Clean Dish Tables
Clean Dish Table
•Heavy duty 16 Gauge stainless steel
•7.5" backsplash
•Galvanized legs with adjustable bullet feet
•Three sided open base
•Order "L" for table left of dishwasher; order "R" for table right of dishwasher
•Available 14 gauge as special order - add "-14" to item number and add 25% to list price
2”
30”
CLEAN LEFT
CDT60R
Model No. Description
CDT24R Right side 30 x 24 x 35 45
CDT24L Left side 30 x 24 x 35 45
CDT36R Right side 30 x 36 x 35 50
CDT36L Left side 30 x 36 x 35 50
CDT48R Right side 30 x 48 x 35 65
CDT48L Left side 30 x 48 x 35 65
CDT60R Right side 30 x 60 x 35 75
CDT60L Left side 30 x 60 x 35 75
CDT72R Right side 30 x 72 x 35 90
CDT72L Left side 30 x 72 x 35 90
CDT84R Right side 30 x 84 x 35 105
CDT84L Left side 30 x 84 x 35 105
CDT96R Right side 30 x 96 x 35 115
CDT96L Left side 30 x 96 x 35 115
CDT108R Right side 30 x 108 x 35 125
CDT108L Left side 30 x 108 x 35 125
CDT120R Right side 30 x 120 x 35 140
CDT120L Left side 30 x 120 x 35 140
Sizes nominal, detailed specifications available upon request.
Specifications subject to change without notice.
Overall Size
D” x L” x H”
Weight
lbs.
L
6”
20.5”
1.5 ”
6”
20.5”
1.5 ”
DTU30366S
L
2”
30”
CLEAN RIGHT
Note: Use at least 12" shorter undershelf than
dish table size
Undershelf with 6" Legs
for Clean or Soiled Dish Table
Model No.
Stainless Steel
DTU30246S 22 x 24 16
DTU30366S 22 x 36 18
DTU30486S 22 x 48 22
DTU30606S 22 x 60 27
DTU30726S 22 x 72 32
SSLEG 35 4
Sizes nominal, detailed specifications available upon request.
Specifications subject to change without notice.
Size
D” x L”
Weight
lbs.
18
