Translation of the original instructions of use
Symbols
Intended use of machinery
The TASKI vento 8/15 is a vacuum cleaner that is intended for commercial use (e.g. in hotels, schools, hospitals, factories, shopping centres, offices, etc.). Under strict compliance with these Instructions for Use, it can be used for the dry cleaning of textile floor and wall coverings. This machine has been exclusively designed for indoor use only.
Content
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Translation of the original EU Declaration of Conformity . . . . . . . . . 11
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Preparation for operation/Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Beginning work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
End of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Service, maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
General survey. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety instructions
Due to their design and construction, TASKI machines comply with health and safety requirements of the EC guidelines and therefore carry the CE sign.
Important! Switch the machine off when you:
• e.g. carry out cleaning or maintenance work, or convert the machine to another function
• store it in a suitable room to avoid any unauthorised use of the unit
• leave it standing without supervision
Do this by pulling the power supply cord out of the mains socket.
Store the machine in a dry, dust-free room with a corrosion-free atmosphere.
The temperature must not fall below +10 °C or exceed +35 °C. Low temperatures, damp and dust can significantly reduce the service life of the electrical components.
ATTENTION!
Before first start-up, it is essential that you read the instructions of use and the safety notes carefully.
Keep the instructions of use in an easily accessible place so that they can be consulted at any time.
Non-observance of this information can endanger people and / or cause servere damage!
Non-observance of this information can lead to malfunctions and property damage!
Important information about correct use. Non-observance of this information can lead to malfunctions!
Action points.
Modifications to this machine that have not been authorised by Diversey will lead to the cancellation of the Safety Marks and the CE Conformity. Any use of this machine other than its defined intended use could lead to injuries to persons and damage to the machine and the working environment. In such cases, all guarantee and warranty claims will normally become null and void.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack experience and knowledge unless they have been given initial supervision or instruction concerning use of the appliance by a person responsible for their safety!
Children should be supervised to ensure that they do not play with the appliance.
Do not use the machine in rooms where explosive and flammable substances (e.g. petrol, thinners, heating oil, solvents, etc.) are stored or processed. The electrical or mechanical components of the machine could lead to ignition of these materials.
Do not use this machine to vacuum toxic, poisonous, caustic or irritating substances (e.g. acids, alkalis, hazardous dusts, etc.). The filter system will not adequately retain these kinds of materials. A possible impairment of the health of the user and of third parties cannot be excluded.
While operating the machine, take note of the surrounding area and pay particular attention to third parties and children! In particular, the speed of the machine must be reduced in unclear situations, for example, near doors or curves .
STOP
t
STOP
STOP
STOP
STOP
STOP
In case of damage to parts that could affect safety, such as the tool cover, power supply cord or covers that prevent access to current-carrying parts, the operation of the machine must be stopped immediately!
Regularly check the power supply cord for tearing or aging, and do not put the machine into operation if it is not in a safe and suitable condition!
Caution:
Repairs to mechanical or electrical parts of the machine must only be undertaken by Diversey authorised customer service workshops or experts who are experienced in all relevant safety regulations.
Minimum requirement for the power supply cord H05VV-F2x1.0.
Caution:
This machine is only intended for use in dry areas, and must not be used or stored in the open air or under damp conditions.
Caution:
Pay attention to the accident prevention regulations!
Caution:
Only use tools which are specified in the instructions of use under accessories and which the TASKI-technical specialist recommends (Page 13), as the use of other tools could impair safety.
Caution:
Personal safety is covered by appropriate national regulations!
Caution:
It is forbidden to plug in or unplug the main power supply cord with wet hands!
Caution:
Take care not to damage the power supply cord by driving over it. Avoid crimping, tearing or damaging the power supply cord through heat, oil, or sharp objects!
Caution:
Please make sure that the voltage stated on the machine label is the same as the voltage rating of the plug socket!
Caution:
The additional power outlet (only vento 15) may only be used for additional equipment that is specified in the Instructions for Use (Page 13)!
Noise emission:
TASKI machines and units have been designed so that they present no danger to health through their noise emission accoring to the curent state of scientific knowledge. See the technical information on page 13.
STOP
STOP
To Order Parts Call 1-888-702-5326 - https://monsterfloorequipmentparts.com
I18I17I16 trsvslplnoithufr fiesendecz
Translation of the original EU Declaration of Conformity
We hereby declare that the product described below both in this basic design and con-struction and in the version marketed by us conforms to the relevant health and safety related requirements of the appropriate EU Directive.
This declaration shall cease to be valid if modifications are made to the product without our approval.
Applicable EU Directives:
Directive 2006/42/EC of the European parliament and of the council of
17 May 2006 on machinery, and amending Directive 95/16/EC (recast) Directive 2004/108/EC of the European parliament and of the council of
15 December 2004 on the approximation of the laws of the Member States relating to electromagnetic compatibility and repealing Directive 89/336/EEC
Harmonised standarts applied:
EN 60 335-1 / EN 60 335-2-69 / EN 62 233 EN 55 014-1 / EN 55 014-2 EN 61 000-3-2 / EN 61 000-3-3
It is ensured through internal measures that series-production units conform at all times to the requirements of current EU Directives and relevant standards.
The signatories act on behalf of company management and with full power of attorney.
Overview
1 Fastener catch 2 Socket (max.150W) Only recommended accessories might be used with
this socket!
3 Cable rewind 4 Transport handle 5 Vacuum lid 6 ON/OFF switch 7 Cord support 8 Power supply socket for power supply cord 9 Parking position for the suction tube and squeegee 10 Accessories holder (only vento 15) 11 Canister 12 Unlocking device for suction hose 13 Hose connector 14 Universal dust squeegee 15 Dusting brush nozzle (standard accessory: only vento 15) 16 Crevice nozzle (standard accessory: only vento 15) 17 Suction tube 18 Hose tube 19 Suction hose
Preparation for operation/Operation
Beginning work
End of operation
Designation: Dry vacuum cleaner for commercial use Product: Vacuum Cleaner Name: vento 8/15 Model: vento 8 (220-240VAC/50-60Hz, 900W) vento 15 (220-240VAC/50-60Hz, 1150W)
Serial number: see rating label at the machine
Trademark:
Producer: Techtronic Product Development Ltd.,
24/F CDW Building, 388 Castle Peak Road, Tsuen Wan, Hong Kong
Person authorised to compile the technical file:
Angelo Sabatino Diversey Europe B.V. Utrecht Zweigniederlassung Münchwilen CH-9542 Münchwilen
Hong Kong, 11.01.2012
• This marking indicates that this product should not be disposed with other houshold wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
Zhang Guo Feng Manager
• See the leaflet included in the packaging.
• Insert the dust bag as described in the pictogram on the dust bag.
• Insert the basket, the arrow at the top must point towards the hose connector.
• Place the ridge of the vacuum lid (2) into the guide provided on the canister (1), then press down until you hear the fastener catch click into place.
• Assemble the suction accessories.
• Insert the suction hose into the hose connector until it locks in.
• Plug the power supply cord into the mains socket.
• Switch the machine on (ON/OFF).
A bleed hole cover with which the suction force can be regulated is mounted on the tube bend.
The supplied accessory (for vento 15 only) can be attached to the tube or the hose tube.
• Switch the machine off (ON/OFF) and pull the power supply cord out of the mains socket.
• Wipe down the machine with a damp cloth.
• Wind up the power supply cord from the vacuum lid starting at the cable rewind.
Caution:
Never clean the machine with high water pressure or a water hose.
The ingress of water into the machine might cause considerable damage to mechanical or electrical parts.
123567
8
9
10
11 12 13 14
15
16
17
18
19
4
1
2
To Order Parts Call 1-888-702-5326 - https://monsterfloorequipmentparts.com
If the suction perfromance is inadequate, replace the dust bag and service the filter as described below:
Servicing the optional filter
Service, maintenance and care
The machines maintenance is a pre-condition for trouble-free running and an extended life.
Service intervals
TASKI machines are built to the highest quality standards. This is supported by internationally recognised quality control procedures. Electrical and mechanical parts are subject to wear or aging if used for long periods of time.
Service centre
Should you contact us due to a malfunction or for placing an order, please always state the type, description and the serial number of your machine.
You can find this information on the name plate of your machine, and the address of your nearest TASKI partner can be found on the last page of this manual.
Malfunctions
Wait a moment for dust to settle before removing the dust bag.
• Press down the fastener catch (1) and lift off the vacuum lid (2).
• Take out the basket, check if the cloth filter is dirty (basket), clean if necessary.
• Remove the dust bag from the hose connector and dispose of it according to your national regulations.
• Insert the dust bag as described in the pictogram on the dust bag.
Lightly soiled cloth filter.
• Brush off or using another vacuum cleaner, suck off the dirt.
Heavily soiled cloth filter.
• Wash the cloth filter in the washing machine (max. 30° C/86° F).
• Rest the damp cloth filter on the basket (so it adopts the right shape) and leave to air dry.
The cloth filter may not be put in the tumble drier!
Caution:
The machine may only be operated with a dry and functional filter cloth!
• Insert the basket, the arrow at the top must point towards the hose connector.
Heavy soiling of the filter disc
• Turn the vacuum lid round, and replace the filter disc with a new one.
The blue side of the filter disc must be visible.
Caution:
The machine may only be operated with the filter disc fitted!
• Place the ridge of the vacuum lid (2) into the guide provided on the canister (1), then press down until you hear the fastener catch click into place.
Heavily soiled exhaust filter
• Remove the exhaust filter and fit a new one.
Heavily soiled HEPA filter
• Vento 15 only: Remove the HEPA filter and dispose it in accordance with the national regulations.
HEPA filters cannot be cleaned!
1
2
1
2
Caution:
Only TASKI branded spare parts must be used, otherwise warranties and liabilities will be omitted!
Symbols: = after use,  = every week
Activity page
Checking/replacing the dust bag
Cleaning/replacing the filter cloth 11
Checking/replacing the filter disc
11
Checking/replacing the exhaust filter
11
Checking/replacing the HEPA filter
11
Clean the machine with a damp cloth
• In order to maintain operational reliability and availability for use, the service must be carried out after 500 working hours or at least once a year.
Under rough or extreme working conditions and / or insufficient maintenance, shorter periods are necessary.
Malfunction Possible causes Troubleshooting page
Machine does not run
ON/OFF switch (ON/OFF) switched off
• Switch the ON/ OFF switch on
11
No power supply
• Plug the power supply cord into the mains socket.
Plug not connected to the power socket on the machine
• Plug in
11
Power supply cord defect.
•Replace the power supply cord
ON/OFF switch defective
• Call for technical assistance
Motor defect
• Call for technical assistance
Poor vacuum performance
Dust bag full (safety valve has been tripped to prevent the suction motor overheating)
•Replace
11
Cloth filter soiled
• Clean or replace cloth filter
11
Filter disc dirty
• Relace the filter disc
11
Suction hose or sqeegee nozzle blocked
• Remove the blockage
HEPA filter dirty (optional: only on vento 15)
•Replace
12
Exhaust filter (optional) • Replace 11
Build-up of odours
Accumulation of moisture
• replace the dust bag
To Order Parts Call 1-888-702-5326 - https://monsterfloorequipmentparts.com
I18I17I16 trsvslplnoithufr fiesendecz
Disposal
When it has reached the end of its operational life, the machine and its accessories must be disposed of according to the national regulations. Your TASKI partner can support you with proper disposal upon notification.
Technical data
Accessories
General survey
Machine/model type vento 8 vento 15
Rated voltage 220-240V 220-240V AC
Frequency 50-60 50-60 Hz
Rated power 900 1000 W
Rated power (max.) - 1150 W
Power supply cord length 10.5 10.5 m
Machine weight 6 8 kg
Dimensions (L x W x H) 42x39x34 42x39x48 cm
Assessed sound level LPA according to EN 60704-1/EN 60704-2-1
<70 <70 dB(A)
Electrical protection class II II
Nr. Article vento 8 vento 15
7514803 Disposable Fleece Dust Bags
(pack of 10 pieces)
(1)
7514886 Disposable Paper Dust Bags
(pack of 10 pieces)
(1)
7514804 Disposable Fleece Dust Bags
(pack of 10 pieces)
-(1)
7514888 Disposable Paper Dust Bags
(pack of 10 pieces)
-(1)
4091150 Filter disc X X
7514883 Exhaust Filter X X
7514884 HEPA Filter Kit
(includes exhaust filter)
-X
7514885 HEPA filter (reserve) - X
7514889 Accessory Kit
(Crevice and Dusting Brush Nozzle)
XX
8500740 Conicle coupling X X
7514937 Telescopic Tube (32 mm) X X
8500520
8500540
8500530
8503460
8500480
8500730
8500740
(1)
7514885
8502000
7515017
vento 8
vento 15
TASKI vento 8,15
7514883
7514889
7509903
7514884
7515055
7514937
standard
alternativ(e)
D32mm
4091150
4104630
4103280
4126592
