TAC Xenta OP
Handbook
TAC Xenta OP
Handbook
Copyright © 2007 TAC AB. All rights reserved.
This document, as well as the product it refers to, is only intended for licensed users. TAC AB owns the copyright of this document and reserves
the right to make changes, additions or deletions. TAC AB assumes no responsibility for possible mistakes or errors that might appear in this
document.
Do not use the product for other purposes than those indicated in this document.
Only licensed users of the product and the document are permitted to use the document or any information therein. Distribution, disclosure,
copying, storing or use of the product, the information or the illustrations in the document on the part of non-licensed users, in electronic or
mechanical form, as a recording or by other means, including photo copying or information storage and retrieval systems, without the express
written permission of TAC AB, will be regarded as a violation of copyright laws and is strictly prohibited.
Trademarks and registered trademarks are the property of their respective owners.
TAC Xenta, TAC Xenta OP Contents
TAC AB, July 2007 5 (46)
04-00065-01-en
Contents
INTRODUCTION
1 About this Manual 9
1.1 Structure ..................................................................................................................... 9
1.2 Typographic Conventions .......................................................................................... 9
REFERENCE
2 Introduction 13
2.1 TAC Xenta OP ........................................................................................................... 13
2.2 This Manual ............................................................................................................... 13
2.3 More information ....................................................................................................... 14
3 Connection and Basic Functions 15
3.1 Description ................................................................................................................. 15
3.2 Connecting to TAC Xenta 100................................................................................... 16
3.3 Connecting to TAC Xenta 280/300/401 .................................................................... 16
3.4 Keys............................................................................................................................ 18
3.5 Local Functions of the OP Service Menu .................................................................. 19
3.5.1 Two Hardware Tests .................................................................................................. 19
3.5.2 System Information.................................................................................................... 20
3.5.3 Selecting the Language of the OP Messages ............................................................. 20
3.5.4 Controlling the Display Light .................................................................................... 20
3.5.5 Leaving the OP Service Menu ................................................................................... 21
3.5.6 Selecting the OP Mode............................................................................................... 21
3.6 Selecting the OP Communication Mode.................................................................... 21
3.6.1 Summary ....................................................................................................................22
3.6.2 Bindable ..................................................................................................................... 23
3.7 Remove the OP .......................................................................................................... 24
3.7.1 Tool: MetraVision...................................................................................................... 24
3.7.2 Tool: LonMaker ......................................................................................................... 25
4 Dialogs with TAC Xenta 100 27
4.1 General ....................................................................................................................... 27
4.2 Connecting to TAC Xenta 100................................................................................... 27
4.3 Setting the Node State in TAC Xenta 100 ................................................................. 28
4.4 Reading/Checking NVs in TAC Xenta 100 ............................................................... 29
4.5 Initiate Service Pin Message ...................................................................................... 30
5 Dialogs with TAC Xenta 280/300/401 31
5.1 The Menus.................................................................................................................. 31
5.2 Find and Change a Setpoint ....................................................................................... 32
Contents TAC Xenta, TAC Xenta OP
6 (46) TAC AB, July 2007
04-00065-01-en
5.3 View/Acknowledge Alarms ....................................................................................... 33
5.4 Change the Time Channels......................................................................................... 35
5.5 Access Code ............................................................................................................... 37
5.6 Edit Access Code........................................................................................................ 37
5.7 Overriding Inputs/Outputs.......................................................................................... 38
5.8 Daylight Saving .......................................................................................................... 38
5.9 Log Off ....................................................................................................................... 39
6 Technical Data 41
Index 43
INTRODUCTION
1 About this Manual
TAC Xenta, TAC Xenta OP 1 About this Manual
TAC AB, July 2007 9 (46)
04-00065-01-en
1 About this Manual
This manual describes a particular process. For information on certain
products, we refer you to the manual or the Help for the product in question.
For information on how to install software, we refer you to the instructions delivered with the software.
For information on third party products, we refer you to the instructions
delivered with the third party product.
If you discover errors and/or unclear descriptions in this manual, please
contact your TAC representative.
1.1 Structure
The manual is divided into the following parts:
• Introduction
The Introduction section contains information on how this manual
is structured and how it should be used to find information in the
most efficient way.
• Reference
The Reference section contains more comprehensive information
about various parts of the Getting Started section. It also provides
you with information on alternative solutions not covered by the
Getting Started section.
1.2 Typographic Conventions
Throughout the manual the following specially marked texts may occur.
Note
• We are continuously improving and correcting our documentation. This manual may have been updated.
Please check our Docnet site at www.tac.com for the latest version.
1 About this Manual TAC Xenta, TAC Xenta OP
10 (46) TAC AB, July 2007
04-00065-01-en
!
Warning
• Alerts you that failure to take, or avoid, a specific action might
result in physical harm to you or to the hardware.
Caution
• Alerts you to possible data loss, breaches of security, or other
more serious problems.
Important
• Alerts you to supplementary information that is essential to the
completion of a task.
Note
• Alerts you to supplementary information.
Tip
• Alerts you to supplementary information that is not essential to
the completion of the task at hand.
Advanced
• Alerts you that the following information applies to complex
tasks or tasks restricted by access.
REFERENCE
2 Introduction
3 Connection and Basic Functions
4 Dialogs with TAC Xenta 100
5 Dialogs with TAC Xenta 280/300/
401
6 Technical Data
TAC Xenta, TAC Xenta OP 2 Introduction
TAC AB, July 2007 13 (46)
04-00065-01-en
2 Introduction
2.1 TAC Xenta OP
TAC Xenta OP is a small operator panel designed to be used together
with TAC Xenta 100, 280, 300, 401 and 901 units.
The operator panel gives the user access to parameters and alarms without communicating with a central system. Additionally, it is used to
monitor status, adjust setpoints and time channels. All values are displayed with an explanatory text in the alphanumeric display window.
2.2 This Manual
This handbook has the following contents:
Chapter 2
In this chapter the connection of the operator panel, TAC Xenta OP, to
the TAC Xenta 100/280/300/401 controllers is shown.
Chapter 3
The use of the OP together with TAC Xenta 100 and the principles for
handling display of Network Variables are explained in this chapter.
Chapter 4
The use of the OP together with TAC Xenta 300/401 controllers and the
most common menus are discussed here.
Chapter 5
This chapter contains technical data on the TAC Xenta OP.
Caution
• The TAC Xenta OP and the other products of the Xenta family
must not be used for any other purpose than that for which it was
designed.
• Installation and repair may only be performed by authorized personnel.
2 Introduction TAC Xenta, TAC Xenta OP
14 (46) TAC AB, July 2007
04-00065-01-en
2.3 More information
TAC Xenta OP is also described or mentioned in the following documents:
• The TAC Xenta OP Operator panel data sheet
• The handbooks for the different TAC Xenta controller units
• The TAC Menta User’s manual
Stand-alone TAC Xenta 300/3000 controllers and I/O modules can be
commissioned by using the Service menu of TAC Xenta OP (which is
not the same as the local OP service menu). This procedure is described
in the TAC Xenta 300 and 401 Handbook.
TAC Xenta, TAC Xenta OP 3 Connection and Basic Functions
TAC AB, July 2007 15 (46)
04-00065-01-en
3 Connection and Basic Functions
3.1 Description
The TAC Xenta OP Operator panel has an LCD display with 4*20
characters and six push buttons. A modular socket or four screw terminals are used for communication and for connecting the power supply.
These connectors are placed on the rear. There is also a potentiometer
to adjust the contrast of the display, on the rear.
The OP has an LCD display that can be lighted from beneath. The light
is controlled from the OP Service menu (section 2.5).
The operator panel is used to monitor status and to adjust setpoints and
time channels. It also makes it possible to list the alarms without communicating with a central system.
The operator panel is controlled from a master, a TAC Xenta 100, 280,
300 or 401 controller. When you start using the operator panel, it will
send a message to the master telling it what button was pushed. The
master contains the dialog messages and will direct the operator panel
what to show on the display. Thus the operator panel will act as a dumb
terminal.
Fig. 3.1: The TAC Xenta OP operator panel.
LCD display
Push buttons
Connectors (rear)
3 Connection and Basic Functions TAC Xenta, TAC Xenta OP
16 (46) TAC AB, July 2007
04-00065-01-en
3.2 Connecting to TAC Xenta 100
Normally the TAC Xenta OP is connected to the modular jack on the
lower side of the Wall Module. In this way the Xenta OP will get power
supply from the TAC Xenta 100 unit.
Cable between controller and Operator panel: max. 10 m
The contrast of the display can be adjusted with the potentiometer on the
rear of the operator panel; please refer to the figure in the next section.
3.3 Connecting to TAC Xenta 280/300/401
Cable between controller and Operator panel: max. 10 m.
When connecting the operator panel there are two alternatives (please
refer to the adjacent figures):
• Use the modular socket on the front of the TAC Xenta 280/300/
401 controller and the corresponding socket on the back of the
operator panel. This requires a special cable.
• Use the screw terminals on the back of the operator panel,
labelled 1–4. Terminals 1 and 2 are used for communication and
terminals 3 and 4 for 24 V AC (or DC).
Fig. 3.2: Connecting the TAC Xenta OP to TAC Xenta 100 via the Wall
Module.
COMFORT
ECONOMY
OFF
TAC Xenta 100
Wall module
TAC Xenta, TAC Xenta OP 3 Connection and Basic Functions
TAC AB, July 2007 17 (46)
04-00065-01-en
At the controller you use the terminals C1, C2 and G, G0.
The contrast of the display can be adjusted with the potentiometer on the
rear of the operator panel.
(The Service pin is available from the rear if, in special cases, the network configuration procedure requires this. When the pin is pressed, a
unique hardware identity code is sent on the network.)
Fig. 3.3: TAC Xenta OP connectors and contrast potentiometer.
4
3
21
C1 C2 G G0
TAC Xenta 280/300/401 controller
Socket for the
connection to
the operator panel
Socket and screw terminal
for the TAC Xenta
controller connection
Service pin
Modular socket
on the OP
Contrast adjustable
(on the rear)
l
3 Connection and Basic Functions TAC Xenta, TAC Xenta OP
18 (46) TAC AB, July 2007
04-00065-01-en
3.4 Keys
Keys and their functions
Fig. 3.4: The TAC Xenta OP keys.
+
–
is used to step up one level in the
directory hierarchy (“Home”).
There may be several levels in
the hierarchy. The cursor will
return to the line selected the last
time this level was active. This
button does not by itself make
changes effective.
is used to decrease values. If this
button is kept depressed, the
stepping speed increases.
is used to increase values. If this
button is kept depressed, the
stepping speed increases.
is used to move the cursor
upwards in a menu list or to
move to previous alarm or
logged record.
is used to move the cursor
downwards in a menu list or to
move to previous alarm or
logged record.
is used to select a line, indicated
by the cursor (“Enter”) or to
move between the different
adjustable values.
This button also makes changes
effective.
–
+
TAC Xenta, TAC Xenta OP 3 Connection and Basic Functions
TAC AB, July 2007 19 (46)
04-00065-01-en
3.5 Local Functions of the OP Service Menu
For simple hardware check of the OP and for certain system parameters
there is a local Service menu in the operator panel. The OP functions are
quite independent of the other TAC Xenta units and only require that the
operator panel is connected to the network and that the panel has not
been set in the TAC Xenta 100 communication mode (see below).
The Service menu appears if both the keys and are pressed
for about three seconds simultaneously.
OP Service menu
1. Exit service mode
2. Keyboard test
3. Display test
4. LON address
5. National text
6. SW version
7. LonTalk status
8. Display backlight
9. Service pin
10. OP mode
Select the required function and press .
3.5.1 Two Hardware Tests
2. Keyboard test
This tests the keyboard functions.
Keyboard test
* * * Press keys!
* * Double-press
* for QUIT
Each asterisk corresponds to a key. Double pressing on any key means
leaving the test.
3. Display test
This tests all display positions in a number of steps. Each step is initiated by pressing any key.
3 Connection and Basic Functions TAC Xenta, TAC Xenta OP
20 (46) TAC AB, July 2007
04-00065-01-en
3.5.2 System Information
4. LON address
Shows the current Domain/Subnet/Node address for the operator panel.
6. SW version
Lists the current version of the operator panel version and
7. LonTalk status
Shows statistics from the network communication.
9. Service pin
Is a way to send the unique Neuron ID on the network. Mainly used for
testing purposes.
3.5.3 Selecting the Language of the OP Messages
5. National text
Means that the operator can switch between different languages for
those messages that are generated in the OP.
Select language
No reply ...
Wait ...
Press Enter to save!
If you press or the language will change, for example into
German:
Select language
Keine Antwort ...
Bitte warten ...
Press Enter to save!
When you have selected a suitable language you press (“Enter”)
and then leave the menu.
3.5.4 Controlling the Display Light
8. Display backlight
Controls the background light of the OP display. There are three modes:
OFF, ON and AUTO.
•OFF
Means that the backlight is always turned off,
TAC Xenta, TAC Xenta OP 3 Connection and Basic Functions
TAC AB, July 2007 21 (46)
04-00065-01-en
•ON
Means that the light is turned on permanently and
•AUTO
Means that the light is turned on as soon as a button is pressed, but
goes off about 30 minutes after the last key has been pressed.
Use and to select the required mode.
As the display light may cause loss of contrast if turned on permanently,
we recommend the AUTO or OFF mode.
3.5.5 Leaving the OP Service Menu
1. Exit service mode
Means leaving the local OP service menu.
This will also happen if no key has been used during about 40 seconds.
3.5.6 Selecting the OP Mode
10. OP mode
In TAC Xenta networks the OP may working in one of two communication modes:
• For communication with TAC Xenta 280/300/400
• For communication with TAC Xenta 100
Furthermore, the OP can be more or less mobile, depending on the way
the OP is connected to the network.
Please refer to the next section!
3.6 Selecting the OP Communication Mode
Xenta 100: ON/OFF
When delivered, the OP is set for Base unit (TAC Xenta 280/300/400)
communication. To change the communication mode, you have to call
up the OP Service menu and go to the 10.OP mode menu, where the
TAC Xenta 100 mode can be turned on/off.
Change OP mode
Xenta 100 : OFF
Bindable : TAC
Use or to change the Xenta 100 mode and press.
+
–
+
–
3 Connection and Basic Functions TAC Xenta, TAC Xenta OP
22 (46) TAC AB, July 2007
04-00065-01-en
When the OP is set to allow the Xenta 100 mode, the operator is given
a choice to access TAC Xenta 100 (in stead of TAC Xenta 280/300/400)
by pressing “Enter”, each time an OP is connected.
The OP Service menu cannot be reached when the OP is in the Xenta
100 mode.
If you want to turn OFF the Xenta 100 mode, once you are in this mode,
you must temporarily disconnect the OP and let the OP revert to the
Base unit communication mode in order to be able to reach the Service
menu and from there select the 10. Change OP mode menu.
The TAC Xenta 100 OP communication is described in the next chapter.
“Bindable” is explained after the Summary below.
3.6.1 Summary
To turn ON the Xenta 100 mode
Connecting to
Xenta Base unit
1. Connect the OP and wait for message
on display.
OP Service menu
1. Exit service
mode
2. Keyboard test
3. Display test
2. Press both keys and for
about three seconds simultaneously.
10 OP mode 3. Select 10. OP mode menu.
Change OP mode
Xenta 100 : ON
Bindable : TAC
4. Press or to set the Xenta
100 mode ON and press .
Press enter to
access Xenta 100
5. Temporarily disconnect the OP and
wait for message on display.
Connecting to
Xenta 100 ...
6. Press to access Xenta 100.
7. Wait for message on display.
+
–
TAC Xenta, TAC Xenta OP 3 Connection and Basic Functions
TAC AB, July 2007 23 (46)
04-00065-01-en
To turn OFF the Xenta 100 mode
3.6.2 Bindable
“Bindable” is a LonWorks term, describing how the OP is connected
and addressed in the network. This, in turn, affects the mobility of the
OP.
Use or to select Bindable mode from the following:
• TAC OP movable.
Two available addresses following each TAC Xenta Base unit.
• INST
OP permanently electrically connected to the network; installed
with a binding tool.
• MAN
OP movable, the domain ID of the network has to be programmed
via OP Service menu – 4.LON address (communication is here limited to Base units on the same channel).
For OP version 3.11 and earlier the following modes can be chosen:
•OFF
OP movable. Two available addresses following each TAC Xenta
Base unit.
Press enter to
access Xenta
100(wait)
Connecting to
Xenta Base unit
1. Disconnect and then) connect the OP;
wait for a couple of seconds for the Base
unit message to appear.
2. Press both keys and for
about three seconds simultaneously.
OP Service menu
1. Exit service
mode
2. Keyboard test
3. Display test
10 OP mode 3. Select 10. OP mode menu.
Change OP mode
Xenta 100 : OFF
Bindable : TAC
4. Press or to set the Xenta
100 mode ON and press .
1. Exit service
mode
5. Select the 1. Exit service mode menu
and press .
+
–
+
–
3 Connection and Basic Functions TAC Xenta, TAC Xenta OP
24 (46) TAC AB, July 2007
04-00065-01-en
•ON
OP permanently electrically connected to the network; installed
with a binding tool.
Confirm your choice by pressing .
3.7 Remove the OP
If the OP is to be removed from the network, it should be restored to the
original factory setting to avoid problems, if used in another network.
Depending on which binding tool has been used, the removal is made
according to one of the methods shown below.
3.7.1 Tool: MetraVision
1 Select OP Service menu ⏐ 10. OP mode and set Bindable to
TAC or, in OP version < 3.11, OFF.
2 Disconnect the OP electrically from the network.
3 “Remove” the OP node from the data base.
Factory setting
If the OP has been labelled ”Unconfig”, which may happen if step 3
above was executed before step 2, or for any other reason; the OP may
be restored to the factory setting in one of two ways:
• Reconnect the OP to the network, reinstall it and perform the steps
above in the correct order, or
• Use the Nodutil program and do the following.
Select OP Service menu
⏐ 10. OP mode and set Bindable to TAC or,
in OP version < 3.11, OFF.
1 Start Nodutil.
2 Press the Service pin of the OP.
3 Type “G ” .
4 Type “1”, press Enter.
5 Type “M”.
6 Type “S”.
7 Type “C ” .
TAC Xenta, TAC Xenta OP 3 Connection and Basic Functions
TAC AB, July 2007 25 (46)
04-00065-01-en
3.7.2 Tool: LonMaker
1 Check in the OP Service menu ⏐ 10. OP mode that Bindable is
set to TAC or, in OP version < 3.11, OFF.
2 Start the LonMaker Browser.
3 Right-click, and then click Properties.
4 Disconnect the OP electrically from the network.
5 Remove the OP from the data base of LonMaker.
Factory setting
If the OP has been de-installed in an incorrect way, it may be restored
to the factory setting in one of two ways:
• Reconnect the OP to the network, reinstall it and perform the steps
above in the correct order, or
• Use the Nodutil program and perform the following.
1 Select OP Service menu
⏐ 10. OP mode and set Bindable to
TAC or, in OP version < 3.11, OFF.
2 Start Nodutil.
3 Press the Service pin of the OP.
4 Type “ G ”.
5 Type “1”, and then press Enter.
6 Type “M”.
7 Type “ S ”.
8 Type “ C ”.
9 Type “ U ”.
10 Type “2”, and then press Enter.
11 Type “00”, and then press Enter.
Note
• Restore SNVT_config_src from cfg_external (1) to cfg_local (0).
SNVT_config_src is called var_2 in the Browser.
3 Connection and Basic Functions TAC Xenta, TAC Xenta OP
26 (46) TAC AB, July 2007
04-00065-01-en
TAC Xenta, TAC Xenta OP 4 Dialogs with TAC Xenta 100
TAC AB, July 2007 27 (46)
04-00065-01-en
4 Dialogs with TAC Xenta 100
4.1 General
TAC Xenta OP can be used as a service and limited commissioning tool
for the TAC Xenta 100 Zone Controllers. These controllers use Network Variables of the LonWorks standard type (“SNVT”, Standard
Network Variable Type) for all data communication on the network. All
Network Variables, including the configuration parameters can be
accessed via the keypad and the LCD display.
In order to separate this general kind of communication from the dedicated communication used with TAC Xenta 280/300/401 controllers,
the TAC Xenta OP has two different communication modes.
4.2 Connecting to TAC Xenta 100
Press enter to
access Xenta 100
Press the key to get the display
Connecting to
Xenta 100 ...
Notes
• The very first time a TAC Xenta OP is connected to a Xenta network, the TAC Xenta 100 communication mode is, by default, in
the Off state.
Please refer to the end of chapter 2 for the necessary procedures
to change the communication mode.
• When this has been done, the operator is given a choice to access
TAC Xenta 100 (instead of the TAC Xenta 280/300/401).
4 Dialogs with TAC Xenta 100 TAC Xenta, TAC Xenta OP
28 (46) TAC AB, July 2007
04-00065-01-en
Check that the LED on the Wall Module will flash for some 10 seconds
or that the red Service LED turns on and then off after a couple of seconds, on the connected controller.
If contact is established without the LED flashing, Xenta OP has connected to another node in the network. In this case disconnect Xenta OP
and then reconnect.
Wait for the display.
Xenta 100 is:
Configured
Press <DOWN> to
continue
Press the key and wait for a display looking like:
Xenta 103v1.00-10
103/A/v10003
units as SI [^]
NV index? 000
The first two lines, showing software versions, are displayed the first
time only.
The third line shows which unit system is used, when SNVT values are
presented in the OP menus.
The key toggles between SI (metric) and US Imperial (Inch-Pound)
units.
From this display (normally only lines 3-4 appear) the different Network Variables can be selected.
4.3 Setting the Node State in TAC Xenta 100
When the display
Xenta 100 is:
Configured
Press <DOWN> to
continue
TAC Xenta, TAC Xenta OP 4 Dialogs with TAC Xenta 100
TAC AB, July 2007 29 (46)
04-00065-01-en
is shown, the second line can be switched between Configured and
Unconfigured, using the and keys.
When Configured the TAC Xenta 100 can send and receive Network
Variables.
When Unconfigured the TAC Xenta 100 cannot communicate on the
network.
In normal operation on a network, the TAC Xenta 100 should always be
set to Configured.
Configured/Unconfigured are normally set by a binding tool, in a network configuration and by TAC Xenta OP in a stand-alone configuration. See also the TAC Xenta Network guide.
4.4 Reading/Checking NVs in TAC Xenta 100
When a connection has been established (see, Section 4.2, “Connecting
to TAC Xenta 100”, on page 27) a NV (Network Variable) index can be
selected by the use of the and keys.
Keep the key pressed to increase the toggling speed. Press the key
to display the selected variable.
Example: Select NV 004 to get the Effective Setpoint:
4 nvoEffectSetpt
21.00 °C
nvo indicates that this is an output value and cannot be changed from
the OP.
Use the key to return to NV index selection.
Input variables appear further down in the list:
Example: Select NV 013 to get the Application Mode:
13 nviApplicMode
Auto _
nvi indicates that this is an input value. The cursor is visible and allows
the value to be changed from the OP.
Use and to change the value. Keep the key pressed to
increase the toggling speed.
Press to enter the new value.
+
–
+
–
+
–
4 Dialogs with TAC Xenta 100 TAC Xenta, TAC Xenta OP
30 (46) TAC AB, July 2007
04-00065-01-en
If or or is pressed before , no change will take place.
The keys and will take you to the adjoining NVs in the list.
4.5 Initiate Service Pin Message
When the NV index selection is displayed
uunits as SI [^]
NV index? 000
a service pin message is sent from the Xenta 100, initiated from the OP,
each time the key is pressed.
TAC Xenta, TAC Xenta OP 5 Dialogs with TAC Xenta 280/300/401
TAC AB, July 2007 31 (46)
04-00065-01-en
5 Dialogs with TAC Xenta 280/300/
401
5.1 The Menus
The menus of the operator panel and the order in which they are presented are designed by an application programmer, using the
TAC Menta design tool.
Thus, the menus shown below are only examples. The principles showing how to select among the menus and how to change the values are,
however, general.
Cyrillic characters
The TAC Xenta OP/RU model has the capability of displaying Cyrillic
characters.
The TAC Menta User’s manual describes how you switch the character
files of the OP.
24 hour clock vs. AM/PM clock
In those menus that allow time (clock) entries, like the Time Schedule,
the Holiday chart (Time channels) and the Daylight saving menus, you
may choose to present time with a 24 hour clock or with a 12 hour clock,
also called an AM/PM clock. The choice is made already during the
menu design phase in TAC Menta.
To translate between the two modes of display the following table can
be used.
24 hour clock AM/PM clock
01.00 01.00 AM
06.00 06.00 AM
11.59 11.59 AM
12.00 12.00 PM
12.59 12.59 PM
13.00 01.00 PM
5 Dialogs with TAC Xenta 280/300/401 TAC Xenta, TAC Xenta OP
32 (46) TAC AB, July 2007
04-00065-01-en
When the AM/PM clock is used, the time in the OP menus are compressed to hhAmm and hhPmm for hh.mm AM and hh.mm PM respectively.
5.2 Find and Change a Setpoint
This example starts with the first screen showing all TAC Xenta 300/
401 controllers in the network and shows how to find and change the
supply air setpoint in “AH02 West”:
AH01 East
AH02 West
HEAT-1 North
HEAT-2 South
Press once and then .
AH02: West
_STATUS
TEMPERATURES
ALARMS
Press once and then .
AH02: Temperatures
Outdoor temp:
Now: 16.5 C
Max:22.5 Min:11.3
Press until the required screen is found.
18.00 06.00 PM
23.59 11.59 PM
00.00 12.00 AM
00.59 12.59 AM
24 hour clock AM/PM clock
TAC Xenta, TAC Xenta OP 5 Dialogs with TAC Xenta 280/300/401
TAC AB, July 2007 33 (46)
04-00065-01-en
AH02: Temperatures
Supply air
Measured: 17.1 C
Set value: 27.5 C
As there is only one value that could be changed in this screen the cursor
is already in the right position and the setpoint could be set with
and .
Changes will be effective as soon as is pressed.
5.3 View/Acknowledge Alarms
To make the operator aware of unacknowledged alarms in the alarm list
the abbreviated application/base unit name (“AH02” in our examples)
will flash. When the item “Alarms” has been found and selected with
Enter, a screen like the following will appear:
AH02 ALARMS: 6/6
P1
PUMP STOPPED
99-JAN-15 14:05 ON
On the top row there is an indication that this is alarm number six of six
in the list. To see the other alarms in the list use or .
The text ON in the above alarm example indicates that the alarm has
tripped but not been acknowledged.
A selected alarm is acknowledged when the operator presses
(Enter). The text ON will change to, for example, “ACK”.
Alarms which have tripped and then returned to normal state are indicated with OFF.
On the Operator panel, for each point at any given moment, at most one
of the three alternatives below can appear:
+
–
5 Dialogs with TAC Xenta 280/300/401 TAC Xenta, TAC Xenta OP
34 (46) TAC AB, July 2007
04-00065-01-en
Transitions between these three states at moments in time t1, t2 etc., and
the disappearance from the list, may occur in the way shown in the diagram below.
The alarm list is sorted in chronological order with the oldest event displayed at the top. The alarm list is dimensioned to allow all points of
alarm to appear at the same time.
If a TAC Xenta controller is connected to a supervisory system like
TAC Vista, another indication may appear in the alarm list. An asterisk
(*) in front of the signal name means that the alarm is blocked, that is,
information about changes between alarm on and alarm off will not be
sent to TAC Vista.
The alarms will, however, be listed on the OP as usual.
The blocking request is set/removed from TAC Vista.
Example:
AH02 ALARMS: 2/6
*SF1
SUPPLY FAN STOPPED
99-JAN-15 13:50 OFF
Fig. 5.1: Possible events at alarms and the way they are presented in the alarm list: time, Alarm text, status
t1 Alarm ON
t2b Alarm OFF
t2a Alarm ACK
t3 Alarm ON
t3 Alarm ON
- - - -
- - - -
t1 Alarm ON
Acknowledge
Alarm goes
off
New alarm
New alarm
Alarm goes off
Acknowledge
New Alarm
TAC Xenta, TAC Xenta OP 5 Dialogs with TAC Xenta 280/300/401
TAC AB, July 2007 35 (46)
04-00065-01-en
5.4 Change the Time Channels
The operating hours for a selected object can be adjusted by altering one
or more time channels. This can be done from the operator panel. The
number of week schedules available for a specific time schedule is
defined in the application program.
The following is an example of an object (AH02) controlled by three
different schedules. The object is active 08:00–12:00 and 13:00–17:00
on weekdays and 08:00–12:00 on Saturdays. The example shows how
to change operating hours on Saturdays to be 08:00–13:30.
Example:
Week schedule
Go to the week schedule for AH02.
AH02: Time schedule
1234567
08:00–12:00 MTWTF
13:00–17:00 MTWTF
To get to the next schedule controlling AH02 press once.
AH02: Time schedule
1234567
08:00–12:00 S
As the cursor is positioned under “08”, must be pressed twice to
move the cursor to “12”. Use and to change the off hour to
“13”. Press once and adjust the minutes.
Notes
• Starting with TAC Xenta System program v 3.4 this blocking
function has been changed. The alarm information will be sent to
TAC Vista, as any normal alarm, but it will not be displayed on
the OP.
• TAC Vista stores the alarm event in the historical log, even if
alarms of priority 0 are not displayed in the alarm list.
+
–
5 Dialogs with TAC Xenta 280/300/401 TAC Xenta, TAC Xenta OP
36 (46) TAC AB, July 2007
04-00065-01-en
When finished, press after the last entry and then use to
return to the previous menu level.
Holiday chart
The week schedule can be modified by a Holiday chart which defines
conditions for certain dates, for example when Christmas Eve occurs on
a workday:
AH02: Holiday chart
1234567
14:00–17:00 MTWTF
**-12-24 : **-12-24
The asterisks (**) act as “wild card”, that is, the date will in this case be
valid each year.
Use and to change the time and date values. Use to
move the cursor between the fields. To obtain asterisks in the date
fields, toggle the month value past 12. To obtain asterisks for the year
value, you must toggle backward from the value 94.
When finished, press after the last entry and then use to
return to the previous menu level.
The Holiday chart is valid throughout the 24 hours.
Note, for example, the following case:
Week schedule says active 08:00-18:00
Holiday chart says active 00:00-00:01
The object will be active for the one minute only.
Special cases
If you want the time channel to be turned off for the whole day and night
and use the 24 hour clock, you indicate this by
00:00-00:00
and with the AM/PM clock (please refer to section 4.1)
12A00-12A00
If, instead, you want the time channel to be turned on for the whole day
and night and use the 24 hour clock, you indicate this by
00:00-24:00
and with the AM/PM clock
12A00-00P00
+
–
TAC Xenta, TAC Xenta OP 5 Dialogs with TAC Xenta 280/300/401
TAC AB, July 2007 37 (46)
04-00065-01-en
In the latter case the end time (24:00 respective 00P00) is a normally
’nonexistent’ time value.
5.5 Access Code
Every item that is displayed in a menu on the operator panel has an
access level, which can be low, medium or high. An item with low
access level will always be visible on the display of the operator panel.
To show items, with access level medium or high, a correct access code
has to be given. There is one code giving access to low and medium
level items and one to give access to all levels.
The default codes are
Medium level: 1111
High level: 2222
To change access level go to the following menu:
AH02: ACCESS CODE
CODE: 0000
Change code to
extend menu
Use to move the cursor between the digits and use and
to change their value. When finished, leave the menu with .
If the correct code has been entered, some more items will now be visible in the list, for example, “Edit Access code”.
5.6 Edit Access Code
To change the code that gives the operator access to the medium or high
level items, the access level code for the level to be changed must first
be entered as described above. Then go to the Edit Access Code screen:
A2: EDIT ACCESS CODE
EDIT CODE: 0000
Change code for
the active level (no.)
Use to move the cursor between the digits and use and
to change their value. When finished, press and leave the
+
–
+
–
5 Dialogs with TAC Xenta 280/300/401 TAC Xenta, TAC Xenta OP
38 (46) TAC AB, July 2007
04-00065-01-en
menu with . As the access code is changed only the standard (low
level) items will be shown. To show the medium or high level menu
items the new access code has to be entered as described in the previous
example.
After the download of an application from TAC Menta, the access code
will revert to the default value.
5.7 Overriding Inputs/Outputs
For access code high, it is possible to override the input and output values in the Status displays of the OP.
For example, to override a digital output you must indicate “manual
override” in the field just in front of the displayed value:
A2: Fan status
SF_out _0
With the cursor in the position just to the left of the 0 value, use
or twice to toggle up the manual override indicator (
→).
Press to confirm and to move the cursor to the value itself. It is
now possible to change the value, a value that will override the value set
by the controller.
The override indicator will remain visible (for all access levels) until it
is reset to normal, automatic mode.
Network Variables (please refer to the TAC Menta User’s manual) can
also be overridden in this way.
5.8 Daylight Saving
TAC Xenta 280/300 has built-in support for the European standard daylight saving. However, the OP can be used to set other conditions.
To change the Daylight saving period, the following menu is used.
L2: DAYLIGHT SAVING
MODE: 1 HOURS: 1
FROM: MM:DD HH:MM
TO : MM:DD HH:MM
+
–
TAC Xenta, TAC Xenta OP 5 Dialogs with TAC Xenta 280/300/401
TAC AB, July 2007 39 (46)
04-00065-01-en
As long as MODE: is 1, the European standard changeover prevails
(one hour on the night before the last Sunday of March at 02:00 and
October at 03:00).
If MODE: is toggled to 2 the displayed (entered) values will govern the
changeover from/to the Daylight saving time.
MODE: equal to 0 means that there will be no change.
Press to move the cursor between the figures and use and
to change the values. When you are finished, press a last
time and leave the menu with .
If an AM/PM clock is used, the time is entered according to the instructions given in section 4.1
5.9 Log Off
If no changes have been made within 30 minutes, the operator will be
logged off and the access level returned to the default access level low.
Values that have been modified in the menu, but not “Entered”, will not
be saved at Log off.
+
–
Note
• During the first hour after the automatic changeover from daylight saving time (MODE:1, 03:00 to 02:00) you must not set the
time manually. Should this happen, the clock will once again
move back to 02:00 when the time reaches 03:00.
5 Dialogs with TAC Xenta 280/300/401 TAC Xenta, TAC Xenta OP
40 (46) TAC AB, July 2007
04-00065-01-en
TAC Xenta, TAC Xenta OP 6 Technical Data
TAC AB, July 2007 41 (46)
04-00065-01-en
6 Technical Data
Supply voltage (from TAC Xenta or external source)
.................................................................24 V AC ±20%, 50/60 Hz
..........................................................................or 24 (20–30) V DC
Power consumption
........................................................................................max 0,5 W
With the display backlight on, in total............................. max 1,2 W
Ambient temperature
Storage................................................................. –20 °C to +50 °C
Operating.................................................................. ±0 °C to 50 °C
Humidity.................................................max. 90% RH non-condensing
Display....................................................4×20 characters, alphanumeric
Mechanical:
Enclosure............................................................................ABS/PC
Dimensions (mm)...........................................................144×96×32
Weight....................................................................................0,4 kg
Panel cutout (mm)...........................................136 ± 0,5 x 91,5 ± 0,5
Enclosure rating
Hand-held panel.......................................................................IP 20
Network communication
Protocol............................................................FTT-10, LonTalk™
Communication speed.........................................................78 kbit/s
Unit connection
TAC Xenta 100............................via modular jack on Wall Module
TAC Xenta 280................................modular jack or screw terminal
TAC Xenta 300................................modular jack or screw terminal
TAC Xenta 401................................modular jack or screw terminal
Standards
Emission.......................................................................EN 50081-1
6 Technical Data TAC Xenta, TAC Xenta OP
42 (46) TAC AB, July 2007
04-00065-01-en
Immunity.......................................................................EN 50082-1
Part number
Operator terminal TAC Xenta OP..................................0-073-0907
Operator terminal TAC Xenta OP/RU...........................0-073-0923
Mounting kit panel TAC Xenta OP................................0-073-0904
TAC Xenta, TAC Xenta OP Index
TAC AB, July 2007 43 (46)
04-00065-01-en
Index
Numerics
24 hour clock 31
A
Access code 37
adjust contrast
15
adjust setpoints
15
adjust time channels
15
AM/PM clock
31
Ambient temperature
41
B
Bindable 23
C
Cable 16
Change a setpoint
32
change communication mode
21
communication
15
communication modes
27
Communication speed
41
configuration parameters
27
Configured
29
connecting
15
connecting the operator panel
16
connection of OP
13
contrast
17
Cyrillic characters
31
D
data communication 27
Daylight saving
38
Dimensions
41
Display
41
display
15
display - network variables
13
Display backlight
20
Display Light
20
Display test
19
Docnet
9
E
Enclosure rating 41
Exit service mode
21
F
Factory setting 24–25
H
handling display 13
hardware check
19
Hardware Tests
19
Holiday chart
36
Humidity
41
I
I/O modules 14
Initiate Service Pin Message
30
K
Keyboard test 19
L
Language 20
lighted
15
limited commissioning tool
27
list alarms
15
Local Functions
19
Log off
39
LON address
20
LonMaker
25
LonTalk status
20
M
Mechanical 41
menus of the operator panel
31
MetraVision
24
modular jack
16
modular socket
15–16
monitor status
15
N
National text 20
Network communication
41
Network Variables
13, 27
Node State
28
Index TAC Xenta, TAC Xenta OP
44 (46) TAC AB, July 2007
04-00065-01-en
O
OP Communication Mode 21
OP Mode
21
OP Service Menu
19
OP Service Menu - exiting
21
Operator panel
15
Overriding inputs/outputs
38
P
Part number 42
potentiometer
15
Power consumption
41
power supply
15–16
Protocol
41
push buttons
15
R
Reading/Checking NVs 29
S
screw terminals 15–16
service
27
Service menu
14
Service pin
20
service pin
17
Service Pin Message
30
Special cases
36
Standards
41
Supply voltage
41
SW version
20
System Information
20
system parameters
19
T
TAC Menta 31
TAC Xenta 100
27–28
TAC Xenta 280/300/400
21
TAC Xenta 300/3000
14
TAC Xenta OP
13, 15
Time channels
35
U
Unconfigured 29
Unit connection
41
W
Weight 41
X
Xenta 100 21
Xenta 100 mode
22
Copyright © 2007, TAC AB
All brand names, trademarks and registered trademarks are
the property of their respective owners. Information contained within this document is subject to changewithout notice. All rights reserved.
04-00065-01-en
Europe / Headquarters
Malmö, Sweden
+46 40 38 68 50
Americas
Dallas, TX
+1 972-323-1111
Asia-Pacific
Sydney, Australia
+61 2 9700 1555
www.tac.com
Last Manual Page
Loading...
