Tatung ROS2000 User Manual

Quick Start Guide
Models: ROS2000 and ROS1000
Read the Safety and Notices section on page 14 for important safety and regulatory information.
© COPYRIGHT 2006-2008 PRODEA SYSTEMS, INC. ALL RIGHTS RESERVED.
PRODEA SYSTEMS CONFIDENTIAL INFORMATION AND TRADE SECRETS
THE INFORMATION CONTAINED HEREIN IS THE PROPERTY OF PRODEA SYSTEMS, INC. (“PRODEA”), AND CONSTITUTES CONFIDENTIAL INFORMATION OR TRADE SECRETS OF PRODEA SYSTEMS, INC. THE HOLDER OF THIS DOCUMENT MUST KEEP ALL INFORMATION CONTAINED HEREIN STRICTLY CONFIDENTIAL AND IS GRANTED NO RIGHTS TO USE THAT INFORMATION EXCEPT TO THE EXTENT EXPRESSLY AUTHORIZED BY PRODEA. IF YOU ARE NOT AUTHORIZED TO POSSESS THIS DOCUMENT, YOU MUST RETURN IT TO PRODEA IMMEDIATELY UPON RECEIPT OR, IF YOU HOLD IT IN A FORM THAT CANNOT BE RETURNED, YOU MUST DESTROY IT. IF YOU FAIL TO DO SO PROMPTLY, YOU MAY FACE LEGAL ACTION FOR THEFT AND MISAPPROPRIATION OF TRADE SECRETS.
2
© COPYRIGHT 2006-2008 PRODEA SYSTEMS, INC. ALL RIGHTS RESERVED.
3
© COPYRIGHT 2006-2008 PRODEA SYSTEMS, INC. ALL RIGHTS RESERVED.
© COPYRIGHT 2006-2008 PRODEA SYSTEMS, INC. ALL RIGHTS RESERVED.
PRODEA SYSTEMS CONFIDENTIAL INFORMATION AND TRADE SECRETS
Contents
Setup Hardware ............................................................................. 4
Standard DVD / Satellite Composite vDMA Setup ............................8
High Denition Component vDMA Setup .........................................9
High Denition HDMI vDMA Setup ..................................................10
RHC LED Description .......................................................................11
vDMA LED Description ....................................................................12
Universal Remote Description ........................................................ 13
Safety and Notices ......................................................................... 14
Warranty ....................................................................................... Back
Actual product may vary from depictions in this guide.
OPS-DOC-GEN-SUB-700040-22
4
© COPYRIGHT 2006-2008 PRODEA SYSTEMS, INC. ALL RIGHTS RESERVED.
5
© COPYRIGHT 2006-2008 PRODEA SYSTEMS, INC. ALL RIGHTS RESERVED.
SETUP HARDWARE
1. Before you begin, make sure you have
following equipment.
Working high-speed Internet connection• Television• Activation code • you received from your ROS service
provider.
At least the following ROS hardware:•
ROS Home
Center
ROS Home Center
AC Adapter
ROS Set Top
Box
ROS Set Top Box
AC Adapter
IMPORTANT! If you have a modem - router
combination, you need to turn on bridge mode.
What is a router?
A router manages and connects your home networked
Specications
computers and devices via Wi­Fi or Ethernet.
What is a modem?
A modem connects your home to the Internet services provided by your
Internet Service Provider (ISP).
Remote
(with batteries)
Ethernet
Cable
Component
Cables
Component
Dongle
Composite
Cables
RHC Supply voltage: ........................................................................ 115/230 V.C.A. ±10%
RHC Frequency: ...............................................................................50/60 Hz
RHC Current consumption: ............................................................... 3.33 A
vDMA Supply voltage: ..................................................................... 115/230 V.C.A. ±10%
vDMA Frequency: ............................................................................ 50/60 Hz
vDMA Current consumption: ............................................................2.1 A
