Declaration of Performance
AJR(B), AJ8(B) / F300
(120)
Mechanical smoke and heat extraction device;
Smoke extract axial fan series AJR(B), AJ8(B);
Nominal diameter: 315-400 mm;
Class: F300 (120)
1 (3)
GB
Systemair GmbH
Seehöfer Straße 45
97944 Boxberg
The international research laboratory Applus in Barcelona (authorised testing authority N° 0370) has determined the
characteristics of the product after an initial test. The authorised testing authority BSI (N° 2797) has carried out an initial
factory inspection and a factory production control according to system 1 of the Construction Products Regulation. The
testing authority carries out ongoing monitoring, assessment and evaluation of the factory production control and issued
the certificate 2797-CPR-719672.
Declared performance
The declared performance, described in appendix ZA of the standards DIN EN 12101-3; 2015 have been applied and the
product fulfills all following, essential characteristics.
Systemair·GmbH,·Seehöfer·Straße·45,·97944·Boxberg,·Germany
Phone: +49 (0) 7930 9272 0 Fax: +49 (0) 7930 9272 92 -en_GB-
Declaration of Performance
2 (3)
Performance
Features
Mechanical smoke and heat extraction devices (fans) and flexible connections
Classification
[X]
[X]
[X]
[ ]
[ ]
[ ]
a)
The result of the product testing was a minimum duration of 120 min.
1. Temperature load direction
FEI
FEI
FEI
FEI
FEI
FEI
200
250
300
400
600
842
1)
120
120
120
120
60
30
a)
[ ] I -> OAoutside buildings without
insulation
[ ] I -> O
[ ] I -> O
outside buildings with insulation
AI
inside buildings, outside fire room
G
without insulation
[ ] I -> O
inside buildings, outside fire
GI
room with insulation
[X] I <- -> O inside the fire room
2. Installation position*
1)
Harmonised Technical
Specification
[X] h horizontal axis, floor installation
[X] h
[X] h
[X] v
[X] v
3. Flexible connection
horizontal axis, wall installation Exception: Fans with B3
W
horizontal axis, ceiling installation Exception: Fans with B3
D
vertical axis, pressure Exception: Fans with motors
dpup
vertical axis, suction Exception: Fans with motors
dpdo
1)
[ ] eSflexible connection suction side
[ ] e
[ ]
flexible connection pressure side
D
e
flexible connection suction /
S,D
pressure side
[ ] e
4. Cooling air
1)
[ ] c
flexible connection cooling air
Sair
Volumetric flow cooling air Air = min. volumetric flow q = max.
Air,q
cooling air temperature
5. Starting type
[X]
6. Snow load
1)
AA or MA (automatic or manual)
1)
motors from IEC 160
motors from IEC 160
from IEC 160
from IEC 160
DIN EN 12101-3; 2015
[ ] SL0 without deflector
[ ]
Systemair·GmbH,·Seehöfer·Straße·45,·97944·Boxberg,·Germany
Phone: +49 (0) 7930 9272 0 Fax: +49 (0) 7930 9272 92 -en_GB-
SL121
