Page 1
Tapplock one+
User Manual
World’s first smart fingerprint padlock
Tapplock.com
Page 2
Cutting-edge fingerprint technology
• Unlocks in 0.8 seconds
• Stores up to 500 fingerprints
• Adaptive algorithm: faster and more
accurate access each time you use it
Shareable wireless access
• Supports wireless Bluetooth access via
the Tapplock app
• Share & control access remotely to
unlimited users
• View access history with time and
location
Water and weather resistant
• Water resistant up to IP67
• Rust-proof & rain-proof
• Fully functional between
-20ºC to 65ºC (-4ºF to 149ºF)
Page 3
Rechargeable battery
• Up to 1-year battery life per 2-hour
charge time
• Check remaining power using the
Tapplock app
Unbreakable durability
• Zamak 3 zinc alloy metal body with
cut-resistant stainless steel shackle
• Double-layered design with anti-shim and
anti-pry capabilities makes Tapplock virtually
unbreakable
Morse code backup access
• Set up Morse code access using the Tapplock app
• Access the Tapplock using the power button in
case a user's fingerprint isn't enrolled and / or
access to a smartphone is unavailable
Page 4
Overview
Status
indicator
Power
button / mode
FRONT VIEW
Fingerprint
sensor
BOTTOM VIEW
Charge
port
Page 5
Quick Start
1
Register / log in on the
2
Tapplock app and follow
instructions to set up
your new Tapplock.
Make sure Bluetooth
is enabled in your
phone settings before
setting up the
Tapplock.
Download the Tapplock app on
the App Store or Google Play.
Page 6
Status Indicator
The status indicator is the visual cue to understanding
your Tapplock one+.
Refer to the table to understand what each colour
means.
Page 7
Status Mode
Fingerprint
Bluetooth
Morse Code
Lock
Successful
Lock
Notification
Charging
Low Battery
Notification
Function/Action
Press power button 1x
Fingerprint accepted
Fingerprint rejected
Press power button 2x
Searching
Connected
Unlock via Bluetooth
Upgrading firmware
Press power button 3x
Long press
Short press
Correct Morse code
Incorrect Morse code
Locking successful
Lock is unlocked
Charging
Fully charged
Battery at 30%
Battery at 20%
Battery at 10%
* indicates LED will be blinking
LED Color Beep Sound
White
Green
X
Red
Blue*
Blue*
Blue
Green
X
Yellow
Purple
White
Blue
Green
X
Red
Green
Green
X
X
Red
Green
Red*
Red*
Red*
X
Page 8
3 ways to unlock
Tapplock one+ is equipped with multiple access
capabilities to allow for maximum convenience
and flexibility.
Fingerprint access: Unlock in 0.8 seconds
Bluetooth access: Bluetooth access via the
Tapplock app using your smartphone
Morse code access: Backup access using
long-short combinations by pressing the
power button
Page 9
Fingerprint Mode
To turn on Tapplock one+, press the power button
once (1) located below the rim. The status indicator
light will be white. Your Tapplock one+ is now ready
to unlock with your registered fingerprint.
If you are having trouble getting to fingerprint mode,
hold down the power button until the status indicator
light turns off, putting your lock in sleep mode. Then
press the power button once (1) to enter fingerprint
mode.
** Tapplock one+ will automatically enter sleep
mode after 10 seconds of inactivity. This increases
the lifespan of your battery.
Page 10
Bluetooth Mode
Connect your phone using Bluetooth mode to:
• Add a new Tapplock to your account
• Unlock with your phone
• Set up / remove fingerprints
• Set up Morse code
Press the power button twice (2) to enter Bluetooth
mode for phone pairing. The status indicator light will be
blue.
If you are having trouble getting to Bluetooth mode,
hold down the power button until the status indicator
light turns off, putting your lock in sleep mode. Then
press the power button twice (2) to enter Bluetooth
mode.
Page 11
Morse code Mode
Morse code is a backup access mode. It allows you to
unlock your device using long / short combinations by
pressing the power button. Morse code gives you
access to your Tapplock without your fingerprint or
your phone.
Follow the on-screen instruction in the Tapplock app to
set up your custom Morse code.The status indicator
will be white for a long hold. The status indicator will
be blue for a short hold.
Press the power button three (3) times to enter Morse
code mode. The status indicator light will be purple.
If you are having trouble getting to Morse code mode,
hold down the power button until the status indicator
light turns off, putting your lock in sleep mode. Then
press the power button three (3) times until the status
indicator light turns purple.
Page 12
FCC notice
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
Page 13
This device complies with Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions: (1) This device may
not cause interference, and (2) This device must accept any interference,
including interference that may cause undesired operation of the device.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without
restriction.
Visit Tapplock.com for
newest updates, instructions and FAQ.
Contact us by emailing: [email protected]
