SZ DJI TECHNOLOGY 201309581 User Manual

PVT581

PHANTOM VISION

User Manual V1.00

Thank you for purchasing this DJI product. Please strictly follow these steps to use this product, including

PHANTOM VISION and DJI VISION App.

Please regularly check the web pageof PHANTOM VISIONat our websitewww.dji-innovations.com,

which is updated regularly. Product information, technical updates and manual corrections will be available on

this web page. Due to unforeseen changes or product upgrades, the information contained in this manual is

subject to change without notice.

This manual is only referenced for basic assembly and configuration; you can obtain more details and advanced

instructions when using the Assistant software or DJI VISION App. To assure you have the latest information,

please visit our website and download the latest manual and software.

If you have any problem that you cannot solve during usage, please contact your dealer.

Index

INDEX ............................................................................................................................. 2

DISCLAIMER &WARNING ................................................................................................ 3

BATTERY USAGE & CHARGING CAUTIONS..................................................................... 4

TRADEMARK .................................................................................................................. 5

IN THE BOX ..................................................................................................................... 5

REQUIRED ITEMS .......................................................................................................... 6

SYMBOL INSTRUCTION ................................................................................................... 6

ASSEMBLY ...................................................................................................................... 7

MOUNT THE PROPELLERS ......................................................................................................... 7

MOUNT THE RANGE EXTENDER ................................................................................................ 7

VIEW OF MOBILE PHONE MOUNT ............................................................................................. 7

MOUNT THE MOBILE DEVICE MOUNTING................................................................................... 7

BASIC USAGE .................................................................................................................. 8

BATTERY AND CHARGER KNOWLEDGE ........................................................................................ 8

BatteryCharge Procedure ............................................................................................... 8

Battery Usage Knowledge ............................................................

错误！未定义书签。

TRANSMITTERKNOWLEDGE ...................................................................................................... 9

View of Transmitter ........................................................................................................ 9

How to Power on the Transmitter .................................................................................. 9

Transmitter State Introduction ....................................................................................... 9

TransmitterOperation Mode ........................................................................................ 10

RANGE EXTENDERKNOWLEDGE ............................................................................................... 11

View of Range Extender ............................................................................................... 11

Function Description .................................................................................................... 11

How to Use the Range Extender ................................................................................... 11

How to Do the Camera &Range Extender &DJI App Rebind ........................................ 12

AIRCRAFT OF PHANTOM VISION KNOWLEDGE ....................................................................... 13

View of PHANTOM VISION (including aircraft and camera) ........................................ 13

Get the Aircraft Ready .................................................................................................. 13

Compass Calibration Procedures .................................................................................. 14

Failsafe Function .......................................................................................................... 16

Low Voltage Protection ................................................................................................ 17

CAMERAOF PHANTOM VISION KNOWLEDGE ......................................................................... 18

MainFunction Description ............................................................................................ 18

DJI VISION APP ............................................................................................................. 20

BEFORE USE ....................................................................................................................... 20

Downloadand Installation ............................................................................................ 20

Wi-Fi Network Selection ............................................................................................... 20

Register and Login ........................................................................................................ 20

Main Page .................................................................................................................... 21

CAMERA PAGE ..................................................................................................................... 22

Basic Usage .................................................................................................................. 22

Camera Settings ........................................................................................................... 24

ALBUM PAGE ...................................................................................................................... 26

Album inCamera SD Card ............................................................................................. 26

Album In mobile device ................................................................................................ 28

NEWS PAGE ........................................................................................................................ 29

SETTINGS PAGE .................................................................................................................... 30

APPENDIX ..................................................................................................................... 33

ASSISTANT SOFTWARE& MC/PMU FIRMWARE UPGRADE ........................................................... 33

AUTOPILOT SYSTEM LED DESCRIPTION ..................................................................................... 33

SPECIFICATION ..................................................................................................................... 34

WARNING .......................................................................................................................... 35

Disclaimer &Warning

Please read this disclaimer carefully before using the product. By using this product, you hereby

agree to this disclaimer and signify that you have read them fully. THIS PRODUCT IS NOT

SUITABLE FOR PEOPLE UNDER THE AGE OF 18.

Despite the built-in autopilot system and our efforts in making the control as safe as possible, we strongly

recommend users to remove all propellers when calibrating and setting parameters. Make sure all connections

are good, and keep children and animals away during firmware upgrade, system calibration and parameter setup.

DJI Innovations accepts no liability for damage(s) or injuries incurred directly or indirectly from the use of this

product in the following conditions:

1. Damage(s) or injuries incurred when users are drunk, taking drugs, drug anesthesia, dizziness, fatigue,

nausea and any other conditions no matter physically or mentally that could impair your ability.

2. Damage(s) or injuries caused by subjective intentional operations.Any mental damage compensation

caused by accident.

3. Failure to follow the guidance of the manual to assemble or operate.

4. Malfunctions caused by refit or replacement with non-DJI accessories and parts.

5. Damage(s) or injuries caused by using third party products or fake DJI products.

6. Damage(s) or injuries caused by mis-operation or subjective mis-judgment.

7. Damage(s) or injuries caused by mechanical failures due to erosion, aging.

8. Damage(s) or injuries caused by continued flying after low voltage protection alarm is triggered.

9. Damage(s) or injuries caused by knowingly flying the aircraft in abnormal condition (such as water, oil, soil,

sand and other unknown material ingress into the aircraft or the assembly is not completed, the main

components have obvious faults, obvious defect or missing accessories).

10. Damage(s) or injuries caused by flying in the following situations such as the aircraft in magnetic

interference area, radio interference area, government regulated no-fly zones or the pilot is in backlight,

blocked, fuzzy sight, and poor eyesight is not suitable for operating and other conditions not suitable for

operating.

11. Damage(s) or injuries caused by using in bad weather, such as a rainy day or windy (more than moderate

breeze), snow, hail, lightning, tornadoes, hurricanes etc.

12. Damage(s) or injuries caused when the aircraft is in the following situations: collision, fire, explosion, floods,

tsunamis, subsidence, ice trapped, avalanche, debris flow, landslide, earthquake, etc.

13. Damage(s) or injuries caused by infringement such as any data, audio or video material recorded by the use

of aircraft.

14. Damage(s) or injuries caused by the misuse of the battery, protection circuit, RC model and battery

chargers.

15. Other losses that are not covered by the scope of DJI Innovations liability

Battery Usage & Charging Cautions

1. Do not put the battery into water; store the battery in a cool and dry environment.

2. Only use the correctly specified batteries

3. Batteries must be kept out of the reach of children; if a child accidentally swallows the battery you should

immediately seek medical assistance.

4. Do not use or store the battery near fire.

5. Battery should be charged with proper standard charger.

6. Do not connect the battery reversed in positive and negative terminals in the charger or equipment.

7. Do not connect the battery directly to the wall plugs or vehicle-mounted socket.

8. Do not put the battery into a fire or heat the battery.

PHANTOMVISION X1

5.8GHz Transmitter X1

Range ExtenderX1

Propellers X3

mobile device MountingX1

Assistant Wrench X1

9. Do not let the battery terminals (+and-) touch together to cause short-circuit.

10. Do not transport or store the battery together with metal objects.

11. Do not hit or throw the battery.

12. Do not weld the battery terminals together.

13. Do not drive a nail in, hit with a hammer, or stomp on the battery.

14. Do not disassemble or alter the battery.

15. Do not use or store the battery in extreme heat environments, such as direct sunlight or in the car in hot

weather. Otherwise, the battery will overheat, may cause fire (or self-ignite), this will affect the performance

of the battery, shorten the service life of the battery.

16. Do not use the battery in strong electrostatic areas, otherwise the electronic protection may be damaged

which may cause a hazard.

17. If you get the battery electrolyte leakage into your eyes, don't rub, first wash your eyes with clean water

then seek medical assistance immediately. If not handled in a timely manner, eyes could be damaged.

18. Do not use the battery when it emits an odour, high temperature, deformation, change in colour or other

abnormal phenomena; if the battery is in use or charging, you should stop charging or using immediately.

19. If the battery terminal gets dirty, please clean it with a dry cloth before using. Otherwise it will cause a poor

contact, thus causing energy loss or inability to charge.

20. Discarded battery could lead to a fire; you should completely discharge the battery and wrap the output

terminal with insulating tape before discarding.

Trademark

DJI and PHANTOM VISION are registered trademarks of DJI Innovations. Names of product, brand, etc., appearing

in this manual are trademarks or registered trademarks of their respective owner companies. This product and

reproduced in any form without the prior written consent or authorization of DJI Innovations. No patent liability

is assumed with respect to the use of the product or information contained herein.

In the Box

Battery X8

ChargerX1

Cable X2

Screw X10

AC Adapter X3

Accessories Box X1

Required Items

Phillips Screwdriver x1

5# AA Batteries x4

Micro-SD Card

Forbidden(Important)

Cautions

Tip Reference

Symbol Instruction

Assembly

For Mobile Phone Fixing

For Screw Fixing

Mount the propellers

Mount the Range Extender

View of Mobile Phone Mount

Mount the Mobile Device Mounting

Basic Usage

Charger Status LED Charging

Charge complete

Battery and Charger Knowledge

BatteryCharge Procedure

1. Connect the battery to the charger.

2. Connect the charger to a wall socket AC.

3. You can use the Charger Status LED to figure out the changing status.

TransmitterKnowledge

Front View

Antenna

Carrying Handle

Switch(S1: Control Mode: GPS/ATTI/ATTI)

Switch(S2: IOC Mode: OFF/CL/HL)

Stick(J1: Roll, J2: Pitch)

Stick(J3: Throttle, J4: Yaw)

Neck Strap Attachment

Power Switch

Power LED

Battery Compartment (On the back)

Transmitter State

Introduction

Low-battery Alert (Need to change the battery)

BB…………

Linking between the Transmitter and the Receiver

Normal Operation

7 8 9

(J1)

(J2)

(J3)

(J4 )

S2 OFF

S1 GPS

View of Transmitter

How to Power on the Transmitter

1. Install the 5# Batteries

2. Put the Switch S1 to the GPS stop and the S2 to the OFF stop, and then turn on the power switch.

Transmitter State Introduction

TransmitterOperation Mode

Transmitter

(Mode 2)

Aircraft

（ is the nose direction）

Operation Mode details

The throttle stick is for aircraft up& down control.

The aircraft will hold the height automatically if the stick is

centered. You should Push the throttle stick to the neutral

position to take-off.

The yaw stick is for aircraft rudder control.

The command stick controls the angular velocity of the

aircraft, with the maximum rudder angular velocity of

200°/s. The left stick command gives counter clock-wise

rotation of the aircraft, & vice versa.

The roll stick is for aircraft left/right control and pitch stick

is for front/back control. The command stick controls the

angle of aircraft.The stick neutral position is for 0˚, its

endpoint is 35˚. The roll and pitch sticks return to the central

position when released.

 In GPS Mode, the aircraft will hover (hold horizontal

position) when sticks released.

 In ATTI. Mode, the aircraft will keep attitude stabilizing

without horizontal position (different from hover in GPS

Mode).

GPS ATTI. ATTI. ATTI.

(Manual or

Failsafe is

selectable

software.)

3-position switch (S1) on the Transmitter for mode control.

Only after Compass Module connection and Compass

calibration, GPS ATTI. Mode is available. Otherwise, all

switch positions are for ATTI. Mode. Pay attention because

the GPS ATTI. Mode is dependent on the number of

GPSsatellites acquired by the main controller. Refer to the

LED Indicator. When GPS signal has been lost for 3s, system

enters ATTI. Mode automatically. You can enable the Manual

Mode or FailSafe (also known as One-key Go-home) in the

assistant software->Basic->R/C->Control Mode.

OFF Course Lock Home Lock

3-position switch (S2) on the Transmitter for Intelligent

Orientation Control (IOC). Set the switch to OFF in basic

flight.This function is defaulted to off. If you want to use this

function refer to the advanced manual, and enable it in the

assistant software. Use IOC when you are familiar with basic

flight.

Definitions

 Stick neutral position and stick released means the stick of Transmitter is pushed to the central position.  Command Stick means the stick of Transmitter is pushed away from the central position.

Range ExtenderKnowledge

Front View Right View

System LED

Power LED

Screw for Fixing

Mount Slot

Power Switch

USB Charging Port

Rebinding Button

Wifi Indicator

Description

Green blink

The Range Extender system is working normally.

LED Off

The Range Extender system is working

abnormally.

Power Status Indicator

Description

Green Solid on

The Range Extender is working

normally.

Red Solid on

Low voltage alert.

Yellow Solid on

The Range Extender is charging.

6 7

1 2

3 4

OFF

View of Range Extender

Function Description

① System LED

② Power LED

③Screw for Fixing

④Mount Slot:For mounting the Range Extender on the right side of Transmitter Carrying Handle.

⑤Switch: (1) OFF – Power off

(2)ON –Power on

⑥ USB Port: For charge the Range Extender.

⑦Rebind Button: Press to rebind system.

How to Use the Range Extender

1. Turn the Power Switch of Range Extender to ON stop.

+ 25 hidden pages

SZ DJI TECHNOLOGY 201309581 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
