EC Vent
User Manual
-EN_GB
15-03-2011V.A-003
Contents
1 Warnings................................................................................................................................... 1
2 Product Description.................................................................................................................... 1
2.1 Room unit ........................................................................................................................ 1
2.1.1 Display Symbols ..................................................................................................... 3
3 Operation .................................................................................................................................. 4
3.1 Before starting.................................................................................................................. 4
3.2 Program overview ............................................................................................................ 4
3.2.1 Navigation .............................................................................................................. 4
3.2.2 User menu.............................................................................................................. 4
3.2.3 User Overview........................................................................................................ 6
3.2.4 User Menu Auto Mode ............................................................................................ 8
3.2.5 Service Menu .........................................................................................................10
3.2.6 Installation .............................................................................................................12
3.2.7 User Interface......................................................................................................... 16
3.2.8 Alarm Menu ............................................................................................................18
3.2.9 Temperature Control ...............................................................................................19
3.2.10 CO
2
Control ..........................................................................................................21
3.2.11 Humidity Control....................................................................................................23
3.2.12 Manual Control .....................................................................................................24
3.2.13 Time Control .........................................................................................................26
3.2.14 Pressure Control ...................................................................................................27
3.2.15 DI Control .............................................................................................................29
3.2.16 Flow Control ......................................................................................................... 31
3.2.17 Slave Control ........................................................................................................33
3.2.18 Heater/Cooler Control............................................................................................34
3.2.19 Output ..................................................................................................................37
3.2.20 Alarm Setting ........................................................................................................ 38
3.3 Set up cases ....................................................................................................................39
3.3.1 Pressure control with outdoor temperature compensation .......................................... 39
3.3.2 Constant a ir volume with CO
2
controlled forced ventilation.........................................42
3.3.3 Manual fixed min. airflow with humidity controlled forced ventilation ...........................45
3.3.4 Fixed rpm with presence detector control..................................................................46
3.3.5 Free cooling with control of room radiator .................................................................47
3.4 Set up of operation schedules ...........................................................................................49
3.4.1 Set up example.......................................................................................................51
1Warnings
The following admonitions will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with
local rules and regulations.
2 Product Description
2.1 Room unit
The objective of the room unit is to display the information provided by the installed sensors and make
it possible for the user to enter desired settings. The room unit is equipped with 2 internal sensors;
Temperature and humidity sensor, which register the temperature and humidity in the location of the
installed room unit. It is possible to connect 2 extra sensors to the internal connection block.
Up to 10 room units can be active simultaneously.
Note:
The installed room units can only be regulated one by one. It is not possible to perform settings on
two or more controls simultaneously!
In order for the room unit to function the control board needs to be installed and connected. See
“Installation Ins tru ction s” for more inform ation.
EC Vent User Manual
1
System
air AB
Fig. 1 Room unit components
Position Description Explanation
1Display
Shows symbols, menus and settings
2
Selection knob
Move through the menu lists or change
settings and values by turning the knob
left or right
3
Confirm button Confirm menu choices or settings by
pressing the button
4 Back button
Step back in the menu levels by
pressing the button
EC Vent User Manual
2
System
air AB
2.1.1 Display Symbols
Symbol
Description Explanation
Fan speed
Illustrates the current set fan speed. The
speed setting is stepless or in steps determined
by the user. The speed is also displayed as
percentage of the maximum fan speed at the
bottom of the display (valid if manual mode is
selected)
Empty symbol equals stopped fan and
completely filled symbol equals maximum
speed (100%)
The fan speed can be set manually by turning
the selection knob while in manual mo de .
Temp set Illustrates the current set temperature.
Temperature icon is connected to the set
point for the heater/cooler. If no heater/cooler
controller is activated the icon indicates the
setting of the first temperature controller for
the fan. If there are no temperature controllers
in the system the temperature icon is not
shown. The temperature is set in steps of 0,5°C
and can be changed manually by turning the
selection knob.
Service Access to the service/setup menu by pressing
the confirmation button
Login to “Service” with “1111” and to “Setup”
with “2222”.
Alarm
Shows only if an alarm is active and not
blocked. Icon is flashing when an alarm is
active
Check box
Used to marked selectable and selected items
(unmarked and marked boxes).
EC Vent User Manual
3
System
air AB
3Operation
3.1 Before starting
Before starting up the system make sure you have checked the following:
• That the equipment is installed according to the installation instructions
• That the correct accessories are used for the intended function
• That you have read and understood this manual.
3.2 Program overview
The program interface is separated in three levels.
• User level is intended to be used by any user of the system. It’s only possible to change a limited
number of parameters
• Service level is intended to be used by persons with some knowledge of the system. For example care
taker or similar
• Installation level is used for advanced setting and is intended for the installation personnel that do the
initial setup of the complete system.
3.2.1 Navigation
The room unit has two buttons and a knob.
• Menu selector (choose function and move in menus)
•Confirm(buttontoconfirm choice)
• Back (button to go back in menu level)
Items in the menu that lead to a sub menu level are marked with >>. Itemsthatleadtoamenuwith
changeable items are marked with>. Changeable Parameters and values in menus are marked with
underscore. When turning the knob the selected value is marked with inverted background colour. The
Confirm button will enable changes of value, this is indicated by flashing the inverted background colour
on and off.
After a value has been changed the change must be confirmed with the Confirm button. If the back button
is used the value will go back to previous. Inactivity for 1 min. is the same as selecting back button.
The display back light will be activated from any user input. The back light goes off after 1 min. of inactivity
except for the adjusting menu where the back light is always on
The password menu has a time out of 15 sec.
3.2.2 User menu
The control mode list shows activated selection. If only manual is chosen and a manual controller is
selected the controller mode menu is not shown
Manual controller setting menu has no time out.
The temperature icon is connected to the set point for the heater/cooler. If no heater/cooler controller is
activated the icon is connected to the first temperature controller for the fan. If there are no temperature
controllers in the system the temperature icon is not shown. The Alarm icon flashes in case of alarm and
an alarm message is shown; if more than one alarm is activated the messages alternate.
In the bottom of the display the actual operate mode is shown.
This can be:
•Auto
• Boost: 00:30 (remaining time counter, in this example the remaining boost time is 30 minutes)
EC Vent User Manual
4
System
air AB
• Extended time: 00:30 (remaining time counter, in this example the remaining extended time is 30
minutes)
•Away
• Manual: (If the controller is set to stepless the fan signal output is shown in %. If step controller is
selected the selected step is shown.) The manual speed is shown if a manual controller is activated and
the system is in auto mode.
3.2.2.1 Sleep Mode
If the sleep mode is activated the system will go to sleep mode 5 min. after last user interaction, except
when the adjusting menu is selected. When the system is in sleep mode any u ser input will change the
system to user menu. If a user password is selected a password question will appear.
3.2.2.2 Operation mode
Boost: When entering the Boost functionadefaulttimeisshownandatimefield is selected for edit.
(Boost speed is equal to 100% fan speed)
Default tim e is set in User interface menu
1. Select a time with the selection knob, confirmthetimeandthetimerstarts
2. Return to main menu with the back button or time out
3. Text Boost and remaining time is shown under the display icons
Extended time: Disables the effect of the schedule. If no schedule is programmed the function is
hidden. Same function and procedure as Boost function.
Away: Activates the away speed. Is Aborted by selection of boost, extended time or auto mode. Away
speed is set in User interface menu.
Auto: Return to Auto mode.
Manual:Activatefixed speed with manual setting. Can be step or stepless. The menu for changing speed
has no time out. The fan speed can be higher than the set manual speed if a separate room unit (up to 10
pcs of RU can be installed) gives a higher signal to the fan.
EC Vent User Manual
5
System
air AB
3.2.3 User Overview
Auto
Monday
12:00
Auto
Password
Service
Setup
xxxx
Password
xxxx
12:00
20°C
Auto
Fan Speed <500RP M
A
B
C
D
E
F
G
Fig. 2 User overview
EC Vent User Manual
6
System
air AB
Table 1: Explanations User overview
Position
Description (figure 2)
A
Shows a warning symbol with the text Fan speed
<500 rpm. Indicates that no fan speed setting has
been made
B
Sleep mode display option.
Will be shown after 5 min. of inactivity if the
function is activated.
C
User p a ssword
Displayed after pressing the confirmat ion button
when standing in sleep mode (section 3.2.6.1)
D
Symbol has different meaning:
If manu al mode is activated (section 3.2.12) the
symbol will change according to the actual fan
speed
If Away, Auto or Boost mode is chosen the symbol
will be fille d accordingly (little, medium, full).
For more info. (section 2.1.1 and section 3.2.4).
E
Symbol has different meaning:
If no temperature control or heater/cooler is used
then the symbol will not be visible
If a heater/cooler is installed the desired working
point of the heater/cooler can be changed here.
If the fan is controlled with the help of a temperature
sensor you can change the desired temperature
between the Max/Min set point here. If a fixed set
point has been chosen the symbol is visible but no
changes can be done (section 2.1.1 and section
3.2.9).
F Push to enter either the installation mode or the
service mode
G Write the password for the mode you want to enter
EC Vent User Manual
7
System
air AB
3.2.4 User Menu Auto Mode
Auto
Fan Speed <500RP M
Setting
Password
Service
xxxx
Away
Auto
Ext ended time
Boost
Manual
Away
Auto
Ext ended time
Boost
Manual
Away
Auto
Extende d time
Boost
Manual
Boost
Duration 00:30
Ext ended time.
Durati on 00:30
Away
Auto
Ext ended time
Boost
Manual
Away
Auto
Ext ended time
Boost
Manual
Fan speed 33%
or
Fan step 1
Set temp /Fixed temp set
A
B
C
D
E
F
G
H
I
Fig. 3 Auto Mode
EC Vent User Manual
8
System
air AB
Table 2: Explanations User menu Auto mode
Position Menu Headline
Description (figure 3)
A
Away
Activate the Away function. For more info.
(section 3.2.2.2 and section 3.2.7).
B
Auto
Abort away, boost or extended time.
The fan will then be controlled by the
installed sensors and/or week schedule.
For more info. (section 3.2.2.2 and section
3.2.6.1).
C
Set temp/Fixed temp set
Change set point of heater/cooler controller
or temperature controlled fan.
D
Setting
Push to enter eith er the installation mode
or the service mode
E
Alarm
Alarm
Symbol appears if there is an active alarm
(section 3.2.8).
F
Extended time
Activate the Extended time function.
For more info. (section 3.2.2.2 and section
3.2.7).
G
Boost
Activate the Boost function. For more info.
(section 3.2.2.2 and section 3.2.7)
H
Manual
If manual mode is chosen the fan can be
controlled in a stepless mode if this mode
is chosen (section 3.2.12).
I
Fan step 1
If manual mode is chosen the fan can be
controlled in a step m o de if this mode is
chosen (section 3.2.12).
EC Vent User Manual
9
System
air AB
3.2.5 Service Menu
Service
• Fan set point adjustment
• Heat er / Cooler s et point
• Tim e and Date
Fan set point
xxx °C / ppm / %Rh / Pa / l/s
Service
• Fan s et point adjust ment
• Heat er / Cooler set point
• Time and Date
Time and dat e
HH
:MM
DDD
Service
• Fan s et point adjust ment
• Heater / Cool er set poin t
• Tim e and Date
Heater / Cooler s et point
xxx °C
Fan set point
Control ler
• 1 Control ler name
• 2 Cont roller name
• 3 Cont roller name
• 4 Cont roller name
• 5 Cont roller name
.
.
.
A
B
C
D
E
Service
• F an set point adjus tment
• H eater / Cooler set poi nt
• T ime and Date
• SW Version
SW Ver CB RU
Main X.X.X X.X.X
Boot X.X.X X.X.X
String X.X.X
• SW Version
• SW Version
• SW Version
F
Fig. 4 Service Menu
Table 3: Explanations
Position Menu Headline
Description (figure 4)
A
Fan set point adjustment
Service menu gives you the possibility to
change some basic features.
B
Controller name
Chose for which controller function you
want to change the set point for. The
different controller functions has to be set
in the installation menu before the appear
here (section 3.2.6).
C
Fan set point
Change the fan set point so that the fan
always works towards achieving the preset
set point. The set point has to be within
the pre-defined range, see section that
corresponds to the desired control mode.
D
Heater/Cooler set point
Choose the desired set point for the
heater/cooler. If no heater/cooler has been
installed this option will not be shown
(section 3.2.18).
EC Vent User Manual
10
System
air AB
Explanations cont'd
Position
Menu Headline
Description (figure 4)
E
Time and Date
Change the time and date
F
SW Version
Software version
EC Vent User Manual
11
System
air AB
3.2.6 Installation
3.2.6.1 Installation-1
Control mode
• Disable
• Tem perature Control
• CO2Control
• Humidity Control
• Pre ssure C ontrol
• Flow C ontrol
• Sl ave Control
Installation
• C ontrollers
• User interface
• Security
• Output
• Alarm Setting
• Addres s
• Adjusting
• Units
Security
• U ser level
• Serv ice Level
• Installation level
Security
• User level
• Service level
• In stallation l evel
Security
• User level
• Ser vice Level
• Installation level
User level
Change Pas sword
Act ual XXXX
New XXXX
Service Level
Change Pas sword
Act ual XXXX
New XXXX
Inst allation lev el
Change Pas sword
Act ual XXXX
New XXXX
Installation
• C ontrollers
• User interface
• Security
• Output
• Al arm Setti ng
• Addres s
• Adjusting
• Units
Installation
• C ontrollers
• User interface
• Secu rity
• Output
• Al arm Setti ng
• Addres s
• Adjusting
• Units
Cont rollers
• Control 1
• Control 2
• Control 3
• Control 4
• Control 5
• Manual Control
• H eater / Cool er Control
• Time Control
• DI Control
Cont rollers
• C ontrol 1
• C ontrol 2
• C ontrol 3
• C ontrol 4
• C ontrol 5
• Manual Control
• H eater/ Cool erC ontrol
• Tim e Control
• DI Control
.
• Calibration
• Calibration
• Calibration
A
B
C
D
E
F
G
H
I
J
Fig. 5 Installation-1
EC Vent User Manual
12
System
air AB
Table 4: Explanations installation-1
Position Menu Headline
Description (figure 5)
A
Installation
Installation, main menu options
B
Controllers
Control 1-5 gives you the possibility to run
thefanwiththehelpof5differentsensors,
either simultaneously or individually. The
fan w ill be controlled by the sensor that
gives the fan the highest out put.
C
Control mode
Choose what kind of control mode for the
fan that will be used.
Slave control allows the fan speed to be
controlled from a main control system
(section 3.2.9, section 3.2.10, section
3.2.11, section 3.2.14, section 3.2.16,
section 3.2.17).
D
Manual control
Heater/Cooler control
Time control
DI control
Manual control – Set if you want the fan to
be manually controlled (section 3.2 .12).
Heater/Cooler control – Set if you want EC
Vent to control a heater or cooler (section
3.2.18).
Time control – Set if you want the fan to be
controlled with a week schedule (section
3.2.13).
Digital control – Set if you want the fan to
be controlled with a digital input, e.g. PIR
sensor (section 3.2.15).
E
User interface
Sets functions that are available in
the user
menu. A disabled function will be hidden.
Setting of the user interface is individual
for each room unit in the syste
m (section
3.2.7).
F
Security
Change password for the different levels in
the system. Password 000
0 disable s the
password question
J
Continuation
EC Vent User Manual
13
System
air AB
3.2.6.2 Installation-2
Installation
• C ontrollers
• User interface
• Security
• Output
• A larm Setting
• Address
• Adjusting
• Units
Installation
• C ontrollers
• User interface
• Security
• Out put
• A larm Set ting
• A ddress
• Adjusting
• Units
Installation
• C ontrollers
• User interface
• Security
• Out put
• A larm Set ting
• Address
• Adjusting
• Units
Adjusting
FS 15-100 %
Board : CB/RU 1/RU 2,,
Internal temp xx °C AI1 xxxx °C / ppm / %Rh / Pa / l/s
Internal Humidity xx %Rh AI2 xxxx°C / ppm / %Rh / Pa / l/s
Installation
• C ontrollers
• User interface
• Security
• Out put
• A larm Set ting
• Address
• Adjusting
• Units
Units
Temperature °C / °F
Pressure Pa / In. wg
Flow l/s / m3/h / m3/s / cfm
Address
RU 01
J
A
B
C
D
Installation
• C ontrollers
• User interface
• Security
• Out put
• A larm Set ting
• A ddress
• Adjusting
• Units
• Calibration
Calibration
Sensor Confirmed
T 20,0 N
RH 47 N
• Calibration
• Calibration
• Calibration
• Calibration
E
Fig. 6 Installation-2
EC Vent User Manual
14
System
air AB
Table 5: Explanations installation-2
Position Menu headline
Description (figure 6)
A
Alarm setting
Output – Possibility to set an output signal
(Digital/Analogue) e.g. Alarm output if fan
speed is to low or analogue (0-10V) signal
to another fan (section 3.2.19).
Alarm settings – Possibility to do a larm
settings (se ction 3.2.20).
B
Address
Set the address for the specific controller.
If several room units are used each unit
needs to have a different address.
C
Adjusting
Gives you the possibility t o manually
control the fan while observing the value
for the different sensors that are used in
the sys tem.
Ideal for finding the correct fan speed (in
%) for a certain air flow or pressure.
D
Units
Possibility to change displayed units
E
Calibration
Possibility to calibrate the internal
temperature and humidity sensor in the
room unit.
EC Vent User Manual
15
System
air AB
3.2.7 User Interface
Us er interface
• S leep mode
• Boost time
• E xtended time
• Away
• Language
Sleep mode
Sleep mode enable / disable
Background Logo / Clock / Temp
Extended time
Dis able / 00 :01-23:59
Boost time
Disable /
00:01-23 :59
Us er interface
• S leep mode
• B oost time
• E xtended time
• Away
• Language
Us er interface
• S leep mode
• Boost time
• E xtended ti me
• Away
• Language
Us er interface
• S leep mode
• Boost time
• E xtended time
• Away
• Language
Away
Speed off / 15-100 %
Enable / D isable
Us er interface
• S leep mode
• Boost time
• E xtended time
• Away
• Language
Language
English
A
B
C
D
E
Fig. 7 User Interface
EC Vent User Manual
16
System
air AB
Table 6: Explanations User interface
Position Menu headline
Description figure 7)
A
Sleep mode
Choose if sleep mode should be enabled or
disabled. If enabled, choose what should
be displayed when the room unit goes in to
sleep mode (5 min.)(section 3.2.3).
B
Boost time
Boost tim e gives the user the possibility
from the user menu ( section 3.2.4) to
setthefantoafixed speed for a certain
amount of time.
Set if Boost time should be able or disabled.
If able – choose also the pre-defined time
that the fan should be in boost mode.
C
Extended time
Extended time gives the user the possibility
from the user menu ( section 3.2.4) to
extend the On time that is defined in the
chapter Time control (section 3.2.13) for at
certain amount of time.
Set if Extended time should be able
or disabled. If able – choose also the
pre-defined time that the fan should be
extended.
D
Away
Away function gives t he user the poss ibility
from the user menu ( section 3.2.4) to set
the sys tem to a fixed s peed. Switching
from Away mode to another m ode has to
be done manually.
E
Language
Set language
EC Vent User Manual
17
System
air AB
3.2.8 Alarm Menu
N Alarm
Alarm 1 fan speed <500 RPM
Mon 12:00
Alarm active / not active
Reset /
Block
A
B
C
D
E
F
Fig. 8 Alarm Menu
Position Description
A
Indicates number of active alarms
B
Shows the reason for the alarm
C Shows weekday and time when the alarm occurred
D
Shows if the alarm is active or not active
E
Reset the alarm if it is no longer a c tive, i.e. if the reason for the alarm
has been fixed
F It is possible t o block an active alarm. A block
ed alarm will automatically
be activated after 1 minute of corrected para
meters.
EC Vent User Manual
18
System
air AB
3.2.9 Temperature Control
Temperature C ontrol
• Sensor
• Control Function
• Min/max speed
• PI setting
• Set point
Sensor
Board: CB/RU 1/RU 2.
.
Channel : 1/2/ 3/Int
Control functi on
Higher s peed at
higher temperat ure /
Lower speed at
higher temperat ure
Min/max speed
Max 15-100
%
Min Off / 15 -100
%
Temperature C ontrol
• Sensor
• Control Function
• Min/max speed
• PI setting
• Set point
Temperature C ontrol
• Sensor
• Control Function
• Min/max speed
• PI setting
• Set point
PI setting
P-band xx
°C
I-time 1-600
sek / off
Temperature C ontrol
• Sensor
• Control Function
• Min/max speed
• PI setting
• Set point
Temperature C ontrol
• Sensor
• Control Function
• Min/max speed
• PI setting
• Set point
Set point
Range
/ Fixed
Max xxx°C
Min xxx
°C
.
A
B
C
D
E
Fig. 9 Temperature Control
EC Vent User Manual
19
System
air AB
Table 7: Explanations Temperature control
Position Menu headline
Description (figure 9)
A
Sensor
Set where the temperature sensor is being
connected or if the internal sensor is being
used. If an external sensor is being used
there are 5 different analogue inputs to
choose from, 2 on the room unit and 3 on
the control board.
External sensor must be type PT1000.
B
Control function
Set what kind of control function you want
C
Min/max speed
Set then min/max speed of the fan. This
will be the min/max speed that the fan
will reach when it’s controlled by the
temperature control function for this given
sensor.
D
PI setting
Set the desired P-band and I-time.
Higher values give a slower controller and
less risk for self-oscillation and vice versa.
E
Set point
Set th e desired set point. The set point
could either be fixed or it could be a range.
If the set point is fixed the user can’t do any
changes from user or service menu; if the
set point is a range the user can change
the set point within the boundaries (sec
tion
3.2.4).
EC Vent User Manual
20
System
air AB
3.2.10 CO2Control
CO2Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
Min/max speed
Max 15-100
%
Min Off / 15-100
%
CO2Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
Sensor range
Min xxxx
ppm
Max xxxx
ppm
CO2Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
PI setting
P-band xxxx
ppm
I-time 1-600
sek / off
CO2Control
• Sensor
• Min/max speed
• PI setting
• Set point
CO2Control
• Sensor
• Min/max speed
• PI setti ng
• Set point
Set point
Range
/ Fixed
Max xxxxppm
Min xxxxppm
Sensor
Board: CB/RU 1 /RU 2.
.
Channel : 1/2/3
A
B
C
D
E
Fig. 10 CO2-Control
EC Vent User Manual
21
System
air AB
Table 8: Explanations CO2control
Position Menu headline
Description (figure 10)
A
Sensor
Set where the CO
2
sensor is being
connected; there are 5 different analogue
inputs to choose from, 2 on the room unit
and 3 on the control board.
If a CO
2
sensor with a switching contact is
being used DI control should be used.
B
Sensor range
Set the measurement range of the sensor
C
Min/max speed
Set then min/max speed of the fan. This
will be the min/max speed that the fan
will reach when it’s controlled by the CO
2
control function for this given sensor.
D
PI setting
Set the desired P-band and I-time.
Higher values give a slower controller and
less risk for self-oscillation and vice versa.
E
Set point
Set th e desired set point. The set point
could either be fixed or it could be a range.
If the set point is fixed the user can’t do any
changes from user or service menu; if the
set point is a range the user can change
the set point within the boundaries (section
3.2.5).
EC Vent User Manual
22
System
air AB
3.2.11 Humidity Control
Humidity Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
Humidity Control
• Sensor
• Min/max speed
• PI setting
• Set point
Sensor range
Min xxx
%Rh
Max xxx
%Rh
Humidity Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
Min/max speed
Max 15-100
%
Min Off / 15-100
%
PI setting
P-band xx x%Rh
I-time 1-600
sek / off
Set point
Range
/ Fixed
Max xxxx%Rh
Min xxxx%Rh
Humidity Control
• Sensor
• Min/max speed
• PI setting
• Set point
Humidity Control
• Sensor
• Min/max speed
• PI setti ng
• Set point
Sensor
Board: CB/RU 1/RU 2..
Channel : 1/2/3/int
A
B
C
D
E
• Sensor range
• Sensor range
• Sensor range
Fig. 11 Humidity Control
EC Vent User Manual
23
System
air AB
Table 9: Explanations humidity control
Position Menu headline
Description (figure 11)
A
Sensor
Set where the humidity sensor is being
connected or if the internal sensor is being
used. If an external sensor is being used
there are 5 different analogue inputs to
choose from, 2 on the room unit and 3 on
the control board.
B
Sensor range
Set the measurement range of the sensor
C
Min/max speed
Set then min/max speed of the fan. This
will be the min/max speed that the fan will
reach when it’s controlled by the humidity
control function for this given sensor.
D
PI setting
Set the desired P-band and I-time.
Higher values give a slower controller and
less risk for self-oscillation and vice versa.
E
Set point
Set th e desired set point. The set point
could either be fixed or it could be a range.
If the set point is fixed the user can’t do any
changes from user or service menu; if the
set point is a range can the user change
the set point within the boundaries (section
3.2.5).
3.2.12 Manual Control
Manual C ontrol
• Mode
• Setting
Manual C ontrol
• Mode
• Setting
Step
Number of st ep x
1Off/ 15 -100%
2Off
/ 15 -100%
3 Off / 15-100%
4 Off / 15-100%
5Off
/ 15 -100%
Min/max speed
Max 15-100%
Min Off / 15-100%
Mode
Step /Stepless/Disable
or
A
B
C D
E
Fig. 12 Manu al control
EC Vent User Manual
24
System
air AB
Table 10: Explanations Manual control
Position Menu headline
Description (figure 12)
A
Mode
Activate the manual control mode
B
Step/Stepless/Disable
Choose if you want the fan to be controlled
manually (3 to 5 steps) or stepless. The
user can then change the fan speed
accordantly from the User menu (section
3.2.4).
Choose also if the manual control mode
should be disabled. If this is done the
“Manual” possibility in the User menu
(section 3.2.4) will not be visible.
C
Setting
Decide on the different settings for the
step/stepless control mode
D
Step
If manual control with step mode is set,
decide how many steps the manual control
should have and which fan speed each
step should correspond to.
E
Min/max speed
If manual control with stepless mode is set,
decide the min/max speed of the fan than
can be achieved with the manual mode.
EC Vent User Manual
25
System
air AB
3.2.13 Time Control
Schedul e
Schedul e 1-14
Clear Y /N
On HH :MM DDD
Off HH :MM DDD
Fixed S peed / s et point xxxx°C / ppm / %Rh / %
A
D
F
B
C
E
Fig. 13 Time Control
Table 11: Time control
Position Menu headline
Description (figure 13)
A
Schedule
Up to 14 different schedules can be
programmed.
All schedules refer to controller 1.
B
On
Set the time you want the schedule
to be in On mode
C
Off
Set the time you want the schedule
to be in Off mode
D
Mon
Set day or period of days. Choose
between;
• Mon, Tue, Wed, Thu, Fri,
Sat, Sun, i.e. each week day
• Mon-Fri
• Sat-Sun
• Ev-Day, i.e. every week day.
E
Speed
Set the fixed speed you want the
fantohaveduringtheOnperiod.
This setting overrides the setup
speed of the fan during the On
period.
Note:
ThespeedcanalsobesettoOff. If
so the period the fan is in Off mode
is between the programmed On and
Off time in the schedule.
F
Clear
By choosing Y you erase the time
settings for the current schedule.
See further information concerning time control in “Set up of operation schedules”
(section 3.4).
EC Vent User Manual
26
System
air AB
3.2.14 Pressure Control
Press ure Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
• Set point displacement
Press ure Control
• Sensor
• Sensor range
• Min/m ax speed
• PI setting
• Set point
• Set point displacement
Sensor range
Min xxx
Pa
Max xxx
Pa
Press ure Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
• Set point displacement
Min/max speed
Max 15-100
%
Min Off
/ 15 -100%
PI setting
P-band xxxx
Pa
I-time 1-600
sek / off
Set point
Range
/ Fixed
Max xxxPs
Min xxx
Ps
Press ure Control
• Sensor
• Min/max speed
• PI setting
• Set point
• Set point displacement
Press ure Control
• Sensor
• Min/max speed
• PI setti ng
• Set point
• Set point displacement
Press ure Control
• Sensor
• Min/max speed
• PI setting
• Set point
• Set point displacement
Cont rol Board
Cont rol board A I1/ AI 2 / AI3
Set point
displacement
• Sensor
• Setting
Set point
displacement
• Sensor
• Setting
Set point displacement
Start xx
°C
Stop xx
°C
Displacement +-xxxx
Pa
Sensor
Board: CB/RU 1/RU 2..
Channel : 1/2/3
A
B
C
D
E
F
G
H
I
Fig. 14 Pressure Control
EC Vent User Manual
27
System
air AB
Table 12: Explanations Pressure control
Position Menu headline
Description (figure 14)
A
Sensor
Set where the pressure sensor is being
connected; there are 5 different analogue
inputs to choose from, 2 on the room unit
and 3 on the control board.
B
Sensor range
Set the measurement range of the sensor,
e.g. 0–200 Pa.
C
Min/max speed
Set then min/max speed of the fan. This
will be the min/max speed that the fan will
reach when it’s controlled by the pressure
control function for this given sensor.
D
PI setting
Set the desired P-band and I-time.
Higher values give a slower controller and
less risk for self-oscillation and vice versa.
E
Set point range
Set th e desired set point. The set point
can either be fixed or it can be a range.
If the set point is fixed the user can’t do
any changes from user or service menu;
if the set point is a range the user can
change the set point within the boundaries
(10%-90% of the current sensor range),
(section 3.2.5).
Note:
If pressure displacement is intended to
be used the min. value in the set poin
t
range needs to be adjusted to include the
desired pressure decrease value. E.g.
a displacement of -50 Pa usin
g 0–200
Pa sensor would have to increase the
min. value 20+50 = 70 Pa in order for the
pressure set point to be ab
le to decrease
50 Pa.
F
Set point displa
cement
Setting if the press
ure set point shall
be adjusted according to measured
temperature. E.g. if the ventilation
shall be reduce
d in case of low outdoor
temperature. See above explanation under
Set point range.
G
Sensor → Control board
Set where t
he displacement sensor is
being connected; there are 3 different
analogue inputs on the control board.
H
Setting
Choos
e the different settings for the set
point displacement
I
Set point displacement
Start sets from what temperature the
p
ressure set point shall start to change.
Stop sets at what temperature the changes
of set point reaches the max displacement.
Displacement sets the maximum
displacement of the pressure set point.
EC Vent User Manual
28
System
air AB
3.2.15 DI Control
Functi on
Go to fi xed speed /Change set point /auto mode
New setpoint / speed xxx °C / ppm / %Rh / l/s / or Off / 15-100%
DI control X
• Input
• Funct ion
• NO/NC
• Delay
• Enable
DI control X
• Input
• Function
• NO/NC
• Delay
• Enable
DI ac tivated i f
input are
Open / C losed
Delay
On H H
:MM:SS
Off H H:MM:SS
Sensor
Board: CB/RU 1/RU 2..
Channel : 1/2/3
DI control X
• Input
• Funct ion
• NO/NC
• Delay
• Enable
DI c ontrol X
• Input
• Funct ion
• NO/NC
• Delay
• Enable
DI control X
• Input
• Funct ion
• NO/NC
• Delay
• Enable
Enable
Dis able/Enable
DI Control
• DI 1
• DI 2
• DI 3
DI Control
• DI 1
• DI 2
• DI 3
DI Control
• DI 1
• DI 2
• DI 3
A
B
C
D
E
F
G
H
Fig. 15 DI-Control
Table 13: Explanations DI control
Position Menu headline
Description (figure 15)
A
DI 1
Do the required settings for D
I1
B
DI 2
Do the required settings for DI 2
C
DI 3
Do the required settings for DI 3
D
Input → Sensor
Set where the digi
tal input is being
connected; there are 5 different digital
inputs to choose from, 2 on the room unit
and 3 on the cont
rol board.
E
Function → Function
Choose the desired action when the DI is
active
F
NO/NC → DI activated if input
is Open/Closed
Choose
if the DI is normally closed (NC) or
normally open (NO)
EC Vent User Manual
29
System
air AB
Explanations DI control cont'd
Position Menu headline
Description (figure 15)
G
Delay → Delay
Choose if you want the desired action
(PositionE)tobedelayedfromthetime
that the DI in being activated. 00:00:00
means that the required action will start
immediately when the DI is activated.
Choose also the time that the desired
action will continue after the DI signal
is inactivated. 01:00:00 means that the
desired action will continue for one hour
after the digital signal has been inactivated.
If the signal is activated before the timer is
finished the time will be reset.
H
Enable → Enable
Enable or Disable the specificDI
EC Vent User Manual
30
System
air AB
3.2.16 Flow Control
Flow Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
• Set point displacement
Flow Control
• Sensor
• Min/max speed
• PI setting
• Set point
• Set point displacement
Sensor range
Max xxx
l/s
Scale Linear
/ exponential
Flow Control
• Sensor
• Sensor range
• Min/max speed
• PI setting
• Set point
• Set point displacement
Min /max speed
Max 15-100
%
Min Off
/ 15 -100%
PI setting
P-band x xxx
l/s
I-time 1-600
sek / off
Set point
Range
/ Fixed
Max xxxxl/s
Min xxxx
l/s
Flow Control
• Sensor
• Min/max speed
• PI setting
• Set point
• Set point dis placement
Flow Control
• Sensor
• Min/max speed
• PI setting
• Set point
• Set point displacement
Set point
displacement
• Sensor
• Setting
Set point
displacement
• Sensor
• Setting
Flow Control
• Sensor
• Min/max speed
• PI setting
• Set point
• Set point displacement
Control Board
Control board AI 1 / A I2 / AI3
Set point displacement
Start xx
°C
Stop xx
°C
Displacement +-xxxx
l/s
Sensor
Board: CB/RU 1/RU 2.
.
Channel : 1/2/3
A
B
C
D
E
F
G
H
I
• Sensor range
• Sensor range
• Sensor range
• Sensor range
Fig. 16 Flow control
EC Vent User Manual
31
System
air AB
Table 14: Explanations Flow control
Position Menu headline
Description (figure 16)
A
Sensor
Set where the flow sensor is being
connected; there are 5 different analogue
inputs to choose from, 2 on the room unit
and 3 on the control board.
B
Sensor range
Set the measurement range of the sensor
and the type.
Linear is used in case an air velocity
sensor is being used
Select Exponential in case a differential
pressure sensor connected to a damper
with a given k-factor is being used. In this
case use the formula Q = k x √∆P, w h e r e Q
is the airflow, k is the k-factor and ∆Pisthe
pressure difference, to determine the air
flow range.
C
Min/max speed
Set then min/max speed of the fan. This
will be the min/max speed that the fan
will reach when it’s controlled by the flow
control function for this given sensor.
D
PI setting
Set the desired P-band and I-time.
Higher values give a slower controller and
less risk for self-oscillation and vice versa.
E
Set point
Set th e desired set point. The set point
could either be fixed or it could be
a range.
If the set point is fixed the user can’t do
any changes (section 3.2.5).
F
Set point displacement
Setting if the flow set point
shall be adjusted
according to measured temperature. E.g.
if the ventilation shall be reduced in case
of low outdoor temper
ature.
G
Setting
Set where the displacement sensor is
being connected; there are 3 different
analogue inputs
on the control board.
H
Sensor → Ce
ntral board
Choose the different settings for the set
point displacement.
I
Set p
oint displacement
Start se
ts from what temperature the flow
set point shall start to change.
Stop s
et at what temperature the
changes of set point reach the maximum
displacement.
Displacement sets the maximum
displacement of the flow set point.
EC Vent User Manual
32
System
air AB
3.2.17 Slave Control
Slav e Control
• Input
• Min / Max speed
Slav e Control
• Input
• Min / Max speed
Min/max speed
Max 15-100
%
Min Off / 15-100
%
Sensor
Board: CB/RU 1/RU 2.
.
Channel : 1/2/ 3
A
B
Fig. 17 Slave control
Table 15: Explanations Slave control
Position Menu headline
Description (figure 17)
A
Input
Set where the input signal is being
connected; there are 5 different analogue
inputs to choose from, 2 on the room unit
and 3 on the control board.
B
Min/Max speed
Set then min/max speed of the fan. This
will be the min/max speed that the fan will
reach when it’s slave controlled for this
given sensor
EC Vent User Manual
33
System
air AB
3.2.18 Heater/Cooler Control
3.2.18.1 Heater/Cooler Control part 1
Temperature C ontrol
• S ensor
• Out put
• C ontrol Funct ion
• PI setting
• Set point
• M in/max temperature sens or
• Min /Max temperature
• M in flow s hut off
• Enable
Output
Cont rol board AO1
/
AO2 / AO 3
Control function
Cooling/ H eating
Temperature C ontrol
• Sensor
• Outpu t
• C ontrol Funct ion
• PI setting
• Set point
• M in/max temperature sensor
• Min /Max t emperature
• M in flow s hut off
• Enable
Temperature C ontrol
• Sensor
• Out put
• C ontrol Function
• PI setting
• Set point
• M in/max temperature sens or
• Min /Max temperature
• M in flow s hut off
• Enable
PI setting
P-band x xx
°C
I-tim e 0.1-600
sek / off
Set point
Range
/ Fixed
Max xxx°C
Min xxx
°C
Temperature C ontrol
• Sensor
• Out put
• C ontrol Funct ion
• P I setting
• Set point
• M in/max tem perature sensor
• Min /Max t emperature
• M in flow s hut off
• Enable
Temperature C ontrol
• Sensor
• Out put
• C ontrol Funct ion
• PI setting
• Set point
• M in/max tem perature sensor
• Min /Max t emperature
• M in flow s hut off
• Enable
Temperature C ontrol
• Sensor
• Out put
• C ontrol Funct ion
• PI setting
• Set point
• M in/max temperature sen sor
• Min/Max t emperature
• M in flow s hut off
• Enable
Sensor
Board : CB/RU 1/RU 2..
Channel : 1/2/3/ Int
Sensor
Board : CB/ RU 1/RU 2 ..
Channel : 1 /2/3
A
B
C
D
E
F
G
Fig. 18 Heater/Cooler control-1
EC Vent User Manual
34
System
air AB
Table 16: Explanations Temperature control
Position Menu headline
Description (figure 18)
A
Sensor
Set where the temperature sensor that
will be the controlling sensor is being
connected.
There are 5 different analogue inputs to
choose from, 2 on the room unit and 3 on
the control board.
This sensor could be e.g. a room sensor.
B
Output
Set which out put signal is being used.
C
Control function
Set the desired control function.
D
PI setting
Set the desired P-band and I-time.
Higher values give a slower controller and
less risk for self-oscillation and vice versa.
E
Set point
Set th e desired set point. The set point
could either be fixed or it could be a range.
If the set point is fixed the user can’t do any
changes, see chapter 3.2.5
F
Min/Max temperature sensor
Set where the min/max temperature sensor
is being connected; there are 5 different
analogue inputs to choose from, 2 on the
room unit and 3 on the control board.
This sensor could be e.g. a duct sensor.
G Continuation to the next chart
EC Vent User Manual
35
System
air AB
3.2.18.2 Heater/Cooler Control part 2
Temperature C ontrol
• Sensor
• Output
• C ontrol Function
• PI setting
• Set point
• Min/max temperature sensor
• Min/Max temperature
• Min speed shut off
• Enable
Min/Max temperature
Min No limit
/ +-xxx°C
Max No limit
/ +-xxx°C
Temperature C ontrol
• Sensor
• Output
• C ontrol Function
• PI setting
• Set point
• Min/max t emperature sens or
• Min/Max temperature
• Min speed shut off
• Enable
Min speed Shut off
No limit
/ Off / 15-100%
Enable
Dis able/Enable
Temperature C ontrol
• Sensor
• Output
• C ontrol Function
• PI setting
• Set point
• Min/max t emperature sens or
• Min/Max temperature
• Min speed s hut off
• Enable
A
B
C
G
Fig. 19 Heater/coo
ler control-2
Table 17: Explanations Temperature control
Position Menu headline
Description (
figure 19)
A
Min/Max temperature
Set the min/max temperature. This
min/max limit will be controlled by the
temperatu
re sensor that is installed unde r
position F (table 16)
B
Min sp
eed shut off
Set the fan speed value for when the
heate
r/cooler should shut down
C
En
able
Set if the Heater/Cooler function is enabled
or disabled.
G Continuation from previous chart
EC Vent User Manual
36
System
air AB
3.2.19 Output
Output
• Out 1
• Out 2
• Out 3
Out 1
• Type
• Ev ent
• Enabl e
Out 1
• Type
• Even t
• Enabl e
Type
0-10V/ DO
Follow Fan speed
Offs et
+- 0- 100
%
Fan speed t hreshold
On if Ov er/Under
10-100 %
Out 2
• Type
• Event
• Enabl e
Out 2
• Type
• Even t
• Enabl e
Type
0-10V/ DO
Out 3
• Type
• Ev ent
• Enabl e
Out 3
• Type
• Event
• Enabl e
Type
0-10V/DO
Output
• Out 1
• Out 2
• Out 3
Output
• Out 1
• Out 2
• Out 3
Follow Fan speed
Offs et
+- 0- 100
%
Follow Fan s peed
Offset
+- 0-100
%
Out 1
• Type
• Ev ent
• Enable
Enable
Dis able/Enable
Out 2
• Type
• Ev ent
• Enable
Enable
Dis able/Enable
Out 3
• Type
• Ev ent
• Enable
Enable
Dis able/Enable
Fan speed t hreshold
On if Ov er/Under
10-100 %
A
B
C
Fan speed t hreshold
On if Ov er/Under
10-100 %
D
E
F
G
B
C
D
E
B
C
D
E
Fig. 20 Output
Table 18: Explanations Output
Position Menu headline
Description (figure 20)
A
Out 1
Settings for output 1
B
Type
Set the type of signal; analogue or digital
C
Event
If analogue signal is chosen under position
A; Set t
he desired offset value. E.g. if -10%
is chosen and the master fan is working
at 80% the output signal will be 10% less,
i.e.
70% (7V).
EC Vent User Manual
37
System
air AB
Explanations Output cont'd
Position Menu headline
Description (figure 20)
D
Enable
Set if the output function for this specific
output is enabled or disabled.
E
Fan speed threshold
If digital signal is chosen under position A;
Chose at what fan speed the digital signal
should be activated. E.g. When fan speed
is below 10% the digital signal can work
as an alarm.
F
Out 2
Settings for output 2
G
Out 3
Settings for output 3
3.2.20 Alarm Setting
Analogue alarm
Alarm 1 / 2 / 3
Board: CB/RU 1/RU 2. .
Channel : 1/2/3/ Int Temp / Int Hum id
< Disable / XXX°C / ppm / %Rh / % / Pa / l/s > Disable / XXX°C / ppm / %Rh / % / Pa / l/s
Alarm
• Fan speed
• Anal ogue inpu t
• Digital input
• Battery
Alarm
• Fan speed
• Analogue input
• Digital input
• Battery
Fan speed
Min D isable / 100- 1000
RPM
Digital input
• Input
• Funct ion
Digital input
• Input
• Function
Digital input
Alarm if high / low
Alarm
• Fan speed
• Analogue input
• Digital input
• Battery
Sens or
Board: CB/RU 1/RU 2.
.
Channel : 1/2/ 3/Int
Alarm
• Fan speed
• Analogue input
• Digital i nput
• Battery
Battery
Yes/No
A
B
C
D
E
F
Fig. 21 Alarm setting
EC Vent User Manual
38
System
air AB
Table 19: Explanations Alarm
Position Menu headline
Description (figure 21)
A
Fan speed
Set at what fan speed (rpm) the fan speed
alarm should be triggered.
B
Analogue input
Set the alarm limits for the different sensors
that have been installed.
C
Digital input
Set the alarm setting for the digital inputs
that have been installed.
D
Input
Choose where the digital signal is being
connected.
E
Function
Choose when the alarm should be
triggered
F
Battery
3.3 Set up cases
Below set up cases describe some of the most common regulation examples. All the cases assume that the
room unit and control board have been installed and connected according to the installation instructions.
3.3.1 Pressure control with outdoor temperature
compensation
Youwouldlikethefantokeepaconstantpressureintheductanddecreasethesetductpressurewith
50 Pa in case the outdoor temperature drops to -10°C or lower. The user should be able to set the duct
pressure within a determined range.
It should also be possible to turn off the fan with an external potential free switch, for example a timer.
For this set up you need the following:
• One pressure sensor
• One Temperature sensor (PT1000)
• One potential free on/off switch, e.g. timer.
Do the installation according to below procedure:
1 Install pressure sensor and temperature
sensor
Install the pressure sensor in the ventilation duct
and the outdoor temperature sensor. Connect the
pressure sensor to the control board to IN 1 (pos.
B) and the temperature sensor to IN2 (pos. C).
EC Vent User Manual
39
System
air AB
2 Service icon
Select the service icon in the main menu screen.
3Setup
Select Set up to enter into the Installation menu.
4 Controllers
Select Controllers.
5 Control 1
Select Control 1.
6 Pressure
Go down to and select Pressure.
7 Sensor
Select CB (control board) and channel 1 by turning the selection knob and confirm. The screen should
now show CB 1. Step back to the previous frame with the back button.
8 Sensor range
Set Min and Max pressure according to the range of the press ure sens
or, for example Min0Paand
Max 200 Pa. Step back to the previous frame with the back button.
9 Min/Max speed
Set Min and Max speed. For example Min 15% and Max 100%. Step back to the previous frame
with the back button.
10 PI setting
Set P-band and I-time. Higher values give a slower more
stable control. R ecommended settings are
P-band 200 Pa, and I-time 60 sek if a pressure sensor with a range of 0–200 Pa has been
installed.
11 Set point range
Choose if the set point should be fixed or a range (table 12). range can be set within 10–100% of
the sensor range.
Set desired Min and Max pressures (default is 20–180 Pa). In order for this set up to work the min.
value needs to be set to 70 Pa, see below e
xplanation (step 13) or above example (table 12.)
Step back to the previous frame with the back button.
12 Set point displacement/Sensor
Set which AI the temperature sensor is connected to on the control board. You will be able to choose
between I2 and I3 since I1 is occu
pied by the pressure sensor. Choose I2, since the temperature
sensor is connected to IN2.
EC Vent User Manual
40
System
air AB
13 Set point displacement/Setting
Set between which temperatures you want the pressure dis pla ce ment. Set Start for example to
0,0 °C and Stop to -10 °C.
Set the Displacement to -50 Pa.
Note:
This is only possible if the value in the set point range is adjusted to include the desired pressure
decrease value. E.g. a displacement of -50 Pa using 0–200 Pa sensor would have to increase the min.
value 20+50 = 70 Pa in order for the pressure set point to be able to decrease 50 Pa.
Press the back button until you reach the main menu start screen.
3.3.1.1 Turn off the unit with an external switch
In this example we use the input terminals on the room unit to connect an external on/off switch for the
installed system.
Do the installation according to below procedure:
1 Connect switch
Connect a potential free on/off switch, for example
a timer, (pos. 1) to I1 and 24V on the room unit.
2 DI Control
Go to Controllers under Installation and scroll down to DI Control
3DI1
Select DI1
4 Input
Select Input
5RU01
Select RU 01 (room unit no. 1) and channel I1.
Step back to the pre
vious frame with the back button.
EC Vent User Manual
41
System
air AB
6 Function
Select Function
7Off
Select Fixed speed and choose New speed off
%
8NO/NC
Go to NO/NC and Select Closed
Note:
The switch needs to be closed in order for this to function.
(see “Explanations DI control” (table 13) for more info.
Press the back button until you reach the main menu start screen.
3.3.2 Constant air volume with CO2controlled forced
ventilation
Youwantthefantoproduceaconstantairflow which can be set by the user in the room unit. With help of
aCO
2
sensor mounted in the ventilated area the fan should go to set maximum speed after a certain fixed
ppm value has been reached.
For this set up you need the following:
• One air s peed sensor
•OneC0
2
sensor for wall mounting
Do the installation according to below procedure:
EC Vent User Manual
42
System
air AB
1 Install air speed sensor and CO2sensor
Install the air s peed sensor in the ventilation duct
and the CO
2
sensor in the ventilated area. Connect
the air speed sensor to the control board to IN 1
(pos. B) and the CO
2
sensor to RU 1 (I1) on the
room unit.
2 Service icon
Select the service icon in the main menu screen.
3Setup
Select Set up to enter into the Installation menu.
4 Controllers
Select Controllers.
5 Control 1
Select Control 1.
6Flow
Scroll down to Flow and s
elect it by pressing the confirm button, see overview (section 3.2.16).
7 Sensor
Select Sensor and then
choose CB I1.
Step back to the previous frame with the back button.
EC Vent User Manual
43
System
air AB
8 Sensor range
Select Sensor range and set the maximum airflow for the air speed sensor in l/s.
Note:
The range of the analogue air speed sensor is normally given in m/s written on the sensor label. You
have to calculate the l/s depending on the actual duct diameter where the sensor is situated. For
example a maximum air speed of 10 m/s in a 200 mm circular duct would give 314 l/s based on the
formula A x V x 1000, where A is the duct cross section area in m² and V is the air velocity in m/s.
Set if the sensor scale is linear, i.e. if an air velocity sensor is used, or exponential, in case a differenti
al
pressure sensor connected to a damper is being used (section 3.2.16). Default is Linear.
Step back to the previous frame with the back button.
9 Min/Max speed
Set Min and Max speed. For example Min 15% and Max 100%.
Step back to the previous frame with the back button.
10 PI setting
Set P-band and I-time. Higher values give a slower more stable contro
l. Recommended (default)
settings are P-band 300 l/s,andI-time 10 sek if an air speed sensor with a range of 0–300
l/s has been installed.
Step back to the previous frame with the back button.
11 Set point range
Set the air flow range in which it’s possible for the user to set a constant airflow. Default is 10–90% of the
sensor range, i.e. with a sensor range of 0–300 l/s the default setting is Min 30 l/s and Max 270 l/s
If Fixed is chosen the Min and Max value are the same, i.e. the value can’t be changed by the user.
Press the back button until you reach the men
uscreenshowingFlow and a filled check box.
12 Control 2
Step dow n to Control 2 and confirm.
13 CO
2
Select CO2and confirm, see overview
(section 3.2.10).
14 Sensor
Select RU 01 channel I1
Step back to the previous frame with the back button.
15 Sensor range
Set the ppm range of the CO
2
sensor, for example Min 0 ppm and Max 2000 ppm
Step back to the previous frame with the back button.
EC Vent User Manual
44
System
air AB
16 Min/Max speed
Set Min and Max speed. For example Min 15% and Max 100%.
Step back to the previous frame with the back button.
17 PI setting
Set P-band and I-time. Set P-band 200 ppm,andI-time to Off
since the sensor set point will be
fixed.
Step back to the previous frame with the back button.
18 Set point range
SetthesetpointtoFixed at Min and Max to 1000 ppm. I.e. the fan will increase the set speed
to maximum within the range of 900–1100 ppm
Press the back button until you reach the main menu screen.
3.3.3 Manual fixed min. airflow with humidity controlled
forced ventilation
Youwanttheusertobeabletosetafixed min. airflow and a humidity s et point within a defined range
(20%–50%). The fan should operate at the fixed min. speed and go to forced speed controlled by the
humidity set point. The fan should then operate steplessl
ywithinadefined range.
For this set up you use the humidity sensor which is integrated in the room unit.
Do the installation according to below procedure:
1 Manual
Go to Controllers and scroll down to Manual.Confirm.
2Mode
Select Mode and continue with choosing Stepless.
Step back to the previous frame with the back button.
3Setting
Go to Setting and set min. and max speed to for example Min 20 % and Max 50 %.
4 Controllers
Go back to Controllers and select Control 1.Confirm
5 Humidity
Scroll down to Humidity and confirm.
6 Sensor
Select sensor RU 01 Internal
Step back to the previous frame with the back button.
EC Vent User Manual
45
System
air AB
7 Sensor range
Set the sensor range to Min 10% and Max 90%
Step back to the previous frame with the back button.
8 Min/Max speed
Set Min and Max speed. For example Min 15% and Max 100%.
Step back to the previous frame with the back button.
9 Set point range
Set the set point to Range, Min 20 % and Max 50 %. The user will now be able to choose a humidity
set point in this interval.
Press the back button until you reach the main menu screen.
3.3.4 Fixed rpm with presence detector control
You would like the fan to keep a constant rpm (in this case 40% of the max speed) and force the fan to go
to max speed (100 %) with the help of a PIR (presence indicator). The fan should continue on max speed
with a 30 minute delay after the presence indicator stops indicatin
g movement (DI contact open).
For this set up you need the following accessory:
• One PIR (presence indicator)
Do the installation according to below procedure:
1 Install the PIR (presence indicator)
Install the PIR (presence indicator) (pos. A) in t
he
ventilated space and connect it to RU 1 (I1) on the
room unit.
2 Manual
Go to Controllers and scr
oll down to Manual.Confirm.
Step back to the previous frame with the back button.
3Mode
Select Mode and conti
nuewithchoosingStepless.
Step back to the previous frame with the back button.
EC Vent User Manual
46
System
air AB
4Setting
Go to Setting and set min. and max speed to for example Min 40% and Max 40%. The user will now
only be able to set the manual speed of the fan to 40%.
5 Controllers
Go back to Controllers,selectDI Control andgoontoselectingDI1.Confirm
Step back to the previous frame with the back button.
6 Input
Go to Input and continue with choosing RU 01 I1
Step back to the previous frame with the back button.
7 Function
Go to Function and continue with choosing Go to Fixed FS and New speed 100%
Step back to the previous frame with the back button.
8NO/NC
Go to NO/NC and choose Closed. The fan will now go to set max speed when the DI closes.
Step back to the previous frame with the back button.
9 Delay
Go to Delay and set On to 00 : 00 : 00 and Off to 00 : 30: 00. A 30 minute delay has
now been set.
Press the back button until you reach the main menu screen.
3.3.5 Free cooling with control o f room radiator
This application is meant for cooling or heating of Telecom cabinets. You want the temperature in the
cabinet to have a min. set point of +5°C and a max set point of +23°C. The lower set point is controlled
with a radiator and the higher set point is controlled with the cooling of a fan controlled by the internal
temperature sensor in the room unit.
For this set up you need the following accessory:
• One Temperature sensor (PT1000)
Do the installation according to below procedure:
EC Vent User Manual
47
System
air AB
1 Install the temperature sensor
Install the temperature sensor used for the control
of the radiator in the ventilated space and connect
it to the control board on IN 1 (pos. B).
2 Temperature control cooling
Start with the control function, which controls the fan speed for the c
ooling of the space. The o bjective is
to keep the upper set point and start the fan if cooling is required.
Go to set up and choose Controllers
3 Temperature
Choose Control 1 and select Temperature.
4 Sensor
Go to Sensor and choose RU 01 Internal
. The internal temperature sensor in the room unit has
now been chosen.
Step back to the previous frame with the back button.
5 Control function
Go to Control function and select Cooling
Step back to the previous frame with the
back button.
6 Min/max speed
Go to Min/max speed and select Min Off
and Max 100%. This ensures that the fan will only start
when there is a need for cooling.
Step back to the previous frame w
ith the back button.
7 PI setting
Go to PI setting and choose P-band 10°C and I-time 60 sek (default).
Step back to the previous fr
ame with the back button.
8 Set point
Go to Set point range and se
lect Fixed.SetMax and Min to 23°C.
Step back to Installation menu frame by pressing the back button twice.
EC Vent User Manual
48
System
air AB
9 Heating control
Go to Heater/Cooler and select Sensor.
10 Sensor
Choose CB I1.
Step back to the previous frame with the back button.
11 Output
Go to Output and select Control Board AO1.
Step back to the previous frame with the back button.
12 Control function
Go to Control function and select Heating.
Step back to the previous frame with the back button.
13 PI setting
Go to PI Setting,selectP-band 5°C and I-time 60 sek (default).
Step back to the previous frame with the back button.
14 Set point range
Go to Set point range,selectFixed and 5,0°C
Step back to the previous frame with the back button.
15 Min. speed shut off
Go to Min. speed shut off an d select No limit.
Step back to the main menu frame with the back button
.
3.4 Set up of operation schedules
The week schedule is used if you want the fan to operate differently from how controller 1 is setup during a
specific time of the day, e.g. if you want
the system to be turned off during a certain time of the day or
go to a different set point, e.g. forced ventilation.
It is po ssible to set up to 14 tim e s
chedules for Controller 1. The settings in the week schedule overrides
the settings determined in the setup of the system or the set point made by the user.
Note:
Make sure time and date has bee
n set in the service menu.
Below table (table 20) di
splays examples of different possible settings.
EC Vent User Manual
49
System
air AB
Table 20: Operation schedule examples
Example Description
On 07:00 Mon
Off 16:00 Mon
Speed 50 %
The system runs at 50% speed 07:00 on Monday and stays like that
until 16:00 the same day.
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up the rest of the week.
On 07:00 Mon
Off 16:00 Wed
Speed 50 %
The system runs at 50% speed 07:00 on Monday and stays like that
until 16:00 on Wednesday.
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up rest of the week.
On 19:00 Mon
Off 07:00 Mon
Speed Off %
The system is turned off at 19:00 on Monday and stays like that until
07:00 the following Monday, i.e. the system is turned off the entire
week.
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up between 07:00 and
19:00 on Monday.
On 07:00 Mon-Fri
Off 16:00 Mon-Fri
Speed 50 %
The system runs at 50% speed 07:00 on Monday and stays like that
until 16:00 the same day. This activity is repeated each day until
Friday, which is the last day of the period.
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up at 16:00 until 07:00
the following day during this period.
The system will also run according to original setup from Friday at
16:00 until Monday 07:00.
On 19:00 Mon-Fri
Off 09:00 Mon-Fri
Speed Off %
The system is turned off at 19:00 on Monday and stays like that until
09:00 the following day. A result of this setup is also that the system
will be turned off at 19:00 on Friday until 09:00 the following Monday.
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up between 09:00 and
19:00 on Monday. This is repeated each day until Friday.
On 09:00 Sat-Sun
Off 20:00 Sat-Sun
Speed 50 %
The system runs at 50% speed 09:00 on Saturday and stays like that
until 20:00 the same day. This activity is repeated on Sunday
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up at 20:00 until 09:00
the following day during this period.
The system will also run according to original setup from Sunday at
20:00 until Saturday 09:00.
On 21:00 Sat-Sun
Off 09:00 Sat-Sun
Speed Off %
The system is turned off at 21:00 on Saturday and stays like that until
09:00 Sunday. A result of this setup is also that the system will be
turned off at 21:00 on Sunday until 09:00 the following Saturday.
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up between 09:00 and
21:00 on Saturday and on Sunday.
On 09:00 Ev-Day
Off 20:00 Ev-Day
Speed 50 %
The system runs at 50% speed 09:00–20:00 every weekday
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up at 20:00 until 09:00
each day during this period.
On 21:00 Ev-Day
Off 09:00 Ev-Day
Speed Off %
The system is turned off 21:00–09:00 every w eekday
If nothing else is set in the rest of the 13 possible schedules the
system goes back to how it was originally set up at 09:00 until 21:00
each day during this period.
EC Vent User Manual
50
System
air AB
3.4.1 Set up example
we will use the set up case based on above example “Pressure control with outdoor temperature
compensation” (section 3.3.1).
In this imagined example you want the week program to achieve the following result:
• Monday to Friday the system should go to maximum speed between 07:00–09:00
• Monday to Friday 09:00–18:00 the system should operate according to above setup case (section
3.3.1.) with the pressure set point determined by the user
• Monday to Friday the system should be turned off at 18:00
• During Saturday and Sunday 09:00–22:00 you want the fan to operate at 30% and be turned off at 22:00
Do the setup according to below procedure:
1Setup
Go to the service icon and select Setup
2 Time C ontrol
Choose Controllers and scroll down to Time Control.Byconfirming
you enter into the Schedule
setup menu.
3 Schedule 1
Start programming Schedule 1.
Set On 07:00 Mon-Fri, Off 09:00 Mon-Fri and Speed 100
%.
The fan will now work at 100% speed between 07:00 and 09:00 Monday to Friday regardless of what
has been set in the setup procedure for the system o
r chosen user set point.
4 Schedule 2
Go to Schedule 2.
Set On 18:00 Mon-Fri, Off 07:00 Mon-Fri and Speed Off %.
The Off period for the system is now started at 18:00 and stopped at 07:00 Monday to Friday. The
system will also be in Off mode Friday 18:00 to Monday 07:00 after this schedule has been programmed.
Since there is no active setting done in the schedule between 09:00–18:00 Monday to Friday the
system will operate according to setup parameters (section 3.3.1) and according to user set point
during this period.
Note:
The Off period needs to be determined with an On and Off time as well.
5 Schedule 3
Go to Schedule 3.
Set On 09:00 Sat-Sun, Off 22:00 Sat-Sun and Speed 30 %.
The system will operate at 30% speed 09:00–22:00 Saturday to Sunday. This is possible since this
time schedule was programmed after the activity determined by schedule 2. After 22:00 on Saturday
and Sunday the sy
stem will go back to Off mode since the activity determined in schedule 2 will again
become active.
Step back to th
emainmenuframewiththebackbutton.
EC Vent User Manual
51
System
air AB
The Time control function check box is filled whenever there is a n active schedule. It is disabled by
erasing all settings in each programmed schedule or if there is no active schedule at the time. Erasing the
schedules is easiest done by selecting Clear Y in the u pper right corner of the schedule display.
EC Vent User Manual
52
System
air AB
EC Vent User Manual
53
System
air AB
lastpage
Systemair AB reserves the right to make changes and improvements to the contents
of this manual without prior notice.
Systemair AB
Industrivä
gen 3
SE-739 30 Skinnskatteberg, Sweden
Phone +46 222 440 00
Fax +46 222 440 99
www.systemair.com
Loading...
