Targus 000052 User Manual

USER MANUAL

Model Name : Targus Bluetooth 3.0 Keyboard

DK-7200BI User Manual

VER: 0.1

MODEL NO. : AKB35 (DK-7200BI)

VERSION : 0.1

DATE : 2013.02.26

Page 1 of 10

Version. # Revised Date PIC Remark

0.1 02/26/2013 Natural Preliminary

DK-7200BI User Manual

VER: 0.1

Page 2 of 10

DK-7200BI User Manual

VER: 0.1

Electrical Specification

1. Operating Voltage

Keyboard supply voltage: 3.5V-5.5V (Inter－Lithium Battery or DC 5V)

2. Current Consumption

Current use :< 5mA

3. Sleeping Mode

3.1 Timing to sleep mode: 10S (The time from all keys are free to the keyboard turn to

sleeping mode)

3.2 Current during the sleeping mode :< 5mA (finally stable the current)

3.3 Wake up: press any key of the keyboard

4. Low-voltage indicate

When the voltage below 3.7V, the LED light was flashing 1Hz, which means the power is

low. (No action during sleeping model)

Wireless specifications

5

2.402-2.480GHz frequency coverage.

GFSK RF transceiver

High Speed RF link data rate Max. 1M bit/s

Page 3 of 10
