SAFETY INSTRUCTIONS
CAUTION: To reduce the risk of electric shock,
do not remove cover (or back). There are no
user-serviceable parts inside. Refer servicing to
qualified service personnel.
• Descriptions of Graphical Symbols
The “lightning bolt” with an “arrowhead” symbol within an equilateral
triangle alerts you to the presence of uninsulated “dangerous voltage” within the product’s enclosure, and to the fact that such voltage may constitute a risk of electric shock to one or more persons.
The exclamation point within an equilateral triangle alerts you to
the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product.
APPLICABLE FOR USA, CANADA OR WHERE
APPROVED FOR USAGE
Wall or Ceiling Mounting: The appliance should be
7.
mounted to a wall or ceiling only as recommended by
the manufacturer.
Ventilation: The appliance should be situated so that its
8.
location or position does not interfere with its proper ventilation. For example, the appliance should not be situated
on a bed, sofa, rug, or similar surface that may block the
ventilation openings; or placed in a built-in installation,
such as a bookcase or cabinet that may impede the flow
of air through the ventilation openings.
Heat: The appliance should be situated away from heat
9.
sources such as radiators, stoves, or other appliances that
produce heat.
Power Source: The appliance should be connected to a
10.
power supply only of the type described in the operating instructions or as marked on the appliance.
Power-Cord Protection: Power-supply cords should
11.
be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE PLUG TO WIDE SLOT,
INSERT FULLY.
ATTENTION: POUR EVITER LES CHOCS
ELECTRIQUES, INTRODUIRE LA LAME
LA PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU AU FOND.
1. Read Instructions: All the safety and operating instruc
tions should be read before the appliance is operated.
2. Retain Instructions: The safety and operating instructions
should be retained for future reference.
3. Heed Warnings: All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions: All operating and other instructions
should be followed.
5. Water and Moisture: The appliance should not be used
near water - for example, near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, or near a
swimming pool, etc.
6. Carts and Stands: The appliance should be used only
with a cart or stand that is recommended by the manu-
facturer.
Cleaning: The appliance should be cleaned only as
12.
recommended by the manufacturer.
Periods of Non-use: The power cord of the appliance
13.
should be unplugged from the outlet when left unused for a
long period of time.
Entry of Foreign Objects and Liquids: Care should be
14.
taken so that objects do not fall into and liquids not spilled
into the inside of the appliance.
Damage Requiring Service: The appliance should be ser-
15.
viced by qualified service personnel when:
a. The power-supply cord or the plug has been damaged
b. Objects have fallen onto, or liquid has been spilled into
the appliance
c. The appliance has been exposed to rain
d. The appliance does not appear to operate normally or
exhibits a marked change in performance
e. The appliance has been dropped or the cabinet has
been damaged.
Servicing: The user should not attempt to service the ap-
16.
pliance beyond those means described in the operating
instructions. All other servicing should be referred to qualified service personnel.
PORTABLE CART WARNING:
Grounding/Polarization: The precautions that should be
17.
taken so that the means of grounding or polarizing the
product is not defeated.
2
INTRODUCTION
Congratulations on your selection of a new Tantra Series
subwoofer from Tantra Audio, a leader in quality and tech-
nology for the new era of audio entertainment. The Tantra
subs, like all our products, are designed in the USA to meet
the needs of discriminating users, with the features needed
to ensure greater convenience, utility and value over the
long term.
Each of the Tantra subwoofers offers practically any control
function one could want right on the front panel: Power
On/Off Indicator; Volume; selectable EQ with presets for
“Movie,” “Rock” and “Jazz”; selectable Phase presets; Low
Pass Frequency adjustment from 40Hz to 120Hz; and High
Pass Frequency adjustment from 60Hz to 160Hz for line-level
outputs and High Pass Frequency On Off switch.
Moreover, the Tantra subs come with their own remote
controllers for one-touch selection of primary functions like
Power On/Off, EQ, Phase, Volume and Mute. But perhaps
the greatest benefit of a Tantra sub is its ability to deliver
tight bass of amazing depth and accuracy, no matter how
demanding the audio source might be.
The Tantra 12 and 10 subwoofers provide accurate bass to
any audio system and are designed to work in conjunction
with other audio components. They can be connected to
any multichannel surround receiver that has a subwoofer
output, any receiver that has a built-in preamplifier, or any
receiver equipped with speaker-level outputs. The passthrough feature of the Tantra subwoofers allows the left and
right line-level input signals to be fed out of the unit to other
amplifiers or system components.
PLACEMENT
The Tantra subwoofer will provide the best possible performance when it is placed in a corner along the same wall as
the front speakers. Because the unit is magnetically shielded, it’s safe to position it near a TV screen or other video
device. Keep the following points in mind when choosing a
place for the subwoofer:
DO
• Place the Tantra subwoofer with its feet resting on a flat,
solid surface.
DO NOT
• Obstruct the driver or ports of the Tantra subwoofer, as
that will hinder its performance.
• Place the subwoofer in any position other than in horizon
tal orientation with the feet firmly on a stable surface.
• Never place on its side or resting on the back, where the
terminals are located.
• Place the subwoofer near a heat source or in an area
where it could be subject to moisture or excessive
humidity.
INSTALLATION
Connecting the LFE Audio Input
(See Diagram 2)
1. If your surround receiver or amplifier has a single subwoof-
er (LFE) output, plug it into the LFE input (see Diagram 2).
CAUTION: Only make connections when the Tantra sub-
woofer is turned off.
2. The LFE Input/Outputs accept the LFE Subwoofer Output
signal from your receiver/amplifier (if so equipped) but bypass the crossover in the Tantra subwoofer. This is appropriate for use with the LFE filtered audio signal from the receiver/amplifier. Signal smoothness through the critical crossover
area is maximized since the low and high pass filtering takes
place in the receiver/amplifier. This filtering is more precise
preventing overlap of crossover points that may occur if the
LPF and HPF controls are set too close together because of
inaccurate settings.
Connecting the Line Level Audio Inputs and
Outputs
(See Diagram 1)
1. If your receiver or amplifier has a built-in preamplifier, the
left and right Pre-outputs can be connected to the linelevel inputs (see Diagram 3).
CAUTION: Only make connections when the Tantra sub-
woofer is turned off.
• Place the subwoofer in a well-vented area to provide
proper cooling. If used in an area that lacks proper ven
tilation, such as a cabinet or rack, it may be necessary to
install one or more small fans to generate air movement.
Diagram 1
Line Level
Input/ Output
3
HPF = 130Hz. 8 Ohms
PRE IN
PRE OUT
L
R
VCR
INPUT
DVD
INPUT
CD
INPUT
SPEAKER
OUTPUTS
LEFT
CENTER
RIGHT
REAR
LEFT
REAR
RIGHT
L
R
L R
L RL R
LEFT REAR SPEAKER
RIGHT REAR SPEAKER
LEFT SPEAKER
RIGHT SPEAKER
CENTER SPEAKER
RECIEVER WITH BUILT-IN PREAMP
LEFT REAR SPEAKER
RIGHT REAR SPEAKER
LEFT SPEAKER
RIGHT SPEAKER
CENTER SPEAKER
HPF = 130Hz. 8 Ohms
SURROUND SOUND RECIEVER
SUBWOOFER
OUTPUT
SPEAKER
OUTPUTS
LEFT
CENTER
RIGHT
REAR
LEFT
REAR
RIGHT
VCR
INPUT
DVD
INPUT
CD
INPUT
L R
L RL R
DIAGRAM 2:
Receiver with Sub Out
DIAGRAM 3:
Receiver with Preamp Outputs
4
HPF = 130Hz. 8 Ohms
VCR
INPUT
DVD
INPUT
CD
INPUT
L R
L RL R
LEFT SPEAKER
RIGHT SPEAKER
STANDARD RECIEVER
SPEAKER
OUTPUTS
LEFT RIGHT
2. The Line Level Input/Output L/R connectors on the back
panel accept the signal from your receiver/amplifier and
filter it using the Tantra subwoofer’s internal LPF and HPF
crossover filters. This method is appropriate if you’re certain
the audio signal to the sub is not crossover-filtered (meaning
there is no low-pass filtering).
3. Sources connected to the left and right Line Level Inputs
can be forwarded to other components or amplifiers by
connecting to the corresponding Line Level Output jacks.
If your receiver or amplifier has a built-in preamplifier, the
left and right Pre-amp inputs can be connected to the Line
Level Outputs (see Diagram 3). Use the Hi Pass Frequency
control on the subwoofer front panel to adjust the highpass
crossover.
Connecting The Speaker Wires
1. Follow these instructions when using the Speaker Level
Outputs of your receiver or amplifier for connection to
the Tantra subwoofer. (See Diagram 4) For best results in
runs up to 75’, use speaker wire of at least 18-gauge. For
runs exceeding that distance, we recommend the use of
14-gauge wire. However, wire larger than 14-gauge is not
recommended because it may not fit into the subwoofer
terminals. For best results, strip all wire insulation no more
than 3/8” from the end before inserting the wire into the
terminals.
2. Strip 3/8” of the insulation from the end of the speaker
wire.
3. Connect the wires from the other speakers in the system
to the back panel and connect the wires from the sub to
the receiver/amplifier. Please observe the proper polarity of the connections, matching positive (+) to positive
and negative (-) to negative (see Diagram 5). Two terminal blocks on the back panel—Speaker Level Input and
Speaker Level Output (the latter with a high-pass crossover
point set at 130Hz), each with its own positive and negative
L/R jacks—let you route the signal from the amplifiers to the
DIAGRAM 4:
Speaker Level
Input/Outputs
front left and right speakers using the sub to fill in the bass
frequencies below 130 Hz.
Other Features
1. Audio Sense. The Tantra can automatically sense when
audio signals are present at it’s Speaker, Line, or LFE Inputs.
When the Audio Sense Toggle Switch is set to the “Audio
Sense” position, the Tantra will turn On within 1 second when
audio starts from the receiver/amplifier and will turn Off in 1
to 2 minutes after audio stops (receiver/amplifier is turned
Off). When the Audio Sense Toggle Switch is set to “Always
On”, the Tantra will always stay on, unless turned Off by the
IR remote or the main Power switch.
2. In Trigger. When a 3.5mm plug is inserted into the In
Trigger jack, the Tantra can be turned On and Off by an external voltage source of 4 to 30V DC. Such a trigger source
may be a trigger output on your Receiver/Amp or a small
DC power supply plugged into an Aux. AC Outlet that is
switched On and Off with the Receiver/Amp.
3. Direct IR Control. The sensor for the internal IR Receiver
on the Tantra subwoofer front panel is located between
the LPF and HPF controls (see Diagram 7). It can be used
for direct IR control of the Tantra using the included remote
control, if conditions permit. You must have a direct line of
site view to the Tantra IR sensor. This sensor will also function
when the IR RCVR and Ext. IR Inputs are connected.
DIAGRAM 5:
Using a Receiver’s Stereo
Speaker Outputs
5
4. IR RCVR jack. This jack permits the use of SpeakerCraft
MU TE
TS R
POWER
EQ
PHASE
VOLUME
IR Receivers that use a mating Quad, 4-circuit 3.5mm plug,
such as models IRC-1.1, IRC-2.1., etc. This is particularly useful when room conditions do not allow a direct view of the
built-in IR sensor on the Tantra front panel. Simple plug the
IRC-x.x into the IR RCVR jack and place it on a shelf, table
top or other location that permits a direct line of view for
aiming the handheld remote control.
5. Ext. IR Input. The External IR Input connector on the Tantra
back panel is provided so that the unit can be controlled
along with the other components in a network IR-controlled
entertainment system. Simply connect a 3.5mm mini plug
cable from an IR output port on the network to this Ext. IR
Input jack.
OPERATION
DIAGRAM 6:
TSR Remote Control
Power
To turn the AC Power ON to the Tantra (after all connections
have been made), use the Power switch on the back panel.
This places the Tantra in a standby “Off” mode. The Power
indicator on the front panel will turn red (See Diagram 7).
To turn the Tantra On to the “Active” mode, use the POWER
button on the included remote control (Diagram 6). The
Power indicator on the front panel will turn green and the
unit will play. When you press POWER again, the Tantra returns to the “Off” or standby mode and the Power indicator
turns red.
Equalization
Use this control to set the overall frequency balance of the
subwoofer bass frequencies with the higher frequencies
of other speakers in the system, so that it suits the listening environment and the type of music played. Press the
Equalization button to select between Movie, Rock and Jazz
in combination with various music selections. Additionally,
these parameters can be changed to suit specific types of
musical selections such as action/adventure movies, Rock,
Jazz and concert performances.
Low Pass Frequency
Use this control to adjust the low frequency range of the Tantra subwoofer. Various kinds of audio material can influence
the setting, but generally the goal is to achieve a good
crossover point between the subwoofer and the main L and
R speakers. If the main speakers cannot support very much
in the low frequency range, then rotate this control to a
higher frequency setting. If the main speakers are large and
can support lower frequencies, then rotate this control to
a lower setting. In general, the LPF and HPF controls should
be set close to the same frequency to achieve a seamless
match in the crossover area between the subwoofer and
the main L and R speakers.
High Pass Frequency
Use this control to adjust the lower frequency limit of the
music fed to the main L and R speakers from the Line Level
Output jacks. In general, adjust this HPF control close to
the same frequency as the LPF control so that a seamless match in the crossover area between the subwoofer
and the main L and R speakers is achieved, as mentioned
above.
On / Off Toggle Switch
This switch turns the HPF filters On and Off. In the Off position,
the HPF control does not function and the main L and R
speakers are fed the full range of audio frequencies, without bass limitation. Use this position only if your main L and
R speakers are large full range types that can support low
frequencies at full power.
Phase
This control toggles the phase of the bass frequencies fed
to the subwoofer between 0° and 180°. Press the Phase button and then try the two modes in combination with various audio materials. Choose the setting that offers the best
presence and definition in subwoofer output. In general, the
best position will be the one that results in the heaviest bass
output.
DIAGRAM 7:
Front-Mounted Controls
Internal IR Receiver Sensor
6
SPECIFICATIONS
TS12
12” long throw
Aluminum Cone woofer
40Hz - 120Hz
Woofer
Variable Low
TS10
10” long throw
Aluminum Cone woofer
40Hz - 120Hz
Pass Crossover
High Pass
60Hz - 160Hz
60Hz - 160Hz
Crossover
Impedance
Power Rating
Magnetic Sheilding
Dimensions H x W x D
(Add 11/2” for feet)
(Add 7/8” for Rear Panel Inputs)
(In an attempt to constantly improve our products, features and specifications are subject to change without notice.)
For technical questions, please call 1-800-448-0976. We are available to assist you weekdays (except holidays) between the hours
of 7:00 a.m. and 5:00 p.m. PST. Tantra Audio offers a variety of accessories to make your installation of these speakers and our other
products easy, economical and professional. For additional information contact your Authorized Tantra Audio Dealer.
4 Ohms
250 Watts
Yes
15” x 15” x 171⁄16”
4 Ohms
500 Watts
Yes
171⁄2” x 171⁄2” x 1911⁄16”
TROUBLESHOOTING
The Tantra subwoofers are designed to function free of problems. Therefore, any trouble that might arise is usually due to an
operating error. However, if you experience a problem please check the troubleshooting list first. If the problem persists, call
Tech Support at 1-800-448-0976 or e-mail us at techsupport@tanraaudio.com. We will do our best to assist you.
The Problem Possible Causes And Solutions
No sound is heard.
A hum or buzzing sound is heard. The sound may be caused by a ground loop in the system.
The TS 10 or TS 12 will not turn on. The subwoofer must be plugged into a live outlet.
Audio cable to the receiver is not connected properly or the cable is bad.
Use another cable that you know is good.
Check all wire connections and plugs.
Try to eliminate this by reversing the AC plugs of other components in the system.
Try plugging the receiver into another outlet.
Other causes may include faulty cables.
The power switch on the back panel must be on.
A signal must be playing into the input jacks.
Press POWER button on remote control to place unit in active ON mode.
7
LIMITED 2-YEAR WARRANTY
Tantra Audio warrants to the original retail purchaser only that
this Tantra Audio product will be free from defects in materials
and workmanship for a period of two years, provided the product
has been purchased from an Authorized Tantra Audio Dealer.
Defective products must be shipped, together with
proof of purchase, prepaid insured to the dealer from
whom they were purchased, or to the Tantra Audio factory at the address listed in this manual. Freight collect
shipments will be refused. It is preferable that this product be shipped in the original shipping container so as to
lessen the chance of damage in transit. In any case, the
purchaser shall bear the risk or loss or damage in transit.
If upon examination at the Tantra Audio factory or dealer
it is determined that the unit was defective in materials or
workmanship at any time during this warranty period, Tantra
Audio or the dealer will, at its option, repair or replace the
product at no additional charge, except as set forth below. If this model is no longer available and cannot be repaired effectively, Tantra Audio may, at its sole option, replace
the unit with a current model of equal or greater value. In
some cases where a new model is substituted, a modification to the mounting surface may be necessary. If modification of the mounting surface is required, Tantra Audio shall
assume no responsibility or liability for such modification.
All products and parts that are replaced shall become the property of Tantra Audio Inc. upon their return for such replacement. Products replaced or repaired under this warranty shall be returned to the original
retail purchaser within a reasonable time, freight prepaid.
This warranty excludes service or parts required to repair
damage that has occurred due to an accident, disaster,
misuse, abuse, negligence, inadequate packing or inappropriate shipping procedures, commercial use, voltage
input exceeding the rated maximum of the unit, or the service, repair or modification of the product that has not
been authorized or approved by Tantra Audio. Moreover,
this warranty excludes normal cosmetic deterioration resulting from environmental conditions. This warranty shall
immediately become void if there is any attempt to remove, alter or deface the serial number on the product.
This warranty is in lieu of all other expressed warranties. If
the product is defective in materials or workmanship as
warranted above, the purchaser’s sole remedy shall be repair or replacement as provided above. Under no circumstances will Tantra Audio bear the liability for any incidental
or consequential damage arising from the use or inability
to use the product, even if Tantra Audio Inc. or an Authorized Tantra Audio Dealer has been advised of the possibility of such damages, or for any claim by another party.
Please be aware that certain U.S. states do not allow the
exclusion or limitation of consequential damage, in which
case the above limitation and exclusion might not apply.
All implied warranties on the product are
limited to the duration of this express warranty. Some states do not allow limitation on the length of an implied warranty.
If the original retail purchaser resides in
such a state, this limitation shall not apply.
940 Columbia Ave., Riverside CA 92507 | USA (800) 448 0976 Fax (951) 787 8747 International +1 951 787 0543 | www.tantraspeakers.com
000-012100 Rev1
Loading...
