Digital Wireless Series Product
User’s Guide
This User’s Guide is applicable to the following products:
#CW1103 - Digital Wireless Camera
#CW1105 - Digital Wireless Transmitter
#CW1104 - Quad Digital Wireless DVR
#CW1106 - Quad Digital Wireless 7” DVR
Ver.1.1
121029
Table of contents
Package contains.......................................................................................................................3
User’s Interfaces ........................................................................................................................ 4
Get unit work quickly..................................................................................................................8
Useful Operation Advices.........................................................................................................10
Recording Duration .................................................................................................................. 10
IR Remote Controller Instruction..............................................................................................11
OSD Introduction......................................................................................................................12
Software & Hardware Specifications on PC, iPhone, iPad.......................................................12
ASP4 (PC Player) User’s Interface...........................................................................................15
Remote View Steps for CW1104 / CW1106.............................................................................17
Remote View Steps for iPhone / iPad ...................................................................................... 20
Technical Specification.............................................................................................................23
Annex1 (Compatible Router list) ..............................................................................................25
Annex2 (Incompatible Router list) ....................................................................................................... 25
- 2 -
Package contains
CW1103 CW1105 CW1104 CW1106
Main Unit x1
Power Adapter x 1
Main Unit x1
Power Adapter x 1
Main Unit x1
Remote Controller x 1
Main Unit x1
Remote Controller x 1
Power Adapter x 1
AV Output Cable x 1
USB Cable x 1
Power Adapter x 1
AV Output Cable x 1
USB Cable x 1
2GB SD Card x 1
3
(Optional)
2GB SD Card x 1
(Optional)
User’s Interfaces
CW1103
4
CW1105
5
CW1104
6
CW1106
7
Get unit work quickly
1. The Power LED (red) will be on when the Transmitter/Receiver is turned on.
2. Below transmitters and receivers are fully inter-operable.
3. How to Pair Up:
3.1 Select a channel on the Receiver (use remoter controller), long press the pairing button till
the channel LED (blue) is flashing.
8
3.2 Press the pairing button on the transmitter.
3.3 After pairing is completed and successful, the Channel LED (blue) on Receiver will be
flashing rapidly, and the image will show on the Monitor.
A Receiver is able to be paired up to 4 different Transmitters, and to receive image from 4
Transmitters simultaneously.
9
Operation Advices
1. Once #CW1104 / #CW1106 is powered on and with SD card inserted, recording is factory
preset at motion detection.
It can be reset as continuous recording, having schedule through OSD menu.
For panic recording, please press on the remote controller.
2. Press on the remote controller to get into playback menu.
3. For #CW1106- 7’’ DVR, press Hotkey + on remote controller to turn off the
LED indication; press + to turn on.
4. Press + on remote controller to turn off the LCD monitor, press any key to
turn on.
5. There is 10 seconds timer count down when start recording, during count down, no remote
control command would be accepted.
6. Receiver USB plug into PC, the video will stream to PC and can be viewed / recorded with
bundled ASP4 software on PC directly. After streaming the video to PC, the recording setup
on receiver will be no function.
The PC Operation System required Windows XP (SP2) or above.
Hardware Environment: CPU P4 2.0G / RAM 2GB or above.
7. The settings on ASP4 can not be applied on Receiver DVR (CW1104 or CW1106), and vice
versa.
8. Remote View function is supported by bundled ASP4 software; please refer to “Remote
View Quick Guide for CW1104 / CW1106” section. (Page 15)
Recording Duration
Single Channel (full screen) with Audio & Continuous Recording
1GB 4GB 8GB 16GB 32GB
3.95 hr 15.84 hr 31.58 hr 63.26 hr 126.56 hr
Quad-View / 4 Channels with 1CH Audio & Continuous Recording
1GB 4GB 8GB 16GB 32GB
2.91 hr 11.65 hr 23.22 hr 46.56 hr 93.31 hr
10
IR Remote Controller Instruction
”
Button Function Description
Power
Playback
Panic Record
QUAD Quad display mode.
SEQUENCE Auto sequence display
MENU Menu
Press the button to get to
the playback menu.
During playback, press
the button to pause, press
again to continue.
Start to record manually.
Press again to cancel
recording mode.
mode
Button Function Description
Numbers Numbers 5 to 0, English
characters, and
punctuation marks “，_．
Clear
Return Return to last page
Confirm Enter
Up / Down /
CH1 Channel 1 & Number 1 &
punctuation marks
“- / +”
CH2 Channel 2 & Number 2 &
“A B C”
CH3 Channel 3 & Number 3 &
“ D E F”
CH4 Channel 4 & Number 4 &
“G H I”
11
Right / Left
Mute Key sound off
Lock Key Lock
OSD Introduction
1.
Press to enter MAIN MENU
2.
Press to select item
3.
Press to enter the selected item
4.
Press to get back to live view
5.
Recording Setup
Peripheral Setup
System Setup
Brightness (CW1106 only)
Recording Setup
Press to get back to last page
OSD MENU Description
- Schedule Setup
- Setup Continuous recording or Motion Detection
recording Mode in a week.
(Default Setting: Motion Detection recording)
- Audio Record from
- CH 1 (Default setting)
- CH 2
- CH 3
- CH 4
- SD Information
- Total: GB
- Remain: GB
- Fullstop or Overwrite (Default setting: Overwrite)
Press to change the recording mode; exit this
option to save the schedule.
To choose the audio source in Quad View during
Recording /Live view. To adjust the speaker volume,
press or on the remote controller.
To choose SD method with Fullstop or Overwrite, press
or on the remote controller.
- Format SD Card
- OK
- Close
12
Peripheral Setup
OSD MENU Description
- Buzzer Setup
- Video Loss
- ON
- OFF
- Motion Detect
- ON
- OFF
- Buzzer Duration
- 02 ~ 10 sec
- Display Setup (TV-out only)
- Left Pos
- Right Pos
- Up Pos
- Down Pos
Press or to change Buzzer ON / OFF.
Default setting is ON.
To setup the Buzzer beep duration time.
Default setting: 2 seconds.
To adjust the display position for TV Out; press
to move.
- Date/Time Setup
- Display Format
- YYYY-MM-DD
- MM-DD-YYYY
- DD-MM-YYYY
- Time Format
- 24 H
- 12 H
-YEAR
- MONTH
- DAY
- HOUR
- MINUTE
- SECOND
System Setup
OSD MENU Description
Press to select item, and press to
change the format.
Press Number keys to setup the Date/Time directly.
- AV Output (CW1106 only)
- Video Out
- LCD
- TV-out NTSC
- TV-out PAL
13
Press to select item, and press to
change the option. Press to confirm and exit the
menu.
- Audio Out
- Speaker Out (Default setting)
- Line Out
- Channel Sequence Time:
- 05 ~ 30 sec.
- Factory Default:
- Yes
- Cancel
- Firmware Version
- Vxxxx.xx
OSD MENU Description
Level 6
Default setting: 5 seconds.
Brightness Setup
(CW1106 Only)
To adjust the Brightness for LCD monitor; Level 6 is the
Level 5
Level 4
Level 3
Level 2
Level 1
brightest. Press to select, and press
to confirm.
14
Software & Hardware Specifications on PC, iPhone, iPad
To use the remote viewing on PC, we highly recommend you to have the following software and
hardware specifications on your PC,
Microsoft® Windows XP, or Windows 7 (.NET Framework 3.5 higher)
Internet Explorer® 8 or higher.
CPU: 2.0GHz or higher (only support x86 and x64)
Memory: 1GB (up)
Display card: Independent display card and support DirectX 9.0 or higher.
To use the remote viewing on iPhone / iPad, we highly recommend you to have the following
software and hardware with your iPhone / iPad,
iPhone 3 or higher
iPad
iOS 4.3 or higher
15
ASP4 (PC Player
) User’s Interface
System Setting
Open file, to search the
recording files
Snapshot, to save JPG
CH2 Full screen display
CH4 Full screen display
Manual recording during
live view & backup files
during playback
Recording Mode
Network ON / OFF
(for remote view)
CH1 Full screen display
CH3 Full screen display
Quad-View display
Backwards
16
Pause
Stop
Forwards
Play
Remote Viewing Steps for CW1104 / CW1106
Easy 3 steps to see the Live View remotely:
Step 1. Install the bundled software ASP4 on PC, and highly recommend to change the log-in
User Name / Password (default User Name & Password: Admin / Admin ) in “Network
Setting”. The “ID” means receiver ID number, it would automatically show on the network
setting when you plug-in your USB cable.
** Click OK to complete the setting and protect the data security.
17
Step 2. Finished the network setting, the Remote viewing web link and the surrounding view will
display on the PC ASP4 software.
**
http://www.ez-see.net/10001901
Server domain name
Receiver ID number (8 digit), each Receiver device has its
own ID number. User have to key in
www.ez-see.net/xxxxxxxx (Receiver ID number) on IE
browser and to enter the remote viewing page.
18
Step 3. You could key in the remote viewing web link on PC IE browser (e.g.,
http://www.ez-see.net/10001901), log-in your account on remote PC IE browser, see the Live
View!
(*Remark: currently IE is the only PC web browser supported for remote viewing.)
PC log-in page:
(Remote viewing page)
19
Remote Viewing Steps for iPhone / iPad
Step1. Search “EZ-SEE” app on APP Store.
Step2. Press "add" to create an account as your EZ-SEE ID,
20
Step3. Fill in the ID, User Name and Password (same as the ASP4 network setting) and press
"Save" button which on the upper right corner.
Step4. You would see your ID number on your iPhone / iPad (e.g., 10001901).
My house
21
Step5. Enjoy your live viewing!! In this page, you could check the Quad-viewing or one channel
viewing mode by your desire. On the top of the page, you would see your defined DVR name
(same as your DVR name on ASP4 software network setting).
(Quad-viewing)
22
Technical Specification
General
Channel Pairing 4 Tx to 1 Rx
Operation Frequency Range 2408.625 ~ 2470.5 MHz
Channels hopping 24 channels
Modulation GFSK, FHSS (digital)
Transmission Range 150M (or longer with high gain antenna)
Transmitter RF output power 15.5 ~ 18.5 dBm
Digital Wireless Camera #CW1103
Resolution / Frame Rate 640x480 @ 30fps
Antenna connection Fixed type
Antenna gain 1.5 dBi
RF Data Rate 3Mbits /Second
Image Sensor 1/4'' SOC Sensor
Lens 2.5MM
IR LED 8pc
IR Filter IR 940nm
Power Consumption
Power 12V
Dimensions ca. 65 x 87 x 175 MM
Operation temperature 0°C ~ 40°C (32°F~ 104°F)
Quad Digital Wireless Recorder #CW1104 / CW#1106
Resolution / Frame Rate 640x480 / Quad View
640x480 @ 30fps per Channel
1CH Recording / 4CH Quad Recording
Antenna connection SMA Reverse
Antenna gain 3 dBi
Receiving sensitivity -85 dBm Above
Video compression MPEG-4
Recording Mode Schedule Continuous
Schedule Motion
Panic
12V 135mA (without IR)
12V 245mA (with IR)
Trigger by Tx PIR Input (under development)
Recording file format .SNX (with bundled ASP4 software)
Playback Mode Listed by Date/Time
Recording Storage
Alarm Out 1 set (NC or NO)
System Setup Date / Time Stamp
23
SD Card Fullstop or Overwrite (support up to
32GB)
AV Output
Channel Seq. Time
Buzzer Setup
Display Setup
Factory Default
USB connection
Yes, with bundled ASP4 software for Remote
View
12V 130mA (#CW1104)
Power Consumption
12V 280mA (#CW1106)
Power Adapter 12V 1A
104 x 112 x 28 MM (#CW1104)
Case Dimension
190 x 122 x 85 MM (#CW1106)
Operation temperature 0°C ~ 40°C (32°F~ 104°F)
24
Annex1
The following routers have all been tested and fully compatible with ASP4 software.
(Compatible Router list)
Router Manufacturer
BELKIN (F5D8235-4 v2)
D-Link (DI-604)
D-Link (DI-707P)
EDIMAX (BR-6204Wg)
GigaByte (GN-BR02G)
IO DATA(ETX-R)
IO DATA(NP-BBRL)
Lemel (LM-IS6400B)
LevelOne (FBR-1418TX)
LevelOne (WBR-3405TX)
Octtle GW/NAT (SP4220)
SMC (SMCBR14)
SMC (SMCWBRS14-N2-TW)
TP-LINK (TL-R402M)
TP-LINK (TL-R460)
BELKIN (F7D1301 v3)
Corega (CG-BARMX2)
IO DATA(ETG-R)
IO DATA(NP-BBRM)
LINKSYS (BEFSR41W)
NETGEAR (WGR614)
NETGEAR (WNDR3400)
NETGEAR (WNDR3700v2)
TP-LINK (TL-R480T+)
Zonet (ZSR0104B)
ZyXEL (NBG-4115)
ZyXEL (NBG-419N)
3COM (3CRWER100-75)
AboCom (WB02N)
ASUS (RT-N12)
ASUS (Rx3041)
ASUS (Rx3041 v2)
BUFFALO (WZR-HP-G300NH)
BUFFALO (WZR-HP-G300NH2)
D-Link (DI-LB604)
D-Link (DIR-101)
25
DrayTek (Vigor2110)
DrayTek (Vigor2200V/VG)
DrayTek (Vigor2910)
EDIMAX (BR-6228nS)
EDIMAX (BR-6314K)
LINKSYS (E2000)
LINKSYS (WRT150N)
LINKSYS (WRT160NL)
SAPIDO (RB-1802)
SAPIDO (RB-3001)
TP-LINK (TL-WR841N)
ZyXEL (Prestige 334)
Annex2 (Incompatible Router list)
So far, there are two routers may not work with ASP4 software. The routers name are as follow.
Router Manufacturer
AboCom (FSM410)
ASUS (Rx3081)
26
Thank you for purchasing our Quad Digital Wireless Series Products. Please
the device suddenly from a hot to a cold place, or vice versa.
read this manual before installation.
For customer support
further support.
Do not open/modify the device, as it may cause damage to the unit and
void the Warranty. For internal repairs, consult your dealer or an Authorized
Service Center.
Do not use any accessories other than what comes with the unit otherwise, it
would void the warranty.
Protect from humidity.
from sea water or high humidity environment etc.
, please contact your dealer, and keep your Invoice for
Do not put it in water and be careful to protect it
Protect from high temperatures
To avoid damage or mis-operation of the device, only use it in the temperature
between 0 ~ +40°C.
Do not bring
This may cause damaged to the inside of the unit by creating condensation.
EU Environmental Protection
The symbol of crossed-out garbage shows that this product should not be
treated as household waste, and it falls into the category of electric /electronic
equipment for recycling. This electronic device should not be disposed in a
regular trash. We strongly advice you to contact related authorization before
you dispose this product.
27
Loading...
