32 33
User Guide
Englisch
Downloaded from ManualMPlayer.com Manuals
34 35
1. Audio Player
Plays MP3 or WMA audio files
2. Video Player
Plays ASF video files
3. Photo Viewer
Displays JPG images
4. Clock and Calendar
Provides real-time clock and electronic calendar
5. Removable Storage Function
Provides built-in USB flash memory and can be used as removable disk
6. Voice Recording
Records voice input as WAV files
7. LINE-IN Encoding
Encodes audio source from external audio player such as
CD player/MD player into MP3 files
8. Games
Play Tetris World and Snake games
9. Display pictures on an external monitor such as a TV
10. SD/MMC memory card support
Access up to 1GB of SD/MMC memory card via the card slot
Features
Englisch
Downloaded from ManualMPlayer.com Manuals
36 37
Chapter 1 Getting Started ......................................................................39
1.1 System Requirements ............................................................................39
1.2 Accessories ..........................................................................................39
1.3 Description of buttons ...........................................................................39
1.4 Installing the battery .............................................................................40
1.5 Using the DC adapter ............................................................................40
1.5.1 To charge the battery .................................................................40
1.5.2 To power the device ...................................................................40
1.6 Inserting/Removing a memory card ........................................................41
1.7 Switching on/off ..................................................................................41
1.8 Converting Videos/Images .....................................................................41
1.8.1 Installing the CineWalker file conversion software ...........................42
1.8.2 Using the CineWalker file conversion software ...............................43
1.9 Installing Driver (for Windows 98/SE) .....................................................45
1.10 Connecting to the PC and downloading files ..............................................46
1.11 Disconnecting the device from the PC safely ..............................................47
1.11.1 For Windows 2000/XP/ME .......................................................47
1.11.2 For Win98/SE ..........................................................................47
1.12 Connecting to a TV ................................................................................47
1.13 Locking the keys ..................................................................................48
1.14 Use as a removable mass storage device ..................................................48
Chapter 2 How to Use ...........................................................................49
2.1 Select Working Mode ............................................................................ 49
2.2 Using the menu ...................................................................................49
2.3 VIDEO ............................................................................................... 50
2.3.1 Playing Videos ..........................................................................50
2.3.2 Setting Play Modes ....................................................................50
2.3.3 Protecting Videos ......................................................................51
2.3.4 Deleting Videos ......................................................................... 51
Table of Content
In the interests of safety, please read the following safety precautions before operation.
Do not subject the device to severe shocks or drop it from a great height.
Do not subject the player to extremes of heat or cold, or to dusty or damp conditions. Do not expose it to direct
sunlight.
Back up data frequently in case of accident data loss.
Keep the player away from strong magnetic fields.
Keep the device away from water or other liquids. In the event that the device is exposed to water or other liquids,
switch the power off immediately, take out the battery and clean the device.
To avoid corrosion, do not use chemical solution to clean the device. Clean it with a dry cloth.
No responsibility is assumed for damage or data loss caused by malfunction, misuse or repair of the device or
by replacement of the battery.
Any attempt to dismantle, repair or modify the product shall void the guarantee.
Important Information on using “DirStructure”
This program enables you to transfer the file structure of the takeMS CineWalker to the SD/MMC Cards
without any data loss.
Connect the SD/MMC Card from a card reader or your CineWalker toyour computer and copy the file
“DirStructure“ to the root directory of the Card.
Launch the “DirStructure” file by double clicking it. After this youshould be able to see two new folders:
“MP3“ and “DCIM“. In the DCIM folder, a subfolder named “100Media“ should be located.
You will now be able to use your CineWalker with the aid of these three folders. All music files must
be stored in the “MP3“ folder. All photos and movie files must be stored in the “100Media“ folder.
Enjoy using your CineWalker.
Safety Precautions
Englisch
Downloaded from ManualMPlayer.com Manuals
38 39
2.4 MUSIC ............................................................................................... 52
2.4.1 Playing Music ...........................................................................52
2.4.2 Displaying Lyrics ........................................................................53
2.4.3 Setting EQ Mode .......................................................................53
2.4.4 Setting Play Mode ..................................................................... 54
2.4.5 Deleting ...................................................................................54
2.5 VOICE ...............................................................................................55
2.5.1 Setting Audio Source ..................................................................55
2.5.2 Voice Recording .........................................................................55
2.5.3 LINE-IN Recording ...................................................................... 55
2.5.4 Playing Recordings .....................................................................55
2.6 PHOTO ...............................................................................................56
2.6.1 Browse Photos/Images ..............................................................56
2.6.2 Slide Show ...............................................................................56
2.6.3 Delete Image ...........................................................................56
2.6.4 Set Boot-up Screen .................................................................... 57
2.7 GAME ............................................................................................... 57
2.7.1 Tetris World .............................................................................. 57
2.7.2 Snake ......................................................................................57
2.8 ACCESSORIES .......................................................................................58
2.8.1 Calendar .................................................................................. 58
2.8.2 System Information ................................................................... 58
2.9 SETTINGS ............................................................................................ 58
Chapter 3 Technical Support ..................................................................60
3.1 Troubleshooting ....................................................................................60
3.2 Technical Specifi cations ..........................................................................62
3.3 Important Notice ...................................................................................63
Chapter 1 Getting Started
1.1 System Requirements
• Hardware: IBM PC & Compatible PC, Note Book with USB port
• Operating System: Windows 98/SE, Windows 2000 Service Pack 4, Windows XP,
Windows ME etc.
1.2 Accessories
1.3 Description of buttons
Table of Content
• USB Cable
• Audio/Video Cable
• Earphone with neck strap
• CineWalker fi le conversion software CD
• LINE-IN Cable
• DC Adapter
• Rechargeable Lithium Battery
• Carrying Case
• Warranty Card
• User Manual
a. USB Port: Connect to USB cable
b. Memory Card Slot: Insert SD/MMC card
c. Power Jack: Connect to DC adapter
d. Power Switch: Power On/Power Off
e. MENU button: Display menu items
f. ESC button: Return or Exit
g. Speaker
h. Power Indicator: Turns green when you
power on the device
i. Charge Indicator: Turns red when you recharge
the battery
j. Display
k. PLAY/NAVI Button: Play/Pause
Volume up/down
Previous/Next
Fast forward/Rewind
Select/Confi rm
l. Audio Output/Earphone Jack: Connect to
earphone jack, audio cable or microphone
m. Video Output/LINE-IN Jack: Connect to video
cable or LINE-IN cable
n. Hold Switch: Locks keys against being pressed
accidentally
o. Battery cover
Englisch
Downloaded from ManualMPlayer.com Manuals
40 41
1.6 Inserting/Removing a memory card
The device contains a card slot for a memory card. Memory cards can be inserted according
to the procedure below:
(1) On the left side of the machine, there is a card slot.
(2) Insert the memory card face-down into the slot.
The display shows the memory card symbol “ ” on the top bar.
Card symbol
To remove the card, press it first and then pull it out.
Note: Make sure the device is powered off before you insert or remove a memory card. Never
insert or remove a card when the device is working, as the card or the device may be damaged.
1.7 Switching on/off
To switch on the device, press and hold the Power Switch until the power indicator lights up.
To switch off the device, press and hold the Power Switch until the screen is off.
1.8 Converting Videos/Images
Before you download a video or image from a PC to the device, please convert into a supported
file type by using the included Transcording Tool on the CineWalker file conversion software CD.
The device supports MP3/WMA audio, ASF video and JPG image files.
The following tables show which file types can be converted:
1.4 Installing the battery
The device comes with a rechargeable lithium-ion battery. Please install the battery as
shown below:
(1) Press the point embossed with an arrow sign, and slide the battery cover as shown below
to remove it.
(2) Place the battery into the battery compartment, making sure it is correctly aligned.
(3) Close the battery cover.
1.5 Using the DC adapter
1.5.1 To charge the battery
After installing the battery, you need to charge it using the DC adapter. Charging the
battery fully takes about 3.5 hours. To charge the battery, follow these steps:
(1) Connect one end of the adapter to the power jack.
(2) Connect the other end to the electrical outlet.
Note:
a. The charge indicator turns red during charging. When the battery is fully charged,
the charge indicator switches off.
b. You can still operate the machine while the battery is being charged.
1.5.2 To power the device
The DC adapter can be used not only to charge the battery but also to supply power to
the device. To conserve the battery’s charge, you can remove the battery and just use
the DC adapter to power the device.
When the DC adapter is connected, the power indication “ ” appears at the upper
right of the screen.
Chapter 1 Getting Started Chapter 1 Getting Started
