Welcome
Thank you for purchasing the new Stand Fan SY-VLR16. Please read this manual carefully
before operating your product and pay close attention to the precautions, which are
mentioned below. Store this user manual in a safe place for future reference
For your safety
WARNING To reduce the risk for fire, electric shock or personal injury
Do not use this fan with any solid-state speed control device.
•
Unplug the fan before cleaning or servicing.
•
If you disassemble your fan, completely re-assemble before plugging into outlet.
•
To reduce the risk of electric shock and injury to persons, do not use in window.
•
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
This fan is for residential use only. It is not intended for use in commercial or industrial
settings.
Page 3
Important instructions
Read and save these important safety
instructions before using this fan, when
using electrical appliances, basic safety
precautions should always be followed
including the following:
WARNING - To reduce the risk of fire or
electrical shock, do not use this product
with any solid state speed control device.
To reduce the risk of fire or electric shock
and injury to persons, do not use in a
window.
-
Use this fan only as described in this
manual. Other uses not recommended
may cause fire or electric shock.
-
This product is intended for
HOUSEHOLD USE ONLY and not for
commercial, industrial or outside use. To
protect against electrical shock, do not
place fan in window, immerse unit, plug
or cord in water, or spray with liquids.
-
Unplug the fan from the outlet when not
in use, when moving fan from one
location to another and before cleaning.
-
Do not operate the fan in the presence
of explosive and/or flammable fumes.
-
Do not place the fan or any parts near
an open flame, cooking or other heating
appliance.
-
Avoid contact with moving fan parts.
-
To disconnect, grip the plug and pull it
from the wall outlet. Never yank the
cord.
-
The use of attachments is not
recommended and may cause hazards.
-
Always use on a dry, level surface.
-
Do not operate if the fan housing is
removed or damaged.
-
Do not operate any fan with a damaged
cord or plug.
-
Discard fan or return to an authorized
service facility for examination and/or
repair.
-
Do not run cord under carpeting. Do
not cover cord with throw rugs, runners,
or similar coverings. Do not route cord
under furniture or appliances.
-
Arrange cord away from traffic area and
where it will not be tripped over.
-
The appliance is not to be used by
persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction.
-
Children being supervised not to play
with the appliance.
-
This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved.
-
Children shall not play with the
appliance.
-
Cleaning and user maintenance shall
not be made by children without
supervision.
Assembly
1. Place the base on a flat
surface. Remove the
locking mechanism from
the pole and insert the pole
onto the base.
2. Turn over the base with the
pole inserted and secure
by turning the locking
mechanism clockwise until completed
fastened.
3. Place the motor assembly and
control panel onto the extension pole
and secure by turning the assembly
knob clockwise.
4. Remove the rear grill-mounting nut
by turning it counter-clockwise.
3
Page 4
5. Place the rear grill onto the motor
housing aligning the 3 raised knobs on
the top of the motor
housing with the 3
holes on the grill.
6. Place the rear grillmounting nut and
tighten turning
clockwise.
7. Align the blade onto
the shaft and secure it
by tightening the blade
knob counterclockwise.
8. Properly align the front
grill with the rear grill. Raise the built-
in clips around the grill
and fasten them to
secure the grill.
9. Secure further by
turning the grill screw
clockwise to fasten.
How to operate
1. Make sure that the fan is on a firm,
level surface.
2. Making sure the speed control is at
OFF position.
3. Plug the power cord into the socket.
4. The speed of the fan can be selected
by buttons on the control panel.
Off (0), Low (1), Med (2), High (3)
5. Oscillation can be activated by pushing
the bar downward and the fan can be
made to operate in a stationary position
by gently pulling the knob.
Cleaning
1. Be sure your fan is in the OFF position.
2. Unplug the fan before cleaning.
3. Use only a soft, damp cloth to gently
wipe the fan.
4. Do not immerse the fan in water and
never allow water to enter the Motor
Housing.
5. Do not use gasoline, paint thinner or
other chemicals to clean the fan.
Removal of front grill for cleaning
1. To access the fan blade, remove the
front grill and securing screw.
2. Clean the fan blade, front and rear
grills with a soft, moist cloth.
3. Replace blade, tighten securing screw
and securely fasten the front grill.
4
Page 5
P 38 W
Description of parts
1. Brand Plate
2. Brand Plate Screws
3. Front grill
4. Blade knob
5. Blade
6. Rear grill mounting nut
7. Rear grill
8. Shaft
9. Oscillating pin
10. Motor assembly
11. Neck
12. Control panel
13. Assembly knob
14. Pole
15. Height adjuster
16. Base
17. Locking mechanism
18. Grill screw
Conforms to all relevant
European Directives.
Maximum fan flow
rate
Fan Power input
Service Value
Standby power
consumption
Fan sound power
level
Maximum air
velocity
F 42.15 m3/min
SV 1.11
P
SB
L
WA
c 2.76
0
53.6
(m3/min
)/W
W
dB(A)
m/sec
5
Page 6
Declaration of Conformity
Manufacturer Name: Satyatrade S. L.
Address: Pol.Ind.La Raya. C/ Guadalquivir,2
Camarma de Esteruelas, 28816 Madrid
Tel: 902 430 967
Fax: 91 8864285
NIF: B83254763
Manufacturing country: China
Description: Stand Fan
Sytech® SY-VLR16 complies with the
following directives:
EMC Standard: Directive 2014/30/EU
LVD Standard: Directive 2014/35/EU
Rohs Standard: 2011/65/EU Restriction of
hazardous substances
Signed: Ajeet Nebhwani Utamchandani
Sole Administrator
