TCL Alto 5 User Manual

2.0 Channel Home Theater Sound Bar

Alto 5

User manual

Product Registration

Please register your purchase on-line at www.tclusa.com or www.tclcanada.com. It will make it easier to contact you should it ever be necessary. Registration is not required for warranty coverage.

Product Information

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. These numbers are located on the product.

Model No. ____________________________________________

Purchase Date ________________________________________

Serial No. ____________________________________________

Dealer/Address/Phone _________________________________

Contents

1 Important safety instructions 3

Important information 3 Important safety instructions 5

2 Welcome 10

What’s in the box 10 Overview of the Sound Bar main unit 12 Overview of the remote control 14 Set up your Sound Bar system 15

3 Connect your Sound Bar system 20

Connect with the supplied optical cable 20 Connect with the supplied 3.5mm-to-3.5mm audio cable 22 Connect your Sound Bar to power supply 23 Connect the Sound Bar with your Bluetooth device 24 Connect the IR pass-through cable 26

4 Use your Sound Bar system 27

Use your Sound Bar with the top panel or remote control 27 Sound settings 28 Control the Sound Bar with your TCL Roku TV remote control 29 Listen to music from your Bluetooth device 31 Use the USB cable or device for music playback 32

5 Specications 34

6 Notice 35

Compliance notice 35 Disposal of your old product and battery 38 Trademarks 39

7 FAQ 40

1 Important safety

instructions

Important information

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning ash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the

product’s enclosure that may be of sufcient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

This symbol indicates that this product incorporates double insulation between hazardous main voltage and user accessible parts. When servicing, use only identical replacement parts.

Warnings

•• To•reduce•the•risk•of•re•or•electric•shock,•do•not•

expose•this•product•to•rain•or•moisture.•This•product• should•not•be•exposed•to•dripping•or•splashing.•No• objects•lled•with•liquids,•such•as•vases,•should•be• placed•on•or•near•the•product.•

•• The•product•is•unstable•if•it•is•not•properly•placed•

or•mounted•to•the•wall.•Be•sure•to•follow•the•wall• mounting•instructions•provided•in•this•user•manual•to• ensure•your•safety.

•• Do•not•expose•batteries•to•excessive•heat•such•as•

sunshine,•re,•and•so•forth.•

Important safety instructions

• Read these instructions - Read all the safety and

operating instructions before operating the product.

• Retain these instructions - Retain the safety and

operating instructions for future reference.

• Heed all warnings - Adhere to all warnings on the

product and in the operating instructions.

• Follow all instructions - Follow all operating and use

instructions.

• Do not use this apparatus near water - The appliance

should not be used near water or moisture - for example, in a wet basement or near a swimming pool and the like

• Clean only with a dry cloth.

• Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including ampliers) that produce heat.

• Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where it exits from the product.

• Use only attachments/accessories specied by the

manufacturer.

• Use only with the cart, stand, tripod, bracket, or table

specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when

unused for long periods of time.

• Refer all servicing to qualied service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Cautions

• To prevent electric shock, match wide blade of plug to

wide slot, fully insert

• The product shall not be exposed to dripping or

splashing.

• Do not place any sources of danger on the product (for

example. liquid lled objects, lighted candles).

• Disconnect the power cord to shut off when nd trouble

or not in use. The power cord shall be readily operable.

• Use of controls or adjustments or performance of

procedures other than those described herein, may result in hazardous radiation exposure or other unsafe operation.

• To reduce the risk of re or electric shock, do not

expose this apparatus to rain or moisture. The apparatus must not be exposed to dripping or splashing and objects lled with liquids, such as vases, must not be placed on apparatus.

• The power cord/appliance coupler is used as the

disconnect device, the disconnect device must remain readily operable.

Battery caution and disposal information

• Install only new batteries of the same type in your product.

• Failure to insert batteries in the correct polarity, as

indicated in the battery compartment, may shorten the life of the batteries or cause batteries to leak.

• Do not mix old and new batteries.

• Do not use rechargeable (Nickel Cadmium) or (Nickel Metal

Hydride) batteries.

• Do not mix alkaline, standard (Carbon-Zinc) or rechargeable

(Nickel Cadmium) or (Nickel Metal Hydride) batteries.

• Do not dispose of batteries in re or water.

• Recycle or dispose of batteries as per state and local

guidelines.

• Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

• When the remote control is not to be used for a long time

(more than a month), remove the battery from the remote control to prevent it from leaking.

• If the batteries leak, wipe away the leakage inside the battery

compartment and replace the batteries with new ones.

• Keep away the batteries from heat or moisture.

• Do not carry or store batteries with other metallic objects.

Doing so could cause batteries to short circuit, leak or explode.

• Do not carry or store batteries with other metallic objects.

Doing so could cause batteries to short circuit, leak or explode.

• Never recharge a battery unless it is conrmed to be a

rechargeable type.

• The product/remote control contains a coin/button type

battery, which can be swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion.

• If you suspect that a battery has been swallowed or placed

inside any part of the body, seek immediate medical attention.

• When you change the batteries, always keep all new

and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery.

• If the battery compartment cannot be completely secured,

discontinue use of the product. Keep out of reach of children and contact the manufacturer.

Installation location

• This product is designed to sit on a rm, at surface. Do

not place the product on built-in installation such as a bookcase or rack because the ventilation slots around the product will be blocked, resulting in reduced lifetime from overheating. To assure adequate ventilation for this product, maintain a spacing of 7.8 inches (20cm) or more around the product.

• Make sure the product on the furniture is of adequate size

and strength to prevent it from being accidentally tipped over, pushed off, or pulled off. This could cause personal injury and/or damage to the product.

• Installation of wall mount must be carried out by

qualied personnel only. Incorrect assembly can result in severe personal injury and property damage (if you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing that may be buried inside the wall). It is the installer’s responsibility to verify that the wall will safely support the total load of the product and wall mount brackets.

2 Welcome

Congratulations on the purchase of your new TCL Sound Bar! After it is set up and connected, you can experience a superb sound quality and state-of-the-art design to best t your home entertainment system. You are recommended to read through this user manual which helps you set up, connect and operate the product easily and properly. For more information, visit www.tclusa.com or www.tclcanada. com

Let’s get started.

What’s in the box

Sound Bar main unit

Optical cable

AC power cord

3.5mm-to-3.5mm audio cable

User

manual

QSG

Warranty

IR pass-through cable

Wall mount template

Remote control (with battery)

Wall anchor x 4 Silicone pad x 2 Wall mount bracket x 2 Wall bracket screw (M4) x 4

Wall mounting screw (M3) x 2

User

manual

User manual

QSG

Quick start guide

Warranty

Warranty card

Overview of the Sound Bar main unit

1 2 3 4

OPTICAL

8 9 10 11 12

USB AUX

Press to turn the Sound Bar main unit on or to standby mode.

Press to switch the audio source among AUX/Bluetooth/Optical/USB modes.

Press to select the Bluetooth function.

4 +/-

Press to increase or decrease the volume level.

5 Remote control sensor

Receive signals from the remote control.

6 LED indicators

Red: in standby mode. Green: in AUX mode. Blue: in Bluetooth mode. Orange: in Optical mode. White: in USB mode.

7 Wall bracket screws

8 Optical input connector

9 USB Type A connector (only for music playback)

10 AUX input connector

11 IR pass-through cable connector

12 AC input power connector .

Overview of the remote control

Press to turn the Sound Bar on or to standby mode.

Press to mute or unmute the sound.

3 Source buttons - AUX/OPTICAL/USB/

Press to switch the audio source among different modes.

4 +/-

Press to increase or decrease the volume level.

5 /

Press to skip to previous/next track in Bluetooth/USB mode.

6 /PAIR

Play/pause/resume playback in Bluetooth/USB mode. Press and hold to activate the pairing function in Bluetooth mode or disconnect the paired Bluetooth device.

7 NEWS/MOVIE/MUSIC

Press to select the equalizer (EQ) effect when you are watching news or movies or listening to music.

Set up your Sound Bar system

Notes

• Make sure you read all the safety information before

you mount the Sound Bar main unit on the wall (see ‘Important safety instructions’ on page 5).

• Make sure you use screws and wall mount brackets

provided or specied by the authorized manufacturer.

• TCL Corporation bears no responsibility for accidents or

damage caused by improper wall mounting and screws installation or insufcient wall strength, etc.

• Additional tools (not supplied) are required for

installation.

Mount your Sound Bar main unit on the wall

You can choose to place your Sound Bar main unit below the center of your TV or mount it on the wall.

A B

Place the supplied wall mount template on the wall.

Make sure the wall mount template is at least 2 inches (5cm) below the center of the TV.

Use a level to make sure the Sound Bar is positioned

accurately.

Use the tape to stick the wall mount template rmly on

the wall.

Mark on the wall using each marking on the template on

the template through the mounting holes (Fig.1).

Take away the wall mount template.

Drill a screw hole at each marking on the wall.

Insert the supplied wall anchors into 4 screw holes on

the wall (Fig. 2).

Insert the supplied wall bracket screws into the wall

anchors. Leave 0.16 inch (4mm) between the screw heads and the wall (Fig. 2).

Fix and tighten the wall bracket screws on the wall.

735 mm / 28.94”

Stick the silicone pads on the wall mount brackets when necessary to adjust the direction of the Sound Bar main unit (Fig. 2).

Replace the screws at the back of the Sound Bar main

unit with the supplied wall mounting screws (Fig. 3 and

4).

Hang the Sound Bar main unit on the screws.

735 mm/28.94”

Fig. 1

Fig.1 Fig.3

Wall template

Fig. 3

Fig. 2

Fig.2

Fig. 4

Fig.4

Silicone pad

Remove the screws

Remove

the screws

Install the wall

mounting screws

Notes

• Check the installation location before you mount the

Sound Bar on the wall (see ‘Installation location’ on page 9).

• You may consider to connect the cables rst before

mounting the Sound Bar on the wall.

Activate the remote control

The battery is pre-installed in the remote control. For rst time use, remove the battery protective tab from the battery door to activate battery connection.

Replace the remote control battery

Warnings

•• Danger•of•explosion•if•battery•is•incorrectly•replaced.•

Replace•only•with•the•same•or•equivalent•type.•

•• The•product/remote•control•may•or•may•not•contain•a•

coin/button•type•battery,•which•can•be•swallowed.•Keep• the•battery•out•of•reach•of•children•at•all•times!•

Caution

• The battery contains perchlorate material, handle

it with care. For information, refer to www.dtsc. ca.gov/hazardous waste/perchlorate.

Open the battery compartment and remove the old

battery.

Place a new lithium CR2025 battery into the battery

compartment with the correct polarity (+/-).

Close the battery compartment.

3 Connect your Sound

Bar system

After you have xed the position of the Sound Bar main unit, you can start connecting it to your TV or other devices and listen to the audio through your Sound Bar. Make sure you have muted the audio of your TV or device. For information, check the user manual of your TV or device.

Connect with the supplied optical cable

Remove the protective caps from the optical cable.

Connect one end of the optical cable to the optical input

connector on your Sound Bar main unit and another end to the optical output connector of your TV or device.

Note

• If there is no sound output from the Sound Bar main unit

and the orange LED ashes rapidly, try to activate the PCM signal output on your TV or device. PCM is used to convert analog audio signals into digital audio signals in most devices. For more information of how to activate the PCM signal output, check the user manual of your TV or device.

Directions for setting up your Sound Bar using an optical cable

Do not bend or kink the optical cable (SPDIF) as it is fragile and can easily get damaged and broken.

To get the best possible audio experience using optical cable:

1. Press the Home button on your TCL TV Remote.

2. Navigate to Audio option under Settings.

3. Uncheck the “TV speaker enabled” option.

4. Under S/PDIF and ARC, select PCM-Stereo.

Notes

• Different•devices•may•have•different•menu•options.

• Devices•such•as•Blu-ray•players,•set-top•boxes,•etc.•are•

also•applicable.

Connect with the supplied 3.5mm-to-

Not supplied

3.5mm audio cable

You can either:

• connect one end of the supplied 3.5mm-to-3.5mm audio cable to the AUX input connector on your Sound Bar main unit and another end to the headphone or audio output connector on your TV or device. This will disable the sound of your TV built-in speakers; or

• connect one end of an RCA-to-3.5mm audio cable (not supplied) to the AUX input connector on your Sound Bar main unit and other ends to the TV’s audio output connectors.

Not supplied

Headphone

Connect your Sound Bar to power supply

Make sure that you have completed all other

connections before connecting the Sound Bar to power supply.

Make sure the power supply voltage complies with your

country’s safety standards (see ‘Specications’ on page 34).

Connect one end of a supplied AC power cord to the

AC input connector on your Sound Bar main unit and another end to the power socket on the wall.

Connect the Sound Bar with your Bluetooth device

Notes

• Make sure your wireless device supports the Bluetooth

function.

• The operational range between the Sound Bar main unit

and your Bluetooth device is approximately 10 meters (without any obstacle between the Bluetooth device and Sound Bar main unit).

Press on the top panel of your Sound Bar main unit or

remote control to power on the Sound Bar.

Press on the top panel of your Sound Bar main unit or

remote control.

 The blue LED ashes slowly. The Sound Bar is ready

to pair.

Power on your Bluetooth device and activate its

Bluetooth function.

Select TCL Alto 5 on the pairing list of your Bluetooth

device.

 You hear distinct double beep sounds.

 The blue LED remains on solidly when pairing is

successful.

Tip

• If you cannot nd the model name TCL Alto 5 on

your Bluetooth device, press and hold /PAIR on the remote control. You will see the blue LED ashes rapidly. Now the Sound Bar main unit is entering the pairing mode.

Your Sound Bar system is now set up and ready to use.

To disconnect the Bluetooth function, you can:

• press on the Sound Bar main unit or the source

buttons on the remote control to switch to another source; or

• disable the Bluetooth function on your device; or

• press and hold /PAIR on the remote control.

Connect the IR pass-through cable

If the Sound Bar blocks the IR receiver of the TV when placing directly in front of it, you can connect the Sound Bar and TV with the supplied IR pass-through cable so that it can receive signal from the remote control of your TV. Connect one end of the IR pass-through cable to the IR pass-through cable connector on your Sound Bar main unit. Then, place another end with the IR blaster close to the TV sensor. For information, check the user manual of your TV.

TV Sensor

Use your Sound Bar system

Use your Sound Bar with the top panel or remote control

Make sure the Sound Bar is properly connected to the

power supply and sources.

Press on the top panel of your Sound Bar main unit or

remote control to power on the Sound Bar.

Press on the top panel of your Sound Bar main unit

or the source buttons on the remote control to switch to the correct source.

LED behaviors under different source modes

LED indicators Sound Bar status

The red LED is on solidly. in standby mode

The green LED is on solidly. in AUX mode

The blue LED is on solidly. in Bluetooth mode

The blue LED ashes slowly. ready to pair

The blue LED ashes quickly. pairing in progress

The orange LED is on solidly. in optical mode

The white LED is on solidly. in USB mode

Tip

• You can use more advanced functions on the remote

control (see ‘Overview of the remote control’ on page

14).

Sound settings

You can enjoy your movies or music with your ideal sound.

• Press +/- to adjust the volume.

• Press on the remote control to mute the sound. Press

again to unmute the sound.

• Press the EQ buttons (NEWS/MOVIE/MUSIC) on the remote control to select the equalizer (EQ) effect when you are watching news or movies or listening to music.

Operation LED indicators

Adjust the volume. The white LED ashes quickly

and goes back to the source LED.

Mute the Sound Bar. The red LED keeps ashing.

Unmute the Sound Bar. The red LED ashes and goes

back to the source LED.

Maximum or minimum volume level is reached.

The red LED is on for 2 seconds and goes back to the source LED.

Select the equalizer (EQ) effect).

Movie: The white LED ashes once. Music: The green LED ashes once. News: The orange LED ashes once.

Control the Sound Bar with your TCL Roku TV remote control

Turn on the Sound Bar

When the sound bar is in standby mode, pressing the volume up (+) button of your TCL Roku TV remote control will turn on the Sound Bar.

Control the Sound Bar volume

When the sound bar is on, pressing the volume up or down button of your TCL Roku TV remote control will turn the Sound Bar volume up (+) or down (-).

Listen to music from your Bluetooth device

Make sure that your device supports A2DP and/or

AVRCP. For information, check the specication of your device.

Pair your Bluetooth device with the Sound Bar main

unit (see ‘Connect the Sound Bar with your Bluetooth device’ on page 24).

• Start listening to music stored in your Bluetooth

device through the Sound Bar. If your Bluetooth device supports A2DP, you can listen to music, but you cannot control the playback.

• If your Bluetooth device supports AVRCP, you can

listen to music and control music playback with the remote control. Press /PAIR to pause or resume music playback. Press / to skip to the previous/next track.

Note

• The operational range between the Sound Bar and your

Bluetooth device is approximately 10 meters (without any obstacle between the Bluetooth device and Sound Bar main unit).

Use the USB cable or device for music playback

Connect the USB device to the USB Type A connector

on your Sound Bar main unit.

Press on the Sound Bar main unit or USB on the

remote control.

 The white LED is on.

You can now listen to music through the Sound Bar.

• To pause or resume music, press /PAIR on the

remote control.

• To skip to the previous or next track, press or on

the remote control.

Operation LED indicators

Listen to music. The white LED is on.

Press to pause the

The white LED is on solidly.

music.

Press or to skip to the

The white LED is on solidly.

previous/next track

Tip

• This Sound Bar can support USB devices of up to 32GB

memory and the supported le formats are MP3, WAV, FLAC.

5 Specifications

Sound Bar main unit

• Power adapter: AC100-240V, 50/60Hz

• Power consumption: 25W

• Power consumption at standby mode: < 0.5W

• Impedance: 8 Ω

• Frequency response: 150 Hz-20 kHz

• Dimensions (W x H x D): 800 x 66 x 84 mm

• Weight: 1.5 kg

• Operating temperature: 0°C - 45°C

Bluetooth

• Bluetooth version: 4.2, Bluetooth prole - Bluetooth stereo supported (Advanced Audio Distribution Prole A2DP; Audio Video Remote Control Prole - AVRCP)

• Frequency range: 2402 Mhz – 2480 Mhz

• Max transmitting power: 5dBm

Remote control

• Distance/Angle: 6m/ 30°

• Battery type: Lithium CR2025 battery (160 mAh) x 1,

user replaceable.

6 Notice

Compliance notice

Notice for US

FCC Information

Warning

•• Changes•or•modications•to•this•unit•not•expressly•

approved•by•the•party•responsible•for•compliance•could• void•the•user’s•authority•to•operate•the•equipment.

Note

• This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio / TV technician for help.

To assure continued compliance, any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This set complies with the FCC rules, Part 15 and with 21 CFR 1040.10. Operation is subject to the following two conditions:

1 This device may not cause harmful interference, and

2 This device must accept any interference received,

including interference that may cause undesired operation.

FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm

between the radiator and your body.This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

WARNING: Changes or modications made to this equipment not expressly approved by TCL Corporation may void the FCC authorization to operate this equipment.

Caution

• The manufacturer is not responsible for any radio or TV

interference caused by unauthorized modications to this equipment. Such modications could void the user authority to operate the equipment.

Notice for Canada

Class B Clause This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications. This Class B digital apparatus complies with Canadian ICES-003 This device complies with Industry Canada licenceexempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAN ICES-3(B)/NMB-3(B)

IC Radiation Exposure Statement

This equipment complies with Canada radiation exposure limits set forth for uncontrolled environments. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Caution: The user is cautioned that changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Disposal of your old product and battery

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities. This product contains non-removable batteries:

• Do not incinerate. Batteries may explode if overheated.

• For disposal or recycling information, please contact

your local authorities.

Trademarks

Bluetooth

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by TCL Corporation under license. Other trademarks and trade names are those of their respective owners.

Dolby Audio

7 FAQ

No power

• Make sure the AC power cord and AC input connector are connected properly.

• Make sure there is power supply.

• Make sure the Sound Bar has turned on.

No sound

• Make sure the audio cable is connected to the Sound Bar and your device.

• Make sure you have selected the correct source.

• Press + to increase the volume level.

• Make sure the Sound Bar is not muted.

The remote control does not work.

• Make sure you have selected the correct source.

• Make sure the distance of remote control and the Sound Bar main unit is within operational range.

• Make sure the battery is correctly inserted and is working.

• Make sure the remote control is close to the remote control sensor of the Sound Bar main unit.

I hear distorted sound.

• Make sure all cables are properly connected.

• Make sure you have selected the correct source.

• Make sure the TV is muted if you play audio from the TV.

I cannot nd the Bluetooth name of this Sound Bar on my Bluetooth device.

• Make sure the Bluetooth function is activated on your Bluetooth device.

• Make sure the Sound Bar has paired with your Bluetooth device.

For further support, visit www.tclusa.com/support or www. tclcanada.com/support

DO NOT RETURN TO STORE

WE ARE

READY TO

HELP

with any questions

any questions

TAKE CARE WHEN

TAKE CARE WHEN REMOVING THE SOUNDBAR

REMOVING THE SOUNDBAR

TCL SUPPORT:

www.tclusa.com/support or

www.tcl.com/support or

www.tclcanada.com/support

1-877-300-9223

TCL Alto 5 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
