TATUNG SMARTPHONE

M1 USER MANUAL

Smartphone User Manual

Congratulations on the purchase of your new Windows Mobile™ Smartphone!

Please read before operating your device.

THE SMARTPHONE IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE PACKAGE.

DO NOT REMOVE THE BATTERY WHEN THE SMARTPHONE IS BEING CHARGED.

WHEN INSTALLING YOUR SIM CARD, MAKE SURE THE SMARTPHONE IS POWERED OFF AND THE SIM CARD IS INSERTED INTO THE SLOT SECURELY.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE OUTER CASING OF THE SMARTPHONE.

Safety Instructions

To ensure your safety, and prevent the Smartphone from potential damages, please follow the instructions carefully at all times.

Avoid dropping, hitting, applying excessive pressure or putting heavy objects on the Smartphone.

Avoid exposing the Smartphone to chemical, corrosive and alcoholic liquids or using materials to clean the Smartphone.

Do not use, leave, expose, or store the Smartphone under fire or where it will be subjected to prolonged direct sunlight or extreme temperatures.

Avoid exposing the Smartphone to water. If any water may drop on the panel, please use a dry cloth to wipe the Smartphone right away so not to harm the player and its system.

Keep the Smartphone away from strong magnetic objects or environments.

Do not try to modify, repair or take apart components of your Smartphone. If you need further service, please refer servicing to the authorized service technician or provider.

Smartphone User Manual

Avoid pushing objects into product Never push

any objects into the Mini-SD card slot or other openings in the product.

Use only original manufacturer-approved

accessories that don’t contain any metal, else FCC RF exposure guidelines will be violated.

While using earphones, please pay attention to

the volume. Being exposed to high volume can damage your hearing.

This device can cause interference to an aircraft's navigation system and network. In most countries it is against the law to use this device on board an airplane.

Do not use this product in gas stations, fuel stores, chemical plants and locations containing explosives.

Vehicle drivers in motion are not permitted to use hand-held devices, except in emergency. In some countries, using hands-free devices as an alternative is allowed.

Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy. In most hospitals or medical facilities, using this device is forbidden.

Contents

Chapter 1 Get Started

1.1 KnowYour Smartphone

1.2 Setup Your Smartphone

1.3 Status Indicators

1.4 Accessories

1.5 Enter Text and Numbers

1.6 Navigate

1.7 Secure Your Smartphone

Chapter 2 Use Your Smartphone

2.1 Make a Phone Call

2.2 Receive a Phone Call

2.3 Use the Contacts and Beam

2.4 In-call Options

2.5 Retrieve a Voice Mail Message

2.6 Review Your Calls

2.7 Speed Dials

2.8 Additional Dialing Information

Smartphone User Manual

Chapter 3 Use Your Camera

3.1 Use the Camera

3.2 Use Pictures & Videos

Chapter 4 Personalize Your Smartphone

4.1 Customize Smartphone Settings

4.2 Customize Profiles and Sounds

4.3 Customize Date and Time

Chapter 5 Get Connected

5.1 Connect to the Internet

5.2 Pocket Internet Explorer

5.3 Bluetooth

5.4 Modem Link

5.5 Wireless Manager

Chapter 6 Messaging Features

6.1 Set up Accounts

6.4 Receive E-mail and Text Messages

6.5 View Message Folders

6.6 Instant Messaging

6.7 MMS Messaging

Chapter 7 Synchronization

7.1 Use ActiveSync

7.2 Install ActiveSync

7.3 Exchange Server

7.4 Synchronize music, video and pictures

Chapter8 Applications

8.1 Use Calendar

8.2 Use Tasks

8.3 Use Calculator

8.4 Use Voice Notes

8.5 Use Windows Media Player

8.6 Use JAVA Manager

6.2 Manage Accounts

6.3 Send E-mail and Text Messages

8.7 Games

Smartphone User Manual

Appendix

Regulatory Notices Troubleshooting Specifications INDEX

Chapter 1 Get Started

1.1 Know Your Smartphone

This section will help you familiarize yourself with your Smartphone, including a basic introduction to the buttons and features.

Chapter 1

Get Started

1.1 Know Your Smartphone

1.2 Setup Your Smartphone

1.3 Status Indicators

1.4 Accessories

1.5 Enter Text and Numbers

1.6 Navigate

1.7 Secure Your Smartphone

1. Power Button

Press and hold the Power Button to switch on or off your Smartphone. Press and quickly release the Power Button to display the Quick List, which enables you to change profiles, lock your Smartphone, manage wireless status, or switch off your Smartphone.

Chapter 1 Get Started

2. Mini-SD Card Slot

Use the push-push technique. Simply push the Mini-SD card to click in or push again to eject.

3. Earphone Jack

Plug the stereo headset into the Earphone Jack to use the headset frofile and listen to music or multimedia files.

4. Volume Up/Down Button

This button allows you to adjust the volume at any time.

5. Camera Button Press this button once to switch on the preview

mode. Press again for still pictures capturing or video recording.

6. Mini USB Port

Plug the Mini USB cable into the port to synchronize data in your Smartphone with desktop or laptop. Also, plug the AC adapter in here to charge the battery.

7. Receiver

8. Microphone

9. Battery Charging Indicator

Indicate the charging status.

Battery Charging Indicator Status Solid Green Battery is fully charged.

Solid Amber Battery is being charged.

10. Navigation Button Scroll left, right, up, and down or press down as

enter. When executing Windows Media Player 10, scroll up or down for adjusting the volume; scroll left or right to select previous or the next song; to fast forward/rewind quickly, scroll and hold left or right, press down to pause, press again to play.

11. Media Player Button

Switch on Windows Media Player 10.

12. Left Softkey

Perform the function shown in the “Softkey

Label” on the screen immediately above the

button. (For example, when in the Home screen, pressing the Left Softkey opens the

Start menu.)

Chapter 1 Get Started

backspace over one character in a text field.

13. Right Softkey

Press and hold to delete the contents of an editable field.

Perform the function shown in the “Softkey

Label” on the screen immediately above the

button. (In many cases, pressing the Right

18. Home Button

Softkey opens a menu associated with a

particular application.)

Press to return to the Home screen at any time.

19. Display Screen

14. Messaging

Execute Text Messages/Outlook E-mail/MMS

The layout of the Display Screen will be described in chapter 1.6.

20. Camera Lens with Self-Portrait Mirror

15. End Button

Press to end a phone call or return to the Home screen. Press and hold to lock the keypad.

Incoming live video stream enters here and is shown on the display screen when you are in

Camera mode. Position the Smartphone until

the mirror reflects the desired image.

16. Talk Button

Press to start a call or answer an incoming call. Press and hold to turn the speakerphone mode on or off, or switch between an active call and a call on hold.

17. Back Button

Press to return to the previous screen, or to

21. Loud Speaker 1 Ring tones, music and speakerphone can be

played through the loud speaker.

22. Loud Speaker 2 Ring tones, music and speakerphone can be

played through the loud speaker.

23. RF ANT Output

Chapter 1 Get Started

1.2 Setup Your Smartphone

In this section you will learn how to install the battery, the SIM card, the Mini-SD card and to charge the battery.

 Install the SIM Card

The SIM (Subscriber Identification Module) card contains a computer chip that stores your personal number, phone book, and other services provided by your service provider.

3. Insert the SIM card into the SIM card slot and leave the chamfered corner facing out.

 Install the Mini-SD Card

Use the Mini-SD (Secure Digital) card in your Smartphone. You may plug the Mini-SD card to the Mini-SD slot to store images, video, music and other data on your Smartphone.

1. Slide the back cover all the way out to open the battery compartment.

2. Remove the battery by lifting the battery grip.

 Install the Battery

1. Align the cooper contacts on the battery towards the battery connector inside the battery compartment (you can see the cooper contacts).

2. Push the upper side of the battery to click in. Slide the back cover back to the Smartphone.

Chapter 1 Get Started

Fully charge the new battery before using your Smartphone for the first time. When the low-battery message appears, save any unsaved data you are working on then switch off the Smartphone. Do not restart your Smartphone until you have connected it to an external power source or connect to a PC’s USB port.

 Charge the Battery

Charge your battery fully (about 4 hours) before using the Smartphone. You may connect your Smartphone to an electrical outlet by using the adapter or connect your Smartphone to a PC by using a Mini USB cable.

NOTE: The time it takes for a battery to be fully charged depends on the environment temperature at the time of charge; a full charge normally takes about

3.5-4 hours under 0-10 degree temperatures, and below 3 hours for temperatures ranging from 20-45 degrees.

NOTE: Do not leave your Smartphone connected to a charger for longer than a week because overcharging can shorten a battery’s lifespan. Your battery will automatically discharge when the device is not in use. Leaving the battery in exceedingly hot or cold places may also reduce its capacity or shorten its lifespan.

Your Smartphone can be charged while switched on or off. Charge your battery by plugging the AC adaptor into the mini USB port on the left side of the Smartphone. You may also charge your Smartphone using the Mini USB cable while connected to the PC’s USB port.

Mode Estimated battery life

Talk time 3.5 to 4 hours GPRS Up to 2 hours Standby 200 hours

Chapter 1 Get Started

 Battery Capacity Indicator Icons

The Battery Capacity Indicator displayed on the Title Bar of the display screen indicates the capacity of the battery,

Full 50%~74% capacity 28%~49% capacity Less than 27% capacity Very Low alert (less than 4%) Charging

1.3 Status Indicators

Chapter 1 Get Started

1.4 Accessories

 Mini USB Cable A Mini USB cable is provided to allow you to

synchronize information between your Smartphone and PC using Microsoft ActiveSync. You may also charge the battery by plugging the cable to a PC USB port.

 Stereo Headset Use the headset to listen to music or multimedia files.

The earphones can also function as a hands free device.

incoming call. Press and hold that button to end a call.

 AC Charger Your Smartphone can be charged while powered on or

off. Charge your battery by plugging the AC adaptor into the mini USB connector on the side of the Smartphone. The AC adaptor is shown below.

Using the headset

Connect the headset cable to the earphone jack located on the top of the Smartphone. Press the “Hook Detect” button on the headset to receive an

 Holster Also furnished with your Smartphone is a handy

carrying pouch.

Chapter 1 Get Started

1.5 Enter Text and Numbers

Your Smartphone supports three input modes for entering text and numbers: Multipress, T9, and Numeric. Your Smartphone will automatically select the appropriate input mode in the editable field. You can toogle the input modes by holding

down the ＊ key. Input and mode choices are Symbols, 123, Abc,

and T9 English. The indicator of input mode functioned displays on the Title Bar. All the indicators are shown as below.

Indicator Mode

abc Abc ABC t9 T9 T9 123

Multipress text input mode, lowercase Multipress text input mode, uppercase Multipress text input mode, caps lock T9 text input mode, lowercase T9 text input mode, uppercase T9 text input mode, cap lock Numeric input mode

 Multipress Mode

In Multipress mode, you can enter a letter by pressing the number key on which the letter appears.

1. To enter the first letter on the number key, press the key once, to enter the second letter, press the key twice quickly, and so on.

2. The letter entered most recently is underlined

until you have completed the keypresses for the letter and moved on to the next letter.

For example (In Multipress Mode) :

Entered word Pressed keys

day 3, 2, 999 great 4, 777, 33, 2, 8

 Press the # key to move a space.  Press the 1 key repeatedly to switch the

punctuation mark.

NOTE: When you enter letters on the same number key, you must pause and wait until the underline disappears after entering the first letter. Then you can continue to enter the next letter. (This pause is called the Multipress time-out, and you can adjust the length of the time of the pause

Chapter 1 Get Started

between keypresses.)

To change the Multipress time out:

1. From the Start menu＞select Settings.

2. Select More＞Accessibility.

3. In the Multipress time out field, select the length of the pause between keypresses preferred.

4. Press the Left Softkey (“Done”) to save the settings and return to the settings screen.

 T9 Mode

In the T9 mode, just press the number keys that contain the letters that you want to spell a word. T9 will then analyze your keypresses and automatically complete the word.

1. Press and hold the ＊ key to invoke the input menu. Scroll down and choose “T9 English.”

2. Enter letters by pressing the keys on which the letters appear. Press a key only once for each letter.

For example (In T9 Mode) :

Entered word Pressed keys

nice 6, 4, 2, 3

 Press the # key to accept the word and enter a

space after it. Or you may scroll through the other word options by using the Navigation Button and then press down to accept the word choice.

 Press 1 and then scroll up or down the

Navigation Button to cycle through common

punctuation symbols.

Chapter 1 Get Started

 Numeric Mode When you are in the Numeric mode, just press the

number(s) you want to enter on the keypad. If a field permits a numerical entry only, such as the Work phone number field in Contacts, the input mode will automatically default to Numeric mode.

Task Directions Enter a number Press the desired corresponding key

on the keypad

NOTE: T9 cannot always find the word you want in the T9 dictionary. You may add your word to the T9

Enter the (＋) sign (for international calls)

Press and hold 0

dictionary.

 Miscellaneous Input Tasks

Task Directions Enter a space In Multipress or T9 mode, press the＃

key.

Start a new line Press down the Navigation Button Enter a symbol Press and hold the＃key＞select the

wanted sym bol＞press Done.

Delete characters Press the Back Button to backspace

over a single character, or hold it to delete a paragraph.

Chapter 1 Get Started

1.6 Navigate

This section discusses how to navigate through your Smartphone’s screens in order to perform tasks efficiently.

menu option will either perform that command or take you to another part of the user interface where you can perform the command. The example menu shown below comes from the File Explorer application.

 Navigation Button

It provides an easy way to move or scroll through selections on the screen. You can scroll the button left, right, up, or down to select desired item. Or you may select a highlighted item by pressing down the

Navigation Button. In many cases, scrolling to an

item and pressing down the Navigation Button executes a command, or takes you to a program or setting, or serves as the Done/Save function. When you scroll to a checkbox, pressing the Navigation

Button activates or clears the box.

 Softkeys

There are two softkeys on your Smartphone, located directly below the display screen: the Left Softkey and the Right Softkey. Each softkey performs the command displayed above it on the screen (called the “Softkey label”).

1. Getting

 Menus

On many screens, the function of the Right Softkey is to open a menu which displays a list of options that are relevant to the current screen/application. Selecting a

 The Home button

Pressing the Home Button takes you to the Home screen. You can access to all the programs of your Smartphone from the Home screen.

The top of the Home screen displays five currently accessed applications. The center of the screen displays the name of the system provider, upcoming appointments, current profile, the number of text massages, and time/date. Selecting one of these will open the related screen.

Chapter 1 Get Started

Title Bar

Service Provider

Date/Time

Current Profile

Numbers of text messages

Note: The screen layout shown above is one of the attributes of Home screen. You may use Settings＞

Home screen to change to the desired Home screen layout including Windows Simple, Windows Default, Large Font, Windows Basic, and MSN Default.

Adittionally, you may press and hold the ＃ button to switch between Line1 and Line 2.

 The Start menu

You can immediately start executing some bundled programs by using the Start menu. (You can also optionally install more from the included Application

CD.)

Grid View List View

1. Press the Left Softkey to open the Start menu. To access the next “page” of the Start menu, press 9 on your keypad.

2. Select an item and press down the Navigation

Button. (Or you may press the corresponding

number in the list view..)

NOTE: You may switch the view of the Start menu by selecting Start menu form the Settings screen.

 The Back Button

Press the Back Button to return to the previous screen (similar to the Back button on an Internet browser.) In a text field, pressing the Back Button to move the cursor back and delete the character to the left (similar

Chapter 1 Get Started

to pressing the Backspace key on a keyboard).

2. Select the item you want and press down the

Navigation Button, or the corresponding

number.

 The Quick List

The Quick List offers convenient access to a list of functions, such as managing your wireless status, locking your Smartphone, locking the Smartphone's keypad, and choosing a different profile.

1.7 Secure Your Smartphone

You can set up the level of security you want to have on your Smartphone by locking the SIM card, the keypad, or the entire phone.

 Lock the Keypad The keypad lock turns off the keypad functionality.

This is a helpful feature if, for example, your Smartphone is turned on and in your pocket, and you want to prevent accidental keypresses from dialing a number, etc.

Task Directions Lock your keypad In the Home screen, press and hold

the End button. Or go to the Quick

List and select Key Lock.

Unlock your keypad In the Home screen, press Unlock,

and press the＊key.

1. Press and quickly release the Power Button on the top of your Smartphone to invoke the Quick

List. (Caution: If you press and hold the Power Button too long, your Smartphone will power

off.)

Chapter 1 Get Started

 Lock your SIM card Locking your SIM (Subscriber Identity Module) card

prohibits you from using the Smartphone, but you can still turn it on and make emergency calls. When you turn your Smartphone on, you will be prompted for your PIN (Personal Identify Number) which you must enter correctly. (shown as the left picture below.)

Task Directions

Lock the SIM Start＞Settings＞Security＞Enable

SIM Lock＞Enter your PIN＞Done

Unlock the SIM Start＞Settings＞Security＞Disable

SIM Lock＞enter your PIN＞Done

 Lock Your Smartphone Locking your Smartphone prevents access to personal

data. When you enable this feature, your Smartphone will lock itself after a specified time of inactivity. You will have to enter your Smartphone lock password before the access is granted. You can still receive calls and make emergency calls, when the Smartphone is locked. p

Chapter 1 Get Started

Task Directions

Lock your Smartphone

Unlock your Smartphone

Turn off phone lock

1.Press Power button to invoke Quick

List＞Device lock Or Start＞ Settings＞Security＞Device lock

2. Select the amount of time in the Prompt if device unused for field

3. In the Password field, enter the password you want to use.

4. In the Confirm password field, enter the password again＞Done

1. Press Unlock＞enter your password

2. Press Unlock again.

Start＞Settings＞Security＞Disable Phone Lock＞enter your password＞ Done

NOTE: If you forgot your password, please call your

Customer Care Service Center for information about how to reset your device and thereby regain access to it. The procedure will cause your Smartphone to lose all programs you had installed, and personal data. However, note that if you had previously synchronized with a PC, you will be able to recover the lost programs easily by synchronizing with it again, after the reset. Therefore it is recommended that you synchronize periodically, in the event that you ever need to easily recover your data.

You can still receive calls and make emergency calls, even when the device, the keypad, or the SIM card is locked.

Chapter 1 Get Started

Chapter 2 Use Your Smartphone

2.1 Make a Phone Call

2.2 Receive a Phone Call

2.3 Use the Contacts and Beam

2.4 In-call Options

2.5 Retrieve a Voice Mail Message

2.6 Review Your Calls

2.7 Speed Dials

2.8 Additional Dialing Information

2.1 Make a Phone Call

There are several ways to make a call on your Smartphone.

 Make a phone call from the Home screen In the Home screen＞enter the phone number＞press

the Talk Button to make the call. Press the Back button if you need to backspace over

a digit. As you enter a phone number, your phone searches Contacts, Call History, Speed Dial lists, and your SIM card, to find a matching number. Matched names and numbers will be displayed.

In this example, the first few digits of a phone number have been entered. The names listed in this screen

Chapter 2 Use Your Smartphone

have all been found to have phone numbers that start with these digits. At this point, you can select the desired name without entering more numbers.

To make a phone call from an open Contact card:

1. In the Home screen or the Start menu, select

Contacts.

 Make a call from Contacts To make a phone call by Contact name:

1. In the Home screen or the Start menu, select

Contacts. If there are many contacts listed, you

can enter the first few letters of the desired contact's name to perform a search.

2. Select the name you want to call and press the

Talk Button.

2. Select the desired contact, then press down the

Navigation Button to display all the information

for that contact.

3. Select the number you want to call, then press the

Talk Button.

NOTE: For more information about Contact list

abbreviations and Contact, please see section 2.3.

To change the default number for a Contact:

1. In the Home screen or the Start menu, select

Contacts.

2. Select the contact＞scroll the Navigation Button left or right to change the default number.

The abbreviation at the right side of the list indicates the default number. For example, if you change “w” to “m,” the default number changes from Work phone (w) to Mobile phone (m).

 Make a phone call using a recently dialed

number

1. Home screen＞press the Talk Button to display a list of recently-dialed names/numbers.

2. Select the item you want to dial＞Talk Button

 Make a phone call from the Call History list

1. Start menu＞Call History

2. Select the number or name you want to call＞Talk

Button.

 Make a phone call from a hyperlink When you see an underlined phone number presented

as a hyperlink in an E-mail message, just scroll to it,

Chapter 2 Use Your Smartphone

and press down the Navigation Button to make the phone call.

 Make emergency calls You can call emergency service numbers under any

circumstances, even if you have locked the SIM card and/or your phone. Dial the emergency number appropriate for your location, and press the Talk

Button.

2.2 Receive a Phone Call

When there is an incoming call, the name and number of the caller are displayed on the screen. If the name of the caller is not in your Contacts list, only the caller's phone number is displayed. You can answer a call by pressing the Talk button or select Answer. If don't want to take the call, select Ignore (Note that selecting

Ignore will connect the caller to your voice mail box, if

you have subscribed to this service.)

NOTE: This is the default display for incoming calls. See the next section if you want a photo you have associated with the caller to be displayed on your screen during incoming calls.

Chapter 2 Use Your Smartphone

When a phone call is in progress, you may select Menu to execute advanced commands.

Not all of the service provider support the Conference function. Please refer the service to the service provider.

Switch on/off the Speakerphone

Use the built-in speakerphone function, you may place the Smartphone away from your face as long as you can hear the voice from the loud speakers.

y When a phone call is in progress, select Menu＞

Use the Hold function

To hold a phone call, select Menu＞Hold. The

icon will flicker on right side of the Title Bar. To

unhold the phone call, select Menu＞Unhold or press

Speakerphone On. The

icon will show on the

screen.

y To switch off the speakerphone, select Menu＞

Speakerphone Off.

Otherwise, you may press and hold the Talk button to

the Left softkey to select Unhold on the screen.

Use the Conference function

1. You may hold a call, and then dial the second phone number or answer another incoming call when a phone call is in progress.

2. Select Menu＞Conference

switch on/off the Speakerphone.

NOTE: Don’t hold your Smartphone closing to your ears when using the Speakerphone function to avoid damage to your hearing.

Use the Mute function

You may mutef the microphone when a phone call is in progress, so that you can hear the other party’s voice

Chapter 2 Use Your Smartphone

and while the other party can’t hear your voice. y To mute the microphone when a phone call is in

2.3 Use Contacts and Beam

You can think of Contacts as an online address book, where you can store information about people and

progress, select Menu＞Mute. The

icon will

show on the screen.

y To Unmute, select Menu＞Unmute to turn on the

microphone.

Otherwise, you may press Left softkey to select Mute on the screen to switch on/off the microphone.

businesses you communicate with in contact cards. For example, you can store multiple phone numbers, E-mail and street addresses, Web pages, birthdays, anniversary dates, etc. You can use Contacts to dial phone numbers and compose E-mail and SMS messages directly from a contact card.

 The Contact list The Contacts list displays the names of your contacts

Answer a second call using Call Waiting

If you are already talking on the Smartphone when you receive another call, the Call Waiting screen will appear.

Task Directions

place the current call on hold and answer the incoming call End the first call before answering the incoming call Swap the first call and the second call

Reject the second call (connected to your voice mailbox)

Select Answer or

Press ＞Answer or

Press Swap

Press

alphabetically, along with an abbreviation for the default communication method, such as the person's work phone number (w) or home phone number (h). This makes it easy to reach the contact using the method you prefer. Note that if the contact entry includes a work phone number, your phone will automatically set it as the default number.

To access your Contacts:

You may access your Contacts in the method as follows:

x In the Home screen, press the Right Softkey to

open the Contacts list directly.

Chapter 2 Use Your Smartphone

x Select Contacts from the Start menu

x Select the Contacts icon from the “most recently

used” icons in the Home screen

A sample Co ntacts listing is shown below.

The following table shows some of the abbreviations that might be displayed in the Contacts list, and their meanings.

Abbreviation Meaning

w w2 h h2 M pgr car txt e e2 e3 co rdo ast im im2 im3

Work phone Work2 phone Home phone Home 2 phone Mobile Home Pager Car phone Text message E-mail E-mail 2 E-mail 3 Company phone Radio phone Assistant phone Instant message Instant message 2 Instant message 3

To call a contact using the default number:

1. In the Home screen, select Contacts to directly

open the Contacts. Or form the Start menu, select

Contacts.

Chapter 2 Use Your Smartphone

2. Scroll to and highlight the contact you want to call.

3. Press the Talk button. The phone dials the contact's default phone number. The abbreviation for this number appears to the right of the contact name.

NOTE: If you want to change the default number, select the desired Contact entry and scroll left or right to select the abbreviation you want to assign as the default.

To call a contact using a number other than the default number:

1. Select the contact on the list. Scroll the Navigation

Button left or right to display the abbreviation for the

number you want to use.

2. Press the Talk button.

To find a contact by entering a name:

Begin entering the name of the contact to find until the name is displayed. For example, to find "Linda," enter 5, 4, 6, 3, 2 because these numbers correspond to the letters for that name.

To filter contacts:

1. Select Filter from the Menu.

2. Select the category whose entries you want to display, such as All Contacts, Recent, No

Categories, Business, Holiday, Personal, or Seasonal. Only the contacts assigned to the

category you select are displayed on the list.

To create a new contact:

1. When the Contacts list is displayed, select New, or select New Contact from the Menu.

2. Af ter entering the desired data, select Done.

To delete a contact:

Select the desired entry in the Contacts list, then select Delete Contact from the Menu.

Chapter 2 Use Your Smartphone

 Contact cards

To view a “contact card,” select the desired contact in the list and press down the Navigation Button.

A contact card displays all of the information that you have entered for that contact. You can use the menu to edit it, send a text message, save it to your SIM card, beam the Contact, delete it, or add it to speed dial.

To view and edit an existing contact card:

1. Select the desired entry from the Contact list.

2. Press down the Navigation Button to view the contact card. If you wish to modify it, select Edit from the menu.

To call a contact from a contact card:

1. Select the desired entry from the Contact list. Press down the Navigation Button to access that contact card.

2. Scroll the Navigation Button to select the number you want to call.

3. Press down the Navigation Button or select Call to dial that number.

To send E-mail from a contact card:

1. Select the desired entry from the Contact list. Press down the Navigation Button to open the related contact card.

3 Scroll to Send e-mail, and then select E-mail (press

the Right Softkey) to go to the Messaging screen.

4. Select Outlook E-mail on the screen. Enter a subject, compose your message, and then select

Send.

 Use contact card menu options Select the desired contact on the list, then press the Action button to access the related contact card.

Chapter 2 Use Your Smartphone

Using the menu accessed from that screen, you can perform the functions illustrated below.

Command Function

Edit

Save to SIM

Send Text Message

Beam Contact

Delete

Add to Speed Dial

Modify information on the contact card. Save the contact to the SIM card. Send text messages from the Contact list. Send the contact card data to another mobile device or a desktop PC using Bluetooth Remove the contact card from the Contacts list. Create a shortcut to a phone number, E-mail address, or Web URL by assigning one or two numbers as a speed dial. (See section 2.7.)

 SIM contacts SIM contacts are stored on your SIM card. When you insert your SIM card into a different device, you can view and use the SIM contact information on the new device. Unlike regular contact cards, you can store only one phone number for each SIM contact.

To create a new SIM contact:

1. In the Home screen or from the Start menu, select

Contacts.

2. Open the Menu and select New SIM Contact.

3. Enter the Name and Number, then select Done. The new contact appears on your conta ct list. A SIM icon will display to the right of the name, indicating that the contact is stored on your SIM card.

Chapter 2 Use Your Smartphone

 Beam information You can use the Bluetooth on your Smartphone phone to send and receive (beam) contact information between your Smartphone and another mobile device or a PC that has Bluetooth.

NOTE: You cannot beam SIM contacts. See Chapter 5 for more information about Bluetooth.

To beam a contact:

1. In the Home screen or from the Start menu, select

Contacts.

2. Select the Contact entry you want to beam.

3. Select Beam Contact from the Menu in the

Contacts screen.

4. Scroll to the device to which you want to beam.

5. Select Beam.

Status information will then be displayed, indicating the name of the device to which your Smartphone is beaming, and whether the beaming process is pending or has failed.

NOTE: Make sure that both Bluetooth radios are turned On and that Bluetooth is Discoverable on the receiving device.

To receive beamed information:

1. Start＞Settings＞Connections＞Beam

2. Select the Receive incoming beams checkbox.

5. Select Done. Your Smartphone is now capable of receiving beams (until you clear the Receive

incoming beams checkbox).

Chapter 2 Use Your Smartphone

NOTE: Make sure your Bluetooth radio is turned On

and in Discoverable mode. Your Smartphone can receive beamed files of any type, but you may need to copy some files to your PC for viewing.

2.4 In-Call Options

Listed menu options below might be available when a call is in progress. Some of these options are only available during multiple calls or a conference call.

Option Function

End Hold Unhold Swap Save Contacts

Conference

Private

Speakerphone

Mute

Unmute

Disconnect the call. Place the active call on hold. Takes the call off hold. Switch between two calls Create a Contact record for the caller. Join together all existing calls, if you have subscribed to this service. Break one call out of a conference and make this call active while the rest of the conference is on hold. Switch the caller’s voice onto the loud speakers. Mute the microphone for the active call. The other callers will not hear anything you say, but you can still hear the other callers. Turn the microphone back on for the active call.

Chapter 2 Use Your Smartphone

2.5 Retrieve a Voice Mail Message

When In the Home screen, press and hold 1 (varies with operator) to call your voice mailbox, and follow the prompts to retrieve your messages.

NOTE: This is actually a Speed Dial (see section 2.7). Speed Dial 1 is re served for voice mail access and the number is configured in your settings.

The oldest calls are automatically deleted from the list to make space for the newest calls.

2.6 Review your Calls

Using Call History and Call Timers, you can view information about phone calls that you have made, received, and missed.

 Call History

Call History displays the last 36 calls that you have

made, received, and missed. Each recorded call contains the caller's name and the number, if available, the duration, the start time, and date. (Shown as the left picture next page.)

To filter the list:

Start＞Call History＞Filter＞select the desired

category from the submenu including Missed Calls,

Incoming Calls, and Outgoing Calls. (Shown as the

right picture above.)

Chapter 2 Use Your Smartphone

Other commands on the menu in the Call History screen besides Filter:

Option Function

Find Contact Send Text

Message E-mail

View Timers

Delete Delete List

Save to Contact

View related Contact information. Send text massage to the contact. Switched to the Messaging screen to

send e-mails. Opens the Call Timers screen. See the subsection below for details. Remove the selected item from the Call

History.

Remove all items from the Call History. Create a new Contact using the info related to the selected item in Call History.

 Call Timers

Call Timers displays detailed information re garding the

length of your last call, the total time of calls made and received, calls by type (incoming, outgoing, roaming, and data), and a lifetime counter.

To access the Call Timers screen:

Start＞Call History＞Menu＞View Timers

Call Timers is useful for keeping track of your calling

patterns. It can help you estimate your monthly bill. You can reset Call Timers to zero from Menu to start timing calls for a new monthly billing cycle.

Chapter 2 Use Your Smartphone

2.7 Speed Dials

You can create “Speed Dials” for frequently-called phone numbers by pressing and holding specific keys. You may choose Speed Dial entries from 2-99; Speed

Dial 1 is reserved for voice mail access and configured

in your settings.

 Create a Speed Dial for a phone number

1. Home screen or Start menu＞Contacts.

2. Select the desired Contact entry＞press down the

Navigation Button to access the Contact card.

3. Select the phone number for which you want to assign a Speed Dial.

4. Select Menu＞Add to Speed Dial＞Keypad

assignment.

5. Scroll the Navigational Button left or right to select

choices, or press down the Navigation Button to view the full list.

6. Select Done to save the new Speed Dial.

You can also create Speed Dials for an E-mail address, an instant message, a call paper, a fax number, or a Web page address (URL) t hat is stored in Cont acts or a program on the Start menu.

 Make a call using a Speed Dial When in the Home screen, press and hold the number

that you have assigned as a Speed Dial for a number.

If the Speed Dial number con si sts of two digits, press the first digit and then press and hold the second digit.

Chapter 2 Use Your Smartphone

 View Speed Dials you have created In the Home screen, select Speed Dial from the Start

menu. All Speed Dial entries will be listed. In addition, you can use the menu in this screen to perform the following:

Option Function

Dial the number, start Internet Explorer, or

Run

Find Contact

Delete Filter

invoke Messaging. Yo u may also select

Open the Contact card associated with the selected Speed Dial. Delete the selected Speed Dial entry from the list. Filter the list.

2.8 Advanced Dialing Information

The following information includes advanced dialing options useful for phone numbers requiring special dialing instructions.

 Insert an international country code To enter the plus sign, press and hold 0 until + appears.

International calls require a country code to be includ ed in the phone number. A plus sign (+) must appear first, followed by the country code and the rest of the phone number.

 Insert a three-second pause in a dialing

sequence

Some international calls require a three-second pause in the dialing sequence in order for the call to process successfully.

1. From the Home screen or Start menu＞Contacts.

2. Select the Contact entry in whose phone number you want to insert a pause＞press the Navigation

Button to access the Contact card.

3. Menu ＞Edit＞select the specific phone number in which you want to insert the pause.

Chapter 2 Use Your Smartphone

4. Press the Navigation Button left or right position the cursor within the number where you want to insert a three-second pause.

5. Menu＞Insert Pause＞Done

 Insert a manual pause in a dialing sequence There may be phone numbers that require a pause

longer than three seconds in the dialing sequence. For these cases, you can pause as long as you want, and manually continue the dialing sequence using the

Talk Button.

Follow the same steps outlined in “Inserting a three-second pause in a dialing sequence,” except in

Step 5, select Insert Wait from the menu. The letter

“w” will appear in the number for your reference, to show where the indefinite pause will occur in the dialing sequence.

Note: Don’t forget that when you call a number containing a “manual pause,” you will ne ed to press th e

Talk Button to continue dialing.

Chapter 3 Use Your Camera

Chapter 3

Use Your Camera

3.1 Use the Camera

3.2 Use Pictures & Videos

3.1 Use the Camera

You can capture still images in Still mode, or switch to

Video mode to capture live video streams (with audio if

desired.) You may send the captured files via E-mail,

MMS, or Bluetooth.

 Invoke Camera mode Switch to Camera mode on your Smartphone by using the methods shown as below:

• Press the Camera Button on the right side of your Smartphone. The live incoming video stream will be shown on your screen.

If you have not yet started the Camera application, the Still capture mode will be active by default. If you previously started the Camera in the current session, the most recently used capture mode will be active.

• Start＞Pictures & Videos＞Camera

NOTE: Newly-captured files are stored in your \My

Documents\My Pictures folder by default. Normally,

the first time you capture a still image or live video streams, a new My Pictures folder will be created under \My Documents, and the newly captured file will

Chapter 3 Use Your Camera

be saved there.  Capture a still image using Still mode

1. Switch to Still mode. (You will see the

icon shown near the lower right of the screen, and the number of images you still can capture, according to available memory and your current settings.)

2. Position the camera lens to capture the desired

4. Press the Camera Button, or press down the

Navigation Button to capture images.

The options of menu in Still mode:

Option Function

Video Switch to Video mode Mode

Normal/Burst/Timer

The capture mode

image. You may scroll the Navigation Button up/down to zoom in/out. (The current zoom ratio is shown near the lower right of the screen.)

Brightness

+3/+2/+1/ 0/-1/-2/-3

Resolution

QQVGA/QVGA/VGA/SXGA

Zoom

zoomX1/zoomX2/zoomX4

White Balance

Automatic/Sunny/Cloudy/Night/ Black & White/Sepia/Negative/ Fluorescent/Incandescent

Flash

On/Off

Select suitable brightness for capturing.

The zoom capability depends on the resolution

SXVGA VGA QVGA QQVGA

Adjust for various lighting conditions

Switch on/off the flash

1X 1X, 2X 1X, 2X, 4X 1X, 2X, 4X

3. Select Menu to choose advanced capturing settings shown as the right picture above. (The items of settings are specified as the table next page.)

Options

General/Slide Show/Camera/ Video

Specify the saved files, output format, or other settings in different mode.

Note: “1X” indicates normal (unzoomed) size.

Chapter 3 Use Your Camera

To review the newly-captured picture:

A review screen will appear immediately after you have captured a picture.

You may press the Left Softkey (“Camera”) to switch to Still mode, or press the Righrt Sofykey (“Menu”) to execute other commands, including Delete, Send,

Beam, Use as Home Screen, Edit, Properties, and Options.

The details of these commands are shown as the table next page.

Command Function

Delete Send

Beam

Use as Home Screen

Edit

Properties

Options

Delete the reviewed picture Go to Messaging to send the picture. Beam the reviewed picture to another device via Bluetooth. Set up the reviewed picture as Home

Screen. You may select the display

area and adjust the transparency.

Rotate, Crop, or Auto Correct the

reviewed picture, and Save As another file. Rename or view the properties of the reviewed picture, including File Type,

Dimensions, File Size, Date Created,

or Protected status. Specify the saved files, output format, or other settings in different mode.

 Capture a video using Video mode

1. Switch to Video mode. (You will see the

icon shown near the lower right of the screen, and the length of time you still can capture, according to available memory and your current settings.)

2. Position the camera lens to capture the desired image.

Chapter 3 Use Your Camera

The options of menu in Video mode:

Option Function

Still Switch to Still mode Brightness

+3/+2/+1/ 0/-1/-2/-3

Select suitable brightness for capturing.

3. Select Menu to choose advanced capturing settings shown as the right picture above. (The items of settings are specified as the table next page.)

4. Press the Camera Button, or press down the

Navigation Button to start or stop capturing (you

may stop by pressing the Left Softkey or pause by pressing the Right Softkey.)

Quality

QQVGA/QVGA

White Balance

Automatic/Sunny/Cloudy/Night/ Black & White/Sepia/Negative/ Fluorescent/Incandescent

Options

General/Slide Show/Camera/ Video

Capture size

Adjust for various lighting conditions

Specify the saved files, output format, or other settings in different mode.

Chapter 3 Use Your Camera

 Set various Options After you select Options from the menu, you can enter

different screens to customize various behaviors of

Camera mode, as follows:

In the General screen:

Item Selection

x Original size

When sending pictures in email, use this picture size:

When rotating a picture, rotate 90 degrees:

x Large (640X480) x Medium (320X240) x Small (160X120) x Left x Right

In the Slide Show screen:

Item Selection

During slide show, optimize for viewing:

Play screensaver when connected to my PC and idle for 2 minutes.

x Landscape pictures x Portrait pictures

x Check x No check

In the Camera screen:

Item Selection

x Main memory

(Files will be saved in \My

Save files to:

Type filename prefix:

Still image compression level:

Documents\My Pictures.)

x Storage Card

(Files will be saved in \Storage Card\DCIM)

x img (by default), or you may

enter desired prefix

x Normal quality x Low quality x High quality

In the Video screen:

Item

Include audio when recording video files.

Time limit for videos:

x Selection x Check

x No check x No limit x 15 seconds x 30 seconds

Chapter 3 Use Your Camera

3.2 Use Pictures & Videos

The Pictures & Videos application allows you to view pictures, play videos, send/beam/delete/edit the files, play slide show, etc. The commands will be detailed as follows:

 Manage your pictures and videos You can scroll to the pictures and videos to manage

them by selecting Menu in the Pictures & Videos screen. The commands are detailed as follows:

Command Function

Send

Beam

Save to contact Delete

Edit

Cut/Copy/Paste/New Folder

Play Slide Show Folders

My pictures/My Device/ Storage Card

Options

Go to Messaging to send the picture. Beam the reviewed picture to another device via Bluetooth. Save the picture as a contact’s photo Delete the reviewed picture

Manage the files. Display the pictures in Slide

Show mode Choose the folder you want to

explorer. Specify the saved files, output

format, or other settings in different mode.

 Play the Videos

1. In the My Pictures screen, select the picture you want to view.

2. Press down the Navigation Button, or select the

Left Softkey. (“Play”)

 View the pictures

1. In the My Pictures screen, select the picture you

Chapter 3 Use Your Camera

want to view.

2. Press down the Navigation Button, or select the

Left Softkey. (“View”)

When you view the picture, the Title Bar will show the file name of the picture. You may select Send to execute Massaging function, or select Menu to execute other commands.

To use the picture as Home Screen:

1. Menu＞use as Home Screen

2. To Select the display area, scroll the Navigation

Button left/right or up/down＞Next

3. To Adjust the transparency, scroll the Navigation

Button to select to percentage of transparency.＞ Finish

4. Then the picture will be displayed in the Home

Screen as the background image.

Besides the same commands introduced in the previous page, the other commands are detailed as follows:

To zoom the picture:

From Menu, select Zoom＞select Zoom in, Zoom out,

Fit to Screen, or Actual Size

Note: If you want to change the picture, you may also

go to Settings＞Home Screen＞Background image ＞scroll the Navigation Button left or right to select the desired picture.

Chapter 3 Use Your Camera

To edit the picture:

You may edit the picture by executing the commands of Rotate, Crop, Auto Correct, Undo, Cancel, or

Save as. The commands are detailed as follows:

Command Function

Rotate the picture 90 degrees left or right

Rotate

Crop

depending on the setting in Options＞

General.

1. To Position the first corner, scroll the

Navigation Button to the desired

position and then press down the

Navigation Button.＞Next＞Position the second corner in the same way.

2. Select Previous to reedit the picture, or select Finish to decide the final picture.

Auto Correct

Undo Cancel Save as

To save the picture

You may select Save to Contact to assign a picture as a contact’s picture, or select Save As to save the file as another name.

To view Properties

You can rename and view properties including File

Type, Dimensions, File Size, the date of Created Date, and Protected status.

The color of the picture will be corrected automatically. Undo the command. End the Edit screen. Save the file as another name.

Chapter 4 Personalize Your Smartphone

Chapter 4

Personalize Your Smartphone

4.1 Customize Smartphone Settings

You can easily view and change various settings in your Smartphone. For example, you can use your favorite photo for the Home screen background, set up Call Forwarding to manage your calls more efficiently, define the Right Softkey to invoke different applications, and much more.

Select Settings from the Start menu. The items in the

Settings screens are detailed below.

4.1 Customize SmartPhone Settings

4.2 Customize Profiles and Sounds

4.3 Customize Date and Time

4.4 File Explorer

Note: If you press 9 (“More”) in the first Settings screen, the second Settings screen (shown above on the right) will display.

Chapter 4 Personalize Your Smartphone

 Phone When you select Phone in the Settings screen, the

Phone screen appears and offers the following

options:

Call Barring

Block incoming and/or outgoing calls.

Call Forwarding Forward calls to another number.

Call Options

Specify your Voice Mail number, Country code, and Area code. If you check the Any key

answer checkbox, you will be able to answer

incoming calls by pressing any key. If Show SIM

Contacts is checked, entries on the SIM card will

be displayed in your Contacts list.

Call Waiting

Turn the Call Waiting function on or off.

Caller ID

Let your identification be known to all callers, to only the people in your contacts, or to no callers at all.

Channels

Configure cell broadcast.

Fixed Dialing

Limit your calling area to one or more specific phone numbers and/or area codes.

1. Check the Enable fixed dialing box

2. Select Menu＞Edit Numbers＞Menu＞Add

3. Enter the number in the Number pattern field.

Note: If you enable the Fixed Dialing function, you will unable to save new contact to the SIM.

Networks

Identifies your current network, and allows you to change your network selection from Automatic to

Manual.

 Home Screen Home Screen settings are used to change the Home screen layout, the color scheme, the background image, and the time delay before the Home screen appears when your Smartphone is idle.

＞Done

Chapter 4 Personalize Your Smartphone

To view or change these settings, select Settings＞

Home Screen. Windows Default is the default

setting in the Home screen layout field.

Note: The images available for selection in the

Background Image field are those currently in the My Documents folder of your Smartphone.

 Start menu Select Settings＞Start Menu to select the display of Start menu. You may switch list view or grid view; hide or show the icon label; turn the highlights of the icons on or off.

 Connections Please see chapter 5 for usage of this setting.

 Security Please see chapter 1.7 for usage of this setting.

 Remove Programs This feature allows you to delete any application software from your Smartphone that you installed. When you select Settings＞Remove Programs, the programs you have installed will be listed in the

Remove Programs screen. Select the one you want

to remove, then select Remove from the menu.

Note: You cannot use this feature to remove any of the core programs that came with the Smartphone, such as Contacts, Calendar, Internet Explorer, etc.

To add programs to your Smartphone, follow the instructions as follows:

1. Download the programs into your PC.

2. Connect your Smartphone and PC.

3. Double Click the *.exe file quickly.

Chapter 4 Personalize Your Smartphone

x If the execute file is a setup wizard, please follow

the instructions to install the program. After installation, the setup wizard will transmit the program to the Smartphone automatically.

x x If the setup wizard isn’t invoked, you need to copy

the program file to the Program Files folder of your Smartphone.

 Power Management Select Settings > Power Management to check the current battery level in the form of a percentage. You may also adjust various power-saving settings, including Backlight time out on battery, Backlight

time out on AC, Display time out, Keypad backlight time out.

 Accessibility Select Settings＞Accessibility to view or modify your settings for System font size, Multipress tme out,

Confirmation time out, and In-call alert volume.

 Flashlight Select Settings＞Flashlight to switch On/Off the flashlight. The function facilitates you to have a handy light in the dark environment.

 Animation Select Settings＞Animation to turn On/Off the Start-Up Animation.

 Format Select Settings＞Format to format the Storage Card.

 Regional Settings Select Settings > Regional Settings to adjust

Language, Locale, Short Date style, Long Date style, Time format, Positive and Negative number, Positive and Negative currency. After changing the

settings, you must power your Smartphone off and back on to make the changes take effect.

Note: When changing languages, it is possible that not all applications will be displayed with the new language because of the default “language set” in your Smartphone.

 Owner Information Select Settings > Owner Information to enter your personal information such as Name, Telephone

number, and E-mail address. This is helpful, for

example, in the event that you lose your Smartphone, so that you can be contacted if it is found. In the Owner Information screen, there is also a Notes field in

Chapter 4 Personalize Your Smartphone

which you can enter any other miscellaneous information, if desired.

 Certificates On your Smartphone, you can add and delete public key certificates. These certificates help establish your identity when you log on to a secure network, such as a corporate network. Certificates also help establish the identity of other computers, such as servers, with which you connect. This helps prevent unauthorized users from accessing your device and its information.

You can store two types of certificates on your Smartphone: Personal certificates that establish your identity, and Root certificates that establish the identity of servers with which you connect. Your Smartphone may include a set of pre-installed certificates.

Certificates that establish your identity:

Select Settings＞Certificates＞Personal, then select

View from the menu to view the selected certificate, or Delete to delete it.

Certificates that identify servers you've connected to:

Select Settings > Certificates > Root. Select the desired certificate in the list, then select View from the menu to view the details of the selected certificate (or Delete to delete it).

 About Select Settings＞About to display information about your Smartphone's operating system such as version numbers, copyright information, processor, total/available storage, and total/available memory.

 Error Reporting Select Settings＞Error Reporting to enable or disable Error Reporting.

Chapter 4 Personalize Your Smartphone

4.2 Customize Profiles and Sounds

 Sounds Sounds settings are used to customize the sounds for ring tones, notifications, and reminders.

Select Sounds in the Profiles screen. You can specify what sound file to use for the following functions:

• Ring tone (line 1 and line 2)

• Reminders

• New e-mail

• New text message

• New voice message

• New instant message

• New channel message

• Alarm clock

• SIM toolkit messages

• Exclamation

• Question

• Warnings

• Keypad control

After selecting one of the fields above, you can scroll the Navigation Button left or right to select sounds. Or, press down the Navigation Button to open the

Select an Item screen to view the entire list of sounds

available for that field, and select from that list. You can use the menu in the Sounds screen to Play or

Delete Sounds. Select Done to save all changes.

To set up your own ring tone:

1. Copy the MP3 files from the PC into your Smartphone. Open ActiveSync, select Explorer, find the My Documents folder and paste the MP3 files.

2. In the Sounds screen＞Ring tone for line 1 (or2).

3. Scroll the Navigation button left or right to select

the desired MP3 song in the field＞Done, then the new ring tone is set.

 About Digital Right Management (DRM)

Chapter 4 Personalize Your Smartphone

Digital Right Management is for protecting the right of the digital content. Due to the digital right management, you may not be able to play some of music on your computer or this product. In the mean time, you are also unable to copy the music from this product to other devices directly.

 Profiles You can choose each of the Profiles of announcing you the incoming phone calls, messages, or upcoming events. Select Profiles in the Settings screen to access the screen shown below. All available profiles are listed, and the active profile is indicated by a check mark to the right.

can choose the Meeting profile, which turns off your system sound volume and ring volume, notifies you of incoming calls via vibration, etc.

The following table illustrates the profiles that come with your Smartphone, and their default attributes.

Profile

Name

Normal

Silent

Meeting

Outdoor

Automatic

Ring

Type

Volume

Ring 3 Increasing 3

Silent Off

Vibrate Off Vibrate Off Vibrate Off Off

Ring Loud Increasing Loud

Alarm

Type

sound

Switch between the Normal profile and Meeting Profile when the calendar shows busy status.

Play

Alarm

Volume

Off

Notification

Type

Play sound

Notification

Volume

3 3

Off Off

System

Sound

Volume

For example, when you are attending a meeting, you

Headset

Car

Speaker

phone

Ring 3 Increasing 3

Ring 4 Increasing 4

Ring Loud Increasing Loud

NOTE: The Headset profile and Car profile both have an additional field (Auto-answer) which lets you optionally specify a number of seconds for the Smartphone to automatically pick up the incoming calls.

Play sound

3 3

4 4

Loud Loud

Chapter 4 Personalize Your Smartphone

To modify the attribute of the profiles:

1. Select the profile you want to modify.＞Menu＞Edit

2. You may rename the existing profile, or scroll left or right to select the desired attribute in each of the item.

If you later want to restore the settings back to the default attributes, select Reset to default in the Menu.

NOTE: You may also select a different profile using the

Quick List. To display the Quick List screen, press

the Power Button on your phone and release quickly. Scroll to the desired profile and then press the Action button to select it.

4.3 Customize Clock and Alarm

Select Clock & Alarm from the settings screen. The

Date and Time and Alarm screen will open as shown

below. It allows you to change your time zone, date, time, set an alarm time, and turn the alarm feature on or off.

Chapter 4 Personalize Your Smartphone

4.4 File Explorer

Select File Explorer from the Start menu to invoke the

File Explorer application which provides many

easy-to-use features for file and folder management. It operates in either the List View or Icons View (shown as the pictures below).

List View Icons View

Menu Commands in File Explorer

Selection Display

Send

Beam Edit

Cut/Copy/Paste /Delete/Rename /New Folder

Properties

Name/Location/Type/ Size/Created time.

View

Icons/List

Sort by

Name/Date//Size/Type

My Device Storage Card My Documents

Go to the Messaging screen to send the file to someone. Beam the file to another Bluetooth device.

Edit the files in your Smartphone.

View the related information of the file.

Switch the View of the file folders. Allows you to sort the items on the

list by the options.

Change the folder to view

Chapter 5 Get Connected

Chapter 5

Get Connected

5.1 Connect to the Internet

5.2 Pocket Internet Explorer

5.3 Bluetooth

5.4 Modem Link

5.5 Wireless Manager

5.1 Connect to the Internet

When in the Home screen, select Settings＞

Connections to access the Connections screen.

The settings in this screen enable you to set up Dial-up,

GPRS (General Packet Radio Service), Proxy, and VPN (Virtual Private Network) connections so you can

connect to the Internet or your corporate network.

With the GPRS connection, you can browse the Web, download E-mails, chat using MSN Messenger, or synchronize wirelessly with the server . Check with your service provider to see if a data connection has already been set up for you, and if over-the-air configuration is supported.

Chapter 5 Get Connected

 Dial-up Connections You need to set up a dial-up connection to connect directly to the Internet or to your corporate network.

To create a dial-up connection to the Internet:

1. In the Home screen, select Settings ＞

Connections＞Dail-up＞Menu＞Add

2. In the Add Dailup screen, enter a name for the connection in the Description field.

3. In the Connects to field, select The Internet.

4. Enter the appropriate information for the remaining fields, and select Done.

To create a dial-up connection to your corporate network:

1. When in the Home screen, select Settings ＞

Connections＞Dail-up＞Menu＞Add

2. In the Add Dailup screen, enter a name for the connection in the Description field.

3. In the Connects to field, select Work.

4. Enter the appropriate information for the remaining fields, and select Done.

In the same way as above, you may choose the following in the Connections screen, then select Add from the menu to add new connections:

 VPN Connections A VPN conne ction is u se d to access your corporate network using an existing Internet connection.

 Proxy Connections A Proxy connection i s used to access the Internet using an existing connection to your corporate or a WAP network.

 GPRS Connections If there is a GPRS coverage in your area and you have subscribed to the service, you may set up a GPRS connection to access your corporate network or the Internet.

Chapter 5 Get Connected

 Options After setting up the connection, you may go to Options to specify number of redial attempts, amount of idle time to wait before disconnecting, and type of connection your desktop has.

1. In the Connections screen, select Menu＞

Advanced＞Menu＞Options

2. Scroll the Navigation Button left or right to select the appropriate settings in the fields＞Press Done

 Add a URL Exception Some URLs for Web pages on your company Intranet may use periods, for example: intranet.companyname.com.

To view these pages on Internet Explorer, you must create a URL exception. Otherwise, the pages will not display.

NOTE: You do not need to create URL exceptions for Internet URLs.

1. In the Connections screen, select Menu＞

Advanced＞Menu＞Work URL Exceptions

2. Select Add from the menu.

3. In the URL Pattern field, enter the URL. Separate multiple URLs with a semicolon (;). Then select

Done.

5.2 Internet Explorer

Using Internet Explorer (IE), you can browse the World Wide Web on your Smartphone. IE supports HTML (Hypertext Markup Language), cHTML (com pact Hypertext Markup Language), xHTML, and WML 2.0. It also supports JScript, ActiveX controls, and CSS (cascading style sheets). The browser supports images and sounds, but it does not support frames on a Web page.

Start Internet Explorer

1. Home Screen＞Start＞Internet Explorer

2. Select one site in the list of Favorites＞Press down the Navigation Button＞Go

Enter a URL

Menu＞Address Bar＞enter the desired URL＞Go

View a list of recently-visited web pages

Address Bar screen, select View History＞select a

pre-visited site＞Go

Chapter 5 Get Connected

Press the Back Button on your Smartphone to return to a Web page you visited in the same session.

The Smartphone caches the Web pages that you view and stores them until the cache is full. It then replaces the oldest pages with the new pages. If you go back to a page that is cached on your phone, you will see the stored version unless you refresh the page to see the current version.

NOTE: While you are connected to the Internet, you can change between Internet Explorer and other programs on your Smartphone by pressing the Home

Button and invoking the program you want. This

does not close your Internet connection. Subsequently returning to Internet Explorer in the same phone session would re-display the most recently opened Web page.

Add a site to the Favorites list

You may mark the Web page you want to visit another time as a favorite.

1. When the desired Web page is open, select Menu

＞Add Favorite

2. The name and URL of the current page is already filled in. You may edit the Name field and Address

(URL) field if necessary. If you previously created

additional folders, select a folder in the Folder field.

By default, only the Favorites folder exists. To create a new folder in which to place URLs, select Add

Folder from the menu in the Favorites screen.

3. Select Add to add it to your Favorites.

To edit the Name, Address (URL), or Folder fields of an existing entry in your favorites, select the desired Favorite on the list, then select Edit from the menu.

To delete a favorite, select Delete.

Chapter 5 Get Connected

Change the display of the Webpage

1. When a Web page is open, select Menu＞View

2. Select one of the selections shown as below.

Selection Display

Display the content in one column. The

One Column

Default

Desktop

Full Screen Show

pictures

width of the column and the screen are the same. It means that you rarely need to scroll left or right. The display is similar to the desktop layout. You don’t need to scroll horizontally and still can view the most part of the Web page. The display is the same with the desktop layout. You need to scroll horizontally and vertically.

If you select the view option, a check will show beside the selection.

Send Link via E-mail

1. Open the Web page you want to send.

2. Menu＞Tools＞Send Link via E-mail

3. In the Messaging screen, select Outlook E-mail or

Text messages.

4. A new message is created and the Web site is concluded in the message content.

Select the font size

1. When a Web page is open, select Menu＞Zoom

2. Select font size including Largest, Larger, Medium,

Smaller, or Smallest.

View the properties of a Web page

You can view the information of a web site, such as the

Name, Address (URL), Type, Size, Protocol, Encryption, and Security Zone.

1. Open the Web page you want to send.

2. Menu＞Tools＞Properties

Customize Internet Explorer

You can customize Web browsing options, change the network to connect to, and make more memory available on your phone by clearing stored cookies an d Web pages.

In the Favorite screen, select Menu＞Options＞select either General, Connections, or Memory to view or edit. The details of Options are shown as below.

Chapter 5 Get Connected

Option Function

Select if Play sounds, Warn when

changing to an unsecure page, Allow

General

Connections

Memory

cookies, Warm when page content is blocked by security settings. You may

also scroll the Navigation Button left or right to select Encoding. Select if Automatically detect settings, and select network. View the storage of Temporary Files,

Cookies, and History.

5.3 Bluetooth

Bluetooth is a short-range wireless communications technology. Devices with Bluetooth capabilities can exchange information over a distance of about 30 feet (10 meters) without requiring a physical connection. The software included with your Smartphone allows you to use Bluetooth to beam information such as files, contact cards, appointments, and tasks to other Bluetooth-enabled devices.

 Bluetooth mode Select Settings＞Connections＞Bluetooth＞select

On, Off, or Discoverable. The behavior of each of

these modes is summarized below.

On — The Bluetooth radio is turned on and you can use the Bluetooth features. But the Smartphone doesn’t allow detection by another device.

Off — The Bluetooth radio is turned off. You might want to turn the Bluetooth radio off at times to conserve battery power, or in situations where ra dio use is prohibited, like on the airplanes or in the hospitals.

Discoverable — The Bluetooth radio is turned on, and any other Bluetooth devices within range (about 10 meters) can detect your device and attempt to beam

Chapter 5 Get Connected

information to it, establish a bond, or use a Bluetooth service. In this mode, other devices can detect your device, whether or not a bond has been created. However, in order to receive a beam from another device, you must accept it on your device.

To Beam information via Bluetooth

1. Select the item you want to beam. The item may

be a contact, an appointment in the calendar, or work.

2. Select Menu＞Beam [an item]＞Select the

Bluetooth device

3. Select Beam

 Bonds A bond is a re lationship that you create between your Smartphone and another Bluetooth device in order to exchange information more securely . Creating a bond involves entering the same PIN (Personal identification number) on the two devices you want to bond. Once a bond is created, the devices recognize the bond and are able to exchange information without your entering a PIN again.

To create a bond:

Make sure that the two devices are within 10 meters of each other and that Bluetooth is in discoverable mode

on both devices.

1. Home Screen＞Start＞Settings＞Connections>

Bluetooth＞Menu

2. Select Devices＞Menu＞New. Your device searches for other Bluetooth devices and displays them on the list.

3. Select the device you wished to connect, then press down the Navigation Button to select it.

4. In the Passkey screen, enter a passkey of between 1 and 17 characters, and select Next.

5. Enter the same passkey on the other device.

Chapter 5 Get Connected

6. If desired, enter the name of the other device in Name, and select Next.

7. In the Services screen, select Done.

To accept a bond:

Make sure that Bluetooth is turned on and in the Discoverable mode.

1. When prompted to bond with the other device, select

Yes.

2. In the Passkey screen, enter a passkey of between 1 and 17 characters, and select Next. You must enter the same passkey that was entered on the device requesting the bond.

3. If desired, enter the name of the other device in Name, and select Next.

4. Select Done. The bond is now created. Now you

can exchange information with the other device.

To delete a bond:

1. Settings＞Connections＞Bluetooth

2. Select Devices from the Menu.

3. Select the bond you want to delete＞Menu＞Delete.

5.4 Modem Link

Using Modem Link, you can use your Smartphone as an external modem for another device or computer by using a bluetooth or USB connection.

 Set up the Smartphone as a modem

1. Select Start＞More＞Accessories＞Modem Link.

2. Select USB in the Connection field.

3. Select Access point name. (Please consult the service provider the appropriate Access point name.)

And then select Activate.

4. Connect your Smartphone to your computer via USB cable. (The ActiveSync program will stop automatically.)

5. If prompted to install a driver, use the modem drivers provided on the companion CD. Follow the wizard to install the device.

6. In the Found New Hardware Update Wiz ard screen, select Install from a list or specific

location (Advanced)＞Next.

Chapter 5 Get Connected

7. Insert the companion CD to the CD-ROM drive. Select Search for the best driver in these

locations.

8. Check the “Include this location in the search:” box＞Browse＞Select the CD-ROM drive or the folder the driver locates＞Next.

9. After installation, click Finish.

 Create a new connection

1. Create your connection on the PC’s desktop by selecting Start＞Control Panel＞Network

Connections＞File menu＞New Connection

2. The New connection Wizard screen displays, and then select Next to create a new connection.

2. Select Connect to the internet＞Next

3. Select Set up my connection manually＞Next

4. Connect using a dial-up modem＞Next.

5. Type the name of your ISP in the ISP Name box＞

Next.

6. If you connect to the Internet by using GPRS, use the dial up numbers (e.g.＊99#) provided by the service provider to dial＞Next.

7. Type an ISP account name and password＞Finish.

NOTE:

You may need to add a string of commends in the Extra initialization commands box (e.g. A T+CGDCO NT=1,"IP","internet") on your PC und er My

Computer＞Property＞Hardware＞Device Manager

＞Modems＞Smartphone Modem Link＞Property＞

Advanced.

Chapter 5 Get Connected

 Dial-up and connect to the Internet

1. Select Start＞Control Panel＞Network

Connections＞Choose the dial-up connection.

2. A connection screen displays＞Enter Password (if necessary)＞Dial.

3. Invoke the Internet Explorer on your PC, and then you cam start to surf the internet.

5.5 Wireless Manager

Wireless manager is like the central switch facilitating you to switch on or off the Smartphone wireless functions.

 Switch on/off the Bluetooth function or have it

discoverable.

 Switch on/off the Phone (GSM) function, this will set

the phone into the flight mode.

Scroll to the corresponding selections and press down the Navigation Button to change the state of the wireless functions.

To execute advanced settings, select Menu＞

Bluetooth Settings or Phone Settings＞Change the

settings＞Done.

Chapter 6 Messaging Features

Chapter 6

Messaging Features

6.1 Set up Accounts

6.2 Manage Accounts

6.3 Send E-mail and Text Messages

6.4 Receive E-mail and Text Messages

6.5 View Message Folders

6.6 Instant Messaging

6.7 MMS Messaging

6.1 Set up Accounts

Your Smartphone is equipped with messaging features such as the functions to send and receive E-mail, Text message, and MMS (Multimedia Messaging). It also allows you to view and manage your message folders, customize message notifications and use MSN Messenger to communicate with others. Please note that not all E-mail services allow users to set up POP3 on mobile devices. Consult your network administrator or service provider for more information.

 Configure E-mail accounts You can send E-mail messages by synchronizing or by connecting directly to an E-mail server through your Internet service provider or a corporate network.

To set up an E-mail account:

1. When in the Home Screen, select Start >

Messaging

2. Select Outlook E-mail＞Menu＞Options＞

New Account

3. Enter your display name for this E-mail account, and your E-mail address＞Next.

Chapter 6 Messaging Features

NOTE: Before configuring E-mail on your Smartphone,

you must have an E-mail account. You will also need to configure your Smartphone's connection, as described in Chapter 5.

4. Leave the Auto setup box checked to obtain E-mail setting from the Internet. Your Smartphone will make an Internet connection and attempt to determine the server settings for E-mail.

NOTE: If the Auto setup couldn’t obtain e-mail settings, select Next to enter settings manually as following steps. If you are not sure what to enter, then consult with your network administrator.

5. Enter your user Name and Password. In Domain, enter the domain name (if necessary)＞Select Save

password＞Next.

NOTE: If your password is saved, you don’t need to

enter it each time you connect to your E-mail server. Please note that if you save your password and then lose your phone, your E-mail could be accessed by someone else.

6. In Server type, scroll to select the type of E-mail

server that hosts your mailbox (IMAP4 or POP3). In Account name, enter a name for this account. You must use a different name for each account that you set up.

7. In Network, scroll to the type of network that your

E-mail server runs on＞Next.

8. Enter information about your Incoming Server and

Outgoing Server＞Next.

9. Select the message download option＞Next.

10.Select the connection option＞Next

Chapter 6 Messaging Features

11. To begin using e-mail, select Finish and select

Send/Receive from the Menu.

6.2 Manage Accounts

Use and manage up to eight messaging accounts with your Smartphone.

 View the list of accounts In the Home screen select Start＞Messaging. The list of accounts is displayed and the number of unread messages in the Inbox of each account is shown in parentheses.

 Move between accounts If you have an account open, you can quickly switch to another account by scrolling right or left, or selecting

Menu＞Switch Accounts.

 Edit the account options

1. In the Home screen, select Start＞Messaging＞ select an account.

2. Select Menu＞Options＞Account Options＞Menu ＞Edit

3. Select the type of options to change＞Done

 Delete an account

1. In the Home screen, select Start＞Messaging＞ select an account.

2. Select Menu＞Options＞Account Options＞ Select an account＞Menu＞Delete

3. An Alert screen displays, and select Yes.

Chapter 6 Messaging Features

6.3 Send E-mail and Text Messages

You can start creating a new E-mail, SMS, or MMS (Multimedia Messaging) from Messaging. Only numbers input are allowed for SMS and MMS messages, and E-mail addresses for MMS and E-mail messages.

 Create a message

1. In the Home Screen, select Start＞Messaging.

2. Select Text Messages, Outlook E-mail, or MMS＞

Select＞New

3. In To, enter the recipient E-mail address or phone number. Insert a semicolon (;) between multiple addresses or numbers.

• Add Recipient from Contacts In To, select Menu＞Add Recipient＞Scroll to

the desired contacts＞Select.

• Check Names from Contacts

If the recipients or addresses are entered by

yourself, you may check if those are valid.

In To, enter the names＞Menu＞Check

Names

4. In Subject, enter a subject. This field does not

5. Enter the content of the message＞Send

If the Smartphone cannot recognize one or more recipient or the addresses are not valid, A Alert screen displays to advice you to check the information.

• Removed Recipient In To, select Menu＞Remove Recipient

appear for Text Messages.

• Insert predefined text into messages. In Subject, select Menu＞My text＞Scroll to the desired text＞Insert or press down the

Navigation Button.

Chapter 6 Messaging Features

• Insert voice notes or pictures into a message.

Select Menu＞Insert＞Select Voice Note or

Picture, and you will be prompted to insert

picture or start recording.

• Cancel a message

Start＞Messaging＞Choose an account＞ New＞Enter information in the message＞ Menu＞Cancel Message

• Save a draft of a message

You can save a draft of a message that you have composed to finish and send later. The message is stored in the Drafts folder of the account.

NOTE: E-mail messages are stored in Outbox and sent to recipients the next time you connect to your E-mail server and receive E-mails. Text messa ges are sent immediately.

When creating a message, you may go to Menu＞

Message Options to select Priority level, set Security options, and select Language.

Start＞Messaging＞Choose an account＞ New＞Enter information in the message＞ Menu＞Save to Drafts

• Reopen and send a message draft

Start＞Messaging＞Choose an account＞ Menu＞Folders＞Select Drafts＞Scroll to the

draft message to open＞Edit＞Edit the message＞Send

• Set up sending options

Start＞Messaging＞Choose an account＞ Menu＞Options＞Sending＞Check the

“

Include copy of original message when

replying to e-mail” box, or/and “Save copies of sent items” box.

Chapter 6 Messaging Features

You can send and receive SMS messages up to 160 characters in size. If an SMS message is longer than 160 characters, it is automatically sent in chunks as several small SMS messages, and is then unified as one SMS message after all of the small SMS messages have been received.

 Insert signatures into messages For each messaging account, you can specify a signature to be automatically inserted into messages that you send.

To specify a signature to insert:

1. Start＞Messaging＞Choose an account＞Menu＞

Options＞Signatures

2. Scroll left or right to switch to the account for which to specify a signature.

3. Select Use signature with this account.

4. Select Include when replying and forwarding. Otherwise, a signature is inserted only in new messages.

5. Replace the text within the Signature box with a signature to insert＞Done. The signature is inserted into messages that you send from this account.

To stop inserting a signature:

1. Start＞Messaging＞Choose an account＞Menu＞

Options＞Signatures

2. Select the account for which you want to stop inserting a signature into messages.

3. Clear the Use signature with this account checkbox＞Done. A signature will no longer be inserted into messages that you send from this account.

Chapter 6 Messaging Features

6.4 Receive E-mail and Text Messages

You can receive E-mail and Text messages through Inbox synchronization or by connecting to your E-mail server.

When an email message is received, the Smartphone play a sound and display an envelope icon on the top of the screen automatically.

By default, the Home screen also displays the number of unopened E-mail and Text messages. To quickly view the new messages, scroll down and select the message notification area on the Home screen, or select the Message soft key.

 Work with the message list Received messages are displayed and stored in the Inbox folder of the appropriate account. By default, messages are displayed in the sequence of the time you receive, allowing you to change the display order and date of sent messages.

View the Inbox message list

Home Screen＞Start＞Messaging＞Scroll to the

appropriate account＞Select＞Menu＞Folders＞

Inbox＞Select. The Inbox message list displays your

received messages.

Change message list display options

Start＞Messaging＞Choose an account＞Menu＞ Options＞Display＞Change the display options＞ Done

Mark a message as Read or Unread

Start＞Messaging＞Choose an account＞Menu＞ Mark as Read/Unread＞Press down the Navigation Button

If the message is marked as Read (or Unread), an unopened envelop icon

) shows in front of the message list.

(or an open envelop icon

Chapter 6 Messaging Features

Forward a message:

1. From an open message, select Menu＞Forward.

2. In To, enter the recipient E-mail addresses or phone numbers. Insert a semicolon (;) between multiple addresses or Phone numbers.

3. Optionally, you can enter an introductory message by scrolling to the message area, pressing down the

Navigation Button to insert a blank line, and

entering your text.

4. Select Send. Text messages are sent immediately. Email messages are stored in Outbox and sent to recipients the next time you synchronize or connect to your E-mail server.

Delete a message:

Start＞Messaging＞Choose an account＞Scroll to the

message to delete＞Menu＞Delete

Download a complete E-mail message or an attachment:

When you receive large E-mail messages and attachments, your Smartphone downloa ds only a portion of them. You can view the partial message or attachment and decide if you want to download the rest

of it. (You may set up the size you want to download first, please see section 6.1)

Start＞Messaging＞Choose an account＞Scroll to a

message or select the attachment in an open message ＞Menu＞Download Message

The complete message or attachment is retrieved the next time you synchronize or connect to your E-mail server and Send/Receive E-mail.

View an attachment:

In an open message containing a downloaded attachment, select the attachment. Note that you can open attachments only for files that are supported by the phone’s installed applications.

The attachment size is omitted from messages received from a POP3 E-mail server.

In the message list, messages with an attachment display an envelope icon with a paper clip, which looks like this:

Within a message, attachments are displayed as a list of hyperlinks at the bottom of the message, and are preceded by an attachment icon. The hyperlink

Chapter 6 Messaging Features

includes the file name and the size of the attachment. The following icons indicate the state of each attachment status:

Not downloaded

Marked for download Downloaded

6.5 View Message Folders

Each messaging account has a set of folders in which your Smartphone stores messages for each account.

Folder Function

Deleted Items

Drafts

Inbox

Outbox

Sent Items

Contains messages that you have marked for deletion.

Contains messages that you have saved before sending.

Contains received messages. Contains sent E-mail messages

awaiting synchronization, or messages that will be sent upon the next E-mail server connection. SMS messages are sent immediately over the network and appear in your SMS Outbox folder only for a few seconds.

Contains copies of the sent messages.

When you synchronize or send and receive E-mail, your Smartphone synchronizes any additional E-mail folders that you have created in Outlook on your desktop computer or on your E-mail server. It also synchronizes the messages contained in those folders, if the folders are marked for synchronization.

Chapter 6 Messaging Features

To view message folder contents:

Start＞Messaging＞Choose an account＞Menu＞ Folders＞Select the folder you want to view＞Select

To move a message to a different folder:

Start＞Messaging＞Choose an account＞Scroll to the

message to move＞Menu＞Move＞Select the folder into which to move the message.

To clear the Deleted items folder:

Start＞Messaging＞Choose an account＞Menu＞ Folders＞Scroll to Deleted items folder＞Menu＞ Clear Text Messages＞Select

To import SIM messages from a SIM card:

Start＞Messaging＞Choose an account＞Menu＞ Options＞Import SIM Messages＞Press down the Navigation Button

The commands in the folders:

Command Function

Delete Reply

Reply All

Forward Folders

Switch Accounts

Move Mark as

Read/Unread Download

message

Options

Send/Receive

Delete the selected message. Reply to the sender. Reply to the sender and all other people who received the message. Forward the message to other E-mail addresses. The folders in this account.

Switch between accounts. Move the selected message to another

folder. To mark the message as read or unread. Retrieve the entire E-mail message from

the E-mail server. Display a list of Inbox options that you can customize. Connect to your E-mail server to send and receive messages.

Chapter 6 Messaging Features

6.6 Instant Messaging

You can use MSN Messenger on your Smartphone to send and receive instant messages. MSN Messenger on your phone provides the same chat environment as MSN Messenger on your desktop computer. Features of this environment include:

• Sending and receiving instant messages.

• Seeing the status of others on your Messenger contacts list, or changing your own status (e.g., available, busy, out to lunch, etc).

• Inviting other people to a chat.

• Blocking contacts from seeing your status or

sending you messages.

 Use Pocket MSN MSN Messenger on your Smartphone provides the same chat/instant message environment as MSN Messenger on your desktop computer. Among other things, you can use it to:

NOTE: You need either a .NET Passport account or a Hotmail account to set up MSN Messenger. To set up a Microsoft .NET Passport account, go to: http://www.passport.com. Once you have an account, you need to create a connection on your Smartphone that allows you to connect to the Internet. For more information about creating connections, see Chapter 5.

To sign in and out of MSN Messenger:

1. Home screen＞Start＞Messaging＞Pocket MSN＞

MSN Messenger＞Sign In.

2. In E-mail address, enter the sign-in name that you use for Hotmail or your .NET Passport

Chapter 6 Messaging Features

3. In Password, enter your Hotmail or .NET Passport password.

4. Select Save password if you don't want to enter your password again next time.

5. Select Sign In.

6. To sign out, select Menu＞Sign out.

NOTE: If you do not sign out of MSN Messenger, you will remain on a data connection. This may result in additional charges from your service provider.

To add or delete an MSN Messenger contact:

In the MSN Messenger contacts list, select Menu＞

Add Contact. Add the Hotmail or .NET Passport

sign-in name of a person with whom you want to chat.

To delete an MSN Messenger contact:

In the MSN Messenger contacts list, select Menu＞

Delete Contact.

To send an instant message:

To reply to an instant message:

1. Select Menu＞Chats.

2. Select the name of the person sending the instant message. The message displays, along with a box for your reply.

3. Enter your reply and select Send. If you want to be able to receive instant messages at any time your phone is connected to a network, select Menu >

Options > Passport Acco unt > Run this program

when connection is available > Done.

To invite a contact to an ongoing chat:

From a chat, select Menu > Invite＞choose a contact. The contact receives an instant message and can join the chat.

To change between chats:

Select Menu＞Chats. In the list of ongoing chats, select the name of a contact with whom to chat.

To return to the contacts list:

From a chat, select Menu＞My Contacts.

Chapter 6 Messaging Features

To end a chat:

Select Menu＞End Chat.

To see who is already chatting:

Select Menu＞Chats.

To block or unblock an MSN Messenger contact:

In the MSN Messenger contacts list, select the contact's name.＞Menu＞Block. The contact will no longer be able to see your status or send you messages. To unblock the contact, select Menu＞

Unblock.

To change your status:

In the MSN Messenger contacts list, select your name. ＞Select a status description, such as Busy. This

status is displayed next to your name on the contact lists of your contacts.

To change your display name:

On the MSN Messenger contacts list, select Menu. Select Options＞Passport Account. In My display

name, enter your name as you want it to display in the

contacts lists of your con tacts＞Done.

6.7 MMS Messaging

You can use MMS to create, view , store, send, or receive multimedia messages that include text, photos, videos, or audio files.

 Invoke MMS To invoke MMS, please follow one of the methods as follows:

1. In the Home Screen select Start＞Messaging＞

MMS

2. In the Pictures & Videos screen＞Select one picture＞Menu＞Send＞MMS

3. From Camera application, after capturing pictures and videos, select Menu＞Send＞MMS

 MMS Settings

Select Start＞Messaging＞MMS＞New＞Menu＞

Options＞MMS Settings＞Scroll to the account to edit

＞Menu＞Select the desired command, including Add,

Edit, Delete, Select, or Cancel.

There are some fields for you to set up in the Edit screen or Add MMS Profile screen , including MMSC

Chapter 6 Messaging Features URL, Data Connections, WAP Gateway, IP Address,

Port, and Encoding. After editing, select Done.

The MMSC (“Multimedia Messaging Service Centre”) settings are normally pre-set to the appropriate values, and in most cases you will not need to change them.

 Edit Message Options You may edit the Send/Receive settings by selecting

Message Options from the Menu in the MMS screen

＞Send Options or Receive Options＞Edit the options.

 Create and send an MMS message You may create messages consisting of multiple slides. Each slide can contain a photo or video, audio (with photos only), and text. Messages will display similar to a slide show. You can then send your messages to other mobile devices or E-mail accounts.

1. Start＞Messaging＞MMS＞New

2. In the To, enter the recipient’s phone number or E-mail address. In the Subject field, enter a subject.

3. Insert a Picture, Video, Audio, and Text

To insert a Picture, Video, or Audio.

a. Select the Insert Picture/Video... or Insert

Audio box.

b. Press down the Navigation Button. All of your

available files will be displayed in a Thumbnail view.

c. Scroll to the photo, video, or audio you want to

attach＞Select.

NOTE: An audio file cannot be inse rted into a slid e which already contains a video file.

To insert text:

Scroll to the Insert Text... portion and manually enter the desired text.

If you want to insert a predefined text, select Insert

＞My Text from the Menu＞Choose desired text ＞Select Insert. You may select Edit My text

from the Menu in the Insert My Text screen to define your text.

4. Optionally, you may insert more slides by selecting

Menu＞Slides＞Insert. Another slide will be

created for you to compose.

Chapter 6 Messaging Features

Scroll the Navigation Button left/right to view the slides you’ve created.

All of the content you insert is included onto a single slide. The recipient will see the photo or video along with any text. Attached audio will play as well.

To preview the MMS message:

In MMS screen, select Menu＞Preview

To save the MMS message to Draft:

In MMS screen, select Menu＞Save to Draft

To change the Background Color:

In MMS screen, select Menu＞Options＞Background

Color＞Scroll to the desired color＞Select

You may edit the slides by select Menu＞Slides. The commands are shown as below:

Command Function

Insert Delete Next Previous

Move

Duration

Insert another slide Remove the selected slide Jump to the next slide. Jump to the previous slide Move the order of the slides Select the slide to move＞Menu＞Move ＞Scroll to the desired order＞Select Set up the slide duration in seconds.

5. Af ter finishing composing the message＞Send

The Menu accessed from the Select a Picture/Video screen contains the following commands:

Chapter 6 Messaging Features

Command Function

View

Camera Cancel

My Pictures My Device Storage Card

Play the selected video or display the selected picture. Lets you capture a new picture or video and attach it to the MMS slide. Return to previous screen.

Lets you choose a different folder from which you can select a photo or video to add to your message.

To use the Template:

To create a new MMS message from the Template

Gallery, select Menu in the MMS screen＞Template＞ Gallery＞Scroll to the desired template＞Select.

To save the current message in the template gallery, select Menu in the MMS screen＞Template＞Save

To send and receive messages:

If you select Never, your account is set up to receive/send messages manually and your message will be routed to the Outbox for sending. To send the message, go to the Outbox of the MMS account, and select Send/Receive from the menu.

If you select a period of time such as Every fifteen

minutes or Every two hours, you will automatically

get an administrator message in your MMS Inbox prompting you to send the message.

Chapter 7 Synchronization

Chapter 7

Synchronization

7.1 Use ActiveSync

7.2 Install ActiveSync

7.3 Exchange Server

7.4 Synchronize music, video and pictures

7.1 Use ActiveSync

Maintaining good data synchronization betwe en your Smartphone and your desktop or notebook PC is important. A tool is provided for sharing information called "ActiveSync" ActiveSync synchronizes information stored on your Smartphone to your PC or Exchange Server. It also allows you to share files between your Smartphone phone and your PC seamlessly.

When you perform synchronization, ActiveSync compares the information on your Smartphone with the information on your PC and/or Exchange Server, and updates all locations with the most recent information.

With ActiveSync, you can:

• Keep your Outlook information, Inbox,Calendar, and Contacts up-to-date by synchronizing your Smartphone with your PC.

• Copy/move files between your Smartphone and

your PC.

y Install new Smartphone software applications and

utilities.

Chapter 7 Synchronization

• Select and specify the type of information you want to synchronize. For example, you can choose how many future appointments to synchronize.

7.2 Install ActiveSync

Before synchronization is begun, you must install the ActiveSync 4.1 or above on your desktop or notebook PC. Use the Companion CD that came with your Smartphone.

1. Insert the Companion CD into the CD-ROM drive, and install the ActiveSync onto your PC. After finished installation, the Synchronization Setup Wizard will be invoked automatically.

2. Follow the instructions on the screen to finish settings,

a. Create the synchronization connection between

your Smartphone and PC.

b. Set up the connection between Your

Smartphone and Exchange Server, and synchronize the information by using Exchange Server directly. You need to assign the site, user name, password, and domain name.

3. Adjust the settings for a particula r type of information, click on the type and then select Settings. By default, Calendar, Contacts, Tasks, and Inbox will be synchronized.

7.3 Exchange Server

Before synchronizing information with a server, make sure all the requested server authentication information such as username, password, and the name of the Mobile Information Server are correct.

 Set up Exchange Server

1. On your Smartphone's Home screen, select Start＞

ActiveSync＞Menu >Add Server Source.

2. Enter the Server address as the server＞Next

If you want your Smartphone to save your password

so that you don’t need to enter it when connecting, select Save password.

3. Enter the User Name, Password, and Domain.

4. Choose the items to sync, including Contacts,

Calendar, E-mail, and Tasks＞Finish

5. Menu＞Options＞Scroll to Calendar or E-mail Select Settings＞Change the settings＞Done

Chapter 7 Synchronization

To begin synchronizing with the server, select Sync in the Active Sync screen and enter the p assword (If necessary).

 Schedule server synchronization You can create a schedule for automatically synchronizing information on your Smartphone with a PC or with an Exchange Server. To set up a synchronization schedule with an Exchange server, you must use ActiveSync on your Smartphone. You can schedule synchronization of your Smartphone on two separate schedules:

1. To edit schedule settings, your Smartphone must be disconnected from your PC.

2. On your Smartphone's Home screen, select Start＞

ActiveSync＞Menu＞Schedule

a. Select how often to synchronize in the Peak

time sync list.

Peak times schedule: To synchronize

during working hours or other times you experience higher mail volumes.

b. Select how often to synchronize in the

Off-peak time sync list.

Off-peak schedule: To synchronize during

times when you experience lower mail volumes. When you are roaming, you can synchronize manually to reduce roaming charges, or you can synchronize using the mobile schedules.

c. Select whether or not to synchronize on a

schedule on the Roaming sync list.

d. Select Sync outgoing items as they are sent to

synchronize every time you send E-mail.

5. Select Done.

Chapter 7 Synchronization

If you created a schedule for synchronizing while connected to a PC as well as a schedule for synchronizing remotely (wirelessly), your Smartphone synchronizes according to both schedules.

 Synchronize information via Bluetooth You may use Bluetooth to connect your Smartphone to the PC, and execute synchronization.

1. Follow the ActiveSync Help on your PC to set up the Bluetooth functions.

2.Home＞Start＞ActiveSync＞Menu＞Connect via

Bluetooth

NOTE: Confirm that the Smartphone and PC have

initiated the Bluetooth function and approached to each other.

7.4 Synchronize music, video and pictures

If you want to take your music or other digital media with you, ActiveSync works with Windows Media Player to synchronize music, video, and pictures with your device.

Other than selecting the Media information type in ActiveSync to be synchronized, all media synchronization settings must be set in Windows Media Player. Before media can be synchronized, do the following:

1. Install Windows Media Player 10 on the PC before synchronization.

2. Connect your Smartphone to the PC with a USB cable. If the device is also connected to PC using Bluetooth, you must end that connection before media can be synchronized.

3. Insert a 32 MB or larger storage card(mini SD card) on your Smartphone.

4. Set up a sync partnership between the storage

card and Windows Media Player.

5. The files will invoke synchronization on your

Smartphone. The next time you connect your Smartphone to the PC and use the Windows

Chapter 7 Synchronization

Media Player on your PC, the synchronization will start to execute automatically.

 Change Media synchronization settings Once you select the Media information type in ActiveSync to be synchronized, any of your favorite music, video and picture files on Windows Media Player playlists can be synchronized by ActiveSync. All you have to do is set up synchronization in Windows Media Player for those media files. You can change which media files are synchronized and set up sync partnerships with a storage card as follows:

1. Open Windows Media Player.

2. Click the Sync tab.

3. Select the storage card.

4. Click Set up Sync .

Chapter 8 Applications

Chapter8

Applications

8.1 Calendar

8.2 Tasks

8.3 Calculator

8.4 Voice Notes

8.5 Windows Media Player

8.6 Games

8.7 Java Manager

8.1 Calendar

Calendar is the scheduling program on your Smartphone, where you can create and view appointments. You can view your calendar by day, week, or month. When you create and edit appointments on the Calendar, your changes are reflected on your PC when you synchronize.

To create a new appointment:

1. On the Calendar screen, select Menu＞New

Appointment.

2. Enter information about the appointment＞Done.

NOTE: In the Reminder field, you can specify the amount of time prior to the appointment that you want to be reminded.

To edit or delete an appointment:

1. Select the desired appointment＞Menu＞Edit or

Delete.

2. If the appointment is recurring, select Yes to edit only the current occurrence, or select No to edit the series.

3. Make your changes and select Done.

Chapter 8 Applications

 View your schedule

You may view your schedule in three different views:

Agenda, Week, and Month. Agenda View is the

default view for calendar information. This view displays meetings and appointments scheduled for the current day.

All day appointment

The hours of the two meetings conflict

2. Press the Left Softkey or select the desired view from Menu to switch to the other views. You may select Menu to Go to Today or Go to Date.

All-day events

Morning appointments

Afternoon appointments

Morning & afternoon

appointments

 Customize the calendar view

Agenda View

Appointments are shown in chronological order according to start time. All-day appointments are shown as a single line on the top of the Agenda view.

To change view of the schedule:

1. Scroll the Navigation Button left or right to select a desired date/time.

You may select Menu＞Options on the Calendar screen to change viewing options for Calendar, such as specifying the first day of the week and the number of days per week to display, showing and hiding week numbers, and set an interval of Rimiders.

Select Start in the Home screen＞Calendar＞Menu＞

Options＞Scroll to the item to change and adjust it＞ Done

Chapter 8 Applications

 Beam Appointment You may beam the appointment to another Bluetooth Device. Select the event to beam＞Menu＞Beam

Appointment＞Select the Bluetooth device to beam to

＞Beam

8.2 Tasks

A task is a personal or work-related project, assignment, or errand to track through to completion. A task can occur once, or it can recur. A recurring task can repeat at regular intervals, or repeat based on the date you mark the task complete.

To start the Tasks application, select Tasks from the Start menu.

 The Task List The task list is your "things to do" list. When you create or edit tasks with Outlook on your PC and then synchronize with your Smartphone, additional task information may display . A task that has been marked as high priority is preceded by an exclamation mark, and one marked as low priority by a downward-pointing arrow. Overdue tasks are displayed bold and red. Note that if you synchronize tasks with your PC, completed tasks are removed from your Smartphone during

synchronization. They are then displayed in gray with a strikethrough on your PC.

To create a new task:

Select Start from the Home Screen＞Tasks＞Scroll up the Navigation Button to move the cursor to “Enter

new task here” field＞Enter the task name and press

down the Navigation Button.

To mark a task as Complete:

Select the desired task in the list (one whose checkbox is not checked) and then select Complete.

To change a completed task to Incomplete:

Select the desired task on the list (one that has already been marked as Complete with a checked checkbox) and then press the select Activate.

Chapter 8 Applications

8.3 Calculator

Calculator performs basic arithmetic, such as addition, subtraction, multiplication, and division.

To perform a calculation:

1. Select Accesories from the Start menu.＞

Calculator.

2. Enter the first number of the formula using the

keypad＞Options.

3. Select the type of calculation to perform: Add,

Subtract, Multiply, Divide, or Decimal Point.

• To insert a decimal point, press the asterisk (＊) key

on your keypad or select Decimal Point from

Options.

• To insert mathematical symbols, press the (＃)key

until the symbol you want is displayed. Or, you may scroll the Navigation Button to select a mathematical symbol as follows: Press the Up button for the plus sign (+); Down for the minus sign (-); Left for the division sign (/); and Right for the multiplication sign (X).

4. Enter the second number of the formula using the keypad.

5. Open the Options menu again and select Equals,

or simply press down the Navigation Button.

To clear a displayed number or calculation, press the Left Softkey (“Clear”).

T o clear the last digit entered, press the Back button.

8.4 Voice Notes

You can use Voice Notes to create and play back short voice recordings and verbal reminders, instead of entering text, using your Smartphone’s built-in audio recorder. Voice Notes are included on t he All Notes list and are named consecutively (Recording1, Recording2, and so on).

To create a Voice Note:

1. Start＞Voice Notes

2. On the All Notes screen, select Record, or select

Record from the Menu. Right after you do this, the

recording process begins, so be ready to start speaking into your Smartphone’s microphone immediately. A counter displays the number of

Chapter 8 Applications

seconds elapsed during recording.

3. Select Stop to stop recording a voice note. The voice note is saved (to \My Documents\Notes), and appears in the All Notes list of Voice Notes. By default, the first recording is named Recording1.

To rename, play, or delete a Voice No te:

Select the desired Voice Note file＞Select either

Rename, Play, or Delete from the Menu.

If you delete a voice note that has a default name, such as “Recording1,” this name becomes available for the next new voice note that you create.

8.5 Windows Media Player

Your Smartphone comes with Microsoft® Windo ws

Media® Player 10 Mobile, which lets you play

Windows Media Audio, Windows Media Video, and MP3 audio files.

To start Windows Media Player, select Windows

Media from the Start Menu. Or, press the Media Player Button.

File Formats Supported File Extensions

Video

Windows Media Video

Audio

Windows Media Audio MP3 MIDI

wmv

.wma .mp3 .mid, .midi, .rmi

Windows Media Player 10 Mobile has three primary screens, including Payback screen, Library screen, and Now Playing screen, which are illustrated on the next pages.

 Playback screen

This screen displays the playback controls (such as

Chapter 8 Applications Play, Pause, Next, Previous, and Volume), the album

art window, and the video window.

1. Select Options＞Buttons

2. Scroll to the desired commands＞Menu＞Assign

3. A “Assign Button” screen appears＞Press button

to assign＞OK

The amount of elapsed time Volume

The functions of operating the keypad in the Playback screen:

Operation Function

Navigation Button

Scroll Up Increase volume Scroll Down Decrease volume Scroll Left Play the previous file. Scroll Left and hold Fast forward Scroll Right Playing the next file. Scroll Right and hold Rewind

Press Down Pause or Play.

＃ Button Switch on/off the sound. ＊ Button Change the preference level.

To assign the functions hardware buttons in Media Player:

Chapter 8 Applications

Select Reset from the menu if you ever want to return all button assignments to their original default settings.

The commands of menu in the Playback screen

Command Function

Library Play/Pause Play or pause playback.

Stop Stop playback.

Shuffle/Repeat

Full screen

Options

Properties

About

Switch to different Library, such as My Device or Storage Card.

Play the items in the Now Playing playlist in a random order or repeatedly. Play the video clip in full screen (Landscape). Adjust Media Player options related to Playback, Video, Network, Library, Skins, and Buttons. Display the property of the selected file. Display the information about Windows Media Player 10 Mobile.

 Library screen This screen alows you to quickly find your audio files, video files, and playlists. It contains categories such as My Music, My Video, My TV, My Playlists, and

Now Playing. Each library represents an available

storage location.

You may sort your content by criteria such as, artist name, album title, or genre (shown as the right picture above).

Chapter 8 Applications

The commands of menu in the Library screen

Command Function

Queue up Delete form

Library Now Playing Display the Now Playing list

Library

Update Library

Open File Open URL Play the media files on a network.

Properties Player Go to the Playback screen

Add the selected item to the end of the playlist.

Remove the selected item from the Library.

Switch to different Library, such as My Device or Storage Card. Automatically searching the new items and add it to the Library by searching your device or storage card. Search and play the item stored in your device or storage card.

Display the property of the selected file.

To play the media from Libraries:

Use the Libraries to search and play the music, video, and playlist stored in your Smartphone or storage card.

1. Go to the Library screen.

2. If necessary, select Menu in the Library screen＞

Library＞Select the desired Library, such as My

Device or Storage Card.

3. In the Library screen, select one item (such as My

Music or My Playlists)＞Select the item to play

(such as the song, album, or artist). If the desired file isn’t in the Library, please select Menu in the

Library screen＞Open File＞Select the desired file

and play.

To play the media on the internet

Use the Open URL function to play the music or video stored on the Internet, or network server.

1. Go to the Library screen.

2. Menu＞Open URL.

3. Enter the address in the URL box or select the

desired address in the History box.

NOTE: You need to connect to the Internet before playing the item on the Internet.

 Change the skin of the Windows Media Player You may select a new skin to change the appearance of the player.

1. Go to the Playback screen

Chapter 8 Applications

2. Select Menu＞Options＞Skins

3. Scroll the Navigation Button left or right to select desired skin＞Done.

NOTE: After downloading the skin to your PC, please unzip the files (if necessary). Copy the .skn and .bmp files to your Smartphone by using ActiveSync. To make sure that the skins will appear in the Skin options, don’t save the skin files in the Windows folder of the Smartphone.

 Now Playing screen

The playlist indicates the media file which is current playing and all other files that are “queued up” to play next.

The commands of menu in the Library screen

Command Function Library

Move Up Move Down

Remove from Playlist

Shuffle/Repeat

Clear Now Playing

Error Details

Properties

Switch to different Library, such as My Device or Storage Card.

Select the upper or lower item Remove the selected item from

the palylist Play the items in the Now Playing playlist in a random order or repeatedly. Clear all the items in the Now Playing list. Display the error content of the selected item. Display the property of the selected file.

NOTE: A number of resources are available to help you troubleshoot. For more information, see the Windows Media Player Mobile pages at:

http://www.microsoft.com/windows/windowsmedia /player/windowsmobile/faq.aspx

Chapter 8 Applications

8.6 Games

 Bubble Breaker The object of Jawbreaker is to clear out all the balls. The rule is that you may only clear out adjacent same-colored balls.

1. Start＞Games＞Bubble breaker＞Menu＞New

Game

2. Scroll to the ball you want to clear and press down the Navigation Button.＞The group will be outlined, and the score for that selection will be shown.

2. Press down the Navigation Button again. To select a different grouping, press down the Navigation Button Up/Down/Left/Right.

Score equation: S = B * (B-1)

S: Score per move B: Number of balls cleared out

 Solitaire The object of Solitaire is to use all the cards in the deck to build up the four suit stacks in ascending order, beginning with the aces. You win the game when all cards are on the suit stacks.

1. Start＞Games＞Bubble breaker＞Menu＞New

Game＞Solitaire

2. Move any aces on the seven stacks to the four card spaces at the top of the screen, and then make any other available plays.

3. When you have made all available plays, select

Draw from the menu to turn over cards. The card

that is face up on the deck is always available for play.

Chapter 8 Applications

To move cards:

A number or character is displayed above each card stack. On the keypad, press the number or character of the card to move, and then press the number or character of the stack to which you want to move the card. Scrolling the Navigation Button up moves a card to one of the four stacks in the upper right corner of the screen if it belongs there.

8.7 Java Manager

Your Smartphone supports Java 2 Edition, J2ME. The Java Manager allows you to download Java applications such as games and tools specifically designed for mobile phones. The Java Manager gives you the flexibility of installing and managing additional J2ME applications from the Internet.

To download and install MIDlets directly from the Internet on your Smartphone:

1. Start＞More＞Games＞Java Manager＞Menu＞

Install

2.Select Browser or URL＞Connect to the Internet and select a MIDlet you wish to download. (Download both the .jad file and related .jar file.)

Chapter 8 Applications

3. Confirm what you wished to download the relevant files before the download begins. Once the download is complete, the Java Manager automatically starts, and prompts you to install your new MIDlet.

4. After installation, confirm if you want to launch the MIDlet. If select Yes, you will start the MIDlet application right away.

To download and install MIDlets from the Internet on your PC:

1. Make sure that your Smartphone is synchronized to

your PC. Using the Internet Explorer, go to any site that provides MIDlets for download.

2. Choose the game or utility you wished to install,

download it, and save it to your PC.

3. Copy the MIDlets to the \My Documents folder or

the \Storage Card folder.

4. Start＞More＞Games＞Java Manager＞Menu＞

Install＞Local Files. The Smartphone will search

the MIDlets antomatically.

5. Select the desired MIDlet form the Searching

Result list＞Install.

6. Select or create a folder to install into.

7. After installation, confirm if you want to launch the MIDlet. If select Yes, you will start the MIDlet application right away.

Chapter 8 Applications

Menu on the Main screen of Java Manager

Command Function Install

Browser URL Local Files

Actions

Info View the information about the MIDlet. Remove Remove the MIDlet. Update

Security

Rename Rename the MIDlet Move Move the MIDlet to another folder.

New Folder Remove All Certification

About Exit

Install a new MIDlet directly form the internet or the folder on your Smartphone.

Update the version of the MIDlet. Set up the state of permission, including

Local connection, Recording, Messaging, Net access and Auto Star

Create a new folder. Remove all of the MIDlets. Manage the certificates.

View the information about Java Manager.

Exit the Java Manager screen.

Security items Description

Local connection

Recording

Messaging

Net access

Auto Start

Allows the MIDlet suite to access service.

Allows the MIDlet suite to record sounds and images. Decides if the MIDlet suite could send/receive Text messages.

Decides if the MIDlet suite could access the internet.

Allows the MIDlet suite to be executed any time.

To launch the MIDlet:

1. Start＞More＞Games＞Java Manager

2. Select the desired MIDlet＞Launch

NOTE: Some of the security items cannot be used in all of the MIDlet suits. The description of the security items are as the following table:

Appendix

Regulatory Notices Specifications Troubleshooting Index

Regulatory Notices

 Agency Identification Numbers

For regulatory identification purposes, your Smartphone is assigned a model number of M1. The Battery Pack has been assigned a model number of

1688.

To ensure continued reliable and safe operation of your Smartphone, use only the accessories listed in this document.

NOTE: This product is intended to be used with a certified class 2 limited power source, rated 5 volts DC, maximum 1A power supply unit.

 European Union Notice

Products with CE marking comply with the R&TTE Directive (99/5/EC), the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community.

Compliance with these directives implies conformity to the following European Norms:

 EN 60950 (IEC 60950) - Safety of Information

Technology Equipment.

Appendix

 ETSI EN 301 489-7 - Electromagnetic compatibility

and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) for radio equipment and services; Part 7: Specific conditions for mobile and portable radio and ancillary equipment of digital cellular radio telecommunications systems (GS M and DCS).

 ETSI EN 301 511 – Global System for Mobile

communications (GSM); Harmonized standard for mobile stations in the GSM 850 and DCS 1800 bands covering essential requirements under article

3.2 of the R&TTE directive (1999/5/EC).

 ANSI/IEEE C.95.1-1992- specific absorption rate in

mobile phone emission condition for body health.

 FCC part 15 - Radio Frequency Devices and part

24 – Personal Communications Services.

 EN 50360 - 2001– Product standard to demonstrate

the compliance of mobile phones with the basic restrictions related to human exposure to electromagnetic fields (300 MHz – 3 GHz).

 SAR value: FCC: (1g) 850MHZ: Body 0.514 mW/g;

Head 0.539 mW/g. 1900MHZ: Body 0.596 mW/g;

Head 1.040 mW/g. CE: (10g) 900MHZ: Head 0.736 mW/g. 1800MHZ: Head 0.558 mW/g.

 ETSI EN 301 489-1 Electromagnetic compatibility

and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements.

 ETSI EN 301 489-17 Electromagnetic compatibility

and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2.4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment.

 ETSI EN 300 328 Electromagnetic compatibility and

Radio spectrum Matters (ERM); Wideband Transmission systems; data transmission equipment operating in the 2.4 GHz ISM band and using spread spectrum modulation techniques.

Tatung M1 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
