Targus Wireless presenter User Manual

USER GUIDE

wireless
presenter
with cursor control

LASER RADIATION. DO NOT STARE INTO THE BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS. CLASS II LASER PRODUCT.

NEVER POINT A LASER BEAM INTO A PERSON’S EYES OR VIEW A LASER BEAM DIRECTLY,
AS PROLONGED EXPOSURE CAN BE HAZARDOUS TO THE EYES.

MOMENTARY EXPOSURE FROM A LASER POINTER, SUCH AS AN INADVERTENT SWEEP OF
THE LIGHT ACROSS A PERSON'S EYES, MAY CAUSE TEMPORARY FLASH BLINDNESS
SIMILAR TO THE EFFECT OF A CAMERA FLASH BULB. ALTHOUGH THIS CONDITION IS
TEMPORARY, IT CAN BECOME MORE DANGEROUS IF THE EXPOSED PERSON IS ENGAGED
IN A VISION-CRITICAL ACTIVITY SUCH AS DRIVING.

CAUTION: ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE
PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO
OPERATE THE EQUIPMENT.

THIS DEVICE AND ITS ANTENNA(S) MUST NOT BE CO-LOCATED OR OPERATING IN
CONJUNCTION WITH ANY OTHER ANTENNA OR TRANSMITTER.

YOUR DEVICE CONTAINS A LOW POWER TRANSMITTER. WHEN DEVICE IS TRANSMITTED
IT SENDS OUT RADIO FREQUENCY (RF) SIGNAL.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH
MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.

COMPLIES WITH 21 CFR 1040.10 & 1040.11

AVOID EXPOSURE--HAZARDOUS ELECTROMAGNETIC RADIATION EMITTED FROM THIS
APERTURE.

1

Introduction

NOTE: T

HE ACTUAL EFFECTIVE DISTANCE MAY INCREASE OR DECREASE

DEPENDING ON THE SURROUNDING ENVIRONMENT.

Contents

• Wireless presenter

• USB receiver

• USB extension cable

• 1 x AAA alkaline battery

• User guide

• Carrying pouch

Congratulations on your purchase of the Targus wireless
presenter with cursor control. This presenter is a combi­nation remote control mouse and laser pointer. With
this presenter you can control cursor movement anywhere
ithin 50 feet (15 m) of its receiver and project a red laser
pointer beam.

TARGUS WIRELESS

PRESENTER WITH

CURSOR CONTROL

The Targus Wireless Presenter also features a cursor
control pad and four (4) control buttons that emulate
mouse controls and command keys in PowerPoint®.

2

Targus wireless presenter with cursor control

Connecting the Receiver and
Installing the Default Driver

To connect the receiver to your computer, plug the
standard USB end of the receiver into an available USB
port on your computer. Alternatively, you can use the
supplied USB extension cable to connect the receiver to
your computer for additional length.

Your computer’s operating system identifies the receiver
as a “USB Human Interface Device” and begins installing
the default driver. Follow any on-screen procedures to
complete the default driver installation.

NOTE: I

F YOU ARE RUNNING THE WINDOWS

®

ME OPERATING SYSTEM, YOU

MAY BE PROMPTED TO INSERT THE INSTALLATION CD-ROM THAT CAME WITH
YOUR COMPUTER.

You are now ready to begin using the presenter.

Changing Modes

To maximize its features, the presenter has two modes of
operation: Mouse mode and Presenter mode. The
presenter’s default setting is Mouse mode. To change

Using the Targus Wireless
Presenter

3

Targus wireless presenter with cursor control

modes, switch the Function button upward for
Presentation mode or downward for Mouse mode.

The various mode features are listed in the table below.

Button Mouse Mode Presentation Mode

1 Left click Page up

2 Right click Page down

3 Internet page forward Start/Stop

4 Internet page backward Screen go dark

5 Cursor control No function

6 No function Laser Pointer

7

= Mouse mode = Presentation mode

8

= On / = Off = On / = Off

1

2

3

4

5

6

7

8

4

Targus wireless presenter with cursor control

Switching Channels

In some instances, radio frequency interference may
require you to switch to an alternate channel. To do this:

1 Press and release the button at the end of the receiver.

2 Within ten seconds, press and release the connection

button on the back of the presenter.

Connection button

Connection
button

5

Targus wireless presenter with cursor control

Safety Measures

• To avoid possible eye damage, never point the
presenter’s laser at people, especially their faces, or
look directly into the presenter’s laser beam.

• Avoid pointing the presenter’s laser beam at a mirror or
other highly reflective surface.

• Keep the presenter away from young children.

• Never view the presenter’s laser beam using telescopic
devices, such as a microscope or binoculars.

• Any attempt to disassemble, adjust or repair the
presenter may result in exposure to laser light or other
safety hazards.

• This is a Class lI Laser Product.

Troubleshooting

What do I do if the response time of the pre­senter’s mouse is slow or intermittently stops
working?

• Increase the distance between the presenter’s receiver
and the rest of your computer equipment. Use the USB
extension cable if necessary.

• Make sure that the presenter is within 50 feet (15 m) of
its receiver.

• Increase the distance between the presenter’s receiver
and the base units of other wireless devices.

• Turn off any wireless devices and their base units that
are near the presenter’s receiver.

• Replace the battery.

6

Technical Support

For technical questions, please visit:

This device complies with Part 15 of the FCC Rules. Opera­tion is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) This device must
accept any interference received, including interference that
may cause undesired operation.

Regulatory Compliance

Targus warrants this product to be free from defects in materi­als and workmanship for one year. If your Targus accessory is
found to be defective within that time, we will promptly repair
or replace it. This warranty does not cover accidental damage,
wear and tear, or consequential or incidental loss. Under no
conditions is Targus liable for loss of, or damage to a devices
nor loss of, or damage to, programs, records, or data; nor any
consequential or incidental damages, even if Targus has been
informed of their possibility. This warranty does not affect your
statutory rights.

Targus recommends that you register your Targus accessory
shortly after purchasing it. Go to:
http://www.targus.com/registration.asp. You will need to
provide your full name, email address, phone number, and
company information (if applicable).

Warranty

Targus wireless presenter with cursor control

US Internet: www.targus.com/support.asp
Australia Internet: www.targus.com.au

Email: [e-mail]
Telephone: [phone]

New Zealand Telephone: [phone]

Product Registration

7

This equipment has been tested and found to comply with the limits of
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and if not installed and
used in accordance with the instructions, may cause harmful interfer­ence to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna;

• Increase the separation between the equipment and receiver;

• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected;

• Consult the dealer or an experienced radio/TV technician for help.

Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. All trademarks and registered trademarks are
the properties of their respective owners. All rights reserved.
Features and specifications subject to change without notice. © 2006, Targus Group International, Inc.
and Targus, Inc., Anaheim, CA 92806 USA.

FCC Statement
Tested to Comply

Changes or modifications not authorized by the party responsible for
compliance could void the user’s authority to operate this product.

Declaration of Conformity

Hereby, Targus, declares that this device is in compliance with the
essential requirements and other relevant provisions of Directive
1999/5/EC.

Targus wireless presenter with cursor control

8

Visit our Website at www.targus.com Features and
specifications subject to change without notice.
© 2006 Targus Group International, Inc. and Targus, Inc.

AMP02US_PAUM30U / 410-0019-001C
