Tandberg Data FC420
Bridge Option User’s Guide
Introduction 3
Fibre Channel Overview ...................................................................... 3
Library Operation After FC420 Bridge Installation ............................... 3
Cabling the M2500 Library for Fibre Channel 4
One- and Two-Drive Library Cabling ................................................... 4
Cabling with Three or More Drives ...................................................... 5
Setting SCSI IDs 7
Configuring FC420 Firmware 8
Setting Up an Ethernet Connection ..................................................... 8
Verifying Current FC420 Firmware .................................................... 10
Setting Local Echo Mode................................................................... 10
Scanning the SCSI buses on the Library........................................... 10
Creating a Map File for the FC420 .................................................... 11
Making Other Configuration Changes ............................................... 11
Updating FC420 Firmware 12
Document T6423053-01, Ver. 1, Rel. 0, November 2002 1
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
FC420 Services Software Commands 13
FC420 Service Software Operation................................................... 13
Command Syntax .............................................................................. 14
List of Abbreviations .......................................................................... 14
Command Listing............................................................................... 14
2 6207947-04fN 13
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Introduction 0
This document describes the configuration and operation of the FC420
Fibre Channel Bridge option installed in the M2500 library.
For FC420 installation steps, refer to the FC420 Fibre Channel Bridge
Quick Reference Guide (PN T6473054).
For a description of M-Series library operating procedures, see the
Tandberg Data M-Series Library User’s Guide (PN T6423045).
Fibre Channel
Overview
The M2500 library is controlled by a host computer via a SCSI
0
differential bus using the SCSI-2 medium changer command set. The
library’s architecture allows for easy conversion from the SCSI host
interface to a Fibre Channel host interface by installing the FC420
Bridge option.
Fibre Channel is a serial data transfer architecture for use with
computers and mass storage devices. Fibre Channel is rapidly
emerging to challenge SCSI as the interface of choice for host-tostorage applications.
Fibre Channel advantages include:
• Connection distances of up to 500 meters
• Up to 2 GB/sec data transfer rates with Autonegotiate
• Support for up to 126 devices on a loop
• Support for 24-bit addressing for over 16 million devices in
point-to-point mode or fabric, when using a Fibre Channel switch
or multiple Fibre Channel switches.
• Operating system independence
• Interconnect flexibility
Library Operation
After FC420 Bridge
Installation
0
• Fibre Channel fabric switches provide full direct connectivity
between all ports on a network, which can increase the total
throughput of all devices on a network.
Once the FC420 Bridge SCSI to Fibre Channel option is installed and
tested, the library operates exactly as a library with a SCSI host
interface. User operation of the library via the graphical user interface
(GUI) panel is unchanged.
Introduction 3
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Cabling the M2500 Library for Fibre Channel 0
The cabling configuration used for the M2500 library with the FC420
option depends on the following factors:
• Number of tape drives installed
•Tape drive type (SDLT or LTO)
• Number of FC420 Fibre bridges installed
• Data transfer rate of the storage area network (SAN)
One- and Two-Drive
Library Cabling
Figure 1 One-Drive
Cabling
M2500
Auxiliary
electronics
module
Slot for FC420
Slot for FC420
If the M2500 library has only one or two tape drives, the cabling is the
0
same regardless of drive type or SAN. One- or two-drive libraries only
require one FC420 Fibre bridge.
Figure 1
shows the cabling for a one-drive library.
FC420
SCSI
SCSI controller
Drive 1
SCSI
Terminator
Primary
electronics
module
Fibre
SAN
As shown in the figure, a SCSI daisy chain is established from one of
the SCSI ports on the FC420 to the SCSI controller and then to drive 0,
where the daisy chain is terminated. The SCSI controller is included in
the chain to pass SCSI commands to the robot.
The SCSI controller and drive 1 must be on the same SCSI bus because
the SCSI controller has termination disabled.
4 Cabling the M2500 Library for Fibre Channel
Figure 2 Two-drive
Cabling
M2500
Auxiliary
electronics
module
Slot for FC420
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
Figure 2 shows typical cabling for a two-drive library.
SCSI
Drive 2 Drive 1
Te rm i n at o r
SCSI
SCSI
FC420
SCSI controller
Primary
electronics
module
November 2002
Fibre
Slot for FC420
Cabling with Three or
More Drives
SAN
In a two-drive library, the second drive (Drive 2) should be connected
to the available FC420 SCSI port, creating a second SCSI bus. This fully
utilizes the FC420 Fibre bridge and maximizes the communication
bandwidth available to each tape drive.
When cabling M2500 libraries with three or more tape drives, you
0
need to know the type of tape drive installed in the library and the
data transfer rate of the SAN to determine the correct SCSI
configuration.
Note: As with the one- and two-drive configurations, all Fibre-to-
SCSI cabling configurations must include the SCSI controller
so that SCSI commands intended for the robot are
successfully communicated.
Cabling the M2500 Library for Fibre Channel 5
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
SDLT/LTO Drive Cabling with a 1-GB SAN 0
For example, if you have SDLT or LTO drives and a 1 GB SAN,
Quantum recommends a ratio of one tape drive per FC420 SCSI port.
This means that three- and four-drive libraries would require a second
FC420 Fibre bridge, and five- and six-drive libraries would require
three FC420 bridges, as shown in Figure 3
Note: SDLT and LTO tape drives are sometimes referred to as
Superdrives.
Figure 3 One-Drive-PerFC420-Port Cabling
M2500
Drive 2 Drive 1
Auxiliary
electronics
module
FC420
FC420
SCSI
Drive 4 Drive 3
SCSI
Drive 6 Drive 5
SCSI
SCSI
SCSI
SCSI
FC420
SCSI controller
Terminator
.
Primary
electronics
module
Fibre
SCSI
Fibre
Fibre
SDLT/LTO Drive Cabling with a 2-GB SAN 0
If the M2500 library with SDLT or LTO drives is connected to a 2-GB
SAN, Tandberg Data recommends a maximum ratio of 2 tape drives
per FC420 SCSI port. This means that one FC420 Fibre bridge could
manage up to four tape drives, but a second FC420 Fibre bridge would
be required for libraries with five or six tape drives.
6 Cabling the M2500 Library for Fibre Channel
1-GB SAN
Figure 4 Two-Drives-PerFC420-Port Cabling
M2500
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Figure 4 shows a six-drive library utilizing a two-drive per port
cabling scheme.
Note: To increase the bandwidth available to each tape drive,
install additional FC420 Fibre bridges and use the cabling
configuration shown in figure 3
SCSI
SCSI
Drive 2 Drive 1
SCSI
.
FC420
SCSI controller
Primary
electronics
module
Fibre
Auxiliary
electronics
module
Slot for FC420
FC420
Drive 4 Drive 3
SCSI
Drive 6 Drive 5
SCSI
Fibre
SCSI
SCSI
Terminator
2-GB SAN
Setting SCSI IDs 0
Table 1 SCSI ID Settings
Use the information in table 1
IDs) for the library.
Device SCSI ID Device SCSI ID
to set the SCSI device addressing (SCSI
SCSI Controller 0 Drive 3 4
Drive 01Drive 45
Drive 12Drive 56
Drive 2 3
Setting SCSI IDs 7
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Configuring FC420 Firmware 0
Each FC420 Fibre bridge installed in the M2500 library must be
configured using the FC420 Bridge Services software. The key to
successfully configuring the FC420 Fibre bridge is to:
• Know exactly how the SCSI cabling in the library is configured
including:
• How many FC420 Fibre bridges are present in the library.
• How many SCSI buses are present in the library.
• How many SCSI devices are connected to each bus.
This was established in the previous section of this document.
• Use the FC420 Bridge Services software to create a Map file
identifying which SCSI devices are electrically connected to which
Fibre Channel ports on the FC420 board.
Setting Up an Ethernet
Connection
The major steps for configuring FC420 Fibre bridge firmware involve:
• Setting Up an Ethernet Connection
• Verifying Current FC420 Firmware on page 10
• Setting Local Echo Mode
• Scanning the SCSI buses on the Library
• Creating a Map File for the FC420
Note: These major steps must be repeated for each FC420 Fibre
on page 10
on page 10
on page 11
bridge in the library.
To set up an Ethernet connection between the FC420 Fibre bridge and a
0
service PC or other stand-alone computer:
1 Establish a physical connection between the FC420 bridge and the
computer using a CAT 5E crossover cable. To do this:
a Make sure the computer and library are both turned off.
b Attach one end of the cable to the RJ-45 connector at the bottom
of the FC420 bracket.
2 Turn on the computer.
8 Configuring FC420 Firmware
c Attach the other end of the cable to the NIC port on the
computer.
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
3 Set network properties and specify an IP address for the computer.
a Right-click the network icon on the computer’s desktop.
For some versions of Windows, this icon may be labeled
Network Neighborhood. For other versions of Windows, the
icon may be labeled
b When the pop-up menu appears, select Properties. A Network
My Network Places or something similar.
dialog box appears.
c Click the Protocols (Windows NT) or Connections (Windows
2000 or later) tab.
d Double-click the TCP/IP Protocol menu item. The TCP/IP
Properties dialog box appears.
e Click the Specify an IP address option button. The IP Address,
Subnet Mask, and Gateway fields become active.
f Type 10.0.0.x (where x is a number between 2 and 253) in the IP
Address field,
255.255.255.0 in the Subnet Mask field, and
nothing in the Gateway field.
g Click OK until you completely exit all dialog boxes.
h For Windows NT users, open a DOS window and type
ipconfig/release <Enter> followed by ipconfig/renew <Enter>.
(For other versions of Windows, this step is not required.)
4 Turn on the library.
5 Establish a Telnet connection to the FC420 Fibre bridge. To do this:
a Start a Telnet session from the computer desktop by selecting
Start > Run.
b In the Run dialog box, type telnet 10.0.0.1 and then click OK.
The Telnet window appears (as shown in figure 5
connection with the FC420 Fibre bridge. When you see the
), indicating a
Ready
prompt, command line mode is available.
Configuring FC420 Firmware 9
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Figure 5 Telnet Window
Showing Connection with
FC420
Firmware version
information
Verifying Current
FC420 Firmware
Setting Local Echo
Mode
Scanning the SCSI
buses on the Library
The Telnet connection window shows the firmware version and gives
0
the firmware revision date. See figure 5
.
Use this information to determine if the FC420 Fibre bridge has current
firmware.
Note: If you suspect that the firmware needs to be updated, follow
the instructions found in Updating FC420 Firmware
on
page 12.
To set local echo mode, type
0
prompt and then press
set SerialPortEcho enabled at the Ready
<Enter>.
Use the following procedure to confirm that the SCSI buses are cabled
0
properly.
1 At the Ready prompt, type scsitargets 0, and then press <Enter>.
This command scans and displays all SCSI devices found on SCSI
bus 0.
2 When the Ready prompt reappears, type scsitargets 1, and then
10 Configuring FC420 Firmware
press
<Enter> if the second SCSI port on the FC420 bridge is being
utilized.
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Creating a Map File for
the FC420
Making Other
Configuration
Changes
Each FC420 Fibre bridge in the library requires a map file to identify
0
the SCSI devices in the library electronically connected to each Fibre
Channel port on the board.
To create the FC420 Map, perform the following steps:
1 At the Ready prompt, type scsiportlist and then press <Enter>.
This command returns a list of available SCSI ports and their
current status. Valid status values are
2 If there are no SCSI bus failures, type automap and press <Enter>.
OK and Failed.
The automap command executes.
3 When the Ready prompt reappears, type saveconfiguration and
<Enter>.
press
4 When the Ready prompt reappears, type firmwarerestart and press
<Enter>.
The preceding firmware configuration steps are mandatory to ensure
the successful operation of the library. After completing these
0
procedures, you may want to make other configuration changes by
issuing other service commands.
Service Command List 0
For your convenience, the entire set of service commands for the
FC420 Fibre bridge are listed in the section that follows.
Using the Help Command 0
You can also obtain a list of service commands by typing
pressing
<Enter>.
To get more information about a particular command, type
command_name
and then press <Enter>. The variable command_name
help and then
help
is the exact name of the command you want information about.
Configuring FC420 Firmware 11
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Updating FC420 Firmware 0
If the FC420 firmware requires updating, follow this procedure:
1 Obtain the latest copy of the firmware. To do this, go to
www.quantum.com/softwaredownload. Locate and download the
appropriate driver.
2 Establish an Ethernet cable connection from the computer with the
new FC420 driver to the Fibre Channel bridge to be updated as
explained in Setting Up an Ethernet Connection
3 From the computer, open a command prompt window and type ftp
[FC420 IP address]
4 When prompted for a username, type sysadmin or the current
system administrator ID and press
password, type
password and press
and then press <Enter>.
<Enter>. When prompted for a
sysadmin or the current system administrator
<Enter>.
on page 8.
5 At the command line, type bin and then press <Enter>.
6 At the command line, type put [firmware filename] and then press
<Enter>.
Several messages appear on the screen. Finally, a success message
appears.
7 Type bye or quit and then press <Enter>.
8 Repeat steps 1 to 7 to update the firware of other FC420 Fibre
bridges installed in the library.
9 Restart the library.
12 Updating FC420 Firmware
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
FC420 Services Software Commands 0
The FC420 Services Software is resident on each FC420 Bridge board,
and is used to configure the bridge for use in the library. The software
uses a Command Line Interface (CLI) that is usable with any PC and a
terminal emulation program such as HyperTerminal or ProComm.
FC420 Service
Software Operation
The Command Line Interface provides access to the FC420 services
0
through a set of ASCII-based command lines. Commands have four
types of operation:
• Immediate—cause an immediate action; not preceded by a get or
set operation.
• Get—returns the current value of a parameter or setting. This
command may be abbreviated to “g.”
• Set—changes the value of a parameter or setting. This command
may be abbreviated “s,” and does not take effect until a
SaveConfiguration command is sent.
• Usage—if the form of an operation cannot be determined, it is
assumed to be the “Usage” form and a brief help message is
displayed.
The commands are not case sensitive.
Decimal numbers may be entered as raw numerical input, such as 123.
Octal numbers must be preceded by the number 0, for example 0713.
Hexadecimal numbers must be preceded by the C-style of 0x prefix,
such as 9x1FA4.
Quoted strings are treated as a single parameter for any command
which expects character input, regardless of space in the string.
Several non-immediate commands require a
SaveConfiguration before
their modified parameters take effect. When such a command is
executed an asterisk appears next to the command line prompt.
FC420 Services Software Commands 13
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Command Syntax 0
List of Abbreviations 0
Command Listing 0
The following is a list of syntax used to describe command lines:
• [ ] indicates required entry
• < > indicates optional entry
• | indicates choose one entry
The following is a list of abbreviations used to describe command
lines:
• fpFibre Channel port number (0 - 2)
• flFibre Channel LUN (0 - 31)
• sbSCSI bus number (0 - 3)
• stSCSI target ID (1 - 15)
• sl SCSI LUN (0 - 7)
A list of the currently available FC420 Services Software commands is
shown in table 1
.
Table 2 Most Common
FC420 Services
Commands
Command Description Default Syntax
AutoMap (Immediate)
BootFibreDelay
BootScan
BootScanPorts
ClearEvent (Immediate)
Automatically maps all currently
operational SCSI devices attached to
the FC420 Fibre bridge.
Selects/displays the boot fibre delay
(in seconds).
Enables/disables the boot scan feature.
This feature provides dynamic
mapping of SCSI devices to fibre port/
lun combinations via a SCSI port at
boot time.
Selects/displays the ports to be used
for a boot scan.
Clears the contents of the event log. clearevent
0 set bootfibredelay [0 | 15 |
disabled set bootscan [enabled |
auto set bootscanports [fp] | [all] |
automap
30]
get bootfibredelay
disabled]
get bootscan
[auto]
get bootscanports
14 FC420 Services Software Commands
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
Command Description Default Syntax
November 2002
DhcpFixedDelay
Selects/displays the delay interval (in
seconds) between DHCP client
requests.
DispEvent
Sets the switches that controls the filtering performed when
displaying events. Switches have the following settings:
[subsystem] switch: mask that controls which subsystem events
are displayed. The mask is a byte value with the following bit
patterns corresponding to the currently supported subsystems:
0x01 FCP Processor /i960
Interaction
0x02 SCSI Processor/i960
Interaction
0x04 Ethernet (Future)
0x20 NVRAM & Flash
To display the events from several different subsystems, use a
mask value equal to the logical OR of the corresponding
subsystem values. To display events from all subsystems enter
the value 3Fh for the mask.
[event_level] switch: mask that controls what reporting level
events are displayed. The mask is a byte value with the following
bit patterns corresponding to the currently supported reporting
levels:
0 set dhcpfixeddelay [0-255]
get dhcpfixeddelay
set dispevent [subsystem]
[event_level] [status]
get dispevent
0x00
0x00
0x01 Info; general information
0x02 Warning; unexpected situation/condition
0x04 Critical; operation limited/curtailed
0x08 Failure; hard failure
0x10 Other; otherwise not categorized
0x20 Debug; tracking events
To display events from several different reporting levels, use a
mask value equal to the logical OR of the corresponding
reporting levels. To display events for all reporting levels enter
the value 3Fh for the mask.
[status] switch: has the following two values which correspond
to the status of the events to be displayed:
all: All events, regardless of their status values are displayed.
ngood: Only events with a status other than good are displayed.
DispFcPortDB
(Immediate)
Displays the contents of the specified
Fibre port’s internal database.
FC420 Services Software Commands 15
ngood
dispfcportdb <fp>
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Command Description Default Syntax
DisplayEvent
(Immediate)
EccLog
ErrorLog
EthernetSpeed
Displays the current contents of the
event log. The log is filtered by the
current switch settings as described in
the DispEvent section. If the optional
all is selected, the display filtering is
temporarily suspended and all logged
events are displayed.
Resets/displays the ECC error
statistics for the Fibre bridge. The get
command displays the statistics; the
set command resets the statistic
counters to zero.
Resets/displays the error logs for the
Fibre bridge. The get command
displays the logs; the set command
resets the logs to zero.
Sets/displays the Ethernet speed of the
Fibre connection. If auto is selected, the
current speed of the connection is
indicated in parentheses in the
response to the get ethernetspeed
command.
displayevent < all >
set ecclog clear
get ecclog
set errorlog clear
get errorlog
auto set ethernetspeed [10 | 100
|auto]
get ethernetspeed
Exit (Immediate)
FcAck0
FcClass2
FcConnMode
FcDataRate
Exits the current Telnet command line
interface (CLI) session. This command
has no effect during a serial or in-band
CLI session.
Specifies whether ACK0 or ACK1 will
be returned in response to a Class 2
Fibre Channel data frame or sequence.
When enabled, this option sends
ACK0; when disabled, this options
sends ACK1.
Specifies whether the Fibre bridge will
support Fibre Channel Class 2
(Multiplexed) or Class 3 service.
Sets/displays the connection mode for
the FC420 to arbitrated loop or pointto-point. Applies to all three Fibre
Channel ports on each board.
Sets/displays the data rate (in GB/s) at
which the Fibre bridge will operate.
exit
disabled set fcack0 [enabled |
disabled]
get fcack0
disabled set fcclass2 [enabled |
disabled]
get fcclass2
loop set fcconnmode [loop | ptp]
get fcconnmode
auto set fcdatarate [1gb | 2gb |
auto]
get fcdatarate
16 FC420 Services Software Commands
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
Command Description Default Syntax
November 2002
FcFairArb
FcFullDuplex
FcHard
FcHardAddress
FcInitiator
FcPortList
(Immediate)
Fcp2
Turns on or off the FC-AL arbitration
fairness. Applies to all three Fibre
Channel ports on each board.
Enables/disables full duplex
communication between the Fibre
bridge and other Fibre Channel
devices.
Enables/disables Fibre Channel hard
address assignment. Under soft
addressing the FC420 loop address is
assigned during loop initialization.
Sets/displays the value used as the FCAL hard address.
Enables/disables the initiator function
of the Fibre bridge on the Fibre
Channel network.
Lists the available Fibre Channel ports
and their current status.
Enables/disables the Fibre bridge’s
compliance with the FCP-2 Fibre
Channel specification.
enabled set fcfairarb [enabled |
disabled]
get fcfairarb
enabled set fcfullduplex [enabled |
disabled]
get fcfullduplex
disabled set fchard [enabled |
disabled]
get fchard
FC port 0
0x03
set fchardaddress [fp [address]]
get fchardaddress [fp]
disabled set fcinitiator [enabled |
disabled]
get fcinitiator
fcportlist
disabled set fcp2 [enabled | disabled]
get fcp2
Fcp2Conf
Fcp2CRN
FcSCSIBusyStatus
FcTargets (Immediate)
Enables/disables the Fibre bridge’s
capability to request FCP_CONF IUs.
This option is only valid when the fcp2
command is also enabled.
Enables/disables the Fibre bridge’s
capability to accept CRNs for precise
delivery of SCSI commands. This
option is only valid when the fcp2
command is also enabled.
Specify the SCSI status value returned
when the FC420 is unable to accept a
SCSI command due to a temporary
lack of internal resources.
Provides the node name, Fibre LUN,
and inquiry data for every Fibre
Channel target device visible to a Fibre
bridge operating in initiator mode.
disabled set fcp2crn [enabled |
disabled]
get fcp2crn
disabled set fcp2conf [enabled |
disabled]
get fcp2conf
BUSY set fcscsibusystatus [busy |
qfull]
get fcscsibusystatus
fctargets <fp>
FC420 Services Software Commands 17
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Command Description Default Syntax
FcWWName
FibreBridgeModel
FibreBridgeName
Sets/displays the current World Wide
Name (WWN) of the Fibre Channel
interface referenced. Each Fibre port
has a unique WWN. The least
significant 6 bits of the WWN are used
as the Ethernet MAC address.
The set variant of the command allows
the user to change the last three bytes
of each WWN. Please note, however,
that the most significant bit of the three
bytes must be 1 in order to provide
WWN verification. Also note that the
last bit of each WWN may only be
assigned one of the following values: 0,
4, 8, or C for port 0; 1, 5, 9, or D for port
1; and 2, 6, A, or E for port 2.
Fabric and loop operation is
unpredictable if duplicate WWNs are
used.
Reports the specific FC420 model
information.
Specify the 8-character name assigned
to the FC420 bridge.
10 00 0x,
where x
is the
Fibre
set fcwwname [portnumber
[0xnn 0xnn 0xnn]]
get fcwwname [portnumber]
port
number.
get fibrebridgemodel
“........” set fibrebridgename [name]
get fibrebridgename
FibreBridgeTargetLUN
FirmwareRestart
(Immediate)
Help (Immediate)
IdentifyFibreBridge
Info (Immediate)
Specify the soft target LUN used by the
FC420 when addressed by the host.
0x7 set fibrebridgetargetlun [0 -
31]
This LUN is taken from NVRAM.
Reboots the FC420 firmware. firmwarerestart
Displays a list of available commands.
help [command name]
When the optional command name is
present, detailed command-specific
information is displayed.
Causes the “Fault” LED on the FC420
board to blink continuously until
disabled.
Displays version numbers and other
disabled set identifyfibrebridge
[enabled | disabled]
Get identifyfibrebridge
info
product information for key
components within the FC420.
18 FC420 Services Software Commands
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
Command Description Default Syntax
November 2002
IPAddress
IPDHCP
IPGateway
IPSubnetMask
IsReserved (Immediate)
Sets/displays the current IP address of
the Fibre bridge. If the ipdhcp
command is enabled, the get
command reports the current IP
address assigned by the nameserver.
Enables/disables the capability of the
Fibre bridge to request an IP address
from a DHCP server on the network.
Sets/displays the current default
gateway. If the ipdhcp command is
enabled, the get command reports the
current IP gateway assigned by the
nameserver.
Sets/displays the current subnet mask.
If the ipdhcp command is enabled, the
get command reports the current IP
subnet mask assigned by the
nameserver.
Displays the reservation status of the
current Fibre bridge services session/
interface. When a reserve flag is set,
the configuration image4 is
undergoing modification by another
Fibre bridge services session. Set
commands are unavailable while in
this state. Get commands are available,
however.
10.0.0.1 set ipaddress xxx.xxx.xxx.xxx
get ipaddress
disabled set ipdhcp [enabled |
disabled]
get ipdhcp
0.0.0.0 set ipgateway xxx.xxx.xxx.xxx
get ipgateway
255.255.
255.0
set ipsubnetmask
xxx.xxx.xxx.xxx
get ipsubnetmask
isreserved
Executing a saveconfiguration,
restoreconfiguration, or
firmwarerestart command releases the
reserved state so that other users may
issue set commands.
FC420 Services Software Commands 19
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Command Description Default Syntax
LogEvent
MaxEnclTempAlrm
Menu
MinEnclTempAlrm
Sets the switches which control the
filtering performed when logging
events. The switches have the
following meanings and settings:
[enabled | disabled] switch: controls
whether or not events logging is
enabled or disabled.
[subsystem] switch: same as switch for
DispEvent in previous section
[event_level] switch: same as switch
for DispEvent in previous section
[status] switch: same as switch for
DispEvent in previous section
Sets/displays the maximum enclosure
temperature alarm of the unit in
degrees C (5-40 degrees C).
Enables/disabled the menu interface.
Entering the command alone without
parameters toggles the current state.
Sets/displays the minimum enclosure
temperature alarm of the unit in
degrees C (5-40 degrees C).
set logevent [enabled |
disabled] | [[subsystem]
[event_level] [status]]
get logevent
disabled
3Fh
3Fh
all
70°C set maxencltempalrm [5 - 40]
get maxencltempalrm
menu <[enabled | disabled]>
0°C set minencltempalrm [5 - 40]
get minencltempalrm
OEMConfigFile
ParityLog
Performance
Reports the name (i.e., the contents of
the first record) of the OEM
configuration file stored in persistent
memory. This file is used to override
the factory default configuration of the
FC420 Fibre bridge.
Resets/displays the parity error
statistics for the Fibre bridge. The get
command displays the statistics; the
set command resets the statistic
counters to zero.
Returns the performance data for a
user-specified Fibre port.
get oemconfigfile
set paritylog clear
get paritylog
get performance <fp>
20 FC420 Services Software Commands
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
Command Description Default Syntax
November 2002
Reserve (Immediate)
Reservation of the FC420 is implicit; once the configuration
image is changed by any user of services (Serial/Ethernet/Etc.,)
the FC420 becomes RESERVED. Performing a
SaveConfiguration, RestoreConfiguration or FcRestart
RELEASES the FC420 so that other devices may access it.
When the FC420 services interface is reserved, set commands are
unavailable, but get commands are available. Note that at least
one service interface always has access to the FC420 at all times.
This interface always reports a RELEASED status, since it may
issue set commands.
RestoreConfiguration
(Immediate)
Restore to factory default
configuration or the last saved
configuration. The new configuration
must be saved to take effect.
RouteChange
(Immediate)
Map a Fibre Channel port (fp) and
LUN (fl) to a SCSI bus (sb), target (st),
and LUN (sl). Valid route change
entries are:
fp (0-2)
fl (0-31)
reserve
restoreconfiguration [default
| saved]
routechange [fp] [fl] [sb] [st]
[sl]
RouteDisplay
RouteOffline
RouteOnline
sb (0-3)
st (0-15)
sl (0-7).
List the currently mapped Fibre
Channel-to-SCSI routes.
routedisplay
routedisplay [fp]
routedisplay [online | offline]
routedisplay [fp [fl]]
routedisplay [fp [online |
offline]]
Set the status of a route to offline. set routeoffline [fp] [fl]
get routeoffline [fp] [fl]
Set the status of a route to online. set routeonline [fp] [fl]
get routeonline [fp] [fl]
FC420 Services Software Commands 21
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Command Description Default Syntax
SaveConfiguration
(Immediate)
ScsiInitID
ScsiPortBusSpeed
ScsiPortList
(Immediate)
ScsiPortReset
(Immediate)
ScsiPortResetOnStartup
Save the new configuration. If a
firmware restart is required to make
saveconfiguration < restart |
nonrestart >
the change, the user is prompted to
confirm the restart. The user can
override the confirmation request by
indicating the override value on the
command line.
Specify the SCSI initiator ID to be used
on the specified SCSI port.
Specifies the transfer rate at which the
Fibre bridge will attempt to negotiate
with SCSI devices. The choices are Fast
SCSI, Ultra SCSI, Ultra 2 SCSI, and
Ultra 3 SCSI.
List the available SCSI ports and their
0x07 set scsiinitid [sb [0-15]]
get scsiinitid [sb]
ultra3 set scsiportbusspeed
[portnumber [fast | ultra |
ultra2 | ultra3]]
get scsiportbusspeed
[portnumber]
scsiportlist
status.
Resets the specified SCSI bus. scsiportreset [sb]
Specify whether the SCSI port should
be reset on power-up.
enabled set scsiportresetonstartup [sb
[enabled | disabled]]
ScsiPortSelTimeout
ScsiPortSyncTransfer
ScsiPortTaggedQueuing
ScsiPortWideTransfer
ScsiTargets
ScsiTermination
Show the time (msec) that the bridge
waits for a response from a SCSI
device on the selected port after a
selection request.
Specify whether synchronous SCSI
transfers should be negotiated with
devices on the specified SCSI port.
Specify whether tagged command
queuing is allowed on the SCSI port.
Specify whether wide SCSI transfers
should be negotiated.
List the SCSI devices that are on the
referenced SCSI bus.
Set the internal termination of the
referenced SCSI port.
get scsiportresetonstartup [sb]
256 msec set scsiportseltimeout [sb [256
| 128 | 64 | 32 | 16 | 8 | 4 | 2
| 1]]
get scsiportseltimeout [sb]
enabled set scsiportsynctransfer [[sb]
[enabled | disabled]]
get scsiportsynctransfer [sb]
disabled set scsiporttaggedqueuing [sb
[enabled | disabled]]
get scsiporttaggedqueuing
[sb]
enabled set scsiportwidetransfer [sb
[enabled | disabled]]
get scsitargets [sb]
enabled set scsitermination [sb
[enabled | disabled]]
get scsitermination [sb]
22 FC420 Services Software Commands
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
Command Description Default Syntax
November 2002
SerialNumber
SerialPortBaudRate
SerialPortEcho
SerialPortHandshake
SerialPortStopBits
ServicesLUN
Reports the FC420 board serial
number.
Set the baud rate for the FC420 serial
port (2400, 9600, 19200, 38400, 57600, or
115200).
Turn on or off the echoing of keyboard
input.
Set the data handshaking method used
for controlling the flow between the
transmitter and receiver (hardware,
software, or none).
Set the number of stop bits for the
FC420 serial port (1 or 2).
Identifies the LUNs (one per Fibre
port) to be used during an in-band
command line interface (CLI) session
with a given host. This information is
taken from NVRAM.
Any map coinciding with a userspecified ServicesLUN must first be set
to offline before attempting to change
the ServicesLUN. This map will be
destroyed upon power-cycling the
Fibre bridge. Disabling a ServicesLUN
for a particular Fibre port will destroy
the map to the Fibre bridge for that
port.
get serialnumber
9600 set serialportbaudrate [rate]
get serialportbaudrate
disabled set serialportecho [enabled |
disabled]
none set serialporthandshake [hard
| xon | none]
get serialporthandshake
1 set serialportstopbits [1 | 2]
get serialportstopbits
8 set serviceslun [fp] [[fl] |
disabled]
get serviceslun <[fp]>
SpeedWrite
Enables/disables SpeedWrite
functionality to any SCSI device
currently mapped to the Fibre bridge.
To enable/disable SpeedWrite for a
particular device, specify the SCSI bus
(sb), the target (st), and the LUN (sl).
Specify “all” to enable/disable this
option for all currently mapped SCSI
devices.
SpeedWriteDefault
Enables/disables SpeedWrite
functionality as a default condition
when SCSI devices are mapped to the
Fibre bridge.
Temperature
Reports the unit temperature in
degrees C.
set speedwrite [sb st sl | all]
[enabled | disabled]
get speedwrite [sb st sl | all]
disabled set speedwritedefault
[enabled | disabled]
get speedwritedefault
get temperature
FC420 Services Software Commands 23
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
Command Description Default Syntax
VerboseMode
Virtual Drive Response
XCDevices
Sets the Command Line Interface to
display extended information about a
parameter when the help command is
given. When verbose mode is enabled,
parameter values are generally
preceded by labels in responses to the
get commands. Only the parameter
value is output when verbose mode is
disabled.
Enables/disables the virtual drive
response feature, which allows the
Fibre bridge to provide proxy
responses to SCSI INQUIRY and TEST
UNIT READY commands in the event
of a SCSI device selection time-out or
busy event.
Displays information about the devices
used in a specified Extended Copy
command. The cmdnumber variable is
obtained using the xcstatus
command.
This command returns the following
information: device type, vendor ID,
product ID, serial number, and data
direction.
enabled set verbose [enabled |
disabled]
get verbose
disabled set virtualdriveresponse
[enabled | disabled]
get virtualdriveresponse
get xcdevices [cmdnumber]
XCError
Retrieves any SCSI sense data returned
by an Extended Copy command as the
result of an error.The cmdnumber
variable is obtained using the xcstatus
command.
This command returns the following
information: SCSI status, sense key,
ASC, and ASCQ. If a device involved
in the command’s data transfer also
returned sense data, the device ID
(serial number) along with sense data
for the device will be displayed.
get xcerror [cmdnumber]
24 FC420 Services Software Commands
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
Command Description Default Syntax
November 2002
XCStatus
Zmodem (Immediate)
Allows the user to poll for the status of
Extended Copy commands issued to
the Fibre bridge. Each Extended Copy
command is identified with a unique
number. This number (called
cmdnumber) is used when invoking the
xcdevices and xcerror commands.
Transfers a firmware image or
NVRAM parameter file to or from the
bridge using ZMODEM file transfer
protocol.
get xcstatus
zmodem [send [filename] |
receive]
FC420 Services Software Commands 25
Tandberg Data FC420 Bridge Option User’s Guide
Document T6423053-01, Ver. 1, Rel. 0
November 2002
26 FC420 Services Software Commands
Loading...
