Digital Video Recorder User Manual
Digital Video Recorder
Digital Video Recorder User Manual
i
Statement:
This manual may contain information that does not match the product. If you have any
unsolved problems in the process of using this product according to this manual,
please contact our technical support department.
The content of this manual may be updated at irregular intervals without prior notice.
This manual is for reference only. DVR’s functions and operations with different
models may be different.
Caution:
Please read this user manual carefully before using the DVR, and retain it for future
reference.
Please comply with all instructions and notice all warning signs.
Observe all electrical safety standards; make sure the power supply voltage is
correct before using the DVR.
Please avoid heavy stress or violent vibration.
To reduce the risk of fire or electrical shock, do not expose this product near the
water, moisture or dust.
Do not install this device near any heat sources such as radiators, heat registers,
stoves or other device that produce heat.
Do not block any ventilation openings and provide good ventilation around the
machine.
Please disconnect any cables during an electrical storm or the DVR will not be used
for an extended period of time.
If cleaning is necessary, use a clean, dry cloth and wipe it gently.
If the product does not work properly, please contact your dealer or the nearest
service center. Never attempt to disassemble the DVR yourself.
Do not power off the DVR when the device is working. The correct procedure to shut
down DVR is to stop recording firstly, and then use “Shut Down” button from the
menu, and finally switching off the main power.
Digital Video Recorder User Manual
ii
Table of Contents
Chapter 1 Product Introduction ......................................................................................1
1.1 Overview ............................................................................................... 1
1.2 Main Features ........................................................................................ 1
Chapter 2 Installation Guide ............................................................................................4
2.1 Open-package Check .............................................................................. 4
2.2 Install Hard Drive .................................................................................... 4
2.3 Front Panel Description............................................................................ 5
2.4 Rear Panel Description ............................................................................ 6
2.5 Remote Controller ................................................................................... 8
2.6 Control with Mouse ............................................................................... 10
2.6.1 Connect Mouse .......................................................................... 10
2.6.2 Use Mouse ................................................................................ 10
Chapter 3 Basic Function Instruction.............................................................................2
3.1 Power On/Off ......................................................................................... 2
3.1.1 Power On .................................................................................... 2
3.1.2 Power Off .................................................................................... 2
3.2 Login..................................................................................................... 3
3.3 Live Preview .......................................................................................... 4
3.4 Live Playback ......................................................................................... 4
Chapter 4 Main Menu Setup Guide .................................................................................6
4.1 Control Menu ......................................................................................... 6
4.2 Basic Configuration ................................................................................. 8
4.2.1 System ........................................................................................ 8
4.2.2 Date & Time ................................................................................. 9
4.2.3 DST .......................................................................................... 10
4.3 Live Configuration ................................................................................. 10
4.3.1 Live .......................................................................................... 10
4.3.2 Main Monitor .............................................................................. 11
4.3.3 Mask ......................................................................................... 12
4.4 Record Configuration ............................................................................. 13
4.4.1 Enable ...................................................................................... 13
4.4.2 Record Bitrate ............................................................................ 14
4.4.3 Time ......................................................................................... 15
4.4.4 Stamp ....................................................................................... 16
4.4.5 Recycle Record .......................................................................... 17
4.4.6 Snap ......................................................................................... 17
4.5 Schedule Configuration .......................................................................... 18
4.5.1 Schedule ................................................................................... 18
Digital Video Recorder User Manual
iii
4.5.2 Motion ....................................................................................... 20
4.5.3 Sensor ...................................................................................... 20
4.5.4 Reboot the System ...................................................................... 21
4.6 Alarm Configuration ............................................................................... 22
4.6.1 Sensor ...................................................................................... 22
4.6.2 Motion ....................................................................................... 25
4.6.3 Video Loss ................................................................................. 27
4.6.4 Other Alarm................................................................................ 28
4.6.5 Alarm Out .................................................................................. 29
4.7 Network Configuration ........................................................................... 30
4.7.1 Network ..................................................................................... 30
4.7.2 Sub-stream ................................................................................ 31
4.7.3 Email ........................................................................................ 33
4.7.4 WIFI Setup ................................................................................. 34
4.7.5 Other Settings ............................................................................ 34
4.8 User Management Configuration ............................................................. 40
4.9 P.T.Z Configuration ................................................................................ 42
4.9.1 Serial Port .................................................................................. 42
4.9.2 Advanced .................................................................................. 43
4.10 Advanced Configuration ....................................................................... 47
4.10.1 Reset ...................................................................................... 47
4.10.2 Import/Export ............................................................................ 47
Chapter 5 Manage DVR .................................................................................................. 48
5.1 Search and Playback ............................................................................. 48
5.1.1 Time Search ............................................................................... 48
5.1.2 Event Search ............................................................................. 49
5.1.3 File Management ........................................................................ 50
5.1.4 Image........................................................................................ 51
5.2 Backup ................................................................................................ 52
5.3 Information ........................................................................................... 53
5.3.1 System Information ..................................................................... 53
5.3.2 Event Information ........................................................................ 53
5.3.3 Log Information .......................................................................... 53
5.3.4 Network Information .................................................................... 53
5.3.5 Online Users Information .............................................................. 54
5.4 Manual Alarm ....................................................................................... 54
5.5 Disk Management ................................................................................. 54
5.5.1 Format Disk ............................................................................... 54
5.5.2 Advanced .................................................................................. 55
5.6 Upgrade .............................................................................................. 55
5.7 Logoff .................................................................................................. 55
Digital Video Recorder User Manual
iv
Chapter 6 Remote Surveillance .................................................................................... 56
6.1 IE Remote Surveillance.......................................................................... 56
6.1.1 On LAN ..................................................................................... 56
6.1.2 On WAN .................................................................................... 57
6.2 Remote Live Preview ............................................................................. 59
6.2.1 Symbol and Function Definition ..................................................... 60
6.2.2 Snap Picture .............................................................................. 60
6.2.3 Color Adjustment ........................................................................ 60
6.2.4 PTZ Control ............................................................................... 61
6.2.5 Preview Control .......................................................................... 62
6.3 Remote Playback & Backup ................................................................... 62
6.3.1 Time Search ............................................................................... 62
6.3.2 Event Search ............................................................................. 64
6.3.3 File Management ........................................................................ 65
6.3.4 Remote backup .......................................................................... 67
6.4 Remote Configuration & Management ...................................................... 68
6.4.1 Remote Configuration .................................................................. 68
6.4.2 Remote Management .................................................................. 68
6.4.3 Remote Check Information ........................................................... 69
Chapter 7 Mobile Surveillance ...................................................................................... 70
For Android ............................................................................................... 71
7.1 Main Functions ..................................................................................... 71
7.2 Installation ........................................................................................... 71
7.3 Application Running ............................................................................... 72
7.3.1 Interface Description.................................................................... 72
7.3.2 Live Preview .............................................................................. 74
7.3.3 Add Device ................................................................................ 75
7.3.4 Switch Channel .......................................................................... 77
7.3.5 PTZ Control ............................................................................... 79
7.3.6 Local Video ................................................................................ 79
7.3.7 Saved Photos ............................................................................. 81
7.3.8 Switch Language ........................................................................ 81
7.3.9 Video Remote ............................................................................ 81
7.3.10 Real-Time Alarm ....................................................................... 81
For Iphone ................................................................................................ 82
7.4 Main Functions ..................................................................................... 82
7.5 Installation ........................................................................................... 83
7.6 Application Running ............................................................................... 84
7.6.1 Interface Description.................................................................... 84
7.6.2 Live Preview .............................................................................. 86
7.6.3 Add Device ................................................................................ 87
Digital Video Recorder User Manual
v
7.6.4 Switch Channel .......................................................................... 88
7.6.5 PTZ Control ............................................................................... 89
7.6.6 Local Video ................................................................................ 90
7.6.7 Saved Photos ............................................................................. 91
7.6.8 Switch Language ........................................................................ 92
7.6.9 Video Remote ............................................................................ 92
7.6.10 Real-Time Alarm ....................................................................... 92
Appendix A FAQ ........................................................................................................ 93
Appendix B Calculate Recording Capacity ............................................................. 98
Appendix C Compatible Devices .............................................................................. 99
Appendix D Specifications ...................................................................................... 101
Digital Video Recorder User Manual
1
Chapter 1 Product Introduction
1.1 Overview
This model of DVR (Digital Video Recorder) is designed for high performance CCTV
solutions. It adopts state of the art video processing chips and embedded Linux system.
Meanwhile, it utilizes most advanced technologies, such as standard H.264 with low bit
rate, Dual stream, HDMI interface, SATA interface, VGA output, mouse supported, IE
browser supported with full remote control, mobile view(by phones), etc., ensuring
powerful functions and high stability. Due to these distinctive characteristics, it is widely
used in banks, telecommunication, transportation, factories, warehouse and other related
applications.
1.2 Main Features
COMPRESSION FORMAT
Standard H.264 compression with low bit rate and better image quality
LIVE SURVEILLANCE
Support HDMI 1080P output
Support channel security by hiding live display
Display the local record state and basic information
Support USB mouse to make full control
RECORD MEDIA
Support a SATA HDD to record (HDD file system is FAT32 format) continuously.
Digital Video Recorder User Manual
2
BACKUP
Supports USB 2.0 devices to backup
Supports saving recorded files to a remote computer through internet
RECORD & PLAYBACK
Record modes: Manual, Schedule, Motion detection and Sensor alarm recording
Supports recycle after HDD full
Supports high-definition 1080P video output, and D1/960H video recording
Resolution, frame rate and picture quality are adjustable
4 audio channels
Supports multi-channel playback simultaneously
Supports deleting and locking the recorded files one by one
Three search modes: time search, event search and image search
Supports remote playback in Network Client through LAN or internet
ALARM
Supports multi-channel alarm input and alarm output available
Supports schedule for Motion detection and Sensor alarm
Supports pre-alarm recording and post-alarm recording
Supports linked channels recording once motion or alarm triggered
Supports linked PTZ preset, auto cruise and track of the corresponding channel
Supports linked snap picture
Supports linked send alarm email
PTZ CONTROL
Supports various PTZ protocols
Supports 128 PTZ presets and 8 auto cruise tracks
Supports remote PTZ control through internet
Digital Video Recorder User Manual
3
SECURITY
Customize user privileges: log search, system setup, shut down, two way audio,
file management, disk management, remote login, live view, manual record,
playback, backup, PTZ control and remote live view
Supports 1 administrator and 63 users
Supports event log recording and checking
NETWORK
Supports TCP/IP, DHCP, PPPoE, DDNS protocol
Supports browser remote viewing
Supports setup client connection
Supports dual streams adjustable to fit your network bandwidth and environment
Supports picture snap and color adjustment in remote live
Supports remote time and event search, and channel playback with picture snap
Supports remote PTZ control with preset and auto cruise
Supports full menu remote setup, changing all the DVR parameters remotely
Supports mobile surveillance by iPhone, iPad and Android OS.
Supports CMS to manage multi devices remotely
Digital Video Recorder User Manual
4
Chapter 2 Installation Guide
2.1 Open-package Check
When you receive the DVR, please check the unit and the accessories:
First, please check whether there is any visible damage to the package appearance.
The protective materials used for the package of the DVR can protect most accidental
clashes during transportation.
Then, please open the box and get rid of the plastic protective materials. Check
whether there is any visible damage to the DVR appearance.
Front panel and rear panel
The key function specification in the front panel and the interface specification in the
rear panel are in the user manual.
Please check the product type in the front panel whether is accordant with the
product type you order.
Notice:
1. The label in the rear panel is very important for the after-sale services. Please
protect it carefully. When you contact us for after-sale service, please provide the
product type and serial number on the label.
2. Please disconnect the power before being connected to other devices. Don't hot
plug in/out.
2.2 Install Hard Drive
Notice: FOR REPAIR PURPOSES ONLY
1. This series support a SATA hard drive. Please use the hard drive
recommended by the manufacturers for security and safe field. Please refer to
Digital Video Recorder User Manual
5
“Appendix C Compatible Devices 2”.
2. Please calculate HDD capacity according to the recording setting. Please refer to
“Appendix B Calculate Recording Capacity”.
Step1: Disassemble the screw and open the top cover.
Step2: Connect the power and data cables. Place the HDD onto the bottom case as
Fig 2-1.
Step3: Mount the HDD.
Fig 0-1 Connect HDD
Notice:
1. For installation please connect the power and data cables first, and then the
screws to secure the HDD.
2. After the hard drive installation is complete format the HDD before using.
2.3 Front Panel Description
Note：The front panel descriptions are only for reference; please make the
object as the standard.
Digital Video Recorder User Manual
6
The descriptions of front panel interface are shown as follows:
Fig 0-2 Front Panel
Item
Name
Description
1
IR
Receive the signal of remote controller.
2
HDD
Hard disk status indicator.
When HDD is writing or reading, the light is white.
3
ACT
Network data indicator.
When exchanging data in the network, the light is
white.
4
LINK
Network connection indicator.
When the network connection is successful, the light
is white.
5
REC
Recording status indicator.
When recording, the light is white.
6
MENU
Enter menu mode.
7
ESC
Return to the previous menu or interface.
8
Direction and Enter
Direction keys: change direction to select items.
Enter key: confirm selection.
9
Power
Power on/off the DVR.
2.4 Rear Panel Description
Note: The rear panel descriptions are only for reference; please make the object
as the standard.
The descriptions of rear panel interface are shown as follows:
Digital Video Recorder User Manual
7
Fig 0-3 Rear Panel
Item
Name
Description
1
V-IN
Video signal input.
2
A-IN
Audio input: connect to pickup and other audio collecting
equipment.
3
A-OUT
Audio output: connect to sound box and other audio
output equipment.
4
V-OUT
CVBS video signal output: connect to monitor with BNC
interface.
5
HDMI port
HD 1080P video signal output: connect to high-definition
display.
6
LAN port
Network connector.
7
VGA port
VGA output: connect to monitor.
8
ALM IN
Alarm input: connect to external alarm sensor.
ALM OUT
Alarm output: connect to external alarm output device.
GND
Grounding
9
USB port
USB connector: connect to USB mouse, USB disk, mobile
HDD, etc.
10
RS-485
RS-485 communication port: connect to PTZ, keyboard,
etc.
11
DC 12V
Power input: DC 12V
Digital Video Recorder User Manual
8
2.5 Remote Control
The remote controller of this product series uses two AAA size batteries:
Step 1: Open the battery cover of the remote controller
Step 2: Place batteries. Please take care the poles (+ and -)
Step 3: Replace the battery cover
Notice: Frequently defect checking as following:
1. Check batteries poles
2. Check the remaining charge in the batteries
3. Check IR controller sensor is mask
If it still doesn't work, please change a new remote controller to try, or contact your
dealers.
The interface of remote controller is shown in Fig 2-4:
Fig 0-4 Remote Controller
Item
Name
Function
1
REC Button
To start the manual recording.
2
ADD Button
Input the number of DVR to control it.
3
POWER Button
To turn on/off the device.
Digital Video Recorder User Manual
9
Item
Name
Function
4
Digital Button
Code input/number input/channel switch.
5
EXIT Button
Return to the previous interface.
6
BACKUP Button
To enter the backup mode.
7
SEARCH Button
To enter the video playback interface.
8
SEQ Button
To enter the auto dwell mode.
9
E-ZOOM Button
To electronic amplify the single channel.
10
MENU Button
To enter the sub menu.
11
Multi Screen
Button
To choose multi-screen display mode.
12
Single Screen
Button
To choose single -screen display mode.
13
Direction and
Enter Button
Direction Button: move cursor to select items.
Enter Button: confirm the selection.
14
AUDIO Button
To enter the audio adjustment interface.
15
Fn Button
Reserved function keys.
16
SNAP Button
To snap the live pictures.
17
Playback Control
Button
To control playback, pause/play, single-frame play,
rewind, stop, fast forward.
18
PTZ Button
To enter the PTZ control interface.
Operation processes with remote controller to control multi-DVR
The default device ID of the DVR is 0. When using a remote controller to control
single DVR, it’s not necessary to reset the device ID, user can do operation directly;
when using a remote controller to control multiple DVR, please refer to below steps:
Step 1: Activate remote controller to control DVR: enable DVR, turn the IR sensor of
the remote controller to the IR receiver that on the front panel, press “add” key and
then input device ID (Range from: 1-65535) with other digital keys, after that, press
ENTER button to confirm.
Step 2: User can check the device ID by enter into System configurationBasic
configurationdevice ID. User also can set other DVRs with the same device ID. For
more convenient to operate, we don’t recommend user to set the device ID too long.
Digital Video Recorder User Manual
10
Step 3: Cancel controller to control DVR: without any action on keys about half a
minute later, the DVR will not be controlled by remote controller.
2.6 Control with Mouse
2.6.1 Connect Mouse
It supports USB mouse through the USB ports.
Note: If mouse is not detected or doesn't work, try another mouse.
2.6.2 Use Mouse
In live: Double-click left button on one camera to be full screen display. Double-click
again to return to the previous screen display.
Click right button to show the control menu at the bottom right of cursor. Here you will
find all the controls and setup options. Click right mouse again to hide the control
menu.
In setup: Click left button to enter.
Click right button to cancel setup, or
return to the previous.
If want to input the value, move
cursor to the blank and click. An input
window will appear as Fig2-5. It
supports digitals, letters and symbols
input.
Fig 2-5 Input Window
It supports mouse drag, I.e. set motion detection area: click customized, hold left
button and drag to set motion detection area.
In playback: Click left button to choose the options. Click right button to return to live
mode.
In backup: Click left button to choose the options. Click right button to return to
previous picture.
Digital Video Recorder User Manual
2
In PTZ control: Click left button to choose the buttons to control the PTZ. Click right
button to return to live mode.
Note: Mouse is the default tool in all the operation below unless otherwise noted.
Chapter 3 Basic Functions
3.1 Power On/Off
3.1.1 Power On
Before you power on the unit, please verify all the connections.
Step 1: Connect with the source power; switch on the power button near the power
port in the rear panel.
Step 2: The device will be loaded, and the power indicator will display red.
Step 3: A WIZARD window will pop-up and display information about device name,
language, date and time, network, record, etc.
User can setup here and refer to the setup steps from the corresponding chapters. If
users don’t want to setup Wizard, please click Exit button and enter into the login
interface.
Notice: This series can only support the menu on VGA monitor, BNC monitor
or HDMI monitor at one time. After the device is power on, if there is live display
without the menu, please check the other outputs for the menu display, or press
Exit /ESC button (press and hold) to switch the output among BNC, HDMI and VGA.
3.1.2 Power Off
User can power off the device by using the remote control, keyboard or mouse
Using the remote control:
Digital Video Recorder User Manual
3
Step 1: press Power button of remote controller to pop up Shut Down window.
Step 2: click OK, the unit will power off after a while.
Step 3: disconnect the power.
By mouse:
Step 1: enter into Main Menu and select Shut Down button to pop up Shut Down
window.
Step 2: Click OK, the unit will power off after a while.
Step 3: Disconnect the power.
3.2 Login
User can login and logout the DVR system. User cannot do any other operations
except changing the multi-screen display once logout.
Fig 3-1 Login
Notice:
The default user name and password is “admin” and blank.
The operation steps for changing the password, add or delete user: please
refer to 4.8 User Management Configuration for more details.
User permissions can be customized. Only administrators can customize other
user's permissions. The user name and password can consist of numbers, letters
or symbols (1~32 characters).
Digital Video Recorder User Manual
4
3.3 Live Preview
Fig 3-2 live preview interface
Symbol
Meaning
Green
Manual record
Yellow
Motion detection record
Red
Alarm record
Blue
Schedule record
3.4 Live Playback
Click of control menu to playback the recordings, refer to Fig3-3.
User can click the control buttons on the screen to change operation.
Digital Video Recorder User Manual
5
Fig 3-3 live playback
Digital Video Recorder User Manual
6
Chapter 4 Main Menu Setup Guide
4.1 Control Menu
Right click to display the control menu, refer to Fig 4-1:
Fig 4-1 control menu
Single: Click this button to pop up the single channel selection box.
Multi: Click this button to pop up the multi-channel selection box. The range of options
synchronizes with configured device. Images can be dragged to any place to display in the
live interface.
Dwell: Display the preview pictures in the dwell mode. The range of options synchronizes
with configured device. Only takes effect when user has selected channel grouping and
preview mode cannot display all channels.
Color: Click this button, select channel and adjust the brightness, hue, saturation and
contrast of live pictures. Click “Default” button to resort default setting; click “Save” button
to save the setting.
E-Zoom: Zoom in to the video of channel (optional), double click the left button or click the
right button to return to the previous interface.
Audio: Open or close the live sound of channel (optional), and adjust the volume.
PTZ: Control PTZ rotational position and speed; zoom, focus and iris are adjustable; run
the preset, cruise and auto scan.
Snap: Click this button to snap current image.
Digital Video Recorder User Manual
7
Record: Click this button to record current video.
Playback: Click this button to playback the recorded files; click the relevant buttons on the
screen to control playback.
Main Menu: Click button to pop up the window shown in Fig 4-2; then
click Setup button to pop up the window shown in Fig 4-3.
Fig 4-2 main menu
Fig 4-3 setup menu
Press MENU button on the front panel or operate with remote controller also can
display the main menu.
SETUP configuration includes nine submenus: basic, live, record, schedule, alarm,
network, users, P.T.Z and advanced.
Digital Video Recorder User Manual
8
4.2 Basic Configuration
Basic configuration includes three submenus: system date & time and DST.
4.2.1 System
Enter into Main MenuSetupBasicSystem; refer to Fig 4-4:
User can setup the device name, device ID, video format, max online users, video
output, language, etc.
Fig 4-4 basic configuration-system
Device Name/ID: The name/ID of device. It may display on the client end or CMS that
help user to recognize the device remotely. ID range: [0~65535].
Video Format: Two modes: PAL and NTSC.
Note: Change the video format, system will reboot.
Password Check: Enable this option. User needs to enter the user name and
password for authentication, and do operations with the relevant right.
Show System Time: Enable this option to display time in live display.
Max Online Uses: Set the maximum number of network connected users.
Video Output: The resolution and menu output of live display, range from: CVBS,
VGA800*600, VGA1024*768, VGA1280*1024 and HDMI.
Digital Video Recorder User Manual
9
Note: When switching between BNC, VGA and HDMI this will change the menu
output mode, please connect to the corresponding device for control.
Language: Select the menu language; built-in multi-languages.
Note: Change the language or video output, the device needs to login again.
Screensaver[S]: Set the screensaver interval time. If there is no any operation within
the period specified, the device will automatically logout and return to login interface.
Startup Wizard: Enable this option to display a wizard window when powered up for
the next time.
Click “Default” button to restore the default setting; click “Apply” button to save the
setting; click “Exit” button to exit current interface.
4.2.2 Date & Time
Enter into Main MenuSetupBasicDate & Time; refer to Fig 4-5:
User can set the date format, time format and time zone; enable “Sync Time with NTP
Server” and click “Update Now” button to synchronize device time with NTP server
(optional); or manually set the device time and click “Save Now” button.
Fig 4-5 basic configuration-date & time
Note: Time zone is GMT by default; please select your local time zone in the
drop-down box, such as GMT+8:00.
Click “Default” button to restore the default setting; click “Apply” button to save the
setting; click “Exit” button to exit current menu.
Digital Video Recorder User Manual
10
4.2.3 DST
Enter into Main MenuSetupBasicDST; refer to Fig 4-6:
Enable “Daylight Saving Time”, and set time offset, mode, start & end time.
Click “Default” button to restore the default setting; click “Apply” button to save the
setting; click “Exit” button to exit current interface.
Fig 4-6 basic configuration-DST
4.3 Live Configuration
Live configuration includes three submenus: live, main monitor and mask.
4.3.1 Live
Enter into Main MenuSetupLiveLive; refer to Fig 4-7:
Camera Name: Click camera name to pop up a soft keyboard, click Shift button to
switch the input state, user can self-define the channel name.
Color: Click “Setting” button to display a window as Fig 4-8. User can adjust the
brightness, hue, saturation and contrast of channel video, click “default” button to
resort default setting; click “OK” button to save the setting.
Digital Video Recorder User Manual
11
All: Select “all” and then do relevant setup, user can set all channels with same
parameters.
Live Rec Status: In upper left corner of the screen will appear a status icon when
manual or triggered recording is active.
Click “Default” button to restore the default setting; click “Apply” button to save the
setting; click “Exit” button to exit current interface.
Fig 4-7 live configuration-live Fig 4-8 live-color adjustment
4.3.2 Main Monitor
Enter into Main MenuSetupLiveMain Monitor; refer to Fig 4-9:
Select the display mode (synchronize with configured device); set the channel
combination of current picture group, click or button to set the previous/
latter channel groups of dwell picture; set dwell time: the time interval for a certain
dwell picture display switching to next dwell picture display.
Digital Video Recorder User Manual
12
Fig 4-9 live configuration-main monitor
Click “Default” button to restore the default setting; click “Apply” button to save the
setting; click “Exit” button to exit current menu.
4.3.3 Mask
Enter into Main MenuSetupLiveMask, user can set private mask area on the
live image, refer to Fig 4-10:
Fig 4-10 live configuration-mask
Set mask area: Click “Setting” button, then click and drag cursor to set the privacy
Digital Video Recorder User Manual
13
area of video image. An image can be entirely or partially masked, it supports 4 areas
maximum. Click right mouse to return to the previous interface. Refer to Fig 4-10(a)
and Fig 4-10(b):
Delete mask area: Select a certain mask area, double click left mouse to delete that
area, click right mouse to return to previous menu.
Click “Default” button to restore the default setting; click “Apply” button to save the
setting; click “Exit” button to exit current menu.
Fig 4-10(a) Setup mask area Fig 4-10(b) live image mask area
4.4 Record Configuration
Record configuration includes six submenus: enable, record bitrate, time, stamp
recycle record and snap.
4.4.1 Enable
Enter into Main MenuSetuprecordenable; refer to Fig 4-11:
Select “Record” and “Audio” to open the record and audio of every channel.
Select “all” to set all channels with same parameters.
Click “Default” button to restore the default setting; click “Apply” button to save the
setting; click “Exit” button to exit current interface.
Digital Video Recorder User Manual
14
Fig 4-11 record configuration-enable
4.4.2 Record Bitrate
Enter into Main MenuSetuprecordrecord bitrate; refer to Fig 4-12:
Fig 4-12 record configuration-record bitrate
Set the resolution, frame rate, encode, quality and max bitrate.
Select “all” and then do relevant setup, user can set all channels with same
parameters.
Click “Default” button to restore the default setting; click “Apply” button to save the
Digital Video Recorder User Manual
15
setting; click “Exit” button to exit current menu.
Note: If frame rate surpasses the maximum resources of device, the value will
be adjusted automatically.
Parameter
Meaning
Resolution
The range of options: synchronize with configured device, such as CIF
Fps
Range from 1~30（NTSC）or 1~25(PAL)
(Resolution and frame rate are determined by the parameter
specifications of specific type)
Encode
Two options: VBR and CBR
Quality
The higher the grade is, the clearer the recorded image is. Six grades:
lowest, lower, low, medium, higher and highest.
Max Bitrate
The range of options: synchronize with configured device, such as
256~2048kbps
4.4.3 Time
Enter into Main MenuSetupRecordTime; refer to Fig 4-13:
Fig 4-13 record configuration-time
Pre-alarm Record Time: Alarm signal needs a little time to process and trigger
recording, it may not record some important information before alarm activation. This
function can save pre-recording and improve monitoring reliability. Set the record time
before event happen (motion detection or sensor alarm).
