SY-TS15
2 SLICE TOASTER
Page 2
Welcome
Dear Customer,
Welcome to Sytech! Thank you for purchasing the Bread Toaster SY-TS15. Please read this
manual carefully before operating your product and pay close attention to the precautions which
are mentioned below. Store this user manual in a safe place for future reference. We are sure
that this new Bread Toaster will sati sfy your needs.
Specifications
Product: 2 slice bread Toaster
Model: SY-TS15
Voltage: AC220-240V / 50Hz / 750W.
Weight: 0.9 Kg
Dimensions: 30 x 16.8 x 18 cm.
Important safeguards
z This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
z Children should be supervised to ensure that they do not play with the appliance.
z Before using, ensure the voltage of your power supply is the same as that indicated in the
instruction manual, only connect appliance to alternating current to a correctly installed
earthed socket, cord and plug must be completely dry.
z Do not leave the appliance unattended during use.
z Do not pull the connection cord over sharp edges; keep the cord away from heat and oil for
protection.
z Do not place the appliance on hot surfaces or near it.
z Do not pull the plug out by the cord or pull it out of the socket with wet hands.
z If the following happens, please unplug the appliance to disconnect the power supply.
--The appliance or cord has been damaged.
--The appliance is dropped accidentally or any defect is susp ected.
z Before switching on, ensure the slices of bread do not get jammed in the toaster slots.
However, if this happens, unplug the appliance first and then take out the jammed bread
slice.
z Caution: In the event of burning the bread, the appliance may become too hot. Never
touch the toaster at this time.
z Note the housing of the toaster will become very hot when using, especially in the area of
the toaster slots. Please be careful not to be burned. Please only use the control knob,
lever and button for operation.
z Do not insert your fingers or metal objects like knives or forks into the bread slots.
z Only use the appliance when it is horizontally placed on a suitable surface.
z Do not toast the bread with wrapped aluminum foil.
z Do not cover the bread slots while in operation.
z Never put bread slices or bread roll into the bread slots directly, as this may cause
overheating.
z Unplug the appliance before cleaning and maintaining.
z Do not immerse the appliance into water or other liquid.
z Your appliance must never be switched on through an external timer or any kind of
separate remote control system.
z Improper use or repair may cause a risk of danger. In case of misuse or incorrect handling
or repair, no li ability will be taken for possible damages.
z The appliance is only designed for indoors using, not for outdoors using.
z Should the cord be damaged, to avoid danger, it should be replaced by the qualified
technician of service agency or its authorized service agency.
z Do not put the appliance on or near the gas cooker, electrothemal elements or hot plate as
well as other electric appliances.
Page 3
z Keep the appliance away from wall, curtain and other combustible material during use.
Instructions for Use
1) General description
1. Lever
Push down to start working
2. Stop button
Push to cancel heating process
3. Defrost button
4. Reheat button
5. Timer set / browning control
Higher number for darker browning
6. Reheat Indicator
7. Defrost Indicator
8. Power ON/OFF
9. Crumb Tray
2) Selecting the browning level
Grades Bread type
1-3 Thin bread slice
3-5 General bread
5-6 Frozen bread
3) How to use the appliance
Set the control knob to the suitable position, put the bread slice into the toast slots and
press the lever down , the heating process will begin. As soon as the toasting cycle is
completed (that is, the bread has been exactly browned as preset.), the slices of bread will
automatically be ejected.
Suggestion:
When using it for the first time, it is recommended to on the appliance without bread, set the
control knob to grade 3 and push the lever down to begin the heating process. At this time, the
appliance will emit some smoke. This is normal behavior of the appliance. It is recommended to
have a good ventilation of air. After the first heating, let it cool down naturally before using it
again.
Page 4
Cleaning
Before cleaning, switch off and unplug the appliance and have it cool down.
Remove the crumbs from the browning slots and grids with the appliance not tilted.
Then, open the door, clean away the crumbs and put the door back to the appliance.
Clean away crumbs from toaster.
Remove the crumbs from the bread slots and grids. Then, slide out the tray, clean it and
put it again into the appliance.
Outside cleaning:
Clean the outside of the appliance gently with a damp and soft cloth, and then wipe it with a
dry cloth. Never use steel wire, abrasive cloth or other caustic cleaning agents, as they will
damage the finish of the appliance.
Maintenance
Do not dismantle the appliance or change the cord by yourself. If there is any problem
with the appliance, please have it adjusted or repaired by Sytech Technical service
center.
During use, if any defect of the appliance is suspected, please take it to the official
service department or its authorized service repair center. The product will be checked
by a qualified engineer who will make sure the appliance can be used safely or not.
Declaration of Conformity
Manufacturer Name: Satyatrade S. L.
Address: Pol.Ind.La Raya. C/ Guadalquivir, 2.
Camarma de Esteruelas, 28816 Madrid
Tel: 902 430 967
Fax: 91 8864285
NIF: B83254763
Manufacturing country: China
Description: Bread Toaster
Sytech® SY-TS15 complies with the following directives:
EMC Standa rd: Directive 2004/108 CE
L V D Standard: Directive 2006/95/CE
ROHS St andard: 201 1/65/EU Restriction of Hazardous Substances
Signed: Ajeet Nebhwani Utamchandani
Sole Administrator
