“Clairvoyance”
Digital Camera Binoculars
TB-320
User’s manual
Table of Contents
1. Introduction
• “Clairvoyance” Features
• System Requirements.
2. Getting to know your “
• LCD display
3. Software Installation
• Installation the “Clairvoyance” software
to your computer.
• Connecting the Clairvoyance to the
computer’s USB port.
Clairvoyance”
• Use Clairvoyance as USB Disk.
• Use Clairvoyance as SD memory card.
• Use Clairvoyance as PC Cam.
6. Maintenance
7. Specifications
• Camera.
• Binoculars.
8. Troubleshooting
9. For Windows XP User Only
• Using Photo Editing Software.
4. Focusing the Binoculars
5. Taking photos.
• Choosing your setting/LCD read out.
• Battery Installation.
• Battery Status indicator.
• Taking still pictures.
• Self Timer – Taking still pictures.
• Taking A Video.
• Erasing/Deleting Pictures.
• Run on PC cam mode.
• Downloading photos to your computer.
1. Introduction
Congratulations on purchasing the
Clairvoyance binoculars. That requires no Film
and your can take far pictures or short.
• Fluorescent lighting settings for - 50/60Hz 220V.
• 22x16mm status LCD display with Icons.
• Fixed focus 15m to infinity.
• 5Pins Mini USB connector for high speed photo
transfer.
• Take Photo& binoculars independently.
• Erase last picture or all pictures and SD card
format.
• Transfer photos to your PC to edit.
• Auto power off to conserve battery life.
• Shoot up a video.
• Read SD card，using by SD
card.(WIN2000/WINXP Do not need drive)
• using by SD card USB disk。(WIN2000/WINXP
Do not need drive).
• Serve as camera to the computer.
“Clairvoyance” Features：
• Resolution modes – when 64M SD memory card
presented.
High(Hi) for UXGA resolution（1600x1200 pixel）up
to 130 pictures.
Low(Lo) for VGA Resolution（640x480pixel）up to
800 pictures.
Video camera mode – up to 600 seconds of
streaming video in CIF resolution.
• Self timer for both resolution.
• “Clairvoyance” CD with applications software to
edit, manipulate and enhance your pictures and
videos.
System Requirements
• Windows 98/Windows ME/Windows 2000/Windows
XP.
• P 200MHz（or equivalent）processor of faster
• 64MB SDRAM.
• Video (VGA) card with 2MB of RAM for minimum
16Bit（HIGH color）display.
• CD-ROM Drive.
• An available USB port.
• 600MB of free hard drive space.
• Optional: Windows compatible sound card，
microphone and speaker.
If you have questions regarding your system
specifications please call your PC manufacturer.
2. Getting know your Clairvoyance
The mode setting operation is a cycle loop .by
pressing Shutter/confirm button each time to
enter the next mode sequentially
LCD display:
Below is the description for each Icon on the LCD
panel.
Choosing your setting/LCD read out:
1. Self-timer:
Self-timer to delay a short time and then take
a snapshot。
2. Hi/Lo quality:
Resolution selection is ”LO” for VGA
resolution mode ，”HI” for UXGA resolution.
3. AVI:
Auto Video impression mode, the frame rate is
about 9 fps for all resolution.
4. Battery status detection:
A 3-segments battery icon is displayed to
inform users the condition of battery.
5. 50/60:
50 for 50Hz electrical power frequency,60 for
60Hz electrical power frequency, Set it
according to the country where your are, and
the flicker effect on the image will be
eliminated.
6. Delete last/all:
the Icon”
“ indicates the deletion of the last
picture, and the Icon” “indicates the
deletion of all pictures stored in the memory.
7. Picture number/PC/Memory _ full:
It will show picture number at “Clairvoyance”
LCD, and show the text ”PC” while PC is
connected. Once memory is full, the text
“full” is shown and the alarm sound rises.
3. Software Installation
Important : Do not connect the “Clairvoyance” to
your computer before installing the software from
the CD-ROM attached.
Connecting the Clairvoyance to the computer
USB port
Installation the “Clairvoyance” software to your
computer:
1. Please install the CD-ROM before connecting your
Clairvoyance computer.
2. Insert the Clairvoyance CD-ROM into your CD-ROM
driver.
3. Choose the “install Ulead photo Explorer7.0” button
and step through to install the photo editing software
included.
4. Choose the ”Install Camera Driver” button to install the
camera driver.
5. Choose the “exit” when the software installation has
completed the next section.
6. Keep the installation CD-ROM inside the CD-ROM
drive until you complete the next section.
Remark
on the windows tool bar and choose ”Run”,
：
If your installation CD-ROM did not run
automatically, please click the “start” button
and then browse the CD-ROM drive and run
the “setup.exe” file.
1. Connect the USB cable(B type) to your computer’s
USB port as below drawing.
2. Connect the USB cable (A TYPE) to your
Clairvoyance as below drawing.
3. Your computer will automatically recognize the new
device.
Using Photo Editing Software：
See the help file of the Ulead phptp Explorer 7.0 Platinum
program for detailed usage instructions.
4. Focusing the Binoculars:
1. Keep only your left eye open and look through the left
lens. Turn the central focus adjustment knot until you
see crystal clear image through your left eye.
2. Close your left eye and look through your right eye
through the right lens. turn the right lens adjustor to
focus.
3. When done, both your binocular lenses would be in
focus.
5. Taking Photos
Battery installation:
Before using your “Clairvoyance”, you need to load the
5. If the SD card is protected, the PrT will be shown.
Please un-protect the SD card then star to capture.
Battery Status indicator:
The battery status indicator is a three-segments indicator
and the meaning is explained briefly below.
When the battery is full, three segments are
shown, the voltage is about 3 volts.
After a period of operation, the voltage drop down
to half, the buzzer sounds a thrilling tone and the
left part of the battery icon disappears.
When the battery is almost exhausted, the battery
icon displays only the right part of a short period
。
batteries as below：
1. Pull down with your thumb on the top of battery
compartment。
2. Insert
2 AAA alkaline batteries into the “Clairvoyance”
according to the engraving battery marks.
3. Press Power/Mode button about 3 second, the
camera will be turned on (Default setting)
4. Insert the SD card to SD card slot, if SD card is not
presented, a warning tone will sounded 10 seconds
then power off automatically.
Attention: Clairvoyance will be auto power off with a
key tone after certain time if not in use and Clairvoyance
will be power on by pressing power/mode button with a key
tone.
Clairvoyance performs best under good lighting conditions,
Please remember that to keep focus 15 meter to infinity to
take picture and do not view the sun directly.
and the camera will be power off automatically
。
Taking still pictures:
1. Press the Mode button to choose your camera mode.
The default mode is single shot mode which the most
commonly used mode
。
2. Aim at your subject through the binoculars.
3. Press the shutter button to capture what you see. A
beep sound will confirm that you have taken a photo
and the LCD photo counter will increase by one. While
capture is start, please hold the “clairvoyance” stably
unit sounded again.
4. If the camera memory is full, the text ”FULL” is shown
no the LCD panel and with an alarm sound
。
Self Timer – Taking still pictures:
The self – timer allows you to take a picture and have 10
seconds delay before taking a picture.
1. Press the mode button until the self – timer icon is
flashing and then press the Confirm button to enter
the self – timer mode.
2. Press and release the Shutter/Confirm button. The
buzzer keeps beeping for 10 seconds before taking a
photo.
3. You may stop the self – timer countdown after is
started be pressing the shutter button once.
Taking a video（Only works by SD Memory card ）
1. Press the Mode button to choose the video mode.
2. Press and hold the shutter button to capture video
and release the Shutter button only when you wish to
end the video capture。
3. The video clip is stored in AVI format and the photo
counter will increase by one。
Erasing/Deleting Pictures:
As with still pictures, you could have the ability to erase the
last or all of your pictures。
Run on PC cam mode:
Press the shutter button while unit is connected with PC
until the “PC” show on the status LCD. Now unit is works on
the PC cam mode success.
Please Note: When the camera memory is full the LCD will
display Full and you cannot take any more
pictures by using the EAL – Erase all or E01
–Erase Last Picture option.
Downloading Photos to Your Computer:
When your “Clairvoyance” is connected to your
computer ，you may see a Removable disk drive which is
the photo storage of your “Clairvoyance” you may simply
copy the files from the removable disk to your computer.
Using “Clairvoyance” as USB Disk:
When your “Clairvoyance” comes with 12MB of memory
built-in for keeping any files you may have. You may
increase the storage size by inserting a SD card. Browse to
the Removable Disk drive labeled ”ICATCH VII” shown
inside your computer to copy or delete files in the camera
storage.
Clairvoyance is bundled application to let you have more
funs with the images on your PC. Also it can be used a web
cam, Operation details please refer to the CDROM contents.
Use Clairvoyance as SD memory card:
Digital camera read in common use SD storage card, at"
Clairvoyance " digital camera read the" Clairvoyance "s of
you card machine when using, Needn't install drivers under
WIN2000/WINXP operating system, but read and write
directly.
Use Clairvoyance as PC Cam:
Work as at" Clairvoyance " digital camera regard you as,
And join USB's cable of digital camera to the mouth of
USB's end of computer reliably, the state display screen of
liquid crystal shows" PC" printed words at this moment, "
install Ulead photo explorer7.0"s start videos , that the
operation method of the software please consult " install
Ulead photo explorer7.0" detailed user's manual at the help
file.
Digital camera truss up and have and let you obtain more
happy application software" Clairvoyance " from your picture
at computer at the same time, Can be regarded as the
camera use of the network too. The detailed detail please
consult the content in the relevant CD.
6. Maintenance
1. Operating Environment：41 to 104 deg F (5 to 40 deg
C ). 20-85% relative humidity, non-condensing,
2. Special Care taking！！
• Never immerse the Clairvoyance into any fluid or
liquid. Remove dust or stains with a soft cloth
dampened with water or neutral detergent. To keep
the Clairvoyance in dry and cool dust-free
environment or container when it is NOT used.
• Long time’s to take the batteries out, when
Clairvoyance is NOT to be used over a long
period.
• Please avoid dropping the Clairvoyance to hard
ground. Do not disassemble the Clairvoyance.
7. Specifications
Camera:
1. Sensor type：1/2.7” Color UXGA（1600x1200
pixels）CMOS image sensor.
2. Auto – exposure and Auto White-balance control.
3. Frame rate：
Auto Video impression: 9fps in all resolution.
4. Memory & Images：128Mbit SDRAM Memory
storage.
130+/-20 pictures for HI Resolutions when 64M
SD card is presented.
800+/-40 pictures for Lo Resolutions when 64M
SD card is presented.
5. Battery：AAA1.5V x 2 alkaline batteries.
10. Interface type：USB1.1
11. Storage Condition：-4 to 131 deg F (-20 to 55 deg
C). 20-85%R.H., non-condensing.
Binoculars:
1. Binocular Magnification： 8x optical
2. Binocular Lens Diameter： 22mm
3. Angular Field of View： 7degree, 122feet at
1000 yards.
4. Exit Pupil： 2.75mm
5. Close Focusing Distance： 4.9m
8. Troubleshooting
Display resolution adjustment- You need to set the display
resolution to 16 bit color or higher for optimum image display.
6. Power Consumption：
Operation voltage：3V-AAA battery x 2
Standby current：150+/-5mA
Refer to the display card manual or below procedure：
Following is to setting HI Color（16Bit）or above procedure：
1. Click the Windows Start button.
Capture current：150+/-10mA
Sleep mode current：Less then 2 +/-20uA
（power off）
With USB connection：No battery consumption
7. Focusing Distance：15 meter min. to Infinity.
8. Minimum Luminosity：300luxs or above
9. Operation System environment：WIN 98/ WIN ME/
WIN 2000/ WIN XP
2. Click Setting and then Control Panel from the
pop-up menus.
3. Double click the Display icon.
4. Click the Setting tab.
5. The Color Palette group showing out setting
reading. Please select to High Color（16Bit）or
True Color（24Bit）。Then choose High Color or
True Color From the list box.
6. Click O.K. If need to do monitor driver, please do
it to change the new setting.
7. Restart your computer.
9. For Windows XP User Only
This driver of Clairvoyance is compatible for Windows XP,
But during installation, you, may find the following error
message.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that my cause undesired operation.
Warning: Changes or modification to this unit not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If the equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
Please click ‘Continue Anyway’ and complete whole installation
process.
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
Loading...
