3. INTRODUCTION

The SPLIT-AHU Kit 0-10V LNS control module enables to control Single- or

Multisplit outdoor units with L, N, S communication. It allows to control
outdoor unit capacity as well as operation mode (heating or cooling) of an air

handling unit or a DX coil.

The control module enables to control inverter outdoor unit capacity between
0 - 10 % ~ 100 % by external input 0 ~ 10 VDC signal.

Dry contact signal is used to control outdoor unit to work in cooling or

heating mode.
SPLIT-AHU Kit 0-10V LNS have a temperature sensor and provide evaporator

froze protection.

The installation and operation of outdoor unit as well as controller must

be done according to the manuals (i.e. User’s manual, Installation manual,

Technical Specication, Service manual).

4. SPECIFICATION AND PACKING LIST

Model SPLIT-AHU Kit 0-10V LNS

Casing Plastic
Dimension (h x w x d) 61 x 100 x 191 mm

Weight approx 0.4 kg
Operation Temperature Range -25 °C... +45 °C

Operation Humidity Range 40 - 90 %
Power Supply 230 VAC, 1 Phase, 50/60 Hz
Voltage Range 208 - 240 V

Fuse 15 A, 250 V
Resistance class IP54

Packing list

Box body 1 piece
Box cover 1 piece

Anti-water seal between box

body and box cover
Temp sensor 1 piece

Gland 3 pieces
Manual 1 piece

1 piece

5 I Installation and Operating Manual

5. SYSTEM DESIGN

Single-Split

Depending on the Outdoor Unit used, up to 5 Indoor Units can be connected.

REFRIGERANT PIPES

LNS communication with
outdoor unit

Power supply

T2 SENSOR

SPLIT-AHU Kit
0-10V LNS

HEATING

0-10V

COOLING

Power supply

ALARM

DEFROST

6 I Installation and Operating Manual

Air Handling Unit 1

Multi-Split

Depending on the Outdoor Unit used, up to 5 Indoor Units can be connected.

Power supply

Power supply

REFRIGERANT PIPES

LNS communication with
outdoor unit

REFRIGERANT PIPES

LNS communication with
outdoor unit

T2 SENSOR

T2 SENSOR

SPLIT-AHU Kit
0-10V LNS

HEATING

0-10V

SPLIT-AHU Kit
0-10V LNS

HEATING

0-10V

COOLING

COOLING

DEFROST

DEFROST

ALARM

Power supply

ALARM

Air Handling Unit 2

7 I Installation and Operating Manual

Multi-Split

Depending on the Outdoor Unit used, up to 5 Indoor Units can be connected

Power supply

Power supply

T2 SENSOR

SPLIT-AHU Kit
0-10V LNS

HEATING

0-10V

COOLING

ALARM

DEFROST

LNS communication with
outdoor unit

REFRIGERANT PIPES

LNS communication with
indoor unit

REFRIGERANT PIPES

Indoor unit for SYSPLIT MULTI

(any Indoor Unit available for SYSPLIT MULTI can be connected)

Air Handling Unit

8 I Installation and Operating Manual

6. FUNCTION AND SETTING

HEAT

COOL

DEF.

ENC1

TE MP 1

T2 Evaporator
Coil Temp
Sensor

CN2

0-10VDC
INPUT

10V 0

COOLHEAT

COOLING

HEATING

MODE

MODE

INPUT

INPUT

POWER

T2A/250VAC
LNS

POWER SUPPLY
&
COMMUNICATION

240VAC

208
FUSE:T2A 250VAC

/

ALARM DEFROST

ALARM

DEFORST

OUTPUT

OUTPUT
max.

max.

5A

5A

250VAC;

250VAC;

5A

5A

30VDC

30VDC

CN1

Recommended Cable

Cabling Typ of cable

Power supply & communication L, N, S
(between Outdoor Unit and SPLIT-AHU Kit 0-10V LNS)

Communication Line
(between Air Handling Unit and SPLIT-AHU Kit 0-10V LNS)

3 x 1,5 mm²

LIYY

10 x 0,25 mm²
LIYY

NOTE

» Cable selection in accordance with the local regulations.
» No low-voltage conductors and high-voltage conductors together in one

cable.

9 I Installation and Operating Manual

Connection Terminal Introduction:
L, N, S Power supply and communication with outdoor unit connection

ALARM Digital output 5A - 250 VAC or 5A-30 VDC. When outdoor unit has

DEFROST Digital output 5A - 250 VAC or 5A-30 VDC. When outdoor unit is in

TEMP1 Terminal for temperature sensors. The temperature sensor must be

0 - 10V Analog input terminal to control outdoor unit capacity.

Pay attention to the polarity 0/- and 10/+

Capacity steps:

0 - 0.5 V 0% (unit stopped)

0.5 - 1.5 V 10 % capacity (LED display digit 1)

1.5 - 2.5 V 20 % capacity (LED display digit 2)

...

9.5 - 10.5 V 100% capacity (LED display digit 10)

terminal 230 V, 1-phase, 50/60 Hz.

malfunction signal is activated.

defrost mode, signal is activated

placed at middle of heat exchanger.

Warning! Signal input cannot exceed 10.5 V DC, otherwise it may destroy

COOL Digital input. When terminals are closed, the unit is running in

HEAT Digital input. When terminals are closed, the unit is running in

Note: Heating mode has priority. If both COOL and HEAT terminals are

this control module.

cooling mode and „COOL“ LED is on.

heating mode and „HEAT“ LED is on.

closed, unit will run in HEAT mode.

When there are different operating mode among active indoor

units, the system will operate as follow:

- Heating mode will have the priority.

- Cooling mode and Fan mode will conict to Heating mode.

10 I Installation and Operating Manual

ENC1 Knob for multi split connection to select indoor unit capacity. This knob

is for multi indoor units connection only. This knob will not work at one

indoor to one outdoor connection.

Knob selection Indoor unit capacity Reference Code (Indoor unit)*

0 2,0 kW unit 09

1 2,6 kW unit 09

2 3,2 kW unit 12

3 3,5 kW unit 12

4 5,3 kW unit 18

5 7,1 kW unit 24

6 7,1 kW unit 24

7 9,0 kW unit 30

8 10,5 kW unit 36

9 14,0 kW unit 48

A-F 16,0 kW unit 60

* The reference (Indoor unit) value is used exclusively to determine the

possible combination.

For combination exceeding 100%, the cooling and heating capacities
of each indoor units will be proportionally reduced.

LED lamps introduction:

HEAT LED is lightened when the unit is operating in heating mode.
COOL LED is lightened when the unit is operating in cooling mode
DEF LED is lightened when unit is in defrost mode.

11 I Installation and Operating Manual

7. TECHNICAL FEATURES

Model
SYSPLIT

Art. no. Outdoor unit 315813 315814 315864 315865

Refrigerant/Charged quantity

Power supply V-Ph-Hz 220-240/1/50-60

Cooling capacity kW 5,28 7,91 10,55 12,31

Power consumption W 1800 2470 3600 3830

Operating current A 7,8 10,7 16,5 17,4

EER 3,01 3,22 2,93 3,21

Heating capacity kW 5,57 8,21 10,55 12,31

Power consumption W 1550 2350 3000 3400

Operating current A 6,7 10,2 13,73 15,5

COP 3,59 3,49 3,52 3,62

MULTI2 18

EVO32 HP Q

kg R32 / 1,3 R32 / 1,57 R32 / 2,1 R32 / 2,4

MULTI3 27

EVO32 HP Q

MULTI4 36

EVO32 HP Q

MULTI5 42

EVO32 HP Q

Nominal conditions

Indoor unit Outdoor unit Piping length Level difference

Cooling mode

Heating mode

27°C DB, 19°C WB

20°C DB, 19°C WB

35°C DB 5 m 0 m

7°C DB, 6°C WB 5 m 0 m

12 I Installation and Operating Manual

Combination possibilities

SYSPLIT MULTI2 18 EVO32 HP Q

Nr. of unit

One Unit

Two Unit

Indoor
Units

9 9 ­12 12 -

18 18 ­9+9 9 9
9+12 9 12
9+18 9 18
12+12 12 12

SYSPLIT MULTI3 27 EVO32 HP Q

Nr. of unit

One Unit

Two Unit

Three Unit

Indoor
Units

9 9 - ­12 12 - -

18 18 - ­9+9 9 9 ­9+12 9 12 ­9+18 9 18 ­12+12 12 12 ­12+18 12 18 ­9+9+9 9 9 9

9+9+12 9 9 12
9+12+12 9 12 12
12+12+12 12 12 12

Combinations

Unit A Unit B

Combinations

Unit A Unit B Unit C

For combination exceeding 100%, the cooling and heating capacities of each
indoor units will be proportinally reduced.

13 I Installation and Operating Manual

SYSPLIT MULTI4 36 EVO32 HP Q

Nr. of unit Indoor Units

9 9 - - -

One Unit

Two Unit

Three Unit

Four Unit

12 12 - - -

18 18 - - -

24 24 - - -

9+9 9 9 - -

9+12 9 12 - -

9+18 9 18 - -

9+24 9 24 - -

12+12 12 12 - -

12+18 12 18 - ­12+24 12 24 - ­18+18 18 18 - ­9+9+9 9 9 9 ­9+9+12 9 9 12 ­9+9+18 9 9 18 ­9+9+24 9 9 24 ­9+12+12 9 12 12 ­9+12+18 9 12 18 ­9+12+24 9 12 24 ­9+18+18 9 18 18 ­12+12+12 12 12 12 ­12+12+18 12 12 18 ­12+12+24 12 12 24 ­12+18+18 12 18 18 ­9+9+9+9 9 9 9 9
9+9+9+12 9 9 9 12
9+9+9+18 9 9 9 18
9+9+12+12 9 9 12 12
9+9+12+18 9 9 12 18
9+12+12+12 9 12 12 12
9+12+12+18 9 12 12 18
12+12+12+12 12 12 12 12

Combinations

Unit A Unit B Unit C Unit D

14 I Installation and Operating Manual

SYSPLIT MULTI5 36 EVO42 HP Q

Nr. of unit Indoor Units

9 9 - - - -

One Unit

Two Unit

Three Unit

12 12 - - - ­18 18 - - - ­24 24 - - - -

9+9 9 9 - - ­9+12 9 12 - - ­9+18 9 18 - - ­9+24 9 24 - - -

12+12 12 12 - - ­12+18 12 18 - - ­12+24 12 24 - - ­18+18 18 18 - - ­18+24 18 24 - - -

9+9+9 9 9 9 - ­9+9+12 9 9 12 - ­9+9+18 9 9 18 - ­9+9+24 9 9 24 - -

9+12+12 9 12 12 - -
9+12+18 9 12 18 - ­9+12+24 9 12 24 - -

9+18+18 9 18 18 - ­12+12+12 12 12 12 - ­12+12+18 12 12 18 - ­12+12+24 12 12 24 - ­12+18+18 12 18 18 - ­12+18+24 12 18 24 - ­18+18+18 18 18 18 - -

Unit A Unit B Unit C Unit D Unit E

Combinations

15 I Installation and Operating Manual

SYSPLIT MULTI5 36 EVO42 HP Q

Nr. of unit Indoor Units

9+9+9+9 9 9 9 9 ­9+9+9+12 9 9 9 12 ­9+9+9+18 9 9 9 18 ­9+9+9+24 9 9 9 24 ­9+9+12+12 9 9 12 12 ­9+9+12+18 9 9 12 18 -

Four Unit

Five Unit

9+9+12+24 9 9 12 24 ­9+9+18+18 9 9 18 18 ­9+12+12+12 9 12 12 12 ­9+12+12+18 9 12 12 18 ­9+12+12+24 9 12 12 24 ­9+12+18+18 9 12 18 18 ­12+12+12+12 12 12 12 12 ­12+12+12+18 12 12 12 18 ­9+9+9+9+9 9 9 9 9 9
9+9+9+9+12 9 9 9 9 12
9+9+9+9+18 9 9 9 9 18
9+9+9+12+12 9 9 9 12 12
9+9+9+12+18 9 9 9 12 18
9+9+12+12+12 9 9 12 12 12
9+12+12+12+12 9 12 12 12 12

Unit A Unit B Unit C Unit D Unit E

Combinations

16 I Installation and Operating Manual

8. MALFUNCTION, ERROR CODE AND SOLVING STEPS

Error Code Malfunction or Protection

E1 communication error with outdoor unit

E5 evaporator coil temperature sensor T2 malfunction

F0 current overload protection

F1 outdoor unit ambient temperature sensor T4 malfunction

F2 outdoor unit condenser pipe temperature sensor T3 malfunction

F3

F4 outdoor unit EEPROM parameter error

F5 outdoor unit fan speed is operating outside of the normal range

F6 outdoor unit T2b temperature sensor malfunction

P0 IPM malfunction or IGBT over-strong current protection

P1 over voltage or over low voltage protection

P2 top temperature protection of compressor

P3 outdoor low temperature protection

P4 compressor protection or malfunction

-- multi split indoor units cooling/heating mode conict

P6 low pressure protection of compressor

For troubleshooting, please refer to outdoor unit factory technical
manual and solution.

outdoor unit compressor discharge temperature sensor TP
malfunction

17 I Installation and Operating Manual

9. Dimensions (mm)

85. 8 56. 36

98. 8

6

7

8

191.5

174.5

149

136.5

9.25

61

55

6

18 I Installation and Operating Manual

Appendix 1: Temperature Sensor Resistance Value Table (°C - kΩ)

°C kΩ °C kΩ °C kΩ °C kΩ

-20 115.266 20 12.6431 60 2.35774 100 0.62973

-19 108.146 21 12.0561 61 2.27249 101 0.61148

-18 101.517 22 11.5000 62 2.19073 102 0.59386

-17 96.3423 23 10.9731 63 2.11241 103 0.57683

-16 89.5865 24 10.4736 64 2.03732 104 0.56038

-15 84.2190 25 10.000 65 1.96532 105 0.54448

-14 79.3110 26 9.55074 66 1.89627 106 0.52912

-13 74.5360 27 9.12445 67 1.83003 107 0.51426

-12 70.1698 28 8.71983 68 1.76647 108 0.49989

-11 66.0898 29 8.33566 69 1.70547 109 0.48600

-10 62.2756 30 7.97078 70 1.64691 110 0.47256

-9 58.7079 31 7.62411 71 1.59068 111 0.45957

-8 56.3694 32 7.29464 72 1.53668 112 0.44699

-7 52.2438 33 6.98142 73 1.48481 113 0.43482

-6 49.3161 34 6.68355 74 1.43498 114 0.42304

-5 46.5725 35 6.40021 75 1.38703 115 0.41164

-4 44.0000 36 6.13059 76 1.34105 116 0.40060

-3 41.5878 37 5.87359 77 1.29078 117 0.38991

-2 39.8239 38 5.62961 78 1.25423 118 0.37956

-1 37.1988 39 5.39689 79 1.21330 119 0.36954

0 35.2024 40 5.17519 80 1.17393 120 0.35982

1 33.3269 41 4.96392 81 1.13604 121 0.35042
2 31.5635 42 4.76253 82 1.09958 122 0.3413
3 29.9058 43 4.57050 83 1.06448 123 0.33246
4 28.3459 44 4.38736 84 1.03069 124 0.32390
5 26.8778 45 4.21263 85 0.99815 125 0.31559

6 25.4954 46 4.04589 86 0.96681 126 0.30754
7 24.1932 47 3.88673 87 0.93662 127 0.29974
8 22.5662 48 3.73476 88 0.90753 128 0.29216
9 21.8094 49 3.58962 89 0.87950 129 0.28482
10 20.7184 50 3.45097 90 0.85248 130 0.27770

11 19.6891 51 3.31847 91 0.82643 131 0.27078
12 18.7177 52 3.19183 92 0.80132 132 0.26408
13 17.8005 53 3.07075 93 0.77709 133 0.25757
14 16.9341 54 2.95896 94 0.75373 134 0.25125
15 16.1156 55 2.84421 95 0.73119 135 0.24512

16 15.3418 56 2.73823 96 0.70944 136 0.23916
17 14.6181 57 2.63682 97 0.68844 137 0.23338
18 13.9180 58 2.53973 98 0.66818 138 0.22776
19 13.2631 59 2.44677 99 0.64862 139 0.22231

19 I Installation and Operating Manual

Notes:

www.systemair.com

Systemai r GmbH ·November 2 020
