RoHS
TANE MICRO
SURFACE MOUNT CONTACTS
.67"L×.31"W×.16"H Surface Mount Type Ultra Mini Type W/Center Leads
Contact Size: .67"L×.31"W×.16"H
(17mm×8mm×4mm)
Standard Magnet Size: .67"L×.31"W×.16"H
(17mm×8mm×4mm)
Standard Gap: .32"(8mm)
Specifications
Part Number
TANE MICRO
Gap
Inch(mm)
.32"(8)
OPERATING TEMPERATURE:-40°C to +60°C
Loop
Open/Closed
CLOSED
Reed
Form
Normally
Open
Outline Dimensions
TANE MICRO
.06"(1.6)
.31"(8)
RoHS
Max. Contact
Rating (W)
1
.16"(4)
Colors: White, Brown
12"(305mm) 22 AWG Leads Standard
Longer leads available
Max. Initial Contact
Resistance (mΩ)
100
.16"(4)
.16"(4)
.31"(8)
Max. Switching
Voltage (V)
AC24/DC24 0.1
Max. Switching
Current (A)
Unit: inch(mm)
44
.67"(17)
.47"(12)
.35"(9)
2-Φ.043"(1.1)
.67"(17)
.47"(12)
2-Φ.043"(1.1)
.35"(9)
