Targus MO10050812, 000001 Users Manual
Targus Wireless
Rechargeable Mouse
Making Your Mobile Life Easier.
Features and specifications are subject to change without notice.
© 2005 Targus Group International, Inc. and Targus Inc.
BRUSSELS HANNOVER BARCELONA TOKYO MILAN AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY
Visit our Web site at: www.targus.com
AMW05US/400-0221-001A
®
USER’S GUIDE
Making Your Mobile Life Easier.
®
TARGUS WIRELESS
RECHARGEABLE MINI
OPTICAL MOUSE
Introduction
Congratulations on your purchase of a Targus Wireless
Rechargeable Mini Optical Mouse. This ergonomically
designed mouse uses a radio frequency (RF) link that
enables you to use the mouse anywhere within four feet of
its receiver. No line-of-sight between the mouse and its
receiver is required.
In addition to this user’s guide this package contains:
•Mouse
• USB receiver
• USB charge cable
System Requirements
Hardware
•PC with a Pentium® processor or equivalent
•USB interface
Operating System
•Windows® 98SE/Me/2000/XP
• USB extension cable
• 2 AAA rechargeable batteries
• Carrying pouch
3
Targus Wireless Rechargeable Mini Optical Mouse
NOTE: The third button and the scrolling wheel only
work with the operating systems listed above. If you
use the mouse with a different operating system, it
will lose its enhanced features and function as a
standard, two-button mouse.
Connecting the Mouse Receiver
To connect the mouse receiver:
1 Plug the USB receiver into an available USB port on
your computer.
2 Your computer’s operating system identifies the receiver
and begins installing the default driver.
Follow any on-screen procedures to complete the
default driver installation.
Using the Mouse
Installing the Batteries
1 If the mouse is on, slide the on/off switch on the bottom
of the mouse to the “off” position.
2 Remove the battery cover from the top of the mouse by
pressing the battery cover hinge located on the bottom
of the mouse and sliding it off.
4
Targus Wireless Rechargeable Mini Optical Mouse
NOTE: The battery cover is also the top cover of the
mouse.
3 Insert the supplied batteries, making sure that the
positive (+) and negative (-) ends of each battery match
the polarity indicators inside the battery housing.
WARNING: When replacing the batteries, use only
heavy-duty NiMH batteries. Recharging alkaline
batteries may damage the mouse.
Avoid mixing new and used batteries in a device.
4 Slide the battery cover back into position until it “clicks”
firmly into place.
5 Turn on the mouse by sliding the on/off switch on the
bottom of the mouse to the “on” position.
The optical sensor, located on the bottom of the mouse,
illuminates.
5
