Tallygenicom 9035 Features & Specifications

Mono

9035 Monochrome Laser Printer

Excellent Speed, Robust Duty Cycle.

The 9035 prints at speeds up to 35 pages per minute with a first page out time of less than 9 seconds. In
addition to the rapid printing speeds, the 9035 is capable of handling duty cycles of up to 150,000 pages
per month. This kind of performance allows the 9035 to be relied upon in even the most demanding printing
environments.

Productivity Enhancing Controller Architecture.

The 9035 incorporates the Intelliprint controller architecture – a proprietary printing control technology
developed by TallyGenicom to provide users with an unmatched fusion of performance and productivity
enhancement. Features such as password-protected printing, saved job library and job accounting set the
9035 apart from the competition.

Intelliprint controller architecture

In addition to the productivity enhancements offered by the Intelliprint controller architecture, the 9035 also
boasts a class-leading 405 MHz processor, Adobe PostScript 3 and PCL6 and PCL5e functionality.

Unmatched Fusion of Performance and Productivity.

Available Configuration:

9035N - Ethernet, Parallel, USB, PS3
9035ND - Ethernet, Parallel, USB, PS3, with duplexer
9035NDT - Ethernet, Parallel, USB, PS3, with duplexer and extra tray
9035M - MICR, Ethernet, Parallel, USB, PS3
9035ME - MICR-extended security laser printer, e-net, PS3

Less than 9 seconds first page output time
1200 x 1200 dpi at up to 35 ppm
Powerful 405 MHz RISC processor processor
Intellifilter for compatibility with legacy print data
streams
Intelliprint controller
Adobe PostScript 3, PCL6, PCL5e
Optional duplex printing
Duty cycle of 150,000 images per month
One year on-site warranty

Features & Specifications

Print Speed 35 ppm

Print Method Electro-photographic semiconductor laser with Intelliprint Controller

Processor MIPS R5000 405 MHz

Resolution 1200 x 1200 dpi

Time To 1st Page Less than 9 Seconds

Memory 64MB expandable to 320MB (2 slots); Optional 20GB (or higher) hard disk

Standard Connectivity 10/100Base-T Ethernet; TCP/IP, EtherTalk, Bonjour; IEEE 1284 parallel; Hi-Speed USB 2.0 480 Mb/s auto

interface switching

Standard Emulation PostScript 3; PCL6 with PJL, PCL5e

Print Monitor SNMP, Printer MIB, e-mail status, and Web-based status and control, TGNetAdmin

Fonts 136 Adobe PostScript fonts; 86 Type 1 PCL

Consumables Single element toner cartridge with 17,000 pages (at 5%). New printer comes with 10,000 letter/A4 yield

capacity.

Maintenance 200K Letter/A4

STD Paper Handling 550-sheet tray; 150-sheet tray

Opt'l Paper Handling 550-sheet feeder tray (up to 2 additional)

Duplexing Optional

Paper Type Sheet paper, transparencies, bond, labels, envelopes, and thick media

Paper Weight 16 to 58 lbs (60 to 216 g/m²) in simplex and duplex modes

Paper Size Letter, executive, legal, folio, A4, A5, A6, B5, statement; Envelopes: Com10, Monarch, DL, C5; Custom sizes:

3.88 to 8.50 W by 5.83 to 14.00 L (tray 1 and 2 only); Officio (8.5" x 13.38" - supported as a custom size in
tray #1 or #2)

Paper Output 500-sheet face-down top output; Optional cassette: 500-sheet offset catch tray

Physical Weight 45 lbs. (20.6 kg)

PhysicalSize 15.9" x 16.6" x 18.3" (404x 422 x 465 mm)

Power Voltage 100/120-127 VAC, 50/60 Hz; Current: 7 amps

Power Consumption 5.38 kWh/Week or less for ENERGY STAR® qualified models

Compliance ENERGY STAR® qualified, Ozone-free; UL950, FCC part 15 Class B, ICES 003, CISPR22 Class B, FDA CDRH,

cUL, CE, GS, IEC 825,GOST (Russia), SABS (S. Africa), C-Tick (Australia), RoHS, Microsoft, ISO-compliant,
Meditech Approved

Workload Up to 150,000 pages per month

Forms Software Intellifilter; Optional: Intellipress

Drivers Vista, XP, 2003, 95, 98, 2000, Me, NT 4.0; Mac OSX, Adobe PostScript and PCL drivers included; Unix and

Linux compatibility

Temperature Operating: 41º F - 95º F (5° to 35° C)

Humidity Operating: 15%-85% Non-Condensing

Acoustic Printing - 53.6 dB(A); Standby - 27 dB(A)

Warranty One year on-site

Option 1 Add-on tray - 550 sheet feeder; duplexer; offset catch tray

Option 2 128MB DIMM; 256MB DIMM

Option 3 Intelliprint Barcode Module; Intelliprint Barcode/Real Time Clock Module; Intelliprint Real Time Clock

Options 4 Hard disk

Option 5 RS232 interface

Note Exceeding the monthly duty cycle will not void the warranty if TallyGenicom consumables and maintenance

kits are used. Toner saver mode provides up to 40% savings.
