LISTED
C
US
U
L
TANE-3/4 TC
RECESSED CONTACTS
.76"(19.4mm) Recessed Type W/Terminal Quick-Connect
Contact Size: .75"×1.18"(19.05mm×30mm)
Standard Magnet Size: .76"×.85"(19.05mm×21.5mm)
Standard Gap: 1.1"(28mm)
RoHS
Specifications
Part Number
TANE-3/4 TC
TANE-3/4B TC
TANE-3/4 TC
W/TAP-10 MAG
*
Special Order
Gap
Inch(mm)
1.1"(28)
1.1"(28)
.6"(15)
Loop
Open/Closed
CLOSED
OPEN
CLOSED
Reed
Form
Normally
Open
Normally
Closed
Normally
Open
OPERATING TEMPERATURE:-40°C to +60°C
*SPECIAL ORDER - Call for Min. Order Qty. - Leadtime - Pricing
Max. Contact
Rating (W)
Outline Dimensions
TANE-3/4 TC/TANE-3/4B TC
.06"(1.5)
10
10
US
LISTED
R
Max. Initial Contact
Resistance (mΩ)
3
Colors: White, Brown
Max. Switching
100
100
100
.06"(1.5)
AC110/DC100
AC110/DC100
Voltage (V)
AC30/DC30
Max. Switching
Current (A)
0.5
0.2
0.5
Unit: inch(mm)
Φ.35"(9)
Φ.75"(19.05)
1.18"(30)
.53"(13.5)
Φ.97"(24.6)
Φ.97(24.6)
.53"(13.5)
.85"(21.5)
Φ.52"(13.2)
Φ.75"(19.05)
17
TANE-3/4 TC
RECESSED CONTACTS
Outline Dimensions
TANE-3/4 TC W/TAP-10 MAG
Unit: inch(mm)
.06"(1.5)
Ø.37″(9.5)
1.26″(32)
Ø.45″(11.5)
Φ.97"(24.6)
.53"(13.5)
Φ.75"(19.05)
1.18"(30)
Φ.35"(9)
18
