Talos Security WASPIR01 Quick Manual

Talos Security WASPIR01

Wireless DVR PIR Alarm System

2

C

CONTENTS

I. Introduction ------------------------------------------------------------------------------ 3
II. Features------------------------------------------------------------------------------------------3
III. Product Overview-----------------------------------------------------------------------------4

1. Technical parameters-----------------------------------------------------------------------4

2. Recommended Scan------------------------------------------------------------------------4

3. Time and date set up------------------------------------------------------------------------5

4. Installation--------------------------------------------------------------------------------------5

5. Turn on and Start:----------------------------------------------------------------------------5

6. Arm operation---------------------------------------------------------------------------------5

7. Disarm operation-----------------------------------------------------------------------------5

8. Automatic recording-------------------------------------------------------------------------5

9. Emergency Alarm-----------------------------------------------------------------------------5

10. Recording Indication------------------------------------------------------------------------5

11. Playback of recorded video---------------------------------------------------------------6

12. Adding wireless accessories-------------------------------------------------------------6

13. Removing wireless accessories---------------------------------------------------------6

IV. Wireless Remote Controller----------------------------------------------------------------6

1. Features------------------------------------------------------------------------------------------6

2. Technical Parameters------------------------------------------------------------------------6

3. Installation and Use---------------------------------------------------------------------------6

4. Adding or removing a connection with alarm host--------------------------------7

V. Wireless Door Magnetic Sensor-----------------------------------------------------------7

1. Features------------------------------------------------------------------------------------------7

2. Technical Parameters------------------------------------------------------------------------7

3. Installation and Use--------------------------------------------------------------------------7

VI. Wireless Sound and Flash Siren ----------------------------------------------------------------7

1. Features -----------------------------------------------------------------------------------------7

2. Technical Parameters------------------------------------------------------------------------7

3. Installation and Use--------------------------------------------------------------------------7

4. Adding a wireless connection with the alarm host-------------------------------8

VII. Cautions-------------------------------------------------------------------------------------------------8

3

I. Introduction:

This product is suitable to work with alarm system .It’s a new hi-tech product which can
automatically take and save audios and videos of the area where alarm events occur. Helpful
for evidence obtain. It has a wide application range such as home, office, hotel, market place,
store, villa, museum and warehouse etc. and any other kind of places which needs special
protection.
The package mainly contains: 1pc wireless DVR PIR alarm, 1pc SD card (4GB), 1pc USB
cable, 1pc power adaptor, 2 remote controls and 1 wireless siren. Please read below
instructions carefully before using.

II. Features:

1. Intelligent microchip control, good performance and reliable quality.

2. Wide-angle PIR detection, special temperature compensation circuit design, wireless signal
transmission.

3. Remote arm and disarm, system will automatically start audio and video recording and save
recorded files named by the starting time (year, month, date, hour, minute, second) of
recording.

4. Remote emergency alarm, automatically start audio and video recording.

5. Default (can be change according to special requirements) recording time for motion
detection is 1 minute , max 9 minutes for emergency alarm recording;

6. 4G default memory capacity and can be extended to 8G, 16G, 32G, files overwrite function,
data can be saved when power off, can connect with computers via data cable to read the
recording files.

7. DC power supply with rechargeable backup battery, backup battery up to 3 hours.

8. Automatic visual prompt for easy identification of recordings.

9. Connect up to 10 wireless sensors or remote controls.
