Sytech SY-1536BT User Manual

Welcome

Thank you for having purchased the new Sytech Bluetooth FM Transmitter SY-1536BT. For a proper use of this
product, please read this instruction manual carefully. In order to avoid damage or personal injuries, always
follow the safety instructions given in this user manual.

Package contents

 Bluetooth device
 IR Remote
 User Guide

Compatibility:

This device can be paired as a hands free kit with any compatible Bluetooth 2.1 or higher enabled devices.

Safety Precautions

Please read all safety instruction warnings carefully before using this product. Improper use of this product may
result in damage to this or attached products.

1. To ensure the products work well, please never use this in the following conditions:
a. Moist or underwater conditions.
b. Conditions near heater or high-temperature places.
c. Conditions with direct and strong sunshine,

2. Never dismantle the product without due permission, otherwise it may void the warranty clause.

3. This product contains dual USB outputs. It can charge two devices at the same time with the maximum

output of 5V/3.4A. Note: When charging two mobile phones of 1A, both ports will work. When charging one
tablet of 2.4A, all the power will be used from one USB port only.

4. Never turn the volume too loud (generally at 28 or below) when FM is working in order to avoid sound

distortion. Please adjust the sound volume through the car audio.

5. A built-in antenna is provided for the product, so please avoid using a frequency with strong signal in order

to get a better sound quality.

6. The Bluetooth operating functions may vary according to the mobile phone being used.

7. Some phones may not support automatic connection if they are powered on after the power failure. If so,

please connect them manually.

8. This product is compatible with more than 95% phones on the market but some are still incompatible.

Please pay attention to it when purchasing our product.

9. The volume should be proper during the call to avoid affecting the other party.

10. Avoid dropping the product to prevent damage to the surface or the body.

Using the FM Transmitter function:

1. Plug the FM transmitter into your vehicle’s cigarette lighter or power port.

2. Tune your radio to an unused FM frequency and then tune the device to the same frequency.

3. Insert a Micro SD card or a USB disk that contains MP3 files into the card/USB slot (please check above

image). Playback will commence automatically when the USB is plugged in.

4. You may also charge your mobile phone or any other electronic device, using one of the USB ports providing

they comply with the max voltage.

5. Follow the pics below to control your music easily.

Using the Bluetooth function:

1. When using Bluetooth for the first time, you need to pair your mobile phone with this unit. Activate your

mobile phone's Bluetooth function, then search for the device as SY-1536BT. When the mobile phone detects
this unit, please pair and connect using the default password "0000"

2. While in music playback mode, you receive an incoming call, the unit will automatically switch to the

telephone mode and will enter into hands free mode.

Bluetooth calling

1. Please press to answer an incoming call.

2. Please press to end a call.

3. Press twice to dial the last Number automatically.

4. When making a call, you can only dial the phone number through your mobile phone. However, once the call

is connected, you can use the hands free function.

Remote controller:

Most of the functions can be fulfilled by the remote controller provided.

Operation Guide On FM transmitter On Remote Controller

1. Answer / hang up
the call:

Press : answer the call

Press : end the call

Press ” ” button

2. Play and Pause
the music:

Press Button: Play the music

Press again: Pause playing

Press “ “ Button

3. Adjust the
Volume:

Rotate clockwise and hold for a few
seconds to increase the Volume
Rotate anticlockwise and hold for a few
seconds to decrease the Volume

Press “Vol+” to increase the
Volume；
Press “Vol-” to decrease the
Volume；

4.Set the
frequency:

Press and hold till Frequency starts
to flash, then

Rotate clockwise to increase the
frequency
Rotate anticlockwise to decrease the
frequency

Press “CH+” button: Increase by

0.1MHz
Press “CH-” button: decrease by

0.1MHz
Or press the numbers of the
frequency directly using the
numerical keypad, press “CH+” to
confirm.

5. Select music:

Rotate clockwise to Play the next song
Rotate anticlockwise to Play the previous
song

Press the button: Play the next
song; Press the button: Play the
previous song;
Or press the number of the song on
the numerical keypad and then
press to confirm

6. Choose EQ: Supported by remote controller only

Press the “EQ” button to choose
your favorite EQ

8. Switch folder: Supported by remote controller only

Press the "folder" button to switch
folder

Specifications

FM Transmitter with Bluetooth Function
Hands free function with Bluetooth technology.
Built-in Microphone
Retro illuminated LED Display
Auxiliary connection for connecting sources of external audio. (MP3, Discman.)
Double USB port that allows you to charge other electronic devices
Micro SD card slot
Includes Remote Controller
Transmission Edit distance :> 10m.
Bluetooth version: JL IC V2.1
Bluetooth Protocol: AVRCP, HFP, A2DP
Frequency range: 87.5-108.0MHZ
Frequency stability: ±10ppml
Product Input: 12-24V
Music Format: MP3, WMA
USB (Max capacity): 32GB
Charger output: 5V/3.4A
Size of Screen: 20*8*4mm (yellow digits)

Declaration of Conformity

Manufacturer Name: Satyatrade S. L.
Address: Pol.Ind.La Raya. C/ Guadalquivir, 2.
Camarma de Esteruelas, 28816 Madrid
Tel: [phone]
Fax: [phone]
NIF: B83254763
Manufacturing country: China
Description: Bluetooth FM transmitter
Sytech® SY-1536BT complies with the following directives:

R&TTE Standard: Directive 2014/53/EU
ROHS Standard: Directive 2011/65/EU Restriction of Hazardous Substances

Signed: Ajeet Nebhwani Utamchandani
Sole Administrator
