Tanaka TBC-355DH User Manual
Specifications and Main Features
- Model : TBC-355/DH
- Type of Engine: 2-Cycle Engine
- Nylon line that can be used includes:
746157 .105, Box, 50 ft
746161 .105, 1/2 tb. Box, 110 ft
746162 .130, 1/2 lb. Box, 75 ft
746166 .105, 1 lb. Box, 235 ft
746167 .130, 1 lb. Box, 150 ft
746170 .105, 3 lb. spool, 705 ft
746171 .130, 3 lb. spool, 450 ft
746174 .105, 5 lb. spool, 1175 ft
746175 .130, 5 lb. spool, 750 ft
- Blades Available:
746105 Weed Blade, 10"X4T
746106 Weed Blade, 10"X8T
746108 Saw Blade, 10"X80T
746192 Carbide Blade, 9"X36T
- Shoulder straps include:
SS-250
PSS-175
- Semi-auto head included and accessories are:
746153 PNH-180
- Perfect Mix 2-Cycle Engine Oil is available in:
700109 2.8 oz. Bottle
700108 16 oz. Self measuring bottle
700170 1 gallon jug commercial size
- Special Tools include:
006 - 29326 – 000 Flywheel remover
009 - 29326 – 000 Piston pin remover
015 - 29338 – 000 Gear shaft remover
016 - 29371 – 000 Pinion remover
020 - 29013 – 000 Coil gap gauge
001 - 29000 – 000 Tachometer
070 – 2000W – 500 Pressure tester
070 – 2000W – 501 Carburettor tool kit
Frequently Asked Questions
- What kind of engine is the TBC-355/DH equipped with?
TBC-355/DH is powered with a 2-cycle engine as previously stated.
- Is there other blades that are compatible with the TBC-355/DH?
More blades that are compatible With the TBC-355/DH include the 10”X4T weed blade, 10” X8T weed blade, 10” X 80T saw blade, and 9” X 36T carbide blade among others.
- How about other accessories meant for TBC-355/DH?
Strap accessories (SS-250 and PSS-175) and semi automatic heads (746153 PNH-180) are available for use with TBC-355/DH.
- Does the TBC-355/DH allow for other types of nylon lines?
Yes, TBC 355/DH allows for the use of different types of lines shaped as nylon in different sizes and in different lengths.
- Which type of oil do you recommend for TBC-355/DH?
Perfect Mix® 2-Cycle Engine Oil is recommended for use with a TBC-355/DH which comes in bottles of different sizes; 2.8 oz, 16 oz, and one gallon.
