GENERAL SAFETY RULES
GB
MODEL NO. AT203A16, AT203A22, AT203A24
SAFETY
OPERATION
MAINTENANCE
Electric Hedge Trimmer
USER MANUAL
DOUBLE INSULATED
Meaning of symbols marked on the product
Read the user manual before using the machine
Wear safety goggles to protect your eyes
Wear ear protector to protect against noise
Wear gloves to protect your hands
Wear safety boots to protect against electric shock
Do not expose to rain
WARNING!
When using electric tools, basic safety precautions, including the following, should always be followed to
reduce the risk of fire, electric shock and personal injury.
Read all these instructions before operating this product and save these instructions.
• Keep work area clean
Cluttered areas and benches invite injuries.
• Consider work area environment
Do not expose power tools to rain. Do not use power
tools in damp or wet locations. Keep work area well
lit. Do not use power tools where there is risk to
cause fire or explosion.
• Keep children away
Do not let visitors touch the tool or extension cord. All
visitors should be kept away from area.
• Store idle tools
When not in use, tools should be stored in a dry, high
or locked up place, out of reach of children.
• Do not force the tool
It will do the job better more safely at the rate for
which it was intended.
• Use the right tool
Do not force small tools or attachments to do the job
of a heavy duty tool. Do not use tools for purposes
not intended.
• Dress properly
Do not wear loose clothing or jewellery, they can be
caught in moving parts. Rubber gloves and non-skid
footwear are recommended when working outdoors.
Wear protecting hair covering to contain long hair.
• Use safety glasses
Also use face or dust mask if the cutting operation is
dusty.
• Do not abuse the cord
Never carry the tool by the cord or yank it to disconnect it from the socket. Keep the cord away from
heat, oil and sharp edges.
• Do not overreach
Keep proper footing and balance at all times.
• Maintain tools with care
Keep cutting tools sharp and clean for better and
safer performance. Follow instructions for lubrication
and changing accessories. Inspect tool cord periodically and if damaged have it repaired by an authorized service facility. Inspect extension cords periodi-
cally and replace, if damaged. Keep handles dry,
clean and free from oil and grease.
• Disconnect tools
When not in use, before servicing and when changing accessories such as blades, bits and cutters.
• Avoid unintentional starting
Do not carry a plugged-in tool with a finger on the
switch. Ensure switch is off when plugging in.
• Use outdoor extension leads
When tool is used outdoors, use only extension cords
intended for outdoor use.
• Stay alert
Watch what you are doing. Use common sense. Do
not operate tool when you are tired.
• Check damaged parts
Before further use of the tool, a guard or other part
that is damaged should be carefully checked to
determine that it will operate properly and perform its
intended function. Check for alignment of moving
parts, free running of moving parts, breakage of
parts, mounting and any other conditions that may
affect its operation. A guard or other part that is damaged should be properly repaired or replaced by an
authorized service centre unless otherwise indicated
in this instruction manual. Have defective switches
replaced by an authorized service facility. Do not use
the tool if the switch does not turn it on and off.
• Warning!
The use of any accessory or attachment, other than
those recommended in this instruction manual, may
present a risk of personal injury.
• Have your tool repaired by a qualified person
This electric tool is in accordance with the relevant
safety requirements. Repairs should only be carried
out by qualified persons using original spare parts,
otherwise this may result in considerable danger to
the user.
• Plug and Socket
Please choose the right type of plug and socket by
international codex.
Wear dust mask to protect against dust
Remove plug from the mains immediately if cable is damaged or cut
6096-203A01
3
GB GB
SPECIFICATIONS AT203A166 AT203A22 AT203A24
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .500Watt . . . . . . . . . . . . . . .600Watt . . . . . . . . . . . . . . .650Watt
No Load cutting rate . . . . . . . . . . . . . . . . . . .3,100 spm . . . . . . . . . . . . . .3,100 spm . . . . . . . . . . . . .3,100 spm
Blade Length . . . . . . . . . . . . . . . . . . . . . . . . .16” (40cm) . . . . . . . . . . . . .22” (55cm) . . . . . . . . . . . . .24” (60cm)
Cutting Action . . . . . . . . . . . . . . . . . . . . . . . .Double . . . . . . . . . . . . . . . .Double . . . . . . . . . . . . . . . .Double
Max. Cutting Capacity up to : . . . . . . . . . . . .12mm . . . . . . . . . . . . . . . . .12mm . . . . . . . . . . . . . . . .12mm
Net Weight . . . . . . . . . . . . . . . . . . . . . . . . . .2.05 kg . . . . . . . . . . . . . . . .2.4 kg . . . . . . . . . . . . . . . .2.5 kg
1. The Hedge Trimmer must not be used by anyone
under the age of 16.
2.
Keep children, other people and pets away from the
trimmer.
3.
Always dress properly. Don’t wear loose clothing or
jewellery; they can be caught in moving parts. Use
of rubber gloves and substantial footwear is recommended when working outdoors. Wear protective
hair covering to contain long hair.
4. Use face or dust mask if operation is dusty.
5. Do not use the trimmer if the cutting device is not
secured properly or is damaged.
6. Before starting the trimmer, make sure that the
cutting blade is not touching stones or debris.
7. When the trimmer is in operation, keep the cutting
section away from all parts of the body.
8. Do not cut against hard objects. This could cause
injury or damage the trimmer.
9. Only cut during broad daylight or with corresponding
artificial light.
10. Don’t abuse cord, never carry hedge trimmer by
cord or yank it to disconnect from receptacle. Keep
cord from heat, oil, and sharp edges.
11. When the trimmer is not in use, store it in a dry place
so that the blade is not exposed and out of the reach
of children.
12. The main voltage must correspond to the one
marked on the technical data plate. Do not use other
sources of power.
13. Never use the trimmer when it is raining. Try to prevent it from getting wet or being exposed to humidity. Do not leave it outside overnight. Do not cut
damp or wet grass.
14. The power supply cable should be checked
regularly. Before each use, make sure cable is not
damaged or worn. If the cable is not in good condition, do not use the trimmer. Take it to an authorized
service center for proper repair.
15.
Only use an extension cord which is suitable for outdoor work. Keep it away from the cutting area,
damp, wet or oily surfaces, or sharp edges. Keep
away from heat and fuels.
16. Avoid unintentional starting. Don’t carry plugged in
hedge trimmer with fingers on both switches. Be
sure switch is off when plugging in.
17. Do not attempt to remove cut material or hold material to be cut when blades are moving. Make sure
trimmer switch is off when clearing jammed material
from blades. Do not grasp the exposed cutting
blades or cutting edges when picking up or holding
the hedge trimmer.
CAUTION: Blades coast after turn off.
18. Don’t force hedge trimmer, it will do the job better
and with less likelihood of risk of injury at the rate for
which it was designed.
19. Stay alert, watch what you are doing. Use common
sense. Do not operate hedge trimmer when you are
tired.
20. Maintain hedge trimmer with care, keep cutting
blades sharp and clean for best performance and to
reduce the risk of injury. Inspect extension cord periodically and replace if damaged. Keep handles dry,
clean and free from oil and grease.
21.
If the supply cord is damaged, it must be replaced by
the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
HEDGE TRIMMER SAFETY RULES
GENERAL IDENTIFICATION
A
A Rear Handle
B Trigger Switch
C
Hand Safety Switch
D Front Handle
E Safety Guard
F Blade
G
Cord Retainer
B
C
D
E
F
G
• INSTALLING SAFETY
GUARD (FIG. 1)
1. Your Hedge Trimmer
comes fully assembled
except for the safety guard.
2. To assemble safety guard,
align holes in safety guard
(A) to holes in hedge trimmer and fix with screws (B)
provided.
• SWITCH (FIG. 2)
For your safety, this hedge trimmer is designed with a two
hand safety switch. If you only squeeze one trigger, the
trimmer will not be actuated. To turn the trimmer ON,
squeeze both triggers at the same time. To turn the trimmer OFF, simply release either trigger.
• POWER CORD
To prevent the power cord (A) from disconnecting from
the hedge trimmer, loop the cord around the recessed
hook and pull gently to tighten. (See Fig. 3)
• TRIMMING INSTRUCTIONS
1. EXTENSION CORD. Always keep extension cord
behind trimmer and away from the trimming
operation. Never drape it over a hedge being
trimmed. If you cut or damage the cord, unplug it at
the electrical outlet immediately, before inspecting
or repairing cord.
2. WORKING POSITION. Maintain proper footing and
balance and do not overreach. Wear safety
goggles, non-skid footwear and rubber gloves when
trimming. Hold the tool firmly in both hands and turn
the tool ON. Always hold the trimmer, as shown in
the illustrations, with one hand on the body handle
and one hand on the front handle. Never hold the
tool by the blade guard.
3. TRIMMING NEW GROWTH. A wide, sweeping
motion, feeding the blade teeth through the twigs is
most effective. A slight downward tilt of the blade, in
the direction of motion gives the best cutting. (Fig. 4)
4. LEVEL HEDGES. To obtain exceptionally level
hedges, a piece of string can be stretched along the
length of the hedge as a guide.
5. SIDE-TRIMMING HEDGES. Hold the trimmer as
shown and begin at the bottom and sweep up. (Fig. 5)
ASSEMBLY
Fig. 1
A
B
OPERATION
CAUTION: Always ensure all handles and
guards are fitted when using the tool.
Fig. 2
Fig. 3
Hand Safety
Switch
Trigger
TRIMMING INSTRUCTIONS
Fig. 4
CAUTION: Do not use the trimmer for cutting
stems greater than 12mm. Use the trimmer
only for cutting normal shrubbery found around
houses and buildings.
Fig. 6
A
2
4
GB
• BLADE LUBRICATION
For easier operation and
longer blade life, lubricate the
garden trimmer blade before
and after each use. Apply light
machine oil along the edge of
the blade bar. (Fig. 6)
Your trimmer should be stopped, disconnected and oiled
occasionally during use.
1. The cutting blades are made from high quality, hardened steel and with normal usage, they will not require
resharpening. However, if you accidentally hit a wire
fence, stones, glass or other hard objects, you may put
a nick in the blade. There is no need to remove this nick
as long as it does not interfere with the movement of
the blade. If it does interfere, unplug unit and use a fine
toothed file or sharpening stone to remove the nick.
2. If you drop the trimmer, carefully inspect it for damage. If the blade is bent, housing cracked, or handles
broken or if you see any other condition that may affect
the trimmer’s operation contact an authorized service
center for repairs before putting it back into use.
3. Fertilizers and other garden chemicals contain agents
which greatly accelerate the corrosion of metals. Do
not store the tool on or adjacent to fertilizers or chemicals.
4. With the unit unplugged, use only mild soap and a
damp cloth to clean the tool. Never let any liquid get
inside the tool; never immerse any part of the tool into
a liquid.
SERVICING DOUBLE-INSULATED APPLIANCE
In this double-insulated appliance, two systems of insulation are provided instead of grounding. No grounding
means is provided on a double-insulated appliance, nor
should a means for grounding be added to the appliance.
There are no owner serviceable parts insidel. A doubleinsulated appliance is marked with the words, “DOUBLE
INSULATION” or “DOUBLE INSULATED”. The symbol
(square within a square) may also be marked on the appliance.
Any service must only be carried out by a qualified technician at an authorized service centre.
1. Place switch in “OFF” position and unplug the power
supply before the appliance is serviced, cleaned or
maintenance is performed.
2. Keep air intake clean and air vents free of debris to
avoid overheating the motor.
3. Clean with a damp sponge and mild soap. Do not
squirt with water, hose with water or other liquids.
4. No lubrication is necessary as the motor is equipped
with lifetime lubricated bearings.
5.
If the blower does not operate, turn switch to “OFF”
position and disconnect extension from power supply first, then from blower. Check power supply for
blown fuses or tripped circuit breakers. Do not
attempt to repair it yourself. There are no serviceable
parts inside.
MAINTENANCE
WARNING:
Before lubricating, be sure your
garden trimmer is disconnected from the power
supply. Failure to do so can result in accidental
starting, causing serious personal injury.
Fig. 6
IMPORTANT: To assure product SAFETY
and RELIABILITY, repairs, maintenance and
adjustments should be performed by an
authorized service center using identical
replacement parts.
Loading...
