Preface

Purpose of this document

White Paper Z600

The Sony Ericsson Z600 White Paper is designed to give the reader a deeper technical understanding of how the Z600 is designed, and of how it interacts with other media. This document will make it easier to integrate the Z600 with the IT and communications solutions of a company or organization.

People who can benefit from this document include:

• Corporate buyers

• IT Professionals

• Software developers

• Support engineers

• Business decision-makers

More information, useful for product, service and application developers, is published at http://www.SonyEricsson.com/developer, which contains up-to-date information about tech n olo gies, products and tools.

This White Paper is published by: Sony Ericsson Mobile Communications AB, SE-

221 88 Lund, Sweden Phone:+46 46 19 40 00 Fax: +46 46 19 41 00 www.SonyEricsson.com/

Second edition (September 2003) R2A Publication number EN/LZT 108 6812

This document is published by Sony Ericsson Mobile Communications AB, without any warranty*. Improvements and changes to this text necessitated by typographical errors, inaccuracies of current information or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this document are to be regarded as temporary reference copies only.

*All implied warranties, including without limitation the implied warranties of merchantability or fitness for a particular purpose, are excluded. In no event shall Sony Ericsson or its licensors be liable for incidental or consequential damages of any nature, including but not limited to lost profits or commercial lost, arising out of the use of the information in this document.

2 September 2003

Contents

Purpose of this document .....................................................................................2

Key functions and features .......................................................................................6

Two displays ..........................................................................................................6

Built-in camera ......................................................................................................6

QuickShareTM ...................... .................................................................... .............6

Exchangeable front and back covers ....................................................................7

New and innovative user interface ........... ... ... ... .................................................... 7

Pictures ........................... ................................... .................................... ................ 9

Multimedia in Z600 ...................................... ... ... ... .......................................... .... ...9

MMS (Multimedia Messaging Service) ................................................................10

MMS objects ........................ ... .... ... ... ... ...............................................................11

Benefits ........................... ................................... .................................... .............. 12

EMS (Enhanced Messaging Service) ...................................................................13

Messaging using EMS .........................................................................................14

Java .....................................................................................................................16

Games .................................................................................................................17

MIDI - Musical Instrument Digital Interface .........................................................19

Polyphonic ring signals ................................ ... ... ... .... ... ... .....................................20

Bluetooth™ wireless technology .................................................... .... .................20

Using Bluetooth wireless technology in the Z600 ...............................................21

Synchronize calendar and phone book ...............................................................21

SyncML, an open standard for remote synchronization in the Z600 ..................22

Local synchronization ............................................................... ... ........................24

WAP services .................................. ... ... .... ... ....................................... ... ... ... ... .....25

Bearer type characteristics ..................................................................................27

Gateway characteristics ......................................................................................27

Security using the WAP ..................................................... .... ... ...........................28

Configuration of WAP settings ............................................................................28

Push services .......................................................................................................29

cHTML support .................................. ... .... ... ....................................... ... ... ... ... .... .30

Mobile Internet ............................. ... ... ... .... ... ... ..................................................... 3 0

Data connections .................................................................................................30

Mobile positioning ....................................... ... ... ... .... ... ........................................30

General Packet Radio Services ...........................................................................31

Using GPRS in the Z600 ......................................................................................31

Modem and AT commands ................................................... ... ... ........................32

GSM data communication ...................................................................................32

AT commands support ........................................................................................33

Online Developer Resources ...............................................................................33

Sony Ericsson Developer Support .......................................................................34

Infrared transceiver ..............................................................................................34

Connection via infrared ........................................................................................34

Network-dependent features ...............................................................................41

SIM application toolkit .........................................................................................42

SIM AT services supported by the Z600 ........................ ... .... ... ... ........................43

User interaction with SIM AT ...............................................................................46

Security and M-commerce technical data ..........................................................47

Terminology and abbreviations ...........................................................................47

Related information .............................................................................................50

White Paper Z600

3 September 2003

Technical specifications ..................................................... ... .... ... ... ... .....................51

General technical data ....................... ... .... ... ... .......................................... ... ........52

Exterior description ..............................................................................................52

Ambient temperatures .........................................................................................53

Supported Man-Machine Interface (MMI) languages ..........................................53

Current consumption, talk and standby times .................. .... ... ... ... .....................54

Speech coding .....................................................................................................54

Cell broadcast service .........................................................................................54

Short message service ................ ... .....................................................................56

Enhanced message service .................................................................................58

Multimedia message service ................ .... .......................................... ... ... ... ........60

Bluetooth technical data .............................. ........................................................62

Performance and technical characteristics .........................................................62

Tone and percussion maps in the Z600 ..............................................................63

Percussion map ...................................................................................................66

WAP browser technical data ...............................................................................67

WAP Operator technical data ..............................................................................69

GPRS technical data ...........................................................................................73

Built-in GSM data modem technical data ...........................................................76

E-mail client technical data ............... ... .... ... ........................................................76

USSD technical data ...........................................................................................78

Image format technical data ................................................................................78

Images – downloading to phone .........................................................................78

SyncML technical data ...................................... ... .... ... ... ... ..................................80

Infrared transceiver technical data ......................................................................80

White Paper Z600

4 September 2003

White Paper Z600

Product overview

Z600 is a dynamic and easy to use high-en d mobile phone. It offers complete imaging and messaging capabilities that allow family and friends to capture, share and preserve those special moments.

Designed for fun-loving people, the Z600 features a distinctive clam shell body cloaked in vibrant, youthful colours. This visual statement is complemented by extensive functionality and offers the user endless possibilites in mobile communications.

Z600 features an active flip, two displays and its built-in camera makes taking a picture quick and easy. Pictures can be used as wallpapers, in multimedia messages and in the phone book.

5 September 2003

Key functions and features

Two displays

White Paper Z600

The Z600 features two displays. When in the open position, the user can enjoy the ultimate viewing experience afforded by the 65,536 full colour LCD. The LCD has 128x160 pixels and is a 2” film diode (TFD) type which is driven by a diode as opposed to a transistor. The display has a 16 bits pixel memory depth. Camera pictures, picture messages and gaming are all enhanced by the crisp, sharp colours afforded by the TFD. The screen also offers the user maximum information with the least scr olling.

Built-in camera

The built-in camera is capable of taking still pictures up to common image format (CIF) resolution (352x 288 pixels) and 24 bit colour depth. The lens is recessed into the front co ver of the Z600. The viewfinder will fill up the whole screen, irrespective of the resolution at which the picture is taken. A dedicated hardware button provides fast access to the camera application.

When in the closed position, a status display with 91x29 pixels is visible. This black & white display has a blue background and lets you see who is calling when a call comes in and also shows information such as time, network and battery status.

ing that all of the free storag e is available for the camera application and using the current settings for size and quality. Approximate JPEG file sizes are 20 kbytes for CIF.

Saved images may be viewed in the image viewer application, and are available for use by other applications in Z600 such as MMS and e-mail.

Images are stored in the phone’s filing system and are therefor e available for o ther applications to use . The number of images that can be s t ored depends on the available file space, which is shared with other applications. The viewfinder will give an estimation of the number of images remaining, assum-

QuickShare

The Sony Ericsson QuickShareTM is the smartest, fastest and easiest way to share images. By combining several imaging features and capabilities in

the Z600, QuickShare with two rapid clicks and then in four further steps send it anywhere in the world.

lets you take a picture

The camera is optimised for ‘point-and-shoot’ speed. The first press on the Commun iCam but ton will switch on the viewfinder. Each subsequent press on the button will then act as a shutter release and take a picture.

It is also possible to exchange pictures directly over Bluetooth connections and even drag and drop pictures to and from the Z600 and a PC.

6 September 2003

Exchangeable front and back covers

White Paper Z600

Exchangeable front and back covers are available as accessories. These covers come in an array of wonderful colours that allow the user to change the look of their Z600.

Whether it’s to complement an outfit with colour coordination, make a pleasant change to your existing phone, or simply match the way you feel, Z600 exchangeable covers offer endless possiblities.

New and innovative user interface

The Z600 has a new, innovative user interface which enables the user to manage the phone in an easy and efficient way. Combined with attractive graphics in a wide variety of styles, the new user interface gives the user a new and stimul ating experience.

The development of the new user interface is founded on usability tests performed on a wide range of mobile phones - Sony Ericsson phones a s well as competitors’. The result is a new interface that is easier and quicker to use than the vast majority in products on the market.

The keys to efficiency

The lay out of the keys is one of the many new and improved elements in the Z600, helping the user to find functions and features in the phone quickly and easily. Conveniently and ergonomically grouped together on the front, the two soft keys, a navigation key, the back key and the “C” key enable the user to navigate, select and perform actions.

7 September 2003

Actions and options

The left and right soft keys perform the actions shown immediately above these keys in the display. The most frequently used actions are always available on the left soft key. Other actions are accessible on the right soft key, directly on the key or via the More list. Since most of the common actions are carried out by the left soft key, the back key is conveniently placed immediately under it.

Back and delete

The Back key enables the user to go back one step at the time. It makes it easy to find the way back, but more importantly gives the possibility to recover from mistakes. To pr ess and hold the Back key is an instant return to stand by.

The “C” key is used to delete items and to turn off sounds:

White Paper Z600

• Press and hold in Stand by - activate silent mode

• Press and hold during ongoing call - mute

• Normal press during incoming call - mute ring

More Features

The key features in the phone are easily accessible, and the main menu is reached by a press with the navigation key in stand by. It is also accessible during an ongoing call, which allows for multitasking an air time generator. The main menu gives an overview of all functions and features in the phone.

Actions in the Z600 are always carried out in the most efficient way, and ther e is always a visible status bar at the top of the display. The status bar extends the usage of non voice features by displaying icons and indicators of ongoing actions.

The already popular Themes in Sony Ericsson mobile phones have been further developed and improved in the Z600, enabling the user to personalize the phone with pictures, colours, wallpapers, etc. The Themes and all their features are displayed in the large 65k colour screen, which gives a unique user experience.

8 September 2003

White Paper Z600

Technologies in detail

Pictures

Pictures is the Z600’s image viewer. It enables you to view and organise your photographs, including pictures taken by the built-in camera plus images loaded from elsewhere, such as received via eMail. Pictures supports image types JPEG, GIF, Animated GIFs and WBMP.

Pictures can be viewed in thumbnail and full screen mode. Thumbnail images may be ordered by name, date, size or type. In full screen mode the user can browse through the images and rename or delete them. It is also possible to send them as e-mail, MMS messages or via Bluetooth and infrared. Sim-

ply select a picture, add a message and send just like an SMS message or build a slide show with several images and your favourite sound clips.

Pictures of loved ones can be saved in Contacts. When a contact calls (or the user calls that contact), the picture is displayed with the details of the call. This is known as Picture Phone Book.

Pictures may be loaded up to the Internet. Sony Ericsson Mobile Internet has an on-line album enabling you to share pictures and video clips: wap.sonyericsson.com

Multimedia in Z600

Graphics

Graphics (tables, charts, diagrams and layouts) have a major impact on the way we work. The Z600 supports JPEG (max 640x480), GIF (max 160x120 ), WBMP (max 320x320) and animated GIFs. With

MMS, the user can personalize the appearance of the display – for example the background colours and the background picture.

9 September 2003

White Paper Z600

F m

Audio

With the sound recorder function in the Z600, it is easy to make a voice recording, for example a personal rendition of “Happy Birthday”. The audio function in the Z600 also allows downloading of sounds and melodies.

Themes

With themes, the user can change the appearance of the display, for example the background colours and the background picture. The phone comes with a number of pre-defined pictures, and it is possible to download additional themes. The maximum number of themes is limited only by the amount of memory.

MMS (Multimedia Messaging Service)

One of the key features in the Z600 is the Multimedia Messaging Service (MMS), this is expected to become the preferred messaging method of mobile terminal users, since there are virtually no limits to the content of an MMS transmission. An MMS message (also known as a Picture Message) from the Z600 can contain text, pictures, graphics, animations, images, audio clips and ring melodies. For more detailed information, see “Multimedia mes- saging service” on page 53. For third-party developers’ information, please visit www.SonyEricsson.com/developer and look for the MMS Developers’ guidelines.

Defined and specified by 3GPP as a standard for third generation implementation, MMS completes the potential of messaging. Sending digital postcards and PowerPoint-style presentations is expected to be among the most popular user applications of MMS. Eagerly awaited by young users in particular, MMS is projected to fuel the growth of related market segments by as much as forty percent.

igure 1. An MMS message can contain images,

usic, audio and graphics.

Using the Wireless Application Protocol (WAP) as bearer technology and powered by th e h igh- speed transmission technologies EDGE, GPRS and UMTS (W-CDMA), Multimedia Messaging allows users to send and receive messages that look like PowerPoint-style presentations. The messages may include any combination of text, graphics, photographic images, speech and music clips. MMS messaging will serve as the default mode of messaging on all terminals, making total content exchange second nature. From utility to sheer fun, it offers benefits at every level and to every kind of user.

10 September 2003

MMS objects

White Paper Z600

Although MMS is a direct descendant of SMS, the difference in content is dramatic. The size of an average SMS message is about 140 bytes, while the maximum size of an MMS message is limited only by the memory. That is why the key word to describe Picture Message content is rich. Complete with words, sounds and images, MMS content is endowed with the user’s ideas, feelings and personality. An MMS message can contain one or more of the following:

Text

As with SMS and EMS, an MMS message can consist of normal text. The text can consist of up to 1000 characters. The main difference between an EMS and MMS message is that in an MMS message, text can be accompanied not only by simple pixel images or melodies but by photographic images, graphics, audio clips and in the future, video sequences.

Templates

The Z600 comes with a number of MMS predefined templates, for example templates for birthday cards, meeting requests etc.

Audio

MMS provides the ability to send and receive full sound (iMelody and AMR) messages. Not only can users share a favourite song or ring signal with a friend, they can also use the mobile phone to record sound and send it along with a message. Because sound includes speech as well as music, this extra dimension of an MMS message makes for enhanced immediacy of expression and communication. Rather than sending a downloaded birthday jingle in EMS, for example, a user can send a clip of his or her own personal rendition of “Happy Birthday”.

Mobile picture transmission als o offers inestimable utility in business applications, from sending onsite pictures of a construction project to capturing and storing an interesting design concept for later review. Editing a picture by adding text allows users to create their own electronic postcards, an application that is expected to substantially cut into the traditional postcard-sending market.

Themes (downloaded or pre-defined) can be exchanged via MMS.

SMIL presentations

SMIL stands for Synchronized Multimedia Integration Language and is pronounced “smile”. SMIL in the Z600 allows the user to the create and transmit PowerPoint-style presentations on the mobile device. SMIL is an advanced XML-based protocol, and Sony Ericsson MMS supports a subset of this protocol. Using a simple media editor, users can incorporate audio and animated GIFs along with still images, animations and text to assemble full multimedia presentations.

The idea of SMIL is to allow the user to customize the page timing in PowerPoint-style presentations. The user can decide in which order the image and text will be displayed, as well as for how long the images and text lines are to be shown in the display

PIM communication with MMS

With MMS in the Z600, it is easy to send and receive business cards, calendar entries and notes.

Business card (vCard)

With MMS in the Z600, the user can send a business card.

Pictures and themes

By using the built-in digital camera in the Z600 users can take a snapshot and immediately send it to a recipient. The ability to send pictures is one of the most exciting attributes of MMS, as it allows users to share meaningful moments with friends, family and colleagues.

Calendar entry (vCal)

With the vCal function the user can enclose a vCal entry when sending a meeting request via MMS.

Notes

The Z600 supports vNote. Notes can be sent via MMS.

11 September 2003

Benefits

White Paper Z600

Essentially enabling the mobile terminal to serve as image processor and conveyor, Multimedia Messaging accommodates the exchange of important visual information as readily as it facilitates fun. Business and leisure usage of MMS will be dynamically merged, resulting in enhanced personal efficiency for users and increased network activity for operators. In short, MMS affords total usage for total communication

Because MMS uses WAP as its bearer technology and is being standardized by 3GPP, it has wide industry support and offers full interoperability, which is a major benefit to service providers and end users. Ease-of-use resulting from both the gradual steps of the messaging evolution and the continuity of user experience gained from interoperability is assured.

The MMS server, through which MMS messages are sent, supports flexible addressing (to both normal phone numbers (MSISDN) and e-mail accounts), which makes user interface more friendly and allows greater control for operators. The MMS server, moreover, is responsible for the instant delivery feature of MMS.

acts with the application being run on the MMSenabled terminal to provide various messaging services. WAP is used as bearer of an MMS message between the MMS-C and the MMS client (application). The WAP Gateway is used for delivery and retrieval of messages.

MMS technical features

The MMS standard, just like SMS, offers store-andforward transmission (instant delivery) of messages, rather than a mailbox-type model. MMS is a person-to-person communications solution, mea ning that the user gets the message directly into the mobile phone. He or she doesn’t have to call the server to get the message downloaded to the mobile phone. Unlike SMS, the MMS standard uses WAP as its bearer protocol. MMS will take advantage of the high speed data transport technologies EDGE and GPRS and support a variety of image, video and audio formats to facilitate a complete communication experience.

Architecture

The MMS Centre (MMS-C) is comprised of the MMS Server, the MMS Proxy-Relay and the MMS Store. The MMS Centre is the central element of the MMS network architecture, providing storage and operational support, enabling instant delivery of multimedia messages from terminal-to-terminal and terminal-to-e-mail, and supporting flexible addressing. The centre’s MMS Proxy-Relay inter-

12 September 2003

White Paper Z600

Figure 2. The architecture of MMS

Message conversion

The MMS-C is able to perform limited message conversion - for example, from MMS to SMS - so that processing and air time is not wasted in sending messages to mobile terminals that do not have adequate capability to receive them. It also handles service aspects such as store and forward, guaranteed delivery, subscriber preferences, operator constraints, and billing information. The MMS-C also vouches for high quality messaging, e.g. by format conversion. This means that the MMS-C

recognizes which formats are supported in the mobile phone, and adapts the MMS messages to these formats.

OTA configuration

Users can easily get MMS into their phone. MMS supports OT A, meaning that the user does not have to configure the settings manually. The configuration is done by the operator.

EMS (Enhanced Messaging Service)

EMS uses existing SMS infrastructure and industry standards, keeping investments to a minimum for operators and providing a familiar user interface and compatibility with existing phones.

Sounds and melodies

EMS gives the user the ability to send and receive melodies. These can be pre-defined sounds, downloaded from the Internet, received in SMS messages or composed by the user on the phone keypad or a PC.

13 September 2003

White Paper Z600

Several sounds and melodies can be inserted in one message, and they can be combined with pictures.

Pictures and animations

Phones supporting EMS include a set of predefined animations. New pictures and animations can be downloaded from the Internet or received in SMS messages.

Messaging using EMS

Concatenated messages

A part of the EMS standard is the support for concatenated messages, which means that the phone is able to automatically combine several messages both when creating and receiving EMS. This is useful to be able to build and display messages with rich content since the amount of information in each SMS is limited by the SMS standards.

Compatible with SMS standards

Users will find EMS as easy to use as SMS. At the moment 15 billion SMS messages, are sent every month worldwide. Roughly 80% of this traffic is user-to-user i.e. mobile phone users sending short messages to each other using the keypad of the phone to enter text. The remaining 20% is shared by downloads and notifications of different kinds.

Huge business potential

Network operators can now enhance their services and attract more customers by offering pictures, animations, ring signals and melodies for downlo ad at their portals. Operators can charge more per EMS message since it contains more data. Thereby EMS adds more value to the operators and to the end users.

Pictures can be created and edited in the phone using a built-in Picture Editor. Several pictures can be inserted in one message, and they can be combined with sounds and melodies.

now stable and complete as part of the 3rd Generation Partnership Project (3GPP) technical specification.

EMS dynamics

An EMS message can be sent to a mobile phone that does not support EMS, or only supports part of EMS. All the EMS elements i.e. text formatting, pictures, animations and sounds are located in the message header . The EMS contents will be ignor ed by a receiving phone that does not support the standard. Only the text message will be displayed to the receiver. This is true consumer-friendly standardization.

Examples of EMS contents and applications

A wide range of contents, applications and services may be developed. Below is a list of examples and areas where messaging can be enhanced with EMS.

User-to-user message

Messages usually originating from the keypad of a mobile phone can include pictures, animations, melodies, formatted text with EMS.

Standards

The Enhanced Messaging Service (EMS) was first submitted to the standards committees by Ericsson. Ericsson presented the outline structure of EMS to the relevant ETSI/ 3GPP committees. The major mobile phone manufacturers and most operators are actively contributing to the 3GPP standards. Hence the EMS standard has evolved and is

Vo ice and e-mail notifications

Notifying mobile phone users that they have new voice or fax mail messages waiting - including icons or melodies with EMS.

14 September 2003

White Paper Z600

Unified messaging

The user typically receives a sh ort message notifying them that they have a new message in their unified messaging box, with icons or formatted text further enhancing the message.

Internet e-mail alerts

An Internet e-mail alert is provided in the form of a short message that typically details the sender of the e-mail, the subject field and first few words of the e-mail message, and in this case formatted text is excellent to identify message elements.

Ring signals

Downloading ring signals from the Internet

News & commercials

World news illustrated, sports scores and news headlines, finance and stock mark e t n ews wi th diagrams and tickers, commercial product promotions, weather reports with maps, tunes from TV commercials as ring signals.

Info & entertainment

Ring signals, e-greetings, football club logo, jokeof-the-day illustrated by pictures or sound, horoscopes, movie related animation or theme so ng, TV show promotions, music artist promotions, lottery results, food and drinks pictures and recipes, mood-related pictures.

call centres providing answers to questions about a product, vehicle positioning combining EMS with Global Positioning System (GPS) position information, job dispatch with delivery addresses for sales or courier package delivery, using EMS in a retail environment for credit card authorization, remote monitoring of machines for service and maintenance purposes.

Using WAP, WAP and SMS for download

Already today services exis t on the Internet where users can create melodies, an d v iew ico ns an d pic tures, subscribe to entertainment and informations services. These may develop further in the future to support access via PC over the Internet, from the phone using WAP and even with an SMS request interface.

Corporate

Flight schedules, pre-installed corporate logos, map snippets and travel info, company branded icons and ring signals, corporate e-mail notifica tions, affinity programmes where companies notify customers of product updates e tc., banks notifying customers about new services and interest rates,

15 September 2003

Java

J2ME CLDC Sandbox

JAR file resource

MIDP Application

running on

MIDP /CL DC/ kVM

Persistent Storage

User Interface

HTTP/ Dat agram

White Paper Z600

Internet

Services and pages with response in HTML format

Other networked devices (datagram communication)

The Z600 supports J2ME CLDC/MIDP. It is ready to run applications written for handheld computers and mobile phones.

Applications are easily downloaded directly to the Z600 using the browser, or may be installed from a connected PC. Applications such as the currency converter can obtain the latest exchange rates from the Mobile Internet and then ma ke up-to-d ate calculations. It is also possible to access and download data from a company server.

Z600 supports JSR-135 allowing control of the synthesizer for MIDI, I-melody and Tone sequence playback.

Sandbox security concept

J2ME/CLDC uses a sandbox security concept which includes a number of system components working together to ensure that untrusted applications cannot gain access to system resource.

Selection keys

When executing a MIDP application a lower portion of the screen is reserved for displaying selection keys associated with the application. The appearance of this soft key area at runtime depends on which base class the displayed application is derived from.The left soft key is for the first command in the command list and the right soft key is for the “More” list and “Help”.

Optional download features

The browser can download JAR/JAD files from WAP and HTML pages provided that the server supports the actual file types. Z600 can also download JAD/JAR files from ordinary WAP servers provided that they support the mime type for each of the file types.

Supported protocols

The Z600 supports “Sun OTA recommended practice for J2ME CLDC/MIDP” and ordinary MIDP 1.0 applications without extension API’s.

Sony Ericsson Online Support

Some online resources are available to all developers for free. All that is needed is to register as an Ericsson Mobility World Community member. After registration, access is granted to selected technical product information and development tools as well as limited access to interactive and static online support resources.

16 September 2003

White Paper Z600

General information Note: For more information see “Java in Sony Eric-

Implementation

CLDC 1.0 MIDP 1.0 JSR 135 Support Over the Air Recom-

mended Practice

Permissions Net Access

Memory

Heap size (RAM) 256 KB Max no.of applications 50 Size of applications Approximately 60 KB

sson mobile phones” at www.SonyEricsson.com/ developer

File system size Up to 2 MB Number of simultaneous

executing applications

One

Games

Z600 has four games pre-loaded and more can be easily downloaded. The games download is made possible by a true virtual machine. The Sony Ericsson portal for downloading of free games for the Z600 is accessible with only one key press in the games menu. The openness of the downloadable games solution is dedicated to provide an enhanced gaming experience.

Downloadable games can fully take advantage of the phone´s interfaces, such as TCP/IP, SMS/MMS, 32 voices polyphonic sounds, and vibrator. The virtual machine executes the downloading of games for the optimal game experience. The user can download an unlimited number of games as long as the file system allows it, i e until the phone memory is full.

The downloading concept includes certification of the games, which makes it possible to create a revenue chain and favourable business opportunities

for network operators and content providers. The virtual machine uses true sandbox technology for the highest level of security.

mophun ™

mophun™ is a software based ga ming console fo r mobile terminals. It offers the user optimized graphics and interaction access to ensure the best possible gaming experience.

mophun revenue for operat ors.

™ gamelets will drive traffic and increase

mophun RTE

The mophun™ runtime environment consists of a virtual machine that requires less than 40kb of memory. Its small size means that it can fit inside the instruction cache of the host CPU. It has a native code interface that requires as little as 10 machine instructions (depending on the host system) overhead for calls to native functions.

17 September 2003

White Paper Z600

Gaming API

The gaming API provides all the functionality a game requires. It provides platform independent video access, input, sound and communication. It also features a query interface that lets you adapt a game to the capabilities of the device. The API consists of 100% native code that ensures the best possible performance.

Because different platforms have varying capabilities, this gaming API has been created with differentiators such as a built in sprite engine, map engine, differen t color depth t iles and t ranspar e ncy support etc. With this gaming API it is possible to isolate code and data into modules that can be loaded according to the capabilities of various platforms. It is possible to have both grayscale and color graphics resources but only load the specific resources that are compatible with the surrounding system. Games that do not provide multiple resources are not a problem because the mop-

hun

™ system automatically handles the conver-

sions. Indeed, future extensions even include a 3D API.

Certification and deployment

Each game must be certified by Synergenix Interactive AB before it can be run on a mobile phone. This ensures there is no offensive content, that the game is of sufficient quality and that the gameplay and functionality conform to settled standards.

A game file can be downloaded via WAP or cable from an operator’s page or from any publisher’s WAP page. If the download is supposed to be in one session, the file size should be less that 60 000 bytes.

Game file sizes

Each game has its own directory in the file system. A game directory in the Z600 can contain up to 16 different files but together they may not exceed an aggregate of 480 000 bytes.The maximum size of files for downloading depends on the size of the WAP gateway. When provisioning mophun games that are larger than the WAP gateway limitation, the games may be split up in portions and reassembled on the mobile terminal.

Secure gamelets

mophun™ gamelets are executed in a secure sandbox environment that eliminates any possibility of illegal actions. A secure layer exists between the mophun interfaces. Security is furt he r enha nc ed as result of the gamelets having to be digitally signed before execution on the mobile terminal is possible. Gamelets are signed in the publishing pr ocess after being screened for malicious content.

™ application and the “real” system

Software development kit

The mophun™ SDK is built with GNU tools using open standards. It is non-proprietary and is offered to developers completely free of charge. Games are written in C/C++ or assembler and the kit was built by game developers. A general PC can be used to both write and test the software without any need to access the real device. Source level debugging is available for both the Linux and Windows versions of the SDK.

Emulation profiles for the target mophun bled mobile terminal are included in the SDK. It also ships with a full set of binary utilities for manipulation and handling of code, data and resources.

™ ena-

Functions

Send/receive via TCP/IP link Yes Send/receive via SMS Yes Send/receive via Bluetooth Yes Send/receive via infrared Yes Vibrator on/off Yes Backlight on/off Yes Colour support Yes Certification control of games Yes True sandbox technology Yes True file support Yes Sprite detection collision Yes Built-in Unicode including Chinese Yes

Getting started

In order to receive the mophun™ SDK developers must go to http:// www.mophun.com load the free software. Developers will also benefit

and down-

18 September 2003

from the full support package that is available at http://www.SonyEricsson.com/developer thing needed to begin developing games for Son yEricsson mobile phones is available at these sites free of charge.

Every-

Game controls

Use the navigation key to move up, down, left or right and to select an item, or use the keys as follows:

left and up

left

left and down down

select or fire

White Paper Z600

right and up

right

right and down

Press once to go back one level in the menus. Press and hold to return to standby. Exit the game.

Select the options that might appear in the display immediately above these keys.

Delete numbers, letters or an item from a list.

Other useful key functions:

• Press

Note: The above text and control panel does not

apply to Java games.

START to start a new game. EXIT to finish a game. MORE to delete, view game info, or view

memory status.

MIDI - Musical Instrument Digital Interface

The Z600 contains an advanced MIDI composer that allows the user to compose melodies and ring signals in polyphonic sound. A MIDI signal or file does not contain any music. It contains binary data (information) of how a melody is played and when this data reaches a synthesizer, the synthesizer will translate the binary data to mus ic, when connected to an amplifier with speakers so that the sound becomes audible.

The development from the iMelody format to the MIDI format means a revolution to the sound quality. The MIDI files are small, and perfect for mobile devices, which have limited storage capacity.

MIDI is a specification for a communications protocol principally used to control electronic musical instruments. MIDI is today a well known standard used by musicians, composers and arrangers.

Composing

You can compose and edit melodies to use as ring signals. A melody consists of four tracks - Drums, Basses, Chords and Accents. A track contains a number of music blocks. The blocks consist of prearranged sounds with different characteristics. The blocks are grouped into Intro, Verse, Chorus, and

19 September 2003

Break, depending on where in the melody they fit in. You compose a melody by adding music bloc ks to the tracks.

Polyphonic ring signals

White Paper Z600

Protocol

The Z600 has a hardware synthesizer chip, built into the mobile phone. The software controls the MIDI files, and makes sure they fit into the hardware chip. It is possible to modify the dynamics, and it is possible to make the sound escalate, start quietly and grow louder.

The Z600 Sony Ericsson mobile phone completely supports the MIDI 1.0 detailed specification. Please visit http://www.midi.org/ for more information.

Excellent sound quality – 32voices

The human ear can hear sounds from approximately 20 Hz up to 20 KHz. In most GSM mobile phones, the speech sound range is from 300 Hz to 3400 Hz, which is good enough for speaking, but quite poor for music. The Z600 can handle up to 15000 Hz, equivalent to an FM stereo radio, which means excellent sound quality.

Z600 has a dedicated speaker to ensure the best possible sound quality. This speaker is situated on the back of the phone ensuring no discomfort is f elt if a second call is rece ived during an ongoing call. It also ensures louder ring signals and removes the need for escalating rings signals.

The quality of the sound heard from the speakers depends on many different things, for example on the synthesizer, the amplifier, or the speakers. An important factor for sound quality is the number of voices. The human ear cannot separate each voice if the number of voices increases above about 16, then the voices merge t ogether. But the nuances in the music increase, and the music is experienced as more sophisticated if the number of voices increases. Many modern sound modules in synthesizers used by musicians have 16, 24 or 32 note polyphony. The number of voices used in the Z600 is 32, which gives excellent sound quality.

Wavetable synthesis

Sony Ericsson has chosen to implement the Wavetable synthesis, which consists of sampled real instruments, which gives a much higher qua lity than the FM-synthesis. Especially the treble is mor e distinguished.

Touch correct feature

The so called “Touch correct” feature makes dynamic compression possible. This equalizes the amplitude of the instruments included in the MIDI file, which greatly improves the sound quality, especially in melodies with big differences in a mplitude.

Bluetooth™ wireless technology

The Z600 features built-in Bluetooth wireless technology. Its short-range radio link operates in the globally available 2.4 GHz radio frequency band, ensuring fast and secure communications up to a range of 10 metres.

Bluetooth wireless technology is designed to be fully functional even in noisy radio frequency environments. All data transfer is protected by advanced error-correction methods, ensuring a

high level of data security. Bluetooth wireless technology facilitates instant connections, which are maintained even when the devices are not within line of sight. High-quality voice transmission is provided under adverse conditions, making it possible to use a headset connection to the Z600 at all times.

20 September 2003

White Paper Z600

Ericsson was a founding partner of the Bluetooth Special Interest Group (SIG). Bluetooth wireless technology devices that are expected to be available in the near future, include:

• Headsets for wireless voice transmission and remote call control

• PCs, laptops, PDAs, palmpads for data transfer, synchronization etc.

•PC cards for Bluetooth wireless technology in laptops and PDAs

• MP3 music player

• Other phones for exchanging business cards, ring signals, playing games etc.

• Digital still and motion video cameras

• Printers, hard disks and other storage devices

• Handheld scanners for text, barcodes and images

• Household appliances with built-in logic, as well as games and entertainment devices

• Access points in hotel lobbies and airports for connecting to computer networks and the Internet

• Car handsfree solutions

Using Bluetooth wireless technology in the Z600

Key benefits include:

• True wireless connection

• Cable replacement for connecting to headsets, computers, networks, printers and other devices.

• Secure and fast

• Data connection with a Bluetooth PC/laptop turns the phone into a modem for connecting to the Internet and for data transfer (faster than infrared or cable).

• The Z600 identifies and maintains several devices in a pairing list.

• Radio link

• No line of sight required; the phone can remain in a briefcase or in a pocket, as long as no solid objects are in between (whereas infrared requires line of sight).

•Synchronization

• Fast synchronization, even without line of sight, of calendar and phone book with PC/lapt op and PDA, and quick exchange of business cards, calendar events and melodies with other phones and devices.

Synchronize calendar and phone book

In everyday life, access to a n updated calendar and addresses of friends and business colleagues is greatly appreciated. To be truly mobile, users must be able to carry their important information with them. Equipping mobile phones with Personal Information Manager (PIM) programs such as calendars, to-do lists and address books gives users access to their most important data anywhere and

anytime. The information is kept updated by synchronizing with the information at the office or at home.

Hierarchical phone book with contacts

The Z600 features a hierarchical phone book. For every contact, details such as name, home, work and mobile numbers, pager number, e-mail

21 September 2003

White Paper Z600

address and other information can be stored. The hierarchical phone book in the Z600 is compatible with most groupware and agenda programs, such as Microsoft Outlook, enabling smooth local synchronization of contact information between the

phone and a PC, via cable, Bluetooth wire less technology or IR. For remote synchronization of Contacts and Calendar over WAP, the Z600 supports SyncML.

SyncML, an open standard for remote synchronization in the Z600

SyncML – background

The SyncML Initiative Ltd. was founded by Ericsson, IBM, Lotus, Motorola, Matsushita, Nokia, Palm Inc., Psion and Starfish Software in February

2000. Supported by more than 60 software and hardware developers, the SyncML Initiative Ltd. seeks to develop and promote a globally open standard for remote synchronization, called SyncML. Unlike many other synchronization p latforms, SyncML is an open industry specification that offers universal interoperability. Because it uses a common language, called XML, for specifying the messages that synchronize devices and applications, SyncML has been called the only truly futureproof platform for enabling reliable and immediate update of data. The benefit for the e nd user is that SyncML can be used almost anywhere and in a wide variety of devices, regardless of application or operating system.

special challenges of wireless synchronization, such as relatively low connection reliability and high network latency. SyncML supports synchronization over WAP, fixed networks, infrared, cable or Bluetooth wireless technology.

In the Z600 SyncML enables synchronization over WAP – an ultimate solution for travellers.

What is SyncML?

SyncML is the common language for synchronizing all devices and applications over any network. SyncML leverages Extensible Markup Language (XML), making SyncML a truly future-proof platform. With SyncML any personal information, such as e-mail, calendars, to-do lists, contact information and other relevant data, will be consistent, accessible and up to date, no matter where the information is stored. For example, a calendar entry made to a mobile device on a business trip is equally available to a secretary in a network calenda r. SyncML is the ultimate choice for remote synchronization.

In the Z600 SyncML supports remote synchronization of the calendar and phone book, designed for the requirements of the wireless world

SyncML is designed specifically with the wireless world’s tight requirements in mind. SyncML minimizes the use of bandwidth and can deal with the

22 September 2003

White Paper Z600

Benefits of a common synchronization protocol

End users

Today’s user of mobile devices probably uses a different synchronization product with every device. Each technology can synchronize only a few applications, or is limited to a particular type of ne twork connection. This arrangement is expensive to install, confusing to configure and operate, and costly to administer. With SyncML, users will be able to buy devices that synchr onize with a br oader range of data.

Device manufacturers

Device manufacturers will benefit from a common protocol that will make the device interoperable with a broader range of applications, services, and network and transmission technologies.

Service providers

Service providers moving into the growth area of application hosting are particularly concerned that a proliferation of synchronization technologies will

make it impossible to deploy and support their customers in a cost-effective manner. To support the range of data types and devices in use today, service providers must install and configure multiple server infrastructures, maintain and support that infrastructure, and maintain compatibility and performance. The alternative now available, to use a single solution for data connectivity, involves the risk of a tight coupling to a propriety solution. With SyncML, they will be able to provide connectivity to a wider selection of applications.

Application developers

Choosing to support multiple synchronization technologies enables an application to support more types of devices and networked data , bu t th at choice comes at a cost. With SyncML, application developers will be able to develop an application that can connect to a more diverse set of devices and network data.

23 September 2003

Network operators

As multiple applications that need remote synchronization over WAP are developed, there will be an automatic growth of r evenue for netwo rk operators.

Local synchronization

White Paper Z600

Open standard

Synchronization is possible with almost any groupware or office program, since the synchronization method complies with the open standard IrMC 1.1, as specified by the Infrared Data Association – reference http://www.ird a.org. IrMC 1.1 brings together the following standards:

• vCard 2.1 for address book information

• vCalendar 1.0 for appointment and to-do information

• ObEx (Object Exchange) for data exchange

Bluetooth wireless technology or infrared

The Z600 synchronizes using the same protocol, regardless of connection type. It connects via Blue- tooth wireless technology, infrared or cable. The cable is connected either directly to the phone or to the desktop charger.

Automatic synchronization

When infrared or Bluetooth wireless technology is switched on in the phone, the synchronization process starts automati cally, as soon as the phone is within range of a compatible port on a PC or handheld device (a suitable synchronization program must be running on the device).

Intelligent process

A synchronization engine performs the task of synchronizing. For local synchronization, the synchronization engine is an application that runs on the desktop computer. The synchronization engine compares, updates and resolves conflicts to ensure that the information in the phone is the same as that in the computer.

Local synchronization software and the Z600

PCs equipped with XTNDConnect For Sony Ericsson will perform synchronization with Microsoft Outlook. For other groupware environments (Lotus Notes, etc.), the full version of XTNDConnect PC is required. By using Bluetooth wireless technology, infrared, USB or the RS 232 Cable, you can easily perform a fast, local synchronization.

Integration between XTNDConnect For Sony Ericsson and Microsoft Outlook provides an embedded menu for one-key synchronization.

To enhance functionality and compatibility further, the synchronization software can easily be upgraded.

The number of units that can talk to each other is unlimited. One phone can be partner with several PCs. This ensures that information from both the work PC and the home PC can be synchronized with the phone. For users that have both a desktop PC and a laptop (free version XTNDConnect PC) or a PDA (free version XTNDConnect PC), it is an efficient way to synchronize data with the phone. This way, data can also be transferred between PCs to keep them in sync.

If the synchronization software is upgraded to a full version of XTNDConnect PC, one PC can be partnered with several different phones. This is vital if, for example, each member in a work group has his/ her own Z600, and needs to synchronize with a PC. It makes it easy, for example, to download a common company phone directory to the phone book in each company mobile phone. With the full version of the synchronization software, other phone types and handheld devices, such as PDAs and Windows CE computers, can also be synchronized.

24 September 2003

White Paper Z600

XTNDConnect for Sony Ericsson

This synchronization software can be downloadedfrom www.SonyEricsson.com/developer and provides a powerful set of functions:

• Z600 phone book and calendar synchronization with Microsoft Outlook.

• An embedded synchronization in Microsoft Outlook, providing one-key synchronizat ion and allowing the user to control the synchronization process with easy-to-use settings.

• PC applications supported by XTNDConnect For Sony Ericsson:

• Microsoft Outlook 97, 98, 2000

• Platforms for using XTNDConnect For Sony Ericsson:

• Windows 98, Me (Millennium Edition), Windows NT 4.0 and 2000.

• Pentium II recommended

• 64 MB RAM recommended (minimum 32 MB)

• Other requirements:

• 20 MB free hard disk space

• Bluetooth wireless technology , infrar ed, or cable connection

• Support is handled by Sony Ericsson.

XTNDConnect PC

All users of the Z600 can easily upgrade to the full version of the synchronization software. A number of features and supported applications will then be added, including XTNDConnect Phone Viewer.

• Phone book and calendar synchronization for the Z600.

• XTNDConnect Phone Viewer for easy data entry. All data can be created, viewed and edited on a PC.

• PC applications supported by XTNDConnect PC (full upgraded version):

• Microsoft Outlook 97, 98, 2000

• Lotus Notes 4.5, 4.6, R5

• Lotus Organizer 4.1, 5.0, 97, 97 GS, 6.0

• Symantec ACT! 3.05, 4.0, 2000

• NetManage Ecco Pro 4.0

• GoldMine 3.0, 4.0 (StandardEdition)

• Platforms for using XTNDConnect PC:

• Windows 98, Me (Millennium Edition), Windows NT 4.0, 2000 and XP.

• Pentium II recommended

• 64 MB RAM recommended (minimum 32 MB)

• Other requirements:

• 20 MB free hard disk space

• Bluetooth wireless technology , infrared, or cable connection

• An embedded synchronization in Microsoft Outlook, providing one-key synchronization and allowing the user to control the synchronization process with easy-to-use settings.

• Handheld devices supported include the Z600, palm-sized and handheld devices using Windows CE and PalmOS/ Casio Personal Organizers.

WAP services

The Z600 has a WAP br owser, supporting WAP 2.0 (WML 1.3). WAP 2.0 optimizes usage of higher bandwidths and packet-based connection s of wireless networks.

Using the WAP browser

The WAP browser in the Z600 is compliant with WAP 2.0 and includes WTLS class 3 as well as mechanisms for digital signatures. It supports WML and XHTML. The WAP browser in the Z600 is also designed to access information such as timetables, share prices, exchange rates, Internet banking and other interactive services.

The built-in WAP browser in the Z600 gives the user portable, fast and secure access to a wide variety of services, including personalized services, with new opportunities for business, individuals and service providers.

Direct Links

There are direct links in the menu system for easy download of e.g. pictures and melodies from WAP sites.

25 September 2003

White Paper Z600

Push services

Businesses and service providers can “push” content or service indications to work groups and/o r customers. Examples of pushed content would be mail alerts, messaging, news, stock quotes, contacts, meeting requests, etc.

Support of XHTML

The WAP browser supports the markup languages of WAP 2.0. It supports WAP 1.2.1 + XHTML Mobile Profile 1.0 + WCSS (XHTML-MP), XHTML Basic, a subset of XHTML-MP, IHTML, WAP Cascading Style Sheets (WCSS), WML version 1.3 and WMLScript. The subsets of the WAP standard XHTML are supported by all major WAP browsers. WAP pages authored in XHTML an d WCSS ca n be displayed in standard PC browsers such as IE and Netscape. WAP pages authored in WML can be displayed in WAP browsers only. It is preferable, therefore, that developers use XHTML and CSS to develop content as these ar e pur e W AP standa r ds. WML and WMLScript are for backwards compatibility.

All of the basic XHTML and IHTML features are supported, including text, images, links, checkboxes, radio buttons, text areas, headings, horizontal rules and lists. For IHTML also blink and marquee, but not tables.

Support for cookies

Z600 has support for cookies (client based), an application used by WAP sites to store site-specific information in the browser between visits to the site. Cookies give the site owner a possibility to see when a person has visited their site. They also save the user from having to enter the same information (e.g. the password or user ID) more than once. Cookies are often used by e-commerce sites (shopping carts and wish lists).

Style sheets

Z600 supports style sheets offering content developers more control over the way their WAP pages are displayed.

Provide settings

Using SMS messages, configuration settings can be sent over the air, OTA, so that the user does not need to configure the WAP access settings manually. WAP settings may also be customized by the operator.

Adapt to phone type

The User Agent Profile function allows WAP content to be automatically optimized for the Z600, ensuring the intended user experience.

Several bearer types

The Z600 accesses the WAP over a standard GSM Data connection as well as over a GPRS connection (network-dependent services.)

Bandwidth efficiency

Unlike traditional Internet services, WAP services are relayed to wireless devices as binary encoded data, maximizing bandwidth efficiency. A GPRS connection further increases efficiency.

Easy create for WAP

Creating a WAP service is no harder than creating an Internet/intranet service, as WML and WMLScript are based on well-known Internet languages such as HTML and JavaScript.

Using standard tools

Service creators can use standard tools such as ASP (Active Server Page) or CGI (Common Gateway Interface) to generate content dynamically. Services can be created once and then made accessible on a broad range of wireless networks.

Maintain customer base

Existing services can be adapted to WAP. The necessary binary encoding is handled by a WAP Gateway, allowing HTML-based services to be viewed on the WAP browser of the Z600. An XHTML page can be viewed in both the WAP br owser and in any standard Web (HTML) browser.

Sending bookmarks

WAP 2.0 enables the sending of bookmarks via infrared as well as via SMS.

26 September 2003

White Paper Z600

Improve productivity

A business can use a WAP gateway to provide a secure connection to its corporate network, improving internal communication flow by making information available to mobile as well as office users.

The WAP profiles

A WAP profile holds network settings and user identification, allowing the user to switch easily between corporate services and WAP services on the Internet, simply by switching WAP profile.

Bearer type characteristics

The Z600 accesses WAP services over IP. IP can be provided either over GSM Data, HSCSD or GPRS, depending on network services.

Typical differences which distinguish the bearer types are listed below.

High Speed Data

High Speed Data (HSCSD) increases speeds for circuit switched data by allowing the phone to use a coding scheme with a high capacity, and to use two time slots for receiving data. The download speed is increased to up to 28,800 bps. The speed for sending data is limited to 14,400 bps. The data rate can be increased several times by the use of rate adaption, interworking with ISDN. This also provides additional features, such as quick call set-

up capability.

GPRS access

The connection is maintained “constantly”, with data transmitted in packets, and transmission capacity being used by the application in use on an as-needed basis.

The Z600 has dynamic WAP profile handling, which means that the user can add, edit and delete WAP profiles. There are up to 5 WAP profiles.

During WAP browsing, the options button gives th e user immediate access to a dynamic option menu for WAP services, similar to a mouse right-click in PC programs.

Higher transmission speed than with GSM Data or SMS access.

Pricing of GPRS can be dependent on the actual use of bandwidth, which means the user is charged for the volume of data transmitted, rather than the duration of the connection.

When transmitting large amounts of data, bandwidth can be increased automatically to allow faster transmission speed.

Ideal for complex pull services, browsing, data transfer, provisioning, pager services, messaging services, info services, push initiations.

GSM data access

Circuit connection of data calls, which means that the phone is connected during the entire WAP session.

Pricing is comparable to that of data calls in the network.

Gateway characteristics

A WAP Gateway provides Internet/intranet as well as WAP services to the mobile browser . A Gateway is identified by an IP number , depending on access type.

End-to-end gateway navigation

The WAP 2.0 supports E2E (End-to-End) Gateway navigation, making it possible for example for a bank to redirect its clients from the Internet gateway to its own gateway.

27 September 2003

Security using the WAP

White Paper Z600

For certain WAP services, such as ban king services, a secure connection between the phone and WAP gateway is necessary. An icon in the display of the Z600 indicates when a secure connection is in use.

The Z600 is based on the WAP 2.0 (WML 1.3) specification suite, in which security functionality is specified by a technology called Wireless T ransport Layer Security (WTLS). The WAP protocols for handling connection, transport and security are structured in layers, with security handled by the WTLS layer, operating above the transport protocol layer. WTLS classes define the levels of security for a WTLS connection:

• WTLS class 1 – encryption with no authentication.

• WTLS class 2 – encryption with server authentication.

• WTLS class 3 – encryption with both server and client authentication.

Server authentication requires a server certificate stored at the server side and a trusted certificate stored at the client side.

Client authentication requires a client certificate stored at the client side and a trusted certificate stored at the server side.

A Wireless Identity Module (WIM) can contain both trusted and client certificates, private keys and algorithms needed for WTLS handshaking, encryption/decryption and signature generation. The WIM module can be placed on a SIM card and is then referred to as a SWIM card.

Certificates

To use secur e conne ction s, the us er nee ds to ha ve certificates stored in the phone. There are two types of certificates:

Trusted certificate

A certificate that guarantees that a WA P site is genuine. If the phone has a stored certificate of a certain type, it means that the user can trust all WAP gateways that use the certificate. Trusted certificates can be pre-installed in the phone, in the SWIM or they can be downloaded from the trusted supplier’s WAP page.

Client certificate

A personal certificate that verifies the user’s identity . A bank that the user has a contract with may issue this kind of certificate. Client certificates can be pre-installed in the SWIM card.

WIM locks (PIN codes)

There are two types of WAP security locks (PIN codes) for a SWIM, which protect the subscription from unauthorized use. The PIN codes should typically be provided by the supplier of the SWIM.

Access lock

An access lock protects the data in the WIM. The user is asked to enter the PIN code the first time the SWIM card is accessed when establishing a connection.

Signature lock

A signature lock is used for confirming transactions, much like a digital signature.

In the Z600, the user can check which tran sactions have been made with the phone when browsing. Each time the user confirms a transaction with a signature lock code, a contract is stored in the phone. The contract contains details about the transaction.

Configuration of WAP settings

An easy way to perform WAP configuration in the Z600 is to use the step-by-step WAP configurator available on http://www.SonyEricsson.com. The configurator utilizes OTA provisioning.

Manual configuration is done using the menu system in the phone. This is described in the User’s guide.

28 September 2003

White Paper Z600

Over -the-air provisioning of WAP settings

To simplify the configuration of WAP settings in the Z600, all settings can be sent to the phone as an SMS message. This makes it easy for an operator, a service provider or a company to distribute settings for Internet/intranet, and WAP, without the user having to configure the phone manually. This also makes it easy to upgrade services, as no manual configuration is required.

• The OTA configuration message is distributed via SMS point-to-point.

• The setup information is a binary encoded XML message (WBXML). To receive information about OTA specifications, please contact your local Sony Ericsson representative for con-

Push services

Examples of WAP services that can be pushed include:

• Notification of new e-mail, voice mail, etc.

• News, sports results, weather forecasts, financial information (stock quotes etc.).

• Personal Information Manager (PIM) - delivery of contacts, meeting requests etc.

• Smart card e-cash.

• Interactive games.

In the , the user selects whether to allow push messages or not. There are two different forms of Push services:

sumer products. A configurator that utilizes OT A provisioning can be tested on www.SonyEricsson.com

• The user is alerted about new settings when the ongoing browsing session ends. Settings are not changed during an ongoing browsing session.

• User interaction is limited to receiving and accepting/rejecting the configuration message, and selecting which WAP profile to allocate the settings to.

• Security can be handled using a keyword identifier displayed on the screen as a shared secret between the SMS sender and recipient. Therefore the user can verify that the configuration message is authentic.

Service Loading (SL)

An SL service sends and displays a WAP page if accepted by the user . If the SL is not accepted, it is loaded and stored in the cache for later use. The user can start the browser and load the page from the cache manually.

Service Indication (SI)

An SI service sends to the browser a text message with a URL of a WAP page. If the user decides to load the URL, normal WAP browsing commences. When an SI is received by the Z600, the user can load it immediately, postpone it or delete it. Received SIs are stored in the Push Inbox and can be viewed and loaded at a later time. The Push Inbox displays a list containing the first part of each received message. The list is sorted by action attribute (high/medium/low) or reception time of the message.

29 September 2003

cHTML support

White Paper Z600

Compact HTML or cHTML is defined as a subset of HTML 2.0, HTML 3.2 and HTML 4.0 specifications. This means that Compact HTML inherits its flexibility and portability from standard HTML. Z600 supports cHTML to facilitate development of I -mode

Mobile Internet

The mobile Internet offers much more than mobile access to the Internet. It opens up a whole new range of situation-based services that give the user access to personalized communications, information and entertainment, anytime, anywhere.

Data connections

In order to browse via WAP or use an Internet connection, the user must have a data communicati on connection configured in the phone. This connection contains specific settings and parameters to connect to an appropriate server. Several data connections can be saved in the Z600. To make it easier for the user, data connections can be provided by the operator via OTA provisioning.

Advantages of data connections include:

• Once the data connections are defined and named, the user does not have to enter the settings for the connection again.

applications for the handset. I-mode is a Japanese service for transferring packet-based data to handheld devices and is owned by NTT DoCoMo. cHTML does not use WAP as a transmission method.

• Data connections can be r e-used at any time.

• Individual data settings for working with WAP, email or the Internet can be stored and activated as needed.

• Data connections can be used for both GSM Data and GPRS connection settings.

• Bearer type for WAP and corresponding bearerspecific parameters may be selected.

• Data connections contain all the necessary settings for the Internet access poin t, inc lud in g modem pool phone number or IP address, user ID and password.

Mobile positioning

The geographic location of mobile subscribers can be used to provide them with related information and a variety of services. Sony Ericsson’s Mobile Positioning System (MPS) gives operators a fast and cost-effective way to establish and roll out location-based services.

For users of the Z600, the integration of mobile positioning with WAP services means that a complete range of service and information tools is available.

More information regarding possibilities with and technologies for mobile positioning is available at http://www.SonyEricssonMobile.com/mps.

30 September 2003

General Packet Radio Services

White Paper Z600

The introduction of GPRS (General Packet Radio Services) is one of the key steps in the evolution of today’s GSM networks for enhancing the capabilities of data communication. Data traffic is increasing enormously (over both wired and wireless networks), with the growth in demand for Internet access and services paralleling that for mobile communications. Users want access to the Internet while they are away from their offices and homes, and surveys have found that the vast majority of business professionals want the ability to send and receive e-mail, browse the WAP and transmit text and graphics on a portable device. That is why the main applications driving Mobile Internet development are e-mail clients and WAP browsers.

The demand for high-speed Internet access will be the key driver for coming generations of wireless services, and GPRS can deliver the necessary speed. GPRS allows innovative services to be created, enabling new and previously inaccessible market segments to be addressed and increasing customer loyalty.

GPRS applications can be developed as both horizontal and vertical. Vertical applications are specific, including those for operations such as reaching police and emergency, taxi, delivery or automated services (vending machines, supervision, vehicle tracking). Horizontal applications are more generic and include those for Internet access, e-mail, messaging, e-commerce and entertainment.

GPRS is able to take advantage of the global coverage of existing GSM networks. Applications developed for GPRS can be deployed on a large scale and can reap the associated benefits. GPRS also provides a secure medium for connections to private networks, banking and financial services.

With GPRS, the Z600 sends data in “packets” at a very high speed. The Z600 remains connected to the network at all times, using transmission capacity only when data is sent or received.

Using GPRS in the Z600

Instead of occupying an entire voice channel for the duration of a data session, the Z600 sends/ receives data in small packets, as needed, much like IP on the Internet. Because of this, the Z600 maintains a constant online connection, its dat a transmission abilities summoned by the application in use on an as-needed basis.

The GPRS specification includes four coding schemes – CS1, CS2, CS3 and CS4 – that allow data speeds of 9,050 bps, 13,400 bps, 15,600 bps and 21,400 bps respectively. The Z600 works with all four coding schemes, but data speed will naturally vary according to network configura tion. At the moment, CS-3 and CS-4 are not supported in any live network, i.e present speed is limited to 53,600 bps.

The GSM system limits the ability to use all eight time slots, so the Z600 uses up to four time slots for receiving data, and one slot for transmitting. This means the speed for receiving data is up to 85,600 bps and up to 21,400 bps for sending data.

Using GPRS with the Z600 has several advantag es, for example:

• Constant connection

• Keep an open connection to an e-mail system or the company network, staying online to receive and send messages at all times. All connection settings can be managed by using the data connections feature.

• High speed

• Gain access automatically to increased bandwidth when downloading large files, images etc.

• Cost efficient

• Use transmission capacity only when needed, thus reducing costs.

• WAP over GPRS

• Access the Internet via WAP at high speed and with a constant connection.

• E-mail over GPRS

• Remain connected to an e-mail system while reading and preparing messages, (which are sent at a high speed).

• Data communication

31 September 2003

White Paper Z600

• Transfer data and access the Internet or an intranet with a PC, PDA or handheld device connected via Bluetooth wireless technology, infrared or cable.

• Data and voice

• Maintain a data connection, for example, a constant connection to an e-mail system when conducting a voice call.

• Provide settings

• Receive GPRS configuration settings from the provider over the air, OTA, making manual configuration unnecessary.

• User controlled settings

Modem and AT commands

The Z600 contains a complete GSM/GPRS modem. This provides data and e-mail communication, as well as Internet/intranet access, for a connected PC, PDA or handheld device. Once the PC/PDA is connected to the phone using a cable, Bluetooth wireless technology or infrared, and the appropriate softwar e is insta lled, th e modem in the phone works in a similar way to a PC Card modem, or an external modem.

• Take advantage of full user control in the data connections menu, establishing multiple descriptions and accessing advanced settings for GPRS.

Interruption of GPRS data account

When the user is browsing with a Z600 the GPRS connection will be automatically disconnected when an incoming call is received. This is the default behaviour. However, it is possible for operators to customize the phone in such a way as to ensure that the user is asked if they wish to remain connected when an incoming call is received.

In the Z600, AT commands are used for:

• controlling the data communication between the PC and the remote service

• configuring and requestin g settings and behaviours in the phone, from a connected PC or PDA

GSM data communication

The built-in data capability turns the phone into a modem when connected to a PC/PDA. The Z600 offers the user data connection anytime, anywhere, unmatched by fixed telephone networks. Each GSM channel is divided into eight repeating time slots. A normal GSM voice or data call is circuit switched, and only one time slot is used for each call. The data speed is therefore limited to 9,600 bps.

High Speed Data gives a faster speed

rate adaption, interworking with ISDN. This also provides additional features, such as quick call setup capability.

GPRS enables constant connection and high speed

With GPRS, the connection is maintained “constantly”, and data is transmitted in packets. Pricing of GPRS can be dependent on the actual use of bandwidth, which means very low cost when no data is sent or received, while the phone remains connected. When transmitting large amounts of data, bandwidth can be increased automatically to allow faster transmission speed, up to 85,600 bps download speed.

32 September 2003

AT commands support

White Paper Z600

This section outlines the AT commands supported by the Z600. The information here can be of use for advanced users, to indicate the possibilities they have to:

• develop new communications software

• add the Z600 to an application’s list of compatible modems

• adjust the settings of their mobile telephone and modem

The modem in the Z600 supports the V.25ter command set, which is the standard communication set used by modems.

The Z600 is compatible with industry de facto extensions, ETSI 07.05, 07.07 and 07.10.

Overview of AT command functions

AT commands are used to configure the mobile telephone, to request information about the current configuration or operational status of the mobile phone, and to test availability and request the range of valid parameters, when applicable, for an AT command.

The built-in modem can be set to any one of three modes of operation. These are:

Off-line command mode

The command mode for entry of AT commands, when the device is first turned on.

On-line data mode

Allows “normal” operation of the built-in modem, for exchanging data or facsimiles with a remote modem.

On-line command mode

For sending AT commands to the built-in modem while remaining connected to a remote modem.

The AT commands are grouped as follows:

• Control and Identification

• Call Control

• Interface Commands

• Data Compression

•Mode Management

• Audio Control

• Accessory Menus

• Accessory Authentication

• Voice Call Control

• Accessory Identification

• GSM DTE-DCE Interface Commands

• GSM Call Control

•GSM Data

• GSM High Speed Circuit Switched Data

• GSM Network Services

• GSM USSD

• GSM Facility Lock

• GSM Mobile Equipment, Control and Status

• GSM Mobile Equipment Error Control

• GSM SMS and PDU Mode

•GSM GPRS

• GSM Phonebook

• GSM Clock, Date and Alarm Handling

• GSM Subscriber Identification

• Ericsson Specific AT Commands for GSM

• MMI Settings

•Voice Control

•OBEX

• WAP Browser

Online Developer Resources

On www.SonyEr icsson.com/developer, developers will find discussion forums monitored by our Sony Ericsson Developer Support, a searcheable knowledge base of support queries and solutions, Tips &

33 September 2003

T ricks, example code, and so on. To stay up to date on development issues, register and subscribe to the monthly Sony Ericsson Developer Newsletter.

Sony Ericsson Developer Support

White Paper Z600

Sony Ericsson offers developers professional technical support services. The service can be purchased from www.SonyEricsson.com/developer There are two levels of support, described below:

•The Basic Developer Support is an annual support service that provides developers with all the basics to successfully develop worldclass applications for Sony Ericsson products. With this support contract, developers get access to high-quality e-mail support with

Infrared transceiver

Infrared communication creates a data link between two communications devices through an infrared beam of light. On the Z600, this link is used to connect with desktop computers, PDAs, Sony Ericsson handheld computers, laptop PCs, other phones and other hardware supporting the standard. The Infrared Data Association (IrDA) has set the hardware and software standards that form the infrared communication links. The Z600 complies with the IrMC 1.1 specification, which defines how mobile telephony and communication devices can exchange information. In the Z600, the IrMC 1.1 specification is also used for communication via a cable.

same-day response and resolution times, five technical support incidents as well as the ability to purchase more.

•The Advanced Developer Support is an annual support service that equips professional developers with everything they need to successfully develop world-class applications for Sony Ericsson products. With this support contract, developers get access to a high-quality email support with fast response and resolution times, and up to 50 technical support incidents.

• True wireless communication

• Low power consumption

• Secure data transmission with the IrDA DATA standard

• Ability to send and receive e-mail and data on the connected PC/PDA

• Ability to connect to the Internet or intranet/LAN from the connected PC/PDA

• Ability to manage the phone book from a PC

• Exchange of business cards and calendar events with vCard/vCalendar compatible devices

• Exchange of ring signals between compatible phones

Key benefits of using the Z600 with its built-in in frared transceiver:

Connection via infrared

IrDA is a point-to-point communication link between two infrared ports. The infrared beam has to be directed towards the target infrared port and as long as the two infrared ports are within sight and range, the devices exchange data. For optimal performance, place the Z600 within a metre and at an angle of 30 degrees to the infrared port on the PC/PDA, or other phone. An advantage of the necessary proximity of devices is reduced risk of transmitting data to other nearby devices. An infrared link is a serial connection, which means that data

bits are sent one after another in a long stream. The IrDA–SIR Data Link Standard is a pr otocol that makes transmission of data faultless. The standard provides a high level of noise immunity, which means that the connection is not affected by fluorescent light, sunlight and electromagnetic fields – making it suitable for the modern office environment.

34 September 2003

Connection via cable

The infrared connection is not always the best solution when connecting to a PC/PDA. Indeed, it is not always even possible. The DRS-11 cable and the USB cable DCU-11 provides the same connectivity between the phone and another unit.

The DRS-11 cable supports a subset of the signals in the RS-232 standard.

White Paper Z600

35 September 2003

White Paper Z600

Facts and figures

*Subscription and/or network-dependent

A Antenna connector, external for HF kits Yes B Background light Yes

Background pictures, pre-defined Yes Background pictures, downloadable Yes, only limited by memory Bluetooth wireless technology support Yes , built-in Bookmarks (URL memory) Yes, (25) Built-in antenna Yes Business card exchange Yes

C Call functions

Call counter Yes, outgoing and total (not incoming) Call barring* Yes Call divert* Yes Call hold* Yes Call list (last dialled, answered and missed

calls)

Yes, 30 entries

36 September 2003

Call screening* Yes

White Paper Z600

Call time/call cost (a.k.a Advice of Charge, Information/Charging)*

Call transfer* Yes Calling card service Yes Calling Line Identification (CLI) Yes. Either as the number of the caller, or

Conference calls* Yes Camera Yes. Chat application Yes, SMS as radio bearer, developed in-

Clock Yes, with automatic Time Zone* Closed User Groups (CUG)* Yes Colour display Yes, 65536 colours, 128x160 pixels Connected Line Identity Presentation (COLP) Yes Contacts Yes Copyright protection Yes, possible with copyright protection

Yes

as a picture, icon or personal ring signal assigned to the number of the caller.

house.

via EMS, MMS, IR and Bluetooth.

CSD, Circuit Switched Data* Yes

DDate Yes

Display light Yes

E EDGE (enhanced Data rates for Global Evolu-

tion)* E-mail address storage Yes E-mail client Yes, supporting IMAP4, POP3, SMTP. EMS (Enhanced Messaging Service)* Yes, with 30 pre-defined pict ur es, 15 pre-

External antenna connecto r Yes

F File system Yes. At the purchase of the Z600 phone,

Fixed Dialling Numbers (FDN)* Yes

defined animations and 4 melodies.

there is up to 2.0 Mb of memory space for own objects such as pictur es, sounds and themes. Customized kits may vary.

37 September 2003

White Paper Z600

G Games Yes, 4 pre-loaded and more games avail-

able for download at Sony Ericsson Mobile Internet.

GPRS (General Packet Radio Services)* Yes, up to 85,6 kbps (multislot class 8,

4+1 time slots) H High Speed Data (HSCSD)* Yes, multislot class 2 I Image browser Yes. Gives access to pictures stored in

the phone.

Imaging support Yes Infrared port Yes Input methods T9 Text Input, multitap alphabetic (GSM

standard) JJava Yes K Keypad lock Yes L Languages 45 M Melody composer Yes, Music DJ

Memory check Yes, dynamic memory allocation: 2.0 Mb MMS (Multimedia Messaging Service) Yes Mobile chat Yes Modem (data) Yes, built-in (max. data rate 108,800 bit/

s.) N Navigation key Yes, five-way

Notes Yes, up to 10 – depending on size.

P Personal management

Calculator Yes Calendar Yes Alarm clock with snooze function Yes Stopwatch Yes Timer Yes Code memo Yes Organizer Yes

Phone book

Capacity 510 numbers in phone + SIM Maximum number of ADN read from the SIM 255

38 September 2003

White Paper Z600

Maximum number of FDN read from the SIM 55 Phone book user groups Yes, 10 Phone lock Yes

Pictures

Total storage capacity Limited by the memory Number of pre-loaded pictures TBD Possibility to download Yes, storage capacity limited by memory Possibility to create Yes, storage capacity limited by memory Picture editor Yes, stand-alone picture editor facility.

Here the user can create new and edit

existing pictures (WBMP).

Picture phone book Yes Pictures, exchange Yes, via EMS, MMS, infrared and Blue-

tooth wireless technology

Polyphonic ring signals Yes, 32 voice Predictive text input Yes Profiles Yes, 7

R Re-dialling, automatic Yes

Ring signals

Total storage capacit y Limited by the memory Preloaded 24

Possibility to download Yes, storage capacity only limited by the

memory

Possibility to compose Y es, storage capacity only limited by the

memory

Exchange Yes, via EMS, MMS, infrared and Blue-

tooth wireless technology S Screen saver Yes

Shortcuts Yes Silent mode Yes Silent mode: activation Long “C” SIM relative features

SIM voltage 3V and 5V

39 September 2003

White Paper Z600

Number of networks that the handset can manage on the SIM card

SDN support Yes, 15. Located in Phonebook menu/

SIM Application Toolkit* Yes SIM card copy Yes

SIM card lock Yes (support of GID 1 and GID 2) Sleep mode Yes SMS (Short Message Service)* Yes SMS, long messages (a.k.a. concatenated

SMS)* SMS Cell Broadcast* Yes SMS counter Yes SMS templates Yes, up to 10 templates of 30 characters

Sound browser Yes. Gives the user access to sounds

Special numbers/ Service numbers

Yes, up to 10 messages of 160 characters each.

each

stored in the phone. Sound handling Yes (iMelody, AMR and MIDI) Speaker phone No Speech coding Enhanced, Full and Half Rate. AMR sup-

ported where available. Speed dialling Yes Start-up/Shutdown shows Yes Status menu Yes Swatch Internet Time No Synchronization with PC Yes, via RS232 cable, USB, infrared and

Bluetooth wireless technology SyncML Yes

T Themes, pre-loaded Yes, 4

Themes, downloadable Yes, limited only by memory Themes, exchange Yes, via MMS, infrared and Bluetooth

wireless technology Two Line Service (a.k.a Alternate Line Service,

ALS)

Yes

40 September 2003

White Paper Z600

U USB protocol support No, but through the DCU-10 accessory

(USB to System Connector cable + driv-

ers) you can get the USB functionality,

though not charging

USB physical interface support No, only with accessory Connection to a PC USB port No, only with accessory Battery recharging through USB port No Maximum data rate through USB port (bit/s) 46080

V Vibrating modes Yes

Vibrating only Yes Vibrating then ringing No Vibrating + ringing Yes

Voice recognition Yes, dialling, answering and rejecting

with HF, redial, switch profile, record/play

memos and “magic word”. Maximum

contacts: 34. Voice command Yes, maximum number of functions: 6 Voice coding Yes Voice memo Yes, the total time is only limited by the

memory. The maximum number of voice

memos is 20. Voice memos cannot be

used as ring signals.

W WAP browser Yes, WAP 2.0 browser with support for

XHTML and CHTML. WTLS for added WAP security* Yes, WTLS class 1, 2, 3 and signText

Network-dependent features

SMS and EMS messaging

The Z600 is capable of sending and receiving SMS and EMS messages, and linked messages.

• With the Short Message Service, a user can send text messages containing up to 160 characters to and from GSM mobile stations

• With the linked SMS, the user can link up to 10 SMS messages together to create a longer message (network-dependent ser-

vice)

A Service Centre (SC) acts as a storage and forwarding centre. The Z600 also supp orts using SMS as a bearer type for connecting to WAP.

SMS consists of two basic services:

41 September 2003

White Paper Z600

• Mobile Originated SMS

• Mobile Terminated SMS

For Mobile Originated SMS, an SMS message is sent from a Mobile Station to the SMS-C where it is forwarded to its destination. This can be another Mobile Station, or a terminal in the fixed network.

A Mobile Terminated SMS is when an SMS message is forwarded from the SMS-C to a Mobile Station. When the Mobile Station receives the message, it returns a delivery report saying the transfer was successful.

SIM application toolkit

The SIM Application Toolkit (SIM AT ) is a smart card-centric method of deploying programs that apply only to GSM and to SMS and USSD transports. Programs must be distributed on smart cards. For an operator, a company or service provider, SIM AT offers a powe rful way to deploy programs and services to users, without the need for new or upgraded equipment. All necessary setup and programming is distributed to users over the air, directly to their phones. In the Z600, a separate menu is available for functions residing on the SIM card. These can include submenus for controlling functions, and also functions which allow the phone to initiate calls, send data, and display information to the user.

Fixed dialling and Restricted calls

For a company or an organization, it can be useful to restrict phone calls. Fixed Dialling allows the user to preset a number of digits, for example area codes. This restricts the user to making calls only to numbers which use the preset digits as leading digits. Fixed Dialling makes use of the PIN2, and it requires fixed dial fields on the SIM card.

The Restrict Calls service allows the user to block outgoing or incoming calls in certain situations, for example international calls.

42 September 2003

White Paper Z600

SIM AT services supported by the Z600

Service Mode Support

CALL CONTROL Yes CELL BROADCAST DOWN-

LOAD DISPLAY TEXT Text of up to 240 characters (120 ucs2 coded). Yes

bit 1: 0 = normal priority Yes

1 = high priority Yes

bit 8: 0 = clear message after a delay Yes

1 = wait for user to clear message Yes

GET INKEY General: The GET_INKEY requires that the user

confirms his/her choice

bit 1: 0 = digits (0-9, *, # and +) only

1 = alphabet set

bit 2: 0 = SMS default alphabet

1 = UCS2 alphabet

bit 3: 0 = character sets defined by bit 1 and bit 2 are

enabled 1 = character sets defined by bit 1 and bit 2 are

disabled and the Yes/No response is requested

Yes

Yes Yes

GET INPUT General: No. of hidden input characters 20

bit 1: 0 = digits (0-9, *, # and +) only

1 = alphabet set

bit 2: 0 = SMS default alphabet

1 = UCS2 alphabet

bit 3: 0 = ME may echo user input on the display

1 = user input not to be revealed in any way (see note)

bit 4: 0 = user input to be in unpacked format

1 = user input to be in SMS packed format

bit 8: 0 = no help information available

1 = help information available

Yes Yes

Yes No

43 September 2003

White Paper Z600

Service Mode Support

LAUNCH BROWSER Yes MORE TIME Yes PLAY TONE Yes POLLING OFF Yes POLL INTERVAL Yes PROVIDE LOCAL INFORMA-

TION

REFRESH General: The reset option requests the user to

SELECT ITEM Yes

'00' = Location Information (MCC, MNC, LAC and Cell Identity)

'01' = IMEI of the ME Yes '02' = Network Measurement results Yes '03' = Date, time and time zone (DTTinPLI) Yes '04' - Language setting Yes '05' - Timing setting Yes

wait while the phone restarts '00' =SIM Initialization and Full File Change

Notification '01' = File Change Notification Yes '02' = SIM Initialization and File Change Notifi-

cation '03' = SIM Initialization Yes '04' = SIM Reset Yes

Yes

SEND DTMF Yes SEND SHORT MESSAGE bit 1: 0 = packing not required

1 = SMS packing by the ME required SEND SS Yes SEND USSD Yes

Yes Yes

44 September 2003

White Paper Z600

Service Mode Support

SET UP CALL General: Capability configuration

Set-up speech call CallParty

Subaddress DTMF support

'00' = set up call, but only if not currently busy

on another call

'01' = set up call, but only if not currently busy

on another call, with re-dial

'02' = set up call, putting all other calls (if any)

on hold

'03' = set up call, putting all other calls (if any)

on hold, with re-dial

'04' = set up call, disconnecting all other calls (if

any)

'05' = set up call, disconnecting all other calls (if

any), with re-dial SET UP EVENT LIST '00' = MT call Yes

'01' = Call connected Yes

Yes No Yes Yes

Yes

'02' = Call disconnected Yes

'03' = Location status Yes

'04' = User activity No

'05' = Idle screen available Yes

'06' = Card reader status Not

Applica-

ble '07' = Language selection Yes '08' = Browser termination Yes '09' = Data available No 'OA' = Channel status No

SET UP IDLE MODE TEXT Yes, 1

row of

text is

sup-

ported

SET UP MENU Yes SMS PP DOWNLOAD Yes

45 September 2003

User interaction with SIM AT

White Paper Z600

DISPLAY TEXT

Text of up to 240 characters (120 UCS coded) is supported. Text clearing times are 5-20 seconds and a 60-second time-out limit for the use r to clea r the text.‘Key’ responses:

• ‘Long Back’ – Proactive session terminated by user.

• ‘Back’ – Backward move in proactive session.

Any other key clears display if the command is performed successfully.

GET INKEY

Prompt for a one-character input. Pressing ‘Ok’ without entering a character gives warning message “Minimum 1 character”. ‘Key’ responses:

• ‘C’ clears current character.

• ‘Long Back’ terminates the proactive session.

• ‘Back’ – Backward move in proactive session.

• ‘OK’ – Command performed successfully.

GET INPUT

Prompt for character input. The phone will refuse to accept further input when maximum response length is exceeded. MMI Maximum Response lengths

• Digits Only – 160 characters

• SMS default alphabet characters – 160 characters

• Hidden Characters (digits only) – 20characters

SELECT ITEM

Scroll to highlight item for selection. ‘Key’ responses:

• Navigation key press down– Scroll down list.

• Navigation key press up– Scroll up list.

• Long ‘Back’ terminates proactive session.

• ‘Back’ – Backward move in proactive session.

• ‘OK’– Command performed successfully.

SEND SHORT MESSAGE

Default message “Sending message, please wait” can be replaced for the Alpha Identifier text, or suppressed completely if a null text is provided. Default responses are “MESSAGE FAILED” or “MESSAGE SENT”. ‘Key’ responses:

• Long ‘Back’ or ‘Back’ ends the proactive session.

SET UP CALL

If the ME is on a call when the command ‘Set up Call’, ‘putting all other calls on hold' is sent, the user will see the text 'Setting up a call current call will be held'. If ‘OK’ is pressed the current call will be put on hold and the new call set up. If the ME is on a call when the command ‘Set Up Call, disconnecting all other calls’ is sent, the user will see the text ‘Setting up a call current call will be disconnected’. If the ‘OK’ key is pressed the current call will be disconnected and the new call set up.

‘Key’ responses:

• ‘C’ clears current character.

• ‘Long Back’ terminates the proactive session.

• ‘Back’ – Backward move in proactive session.

• ‘OK’ – Command performed successfully.

REFRESH

When a refresh command is executed by the phone, it requests the user to wait while the phone restarts. A notification will be made if it is demanded that the SIM card initializes again.

SET UP MENU

Incorporates a SIM Application Toolkit Menu Item into the ME’s main menu structure. From the standby display the right or left arrow buttons can be pressed to select the Menu Items.

If an Alpha Identifier is supplied in the Set Up Menu command, this is used as the SIM AT entry in the ME’s main menu. If no alpha identifier is supplied and several items are found in the menu, a default title is used. If the SIM A T Menu Item is selected by pressing ‘Select’ all the items sent in the Set Up Menu command will be available for selection, in the same way as the Select Item command.

46 September 2003

Security and M-commerce technical data

Feature Support in the Z600 for m-commerce

Dual-slot No

White Paper Z600

Associated with a STK card, allowing ISO B0' bank card payments

Associated with a STK card, allowing EMV bank card payments

Certified by the “GIE Carte Bancaire”

WIM support If separate card, no Ability to use a WIM applica-

tion embedded on a SIM/ USIM card

WIM application embedded on a SIM/USIM card the default WIM application

Number of smart card readers in the handset

Provisioning of the following SATK commands: Perform Card APDU, Power Off Car d, Power On Card, Get Reader Status

If separate card, no

Yes

Release of SIM Application Toolkit supported

Information to the user while in secured mode (WTLS)

Is an incoming class 2 SMS transferred to the SIM even when another application (a browser) is running?

Access to the WIM WIM can only be accessed by native applications, e.g. the browser

R99 with exceptions (missing AT commands, for example “Launch browser” and “Show icon” – still under investigation)

Yes, via icon

Yes

Terminology and abbreviations

3GPP

3rd Generation Partnership Project.

AMR

Adaptive Multi Rate. Audio format for speech sounds.

47 September 2003

White Paper Z600

API

Application Programming Interface.

ASP

Active Server Page. Server technology that generates WAP pages dynamically.

Bearer

The method for accessing W AP from the phone, for example GSM Data (CSD) and SMS.

bFTP

binary File Transfer Protocol.

Bluetooth

Bluetooth wireless technology is a secure, fast, point-to-multipoint radio connection technology. It is a specification for a small-form factor, low-cost radio solution providing links between mobile computers, mobile phones and other portable handheld devices, and connection to the Internet. For more information, http://www.bluetooth.com.

Bookmark

A URL and header/title stored in the phone.

Browsing session

The period from the first a ccess of content until the termination of the connection.

Calling Line Identification (CLI)

Shows the number of the caller, or a picture assigned to the number of the caller in the mobile phone display. Not all numbers can be displayed. Network-dependent service.

Card

A single WML unit of navigation and user interface. May contain information to present to the user, instructions for gathering user input, etc.

CLDC

Connected Limited Device Configuration. A J2ME configuration aimed at, for example, mobile phones.

DRM

Digital Rights Management.

GSM

Global System for Mobile Communications. GSM is the world’s most widely-used digital mobile phone system, now operating in over 100 countries around the world, particularly in Europe and AsiaPacific.

HTTP

Hyper Text Transfer Protocol.

IDE

Integrated Development Environment

J2ME

Java 2 Platform, Micro Edition. A Java platform targeting “micro” devices with small processors and memory capacities, such as mobile phones, communicators and PDAs.

JAD

Java Application Descriptor (file).

JAR

Java Archive (file).

LAN

Local Area Network.

Mobile Equipment.

CDMA

Code division Multiple Access. A generic term that describes a wireless air interface based on code division multiple access technology.

CDC

Connected Device Configuration. A J2ME configuration aimed at, for example, PDAs.

CHTML Compact Hyper Text Markup Language.

Micro browser

Accesses and displays Internet content in a mobile phone, using small file sizes and the bandwidth of the wireless-handheld network.

MIDP

Mobile Information Device Profile. A J2ME profile connected to the CLDC configuration and aimed at mobile phones.

MMI

Man-Machine Interface.

48 September 2003

White Paper Z600

Mobile Station.

Mobile Termination.

OTA

Over-the Air Configuration. To provide settings for the phone by way of sending an SMS message over the network to the phone. This red uces the need for the user to configure the phone manu ally.

PDA

Personal Digital Assistant.

PDP

Packet Data Protocol.

Phone book

A memory in the mobile phone or SIM card where phone numbers can be stored and accessed by name or position.

PIM

Personal Information Management.

Service Centre (for SMS).

Service provider

A company that provides services and subscriptions to mobile phone users.

Service Indication.

Service Loading.

SIM card

Subscriber Identity Module card – a card that must be inserted in any GSM-based mobile phone. It contains subscriber details, security information and memory for a personal directory of numbers. The card can be a small plug-in type or credit cardsized, but both types have the same func tions. The Z600 uses the small plug-in card.

SMS

Short Message Service. Allows messages of up to 160 characters to be sent and received via the network operator's message centre to a mobile phone.

Supplementary Services.

SyncML

An open standard fo r synchr onization of all devices and applications over any network.

TCP/IP

Transmission Control Protocol/Internet Protocol.

UMTS

Universal Mobile Telecommunications System. Th e telecommunications system, incorporating mobile cellular and other functionality, that is the subject of standards produced by 3GPP.

URL

Uniform Resource Locator.

USSD

Unstructured Supplementar y Services Data.

VAD

Voice Activated Dialling.

VAS

Value Added Serv ice.

vCalendar

vCalendar defines a transport and platform-independent format for exchanging calendar and scheduling information for use in PIMs/PDAs and group schedulers. vCalendar is specified by IETF.

vCard

vCard automates the exchange of personal information typically found on a traditional business card, for use in applications such as Internet mail, voice mail, WAP browsers, telephony applications, call centres, video conferences, PIMs /PDAs, pagers, fax, office equipment, and smart cards. vCard is specified by IETF.

WAE

Wireless Application Environment.

WAP

Wireless Application Protocol. Handheld devices, low bandwidth, binary coded, a deck/card metaphor to specify a service. A card is typically a unit of interaction with the user, that is, either presentation of information or request for information from the user. A collection of cards is called a deck, which usually constitutes a service.

49 September 2003

White Paper Z600

WAP Application

A collection of WML cards, with the new context attribute set in the entry card.

WAP service

A WML application residing on a WAP site.

WBMP

WAP Bitmap.

WBXML

Wireless Binary Extensible Markup Language.

WDP

Wireless Datagram Protocol.

WML

Wireless Markup Language. A markup language used for authoring services, fulfilling the same purpose as HyperText Markup Language (HTML) does on the World Wide WAP (WWW). In contrast to HTML, WML is designed to fit small handheld devices.

WMLScript

WMLScript can be used to enhance the functionality of a service, just as, for example, JavaScript may be utilized in HTML. It makes it possible to add procedural logic and computational functions to WAP-based services.

WSP

Wireless Session Protocol.

WTLS

Wireless Transport Layer Security.

WWW

World Wide WAP.

XML

Extensible Markup Language.

XHTML

Extensible HyperText Markup Language.

Related information

Documents

• The Z600 User’s Guide

• Sony Ericsson Z600 FAQ

• AT Command Reference Manual

• WAP June2000 (WAP 2.0) Specification

Software

• XTNDConnect PC, upgraded version from Extended Systems Inc.

Links

• http://www.SonyEricssonmobile.com/

• http://wap.SonyEricssonmobile.com/

• http://www.gprsworld.com/

• http://www.extendedsystems.com/

• http://www.bluetooth.com/

• http://www.imc.org/

• http://www.3gpp.org/

• http://www.irda.org/

• http://www.etsi.fr/

• http://www.wapforum.org/

• http://www.imc.org/pdi/

• http://www.syncml.org/

• http://www.SonyEricsson.com/developer

• http://www.w3.org/TR/xhtml-basic/

Trademarks and acknowledgements

• BLUETOOTH is a trademark owned by the Bluetooth SIG, Inc. The IrDA Feature Trademark is owned by the Infrared Data Association and is used under licence there from.

• Microsoft, Windows, Windows CE and Windows NT are registered trademarks or trademarks of Microsoft Corporation.

• Pentium is a registered trademark or trade-

50 September 2003

White Paper Z600

mark of Intel.

• Palm, PalmPilot and Palm OS are trademarks or registered trademarks of Palm Inc. or its subsidiaries.

• T9 is a registered trademark of Tegic

• XTNDConnect is a trademark of Extended

• XHTML™ is a registered trademark of the

Technical specifications

The consumer pack includes:

• Mobile Phone Z600

• Battery

• Travel Charger

• CD containing Windows SW package for the

phone; Extended Systems XTNDConnect Server synchronization, Sony Ericsson applications to create and manage content in the mobile phone, Connection Wizard to create dial-up connections for CSD, HSCSD, GPRS.

• User’s guide, including Battery Information

• Accessory leaflet

• Service and Support Leaflet

Communications. Systems Inc. W3C.

51 September 2003

White Paper Z600

General technical data

Product name Z600 System Tri-band. GSM phase 2 r e co mme ndat ions. GSM 9 00 (3 GPP TS 51.0 10 -

1), GSM 1800 (3GPP TS 51.010-1) and GSM 1900 (NATWG 03), e-GSM supported

Speech coding Enhanced, Full and Half Rate. AMR supported where available for high

speech quality SIM card Small plug-in card, 3 V and 5V type Type number TBD

Exterior description

Size 90x48x27.9 mm (incl. exchangeable front and back cover) Weight 110 grams (incl. Standard battery) Status display Gray scale 91x29 pixels Main display Full graphical display TFD (active-matrix) 128 x 160 pixels

65536 colours

16 bits/pixel memory depth.

Pixel size: 0.249x0.249mm: 2” panel

Colour depth: 16 bits represented by two byte (5 bits red, 6 bits green

and 5 bits blue)

1st Byte d0-d7: G3G4G5R1R2R3R4R5

2nd Byte d0-d7: B1B2B3B4B5G0G1G2

Response time (black to white) <100ms

1) Type: graphical

Resolution: 128 x RGB x 160 pixels.

Size: Minimum viewing area: 32 x 38 mm

Technology: TFD LCD, 65536 colours

Colours displayed together: 65536 colo ur s

Size (lines): 9

Backlight colour: 1

Fonts: 3 2nd display 91x80 pixels

Active area 18.19 x 5.79 mm

Viewing area 20.36 x 7.83 mm

Glass size (mm) 12.23 (+/-0.2) + end seal (0.8 max)

200 x 200 µm pixel pitch (dot size 0.19 x 0.19 mm & g ap 0.01 x 0.01mm

Black and white

Blue backlight Antenna Built-in

52 September 2003

White Paper Z600

Text size 1 Colours 1 Battery TBD Network LED No Exchangeable covers Yes Keypad 5-way navigation key, 18 keys, volume keys, camera key , power butt on,

Web access key.

Keypad lock: from standby, Lock keys in Mor e list. It is also possible to

select Auto key lock in the Settings menu.

Use of several keys simultaneously (e.g. for games) is possible.

Ambient temperatures

Operating Max: +50×C, Min -10×C Storage Max: +85×C, Min -40×C Charging Max: +45×C, Min +4×C

Supported Man-Machine Interface (MMI) languages

Depending on software in the phone, these languages are supported: Albanian (SQ), Arabic (AR), Brazilian Portuguese (PB), Bulgarian (BG), Canadian French (CF), Czech (CS),

Croatian (HR), Danish (DA), Dutch (NL), English (EN), Estonian (ET), Farsi (FA), Finnish (FI), French (FR), German (DE), Greek (EL), Hebrew (IW), Hungarian (HU), Indonesian-Bahasar (IN), Italian (IT), Latin American Spanish (XL), Latvian (LV), Lithuanian (LT), Malay (MS), Norwegian (NO), Philippine-Tagalog (TL), Polish (PL), Portuguese (PT), Romanian (RO), Russian (RU), Serbian (SR), Sesotho (ST), Slovakian (SK), Slovenian (SL), Spanish (ES), Swedish (SV), Thai (TH), Turkish (TR), US English (AE), Vietnamese (VI), Zulu (ZU).

53 September 2003

Current consumption, talk and standby times

Dimension Value in GSM 900 Transmission current 55 mA (min)

215 mA (max) Standby current 2,45 mA (min), (paging rate 9, 1 neighbour present)

4,5 mA (max), (paging rate 2, 16 neighbours pre sent) Talk time Up to 9 hrs Standby time Up to 300 hrs

Speech coding

White Paper Z600

Dimension Full rate Enhanced full rate Type RPE/LPC with LTP ACELP Bit rate 13.0 Kbp/s 12.2 Kbp/s Frame duration 20 ms 20 ms Block length 260 bits 244 bits Class 1 bits 182 bits Class 2 bits 78 bits

Cell broadcast service

Feature User notification of the reception of a CB

message Handling of reception of several unread mes-

sages

Message displayed on screen

The messages are queued in order to be read in the

same order they were received. Support of all CMBI from 0 to 4096 Yes File support CBMI and CBMID Support CB SIM data download Yes

54 September 2003

Feature

White Paper Z600

Support of all applicable Data Coding Scheme values as defined in 3G TS 23.038 V3.3.0 (with the exception of Language preference)

Ability to display in a understandable way a message with a DCS “language unspecified” whatever language is set in the SIM card

Ability to extract a phone number or short number of a CB message to re-use it

Support of multi-page CB-messages Yes

Yes

55 September 2003

White Paper Z600

Short message service

Feature Support in the Z600

SMS Service Centre Number It is possible to pre-record the SMS Service Centre

Number.

Pictures It is possible to insert a picture or an icon into the text

message. EMS compliant mobile handsets will be able

to see the picture correctly. Input methods Predictive text input or multitap Reply to messages It is possible to reply to received messages by SMS,

phone call,... Message creation methods support Predictive writing or multitap

Copy, cut and paste words No Teaching of predictive words that are not

in the predictive dictionary

Possibilities when creating a message:

save a sent message in a “Sent items” folder or a “SIM archive” folder

insert a line in the message Yes assign a validity period to the message Yes print via IrDA No use pre-defined messages Yes

Possibilities when receiving a message:

reply to the sender Yes (only to the sender , not to all or part of the message

resend the message Yes forward the message Yes save the message in the “SIM archive” Yes get delivery time and date Yes

Yes

recipients)

print via IrDA No

Possibilities of the previously sent message:

delivery report of the message Yes forward the message Yes save the message in the “SIM archive” or

“Sent items” folders know the remaining capacity storage Yes

Yes

56 September 2003

White Paper Z600

Feature Support in the Z600

print via IrDA No

Possibilities of the previously received message:

reply to the sender Yes (only to the sender , not to all or part of the message

recipients)

save the message in the “SIM archive” Yes forward the message Yes know the remaining capacity storage Yes

Supported ways for replying to a received SMS:

via SMS Yes via phone call (set up a call to the number

contained in the message body) via WAP call (go to the WAP address

contained in the message body) via USSD session No

Possibility to offer the user the ability of sending an SMS to a list of recipients

Possibility to write an e-mail address as a recipient address

SMS storage In the SIM and in the handset. Nokia Picture Messaging Yes

Yes

Yes, using Phone Book groups or by adding more

recipients

Yes, if SMS type=e-mail

57 September 2003

Enhanced message service

Feature Support in the Z600

White Paper Z600

Level of compliance supported by the handset regarding the specifications described in release 99.

Number of messages that the handset is able to handle to generate a concatenated message

Capacity storage 100 messages Outgoing messages It is possible to...

Incoming messages • A signal is heard once all parts of the message have

Concatenated messages A receipt is received in the handset when all parts of a

Enhanced Messaging Service (EMS) according to the standard 3GPP TS 23.040 v4.3.0, with the addition of the ODI feature from 3GPP TS 23.040 v5.0.0.

• see how many short messages an EMS message consists of before sending it.

• choose whether to send the message or not after writing it.

been received or when a timeout occurs.

• It is possible to re-use the content of an EMS message. Sounds, pictures, animations and text formatting can be aved in the terminal and then inserted in a new message, if the object is not protected using ODI.

concatenated message have been delivered.

Attachments It is possible to attach pictures, animations and sounds

to an EMS message.

Text formatting • Centred, left and right aligned text.

• Small, normal and large font size.

• Bold, italic, underlined and strikethrough style.

Sounds Chimes high, chimes low, ding, tada, notify, drum, claps,

fanfare, chords high, chords low. I-melody Yes, version 1.2.

Melodies It is possible to....

• send and receive melodies via EMS. If the melodies are not protected by copyright.

• download melodies and commercial tunes from WAP/WAP portals.

• create melodies on WAP/WAP portals.

• Music DJ in the terminal only supports MIDI-format

WBMP Yes Picture sizes 16x16 mm, 32x32 mm, variable size receipts in black

and white.

58 September 2003

White Paper Z600

Feature Support in the Z600 Pictures It is possible to...

• edit and create pictures by using the phone keypad.

• send and recei ve pictures via EMS. If the pictures are not protected by copyright.

• create pictures on WAP/WAP portals.

• download pictures from WAP/WAP portals.

• receive pictures in enhanced messages originated by service providers.

Animations The handset supports the following animations: I am

ironic, I am glad, I am sceptic, I am sad, WOW!, I am crying. I am winking, I am laughing, I am indifferent, I am in love, I am confused, Tongue hanging ou t, I am angry, Wearing glasses, Devil.

It is possible to...

• send and receive animations.

TP-PID field value given by the handset before sending an EMS message

0x00

59 September 2003

Multimedia message service

Feature Support in the Z600

White Paper Z600

MMS/CSD parameters and MMS/GPRS parameters placement

Possibility to pre-configure the MMS parameters in factory

Possibility to configure the MMS parameters by OTA provisioning

Possibility for all the parameters from the parameters set to be OTA provisioned at the same time

Possibility for only one parameter from the parameters set to be OTA provisioned

OTA provisioning solution OTA specified by Sony Ericsson and Nokia MMS User Agent functional entity will be a

separate entity from WAP browser: MMS User Agent support WAP WTA, WAP UAProf and WTA Public. Supplier indication of realized inter operabil-

ity tests between its MMS User Agent and MMS Relay/Server from other suppliers

MMS is bound to a WAP profile. A WAP pr ofile is bound to a Data Account. A Data Account contains either CSD parameters or GPRS parameters.

• MMS/CSD: Yes

• MMS/GPRS: Yes

• MMS/CSD: Yes

• MMS/GPRS: Yes

• MMS/CSD: Yes

• MMS/GPRS: Yes

• MMS/CSD: No

• MMS/GPRS: No

Yes

Support of a standard or a proprietary procedure for OTA provisioning of MMS parameters

Functionalities that the user is able to set during message composition:

From where can the user insert multimedia elements into multimedia messages:

Supplier indication if MMS User Agent will be able to handle a network-based address book

Possibility for sent messages to be memorized into a folder in handset memory

Actions that the user can perform after message notification:

Proprietary

• message subject

• MSISDN recipient address

• e-mail recipient address

• message Cc recipient(s) address(es)

• delivery report request

• read-reply report request

• message priority

• terminal memory

• directly from camera No

Yes

• retrieve the message immediately

• defer message retrieval

• reject message

60 September 2003

Feature Support in the Z600

White Paper Z600

Actions that the user can perform after message retrieval:

Multimedia codecs/formats supported for audio

Multimedia codecs/formats supported for video

Multimedia codecs/formats supported for image

MMS User Agent provides: • text formatting facilities (only textsize)

Supported formats for message presenta tion:

Maximum message size that can be handled by the handset for message

• reply to the sender of the message

• reply to the sender and to Cc people

• forward the message

• delete the message

• save message into terminal AMR,

None

Baseline JPEG, wbmp, GIF 89a

• coloured text/background (Viewer/player supports coloured text and background.)

• predictive writing

• message body + attachments (e-mail presentation)

• SMIL version as described in “Nokia/Ericsson MMS Conformance document (not WML and SMIL 2.0 Boston)

Unlimited

Possibility to configure unconditional message modification (such as media modification in messages)

MMS User Agent will report problems to user in case of:

Yes

• message not sent causes no user subscription to service, if included in ResponseText (please see WAP209)

• message not sent causes required functionality not supported by MMS Relay/Server, if included in ResponseText (please see WAP209)

• message not sent causes insufficient credit (in case of prepaid charging), if included in ResponseText (please see WAP209)

Instant messaging/ Chat

Feature Support in the Z600

Support of instant messaging No Chat application Yes, SMS as the radio bearer.

61 September 2003

Bluetooth technical data

Dimension Support in the Z600

White Paper Z600

Bluetooth capability statement

Bluetooth functions Dial-up Networking Profile

Connectable devices All products supporting Bluetooth spec. 1,0b or 1.1 and at least one

Coverage area Up to 10 metres (33 feet) Transmission power 1mW (0dBm) Frequency band 2.4 GHz - the unlicensed ISM band

This product is manufactured to meet Bluetooth Specification 1.0b and is designed to work with V1 devices.

File Transfer Profile Generic Access Profile Generic Object Exchange Profile

Headset Profile Object Push Profile Serial Port Profile Synchronization Profile

Basic Imaging Profile Handsfree Profile

of the above profiles.

Power consumption Standby current: < 0.3 mA

Voice mode: 10-35 mA

Data mode average: 5 mA [0.3-30 mA, 20 kbps, 25%] Data transmission rate up to 108 kbps with one time slot Specific commands working

with the SIM card Support of multipoint con-

nections

Performance and technical characteristics

Dimension GSM 900/E-GSM

900

Frequency range TX: 880 – 914 MHz

RX: 925 – 959 MHz Channel spacing 200 kHz 200 kHz 200 kHz

GSM 1800 GSM 1900

TX: 1710 – 1785 RX: 1805 – 1880

TX: 1850 – 1910 RX: 1930 – 1990

62 September 2003

White Paper Z600

Dimension GSM 900/E-GSM

900

Number of channels 174 Carriers *8

(TDMA) Modulation GMSK GMSK GMSK TX Phase Accuracy < 5º RMS Phase

error (burst) Duplex spacing 45 MHz 95 MHz 80 MHz Frequency stability +/- 0.1 +/- 0.1 +/- 0.1 Voltage operation (nominal) 3.6 Volts 3.6 Volts 3.6 Volts Transmitter RF power output 33 dBm Class 4 (2W

peak) Transmitter Output imped-

ance Transmitter Spurious emis-

sion

W 50 W 50 W

< -36 dBm up to 1

GHz

< -30 dBm over 1

GHz

(according to GSM

spec.)

GSM 1800 GSM 1900

374 Carriers *8 (TDMA)

< 5º RMS Phase error (burst)

30 dBm Class 1 (1W peak)

< - 30 dBm (according to GSM spec.)

299 Carriers *8 (TDMA)

< 5º RMS Phase error (burst)

30 dBm Class 1 (1W peak)

< - 30 dBm (according to GSM spec.)

Receiver RF level Better than – 102

dBm Receiver RX Bit error rate < 2.4% < 2.4% < 2.4%

– 102 dBm – 102 dBm

Tone and percussion maps in the Z600

The Z600 has a tone bank of 128 (0-127) sample d inst ru ment s. T he instr ume nts are complemented by 47 percussion sounds, see table number two. Echo effects are possible.

Tone map

GM Poly GM Tone Map GM Poly

0 1 Acoustic Grand Piano 65 1 Alto Sax 1 1 Bright Acoustic Piano 66 1 Tenor Sax 2 2 Electric Grand Piano 67 1 Baritone Sax 3 2 Honky-tonk Piano 68 1 Oboe 4 1 Electric Piano 1 69 1 English Horn

GM Tone Map

5 1 Electric Piano 2 70 1 Bassoon 6 1 Harpsichord 71 1 Clarinet

63 September 2003

Tone map

White Paper Z600

GM Poly GM Tone Map GM Poly

7 1 Clavi 72 1 Piccolo 8 1 Celesta 73 1 Flute 9 1 Glockenspiel 74 1 Recorder 10 2 Music Box 75 1 Pan Flute 11 1 Vibraphone 76 2 Blown Bottle 12 1 Marimba 77 2 Shakuhachi 13 1 Xylophone 78 1 Whistle 14 1 Tubular Bells 79 1 Ocarina 15 2 Dulcimer 80 2 Lead 1 (square) 16 2 Drawbar Organ 81 2 Lead 2 (sawtooth) 17 2 Percussive Organ 82 2 Lead 3 (calliope) 18 2 Rock Organ 83 2 Lead 4 (chiff) 19 2 Church Organ 84 2 Lead 5 (charang) 20 1 Reed Organ 85 2 Lead 6 (voice)

GM Tone Map

21 2 Accordion 86 2 Lead 7 (fifths) 22 1 Harmonica 87 2 Lead 8 (bass + lead) 23 2 Tango Accordion 88 2 Pad 1 (new age) 24 1 Acoustic Guitar (nylon) 89 2 Pad 2 (warm) 25 1 Acoustic guitar (steel) 90 2 Pad 3 (polysynth) 26 1 Electric Guitar (Jazz) 91 2 Pad 4 (choir) 27 1 Electric Guitar (clean) 92 2 Pad 5 (bowed) 28 1 Electric Guitar (muted) 93 2 Pad 6 (metallic) 29 1 Overdriven Guitar 94 2 Pad 7 (halo) 30 1 Distortion Guitar 95 2 Pad 8 (sweep) 31 1 Guitar Harmonics 96 2 Fx1 (rain) 32 1 Acoustic Bass 97 2 Fx2 (soundtrack) 33 1 Electric Bass (finger) 98 2 Fx3 (crystal) 34 1 Electric Bass (pick) 99 2 Fx4 (atmosphere) 35 1 Fretless Bass 100 2 Fx5 (brightness) 36 1 Slap Bass 1 101 2 Fx6 (goblins)

64 September 2003

Tone map

White Paper Z600

GM Poly GM Tone Map GM Poly

37 1 Slap Bass 2 102 2 Fx7 (echoes) 38 1 Synth Bass 1 103 2 Fx8 (sci-fi) 39 1 Synth Bass 2 104 1 Sitar 40 1 Violin 105 1 Banjo 41 1 Viola 106 1 Shamisen 42 1 Cello 107 1 Koto 43 1 Contrabass 108 1 Kalimba 44 1 Tremolo Stri ngs 109 2 Bag pipe 45 1 Pizziano Strings 110 2 Fiddle 46 1 Orchestral Harp 111 1 Shanai 47 1 Timpani 112 1 Tinkle Bell 48 1 String Ensemble 1 113 1 Agogo 49 1 String Ensemble 2 114 2 Steel Drums 50 1 Synth String 1 115 1 Woodblock

GM Tone Map

51 2 Synth String 2 116 1 Taiko Drum 52 1 Choir Aahs 117 1 Melodic Tom 53 1 Voice Oohs 118 2 Synth Drum 54 2 Synth Voice 119 1 Reverse Cymbal 55 2 Orchestra Hit 120 1 Guitar Fret Noise 56 1 Trumpet 121 1 Breath Noise 57 1 Trombone 122 2 Seashore 58 1 Tuba 123 1 Bird Tweet 59 1 Muted Trumpet 124 1 Telephone Ring 60 2 French Horn 125 1 Helicopter 61 1 Brass Section 126 2 Applause 62 2 Synth Brass 1 127 1 Gunshot 63 2 Synth Brass 2

65 September 2003

Percussion map

No. Percussion name No. Percussion name

35 Acoustic Bass Drum 59 Ride Cymbal2 36 Bass Drum 1 60 Hi Bongo 37 Side Stick 61 Low Bongo 38 Acoustic Snare 62 Mute Hi Conga 39 Hand Clap 63 Open Hi Conga 40 Electric Snare 64 Low Conga 41 Low floor T om 65 High Timbale 42 Closed Hi-Hat 66 Low Timbale 43 High Floor Tom 67 High Agogo

White Paper Z600

44 Pedal Hi-Hat 68 Low Agogo 45 Low tom 69 Cabasa 46 Open Hi-Hat 70 Maracas 47 Low-Mid Tom 71 Short Whistle 48 Hi-Mid Tom 72 Long Whistle 49 Crash Cymbal 1 73 Short Guiro 50 High Tom 74 Long Guiro 51 Ride Cymbal 1 75 Clavas 52 Chinese Cymbal 76 Hi Wood Block 53 Ride Bell 77 Low Wood Block 54 Tambourine 78 Mute Cuica 55 Splash Cymba 1 79 Open Cuica 56 Cowbell 80 Mute Triangle 57 Crash Cymba 2 81 Open Triangle 58 Vibraslap

66 September 2003

White Paper Z600

WAP browser technical data

Feature Support in the Z600 WAP browser

Back to previous page Yes Bearer type GPRS (IP) Yes Bearer type GSM Data (IP) Yes, HSCSD, ISDN and analog Bookmarks Yes, up to 25 named bookmarks for easy access to frequently visited

pages Bookmark Export/Import Yes, can be sent and received as link using SMS and vBookmark for-

mat via IR and BT Cache Yes (size 6 kbyte) Character sets * UTF8 (Default), USASCII, Latin1, UCS2 Clear cache Yes Colour Colour display Home page Yes, up to 5 different, one for each WAP profile HTML version for WAP

browser Hyperlinks in Text Yes, highlighted by inverse video Hyperlinks in Images Yes, indicated by a frame Image Animation No Image Formats GIF (interlaced and non-interlaced), WBMP, no transparent layers,

Network Settings Up to 5 different settings available by selecting WAP profile (Intranet,

OTA Support Yes PPP Authentication PAP, CHAP supported Reload page Yes Tables Yes User Agent Profiles Yes, list of client characteristics - e.g. display size

xHTML, mobile profile

JPG

Internet, Banking, Gateway etc.)

WAP/WML WAP WAP 2.0/ WML 1.3

67 September 2003

White Paper Z600

Feature Support in the Z600 WAP browser

*) When creating WML applications, it is recommended that you

always save the page contents as UTF8, and that this is clearly indi-

cated in the pages before publishing. This ensures that the contents

of the application can be viewed, regardless of character sets used in

gateways and the phone. All characters are not supported in all

phones. The software version depends on which market the phone is

associated to. Also, please note that the phone may not support input

on a WAP Service which uses certain characters (languages), even if

those characters are supported for browsing in the phone. WAP browser WAP 2.0 baseline WAP profiles Dynamic - up to 5 WAP profiles, each with its own settings WTLS (security) Yes,

WTLS Class 1 - Encoding

WTLS Class 2 - Encoding + Server Authentication. Root Certificates

needed in phone

WTLS Class 3 - Encoding + Server Authentication + Client

Certification. Root Certificates needed in phone + special SIM cards

Sign text

68 September 2003

WAP Operator technical data

Feature Support in the Z600 for WAP WAP Browser

Version 2.0 baseline HTML XHTML, mobile profile

WAP Provisioning

Total Parameter sets 5 Parameter set list Name

Startpage IP settings:

CSD phone no., CSD Data rate, CSD dial type GPRS APN, password request, allow calls, authentication,

data compression, header compression, quality of services IP address, datamode (conn.less or oriented) UserId and password Security on/off Show images on/off Response timer

White Paper Z600

Manual selection Yes, between Analog (V32) and Digital (V110) Parameter sets include WAP/CSD, WAP/GPRS (different sets) Factory pre-configuration WAP/CSD (possibility to lock a setting), WAP/GPRS OTA WAP/CSD, WAP/GPRS configuration possible Simultaneous OTA WAP/CSD, WAP/GPRS configuration possible Single OTA WAP/CSD, WAP/GPRS is not possible Bookmarks Not empty by default URL format Underlined

Security mechanism

OTA provisioning (if empty) Operator verification through a code, included in the OTA data.

This code is shown to the user who can choose installat i on or not.

Interface (if empty) An Install question is asked with the code, if available.

The user has to choose if a new WAP profile shall be created or an existing profile shall be replaced.

Re-provisioning (Set 1 filled) As above Interface (Set 1 filled) As above Carrier reset/provisioning Yes, but not if the set is pre-configured in the factory and locked.

69 September 2003

White Paper Z600

Feature Support in the Z600 for WAP

SWIM Not used for provisioning.

The SWIM is only used for WAP security, both WTLS connections and digital signatures.

SWIM certificate Both client and trusted certificates can be used for WTLS

connections and digital signatures. No new certificates can be stored and no old ones can be removed by the terminal.

Applicative provisioning

Preferred bearer customization Yes E-mail customization No Other applications/features Yes. MMS, SyncML

Technologies

SonyEricsson and WAP Forum provisioning over SMS and Cell Broadcast

Openwave OTA No Other Yes. The Ericsson-Nokia solution. Provisioning bearer SMS Parameter sets available 5 Parameter sets for OTA

modification

PUSH Content types

Service Indication (SI) Yes Service Loading (SL) Yes Cache Operation (CO) content

type Session Initiation Application (SIA) Yes

Yes

Man Machine Interface

SI/content retrieval postponing Yes SI menu structure accessability WAP services, Push inbox SL reception warning The user can make a choice if a dialog is wanted or not before

loading the SL. WAP services/options/common/Push access/prompt

SIA reception warning Yes

70 September 2003

White Paper Z600

Feature Support in the Z600 for WAP

Number of push messages Depending on the size of the push messages. Around 20 push

messages with a size of 500 bytes can be stored.

Push de-activate Yes. WAP services/options/common/Push access/Off Dynamic push menu changes No. There are no changes in the menus when activating/

deactivating push

Security

Mechanisms for push None Trust with PPG Sending a SIA is the most trustful. WSP push sessions 1 Denial of service/spoofing

User agent profile

UA profile content sent at beginning of WSP session

OA profile content size URL sent pointing to the UA profile

at the beginning of WSP session URL location On the manufacturer WAP site.

WTAI

WTA Make Call Yes WTA Send DTMF Yes WTA Add Phone Book Yes Other WTA/WTAI No

DOWNLOAD WAP solutions

SAR/WSP/HTTP GET solution to download content over WAP

Yes

Download Fun from Openwave No Other download content over WAP Yes. Downloade d witho ut usin g SAR is limited to 10kB

Features

Download application/product memory check

Downloaded object solution Yes. The user is asked if the content is to be saved. UAP indication for downloading Yes

Yes

71 September 2003

White Paper Z600

Feature Support in the Z600 for WAP

Other features Yes. Store, delete, forward, use, manage.

Object formats

Ringing tones audio/iMelody, other/eMelody, vMel. Wallpapers Image/WBMP, GIF, JPEG. Pictures Image/WBMP, GIF, JPEG. Games Yes, 4-6 pre-loaded and 5-7 at Sony Ericsson Mobile Internet. JAVA applications Yes Screen savers Image/GIF, JPEG Audio files audio/MPEG4 not use d,MP3 not used, WAV not used Skins Application /skin Video Video/MPEG4 not used

GRAPHICAL USER INTERFACE Man Machine Interface

Soft keys Yes Separate/dedicated back or erase

keys Screen backlight on when

browsing Predictive writing Yes “http://” string displayed

automatically when entering URLs

Elements

Number of display lines for a WAP connection

Pop-up menus Yes, in XHTML Radio buttons Yes, in XHTML. Check boxes Yes, in XHTML. Buttons Available as XHTML form controls.

Yes

Not displayed but the “http://” is added automatically to the URL.

4 to 7 plus Title, depending on the selected font size.

72 September 2003

GPRS technical data

Dimension Support in the Z600

White Paper Z600

Compatible GPRS and SMG specifications

Data rates Multislot class 8 supported (4+1)

Indicator of attachment to the GPRS service

Indicator of PDP context activation

Data volume counter • The Data volume counter details the volume of data exchanged in

Medium Access Modes Fixed and dynamic allocation Support of Packet Con-

trol Channels (PBCCH/ PCCCH)

Network operation mode NOM I, II, III

ETSI R97 SMG 31 bis

CS-1, CS-2, CS-3, CS-4 9,050 bps, 13,400 bps, 15,600 bps, 21,400 bps supported (networkdependent)

Yes, an icon in the bottom left corner, a filled triangle if attached

Yes, an icon on the right side. Animated globe

bytes for the up/down link for last call for each PDP context.

• The Total data counter details the sum of a ll GPRS sessions (i.e. no t the sum of total data received + sent during the last GPRS session. The total data counter can be reset by the user.

Yes

Support of GPRS/CS combined procedures

Network control mode NC0 Support of access in 2

phases Support of PRACH on 11

bits Support of GPRS re-

selection C31/C32 Support of static and

dynamic addressing Support of power control

Uplink and Downlink Support of ciphering

algorithms Support of compression

algorithms

Yes

Uplink = yes, Downlink is a network feature

GEA1 and GEA2

Yes, V42bis and IP header compression

73 September 2003

Dimension Support in the Z600

White Paper Z600

Support of the QoS modification procedure

Interfaces to external devices supported by the handset and available for a GPRS link

Downlink data rate Up to 85,600 bps for packet data communication, using 4 time slots in

Uplink data rate Up to 21,400 bps for packet data communication, using 1 time slot in cod-

Mode of operation Class B and Class C modes of operation supported. It is possible for the

R Reference point Physical layer: Support of RS232

IP connectivity PDP type IP is supported

Yes, when initiated by the network (not by the handset)

IrDA, RS-232, A T commands. IrDA, Datarate=SIR & MIR RS232, autobaud, max 460kbit/s Bluetooth, v1.0B+Critical errata, Certified and listed Supported Bluetooth profiles: DUN, FAX, Headset, Synch, Object push

coding scheme CS-4

ing scheme CS-4

user to choose if the Circuit Switched services should be favoured.

PPP is supported as L2 layer in the R reference point Authentication algorithms PAP, CHAP supported

IP termination in mobile or TE (laptop, PDA) supported

Application WAP over GPRS supported (UDP/IP and GPRS-SMS)

SMS over GPRS (SMS-MT, SMS-MO) supported

QoS QoS negotiation supported. Default requested QoS sent by the handset at

PDP context activation is reliability Class 3. Peak/Mean/Delay/Precedence Class: subscribed

• Precedence class supported (1,2,3)

• Reliability class 1-5 supported

• Delay classes supported (1,2,3,4)

• Mean and peak throughput rate limited by multislot class 4 and CS-4

PDP context 10 PDP context descriptions stored in mobile

PDP context description is edited via application in mobile, AT-command or via OTA Simultaneous PDP contexts not supported Network requested PDP context not supported

SIM GPRS aware, as well as non GPRS aware SIMs are supported

74 September 2003

Dimension Support in the Z600

White Paper Z600

AT commands supported • AT+CGDCONT - DEFINE

PDP CONTEXT

• AT+CGQREQ - Quality of Service Profile (REQUESTED)

• AT+CGQMIN - Quality of Service Profile (Minimum Acceptable)

•AT+CGATT - PACKET DOMAIN SERVICE ATTACH OR DETACH

• AT+CGACT - PDP CONTEXT ACTIVATE OR DEACTIVATE

•AT+CGDATA - ENT

75 September 2003

White Paper Z600

Built-in GSM data modem technical data

Dimension Support in the Z600

Standards AT commands industry standard, ETSI 07.05 and 07.07 and 07.10, V.25ter

command set supported

Data rates, Circuit Switched (CSD)

Data rates, GPRS See GPRS Technical data

Download data rate Up to 19,200 or 28,800 bps (depending on base

rate) no compression, with V.42bis compression up to four times higher transmission rates depending on the data type

Upload data rate Up to 9,600 or 14,400 bps (depending on base

rate) for GSM Data communication, no compression with V.42bis compression up to four times higher transmission rates depending on the data type

E-mail client technical data

Feature Support in the Z600 e-mail client

Attachment Yes (outgoing,

images only) Bearer type GPRS (IP) Yes Bearer type GSM Data (IP) Yes, HSCSD, ISDN and analog Character sets * US ASCII (All variants)

ISO8859-1 (All variants)

76 September 2003

Feature Support in the Z600 e-mail client

ISO8859-2 All variants

ISO8859-5 All variants

ISO8859-10 All variants

KOI8-R All variants

WIN1251 All variants WIN1252 (All variants UTF7 (All variants)

UTF8 All variants

GB2312

BIG5

GB18030

White Paper Z600

OTA Support Yes Supported protocols POP3, IMAP4, SMTP

77 September 2003

White Paper Z600

USSD technical data

Feature Support in the Z600

USSD support GSM Phase 1/ 2 (Cross-phase compatibility). GPRS

behavior according to class B

Mode support -mode MMI-mode supported.

No application mode support (not needed for any application).

MMI-mode details • USSD messages displayed until removed by user

• It is possible to scroll up and down the text in USSD messages

Image format technical data

Format Visible Max Animation Colours Visible col-

ours

GIF 160x160

pics

JPEG 160x160

pics

WBMP 160x160

pics

160x160 pixels

640x480 pixels

320x320 pixels

50 frames (1 frame/ 100ms)

No 16.8 mil. 65535

No Black/

256 65535

(5:6:5=RGB; less blue colours)

White

Images – downloading to phone

Feature File type Max. size PC/

Cable

EMS icons WBMP WxH<=1024

pixels

Yes Yes Yes Yes Yes Yes

PC/ IrDA

PC/ BT

Phon e-tophon e

Transparency support

WAP MMS

MMS GIF , WBMP ,

JPG

Limited by the memory

Yes Yes Yes Yes Yes Yes

78 September 2003

White Paper Z600

Feature File type Max. size PC/

Cable

Background GIF,

WBMP; JPG

MMS template

Animations Animated

GIF

Themes GIF (propri-

ety, THM)

Screensaver Animated

GIF

Exceptions: MMS: GIF, WBMP, JPG, 128x160 pics EMS icons: WBMP max WidthxHeight<=1024 pixels (e.g. 32x32=1024)

Limited by the memory

Send 30k, Receive 50k

Limited by the memory

Yes Yes Yes Yes Yes Yes

No No No No No Yes

Yes Yes Yes Yes Yes, 1) Yes

Yes Yes Yes Yes Yes No

Yes Yes Yes Yes Yes Yes

PC/ IrDA

PC/ BT

Phon e-tophon e

WAP MMS

Themes: GIF, JPG max, 128x160 pixels WAP: Can not show animations in the W AP Browser. You can downlo ad maximum 3kb. The animation

will be shown in the Image Browser if it’s saved in the phone. GIF: Animations used as background images or user greetings displays first frame only.

79 September 2003

White Paper Z600

SyncML technical data

Feature Support for Sync ML in the Z600

SyncML compliance The handset is fully SyncML compliant (it passed both Syn-

cML Conformance and Inter operability testing [SyncFest])

Basic data formats Contacts: vCard 2.1, Calendar: vCalendar 1.0, Tasks: vTodo

1.0.

Possibility for operators to extend SyncML functionality

Possibility to synchronize other handsets using SyncML

Transport method for SyncML messages

Synchronization application placement

Possibility for the user to configure login parameters (e.g. username and password) to access the remote database

Configuration parameters that can be entered/modified by the user

Mechanisms used by the handset to capture changes made by the end user (i.e. how does the SyncML client in your handset know which changes were made to the address book)

WSP (i.e. using a WAP connection)

Inside the handset

Yes

Server URL, Server UserID, Server PWD, Paths to databases (Calendar, Contacts, Tasks) UserID and PWD for Databases, Databases to be synced (on/off), WAP Account, Sync Sound

It uses a change log where it marks the contact as updated

Ability to deal with multiple servers No Ability to perform conflict resolution

actions

Infrared transceiver technical data

Signal in RS-232 Support in DRS-11 CD (Carrier

Detect) CTS (Clear To

Send)

No. Set statically

Yes

80 September 2003

White Paper Z600

DSR (Data Service Ready)

DTR (Data Terminal Ready)

GND (Signal Ground)

RI (Ring Indication)

RTS (Request To Send)

Rx (Received Data)

Tx (Transmitted Data)

Statically connected with DTR

Statically connected with DSR

Yes

No. Set statically

Yes

81 September 2003

Index

White Paper Z600

Numerics

3GPP

.......................................................14

Abbreviations

Acknowledgement ......................................50

Architecture ...............................................12

.............................................47

MMS Centre .....................................12

assembler .................................................18

AT Command Functions ..............................33

Audio .......................................................11

Backlight

Bluetooth ..................................................18

Bluetooth devices .......................................21

Bluetooth technical data ..............................62

Built-in GSM data modem technical data ........76

Cell broadcast service

Certification ...............................................18

cHTML support ..........................................30

colour support ...........................................18

Compatibility .............................................14

Compatible with old phones .........................14

Connection via desktop charger ....................24

Current consumption, talk and standby times ..54

deployment

Desktop charger .........................................24

Documents ................................................50

E-mail client technical data

Enhanced message service ..........................58

Exterior description .....................................53

Fixed Dialling

Game file sizes

Games .....................................................54

Gaming API ...............................................18

General Packet Radio Service .......................31

GPRS .......................................................31

GPRS access characteristics ........................27

..................................................18

.................................54

...............................................18

...........................76

.............................................42

...........................................18

GPRS technical data ..................................73

Graphics .................................................... 9

GSM Data access characteristics .................. 27

GSM system support .................................. 52

Image format technical data

Images, downloading to phone ..................... 78

Info & entertainment ................................... 15

infrared ....................................................18

Languages, MMI

Links ....................................................... 50

MMS Centre MMS content

........................................ 53

............................................. 12

......................... 78

audio ................................................ 11

graphics .............................................9

SMIL presentations .......................... 11

text ................................................... 11

video ................................................ 11

MMS Technical features

architecture ...................................... 12

MMSC ..................................................... 12

Mobile Internet .......................................... 29

Modem and AT Commands ......................... 32

mophun RTE ............................................. 17

Multimedia message service ........................ 60

Music block ..............................................19

News & commercials

Online Services

OTA configuration .................................13, 29

Overview of AT command functions .............. 33

Performance and technical characteristics

Push inbox ............................................... 29

Push services ............................................ 29

Related information

Restricted Calls ......................................... 42

..................................15

......................................... 42

...... 62

....................................50

82 September 2003

White Paper Z600

Ring signals Ring signals and melodies

...............................................15

music block ......................................19

track .................................................19

sandbox

Secure gamelets ........................................18

Short message service ................................56

SIM Application Toolkit ................................42

SIM AT Services .........................................43

SIM card type ............................................52

SMIL presentations .....................................11

SMS ........................................................18

SMS access characteristics ..........................27

SMS request .............................................15

SMS standard ............................................14

Software ...................................................50

Software developement kit ...........................18

Sony Ericsson Developer Support ..................34

Speech coding ...........................................54

Sprite detection ..........................................18

Supported MMI languages ...........................53

Synchronization software .............................25

Synchronization, local .................................24

SyncML ....................................................22

SyncML technical data ................................80

Synergenix Interactive AB ............................18

...................................................18

XTNDConnect PC

...................................... 25

TCP/IP link

Technical Specifications ..............................51

Terminology and abbreviations ......................47

Text .........................................................11

Touch correct feature ..................................20

Trademarks and acknowledgements ..............50

True file support .........................................18

Two displays ...............................................6

Unicode

Unified messaging ......................................15

User-to-user ..............................................14

USSD technical data ...................................78

Vehicle positioning

Vibrator ....................................................18

Video .......................................................11

WAP browser technical data

WAP Operator technical data ........................69

WAP, security ............................................28

Weight ......................................................52

................................................18

....................................................18

......................................15

.........................63

83 September 2003

Tannoy Z600 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
