After unpacking TV, please read this section carefully to assemble the stand or
remove the base neck.
Assemble the Stand
Step 1: To prevent TV from being damaged or falling, place TV on a stable, level and
vibration-free surface with packaging materials or soft cloth.
Step 2: Slide the base plate to TV.
base plate
base neck
ii
Step 3: Line the holes on the plate up with the screw holes on TV base neck. Insert
and tighten supplied screws in clockwise with the offered screwdriver.
Remove the Base Neck
To mount your LCD TV, (1) do not assemble the base plate and (2) remove the neck
from the TV. Refer to the instructions in your wall-mounting kit (not included).
Step 1: To prevent TV from being damaged or falling, place TV on a stable, level and
vibration-free surface with packaging materials or soft cloth.
iii
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Step 2: Remove screws securing the stand to the base (shown in marked circles) in
anti-clockwise. Remove the base and put aside until re-assembly.
iv
Table of Contents
BEFORE GETTING STARTED .................................................................................. 1
O
PERATING SAFETY
................................................................................................... 1
C
ONNECTING
............................................................................................................ 2
Power supply....................................................................................................... 2
Point of use.......................................................................................................... 2
A
DDITIONAL SAFETY INSTRUCTIONS
............................................................................ 3
Precautions.......................................................................................................... 3
INTRODUCTION ........................................................................................................ 4
B
OX CONTENTS
......................................................................................................... 4
F
URTHER FEATURES
.................................................................................................. 5
O
VERVIEW OF THE
TV................................................................................................ 6
Indicator............................................................................................................... 6
Function Keys...................................................................................................... 7
Connections......................................................................................................... 8
O
VERVIEW OF THE REMOTE CONTROL
......................................................................... 9
SETTING UP .............................................................................................................11
CONNECTIONS ........................................................................................................11
Connecting video devices via AV cables.............................................................11
Connecting a video device via HDMI - HDMI..................................................... 13
Connecting a PC via VGA cable........................................................................ 14
W
ATCHING
TV......................................................................................................... 15
Turning the LCD Display On and Off................................................................. 15
Initial Power on.................................................................................................. 17
Source Buttons.................................................................................................. 18
Volume Control.................................................................................................. 19
Setting the Sleep Timer ..................................................................................... 19
ARC - Aspect Ratio Control............................................................................... 20
APC - Automatic Picture Control........................................................................ 20
NICAM/A2 (IGR) B
ROADCAST SELECTION
............................................................... 21
GENERAL CONTROLS & ADJUSTMENT .............................................................. 22
H
OW TO CONTROL ON-SCREEN DISPLAY
(OSD) ........................................................ 22
V
IEWING THE ON-SCREEN DISPLAY
(OSD)................................................................ 23
v
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
P
ICTURE SETTING
.................................................................................................... 24
S
OUND SETTING
...................................................................................................... 25
S
ERVICE IN ANALOGUE
TV ....................................................................................... 26
Service Management......................................................................................... 27
Rename/Sort/Delete .......................................................................................... 27
S
ERVICE IN DIGITAL TV
(DTV)
FOR
V26MMFJ-ET
A WITH
DVB-T
ONLY
...................... 28
Recording Settings ............................................................................................ 29
Service Scan ..................................................................................................... 30
Setup ................................................................................................................. 31
New Service Alert.............................................................................................. 32
Parental Control................................................................................................. 32
V
IEWING THE BANNER OF DIGITAL
TV........................................................................ 33
EPG (E
LECTRONIC PROGRAMME GUIDE) IN
DTV....................................................... 34
P
REFERENCES
........................................................................................................ 36
Child Lock.......................................................................................................... 37
On Timer............................................................................................................ 38
C
ONNECTIVITY: PC SETTING
.................................................................................... 39
I
NFORMATION
.......................................................................................................... 41
R
ESET
.................................................................................................................... 42
TELETEXT ............................................................................................................... 43
TELETEXT O
PERATION
.......................................................................................... 43
TELETEXT P
AGE SELECTION
.................................................................................. 44
U
SEFUL FEATURES FOR
TELETEXT ......................................................................... 44
TROUBLESHOOTING ............................................................................................. 47
SAFETY AND REGULATORY INFORMATION........................................................ 50
R
EPAIR
................................................................................................................... 50
N
OTES FOR SERVICE ENGINEERS
............................................................................. 50
E
NVIRONMENTAL CONDITIONS
................................................................................... 50
PC INPUT PRESET TIMING TABLE........................................................................ 51
SPECIFICATIONS.................................................................................................... 52
1
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Before Getting Started
Please read through this section carefully and follow the instructions to maximize
the reliable operation and lifetime of your LCD display. Always keep these
instructions handy and close by your LCD display. Keep the instructions and the
packaging so that if you sell or give away your LCD display you can give them to the
new owner.
Conventions used in this manual
WARNING
Information to prevent injury to yourself when trying to
complete a task.
CAUTION
Information to prevent damage to the components when
trying to complete a task.
Operating Safety
• Never open the housing of the LCD display/power supply! When the housing is
open, there is a danger of injury from electric shock!
• Do not insert any objects through the slots and openings of the monitor. This may lead
to an electrical short-circuit or even fire resulting in damage to your LCD display.
• Slots and openings in the LCD display are for ventilation purposes. Do not cover
these openings, as this may lead to overheating.
• Do not allow children to play unattended with electrical equipment. Children
may not always correctly recognize danger.
• This LCD display is intended for personal use only. It is not intended for
commercial use in a heavy industry environment.
• An injury hazard exists if the display breaks. Wear protective gloves to pack the
broken parts and send them to your service centre for proper disposal. Then wash
your hands with soap, because it is possible for chemicals to escape.
• Never exert pressure on the display. This could break the monitor.
• Do not touch the display with your fingers or with sharp objects to avoid damage.
• No naked flame sources, such as lighted candles, should be placed on the
apparatus.
2
Contact the Call Centre immediately in any of the following situations. Do NOT
plug in or switch on your display:
• If the power cable/power supply overheats or is damaged
• If liquid is leaked into the monitor
• If the LCD display is dropped or the housing damaged
Connecting
Observe the following instructions to connect your LCD display properly:
Power supply
• Do not open the power supply housing. An open housing presents
a lethal hazard from electrical shock. There are no parts inside to
be cleaned or serviced.
• Operate your LCD display only with grounded outlets with AC 100-240V/ 50-60 Hz. If
you are not sure about the power supply at your location, check with your power
company.
• Use only the power supply and power connection cable provided.
• For additional safety we recommend use of a surge protector to protect your LCD
display from damage resulting from voltage surges or lightning.
• To remove the LCD display from the power supply, disconnect the plug from the
AC outlet.
• Where the main plug is used as the disconnect device, the power outlet must be
in the vicinity of your LCD display and within reach of the power cables.
DO NOT
stretch the power cables tightly to reach a power outlet.
• You should arrange the LCD display cables in a manner so that no one can trip
over or step on them.
• To avoid damage to cable do not place any objects or furniture on the cable.
• Do not defeat the safety purpose of the polarized or grounding-type plug. If the
provided plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
Point of use
• Keep your LCD display and all units connected to it away from moisture and avoid
dust, heat and direct sunlight. Failure to observe these instructions can lead to
malfunctions or damage to the LCD display.
• Place and operate all units on a stable, level and vibration-free surface in order
to avoid the LCD display from falling.
3
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Additional Safety Instructions
When using any electronic equipment, basic safety precautions should always be
taken. Following the guidelines below can reduce the risk of fire, electric shock and
injury to person:
• Do not use this product including TV set and remote near water (e.g. near a
bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool).
• Use only the power cord indicated in this manual. Do not dispose of batteries in a
fire. They may explode. Check with local codes for possible special disposal
instructions.
• Keep batteries away from children at all times.
Precautions
• There are no parts which can be serviced or cleaned inside of the
TV display housing.
You can increase the life of your LCD display by taking the following precautions:
• Before cleaning always disconnect the power line and all connection cables.
• Do not use any solvents, caustic or gaseous cleaning agents.
• Clean the display with a soft, lint-free cloth.
• Ensure that no water droplets remain on the screen. Water can cause permanent
discoloration.
• Do not expose the screen to bright sunlight or ultraviolet radiation.
Information on Disposal of Waste Electrical and Electronic Equipment
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end of its
life cycle separately from your household waste. There are separate
collection systems for recycling in the EU. For more information, please
contact the local authority or your retailer where you purchased the
product.
4
Introduction
Thank you for purchasing our LCD display. We thank you for your confidence in our
products and are pleased to greet you as a new customer.
We focus on great features, ease of use and reliability in manufacturing your LCD
display.
Service
Your display comes with a one-year warranty; this is in addition to your statutory
rights. This manual contains a separate chapter on Troubleshooting on page 47.
Performance Characteristics
Advantages relating to CRT (cathode ray tube) display:
• Less space required
• Lighter weight
• Lower power consumption
Box Contents
Please check that you have received the following items with your LCD display. If
any following items are missing, please contact your nearby retailer
User’s Manual & Documents
Remote Control &
Batteries(AAA X2)
AC Power Cord
Screwdriver & Screws
USER’S MANUAL
5
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Further Features
The connection terminals include Antenna IN, D-SUB, HDMI 1, HDMI 2, SCART
1 (CVBS, RGB), SCART 2 (CVBS, S-VIDEO, RGB), COMPONENT, Headphone,
Common Interface (for V26MMFJ-ETA with DVB-T only)
Easy-to-use remote control, and OSD (On-Screen Display) menu.
ARC (Aspect Ratio Control) settings include Auto image, 4:3, 16:9, 14:9,
Panoramic, and Zoom.
APC (Automatic Picture Control) settings include Normal, Cinema, and Dynamic.
A.P.S. (Auto Programming System) for automatic TV channel tuning.
TELETEXT function is available.
Parental Control is available.
Child lock function is available.
Built-in dual channel speakers.
Built-in NICAM/A2 (IGR) sound decoder for stereo and bilingual listening.
Automatic sleep timer ranges from 10 to 120 minutes in 10-minute increments.
Provided component video input for high definition TV program, resolution up to
720p, 1080i.
Provided 7 days EPG (Electric Program Guide) function is available in Digital TV.
Common Interface (CI) function is available (for V26MMFJ-ETA with DVB-T
only)
Formatted:
Not Highlight
Formatted:
Not Highlight
Formatted:
Not Highlight
Formatted:
Not Highlight
Formatted:
Not Highlight
Deleted: o
Deleted: s
Deleted: d
Deleted: Aspect Ratio modes
Deleted: (Modes available are
dependant upon the source)
Deleted: automatic
Deleted: p
Deleted: c
Deleted: auto
Deleted: programming
Deleted: system
Deleted: 10 to 120 minutes
sleep timer control in 10 minute
intervals.
Deleted: Provided with
component video input for high
definition content.
6
Overview of the TV
Indicator
Indicator
Indicator Lighting Status:
OFF (No power input) Off
Standby passive Red
Power on (TV / Video / PC mode) Blue
Standby active (only available in PC mode) Purple
A blue indicator lights when the power is on and a purple
indicator lights when
in the standby PC mode. A red indicator lights when in standby mode passive.
Remote Control Sensor
Remote control sensor
7
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Function Keys
Function Keys (on the display panel):
ASPECT /
ARC
• Select the TV display mode to switch Auto Image / Panoramic
/ 16:9 / 14:9 / 4:3 / Zoom.
• When in OSD (On-Screen Display)* menu, press ASPECT /
ARC
to close the OSD menu
- VOLUME +
• Increase or decrease the volume.
CHANNEL
• Change channels.
MENU
• Display the OSD main menu.
• Return to previous menu when in OSD menu.
INPUT
• Select input source TV / DTV/ SCART1 / SCART2/ SCART2S/
CVBS/ S-VIDEO/YUV/ HDMI 1/ HDMI 2/ VGA.
• When OSD MENU is invoked, it will function as the "OK" key to
setup a function or enter a sub-menu.
POWER
• Shift on or off the TV.
•
When the status of indicator is off, press POWER on the panel to
enable this LCD TV.
NOTE:
Function Keys control your TV’s basic features, and you may use these to adjust on-screen
display (for example, items in the main menu or sub-menu). To use more advanced features,
you must use the remote control.
8
Connections
NOTE:
• Common Interface (CI) Module: the CI module socket is on the rear side of the LCD display.
• Please turn off the LCD display before inserting or removing a CI module.
• Audio out L/R: The level of audio output cannot be changed using the volume control on your
display. This connector should be used with an external audio amplifier that can be used to
control
the volume.
9
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Overview of the Remote Control
1
Power
Shift the TV on or off.
2 TELETEXT
Press the button to show the TELETEXT
Service.
Toggle text modes between TEXT / MIX / PAT /
OFF
3 INDEX
ATV (analogue): Return to Page 100
(TELETEXT reset).
DTV (digital): To display information when
banner is on.
HOLD
Press “HOLD” button to stop the automatic
TELETEXT page change.
INTERRUPT
Press “INTERRUPT” button to switch to TV while
waiting for the required text page.
REVEAL
To display concealed information, such as
solutions of riddles, puzzles, or a quiz.
EXPAND
Press “EXPAND” button to enlarge the top half or
bottom half of the TELETEXT page.
TIME/SUB-PAGE
Press “TIME/SUB-PAGE” button to access to the
sub-page you required.
Red / Green / Yellow / Blue
ATV (analogue): To
display recording setting and
user profile
Page direct access for Teletext mode.
DTV (digital): Function keys for DTV mode.
4 CH
To change the channel.
5 0~9
Numeric buttons.
6 VOL
To Increase or decrease volume level.
7 RTN
Return to the latest viewed channel or source
8 MUTE
Sound Mute On / Off
9
APC (Automatic Picture Control)
Toggle screens between Normal / Cinema /
Dynamic.
10
ARC (Aspect Ratio Control)
In VGA (PC) mode, to toggle the picture mode
between 16:9 / 4:3.
In Video mode, to toggle the picture mode between
Auto Image / Panoramic / 16:9 / 14:9 / 4:3 / Zoom
10 EXIT
In OSD screen, to exit a menu or sub
-
menu.
11 OK
In OSD screen, to set up a function or enter a
sub-menu.
/ / /
OSD screen in DTV (digital) or in ATV (analogue): to
access menu items.
12
MENU
Display the On-Screen Display (OSD) menu or return
to a layer of menu.
13 TV
Select the TV / DTV mode.
14 PC/HD
Switch to VGA / HDMI1/HDMI2 mode.
15 VIDEO
Switch to CVBS / S-VIDEO / YUV mode.
16 SCART
Switch to SCART1 / SCART2 / SCART2 S mode.
17 SLEEP
Select a pre-set timer for automatic power down.
SUB-TITLE
ATV (analogue): to show information.
DTV (digital): toggle SUBTITEL On/Off
GUIDE
ATV (analogue): the button is navigator.
DTV (digital): to display 7 days EPG.
SOUND
Select sound modes (according to different TV
broadcasts).
11
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Setting Up
Connections
Connecting video devices via AV cables
This TV accepts different Video Inputs. Connecting to device connectors with better
video quality will bring you better viewing enjoyment. The video quality sequence
from the best to a normal one would be Component, SCART, S-VIDEO, and CVBS.
12
NOTE:
• ANT IN: Antenna (aerial) In.
• Connecting cables above are not supplied.
13
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Connecting a video device via HDMI - HDMI
This can be applied only if there is an HDMI Output connector on the external device.
NOTE:
• Video Device: DVD Player, Set-top Box, Game Box…etc.
• HDMI: High-Definition Multimedia Interface
• No audio cable is needed when via HDMI to HDMI connection.
• Either HDMI1 or HDMI2 can work when you connect one video device.
• Connecting cables above are not supplied.
video devices
14
Connecting a PC via VGA cable
NOTE:
• To receive a display, connect a VGA cable between the D-SUB
connector on the TV and
the VGA connector on a PC.
• To receive a sound, connect an audio cable between the PC AUDIO IN jack on the TV
and AUDIO OUT jack on a PC.
• Connecting cables above are not supplied.
15
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Watching TV
Turning the LCD Display On and Off
Turning On
After the LCD DISPLAY is connected, you can then turn on your LCD DISPLAY.
Follow the instructions below to turn the display on:
Step 1: Place supplied two (AAA) batteries into the remote control; make sure the
batteries are oriented correctly.
Step 2: Connect the power cord into the AC IN located in the back of the display and
the other end to the power outlet on the wall. The indicator on the bottom
right side of the display will light up red at this moment.
RED
16
Turning Off
When the display is on, press the POWER button of the display, or press the
POWER button on the remote control to turn the TV off. After the TV is turned off, the
indicator on the front will light up red.
If you go away for a few days or will not use your TV for a long period of time, please
unplug the power cord to turn the main power off.
Step 3. Press the POWER button on the right side of the display, or press the
POWER button of the remote control to swift on the display. T
he indicator will
light up blue.
Blue
17
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Initial Power on
The whole Auto Install process will take around 10 minutes to complete.
Service Scan Progress is completed, when Scan Progress reaches 100%. The TV
resumes to normal operation.
When you switch on the TV for the first time, the Auto Install menu will appear
automatically on the screen. (Please ensure your TV has aerial cables connected.)
1. Press or to highlight Country* and then press OK.
2. Press or to choose your country in the Message Bar,
then press OK.
3. Press or to highlight Language*, then press OK to
enter the Adjustment Bar.
4. Press or to choose your language. Press OK.
5. Press or to highlight Start Service Scan, and then
press OK to enter the Scan Progress.
Note:
Country: Austria, Belgium, Czech, Denmark, Finland, France, Germany, Great Britain, Greece,
Hungary, Ireland, Italy, Netherlands, Norway, Poland, Portugal, Slovakia, Slovenia, Spain,
Sweden, Switzerland, Turkey and Others.
Language: English, French, German, Spanish, Italian, Finnish, Swedish, Dutch, Danish and Norwegian.
18
Source Buttons
1. Turn on the power.
2. Select an input source as described below.
Source buttons
TV
: switch to Analogue/Digital mode
PC/HD
: switch to VGA / HDMI 1/ HDMI 2 mode
VIDEO
: switch to CVBS / S-VIDEO / YUV mode (Composite, Y/C and
Component signal)
SCART
: switch to SCART1 / SCART2 / SCART2 S
19
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Volume Control
Using Volume Control
Press VOL+ / VOL- to increase or decrease
the
sound volume.
Using Mute
At any time, users can temporarily turn off the
sound by pressing the MUTE button.
1. Press MUTE and the sound cuts off.
2. Press MUTE again or VOL+ / VOL- to turn
the sound back to the previous level.
Setting the Sleep Timer
You can set the Sleep Timer to turn off the TV
automatically. The timer can be set from 00 to
120 minutes in 10 minute intervals.
1. Press SLEEP to set the Sleep Timer
screen.
2. Press SLEEP repeatedly to change the
sleep timer.
20
ARC - Aspect Ratio Control
Press ARC to adjust different picture format on the screen. Please
note: in some sources, some modes are only available.
Auto Image :
In this mode, the TV can automatically select the
suitable broadcast mode.
4:3 :
In this mode, will display traditional 4:3 broadcasts
for non-wide screen in the correct proportions.
There will be black strips at both sides of the
screen.
14:9 :
In this mode, will display 14:9 broadcasts in the
correct proportions. There will be black strips at
both sides of the screen.
16:9 :
This mode expands the width of 4:3 broadcasts
evenly to fill the 16:9 screen.
PANORAMIC :
Expands 4:3 broadcasts to fit the 16:9 screen by
expanding the image at the edges of the screen.
This creates less distortion at the centre of the
screen.
ZOOM :
Displays broadcasts in letter box format in the
correct proportions. The top and bottom of the
images are slightly cropped.
APC - Automatic Picture Control
Press the APC button on the remote control repeatedly to cycle
through the APC settings. The button adjusts the different screen
brightness– Normal / Cinema / Dynamic
Normal : Select this mode in a normal environment.
Cinema : Select this mode in a dark environment.
Dynamic : Select this mode in a bright environment.
NOTE:
In VGA (PC) sources, the format of 16:9 and 4:3 modes are only available.
21
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
NICAM/A2 (IGR) Broadcast Selection
Depending on the particular program being broadcast, you can press the SOUND button to listen to
different language sources. Under different systems, broadcast function will show differently.
Sound A : sends the primary broadcast language to the loudspeakers.
Sound B : sends the secondary broadcast language to the loudspeakers.
Mono : sends mono sound
Stereo : sends stereo sound
NICAM System
Mono
Stereo
Stereo
Mono
Sound A
Dual
Sound B
NICAM
Digital
Mono
Mono
Two Carrier System
Mono
Stereo
Stereo
Sound A
Dual
Sound B
Analogue
Mono Mono
22
General Controls & Adjustment
How to control On-Screen Display (OSD)
OSD main menu can appear by pressing buttons either on remote control or the
right side of the TV.
1. You can use the remote control buttons to open the OSD main menu and
change the settings for the TV.
2. You can also use the buttons of the display to open the OSD main menu and
adjust different settings for your TV.
23
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Viewing the On-Screen Display (OSD)
Main menu
Instruction (Message bar)
Use the left / right arrow buttons on the remote to select the menu option ICON. Then
use the up / Down arrow button on the remote to move down the Sub menu items.
Press the OK button to select the option.
Sub-menu
Please press OK on the remote control, after selecting your preferred item in sub-menu.
How to use main menu and sub menu in OSD
1. With the power on, press MENU on the remote. The
OSD (On-Screen Display) main menu appears.
2. Press or to horizontally select the main menu
option and press to enter the sub menu option.
3. Press or to vertically select one sub-menu item,
and then press OK to select.
4. Press or to make adjustments. Press OK to
return to select.
5. Press MENU to return to the Main menu.
6. Press EXIT to exit the menu.
24
Picture Setting
You may need to perform separate adjustments for brightness and contrast for the
different modes.
With the power on, in any mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Video” and press .
4. Press or to highlight one item. Press OK to enter the
Sub-menu.
5. Press or to make adjustments in the adjustment bar and press OK.
6. Press MENU to return to the main menu, or press EXIT to exit the menu.
Video:
Backlight : Adjust the backlight level of the screen.
Contrast : Increase and decrease the picture contrast.
Brightness : Darken and brighten the picture brightness.
Colour : Deepen and lighten the picture colours.
Sharpness : Adjust the outline of pictures to make them more sharper or duller.
Tint*
:
For skin tones to become purplish or greenish. (Only available
when the video input is in NTSC format.)
Noise
Reduction
Decrease the picture noise in a weak signal.
Switch to Auto / High /
Middle / Low / Off.
Main menu Adjustment Bar
NOTE:
It is best viewed with lower brightness and contrast settings in VGA mode.
25
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Sound Setting
With the power on, in any mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Audio” and press .
4. Press or to highlight one item. Press OK to enter the
Sub-menu.
5. Press or to make adjustments in the adjustment bar and press OK.
6. Press MENU to return to Main menu, or press EXIT to exit the menu.
Audio:
Surround Modes:You can choose different audio effects for your TV.
AVC (Auto Volume Correction) :This feature allows you to automatically adjust the
volume by lowering the speaker output when the volume is high or by raising the
speaker output when the volume is low. Switch to “On” or “Off” to enable or
disable the AVC function.
Balance : Adjust the volume balance between the left and right speakers.
Equalizer: You can choose an Audio scenario you
like.
Neutral: Present the original sound.
Movie: Emphasize the live sound for movies.
Music: Present enhanced sound quality for music.
Individual*: Customized sound mode.
Bass* : Adjust Bass.
Treble* : Adjust Treble.
NOTE:
The “Bass” and “Treble” can be only adjusted when Equalizer is set in “Individual” mode.
Neutral
26
Service in Analogue TV
With the power on, in Analogue TV mode.
1. Press TV of Source Button to select TV mode. Press
MENU.
2. Press or to select “Service” and press .
3. Press or to highlight one item. Press OK to enter the
Sub-menu.
4. The operating screens will vary due to different functions; refer to the Message
Bar below to adjust to your favourite settings.
5. Press OK to confirm your setting.
6. Press MENU to return to the previous menu or press EXIT to exit the menu.
Service: A.P.S. and Service Management are only offered in ATV mode.
A.P.S. : This function is to search and store all available channels.
Country : Choose a country.
Start Service Scan : Start scanning all channels.
Sub-menu
Return : Return to the previous menu.
Service Management : Manage the channels to your own preferences.
Sort : Set the channel order according to your preference.
Delete : Delete the selected channel.
Rename : Rename the selected channel.
Add/Change : Add or fine tune a selected channel.
Sub-menu
Return : Return to the previous menu.
Reset :
You can reset all settings to their original default settings, except the scanned
channels.
27
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Service Management
Rename/Sort/Delete
With the power on, in Analogue TV mode.
1. Press TV to select TV mode. Press MENU.
2. Press or to select “Service” and press .
3. Press or to highlight “Service Management”. Press OK to
enter the sub-menu.
4. Press to highlight “Rename”. Press OK to enter the Service
Naming.
5. In the Service Naming, press or to select the programme you
want to rename, and then press OK to edit name.
6. Press to enter the name display area (5 characters), and press or to
choose the characters, and then press OK to confirm.
7. Press MENU to return to Main menu, or press EXIT to exit the menu.
NOTE:
To Sort, or Delete, please select your preferred item in the sub-menu and follow above steps.
28
Service in Digital TV (DTV)
With the power on, in DTV mode.
1. Press TV to select DTV mode.
2. Press MENU.
3. Press or to select “Service” and press .
4. Press or to highlight one item. Press OK to enter the Sub-menu.
5. The operating screens will vary due to different functions; refer to the Message
Bar below to adjust to your favourite settings.
6. Press OK to confirm your setting.
7. Press MENU to return to the previous menu or press EXIT to exit the menu.
Service:
Recording Settings : You can use this function to record all available channels.
Service Scan : Start scanning all channels.
Country : Choose a country.
Confirm : Begin to scan and erase old info
Sub-menu
Return : Return to the previous menu.
Setup : You can setup some DTV settings.
New Service Alert
:
Inform you the new service.
Parental Control : Programme Censorship
“Parental Control” functions depending on your
setting for “Country” in “Service Scan.”
Reset
To select “Reset,” please press on the remote to enter the second page of main menu.
You can reset all settings to their original default settings, except the scanned channels.
29
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Recording Settings
With the power on, in DTV mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Service” and press .
4. Press or to highlight “Recording Settings*”. Press OK to enter the setting
mode.
5. Press MENU to return to the previous menu or press EXIT to exit the menu.
NOTE:
To use DTV recording, other video device must connect to the TV in advance.
30
Service Scan
With the power on, in DTV mode.
1. Press TV on Source button to choose DTV source.
2. Press MENU.
3. Press or to select “Service” and press .
4. Press or to highlight “Service Scan”. Press OK to enter
the Sub-menu.
5. Press to highlight “Country” and press OK.
6. Press or to choose the country and press OK.
7. Press to highlight Confirm* and press OK. If you are sure to do the DTV
service scan, then press OK to start DTV scan.
8. Press MENU to return to the previous menu or press EXIT to exit the menu.
NOTE:
A warning message will appear, after you select “Confirm” in sub-
menu. Your previous stored
information will be substituted and erased.
31
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Setup
With the power on, in DTV mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Service” and press .
4. Press or to highlight “Setup”. Press OK to enter the setting mode.
5. Press MENU to return to the previous menu or press EXIT to exit the menu.
Banner Display Time: Adjust the display time of the banner. Switch to 3 / 5 / 10 seconds
Subtitle Language*: Choose your preferred subtitle language.
Audio Language*: Choose your preferred audio language.
Common Interface: To use pay per view services.
Signal Strength: To show the signal strength for the
channel.
Software Update: To update the software. A message
bar will show, if an updated notification is received.
Time Zone Setting: To set up time zone
Manual Scan: To scan one channel manually
NOTE:
• Common Interface (CI) Module: the CI module socket is on the rear side of the LCD display.
• Please turn off the LCD display before inserting or removing a CI module.
• The language selection for audio and subtitle is offered according to your local broadcasters.
32
New Service Alert
With the power on, in DTV mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Service” and press .
4. Press or to highlight “New Service Alert”. Press OK to enter the setting
mode.
5. Press or to select “On” or “Off” in the message bar and press OK to
confirm.
6. Press MENU to return to the previous menu or press EXIT to exit the menu.
Parental Control
With the power on, in DTV mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Service” and press .
4. Press or to highlight “Parental Control”. Press OK
to enter the setting mode.
5. Press or to select “Allow” or “Block” in the message bar and press OK to
confirm.
6. Press MENU to return to the previous menu or press EXIT to exit the menu.
“Parental Control” functions depending on your setting for
“Country
” in “Service Scan.”
33
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Viewing the Banner of Digital TV
With the power on, in DTV mode.
(The banner will appear, after DTV Service Scan completes)
1. Press Source button to choose desired source.
2. Press CH / OK / or to display the banner.
3. The banner is on the screen, then:
Press or to select channel in the banner.
Press OK to confirm the selected channel.
Press the SUB-TITLE button to display the DTV
SUBTITLE.
Press to display the more details information about the selected
channel.
Press the GREEN button to select the DTV
multi-audio.
Press the YELLOW button to display DTV profile.
This banner is shown only in DTV mode.
1. Logical channel number
2. Service name
3. Service status
4. Current time
5. Event name
6. Now/Next status
7. Duration of event
8. Subtitle status
9. User profile
10. Encrypted service indicator
11. MHEG service indicator
12. Multi-audio indicator
13. Event information indicator
14. Subtitle indicator
15. TELETEXT indicator
34
EPG (Electronic Programme Guide) in DTV
EPG (Electronic Programme Guide) is only provided in Digital TV. Users
can research, view, create or record a list of current and future broadcast
television programmes.
With the power on, in DTV mode.
1. Press Source button to choose desired source.
2. Press the GUIDE button on the remote to display the EPG.
3. The EPG is on the screen, then:
Press the GUIDE button to display the user profile.
Press or to select service category.
Press the BLUE button to switch to theme list.
Toggle among 7 days EPG by using numeric
buttons (1~9) on the remote.
35
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Set up Your Preferred Channels in DTV mode
Buttons on the Remote Control
DTV Guide
Picture 1 Picture 2
Picture 3 Picture
After completing Service Scan,
1. Press GUIDE on the remote control once to enter DTV Guide (see picture 1). Press
again to set up your preferred channels in DTV (see picture 2).
2. Press RED on the remote control to enter User Profile to edit. The
maximum number of
user profiles is no more than three users. Press BLUE on the remote to rename or edit
User Profiles (see picture 3).
3. Press GREEN on the remote control to enter All Services in the right side of User
Guide.
4. Press or to select your favourite channels. There is no limitation to edit your
preferred channel numbers in the right side of All Services (see picture 4).
Press GREEN on the remote repeatedly to switch between User Profiles and All Services.
Press YELLOW on the remote to delete items of User Profiles.
36
Preferences
With the power on, in any mode.
1. Press Source button to choose your desired source.
2. Press MENU.
3. Press or to select “Preferences” and press .
4. Press or to highlight one item. Press OK to enter the
Sub-menu.
5. Press or to highlight one item. Press OK. Press or to
make adjustments, then press OK again.
6. Press MENU to return to Main menu, or press EXIT to exit the menu.
Preferences: Child Lock and Change PIN are offered in ATV.
OSD
: To make adjustments for the OSD (On-Screen Display).
Language : Select language display of the OSD.
OSD Contrast : Adjusts the contrast of the OSD.
OSD Brightness : Adjusts the brightness of the OSD.
Transparency : Adjusts the transparency of the OSD.
Sub-menu
Return : Return to the previous menu.
Child Lock: To lock some channels for the protective reason.
Change PIN: Create your own PIN.
On Timer: To set the TV switch on/off automatically.
Colour Mode: Adjusts the colour of the picture.
Colour R/G/B will appear, when Colour mode is set in “User.”
Normal
: The colour is natural.
Warm: The colour has a reddish tint.
Cool: The colour has a bluish tint.
User: Customizes the colour mode.
User mode
Colour R: Adjusts the red ratio of the picture.
Colour G: Adjusts the green ratio of the picture.
Colour B : Adjusts the blue ratio of the picture.
37
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Child Lock
With the power on, in any modes/sources, except for DTV.
1. Press Source button to choose your desired source.
2. Press MENU.
3. Press or to select “Preferences” and press .
4. Press or to highlight “Child Lock” and press OK.
5. Press or to change the current status to “ON.”
6. Enter your preferred PIN (Personal Identification Number) by using numeric
buttons (0~9). To exit the menu, press EXIT.
(1) To set up child lock for the first time
(2) To change PIN (after setting up child lock) Change PIN
NOTE:
• The default PIN is “0000”. Memorize the new PIN code you entered; to renew the code,
you have
to enter the correct code that you had set recently.
• To remove the lock permanently, you may follow above steps 1~5.
• Child Lock is set or removed separately in each source.
38
On Timer
With the power on, in any mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Preferences” and press .
4. Press or to highlight “On Timer”. Press OK to enter
the Sub-menu.
5. Press to highlight “TV on after”. Press OK to set up
time.
6. Enter desired hours/minutes* by using numeric buttons (0~9),
press OK.
7. Press to highlight “Confirm”, press OK, and then the TV will
turn off immediately.
NOTE:
• For example, if you want to set 10 minutes for TV on after, press numeric buttons “0010” on the
remote.
• If you didn’t do the “Confirm” in step 7, it is not completed.
39
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Connectivity: PC Setting
With the power on, in VGA mode.
1. Press PC/HD of source buttons to select VGA mode.
2. Press MENU.
3. Press or to select “Connectivity”.
4. Press to highlight “PC”, and then press OK to enter
the Sub-menu.
5. Press or to highlight one item. Press OK.
6. Press or to make adjustments, then press OK.
7. Press MENU to return to the Main menu, or press EXIT
to exit the menu.
Connectivity:
PC: The item of PC in the main menu of Connectivity only appears in VGA mode.
Auto image :
Automatically adjusts picture. You may follow steps 1-4, and then
highlight
“Auto image” press OK.
H Position : Adjusts the horizontal position of the picture.
V Position : Adjusts the vertical position of the picture.
Phase : Adjusts the picture phase.
Clock : Adjusts the width of the picture.
Sub-menu
Return : Return to the main menu.
Main menu (in VGA mode) Sub menu (in VGA mode)
.
40
Resolution Adjustment
This message of your current PC resolutions and frequency appears, when PC is
connected.
With the power on, with PC connected.
Press or in the remote control to highlight one item. Press OK in the remote
control.
Note:
1. The picture of “Wide mode selection” will appear in some specific PC resolutions
of 1024x768, 1280x768 1360x768
and 640x350, 720x400.
2. Auto mode is strongly recommended.
41
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Information
With the power on, in any mode.
1. Press Source button to choose desired source.
2. Press MENU.
3. Press or to select “Information”.
4. Press OK or MENU or EXIT to exit the menu.
You can also use the “SUB-TITLE” key on remote control
to invoke the “Information.”
Information:
Panel Res. :Displays the panel resolution of the TV.
Main Source
:
Displays the source of the main picture source.
Main Format
:
Main picture input format.
Sound Mode
:
Displays the sound mode information.
APC Mode :Displays the APC mode information.
ARC Mode
:
Displays the ARC mode information.
42
Reset
With the power on, in any mode
1. Press MENU.
2. Press or to select “Service” and press .
3. Press or to highlight “Reset”. Press OK then
finished.
4. If you want to exit the menu, press EXIT.
(in TV mode)
(in DTV mode)
43
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
TELETEXT
TELETEXT is an information service broadcast offered by some TV stations
(depending on different countries) which gives up-to-the-minute information, news,
weather, television programs, share prices, subtitles, and so on.
This TV has 100 Teletext page number memories.
TELETEXT Operation
Step1. Select a TV station on which TELETEXT is being transmitted.
Step2.
Press TELETEXT on the remote to make the TELETEXT screen appear.
Display: Two page numbers, TV station name, date, and time are d
isplayed on the
screen headline. The first page number indicates your selection, while the
second shows the current page being displayed.
Step3.
Press TELETEXT to toggle text mode between TEXT / MIX / PAT / OFF*.
TEXT mode MIX mode PAT mode
44
TELETEXT Page Selection
Step1. Enter the required TELETEXT page as a three digit number.
Display: The selected page number is displayed at the top left corner of the
screen. The TELETEXT page counter searches until the selected page
number is located, so that the desired page is displayed on the screen.
Step2.
The CHbutton can be used to select the preceding or following page.
Step3.
Fastext movement by the 4 coloured buttons on the remote.
Display: Four subject-heading pages can be selected quickly by pressing the
corresponding coloured buttons Red / Green / Yellow / Blue on the
remote control handset.
Useful features for TELETEXT
Buttons on remote control for TELETEXT mode
45
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
INDEX
Press the button on the remote
to select the index page that displays the list of
TELETEXT contents.
REVEAL
Step1.
Press this button once to display concealed information, such as solutions
to riddles, puzzles, or a quiz.
Step2.
Press this button again to conceal the revealed answers.
TIME
Step1. While watching a TV program with TELETEXT transmission, press
the
button. The current time information will be displayed on the upper centre
corner of the screen.
Step2. The time information will disappear after pressing the button again.
Sub-Page
Press the button to stop the running teletext page and enter your subpage number.
HOLD
The TELETEXT page you have selected may contain more information than what is
on the screen; the rest of the information will be displayed
after a period of time on a
sub-page.
Step1. Press the button on the remote to stop the automatic page change.
Display:
The STOP symbol will be displayed at the top left-
hand corner on the
screen and the automatic page change will be stopped.
Step2. Press the button again to continue.
46
INTERRUPT
In the TELETEXT mode, pressing the button on the remote
will switch the screen to
the TV mode while waiting for the text page you required.
Step1. Select required page number in TELETEXT mode.
Step2. Press the button on the remote
to switch to TV mode while waiting for the text
page. A small blue box in which “???“ shows appears in the upper left corner.
Step3. When the required text page is found, the required page number appears
in
the blue box.
Step4. Press the button again to revert to TELETEXT mode.
EXPAND
Select double height text.
Step1. Press this button to enlarge the top half of the page.
Step2. Press this button again to enlarge the bottom half of the page.
Step3. Press this button again to return to the normal display.
NOTE
:
• No OSD adjustment will be available in TELETEXT mode.
• Press or button on the remote control to adjust different picture brightness.
47
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
Troubleshooting
Here are some tips to solve some common problems. If your problem still exists,
please contact your nearby retailer directly.
There is no picture and sound.
Make sure the power cord is properly
connected.
Make sure the input mode is set correctly.
There is no picture (in AV mode).
Make sure the Contrast/ Brightness is properly
adjusted.
Make sure all external devices are connected
properly.
There is no sound.
Make sure the volume is not set to minimum.
Make sure the sound is not set to mute.
48
There is no picture or sound, just noise.
The reception may be weak.
Make sure the aerial is not disconnected.
The picture is not clear.
The reception may be weak.
Make sure the aerial is not disconnected.
The picture is too bright.
Check Contrast/Brightness adjustment.
Check the APC (Auto Picture Control
) function
setting.
The picture is too dark.
Check the APC function setting.
Check Contrast/Brightness adjustment.
The picture is jittery
Make sure the TV set isn’t near m
icrowave
oven or other equipment.
49
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
The picture has double or triple image.
Make sure the aerial is facing the right
direction.
There may be reflected signals from mountains
or buildings.
The picture is spotty.
There may be interference from automobiles,
trains, high voltage lines, neon lights, etc.
Remote control does not work.
Check the batteries in the remote control are
not flat.
Make sure the remote control sensor
of TV set
is not under strong lighting.
There are stripes on the screen or colours fade.
Is the unit receivin
g interference from other
devices?
Transmission of radio broadcasting station and
transmission of amateur radio and cellular
phones may also cause interference.
Place the unit as far apart as possible from
devices that may cause possible interference.
The picture is not sharp
Check the colour adjustment.
Check the Sharpness adjustment.
50
Safety and Regulatory Information
Repair
• Leave all repairs of your LCD display to authorised and qualified personnel
only.
• Should a repair be necessary, please contact one of our authorized service
partners only.
Notes for Service Engineers
• Before opening the housing, disconnect the product from all power
sources and remove any connecting cables. If the display has not been
disconnected from the power outlet before being opened, there is a danger to
life through electric shock. There is also a risk of damage to the components.
• Internal components of the LCD display may be damaged by electrostatic
discharge (ESD). Carry out repairs in an ESD-protected workshop. If no
such workshop is available, wear an antistatic wrist strap or touch a highly
conductive metal object. We can repair damage sustained by inappropriate
handling for a fee.
• Use only original spare parts.
Environmental conditions
• The LCD display can be operated most reliably at ambient temperatures
between +41°F and +95°F (5° C to 35° C) and at a relative humidity between
20% and 85% (without condensation).
• When switched off, the LCD display can be stored most reliably between -4°F
and +140°F (-20° C - +60° C), up to a maximum height of 39,000 ft (12,000 m)
above sea level at a relative humidity between 10% and 85% (without
condensation).
• After transporting your LCD display please wait until it has reached the
ambient temperature before connecting and switching it on. Extremely high
variations in the temperature or humidity may result in condensation forming
on the inside of the LCD display which could cause an electrical
short-circuit.
51
English Français Italiano
Deutsch
Español
Nederlands
V26MMFJ EN 12/13/2007_ver.A-PD.paula
PC Input Preset Timing Table
No.
Mode
Name
Resolution
H.Freq.(KHZ)
V.Freq.(HZ)
H.
Polarity
V.
Polarity
Pixel
CLK
(MHZ)
Hor.
Total
CLK
No.
Hor.
Display
CLK No.
Hor.
Back
Porch
CLK
No.
Hor.
Sync.
Width
CLK
No.
Vert.
Total
Line
No.
Vert.
Display
Line
No.
Vert.
Back
Porch
Line No.
Vert. Sync
Width
Line No.
1
VGA 70HZ
640*350
31.469
70.087
25.175 800 640 48 96 449 350 60 2
2
VGA 60HZ
640*480
31.469
59.941
25.175 800 640 48 96 525 480 33 2
3
SVGA 60HZ
800*600
35.16
56.25
36.0 1024 800 128 72 625 600 22 2
4
SVGA 60HZ
800*600
37.879
60.317
40.0 1056 800 88 128 628 600 23 4
5
XGA 60HZ
1024*768
48.363
60.004
65.0 1344 1024 160 136 806 768 29 6
6
XGA 70HZ
1024*768
56.476
70.069
75.0 1328 1024 144 136 806 768 29 6
7
MAC VGA
640*480
35.0
66.667
30.24 864 640 96 64 525 480 39 3
8
US TEXT
720*400
31.469
70.087
28.322 900 720 54 108 449 400 35 2
9
WXGA
1280*768
47.73
60
80 167 6 1280 198 136 795 768 23 3
10
WXGA
1360*768
47.7
60
+
+
85.5 1792 1360 256 112 795 768 18 6
The above table is only for your reference.
Messages shown in LCD DISPLAY will be varied according to types of PC and their resolutions.
The resolution 1360*768 is strongly recommended.
52
Specifications
Model
V26MMFC
Screen Size (diagonal)
26’’
Audio Output
7 W x 2
Aspect Ratio
16:9
TV System
PAL / SECAM
Video Playback
PAL / SECAM / NTSC
Sound System
NICAM / A2 (IGR)
Panel Resolution
1366 x 768 (WXGA)
Connectivity
Antenna In, HDMI1,HDMI2, Component In
(YPbPr), Composite In, Audio In(L/R),
D-SUB, PC Audio in, S-Video,
SCART1,SCART2, Headphone
Common Interface, CVBS
Power Supply
AC 100V~240V, 50/60Hz
Power consumption
100 W
Standby power consumption
1 W
Width
674.5 mm
Height
526 mm
Set dimensions (with stand)
Depth
102 mm
Net Weight (with stand)
13.2 kg
Operating Temperature
5°C to 35°C (41°F to 95°F)
Operating Humidity
20 % to 85%, non-condensing
Storage Temperature
-20°C to 45°C (-4°F to 113°F)
Environmental
Considerations
Storage Humidity
10 % to 85%, non-condensing
The actual design and specifications are subject to change without further notice.
We preserve the right of any corrections or errors in this manual.
Loading...
