LISTED
C
US
U
L
RoHS
SD-70
.75"(19.05mm) Steel Door Recessed Type
RECESSED CONTACTS
Contact Size: .75"×.84"(19.05mm×21.3mm)
Standard Magnet Size: .75"×.84"(19.05mm×21.3mm)
Standard Gap: 1.1"(28mm)
Specifications
Part Number
SD-70
SD-71B
SD-70 WG 1.26"(32) CLOSED
SD-72C
SD-74C
Gap
Inch(mm)
1.1"(28)
1.1"(28)
1.1"(28)
.75"(19)
OPERATING TEMPERATURE:-40°C to +60°C
Loop
Open/Closed
CLOSED
OPEN
SPDT
DPDT
Reed
Form
Normally
Open
Normally
Closed
Normally
Open
SPDT
DPDT
Outline Dimensions
RoHS
10
10
R
3
3
3
Max. Contact
Rating (W)
Colors: White, Brown
12"(305mm) 22 AWG Leads Standard
US
LISTED
Max. Initial Contact
Resistance (mΩ)
Longer leads available.
100
100
100
100
100
Max. Switching
Voltage (V)
AC110/DC100
AC30/DC30
AC110/DC100 0.5
AC30/DC30
AC30/DC30
Max. Switching
Current (A)
Unit: inch(mm)
0.5
0.2
0.2
0.2
SD-70/SD-71B
Ø.52″(13.2)
Ø.75″(19.05)
.53″(13.5)
.84″(21.3)
Ø.97″(24.6)
Ø.97″(24.6)
.53″(13.5)
.84″(21.3)
Ø.75″(19.05)
Ø.52″(13.2)
13
SD-70
RECESSED CONTACTS
Outline Dimensions
SD-70 WG
Bare Rare Earth
(BT 3/8"×3/4")
SD-72C
Ø.52″(13.2)
.75″
(19)
Ø.75″(19.05)
.53″(13.5)
.84″(21.3)
Ø.37″
(9.5)
Ø.97″(24.6)
Ø.97″(24.6)
Ø.97″(24.6)
.53″(13.5)
.84″(21.3)
.53″(13.5)
.84″(21.3)
Ø.75″(19.05)
Ø.75″(19.05)
Unit: inch(mm)
Ø.52″(13.2)
Ø.52″(13.2)
SD-74C
Wiring Diagram
SD-72C SD-74C
COM(White)
NC(Red)
NO(Black)
Ø.52″(13.2)
Ø.75″(19.05)
.53″(13.5)
.84″(21.3)
Ø.97″(24.6)
Ø.97″(24.6)
.53″(13.5)
.84″(21.3)
Ø.75″(19.05)
Ø.52″(13.2)
COM(White)
NC(Red)
NO(Black)
COM(White)
NC(Red)
NO(Black)
14
