Talos Security DC650FIR User Manual

v_1.0

DC650FIR / DC650FIRB

User Manual

talossecurity.com

INSTALLATION

How to arrange the cable

How to Open the cover

.2 .1

DIMENSIONS

DC650FIR / DC650FIRB

83

41 42

Fig 1.

Fig 2.

3

1.Draw out the power/video wires
to the installation area.

Connect the power/video jacks

2.
to the camera.

3. Screw up in the camera to the desired
location using the tapping screws.

DC 12V

Power Jack

Video Jack
(BNC/RCA)

CAMREA BASE

FIXING SCREW

CAMREA

CAMREA COVER

Insert coin into the slot to
arrow direction and swing
to up or down to open the
dome over.

Cable Jack Setting

Power (+)

Power (-)

(DC 12V)

TILT 90°

Video Signal

Video GND

Video JackPower Jack

ROTATE 360°

PAN 360°

TOP

SPECIFICATIONS

MODEL

TV System

CCD
Horizontal Resolution
Effective Pixels
Scanning System
Synchronization

Min.lllumination
S/N ratio
Video Output
Scanning Frequency
Electronic Shutter Speed
White Balance

BLC
Sens-up
D-WDR
AGC
Motion Detection
Privacy Function
HLM

DPC
Sharpness

Day & Night

Visible Range

(LED non)

Lens
Power Source
Power Consumption
Operating Temperature
Operating Humidity
Dimension (mm)
Weight

Indoor

Outdoor

DC650FIR / DC650FIRB

NTSC

768(H)x494(V)

15.734KHz / 60Hz

1/60~1/120,000sec

OFF / ON (LOW / MIDDLE / HIGH) selectable3-DNR

OFF / LOW / MIDDLE / HIGH selectable

108

SIDE

LAP

1/3" Color CCD

650TV lines

753(H)x582(V)

2:1 Interlace

Internal

0.00002 Lux(Sens-up)

52 dB or more (AGC Off)

1Vp-p Composite 75Ω

15.625KHz / 50Hz

1/50~1/100,000sec

AWC / MANUAL / PUSH

ON / OFF Selectable

OFF / AUTO (x2 ~ x1024)

ON / OFF Selectable

ON / OFF (4 Area)

ON / OFF, Color, Position (8 zone)

ON / OFF

Built-In OSD

ON /OFF (Level Adjustable 1 ~ 50)

COLOR / BW / AUTO / EXT

25m ( IR LED 5pie -24EA )

20m ( IR LED 5pie - 24EA )

3.6mm Fixed IR Board Lens

DC 12V(±10%)

400mA

-10°C ~ +50°C

30% ~ 90% RH

108mm (W) x 83mm (H)

195g
