Tapplock one

+

User Manual

World’s first smart fingerprint padlock

Tapplock.com

Cutting-edge fingerprint

technology

• Unlocks in 0.8 seconds

• Stores up to 500 fingerprint

• Adaptive algorithm: faster and

more accurate access each
time you use it

Water and weather resistant

• Water resistant up to IP67

• Rust-proof & rain-proof

• Fully functional between -10C

and 60C

Shareable wireless access

• Supports wireless Bluetooth

access via the Tapplock app

• Share & control access
remotely to unlimited users

• View access history with time
and location

Rechargeable battery

• Up to one year battery life per
2 hour charge time

• Check remaining power using

the Tapplock app

Unbreakable durability

• Zamak 3 zinc alloy metal body
with cut-resistant stainless steel

shackle

• Double-layered design with
anti-shim and anti-pry
capabilities makes Tapplock

virtually unbreakable

Morse code backup access

• Setup Morse code access
using the power button in case
a user's fingerprint isn't enrolled
and the phone ran out of
batteries

Overview

Fingerprint sensor

Power / mode button

Status indicator

Charge port

Quick start

1. Download the

Tapplock app

from Google Play

Store or iOS App
Store

1. Register / log in

on the Tapplock

app and follow
instructions to

setup your new

Tapplock

** Make sure Bluetooth is turned on in your phone
settings before beginning to setup the lock

3 ways to unlock

Tapplock one+is equipped with
multiple access capability to allow for

maximum convenience and flexibility.

Fingerprint access: 0.8

seconds

Bluetooth access: Bluetooth
access via the Tapplock app

using your smartphone

Morse-code access: backup

access using long-short
combinations

Status Indicator

The status indicator is the

visual cue to understanding

your Tapplock one. Refer to
table below to understand
what each color means.

Status Indicator

Mode Function/Action White Blue Green Red

Beep Sound

Fingerprint Mode

Press power button x 1

Fingerprint accepted

Fingerprint rejected

Bluetooth Mode

Press power button x 2

Searching

Connected

Unlock via

Bluetooth

Morse Code

Mode

Press power button x 3

Long press

Short press

Correct Morse code

Incorrect Morse code

Lock Successful

Locking successful

Lock Notification

Lock is unlocked

Charging Mode

Charging

Breathing

Fully charged

Low Battery

Notification

Battery at 30%

Batter at 20%

Battery at 10%

Fingerprint

Mode

• To turn on Tapplock, press the Power Button

located below the rim. The Status Indicator light
should be white, and your Tapplock should be
ready to unlock with your fingerprint.

(If you are having trouble getting to Fingerprint
Mode, hold down the Power Button until the

Status Indicator light turns off, putting your lock

in sleep mode. Then press the Power Button to
enter Fingerprint Mode)

** Tapplock one+will automatically enter sleep

mode after 10 seconds of inactivity. This
increases the lifespan of your battery.

Status Indicator

Power Button

Bluetooth

Mode

• Connect your phone using the Bluetooth Mode
to:

• Add new Tapplock to your account

• Unlock with your phone

• Setup / remove fingerprints

• Setup morse code

• Press the Power Button twice (2) to enter

Bluetooth Mode for phone pairing. The Status

Indicator light should be blue.

(If you are having trouble getting to Bluetooth

Mode, hold down the Power Button until the

Status Indicator light turns off, putting your lock
in sleep mode. Then press the Power Button
twice to enter Bluetooth Mode)

Status Indicator

Power Button

Morse-code
Instructions

• Morse-code is a backup access mode. It allows

you to unlock your device using long / short

combinations of pressing the Power Button.
Morse-code allows access to your lock without

your fingerprint or your phone.

• Follow instructions in the Tapplock app to setup

your custom morse-code

• Press the Power Button three (3) times to enter
Morse Code mode. The Status Indicator light

should be green.

(If you are having trouble getting to Morse
Code mode, hold down the Power Button until

the Status Indicator light turns off, putting your

lock in sleep mode. Then press the Power Button
three times until the Status Indicator light turns

green)

Status Indicator

Power Button

This device complies with Industry Canada

licence-exempt RSS standard(s).

Operation is subject to the following two

conditions: (1) This device may not cause

interference, and (2) This device must accept any
interference, including interference that may
cause undesired operation of the device.

Le présentappareilestconforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence.
L'exploitationestautorisée aux deux conditions

suivantes: (1) l'appareil ne doit pas produire de

brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout
brouillageradioélectriquesubi, mêmesi le

brouillageest susceptible d'encompromettre le

fonctionnement.

The device has been evaluated to meet general

RF exposure requirement.

The device can be used in portable exposure
condition without restriction.

le dispositif a été évalué à satisfaire l'exigence

générale de l'exposition aux rf.
l'appareil peut être utilisé dans des conditions
d'exposition portatif sans restriction.

FCC notice

This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to

operate the equipment.

Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for
help.

The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure
condition without restriction.

Visit Tapplock.com for newest updates,

instructions and FAQ.

Contact us by emailing:

[email protected]

Copyright © Tapplock Corp.
