

4

L

GND

3

R

2

T

GND

T

CVBS

1

GND9

P900

GND

C945

0.1U

headphone out

28

7. ESQUEMAS ELÉTRICOS

7.21 PCI PRINCIPAL - AMPLIFICADOR DE ÁUDIO

Power AMP TAS5707

I2S_MCLK
I2S_LRCK
I2S_BCLK

I2S_DATA

R02A
R03A 33R
R04A
R05A
R06A

close to soc

NC/

33R
33R
33R

33R

SDA
SCL

NC/

GND

C01A 33P

C02A 33P

NC/

GND

NC/

33PC03A

AGND

C05A 4U7
C06A

R09A
R10A 100R

C04A

NC/

33P

C11A

C12A 4700P

NC/

3V3A

R07A

18K2

0.1U

100R

33PC07A

GND

AMP_RESET

0.047UC09A

4700PC10A

0.047U

R08A

10K

C08A 33P

3.3V

3.3V

GND

GND

R11A

10K

47K

R15A

C17A

0.47U

13
14
15
16
17
18
19
20
21
22
23
24

GND

R12A

470R

R13A

470R

AVDD
FAULT
MCLK
OSC_RES
DVSSO
VR_DIG
PDN
LRCLK
SCLK
SDIN
SDA
SCL

R01A

100R

C13A

C14A

1U

2200P

GND
R14A

22K1

11

10

987654321

12

PLL_FLTP

PLL_FLTM

AVSSNCOC_ADJ

VR_ANA

U01A

TAS5707

AGND

GND

DVSS

DVDD

STEST

RESET

29

28

27

26

25

GND

3.3V

GND

C15A

0.033U

MAIN_POWER

SSTIMER

GVDD_OUT1

BST_A

PVDD_A2

PVDD_A1

PVDD_D2

PVDD_D1

BST_D

GVDD_OUT2

VREG

35

34

33

32

31

30

C18A 0.1U

C19A 1U

MAIN_POWER

C20A

0.033U

OUT_A

PGND_AB2
PGND_AB1

OUT_B
PVDD_B2
PVDD_B1

BST_B

BST_C
PVDD_C2
PVDD_C1

OUT_C

PGND_CD2
PGND_CD1

OUT_D

36

C21A

0.47U

C16A

0.47U

48
47
46
45
44
43
42
41
40
39
38
37

GND

GND

GND

C22A

0.47U

MAIN_POWER

MAIN_POWER

C23A

0.47U

GND

C24A

0.033U

C25A

0.033U

OUT_A

OUT_B

OUT_C

OUT_D

R16A

10R

C26A

330P

R19A
10R

C27A

330P

L01A

22UH

L02A

22UH

L03A

22UH

L04A

22UH

GND

GND

3.3V

C28A

0.1U

C29A

0.1U

C30A

0.1U

C31A

0.1U

C32A

0.47U

C33A

0.47U

C34A

0.01U

C35A

0.01U

C36A

0.01U

C37A

0.01U

L05A

120R

AGND

C41A
10U

R17A

3R3

R18A

3R3

R20A

3R3

R21A

3R3

C42A

0.1U

GND

GND

R22A

0R

3V3A

GND

3.3V

T T

L-L+

R+ R-

TT

L+

1

L-

2

WHITE

P902

R+

1

R-

2

RED

P901

29

GND

C43A

10U

C44A

0.1U

7. ESQUEMAS ELÉTRICOS

7.22 PCI PRINCIPAL - CONEXÕES PROCESSADOR E MEMÓRIA SDRAM

GND

45

RN302

B-DDR3-DQL2

B-DDR3-DQL0

2

3

22R

6

7

B_DDR3_DQL0

B_DDR3_DQL2

1

RD312

8

B-DDR3-DML

45

22R

RN322

B_DDR3_DML

B-DDR3-MCLK

B-DDR3-MCLKZ

3

1

2

22R

6

7

8

B_DDR3_MCLK

B_DDR3_MCLKZ

B-DDR3-RESET

22R

RD305

B_DDR3_RESET

PART_TYPE=RE-0402

OUTLINE=0402

B-DDR3-DQU6

1

RD304

8

B_DDR3_DQU5

B-DDR3-DQU5

22R

RN306

B-DDR3-DQL4

1

8

45

RN304

B-DDR3-DQL6

2

3

22R

6

7

B_DDR3_DQL6

B_DDR3_DQL4

B-DDR3-DQU1

B-DDR3-DQU7

2

3

45

22R

6

7

B_DDR3_DQU7

B_DDR3_DQU1

B-DDR3-DQU0

B-DDR3-DMU

B-DDR3-DQU3

3

1

45

RN308

8

6

B_DDR3_DQU3

1

2

22R

7

8

B_DDR3_DMU

RN310

B-DDR3-DQSLB_DDR3_DQSL

B-DDR3-DQSLB

2

3

45

22R

6

7

B_DDR3_DQSLB

1

8

45

RN312

B_DDR3_DQSUB

B-DDR3-DQSUB

B-DDR3-DQSU

1

2

3

22R

6

7

8

B_DDR3_DQSU

RN314

B-DDR3-DQU4

2

3

45

22R

6

7

B_DDR3_DQU0

B_DDR3_DQU4

1

8

45

RN316

B-DDR3-DQU2

1

2

3

22R

6

7

8

B_DDR3_DQU2

B_DDR3_DQU6

RN318

B-DDR3-DQL7

B-DDR3-DQL5

2

3

45

22R

6

7

B_DDR3_DQL5

B_DDR3_DQL7

B-DDR3-DQL3

1

RN320

8

B-DDR3-DQL1

2

3

45

22R

6

7

B_DDR3_DQL1

B_DDR3_DQL3

GND

45

RN301

B-DDR3-A12

B-DDR3-BA1

2

3

22R

6

7

B_DDR3_A12

B_DDR3_BA1

B-DDR3-WEZ

B-DDR3-A4

B-DDR3-A10

B-DDR3-CKE

1

2

3

RN303

45

22R

6

B_DDR3_A10

B_DDR3_CKE

7

8

1

8

45

RN305

B-DDR3-A6

2

3

22R

6

7

B_DDR3_A6

B_DDR3_A4

B-DDR3-A8

B-DDR3-A11

3

1

45

RN307

8

6

B_DDR3_A11

1

2

22R

7

8

B_DDR3_A8

RN309

B-DDR3-ODT

B-DDR3-RASZ

3

45

22R

6

B_DDR3_ODT

B_DDR3_RASZ

B-DDR3-A1

1

2

RN311

7

8

3

45

6

B_DDR3_A1

B-DDR3-A14

1

2

22R

7

8

B_DDR3_A14

45

RN313

B-DDR3-A9

B-DDR3-A13

2

3

22R

6

7

B_DDR3_A13

B_DDR3_A9

1

RN315

8

B-DDR3-CS0

3

45

22R

6

B_DDR3_WEZ

B_DDR3_CS0

B-DDR3-A7

1

2

7

8

45

RN317

B-DDR3-A5

2

3

22R

6

7

B_DDR3_A5

B_DDR3_A7

1

8

45

RN319

B-DDR3-A2

B-DDR3-A0

2

3

22R

6

7

B_DDR3_A0

B_DDR3_A2

1

RN321

8

B-DDR3-BA0

B-DDR3-CASZ

2

3

45

22R

6

7

B_DDR3_BA0

B_DDR3_CASZ

B-DDR3-BA2

1

RN323

8

B-DDR3-A3

3

45

22R

6

B_DDR3_BA2

B_DDR3_A3

1

2

7

8

30

7. ESQUEMAS ELÉTRICOS

7.23 PCI PRINCIPAL - PROCESSADOR PRINCIPAL

240R

RD301

GND

E9

ZQ

MIU0

U001

MIU1

B_A[0]
B_A[1]
B_A[2]
B_A[3]
B_A[4]
B_A[5]
B_A[6]
B_A[7]
B_A[8]

B_A[9]
B_A[10]
B_A[11]
B_A[12]
B_A[13]
B_A[14]

B_DQL[0]
B_DQL[1]
B_DQL[2]
B_DQL[3]
B_DQL[4]
B_DQL[5]
B_DQL[6]

B_DQL[7]
B_DQU[0]
B_DQU[1]
B_DQU[2]
B_DQU[3]
B_DQU[4]
B_DQU[5]
B_DQU[6]
B_DQU[7]

B_CASZ
B_RASZ

B_WEZ

B_DQML

B_DQMU

B_ODT
B_BA[0]
B_BA[1]
B_BA[2]

B_RST

B_CKE

B_MCLK

B_MCLKZ

B_DQSL

B_DQSLB

B_DQSU

B_DQSUB

B_CS0

B_DDR3_A0

E11

B_DDR3_A1

F12
D10

B_DDR3_A2
B_DDR3_A3

B10

B_DDR3_A4

E15

B_DDR3_A5

B11
F14

B_DDR3_A6
B_DDR3_A7

C11

B_DDR3_A8

D14

B_DDR3_A9

A12
F16

B_DDR3_A10
B_DDR3_A11

D13

B_DDR3_A12

D15

B_DDR3_A13

C12
E13

B_DDR3_A14

B_DDR3_DQL0

A20

B_DDR3_DQL1

A16

B_DDR3_DQL2

C19

B_DDR3_DQL3

C15
C20

B_DDR3_DQL4

C14

B_DDR3_DQL5
B_DDR3_DQL6

B21

B_DDR3_DQL7

B15
F18

B_DDR3_DQU0
B_DDR3_DQU1

D19
D17

B_DDR3_DQU2
B_DDR3_DQU3

E21

B_DDR3_DQU4

E19

B_DDR3_DQU5

D20

B_DDR3_DQU6

D18
F20

B_DDR3_DQU7

B_DDR3_CASZ

B9

B_DDR3_RASZ

C8

B_DDR3_WEZ

D11

B_DDR3_DML

C16

B_DDR3_DMU

D21

B_DDR3_ODT

B8

B_DDR3_BA0

A9

B_DDR3_BA1

D16

B_DDR3_BA2

A10
F10

B_DDR3_RESET

E17

B_DDR3_CKE
B_DDR3_MCLK

C13

B_DDR3_MCLKZ

B13

B_DDR3_DQSL

A19
C18

B_DDR3_DQSLB
B_DDR3_DQSU

B18

B_DDR3_DQSUB

C17

B_DDR3_CS0

D12

MSD6308RTMN

31

7. ESQUEMAS ELÉTRICOS

7.24 PCI PRINCIPAL - MEMÓRIA SDRAM

B-DDR3-A0
B-DDR3-A1
B-DDR3-A2
B-DDR3-A3
B-DDR3-A4
B-DDR3-A5
B-DDR3-A6
B-DDR3-A7
B-DDR3-A8
B-DDR3-A9
B-DDR3-A10

B-DDR3-A11
B-DDR3-A12

B-DDR3-BA0
B-DDR3-BA1

B-DDR3-BA2

B-DDR3-CS0
B-DDR3-RASZ
B-DDR3-CASZ
B-DDR3-WEZ
B-DDR3-ODT

B-MVREFCA

B-DDR3-A13

B-DDR3-A14

N3
P7
P3
N2
P8
P2
R8
R2

T8

R3

L7
R7
N7

N8

M3

L2

J3

K3

L3
K1

M8

J1

J9
L1
L9

M7

T3
T7

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12

BA1
BA2

/CS
/RAS
/CAS
/WE
ODT

VREFCA

NC1
NC2
NC3
NC4
NC5
NC6
NC7

R9

VDD8

R1

VDD7

N9

VDD6

N1

VDD5

K8

VDD4

K2

VDD3

G7

VDD2

D9

1.5V

B2

VDD

VDD1

UM01

NT5CB64M16

H2

H9

VDDQ7

VDDQ8

E9

F1

VDDQ5

VDDQ6

C9

D2

VDDQ4

A1

C1

VDDQ

VDDQ2

VDDQ3

A8

VDDQ1

DMU

DQSU

/DQSU

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

DMLBA0

DQSL

/DQSL

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

VREFDQ

/CK

CKE

/RESET

CK

B-DDR3-DMU

D3
C7

B-DDR3-DQSU

B7

B-DDR3-DQSUB

B-DDR3-DQU0

D7

B-DDR3-DQU1

C3
C8

B-DDR3-DQU2

C2

B-DDR3-DQU3
B-DDR3-DQU4

A7
A2

B-DDR3-DQU5
B-DDR3-DQU6

B8

B-DDR3-DQU7

A3

E7M2

B-DDR3-DML

B-DDR3-DQSL

F3
G3

B-DDR3-DQSLB

B-DDR3-DQL0

E3
F7

B-DDR3-DQL1

F2

B-DDR3-DQL2

F8

B-DDR3-DQL3
B-DDR3-DQL4

H3
H8

B-DDR3-DQL5

G2

B-DDR3-DQL6

H7

B-DDR3-DQL7

B-MVREFDQ

H1

B-DDR3-MCLK

J7
K7

B-DDR3-MCLKZ

K9

B-DDR3-CKE
B-DDR3-RESET

T2

L8

ZQ

VSS10

T1

T9

RD311
240R

VSS8

VSS9

P9

VSS7

P1

VSS6

M9

VSS5

M1

VSS4

J8

VSS3

J2

VSS2

E1

G8

GND

VSS

VSS1

A9

VSS11

B3

G9

VSSQ7

VSSQ8

F9

G1

32

VSSQ5

VSSQ6

E2

E8

VSSQ2

VSSQ3

VSSQ4

D1

D8

VSSQ

B9

VSSQ1

B1

56R

RD309

0.01U

CD319

GND

56R

RD310

7. ESQUEMAS ELÉTRICOS

7.25 PCI PRINCIPAL - FILTROS FONTE

1.5V

2U2

CD301

0.1U

CD302

0.1U

CD303

Close to DDR POWER PIN

0.1U

CD304

0.1U

CD305

0.1U

CD306

0.1U

CD307

0.1U

GND

CD308

1.5V

RD303

1K

2U2

1K

CD320

RD307

0.1U

CD309

0.1U

B-MVREFCA

CD315

1000P

CD310

0.1U

CD316

0.1U

CD311

CD312

0.1U

NC/

0.1U

CD313

GND

1.5V

0.1U

CD314

RD306

1K

1K

RD308

CD317

0.1U

B-MVREFDQ

1000P

CD318

GND

GND

33

7. ESQUEMAS ELÉTRICOS

7.26 PCI TECLADO

3.3V_STB

3V3_STB

T

R1

470R

MENU

T

SOURCE

T

VOL+

TT

VOL-

CH+

T

CH-

T

POWER

T

R2

470R

R3

470R

VOL+

(1.67V)

R4

470R

VOL-

(1.26V)

R5

470R

CH+

(0.85V)

R6

470R

CH-

(0.44V)

R7

470R

POWER

(0.00V)

K3

1
2 4

F9

K4

1
2

F10

K5

1
2

F11

K6

1
2

F12

K7

1
2

F13

Z9Z10

CH+

CH-

VOL+

Z3

T

3

Z4

T

3
4

Z5

T

3
4

Z6

T

3
4

Z7

T

3
4

R11

R51

KEY

F14

GND

VOL-

F1

F2

F3

F4

GND

KEY

3.3V_STB

GND

T T T

Z8

P1

4

3

2

1

GND

34

7. ESQUEMAS ELÉTRICOS

7.27 PCI SENSOR

R1

100R

R2

100R

C1

1U/16V

C3

0.1U/50V

IR

VCC

GND

AT138B

IR1

C2

100P/50V

P2

KEY

3V3

P1

3

2

KEY

1

+3.3V_STB

5

4

3

LED

GND

2

IR_IN

1

+3.3V_STB

R4

1K5

R5

27R

E

BT3906

Q2

C

B

D1

C4

1U/16V

R6
0R

35

7. ESQUEMAS ELÉTRICOS

7.28 PCI WI FI 1

ANTENNA

LV6

2.2nH

1 2

GND

R11

1 2

0

XTAL_XO

GND

1 2

PMU_OU T

35

GND

1.2VD

34

ADC_VX_LDO

GND

C32

0.1uF

1 2

12

R8

24K

GND

3.3VD

GND

3.3VD

R3

GND

GND

C33

0.5pF

R1

1

0

C38

2

10pF

GND

12

C36

1.0pF

LV5

1 2

1nH

RFOUT_G0

12

C27

1.0pF

GND

2

LV3

2.7nH

C20

12

1.2pF

1

LV4

2.7nH

PA0_OUT+

1 2

PA0_OUT-

12

C21

1.2pF

GND

C17

2

10pF

C19

10pF

GND

1

RF0_PA_OU TP

12

RF0_PA_OU TN

GND

C26

2

1uF

C18

1.0pF

1 2

C1

1

2

0.1uF

0R

1

RF0_PA_OUTP

RF0_PA_OUTN

3.3VD

C25

3.3VD

12

1uF

IC1

1

RF0_VX_LDO

2

RF0_I N

3

RF0_PA2_V33A

4

RF0_OU TP

5

RF0_OU TN

6

RF0_PA1_V33A

7

VCCI O

8

EE_MISO

9

EE_MOSI

10

EE_CLK

40

41

GND

39

BG_EXTR

PLL_VX_LDO

GND

1 2

XTAL_V12A

38

C30

0.1uF

C31
1uF

XI

XO

36

37

XTAL_XI

XTAL_V12A

MT7601-QF N40-5X5

GND

C29

0.1uF

3.3VD

33

12

C28

0.1uF

C24

12

31

WL_GPIO0

WL_GPIO1

WL_GPIO2

WL_GPIO3

WL_GPIO4

WL_GPIO5

WL_GPIO6

LDO_RST_N

DCDC_V33D

0.1uF

PHASE

COMP

GND

30

29

28

27

26

25

24

RST_N

23

22

3.3VD

21

3.3VD

12

C12

0.1uF

3.3VD

12

12

GND

R7
150K

C16

0.1uF

RST_N

1.2VD3.3VD

32

VDD

VCCI O

12

AVDD12

3.3VD
12

GND

C14

0.1uF

1.2VD

3.3VD

12

GND

C5

1uF

EEFL_CS11VDD12PADP13PADM14VDDA15VRES16VOUT_1P217LDO_V15A18DCD C_V33A19FB

3.3VD

VRES

UDP

UDM

12

GND

C10

0.1uF

12

1.2VD

12

GND

R5

8.2K

PMU_OUT

C6

2.2uF

12

GND

GND

20

C8

1uF

3.3VD

12

C7

0.1uF

GND

GND

36

7. ESQUEMAS ELÉTRICOS

7.29 PCI WI FI 2

C11

1uF

5VD

GND

3.3VD

GND

Q1

4

VIN

LX/SW

5

FB

G5728

C43

2

1

FB

100pF

82K

GND

R3

18K

R4

GND

GND

EN

3
2
1

5VD

C4

0.1uF

GND

LV1 4.7uH

1 2

Power-EN

GND

GND

3.3VD

GND

GND

C3

10uF

XI

XO

XTAL/40MHz

2

R9 0 ohm

U5

3

2.5x3.2

4

1

XO_0

GND

2

C34

1

2

1

GND

GND

47pF

Y1

5
4
3
2
1

Power-EN

5VD

12

GND

C13

1uF

1 2

GND

R1
100K

1

R2
150K

2

5VD

GND

C41

5.6pF

GND

5VD

U+

U-

LV8

LV7

18nH

2

1 2

18nH

1

1 2

1 2

GND

UDP

UDM

C42

5.6pF

37

7. ESQUEMAS ELÉTRICOS

7.30 PCI FONTE SMPS

RT101

CY101

CX1 02

R131

BD1 02

C101

FB

HV1

CX103

R132

CY102

IS1

R133

BD1 03BD101

BD1 04

D110D111

C118

P DIR

C130

LF 101

R101

R126

L101

R102

C119

D102

2

K

A

1

ZD101

C120

PFC VCC

R127

C122

Q101

R103

C121

E

1

2

3

R128

D101

U101

FB

CMP

RT

RTZC4IS

Q104

E

B

D112

C102

B

VCC

OUT

GND

C

R141

U106

C135

C113

A0092

T101

8

D109

C114+C116

+48V

2A

7

Q102

Q103

R142A

IS2

T101A

4

C136

R142

+

6

9,10

9,10

D108

11

U102A

C

D

+

C137

R143

12

+12VA

3

+

+

R157

C140

C115

R158

R159

1

D

S

G

Q109

C154

C117

+12V

2

12V 3A

C143

A

12

R145

D113

K

A

A

K

1

1

2

T101B

L102

+3.3V

C145

R152

C142

PH

GND

3

C149

C148

R151

2

C139

C138

R144

32

U105

A

+

Q1 10

R112

R146

R114

C144

R135

R113

PWON

A

K

D115

A

K

R160

R161

C155

C155A

D106

A

K

K

A

C105

8

R104

7

6

C104

C106

D103

P DIR

C128

5

R129

R130

IS1

LLC VCC

C123

U103B

C127

C

4

3

C108

PFC VCC

C129

R105

FB

R106

R107

U102B

C124

HV

C109

4

3

C107

R134

C110

STB

R136

PFC VCC

R137

R108

R110

R111

R109

D103A

C131

R115

R117

R118

C111

STB

R117 A

R118 A

Q105

C125

R138

HV1

C103

R166

R117 D

R117 B

R117 C

R118 C

R118 B

C132

12

R117 F

R117 I

R117 H

R118 J

R118 D

R118 I

R118 H

U104

1

VH

3

BO

4

FB

5

CS

6

STB

7

MODE

GND

R167

R165

R163

R162

R164

VB

HO

VS

LO

VW

VCC

D107

R168

R123

LLC VCC

R169

16

R121

D104

C112

R119

R124

15

14

R122

D105

11

R120

R125

9

R116

10

C134

R140

LLC VCC

IS

8

C126

IS2

C133

R139

BD105

4

VIN

R149

1

EN

R147

5

VSENSE

CY1 03

R170

+12VA

C141

2

1

+

C146

C147

RX101 RX103

RX102 RX104

F10 1

CY105

AC L

CX101

2

CN103

LF 103

RV1 01

1

CY104

AC N

LF 102

+12VA

R148

12

R150

PWON

U103A

R153

C150

Q1 06

R155

C153

Q107

C151

+12VA

2

ZD102

K

A

1

Q108

R156

D114

1

R154

2

C152

+12V

3DEN

+3.3V

ADIM

PWON

PDIM

BLON

CN102

1
2
3
4
5
6
7
8
9
10
11
12
13
14

38

7. ESQUEMAS ELÉTRICOS

7.31 PCI FONTE DO BACKLIGHT

BLON

PDIM

+48V

R202

R203

R220

R221

C201

ENA

C204

C213

VREFA

+12VA

R222

10 PWM

R224

C205

L201

D201

R227

R226

C208

11 IC BOST

R230

C206

ISEN2

R231

ISEN3

R243

ISEN4

R232

R228

CMP

R201

10

11

12

13

R236

14

15

16

D202

BL201

2

DS

1

R212

G

Q201

D203

R219R218

C203

C202

R213

R206

R207

R208

R209

R210

R211

ZD201

R235

9

VIN

LPF

SSTCMP

PWM

ISEN1

ISEN2

GND

ISEN3

VREF

LDR

ISW

ENA

RT

OVP

ISET

ISEN4

U201

VREFA

8

7

6

5

4

3

2

1

C209

ENA

R233

ISETA

ISEN1

R238

R240

C212

R204

R205

C214

ISEN4

ISEN3
ISEN2

ISEN1

C216

1
2

R254

3
4
5
6

CN 201

R231

7
8
9
10

R215

R217

R216

C217

R214

C215

C218

ADIM

R252

R253

C226

ADIM

（

F: 20KHZ,DUTY；50%-100%

VREFA

R244

Q202

R245

C227

C222

R246

ILED,75mA-150mA

，

ISETA

C221

VREFB

R223

R225

C207

+12VA

ISEN4

ISEN3

R229

C210

CMP

R237

9

U202

VIN

10

LPF

11

SSTCMP

12

PWM

13

ISEN1

14

ISEN2

15

GND

16

ISEN3

VREF

LDR

ISW

ENA

RT

OVP

ISET

ISEN4

VREFB

8

7

6

5

4

3

2

ISETB

1

C211

R234

C220

R239

R241

R242

ENA

C219

ADIM

R247

R248

C223

VREFB

R249

Q203

R250

C224

C225

R251

ISETB

39

7. ESQUEMAS ELÉTRICOS

7.32 CONTROLE REMOTO

40

8. VISTA EXPLODIDA

8.1 L48S4700 & L55S4700

Item NE Descrição Modelo Posição

650098 L48S4700

1 AG163

2 650132 ambos PCIFT
3 649840 ALTO FAL 8OHM 10W ambos W660A

4 AG102

5 650276 ambos AG161A
6 649859 PE BORRA CHA ESQUERDO ambos
7 650258 ambos A G164D

8 AG171

9 652568 PCI SENS 48/55S4700 IMC
10 650285 BASE PEDESTAL XXS4700 DIR ambos AG162A
11 649868 PE BORRACHA DIREITO ambos

12

13

14 653139 PCI WIFI WF75RL1510C IMC
15 652540 PCI TEC 48S4700 SMD-TOP ambos PCITC1

16 AG170

17

18 652498 PCI PR 48/55S4700 IMC ambos PCIPR2
19 650089 PAINEL AV LATERAL ambos AG168

PAINEL 48" LVF480CSOT E31 V 2

650515 L55S4700

PAINEL 55" LVF550CSOT E6 V2
PCI FONTE 48/50S4700 MONT

652755 L48S4700

TAMPA TRAS DLED-48 CONJ

652791 L55S4700

TAMPA TRAS DLED-55 CONJ
BASE PEDESTAL XXS4700 ESQ

SUPORTE FIXACAO INF LATERAL

650052 LENTE SENSOR/LED L48S4700
650392 LENTE SENSOR L55S4700

650301 SUPORTE TECLAS L48S4700
650418 SUPORTE TECLAS L55S4700
650267 TECLA CONTROLES L48S4700
650409 TECLA CONTROLES L55S4700

650212 L48S4700

SUPORTE FIXACAO TECLAS/WIFI

650445 L55S4700

SUPORTE FIXACAO TECLAS/WIFI

650249 L48S4700

SUPORTE FIXACAO ALTO FALANTE

650436 L55S4700

SUPORTE FIXACAO ALTO FALANTE

ambos PCISR2

ambos PCIWIFI2

AG162BA

AG170BB

AG170BA

AG172D

41

Av. Arnaldo Rojek, Nº 1, Altos de Jordanesia - Cajamar - SP

CEP 07786-900

Tel.: PABX (0xx11) 3232-2200

Agosto/2016
