Loudspeakers with the natural ability to
SUPERTWEETER
2
DUAL CONCENTRIC
reproduce any kind of music with pace, life
and rhythm whilst effortless dynamics and
expressive realism generate the scale,
excitement and impact of film soundtracks
with ease. The Tannoy Dimension series
incorporates the very latest wide bandwidth
technology in an acoustically optimised
cabinet.
4
RANGE
10
EISA AWARD - TD12
TERMINAL PANEL
6
8
An innovative blend of beautiful styling
and groundbreaking technical
achievement – sound and science in
perfect harmony.
A DESIGN CLASSIC
Tremendous dynamic range, agile, accurate and punchy bass,
with remarkable extension, fluid, open midrange and spacious,
airy high frequency, all combine to produce a performance on
a grand scale.
The compact design of the TD8 belies the effortless
ease with which it produces an enormous performance.
At the heart of Dimension is the famous Tannoy Dual
Concentric™ drive unit.
Featuring a cone material manufactured from a
composite of several different fibres and twin roll
surround, the system delivers enhanced midrange
performance and tight, fast bass with tremendous low
frequency extension.
A SUPERB LISTENING EXPERIENCE
The mix of fibres within the driver cone has been carefully
chosen to obtain a light but very stiff structure providing
chosen to obtain a light but very stiff structure providing
exceptional grip and control of bass transients.
Centrally mounted behind the Tulip Waveguide™, the driver’s
high frequency unit combines transparent, fluid performance
with true point source symmetrical dispersion properties.
While less imposing in size, the TD10 offers
10
performance of immense scale.
With stunning dynamics and seductive musicality. In common
with all models in the range the sheer presence and sound
staging ability of this speaker is captivating; the ideal choice
for listening rooms of more modest proportions.
2 3
A Tannoy SuperTweeter is incorporated into
the design of all Dimension models, not only
to resolve fine detail of high frequency
information but also to effectively enhance
the listening experience even at lower
frequencies. Creating an increased immediacy,
airiness and impact, the SuperTweeter makes
music more natural and true to life.
The low diffraction rounded edge of the baffle
combined with acoustically inert material
SUPERTWEETER
surrounding the SuperTweeter ensures that
high frequency output is not re-radiated,
resulting in superior imaging.
A hugely powerful, stunningly natural,
centre channel speaker.
Precisely tonally balanced to the other models in the Dimension
range. Voicing characteristics matched with such precision are an
essential part of achieving a home theatre system capable of
exceptional multi-channel imaging.
Front grille optional
54
This loudspeaker is the award winning
flagship model of the Dimension range.
“I was won over by this highly musical and articulate speaker,
which provides the kind of dynamics and expressive realism
associated with higher prices.”
“Involving, entertaining, revealing and generous in scale,
the Dimension 12 reproduces any kind of music with pace,
life and rhythm.”
Need we say more?
Hi-fi News – April 2001
Involving, entertaining, revealing and generous in scale,
6
the Dimension TD12 reproduces any kind of music with pace, life and rhythm
7
BI-WIREABLE TERMINAL PANEL
An innovative bi-wireable terminal panel
has been designed to simplify the
connection of even the largest diameter
audiophile loudspeaker cables. In addition
to the high quality gold plated speaker
cable connections there is an 'earth' or
'ground' terminal that is connected to the
chassis of the drive units.
Within any loudspeaker system the voice
coil will pick up radio frequency
interference that contributes to noise and
distortion when fed back to the amplifier.
The Dimension system of driver chassis
earthing optimises the performance of the
amplifier by reducing these effects.
Technical brilliance -
perfect music reproduction.
The TD-SUB underpins a Dimension
home theatre system with truly remarkable
low frequency performance.
Massively constructed around a 15” (380mm) drive unit, this
subwoofer uses a sophisticated, flexible and extremely potent
8
amplifier design to ensure the integrity of the powerful, deep
and controlled bass.
9
DIMENSION RANGE
Electrical filtering via the crossover is kept to a minimum
because the drive unit performance has been optimised
to form a near-natural transition throughout the
frequency range. The design is precisely customised to
our own engineers’ special demands utilising premium
quality non-standard components. This total system
view of crossover design ensures a far more natural
presentation of music to the listener.
The multi-faceted trapezoidal design of the immensely
strong cabinet reduces internal standing waves, further
minimising colouration. The cabinet, which is constructed
using birch ply for the primary panel components,
is comprehensively internally braced to improve rigidity
and further reduce the amplitude of panel resonance.
Heavyweight solid aluminium cones and floor- coupling spikes
ensure any residual cabinet energy is efficiently dissipated.
A SUPERB LISTENING EXPERIENCE
10 11
WIDEBAND TECHNOLOGY
™
BREAKING SOUND BARRIERS.
Modern programme material and sources (e.g. SACD / DVDA) have driven the requirement for
loudspeakers with extended frequency bandwidth performance. Always at the forefront of audio
evolution, Tannoy has been developing just such wide bandwidth loudspeaker technology over
many years.
Music contains transient information and rich harmonics beyond the range of human hearing for
pure tones. Even bass notes have leading edge transients reaching 30kHz. Operating between the
roll-off point of the Dual Concentric™ high frequency unit and 54kHz, the Dimension SuperTweeter
will accurately reproduce the leading edge of individual notes allowing the listener to experience
the entire bandwidth information of instruments.
In addition, by extending the frequency response by two octaves corrects time and phase response
within the bandwidth of normal human hearing. Taking these acoustical phase anomalies beyond
the range of human hearing adds realism to the soundstage by improving imaging and placement
of instruments.
SCIENTIFIC RESEARCH.
Musical instruments have energy up to and beyond 100kHz, but can we perceive it?
Researchers monitoring brainwave activity on subjects exposed to wide bandwidth material to
60kHz have conducted controlled experiments. By careful monitoring and noting subjective scores
under blind conditions, it was discovered that the listeners were indeed responding to the ultrasonic
components in the music.
Further experiments have deduced that profoundly deaf subjects rely on ultrasonic detection in
their discrimination of speech and tones. These tests concluded the mechanism was through bone
conduction, probably to a small organ in the inner ear called the saccule, which is effectively wired
to the cochlea, the organ responsible for hearing as we know it.
HOW DOES IT SOUND?
The proof as always is in the listening; whatever the source - whether vinyl, compact disc or the
latest SACD / DVDA technology. All of the technical features and attention to detail combine in
the Dimension models to provide discerning audiophiles with incredible wide band detail for the
ultimate musical experience.
The addition of a SuperTweeter, time aligned to the acoustic centre of the Dual Concentric, reduces
the high frequency phase error by moving the low pass roll off point much higher, typically –6dB @
54kHz, –18dB @ 100kHz. Research continues into the actual mechanism of the perception of sound
above 20kHz, but it can be clearly shown that the addition of a SuperTweeter will better preserve the
harmonic relationship between instruments. To illustrate this the trace below shows the phase error at
20kHz and 54kHz roll off points. There is clearly less phase error - not just at high frequencies, but
also as low as 5kHz.
TD8 TD10 TD12 TDC1
PERFORMANCE
Recommended amplifier power - Watts RMS 40 - 160 50 - 200 50 - 280 40 - 200
Continuous power handling - Watts RMS 100 130 180 130
Peak power handling 375 480 675 480
Sensitivity (2.83Volts @ 1 m) 90dB 91dB 92dB 92dB
Nominal impedance - Ohms 6 6 6 6
Frequency response -6dB 42Hz - 54kHz 38Hz - 54kHz 30Hz - 54kHz 42Hz - 54kHz
Dispersion 90 º conical 90 º conical 90 º conical 90 º conical
DRIVE UNITS
SuperTweeter
TM
Dual Concentric
Dual Concentric
Low frequency
CROSSOVER
Dual Concentric
Frequency 1.4kHz 1.2kHz 1.1kHz 1.4kHz
Low frequency to Dual midrange type
Frequency
SuperTweeter type
Frequency
CABINET
Enclosure type
Construction High-density 18mm birch-ply
Dimensions mm (inches)
Weight kg (lbs)
Finish options
High frequency
TM
Low frequency
TM
type
25mm (1”)
25-micron titanium dome,
neodymium magnet system
25mm (1”)
50-micron aluminium dome
with Tulip Waveguide.
200mm (8”)
Paper pulp cone, with a twin roll
impregnated fabric surround.
Bi-wired, hard-wired
passive low loss,
2nd order low pass,
1st order high pass.
3rd order high pass filter 3rd order high pass filter 3rd order high pass filter 3rd order high pass filter
14kHz 14kHz 14kHz
Dual chamber coupled reflex
enclosure, internally
cross-braced.
High-density 30mm birch ply
front baffle.
943 x 299 x 305
(37.1 x 11.8 x 12)
22 (48.5) 32 (70.5) 52.5 (115.7) 31.5 (69.4)
American cherry with polished
alloy trim or Rose-nut with
black anodised alloy trim.
25mm (1”)
25-micron titanium dome,
neodymium magnet system
25mm (1”)
50-micron aluminium dome
with Tulip Waveguide.
254mm (10”)
Paper pulp cone, with a twin roll
impregnated fabric surround.
Bi-wired, hard-wired
passive low loss,
3rd order low pass,
1st order high pass.
Twi n port reflex Twin port reflex Closed box
High-density 18mm birch-ply
enclosure, internally
cross-braced.
High-density 30mm birch ply
front baffle.
1095 x 350 x 370
(43.1 x 13.8 x 14.6)
American cherry with polished
alloy trim or Rose-nut with
black anodised alloy trim.
25mm (1”)
25-micron titanium dome,
neodymium magnet system
33mm (1.25”)
50-micron aluminium dome
with Tulip Waveguide.
300mm (12”)
Paper pulp cone, with a twin roll
impregnated fabric surround.
Bi-wired, hard-wired
passive low loss,
3rd order low pass,
1st order high pass.
High-density 18mm birch-ply
enclosure, internally
cross-braced.
High-density 40mm birch ply
front baffle.
1254 x 435 x 435
(49.4 x 17.1 x 17.1)
American cherry with polished
alloy trim or Rose-nut with
black anodised alloy trim.
25mm (1”)
25-micron titanium dome,
neodymium magnet system
25mm (1”)
50-micron aluminium dome
with Tulip Waveguide.
200mm (8”)
Paper pulp cone, with a twin roll
impregnated fabric surround.
2 x 200mm (8”)
Paper pulp cone, with a twin roll
impregnated fabric surround.
Bi-wired, hard-wired
passive low loss,
1st order low pass,
1st order high pass.
Bi-wired, hard-wired
passive low loss,
1st order.
400Hz
14kHz
High-density 18mm birch-ply
enclosure, internally
cross-braced.
High-density 30mm birch ply
front baffle.
373 x 774 x 420
(14.7 x 30.5 x 16.5)
American cherry with polished
alloy trim or Rose-nut with
black anodised alloy trim.
12
Phase 54kHz
Phase 20kHz
Amplitude 54kHz
Amplitude 20kHz
Optional accessories Front grille assembly
TD SUB
Output power
Frequency range
Drive unit
Amplifier type
Input connectors
Mains input - Volts
Mains fuses
Protection
Gain control ranges - dB
High level two channel unbalanced
High level single channel balanced
200 RMS, 400 Peak
18 – 100 Hz, with variable low pass filter
380mm Long Throw Heavy DutyCast Chassis
DC coupled MOSFET
Twin phono connectors, line level
4mm sockets, speaker level
115 or 230, via fused I.E.C. socket
Semi Delay 3.15A 220-240V
Semi Delay 6.3A 110-120V
Internal PCB mounted fuses and electronic protection
80
100k
100k
Low level unbalanced
Black 0dB
Red +12dB
Low level single channel balanced
Phase
CABINET
Enclosure type
Construction
Dimensions mm (inches)
Weight kg (lbs)
Finish options
10k
10k
Normal or reversed
Damped reflex
High-density 25mm birch-ply enclosure,
internally cross-braced.
High-density 40mm birch ply front baffle.
805 x 522 x 510 (31.7 x 20.6 x 20.1)
42 (92.6)
American cherry with polished alloy trim
or Rose-nut with black anodised alloy trim.
13
Tannoy Limited, Home Audio Division, Coatbridge, Scotland, ML5 4TF.
Te l: +44 (0) 1236 420199 Fax: +44 (0) 1236 428230
e-mail: sales@tannoy.com Website: www.tannoy.com
Tannoy/TGI North America Inc., Suite 1, 335 Gage Avenue, Kitchener, Ontario, Canada N2M 2C8
Te l: (519) 745-1158 Fax: (519) 745-2364
e-mail: inquiries@tgina.com Website: www.tannoy.com
Tannoy Nederland b.v., Anthonetta Kuijlstraat 19, 3066 GS Rotterdam.
Te l: (010) 2860555 Fax: (010) 2860431
e-mail: info@tannoy.nl Website: www.tannoy.nl
Tannoy adopts a policy of continuous improvement and product specification is subject to change.
Colours represented here are as accurate as the printing process allows.
6483 0748
Loading...
