Sytech SY-PWC13 User Manual

Quick guide

Technical specifications:

• Battery capacity: 13000mAh

• Output: 4 outputs, each output 5V / 1.2A, max. 5V / 4.8A

• Input voltage AC 220V CC: 5V / 2A

• Micro USB input CC: 5V / 2A

• Short circuit protection

• Over current protection

• Over voltage protection

• Over charge protection

(1) Output socket
(2) Micro USB input socket
(3) DC Input socket
(4) Anti-theft lock socket

(1)

(2)

(3)

(4)

Charging the Power Bank (or external battery)

There are 2 possibilities of charging the Power Bank:
a) Connect the power bank to your PC using the 5 pin micro USB
cable (supplied) or use an external charger (AC 220V). The blue
charging LED light will start to flash indicating the charging process
is currently in progress. Once the charging process is completed,
the 4 blue charging lights will stop flashing and will remain on.
b) Connect the power bank to an external charger (AC 220V), DC
5V.2A (not supplied).

Charging an external device (Mobile, Tablet)

According to the device you need to charge, select the appropriate
cable and connect it to the USB socket of the Power bank. Once
connected, the Power bank will start charging the external device
and blue LED Charging lights as well as the USB ports LED lights
will turn on.
Once the external device is fully charged, the Power bank will
automatically stop. The red LED light of the charging socket as well
as the 3 remaining LED lights of the USB sockets will start to flash
and only the blue charging indicator light will be on.
If the USB cable is disconnected from the USB socket and all 4

sockets are free, the power bank will automatically off and the 4 LED
lights located on the USB sockets will stop lighting and after 60
seconds, the power bank will off completely.

Indicator light

There are 4 indication LED lights, each are equivalent to 25%of the
total battery capacity.

Anti-theft lock

The Power Coffee includes and Anti-theft lock accessory to prevent
anyone stealing it. Adjust it to any table or any fixed equipment.
Keep the key in a safe place.

Declaration of Conformity

Manufacturer Name: Satyatrade S. L.
Address: Pol.Ind.La Raya. C/ Guadalquivir, 2.
Camarma de Esteruelas, 28816 Madrid
Tel: [phone]
Fax: [phone]
NIF: B83254763
Manufacturing country: China
Description: Power Pack
Sytech® SY-PWC13 complies with the following directives:

CE Standard: EMC Directive 2014/30EU

ROHS Standard: 2011/65/EU Restriction of Hazardous Substances

Signed: Ajeet Nebhwani Utamchandani
Sole Administrator
